WiebeTech BayDock 800 Manual

B a yD o c k 8 0 0 Ad d e n d u m - 1 -
BayDock FireWire 800 Addendum
July 3, 2007
Single BayDock:
The FireWire 800 version of the Single BayDock will vary from the example shown in the manual.
The Differences are:
1. There are no audio outputs.
2. Added a USB port and included a USB cable.
3. The Access light is now a Power Indicator light only.
Dual BayDock (Single Bridge):
The FireWire 800 version of the Dual BayDock (Single Bridge version) will vary from the example
shown in the manual. The Differences are:
1. Hard disk drives must have jumpers set to one Master and one Slave. It does not
matter which Drive Tray goes in which Bay, as long as the drives are not both set to
Master.
2. Added a USB port and included a USB cable.
3. Included one 9-Pin to 9-Pin FireWire 800 cable to use for connecting to a host or Daisy
Chaining with other FireWire 800 devices.
Dual BayDock (Dual Bridge):
The FireWire 800 version of the Dual BayDock (Dual Bridge version) will vary from the example
shown in the manual. The Differences are:
1. Both hard disk drives may be set to Master since each has a unique FireWire Bridge.
2. Added a USB port to each Bridge and included two USB cables.
3. Includes two 9-Pin to 9-Pin FireWire 800 cables to use for connecting to a host or
Daisy-Chaining the two FireWire Bridges.
For technical support please contact support@wiebetech.
