WIKA TC82-F Installation manual

EN
FR
DE
ES
Additional information
Zusatzinformation
Informations complémentaires
Información adicional
Additional information for hazardous areas (Ex d)
Models TC82, TC83
Zusatzinformation für explosionsgefährdete Bereiche (Ex d)
Typen TC82, TC83
Informations complémentaires concernant les zones explosives
(Ex d), types TC82, TC83
Información adicional para zonas potencialmente explosivas (Ex d)
Modelos TC82, TC83
Models TC82-F Models TC83-F

EN
DE
2
14302226.02 10/2020 EN/DE/FR/ES
WIKA additional information TC82, TC83, flameproof enclosure (Ex d)
FR
ES
Additional information models TC82, TC83 (Ex d) Page
3 - 16
Zusatzinformation Typen TC82, TC83 (Ex d) Seite
17 - 30
Informations complémentaires types TC82, TC83 (Ex d) Page
31 - 44
Información adicional modelos TC82, TC83 (Ex d) Página
45 - 57
© 09/2020 WIKA Alexander Wiegand SE & Co. KG
All rights reserved. / Alle Rechte vorbehalten.
WIKA®is a registered trademark in various countries.
WIKA®ist eine geschützte Marke in verschiedenen Ländern.
Prior to starting any work, read the operating instructions!
Keep for later use!
Vor Beginn aller Arbeiten Betriebsanleitung lesen!
Zum späteren Gebrauch aufbewahren!
Lire le mode d‘emploi avant de commencer toute opération !
A conserver pour une utilisation ultérieure !
¡Leer el manual de instrucciones antes de comenzar cualquier trabajo!
¡Guardar el manual para una eventual consulta!

Declarations of conformity can be found online at www.wika.com.
1. Ex marking 4
2. Safety 5
3. Commissioning, operation 7
4. Special conditions for use (X conditions) 14
Appendix: EU declaration of conformity 15
EN
14302226.02 10/2020 EN/DE/FR/ES
WIKA additional information TC82, TC83, flameproof enclosure (Ex d) 3
Contents
Contents

EN
14302226.02 10/2020 EN/DE/FR/ES
WIKA additional information TC82, TC83, flameproof enclosure (Ex d)4
1. Ex marking
DANGER!
Danger to life due to loss of explosion protection
Non-observance of these instructions and their contents may result in the
loss of explosion protection.
▶
Observe the safety instructions in this chapter and further explosion
instructions in these operating instructions.
▶
Follow the requirements of the ATEX directive.
▶
Observe the information given in the applicable type examination
certificate and the relevant regulations for installation and use in
hazardous areas (e.g. IEC 60079-0, IEC 60079-1, IEC 60079-10 and
IEC 60079-14).
Check whether the classification is suitable for the application. Observe the relevant
national regulations.
With case and connection terminals With separately certified transmitter
ATEX: II 2/-G Ex db IIC T6 ...T1 Gb/- II 2/-G Ex db IIC Gb
IECEx: Ex db IIC T6 ...T1 Gb/- Ex db IIC Gb/-
Variant Electrical
data
Temperatures Marking
Ambient 1) Temperature class
Variant 1:
Empty
enclosure
Umax = 30 V -40 ... +85 °C
-60 ... +85 °C
T5 ...T1 II 2/-G Ex db IIC T5-T1 Gb/-
-40 ... +80 °C
-60 ... +80 °C
T6 II 2/-G Ex db IIC T6 Gb/-
Variant 2:
Empty
enclosure
+ electro-
nic
Umax = 30 V
Pmax = 2 W
-40 ... +85 °C
-60 ... +85 °C
T4 ...T1 II 2/-G Ex db IIC T4-T1 Gb/-
-40 ... +75 °C
-60 ... +75 °C
T5 II 2/-G Ex db IIC T5 Gb/-
-40 ... +55 °C
-60 ... +55 °C
T6 II 2/-G Ex db IIC T6 Gb/-
Variant 3:
Transmitter
See
transmitter 3)
See transmitter 3) See transmitter 3) II 2/-G Ex db IIC Gb/-
1) For variant 1 and 2: The low ambient temperature -40 °C applies to models with Limatherm or Rosemount cases.The low ambient
temperature of either -40 °C or -60 ° C applies to models with WIKA connection head series 1/4000, 5/6000, 7/8000. For explanation
of symbols for low temperature range see chapter 2.5 “Labelling, safety marks”
2) The temperature class depends on the ambient temperature.
3) The parameters for “Variant 3: Transmitter” have to be taken out of the related manual.
1. Ex marking
Supplementary documentation:
▶
This additional information for hazardous areas applies in conjunction with the
operating instructions “Resistance thermometers (RTD) and thermocouples (TC)”
(article number 14150915).

EN
14302226.02 10/2020 EN/DE/FR/ES
WIKA additional information TC82, TC83, flameproof enclosure (Ex d) 5
When there is a built-in transmitter and/or a digital display, the special conditions from the
type examination certificate (see chapter 4 “Special conditions for use (X conditions)”)
apply.
2. Safety
2.1 Explanation of symbols
DANGER!
... indicates a potentially dangerous situation in the hazardous area that can
result in serious injury or death, if not avoided.
2.2 Intended use
The thermometers described here are suitable for temperature measurement in hazardous
areas like e.g. sulphur recovery units (SRU).
The electrical thermometer model TC8x-F is made of a module (model TC8x-M), which is
fitted to an Ex d certified case.The module consists of the flange assembly with ceramic
tubes, all parts of electrical insulation of the thermocouple wires and a gas-tight bushing to
limit the flameproof area.
The sensing part of the module is made of ceramic insulated thermocouple wires.
The thermometer/module will be mounted to an Ex d or Ex db certified case manufactured
by WIKA series 1/4000F, 7/8000 or 5/6000.The case and covers are made of stainless
steel or aluminum.The cover could be optionally provided with a glass lens (window).
Alternatively, the thermometer will be mounted to other certified cases or assemblies
as listed in the “WIKA ATEX and IECEx Ex-d housing and device list” (article no.
14405410.01).
3 different variants are available:
■
Variant 1: The thermometer is fitted to a certified empty case in the type of protection
“flameproof enclosure”.Terminals are mounted inside the case.
■
Variant 2: The thermometer is fitted to a certified empty enclosure in the type of
protection “flameproof enclosure”. Electronic equipment is mounted inside the case.
■
Variant 3: The thermometer is fitted to a certified apparatus (transmitter) in the type of
protection “flameproof enclosure”.The thermometer is marked II 2/-G Ex db IIC Gb/-.
1. Ex marking / 2. Safety

EN
14302226.02 10/2020 EN/DE/FR/ES
WIKA additional information TC82, TC83, flameproof enclosure (Ex d)6
The non-observance of the instructions for use in hazardous areas can lead to the loss
of the explosion protection. Adhere to the following limit values and instructions (see data
sheet).
Possible sensor measuring ranges:
-40 ... +1,700 °C
2.3 Responsibility of the operator
The responsibility for classification of zones lies with the plant operator and not the
manufacturer/supplier of the equipment.
2.4 Personnel qualification
The skilled electrical personnel must have knowledge of ignition protection types,
regulations and provisions for equipment in hazardous areas.
2.5 Labelling, safety marks
Additional product label (example)
Approval-related data
Symbol for the usability of the instrument in ambient temperatures down to -60 °C

TÜV 10 ATEX 555793 X
IECEx TUN 10.0002X
II 2 G Ex ib IIC T1 ... T6 Gb
Tamb see manual
********ATEX ******
IECEx ************
II 2/-G Ex db IIC T6 ... T1 Gb/-
Tamb see manual
WARNING! DO NOT OPEN WHILE ENERGIZED!
Ex d
Ex i
2. Safety

EN
14302226.02 10/2020 EN/DE/FR/ES
WIKA additional information TC82, TC83, flameproof enclosure (Ex d) 7
3. Commissioning, operation
DANGER!
Danger to life from explosion
Through working in flammable atmospheres, there is a risk of explosion
which can cause death.
▶
Only carry out set-up work in non-hazardous environments!
▶
Do not open the instrument while under voltage.
DANGER!
Danger to life from explosion
By using a measuring insert without a suitable connection head (case), an
explosion risk occurs which can cause fatalities.
▶
Only use the measuring insert in the connection head designed for it.
DANGER!
Danger to life due to loss of explosion protection
If the allowable thread gaps and the corresponding tightening torques are not
observed, this can lead to a loss of the explosion protection.
▶
Ensure the number of engaged threads in accordance with chapter 3.8
and the tightening torques in accordance with chapter 3.2.
Observe the special conditions (see chapter 4 “Special conditions for use (X conditions)”).
3.1 Mechanical mounting
With pre-assembled connection heads, the direct threaded connection of the thermometer
to the connection head or case must not be twisted or opened. Any alignment of the case
may only be made using the optional “nipple-union-nipple” neck tube.
Certified and listed field cases (variant 3) should only be fitted and installed by a specialist
trained to the latest technological standards.
3. Commissioning, operation

EN
14302226.02 10/2020 EN/DE/FR/ES
WIKA additional information TC82, TC83, flameproof enclosure (Ex d)8
3. Commissioning, operation
3.2 Tightening torques
Connection head, selectable (example)
Thread Tightening torques in Nm
Connection head material
Aluminium Stainless steel
1/2 NPT T.F.F.T 2 - 3 1) T.F.F.T 2 - 3 1)
3/4 NPT T.F.F.T 2 - 3 1) T.F.F.T 2 - 3 1)
M20 x 1.5 with counter nut 23 25
M24 x 1.5 with counter nut 27 30
Thread Tightening torques in Nm
Connection head material
Aluminium Stainless steel
1/4 NPT T.F.F.T 2 - 3 1) T.F.F.T 2 - 3 1)
Tightening torques between connection head and neck tube
Tightening torques between purge connection and purge piping
■
Only ever screw in, or unscrew, the instrument via the spanner flats and to the
prescribed torque using an appropriate tool.
■
The correct torque depends on the dimensions of the connection thread and the sealing
used (form/material).
■
When screwing in or unscrewing the instrument, do not use the connection head as
contact surface.
■
When screwing in the instrument, please observe that the threads are not skewed.
■
Assure that the purge gas connection is tighten and no gas can escape, so that there is
no carry-through between zones.
1) Turns from finger tight (T.F.F.T)

EN
14302226.02 10/2020 EN/DE/FR/ES
WIKA additional information TC82, TC83, flameproof enclosure (Ex d) 9
3. Commissioning, operation
3.3 Locking screw
Always tighten the locking screw to prevent unintended opening
of the head with flameproof enclosure.
Before opening the head, always loosen the locking screw
sufficiently.
3.4 Electrical mounting
■
For the installation of the thermometer, only components (e.g. cables, cable glands,
etc.) permitted for “flameproof enclosure” may be used.
■
Using a transmitter/digital display (option):
- Observe the contents of these operating instructions and those of the transmitter/
digital display (see scope of delivery).
- Observe the relevant regulations for installation and use of electrical systems, and also
the regulations and guidelines for explosion protection.
■
The temperature resistance of the connecting cables, the connection heads, the
cable entries and if necessary the blanking connectors shall be at least as high as the
maximum permissible ambient temperature and shall be at least as low as the minimum
permissible ambient temperature.
■
Do not fit any batteries or capacitors into the flameproof case.
■
Mounting within metallic enclosures:
The case must be grounded against electromagnetic fields and electrostatic charge.
It must not be connected separately to the equipotential bonding system. It is sufficient
if the process connection has a solid and secured contact with the metal vessel or its
structural components or pipelines, so long as these components are connected to the
equipotential bonding system.
■
Mounting within non-metal vessels:
All electrically conductive thermometer components within the hazardous area must be
provided with equipotential bonding.

EN
14302226.02 10/2020 EN/DE/FR/ES
WIKA additional information TC82, TC83, flameproof enclosure (Ex d)10
3.5 Overview of temperature zones and safety-related instructions for the different
variants
3. Commissioning, operation
Legend:
Connection head
Neck tube
Metal support tube
Ceramic thermowell
Terminal block
Transmitter (option)
Field transmitter
A (NL) Nominal length
U Insertion length
X Support tube length below process
connection
U: Insertion length / Einbaulänge
X: Support tube length below process connection /
Halterohrlänge unterhalb Prozessanschluss
Legend / Legende:
1. Connection head / Anschlusskopf
2. Neck tube / Halsrohr
3. Metal support tube / Metallisches Halterohr
4. Ceramic thermowell / Schutzrohr
5. Terminal block / Klemmsockel
6. Transmitter (option) / Transmitter (optional)
7. Field transmitter / Feldtransmitter
A (NL): Nominal length / Nennlänge
14294554.01
X
U
ØF4
ØF
A (NL)
2
4
3
X
U
ØF4
ØF
A (NL)
X
U
ØF4
ØF
A (NL)
X
U
ØF4
ØF
A (NL)
2
4
3
2
4
3
2
4
3
1
1
6
5
7
U: Insertion length / Einbaulänge
X: Support tube length below process connection /
Halterohrlänge unterhalb Prozessanschluss
Legend / Legende:
1. Connection head / Anschlusskopf
2. Neck tube / Halsrohr
3. Metal support tube / Metallisches Halterohr
4. Ceramic thermowell / Schutzrohr
5. Terminal block / Klemmsockel
6. Transmitter (option) / Transmitter (optional)
7. Field transmitter / Feldtransmitter
A (NL): Nominal length / Nennlänge
14294554.01
X
U
ØF4
ØF
A (NL)
2
4
3
X
U
ØF4
ØF
A (NL)
X
U
ØF4
ØF
A (NL)
X
U
ØF4
ØF
A (NL)
2
4
3
2
4
3
2
4
3
1
1
6
5
7
Purge (option,
only TC82)
Purge
(option,
only TC82)
Purge (option,
only TC82)
Purge (option,
only TC82)
Marking
per drawing
14343616
Marking per drawing
14343616
Marking per drawing
14343616
Marking
per drawing
14343616
Marking:
Part of TC83-F
Serial number
Process
connection
Process
connection
Process
connection
Process
connection
14294554.01
14294554.01
Variant 1 without transmitter
Model TC83-F
Basic module
Model TC83-M
Variant 2 with transmitter
Model TC83-F
Variant 3 with field transmitter
Model TC83-F

EN
14302226.02 10/2020 EN/DE/FR/ES
WIKA additional information TC82, TC83, flameproof enclosure (Ex d) 11
3.5.1 Variant 1
The thermometer is fitted to a certified enclosure with “flameproof enclosure” ignition
protection type, which has a terminal block built into it.
Detection and conversion of the thermoelectric voltage by means of an electronic module
outside of the hazardous area.
Marking: II 2/-G Ex db IIC T6 ...T1 Gb/-
The flameproof case or the connection head is in zone 1 (or zone 2).The sensor is located
in a non Ex zone.
A heating in the connection head does not occur with variant 1. However, an impermissible
heat reflux from the process which can exceed the operating temperature of the case or
the temperature class, must be prevented through suitable heat insulation or a suitably
long neck tube.
3.5.2 Variant 2
The thermometer is fitted to a certified enclosure with “flameproof enclosure” ignition
protection type, which has an electronic assembly built into it.
The signal is a current signal (4 … 20 mA), voltage signal (0 … 10 V) or fieldbus signal,
which is generated from a head-mounted transmitter.
3. Commissioning, operation
14387940.01
TC82 TC83
Zone 1
Model TC82 Model TC83
Zone 1
T > 400 °C:
Non-Ex area
T > 400 °C:
Non-Ex area

EN
14302226.02 10/2020 EN/DE/FR/ES
WIKA additional information TC82, TC83, flameproof enclosure (Ex d)12
3. Commissioning, operation
Marking: II 2/-G Ex db IIC T6 ...T1 Gb/-
The flameproof case or the connection head is in zone 1 (or zone 2).The sensor is located
in a non Ex zone.
For all WIKA connection heads with built-in WIKA temperature transmitters, the
following interrelation is valid:
The temperature increase on the surface of the connection head or case is less than 25 K
if the following conditions are observed: Power supply UBmaximum DC 30 V when the
transmitter is operated in a current limitation of 22.5 mA.
A heating in the connection head can occur with variant 2 through faulty electronics. The
permissible ambient temperatures depend on the case used and any additionally fitted
head-mounted transmitter.
However, an impermissible heat reflux from the process which can exceed the operating
temperature of the case or the temperature class, must be prevented through suitable heat
insulation or a suitably long neck tube.
3.5.3 Variant 3
The thermometer is fitted to certified equipment (transmitter) with an ignition protection
type of “flameproof enclosure”.
The signal is a current signal (4 … 20 mA), voltage signal (0 … 10 V) or fieldbus signal,
which is generated by an ATEX/IECEx Ex d certified field transmitter.
Only field transmitters listed by name in the appendix of the Ex d certificate may be used.
Marking: II 2/-G Ex db IIC Gb/-
The flameproof case or the connection head is in zone 1 (or zone 2).The sensor is located
in a non Ex zone.
The main marking for models TC82/TC83 is found on the certified connection housing or
Ex d field transmitter.
3.6 Electrical mounting
Using a transmitter/digital display (option):
Observe the contents of the operating instructions for the transmitter/digital display (see
scope of delivery).
The permissible ambient temperature ranges can be taken from the corresponding
operating instructions.
Observe the special conditions (see chapter 4 “Special conditions for use (X conditions)”,
point 3).

EN
14302226.02 10/2020 EN/DE/FR/ES
WIKA additional information TC82, TC83, flameproof enclosure (Ex d) 13
Electrical connection values
■
Variant 1
Umax = DC 30 V (depending on the operating system)
Use in methane atmospheres
As a result of the higher Minimum Experimental Safe Gap (MESG) and Minimum
Ignition Current (MIC) of methane, the instruments can also be used in hazardous gas
atmospheres caused by this.
■
Variant 2
Umax =DC 30 V
Pmax =2 W
■
Variant 3
Umax = depending on the transmitter/digital display
Pmax = in the case: depending on the transmitter/digital display
3.7 Temperature carry-over from the process
Prevent any heat reflux from the process!
Observe the special conditions (see chapter 4 “Special conditions for use (X conditions)”).
3.8 Thread gap
For fitting, the following permitted thread gaps for electrical equipment for gas hazardous
areas must be maintained:
■
Thread gap for parallel threads (IEC/EN 60079-1, table 4):
Case volumes ≤ 100 cm³: ≥ 5 mm
Case volumes > 100 cm³: ≥ 8 mm
There must be at least 5 threads engaged
■
Thread gap for tapered threads (IEC/EN 60079-1, table 5):
on each component ≥ 5
There must be at least 4.5 threads engaged
3. Commissioning, operation

EN
14302226.02 10/2020 EN/DE/FR/ES
WIKA additional information TC82, TC83, flameproof enclosure (Ex d)14
4. Special conditions for use (X conditions)
1) The thermometers shall be fitted to Ex d certified enclosures series 1/4000 F,
series 7/8000 or series 5/6000, manufactured by WIKA. Alternatively, the thermometers
shall be fitted to other certified enclosures as listed in the “WIKA ATEX and IECEx Ex d
enclosure and device list” (article no.: 14405410.01)
2) A prohibited heat reflow from the process has to be prevented for instance by heat
insulation or using an extended neck tube. A prohibited heat reflow occurs if the heat out
of the process exceeds the service temperature of the enclosure or the temperature class.
3) The widths of the flameproof joint of this apparatus are in parts longer and its gaps are
in parts smaller than required by Table 3 of IEC 60079-1:2014.
4) The conditions for safe use and the installation instructions listed in the certificate of the
equipment (transmitter) and empty enclosures must be carefully observed, too.
4. Special conditions for use (X conditions)

EN
14302226.02 10/2020 EN/DE/FR/ES
WIKA additional information TC82, TC83, flameproof enclosure (Ex d) 15
Appendix: EU declaration of conformity

EN
14302226.02 10/2020 EN/DE/FR/ES
WIKA additional information TC82, TC83, flameproof enclosure (Ex d)16

Konformitätserklärungen finden Sie online unter www.wika.de.
1. Ex-Kennzeichnung 18
2. Sicherheit 19
3. Inbetriebnahme, Betrieb 21
4. Besondere Bedingungen für die Verwendung (X-Conditions) 28
Anlage: EU-Konformitätserklärung 29
DE
WIKA Zusatzinformation TC82, TC83, druckfeste Kapselung (Ex d) 17
14302226.02 10/2020 EN/DE/FR/ES
Inhalt
Inhalt

DE
WIKA Zusatzinformation TC82, TC83, druckfeste Kapselung (Ex d)18
14302226.02 10/2020 EN/DE/FR/ES
1. Ex-Kennzeichnung
GEFAHR!
Lebensgefahr durch Verlust des Explosionsschutzes
Die Nichtbeachtung dieser Inhalte und Anweisungen kann zum Verlust des
Explosionsschutzes führen.
▶
Sicherheitshinweise in diesem Kapitel sowie weitere Explosionshinweise
in dieser Betriebsanleitung beachten.
▶
Die Anforderungen der ATEX-Richtlinie beachten.
▶
Die Angaben der geltenden Baumusterprüfbescheinigung sowie die
jeweiligen Vorschriften zur Installation und Einsatz in explosionsgefähr-
deten Bereichen (z. B. IEC 60079-0, IEC 60079-1, IEC 60079-10 und
IEC 60079-14) einhalten.
Überprüfen, ob die Klassifizierung für den Einsatzfall geeignet ist. Die jeweiligen nationalen
Vorschriften und Bestimmungen beachten.
Mit Gehäuse und Anschlussklemmen Mit separat zertifiziertem Transmitter
ATEX: II 2/-G Ex db IIC T6 ...T1 Gb/- II 2/-G Ex db IIC Gb
IECEx: Ex db IIC T6 ...T1 Gb/- Ex db IIC Gb/-
Variante Elektrische
Daten
Temperaturen Kennzeichnung
Umgebung 1) Temperaturklasse
Variante 1:
Leergehäu-
se
Umax = 30 V -40 ... +85 °C
-60 ... +85 °C
T5 ...T1 II 2/-G Ex db IIC T5-T1 Gb/-
-40 ... +80 °C
-60 ... +80 °C
T6 II 2/-G Ex db IIC T6 Gb/-
Variante 2:
Leerge-
häuse +
Elektronik
Umax = 30 V
Pmax = 2 W
-40 ... +85 °C
-60 ... +85 °C
T4 ...T1 II 2/-G Ex db IIC T4-T1 Gb/-
-40 ... +75 °C
-60 ... +75 °C
T5 II 2/-G Ex db IIC T5 Gb/-
-40 ... +55 °C
-60 ... +55 °C
T6 II 2/-G Ex db IIC T6 Gb/-
Variante 3:
Transmitter
Siehe
Transmitter 3)
Siehe
Transmitter 3)
Siehe Transmitter 3) II 2/-G Ex db IIC Gb/-
1) Für die Varianten 1 und 2: Die niedrige Umgebungstemperatur von -40 °C gilt für Typen mit Limatherm- oder Rosemount-Gehäusen.
Die niedrige Umgebungstemperatur von entweder -40 °C oder -60 °C gilt für Typen mit WIKA-Anschlusskopf der Baureihen 1/4000,
5/6000, 7/8000. Zur Symbolerklärung für den Tieftemperaturbereich siehe Kapitel 2.5 „Beschilderung, Sicherheitskennzeichnungen“
2) Die Temperaturklasse hängt von der Umgebungstemperatur ab.
3) Die Parameter für „Variante 3: Transmitter“ sind aus dem zugehörigen Handbuch zu entnehmen.
1. Ex-Kennzeichnung
Ergänzende Dokumentation:
▶
Diese Zusatzinformation für explosionsgefährdete Bereiche gilt im Zusammenhang mit
der Betriebsanleitung „Widerstandsthermometer (RTD) und Thermoelemente (TC)“
(Artikelnummer 14150915).

DE
WIKA Zusatzinformation TC82, TC83, druckfeste Kapselung (Ex d) 19
14302226.02 10/2020 EN/DE/FR/ES
Beim Einbau eines Transmitters und/oder einer Digitalanzeige gelten die besonderen
Bedingungen aus der Baumusterprüfbescheinigung (siehe Kapitel 4 „Besondere Bedin-
gungen für die Verwendung (X-Conditions)“).
2. Sicherheit
2.1 Symbolerklärung
GEFAHR!
... weist auf eine möglicherweise gefährliche Situation im explosionsgefähr-
deten Bereich hin, die zum Tod oder zu schweren Verletzungen führen kann,
wenn sie nicht gemieden wird.
2.2 Bestimmungsgemäße Verwendung
Die hier beschriebenen Thermometer sind geeignet zur Temperaturmessung in explosions-
gefährdeten Bereichen wie z. B. Schwefelrückgewinnungsanlagen (SRU).
Das elektrische Thermometer Typ TC8x-F besteht aus einem Modul (Typ TC8x-M), das an
einem Ex d zertifizierten Gehäuse befestigt ist. Das Modul besteht aus der Flanschanord-
nung mit Keramikrohren, allen Teilen der elektrischen Isolierung der Thermoelementdrähte
und einer gasdichten Durchführung zur Begrenzung des druckfesten Bereiches.
Der Sensorteil des Moduls besteht aus keramisch isolierten Thermoelementdrähten.
Das Thermometer/Modul Typ TC8x-M wird an einem Ex d- oder Ex db-zertifizierten
Gehäuse der WIKA-Serie 1/4000F, 7/8000 oder 5/6000 montiert. Das Gehäuse und die
Abdeckungen sind aus CrNi-Stahl oder Aluminium gefertigt. Die Abdeckung kann optional
mit einer Glaslinse (Fenster) versehen werden.
Alternativ wird das Thermometer an andere bescheinigte Gehäuse oder Baugruppen
montiert, wie sie in der „WIKA ATEX and IECEx Ex-d housing and device list“ (Artikelnum-
mer 14405410.01) aufgeführt sind.
Es stehen 3 verschiedene Varianten zur Verfügung:
■
Variante 1: Das Thermometer ist an einem zertifizierten Leergehäuse in der Zündschutz-
art „Druckfeste Kapselung“ befestigt. Die Klemmen sind im Inneren des Gehäuses
montiert.
■
Variante 2: Das Thermometer ist an einem zertifizierten Leergehäuse in der Zündschutz-
art „Druckfeste Kapselung“ befestigt. Elektronische Geräte sind im Inneren des Gehäu-
ses montiert.
■
Variante 3: Das Thermometer ist an einem zertifizierten Gerät (Transmitter) in
der Zündschutzart „Druckfeste Kapselung“ angebracht. Das Thermometer ist mit
II 2/-G Ex db IIC Gb/- gekennzeichnet.
1. Ex-Kennzeichnung / 2. Sicherheit

DE
WIKA Zusatzinformation TC82, TC83, druckfeste Kapselung (Ex d)20
14302226.02 10/2020 EN/DE/FR/ES
Das Nichtbeachten der Angaben für den Einsatz in explosionsgefährdeten Bereichen
führt zum Verlust des Explosionsschutzes. Grenzwerte und technische Angaben einhalten
(siehe Datenblatt).
Mögliche Sensormessbereiche:
-40 ... +1.700 °C
2.3 Verantwortung des Betreibers
Die Verantwortung über die Zoneneinteilung unterliegt dem Anlagenbetreiber und nicht
dem Hersteller/Lieferanten der Betriebsmittel.
2.4 Personalqualifikation
Das Elektrofachpersonal muss Kenntnisse haben über Zündschutzarten, Vorschriften und
Verordnungen für Betriebsmittel in explosionsgefährdeten Bereichen.
2.5 Beschilderung, Sicherheitskennzeichnungen
Zusätzliches Typenschild (Beispiel)
Zulassungsrelevante Daten
Symbol für die Einsatzfähigkeit des Gerätes in Umgebungstemperaturen bis -60 °C

TÜV 10 ATEX 555793 X
IECEx TUN 10.0002X
II 2 G Ex ib IIC T1 ... T6 Gb
Tamb see manual
********ATEX ******
IECEx ************
II 2/-G Ex db IIC T6 ... T1 Gb/-
Tamb see manual
WARNING! DO NOT OPEN WHILE ENERGIZED!
Ex d
Ex i
2. Sicherheit
