WilTec ARTICEL 61059 User manual

Operation Manual
ARTICEL 61059
Heater
Read and follow the operating instructions and safety information before using for the first time.
Technical changes reserved!
Due to further developments, illustrations, functioning steps and technical data can differ
insignificantly.
Updating the documentation
If you have suggestions for improvement or have found any irregularities please contact us.
© by WilTec Wil anger Technik GmbH Seite 7
http://www.WilTec. e
http://www.aoyue.eu
http://www.teichtip. e

The information contained in this document is subject to change without prior notice. o part of this
document can be copied or duplicated in another form without the prior written consent of WilTec
Wildanger Technik GmbH. The WilTec Wildanger Technik GmbH assumes no liability for any errors in
this user manual or the connection diagram.
Although WilTec Wildanger Technik GmbH has made every effort to make sure that this user manual
is complete, accurate and updated, errors cannot always be avoided. In the event of problems with
this user manual please complete and send this form back to us.
FAX-notification (+++49 2403 55592-15),
from: ________________________________________
Name: ________________
Firm:_____________________
Tel/Fax:__________________
I woul like to report the following mistakes:
_______________________________ ____________________________________
Customer Service WilTec Wildanger Technik GmbH
e-mail: [email protected]
Tel:++ [phone]
Intro uction
Thank you for purchasing this quality product. To minimize the risk of injury by means of fire or
electric shock we urge that our clients take some basic safety precautions when using this
evice. Please rea the operation instructions carefully an make sure you have un erstoo its
content.
Always use a grounded power connection with the appropriate mains voltage. You can find the
corresponding mains voltage on the type plate. If you have any doubts about the connection being
grounded, have it checked by a qualified professional. ever use a faulty electric cable.
Do not inspect the electrical part of the pressure pond filter in a wet or damp environment or when you
are wet yourself and protect it from direct sunlight. Install this device in a safe location so that nobody
can step on the cable, fall over or damage it. Disconnect the power plug before cleaning it and use
only a damp cloth for cleaning. Avoid using cleaning agents and make sure that no liquid enters the
electrical part of the pump.
The electric part of the device contains no parts that can be inspected or serviced by the user. Leave
the maintenance, adjustment and repair to qualified technical personnel. In case of unauthorised
intervention the 2-year warranty is no longer valid! Keep these operation instructions safe.
© by WilTec Wil anger Technik GmbH Seite 8
http://www.WilTec. e
http://www.aoyue.eu
http://www.teichtip. e

Inten e Use
This product is solely intended for indoor use in offices and private homes and not for application out-
side or within an industrial or commercial environment. Please only use this product with a faultless
electric wiring conforming to the ordinance of your local ordinances. In case of questions concerning
the adequacy of your wiring, please consult a qualified electrician.
Safety Instructions
While using this device, please abide to the following rules and regulations in order to prevent acci-
dents potentially leading to the device sustaining damage, severe injuries or even death.
Do not use this heater without a functioning smoke detector located within the nearby vicinity
and only use it as described in this manual as any usage not recommended by the manufac-
turer may cause harm to people and property.
Do not operate the heater if the power cord has been damaged or if the device has been
dropped in any manner and immediately stop it in case of malfunction.
Do not leave this device unattended once it has been turned on.
Children and individuals without the proper experience and knowledge or reduced physical,
mental or sensory abilities are not allowed to utilise this heater unless having been properly in-
structed and being supervised by a knowledgeable person responsible for their safety.
Do not place the heater on carpets, uneven or unstable surfaces or anywhere it may tilt or fall.
In order to guarantee the proper functionality of this device, place it upon a durable, smooth
and non-combustible surface offering sufficient space.
Always make sure to unplug the heater when it is not in use.
Do not operate the heater with any of its safety devices removed.
Do not use extension cords as they may overheat and cause fires.
Do not place the power cord beneath carpets or cover it with other items and make sure to
place it in a way that will not cause people to trip over it.
Electrical Hazar
Only use the heater in dry environments; this product is not intended for usage in damp or
moist areas, such as bathrooms, laundry areas, near sinks, washing machines, swimming
pools or any other sources of water and moisture. ever place the heater in the proximity of
containers of water in order to prevent it from potentially falling into the same. Further do not
use this product outdoors.
This product is equipped with a polarised plug that as a safety precaution was designed to
only fit into polarised outlets in a specific way. Therefore always make sure to match the plug
accordingly. In case of the plug not properly fitting into the outlet please consult a qualified
electrician.
Do not use this device if either the power cord or plug is damaged. Always make sure to utilise
functioning parts that are in pristine condition and therefore safe to use. Do not operate the
device if it shows any visible sign of damage or has malfunctioned before. For further informa-
tion concerning repairs under warranty please look into the warranty statement delivered
along with the product.
© by WilTec Wil anger Technik GmbH Seite 9
http://www.WilTec. e
http://www.aoyue.eu
http://www.teichtip. e

Fire Hazar
Do not use the heater near combustible materials, flammable gases, other heat sources or in
areas where these things are stored. Further ensure to keep a safety distance of at least 1
metre (approx. 3.2 feet) in all directions from the device before operating the same and make
sure that the air can flow without obstruction in order to prevent possible fires. ever place the
device on soft surfaces, such as beds, as openings might get blocked.
Do not insert or allow objects to be inserted into the ventilation as this might lead to electric
shocks, fire or simply cause damage to the heater. ever use extension cords as they may
overheat and thereby cause fire. Always make sure to unplug the device when it is not in use.
Hot Surfaces
either touch the heater while it is running nor shortly afterwards as its frame heats up during
use and therefore might cause serve burns when making contact with bare skin. If provided,
use handles when trying to move this heater or wait for the device to cool down.
Usage
Operation:
Only operate the heater in an upright position, following all the instructions and
recommendations listed within this manual.
Placement:
In order to achieve the maximum effect place the heater in the area of the room that is coldest.
Connection:
Directly connect the heater to a 230 Volt AC 50Hz wall outlet. Be sure the plug fits tightly and
thereby properly into the outlet. A loose connection might cause the
device to overheat and thereby damage the plug and the heater. (Note: In order to prevent a
circuit from overloading, do not connect the heater to a circuit that is
already strained by other electrical needs.)
Turning the evice on:
First press the power control switch by setting it to either I (low) or II (high) before then rotating
the thermostat knob clockwise until it reaches the setting for its highest temperature. (Note:
During the initial use of the heater a burnt smell might originate from the device. We would like
to assure you that this is normal and only a temporary condition caused by the last drips of
lubricant burning off the heating element. The unpleasant smell should disappear after a few
minutes.)
Power in icator:
When being turned on, the heater's power indicator lamp will be illuminated in order to indicate
that the heater is functioning.
Power switch settings:
This heater got two different heating settings and can either bet set to I (low) or II (high). It is
advised to use the "high" setting (1500 watt) in order to quickly increase the temperature to
the desired level. Once said temperature has been reached, switch to the "low" mode, which
is sufficient for maintaining a comfortable temperature.
© by WilTec Wil anger Technik GmbH Seite 10
http://www.WilTec. e
http://www.aoyue.eu
http://www.teichtip. e

Thermostat settings:
After the heater has been turned on and the room reached a comfortable temperature, slowly
turn the thermostat knob counterclockwise until the heater shuts off (a faint clicking noise
should be heard). By setting and leaving the thermostat like this, the device will automatically
maintain the current temperature. By further turning it counterclockwise towards the "low"
position, the temperature can be lowered. In order to raise the temperature simply turn the
knob clockwise towards the "high" position.
Turning the evice off:
Turn the center dial to the "off" position before plugging or unplugging the heater. Always
make sure to unplug the device while it is not in use.
Fan mo e:
Turn the power level control switch to the fan setting before turning the thermostat knob
clockwise in order to make the fan run continuously.
Safety Features
The device's power indicator lamp will be illuminated, if either the fan or the heater are turned
on.
The inbuilt overheating protection device will make sure to automatically turn off the device if
the heater grill is obstructed or the heater will grow too hot. Once the heater has been turned
off this way it needs to be reset by turning it off and unplugging. After waiting approximately 10
minutes in order for the device to cool down, the power cord can be reconnected and the
heater be restarted.
This product is further equipped with a tip-over-switch, which causes the heater to
automatically shut down if it tilts over. Simply place the device on an even surface without
obstructions and make sure it is in an upright position in order to restart the heating process.
Maintenance
Before cleaning the device make sure to unplug it and wait for the heater to cool down completely. A
washable filter is located at the air inlet and can be removed in case it should require cleaning. In case
said filter should appear to be dirty, simply remove it from the device after unplugging the same and
making sure that it had cooled down. The filter can be rinsed with warm water, but needs to have dried
completely before it can be reattached to the filter. The outside of the heater can further be cleaned
with a damp piece of cloth while the device is unplugged.
Do not use any detergents for this process and never immerge the heater in water as it is not only
going to destroy the device, but can also be dangerous. Once the frame has been cleaned, make sure
to let the device dry properly before putting it to use again.
Notes
Do not operate the heater without the grill being properly attached to the device and refrain from using
it, if it has malfunctioned or been damaged in any way. Do not take it apart by yourself and instead
consult a qualified electrician in case repairs are necessary.
The best way to store this heater is inside its original carton with the power cord being tied up in order
to prevent it from being damaged while it is stored away.
© by WilTec Wil anger Technik GmbH Seite 11
http://www.WilTec. e
http://www.aoyue.eu
http://www.teichtip. e

Disposal regulations
EU guidelines regarding the disposal of scrap electric appliances (WEEE, 2012/19/EU) were
implemented in the law related to electrical and electronic equipment and appliances.
All WilTec electric devices that fall under the WEEE regulations are labelled with the crossed-out
wheeled waste bin logo. This logo indicates that this electric equipment must not be disposed with the
domestic waste.
The company WilTec Technik GmbH has been registrated in the German registry EAR under the
WEEE-registration number DE45283704.
Disposal of used electrical and electronic appliances
(intended for use in the countries of the European
Union and other European countries with a separate
collection system for these appliances).
The logo on the article or on its packaging points out
that this article must not be treated as normal
household waste but must be disposed to a recycling
collection point for electronic and electrical waste
equipment. By contributing to the correct disposal of
this article you protect the environment and the health
of your fellow men. Environment and health are
threatened by inappropriate disposal.
Materials’ recycling helps reduce the consumption of raw materials.
Additional information on recycling this article can be provided by your local community, municipal
waste disposal facilities or the store where you purchased the article.
Address:
WilTec Wildanger Technik GmbH
Königsbenden 12 / 28
D-52249 Eschweiler
Important notice:
The reprint or reproduction, even of excerpts, and any commercial use, even in part of this instructions
manual require the written permission of WilTec Wildanger Technik GmbH.
