Wincomm WMP-153 User manual

WMP-153
Medical Panel PC
USER’S MANUAL
P/N: 205G000WMP1530, V1.0
Copyright© ,2015. All rights reserved
All other brand names are registered trademarks of their respective owners.
The information contained in this document is subject to change without notice

WMP-153 User’s manual
ii
Version Change History
Date
Version
Description
Remark
2015/6/25
1.0
First release
James

WMP-153 User’s manual
iii
Acknowledgments
Intel® Atom processor is registered trademarks of Intel®
Corporation.
IBM, PC/AT, PS/2 are trademarks of International Business
Machines Corporation.
Microsoft® Windows is a registered trademark of Microsoft®
Corporation.
RTL is a trademark of Realtek Semi-Conductor Co., Ltd.
C&T is a trademark of Chips and Technologies, Inc.
UMC is a trademark of United Microelectronics Corporation.
ITE is a trademark of Integrated Technology Express, Inc.
Intel is a trademark or registered trademark of Intel
Corporation.
Microsoft Windows is a registered trademark of Microsoft
Corporation.
Winbond is a registered trademark of Winbond Electronics
Corporation.
All other product names or trademarks are properties of
their respective owners.

WMP-153 User’s manual
iv
FCC Class B
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a residential environment.
This equipment generates, uses and can radiate radio frequency energy. If
not installed and used in accordance with this user manual, it may cause
harmful interference to radio communications.
Note that even when this equipment is installed and used in accordance
with this user manual, there is still no guarantee that interference will not
occur. If this equipment is believed to be causing harmful interference to
radio or television reception, this can be determined by turning the
equipment on and off. If interference is occurring, the user is encouraged
to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna
Increase the separation between the equipment and the receiver
Connect the equipment to a power outlet on a circuit different from
that to which the receiver is connected
Consult the dealer or an experienced radio/TV technician for help
Warning:
Any changes or modifications made to the equipment which are
not expressly approved by the relevant standards authority could
void your authority to operate the equipment.
To avoid risk of electric shock, this equipment must only be
connected to a supply mains with protective earth.
Do not modify this equipment without authorization of the
manufacturer.

WMP-153 User’s manual
v
Safety Instructions
Intended use
The WMP-153 is intended to serve as a medical monitor which is
designed for general purpose for hospital environment and for
diagnosis. It could be used for Surgical, Radiology, PACS (Picture
Archiving Communication Systems), LIS (Lab Information
Systems) and Electronic Medical Record purpose. It shall not be
used for life-supporting system.
WARNING: Critical diagnostic decision must not be based solely
on images displayed by this device
Greeting & Setup
Thank you for purchasing the WMP-153 unit. We wish that this
unit will be durable and reliable in providing your medical
application needs. Please follow the instructions below to ensure
the unit continues to have high performance.
Unpacking
After opening the carton, there will be a medical panel PC unit
with an accessory box. Examine the contents to see if there are
damages to the unit and if all accessories are present.
Setting up
Please read this manual carefully and remember to keep this
manual for future reference.
Safety Instructions & Cleaning
The unit has undergone various tests in order to comply with
safety standards. Inappropriate use of the open frame unit may
be dangerous. Please remember to follow the instructions below
to insure your safety during the installation and operating
process.
Transporting & Placement of unit
1. When moving the unit on a cart; be very cautious. Quick
stops, excessive forces and uneven surfaces may cause
the cart to overturn thus risking the unit to fall to the
ground.

WMP-153 User’s manual
vi
2. If the medical panel PC unit does fall to the ground,
immediately turn the power off and disconnect cords. Then
contact a service technician for repairs. Continual use of
the unit may result cause a fire or electric shock. Also, do
not repair the unit on your own.
3. Having two or more people transporting the display unit is
recommended. In addition, when installing the unit by
suspending it also requires two or more people.
4. Before suspending the unit, make sure the material used
for suspension is sturdy and stable. If not properly
suspended, the display unit may fall and cause serious
injury to people standing nearby as well as to the unit
itself.
5. If you wish to mount the display unit, remember to use
only the mounting hardware recommended by the
manufacturer.
Electrical and Power Source Related
1. This medical panel PC unit must operate on a power source
as shown on the specification label. If you are not sure
what type of power supply used in the area, consult your
dealer or local power supplier.
2. The power cords must not be damaged. Applied pressure,
added heat, and tugging may damage the power cord.
3. The power cord must be routed properly when setup takes
place. We advise that this aspect measure is to prevent
people from stepping on the cords or while the unit is
suspended to prevent flying objects from getting tangled
with the unit.
4. Do not overload the AC outlets or extension cords.
Electrical shocks or fires may occur from overloading.
5. Do not touch the power source during a thunderstorm.
6. If your hands are wet, do not touch the plug.
7. Use your thumb and index finger, grip firmly on the power
cord to disconnect from the electrical socket. By pulling the
power cord, may result in damaging it.

WMP-153 User’s manual
vii
8. If the unit is not going to be in use for an extended period
of time, remember to disconnect the unit.
9. The medical panel PC unit uses voltage between
100-240VAC. Connect the unit to a power source with the
same numerical value as shown. Please use only the power
cord provided by the dealer to ensure safety and EMC
compliance.
Various Factors of Environment
1. Do not insert objects into the openings.
2. Do not have liquids seep into the internal areas of the
medical panel PC unit.
3. Having liquids seep in or inserting objects into the unit
may result in electric shocks from taking and/or short
circuiting the internal parts.
4. Do not place the medical panel PC unit in the presence of
high moisture areas.
5. Do not install the medical panel PC unit in a wet
environment.
6. Do not place near unit near heat generating sources.
7. Do not place the unit in a location where it will come in
contact with fumes or steam.
8. Remember to keep the medical panel PC unit away from
the presence of dust.
9. If water has flow in or seep in, immediately disconnect the
open frame unit. Then contact a service technician for
repairs.
Ventilation Spacing
1. Do not cover or block the openings on the top and back
sides of the display unit. Inadequate ventilation may cause
overheating thus reducing the lifespan of the unit.
2. Unless proper ventilation is present, do not place unit in an
enclosed area; such as a built-in shelf. Keep a minimum
distance of 10 cm between the display unit and wall.

WMP-153 User’s manual
viii
Cleaning the unit
1. Remember to turn off the power source and to unplug the
cord from the outlet before cleaning the unit.
2. Carefully dismount the unit or bring the unit down from
suspension to clean.
3. Please use a dry soft cloth to clean the unit.
4. Take a dry cloth and wipe the unit dry. Remember to avoid
having liquids seep into the internal components and areas
of the medical panel PC unit.
Servicing, Repairing, Maintenance & Safety Checks
1. If the unit is not functioning properly, observe the
performance level of the display closely to determine what
type of servicing is needed.
2. Do not attempt to repair the medical panel PC unit on your
own. Disassembling the cover exposes users’ to high
voltages and other dangerous conditions. Notify and
request a qualified service technician for servicing the unit.
3. To avoid risk of electric shock, this equipment must only be
connected to a supply mains with protective earth.
4. If any of the following situations occur turn the power
source off and unplug the unit. Then contact a qualified
service technician.
(a) A liquid was spilled on the unit or objects have fallen
into the unit.
(b) The unit is soaked with liquids.
(c) The unit is dropped or damaged.
(d) If smoke or strange odor is flowing out of the operating
unit.
(e) If the power cord or plug is damaged.
(f) When the functions of the unit are dysfunctional.
5. When replacement parts are needed for the medical panel
PC unit, make sure service technicians use replacement
parts specified by the manufacturer, or those with the
same characteristics and performance as the original

WMP-153 User’s manual
ix
parts. If unauthorized parts are used it may result in
starting a fire, electrical shock and/or other dangers.
ISO 7000-0434 : Caution, consult ACCOMPANYING
DOCUMENTS.
ISO 7000-1641 : Follow operating instructions or
Consult instructions for use.
IEC 60417 -5009 : STAND-BY.
IEC 60417-5031 : Direct current.
EU-wide legislation, as implemented in each
Member State, requires that waste electrical and
electronic products carrying the mark (left) must be
disposed of separately from normal household
waste. This includes monitors and electrical
accessories, such as signal cables or power cords.
When you need to dispose of your display products,
please follow the guidance of your local authority, or
ask the shop where you purchased the product, or if
applicable, follow any agreements made between
yourself.
The mark on electrical and electronic products only
applies to the current European Union Member
States.

WMP-153 User’s manual
x
When networking with electrical devices, the operator is
responsible for ensuring that the resulting system meets the
requirements set forth by the following standards:
–EN 60601-1 (IEC 60601-1)
Medical electrical equipment
Part 1: General requirements for safety
–EN 60601-1-1 (IEC 60601-1-1)
Medical electrical equipment
Part 1-1: General requirements for safety
Collateral standard: Safety requirements for
Medical electrical systems
–EN 60601-1-2 (IEC 60601-1-2)
Medical electrical equipment
Part 1-2: General requirements for safety
Collateral standard: Electromagnetic compatibility;
Requirements and tests
Accessory equipment
connected to the
analog and digital
interfaces must be in
compliance with the
respective nationally
harmonized IEC
standards (i.e. IEC 60950 for data processing equipment, IEC
60065 for video equipment, IEC 61010-1 for laboratory
equipment, and IEC 60601-1 for medical equipment.)
Furthermore all configurations shall comply with the system
standard IEC 60601-1-1. Everybody who connects additional
equipment to the signal input part or signal output part
configures a medical system, and is therefore, responsible that
the system complies with the requirements of the system
standard IEC 60601-1-1. The unit is for exclusive interconnection
with IEC 60601-1 certified equipment in the patient environment
and IEC 60XXX certified equipment outside of the patient
environment. If in doubt, consult the technical services
department or your local representative.

WMP-153 User’s manual
xi
Caution:
DO NOT LEAVE THIS EQUIPMENT IN AN UNCONTROLLED
ENVIRONMENT WHERE THE STORAGE TEMPERATURE IS BELOW
-20° C (-4° F) OR ABOVE 60° C (140° F). THIS MAY DAMAGE THE
EQUIPMENT.
This equipment shall not be used in life support systems.
The user is not to touch SIP/SOPs and the patient at the same
time.
The patient is the intended operator.
Caution –Use suitable mounting apparatus to avoid risk of injury.
The sound pressure level at the operator’s position according to
IEC 704-1:1982 is no more than 70dB (A).
A) Grounding reliability can only be achieved when the equipment
is connected to an equivalent receptacle marked “Hospital
Only” or “Hospital Grade”.
B) Use a power cord that matches the voltage of the power outlet,
which has been approved and complies with the safety
standard of your particular country.
C) Caution: This adapter Sinpro HPU101-105 is a forming part of
the medical device
Contact information:
3F, No.14, Prosperity Road II, Science-Based Industrial Park,
Hsinchu, Taiwan 300, R.O.C
TEL: [phone]
E-Mail: Sal[email protected]

WMP-153 User’s manual
xii
Table of Contents
Acknowledgments ...................................... iii
FCC Class B............................................... iv
Safety Instructions ......................................v
Introduction ............................................1
Product Description .....................................1
Package list ................................................2
Features ....................................................3
Specifications .............................................4
Guidance and manufacturer’s declaration –
electromagnetic emissions ...........................6
Guidance and manufacturer’s declaration –
electromagnetic immunity ............................7
Guidance and manufacturer’s declaration –
electromagnetic immunity ............................9
Immunity...................................................9
Cleaning/Disinfecting .................................11
Getting Started ......................................12
System Set Up..........................................12
Dimension................................................ 13
System View ............................................14
Disconnect Device .....................................17
BIOS Setup ............................................18
Appendix................................................30
A. Jumper settings and Connectors .............30
B. L type Stand (optional kit)......................32
C. Battery Pack Specifications..................... 33
D. How to disable battery when system hang up
-WMP-153................................................ 34
E. Scrap Computer Recycling ......................35

WMP-153 User’s manual
1
Introduction
Product Description
The WMP-153 Medical Panel PC is based on Intel ATOM processor,
it accommodates one 2.5” SATA II hard disk drive and up to 8GB
DDR3L SODIMM.
The high brightness LCD, Low noise Fanless solution, integrated
multimedia functions and extensive expansion options make
them the perfect platform upon which to build comprehensive
lifestyle computing applications.
The WMP-153 includes all the features of a powerful computer
into a slim and attractive chassis. The WMP-153 has a 15.6” high
brightness TFT display with 1366 x 768 resolutions.
The WMP-153 is compact, Giga LAN and selectable WLAN network
compatible PC with full safety and medical approval and features
to control a dedicated system with a wide variety of applications.
Combining the WMP-153 into your system can achieve both
cost-saving and efficient improvements.
Common applications include Surgical, Radiology, PACS (Picture
Archiving Communication Systems), LIS (Lab Information
Systems) and Electronic Medical Record. The WMP-153 are
definitely your perfect choices.

WMP-153 User’s manual
2
Package list
Before you begin installing your Medical Station, please make
sure that the following items have been shipped:
The WMP-153 Medical Panel PC unit
One DVD containing user's manual, chipset drivers
Power Adapter x 1 (Mf:Sinpro, type/model: HPU101-105)
Power cord –Hospital grade used(US type), or other type in
UK, EU…etc.
Screw x 8 (VESA 75/100 use)

WMP-153 User’s manual
3
Features

Seamless on the front side
Easy wipe surfaces with no internal corners
IP65 at front side and IPX1 for whole system
Intel® Celeron® J1900 2.0 GHz quad-core processor 10W
Projective Capacitive Multi-touch screen (10 fingers)
Two mini PCI-e expansion (One full and one half)
HDD Anti-vibration mechanism
Fanless solution
Anti-bacteria (MRSA) plastic housing
Built-in Battery backup function (option)
Support PCI-E x 1 (option)
Support isolated module by different configuration (optional
order configuration)

WMP-153 User’s manual
4
Specifications
[
Hardware Specifications
Display
15.6” 400 nits TFT LCD
CPU Support
Intel® Celeron® J1900 2.0 GHz quad-core
processor 10W
Disk Drive Space
2.5” Hard Disk Drive (SATA II)
Expansion
Two Mini PCIe slot (+3.3V loaded 0.5A, total loaded
= 1A);
One PCI-E x 1 expansion slot (+3.3 loaded 1A,
+12V loaded 0.56A, total loaded = 10.02W)
Button
Power Button // Mute // Audio adjustment (+)(-) //
brightness (+)(-) // LCD on/off // Clean me(auto
release after 1 minute) // Dis-webcam // Fn
I/O
Standard version
1 RS-232 port + 1 RS-232/422/485 port
1 USB 3.0 port + 3 USB 2.0 ports
1 DC-in w/ lock function
1 Gigabit LAN RJ-45 Connectors
1 DVI-I output
Sound:
1 x Line-in
1 x line-out
2 x 2W Speakers on back side
LCD Specifications
Model Name
G156XW01 V1
Display Type
LED backlight LCD
Max. Resolution
1366 x 768
Contrast Ratio
500 : 1 (Typ)
Pixel Pitch (um)
252 (per one triad) × 252
Luminance (cd/m2)
400 (TYP)
Viewing Angle
170°(H)
160°(V)
Operating
Temperature
0°C~ 40°C (32°F~104°F)
Brightness Control
Yes

WMP-153 User’s manual
5
Power Adapter Specifications
Power
Close-frame
MFR
Sinpro
Type
HPU101-105
Input Voltage
AC 100 ~ 240 V, 1.25 –0.5A @ 47 ~ 63 Hz
Output Voltage
DC 12V @ 8.33 A
MTBF
100,000 hrs operation at 25°C
Mechanical Specifications
Architecture
Close-frame
Front Bezel
PET bezel with PCT touch screen
Color
Medical-white
Mounting / Holder
VESA 75/100mm
Construction
3mm ABS + PC TYPE Plastic housing
Dimension (WxHxD)
430 (H) x 300 (V) x 83 (T)
Net Weight
5.0 kg (w/o power adapter)
Packing Filler
PE
Environmental Specifications
Temperature
Operating: 0°C to 40°C (32°F ~104°F)
Storage, Transportation: -20°C to 60°C (-4°F
~140°F)
Humidity
Operating:
10% to 90%@ 40°C, non-condensing
Storage, Transportation:
10% to 90%, non-condensing
Vibration
Operating: 15g/0.53 oz, 11 ms, half sine wave
Non-operating: 50g/1.76 oz, 11 ms, half sine
wave
Shock
Operating: 5 ~ 17 Hz ,
Amplitude：0.117 ~ 500Hz ,
Acceleration：1.0G
Non-operating:10~55Hz/0.15g, 55~500Hz/2.0g
Altitudes
Operational: up to 3000 m (9842 feet)
Shipping: up to 12192 m (40000 feet)
Pressure
700 –1060 hPa (Operation)
186 –1060 hPa (Storage)
186 –1060 hPa (Transportation)

WMP-153 User’s manual
6
Input Power Rating
For Adaptor:
AC100~240 V, 1.25 –0.5A, @47 ~ 63 Hz.
For Unit:
DC 12V, 8.33A
Power Consumption
Typical: 54W
Touch Screen
Type
Full flat projective capacitive touch panel
Interface
Controller with USB interface, 5V
Resolution
100ppi to 25ppi Based WIN7 definition ppi
(Pixel per inch)
Light Transmission
90% ± 3%
Life Time
100M times
Guidance and manufacturer’s declaration – electromagnetic
emissions
The model WMP-153 is intended for use in the electromagnetic
environment specified below. The customer or the user of the model
WMP-153 should assure that it is used in such an environment.
Emissions test
Compliance
Electromagnetic environment –
guidance
RF emissions
CISPR 11
The model WMP-153 uses RF
energy only for its internal function.
Therefore, its RF emissions are very
low and are not likely to cause any
interference in nearby electronic
equipment.
RF emissions
CISPR 11
The model WMP-153 is suitable for
use in all establishments, including
domestic establishments and those
directly connected to the public
low-voltage power supply network
that supplies buildings used for
domestic purposes.
Harmonic
emissions
IEC 61000-3-2
Voltage
fluctuations/
flicker emissions
IEC 61000-3-3
Recommended separation distances between
portable and mobile RF communications equipment and the model
WMP-153

WMP-153 User’s manual
7
The model WMP-153 is intended for use in an electromagnetic
environment in which radiated RF disturbances are controlled. The
customer or the user of the model WMP-153 can help prevent
electromagnetic interference by maintaining a minimum distance
between portable and mobile RF communications equipment
(transmitters) and the model WMP-153 as recommended below,
according to the maximum output power of the communications
equipment.
Rated maximum
output power of
transmitter
W
Separation distance according to
frequency of transmitter
m
150 kHz to
80 MHz
d = 1,2
80 MHz to
800 MHz
d = 1,2
800 MHz to
2,5 GHz
d = 2,3
0,01
0,12
0,12
0,23
0,1
0,38
0,38
0,73
1
1,2
1,2
2,3
10
3,8
3,8
7,3
100
12
12
23
For transmitters rated at a maximum output power not listed above, the
recommended separation distanced in meters (m) can be estimated
using the equation applicable to the frequency of the transmitter, where P
is the maximum output power rating of the transmitter in watts (W)
according to the transmitter manufacturer.
NOTE 1 At 80 MHz and 800 MHz, the separation distance for the higher
frequency range applies.
NOTE 2 These guidelines may not apply in all situations. Electromagnetic
propagation is affected by absorption and reflection from structures,
objects and people.
Guidance and manufacturer’s declaration – electromagnetic
immunity
The model WMP-153 is intended for use in the electromagnetic
environment specified below. The customer or the user of the model
WMP-153 should assure that it is used in such an environment.
Immunity test
IEC 60601
test level
Compliance
level
Electromagnetic
environment –
guidance

WMP-153 User’s manual
8
Electrostatic
discharge
(ESD)
IEC 61000-4-2
6 kV contact
8 kV air
6 kV contact
8 kV air
Floors should be
wood, concrete or
ceramic tile. If floors
are covered with
synthetic material, the
relative humidity
should be at least 30
%.
Electrical fast
transient/burst
IEC 61000-4-4
2 kV for
power
supply lines
1 kV for
input/output
lines
2 kV for
power
supply lines
1 kV for
input/output
lines
Mains power quality
should be that of a
typical commercial or
hospital environment.
Surge
IEC 61000-4-5
1 kV line(s)
to line(s)
2 kV line(s)
to earth
1 kV line(s)
to line(s)
2 kV line(s)
to earth
Mains power quality
should be that of a
typical commercial or
hospital environment.
interruptions
and
voltage
variations
on power
supply
input lines
IEC
61000-4-11
<5 % UT
(>95 % dip in
UT)
for 0,5 cycle
40 % UT
(60 % dip in
UT)
for 5 cycles
70 % UT
(30 % dip in
UT)
for 25 cycles
<5 % UT
(>95 % dip in
UT)
for 5 sec
<5 % UT
(>95 % dip in
UT)
for 0,5 cycle
40 % UT
(60 % dip in
UT)
for 5 cycles
70 % UT
(30 % dip in
UT)
for 25 cycles
<5 % UT
(>95 % dip in
UT)
for 5 sec
Mains power quality
should be that of a
typical commercial or
hospital environment.
If the user of the
model WMP-153
requires continued
operation during
power
mains interruptions, it
is recommended that
the model WMP-153
be powered from an
uninterruptible power
supply or a battery.
