WineEnthusiast WES-45-SB Assembly instructions

Installation
Operation
and
Maintenance
Instructions
Refrigerated Wine Cellars
45 Bottle Single Zone
WES-45-SB
WES-45-SS
WES-45-S-GO
WES-45-S-SO
Note: Wine Cellars are designed exclusively for the stor-
age of wine. Wine Cellars cannot attain storage tempera-
tures suitable for fresh food storage.

NOTE
CONTENTS
2
Unpacking your wine cellar.................................. .. ........
Removing interior packaging...................... ...... ..........
Installing your wine cellar......................... ................ .....
Selecting the location.......................... ............. ..........
Cabinet Clearances ................................. ......... .........
Leveling legs ............................ ...................... ...........
Electrical Connection ..................... ........... ....................
Using Your Control............... ................ ..........................
Dimensions for WES-45-SB and -SS glass door ..........
Recommended Rough in Opening Dimensions
for WES-45-SB and -SS glass door. ..........................
Dimensions for WES-45-S-GO glass overlay door... .... .
Recommended Rough in Opening Dimensions
for WES-45-S-GO glass overlay door...... ........... ........
Dimensions for WES-45-S-SO solid overlay door .. ......
Recommended Rough in Opening Dimensions
for WES-45-S-SO solid overlay door............... ...... ......
Full Overlay Panel Installation Instructions.... . ............ ..
Energy Saving Tips .......................................................
Features ........................................ ....................... .........
Care and Cleaning ................................. ...... ..... ............
Cleaning the cabinet...................................................
Cleaning the interior...................................... ....... .......
Cleaning the wine shelves............................. ......... ...
Cleaning the door gasket.............................. .... ..........
Replacing the light bulb........................ .. ........... .........
Troubleshooting Guide......................... ............... ..........
Obtaining Service ...................... ........................ ...........
Limited Warranty............... .... ............... ..........................
3
3
4
4
4
4
5
6
7
7
8
8
9
9
10
12
13
14
14
14
14
14
14
15
16
17
Important Safety Instructions
Warnings and safety instructions appearing in this guide
are not meant to cover all possible conditions and situa-
tions that may occur. Common sense, caution, and care
must be exercised when installing, maintaining, or operat-
ing this appliance.
Recognize Safety Symbols,
Words, and Labels.
WARNING-Hazards or unsafe practices with high
probability of personal injury or property / product dam-
age.
CAUTION-Hazards or unsafe practices which could
result in personal injury or property or product damage.
NOTE-Important information to help assure a problem
free installation and operation.

UNPACKING YOUR WINE CELLAR
3
Remove Interior Packaging
Your wine cellar has been packed for shipment with all
parts that could be damaged by movement securely fas-
tened. Remove internal packing materials and any tape
holding internal components in place. The owners manual
is shipped inside the product in a plastic bag along with
other accessory items.
Important
Keep your carton and packaging until your wine cellar has
been thoroughly inspected and found to be in good condi-
tion. If there is damage, the packaging will be needed as
proof of damage in transit. Afterwards please dispose of all
items responsibly in particular the plastic bags which can
be a suffocation hazard.
If the unit was shipped or has been laying on its back for
any period of time allow the wine cellar to sit upright for a
period of at least 24 hours before plugging in. This will en-
sure oil returns to the compressor. Plugging the wine cellar
in immediately may cause damage to internal parts.
Help Prevent Tragedies
Child entrapment and suffocation are not problems of the
past. Junked or abandoned refrigerators are still dangerous
- even if they sit out for “just a few days”.
If you are getting rid of your old refrigerator, please follow
the instructions below to help prevent accidents.
Before you throw away your old refrigerator or freezer:
• Take off the doors or remove the drawers.
• Leave the shelves in place so children may not easily
climb inside.
Note to Customer
This merchandise was carefully packed and thoroughly
inspected before leaving our plant. Responsibility for its
safe delivery was assumed by the retailer upon acceptance
of the shipment. Claims for loss or damage sustained in
transit must be made to the retailer.
DO NOT RETURN DAMAGED MERCHANDISE TO THE
MANUFACTURER - FILE THE CLAIM WITH THE RE-
TAILER.
EXCESSIVE WEIGHT HAZARD
Use two or more people to move product.
Failure to do so can result in back or other injury.

INSTALLING YOUR WINE CELLAR
4
Select Location
The proper location will ensure peak performance of your
appliance. We recommend a location where the unit will
be out of direct sunlight and away from heat sources. To
ensureyourproductperformstospecicationstherecom-
mended installation location temperature range is from 55
to 100°F (13 to 38°C).
Cabinet Clearance
Ventilation is required from the bottom front section of the
unit. Keep this area open and clear of any obstructions.
Adjacent cabinets and counter top can be installed around
the unit as long as the front grille remains unobstructed.
Leveling Legs
Adjustable legs at the front and rear corners of the unit
shouldbesetsotheunitisrmlypositionedontheoor
and level from side to side and front to back. The overall
height of your refrigerator may be adjusted from 33 3⁄4”
(85.7cm) with the leveling legs turned in, and up to 34 3⁄4”
(88.3cm) with the leveling legs extended.
To adjust the leveling legs, place the refrigerator on a solid
surfaceandprotecttheoorbeneaththelegstoavoid
scratchingtheoor.Withtheassistanceofanotherperson,
lean the refrigerator back to access the front leveling legs.
Raise or lower the legs to the required dimension by turn-
ing the legs. Repeat this process for the rear by tilting the
refrigerator forward using caution to prevent the door from
opening. On a level surface check the refrigerator for level-
ness and adjust accordingly.
The front grille screws may be loosened and the front grille
adjusted to the desired height. When adjustment is com-
plete tighten the two front grille screws. (See Figure 2).
Front
Leveling Legs
Front Grille,
keep this area
open.
Figure 1
Figure 2
Front grille
Front grille
screw
Rear
Leveling Legs
Front Grille
Do not obstruct the front grille. The openings within the
frontgrilleallowairtoowthroughthecondenserheatex-
changer.Restrictionstothisairowwillresultinincreased
energy usage and loss of cooling capacity. For this reason
it is important this area to not be obstructed and the grille
openings kept clean. Wine Enthusiast does not recommend
theuseofcustommadegrillesasairowmayberestricted
because of inadequate openings. (See Figure 1).

NOTE
Electrical Connection:
A grounded 115 volt, 15 amp dedicated circuit is required.
This product is factory equipped with a power supply
cord that has a three-pronged, grounded plug. It must be
plugged into a mating grounding type receptacle in accor-
dance with the National Electrical Code and applicable lo-
cal codes and ordinances (see Figure 3). If the circuit does
not have a grounding type receptacle, it is the responsibility
and obligation of the customer to provide the proper power
supply.
ELECTRICAL CONNECTION
Ground Fault Circuit Interrupters (GFCI) are prone to
nuisance tripping which will cause the unit to shut down.
GFCI’s are generally not used on circuits with powered
equipment that must run unattended for long periods of
time, unless required to meet local building codes and
ordinances.
5
The wall receptacle should be
located near the product and
be a polarized type with adequate ground protection.
The product must be installed to your local building
codes and ordinances.
Figure 3
Electrical Shock Hazard
• Do not use an extension cord with this ap-
pliance. They can be hazardous and cause
decientoperation.
• This unit should not, under any circumstances,
be installed to an un-grounded electrical supply.
• Do not remove the grounding prong from the
power cord.
• Do not use an adapter.
• Do not splash or spray water from a hose on
the appliance. Doing so may cause an electri-
cal shock, which may result in severe injury or
death.

6
Starting your refrigerator
Plug the refrigerator power cord into a wall outlet. Your
refrigerator will begin cooling after power is applied.
If your refrigerator does not start, check that the refrigerator
is turned on and the set temperature is cold enough.
Turning your refrigerator ON or OFF
If the refrigerator is on, the refrigerator temperature will be
shown on the display. To turn the refrigerator off, press and
hold the “ON/OFF” button for three (3) seconds. “OFF” will
appear on the display.
If the refrigerator is not on, “OFF” will be shown on the
display. To turn the refrigerator on, press and hold the “ON/
OFF” button for three (3) seconds. The refrigerator tem-
perature will be shown on the display.
Set temperature
To set the refrigerator temperature, press and hold the
“SET” button. When the “SET” button is pressed, the dis-
play will show the set temperature. While holding the “SET”
button, press the “WARMER” or “COLDER” buttons to
adjust set temperature.
Refrigerator operation
The available temperature range of the refrigerator is 40° to
65° (4° to 18° C).
It may take up to 24 hours for your refrigerator to reach
desired temperature. This will depend on amount of content
loaded and number of door opening and closings.
For best results allow refrigerator to “pull down” to desired
set temperature before loading. Once contents are loaded,
allow at least 48 hours for temperature to stabilize before
making any adjustments to the set temperature.
Alarms
Your refrigerator control will monitor refrigerator function
and alert you with a series of audible and visual alarms.
• Door Ajar Alarm: If the door has been left
openforoverve(5)minutes,thealarm
will sound in one (1) second intervals. The
displaypanelwillash“do”andtheAlarmLEDlocatedat
the top left of the display below the word “Alarm” will be il-
luminated. This will stop as soon as the door is closed.
• Temperature Sensor Fault: If the control
ler detects that the temperature sensor is
not properly functioning, a temperature
sensor alarm will sound in one (1) second intervals. “E1”
willashonthedisplaypanelandtheAlarmLEDlocated
at the top left of the display below the word “Alarm” will be
illuminated. Please call Wine Enthusiast Customer Service
or your dealer if this error code is displayed.
Alarm Mute
Press any key to mute the audible portion of an alarm.
NOTE-This action will only mute the alarm. If the condi-
tion that caused the alarm continues, the alarm code will
continuetoashandwillsoundfor20secondsevery60
minutes.
USING YOUR REFRIGERATOR CONTROL
Figure 4
Control
Door Switch

DIMENSIONS FOR WES-45-SB AND WES-45-SS GLASS DOOR
ROUGH IN OPENING DIMENSIONS FOR WES-45-SB AND WES-45-SS
GLASS DOOR
* Depth dimension may vary depending on each individual
installation.
Electrical Requirements: A grounded 115 volt, 15 amp dedi-
cated circuit is required.
Power outlet can be located in the back wall behind unit.
Add 1” to depth for thickness of plug, or recess outlet 1”
into the wall. Power outlet can also be installed in adjacent
cabinetry with a cutout for routing of power cord. Follow all
local building codes when installing electrical and unit.
Product weight = 130 lbs. (59.1 kg.)
7
** Minimum rough in opening required is to be larger than
the adjusted height of the cabinet.
24” (61 cm)
*24” (61 cm)
standard cabinet
depth
** 34” to 35”
(86.4 to 88.9cm)
23 7⁄8”
(60.7cm)
3” to 4”
(7.6 to 10.2cm)
22”
(55.9cm)
33 3⁄4” to 34 3⁄4”
(85.7 to 88.3cm)
24 1⁄16”
(61.1cm)
47”
(119.4cm)
26”
(66cm)
25 21⁄32”
(65.2cm)

DIMENSIONS FOR WES-45-S-GO GLASS OVERLAY DOOR
ROUGH IN OPENING DIMENSIONS FOR WES-45-S-GO
GLASS OVERLAY DOOR
* Depth dimension may vary depending on each individual
installation.
Electrical Requirements: A grounded 115 volt, 15 amp dedi-
cated circuit is required.
Power outlet can be located in the back wall behind unit.
Add 1” to depth for thickness of plug, or recess outlet 1”
into the wall. Power outlet can also be installed in adjacent
cabinetry with a cutout for routing of power cord. Follow all
local building codes when installing electrical and unit.
Product weight = 130 lbs. (59.1 kg.)
8
** Minimum rough in opening required is to be larger than
the adjusted height of the cabinet.
24” (61 cm)
*24” (61 cm)
standard cabinet
depth
* To face of door with-
out custom panel
** 34” to 35”
(86.4 to 88.9cm)
23 7⁄8”
(60.7cm)
3” to 4”
(7.6 to 10.2cm)
22”
(55.9cm)
33 3⁄4” to 34 3⁄4”
(85.7 to 88.3cm)
24 1⁄16”
(61.1cm)
46 25⁄32
(118.8cm)
23 5⁄16”*
(59.2cm)
23 1⁄32”
(58.5cm)

DIMENSIONS FOR WES-45-S-SO SOLID OVERLAY DOOR
ROUGH IN OPENING DIMENSIONS FOR WES-45-S-SO SOLID OVERLAY DOOR
* Depth dimension may vary depending on each individual
installation.
Electrical Requirements: A grounded 115 volt, 15 amp dedi-
cated circuit is required.
Power outlet can be located in the back wall behind unit.
Add 1” to depth for thickness of plug, or recess outlet 1”
into the wall. Power outlet can also be installed in adjacent
cabinetry with a cutout for routing of power cord. Follow all
local building codes when installing electrical and unit.
Product weight = 130 lbs. (59.1 kg.)
9
** Minimum rough in opening required is to be larger than
the adjusted height of the cabinet.
24” (61 cm)
*24” (61 cm)
standard cabinet
depth
* To face of door with-
out custom panel
** 34” to 35”
(86.4 to 88.9cm)
23 7⁄8”
(60.7cm)
3” to 4”
(7.6 to 10.2cm)
22”
(55.9cm)
24 1⁄16”
(61.1cm)
23 5⁄16”*
(59.2cm)
33 3⁄4” to 34 3⁄4”
(85.7 to 88.3cm)
46 27⁄32”
(119cm)
23”
(58.4cm)

NOTE
NOTE
FULL OVERLAY PANEL INSTALLATION INSTRUCTIONS
Step 2: Remove door
Remove the top hinge pin from the hinge with an 1⁄8” allen
wrench. Remove the door by angling the top of the door
outward and lifting the door off the bottom hinge.
(See detail in Figure 5).
Step 3: Remove gasket
Lay the door on its front being careful not to scratch it. To
gain access to the screw holes remove the door gasket by
peeling up and out of the channel.
Step 1: Verify door alignment
Verify that the door is aligned correctly with the cabinet
prior to fabricating the custom panel. Failure to do so could
result in mis-alignment of the custom panel with the hinge
bracket. The door should be parallel to the sides and top of
the refrigerator. If alignment is necessary the door may be
adjusted by loosening the 2 screws which secure the upper
and/or lower hinge adapter brackets located on the top
and bottom of the door, and adjusting the door side to side.
Use a 5⁄32” allen wrench for this procedure. (See Figure 5
below).Whennishedaligningthedoor,tightenthescrews
securely.
Door should be
parallel to top
and sides of
refrigerator.
10
Step 4: Cut overlay panel
Depending on the wine cellar model cut the overlay panel
to the dimensions shown. Use Figure 6 and Table A for
solid door models or use Figure 7 and Table B for glass
door models.
H
W
Front of
overlay
panel
For overlay with lock option panel thickness to be
3⁄4” (19mm) maximum to 5⁄8” (16mm) minimum.
Weight of the overlay panel should not exceed 20 pounds
(9.1 kilograms).
For the door to close properly, it is necessary to maintain a
minimum space of 9⁄32” (7mm) between the door and cabi-
netange(SeeFigure5).Thisspacecanbeadjustedby
adjusting the top and bottom hinge adapter brackets.
Figure 5
Hinge adapter bracket
located on top and bottom
of the door.
Remove top hinge pin
to remove the door.
9⁄32”
(7mm)
Model W H
WES-45-S-SO 23 5⁄8”
(60cm)
30 5⁄16”
(77cm)
Figure 6
Solid Door Models
Solid Door Models
Table A

FULL OVERLAY PANEL INSTALLATION INSTRUCTIONS
Step 5: Drill hinge clearance holes in overlay
panel
Set the overlay panel on the door front, align the edges,
andclamptogether.Clampthepanelrmlybutbecareful
not to damage the door or the panel. Mark center of hinge
adapter hole on wood panel, top and bottom. (See Figure
8.) Remove wood panel from door and drill 5⁄16” (8mm) di-
ameter clearance holes into the overlay panels 3⁄4” (20mm)
deep. These will be clearance holes for the top and bottom
hinge pins.
This is also a convenient time to locate and drill the holes
for your handle. Most often the handle is to match that of
the surrounding cabinetry. If your handle attaches from the
back-side of the custom panel, locate the mounting holes
while the panel is attached to the door and cabinet. After
the panel is removed from the door, drill the mounting holes
from the front, to the recommended diameter of the handle
manufacturer. Counter bore the back-side of the panel so
the screw heads do not interfere with the surface of the
door.
Step 6: Drill panel mounting holes
Re-clamp the panel to the door per step 5 and drill the
screw pilot holes for attaching the overlay panel to the door.
Select the size of the hole from Table C. Be careful not to
drill the pilot holes through the overlay panel, (1⁄2” (12.7mm)
deep for 3⁄4” (19mm) and 5⁄8” (15.7mm)
panels ).
Material Type #8 Wood Screw
Hardwood 1⁄8” (3.2mm) Diameter. Pilot Hole
Softwood 7⁄64 (2.8mm) Diameter. Pilot Hole
Table C
Model W H
WES-45-S-GO 23 7⁄16”
(59.5cm)
30 5⁄16”
(77cm)
Figure 7
1 23⁄32”
(38.8cm)
Typical 4
Sides
11
Table B
W
HFront of
overlay
panel Glass Door Models
Top Hinge
Adapter
Hole in hinge
adapter
Door
Overlay Panel
Hole in bottom
hinge adapter
Figure 8
Glass
Door
Models

FULL OVERLAY PANEL INSTALLATION INSTRUCTIONS AND
ENERGY SAVING TIPS
12
Step 8: Install door gasket
Press the door gasket into the door channel. Make certain
the gasket corners are fully inserted.
Step 9: Install the door
Install the top and bottom hinge adapter bushings back into
the hinge adapters that were removed in step 6. Install the
door by reversing the procedure from step 2. Install the top
hingepinsothescrewheadisushwiththetopsurfaceof
the hinge
Top hinge pin Top hinge
Figure 10
Right hand
hinges shown
Bottom
hinge
Top door hinge
adapter
Top hinge adapter
bushing
Bottom door
hinge adapter
Bottom hinge
adapter bushing
Bottom hinge pin
Bottom hinge
cam
Clearance hole through
door gasket channel
#10 Wood Screw
Figure 9
Back of door
Step 7: Secure overlay panel to the door.
With the #10 wood screws provided, fasten the overlay
panel to the door. (See Figure 9).
The following suggestions will minimize the
cost of operating your refrigeration appliance.
1. Do not install your appliance next to a hot appliance,
(cooker, dishwasher, etc.). heating air duct, or other
heat sources.
2. Install product out of direct sunlight.
3. Assure the toe grille vents at front of unit beneath door
is not obstructed and kept clean to allow ventilation for
the refrigeration system to expel heat.
4. Plug your appliance into a dedicated power circuit. (Not
shared with other appliances).
5. When initially loading your new product, or whenever
large quantities of warm contents are placed within
refrigerated storage compartment, minimize door open-
ings for the next 12 hours to allow contents to pull down
to compartment set-point temperature.
6. Maintaining a relatively full storage compartment will
require less appliance run time than an empty compart-
ment.
7. Assure door closing is not obstructed by contents
stored in your appliance.
8. Allow hot items to reach room temperature before plac-
ing in product.
9. Minimize door openings and duration of door openings.
10. Use the warmest temperature control set-point that
meets your personal preference and provides the
proper storage for your stored contents.
11. For wine storage products:
When serving temperatures are not required, re-
turn the compartment(s) set-point to the ideal red
and white wine long term storage temperature of
13°C / 55°F.
12. Minimize use of display lighting option on glass door
products, (light stays on with door closed).
13. When on vacation or away from home for extended pe-
riods, set the appliance to warmest acceptable tem
perature for the stored contents.
14. Set the control to the “off” position if cleaning the unit
requires the door to be open for an extended period of
time.

WES-45 WINE CELLAR FEATURES
Insert Wine Bottles
The four (4) pull-out shelves each hold eight (8) bottles.
See Figure 11 for typical wine bottle spacing. Care should
be taken when storing extra tall bottles in the wine cradle at
the bottom of the compartment because they may prevent
the door from closing.
Loading Tips and Suggestions
Two (2) magnums can be placed in the bottle cradle as
long as they are positioned horizontally.
The bottles on the top rack directly under the light will be
exposed to a slightly higher temperature when the light is
on. Position your wines accordingly and REMEMBER TO
TURN OFF THE LIGHT WHEN IT IS NO LONGER NEED-
ED.
Keep wines that you plan to use for everyday drinking and
entertaining on the front half of the racks where labels are
completely visible. Place wines for aging or longer term
storing in the rear.
Pull-out Racks
The four (4) pull-out wine racks may be pulled out approxi-
mately seven and a half (7.5) inches to facilitate adding or
removing bottles. DO NOT lean on or press down heavily
on the wine shelves. Doing so may damage the shelves
and the wine bottles stored on them. Pull the wine racks
out gently and carefully to minimize unsettling your wine
collection. Avoid pulling out more than one rack at any time
to maintain stability.
The natural maple wood shelf fronts can be stained or
painted to match adjoining cabinetry.
Single Bottle Racks
The single level roll out racks allow you to easily view and
access your inventory without disturbing other bottles (see
Figure 13).
Figure 12
Figure 13
13
Front Bottles (Necks Facing Rear)
Rear Bottles (Necks Facing Front)
Figure 11

CARE AND CLEANING OF YOUR WINE CELLAR
Care and Cleaning
Front Grille
Periodically brush and vacuum the front grille area to main-
tainproperairowthroughthecondensercoil.Seepage4,
Figure 1.
Cabinet
The painted cabinet can be washed with mild soap and
water and thoroughly rinsed with clear water. NEVER use
abrasive scouring cleaners.
Interior
Wash interior compartment with mild soap and water. Do
NOT use an abrasive cleaner, solvent, polish cleaner or
undiluted detergent.
Pull-out Racks
The racks may be cleaned with mild soap and water and a
soft cloth. Do NOT use any abrasive cleaners.
Glass Door
Use a glass cleaner or mild soap and water and soft cloth
to clean the glass door model. Do NOT use any abrasive
cleaners.
Door Gasket
The vinyl gasket may be cleaned with mild soap and water,
a baking soda solution or a mild scouring powder.
Light Bulb Replacement
The WES-45 uses one, 15 watt incandescent light bulb to
illuminate the interior of the wine cellar. The light bulb is a
very reliable electrical component, but should it not func-
tion properly, please call the dealer where you purchased
your wine cellar from for a replacement light bulb. Use only
an original equipment light bulb from your dealer or Wine
Enthusiast.
To replace the light bulb, disconnect power to the unit. Un-
screw the old light bulb located behind the display housing
at the top of the unit. Set the old light bulb aside. Screw
the new light bulb into place. Reconnect power to the unit.
Check to see if the light bulb operates properly to complete
the installation.
The light bulb is not covered by your warranty. A replace-
ment bulb can be obtained from your dealer or from Wine
Enthusiast.
In the Event of a Power Failure
If a power failure occurs, try to correct it as soon as possi-
ble. Minimize the number of door openings while the power
is off so as not to adversely affect the unit’s temperature.
14
DISCONNECT THE POWER CORD BEFORE
ATTEMPTING LIGHT BULB REPLACEMENT.
Failure to do so may result in an electrical shock
that could severely injure you.
Do NOT under any circumstance use a light
bulb that exceeds 15 watts!

TROUBLESHOOTING YOUR WINE CELLAR
15
Problem Possible Cause Remedy
Unit not cold enough.
Adjust temperatures (See “Set Tem-
peratures” on page 6).
• Control set too warm.
• Content temperature not stabi-
lized.
• Excessive usage or prolonged
door openings.
• Airowtofrontgrilleblocked.
• Door gasket not sealing properly.
• Adjust temperature colder. Al-
low 24 hours for temperature to
stabilize.
• Allow temperature to stabilize for
at least 24 hours, with minimal
door openings.
• Airowmustnotbeobstructedto
front grille. See “clearances” on
page 4.
• Check door alignment and/or ad-
just or replace door gasket.
Unit too cold.
Adjust temperatures (See “Set Tem-
peratures” on page 6).
• Control set too cold.
• Door gasket not sealing properly.
• Adjust temperature warmer. (See
page 6, “set temperature”). Al-
low 24 hours for temperature to
stabilize.
• Check door alignment and/or ad-
just or replace door gasket.
No interior light. • Failed light bulb. • Replace light bulb, see page 14.
Light will not go out when door is
closed.
• Door not activating light switch. • Verify cabinet is level, refer to
page 4 for leveling instructions.
• Verify the door is aligned properly,
refer to page 10 for instructions.
Noise or Vibration. • Unit not level. • Level unit, see “Leveling Legs” on
page 4.
Unit will not run. • Unit turned off.
• Power cord not plugged in.
• No power at outlet.
• Turn unit on. See “Start your Appli-
ance” on page 6.
• Plug in power cord.
• Check house circuit.
Before You Call for Service
If the unit appears to be malfunctioning, read through this
manualrst.Iftheproblempersists,checkthetrouble-
shooting guide below. Locate the problem in the guide and
refer to the cause and its remedy before calling for service.
The problem may be something very simple that can be
solved without a service call. However, it may be required
tocontactyourdealeroraqualiedservicetechnician.
Electrocution Hazard
Never attempt to repair or perform maintenance on
the unit until the main electrical power has been
disconnected. Turning the unit control "OFF" does
not remove electrical power from the units wiring.

OBTAINING SERVICE
16
If Service is Required:
• Iftheproductiswithintherstyearwarrantyperiod
please contact your dealer or call Wine Enthusiast Cus-
tomer Service at 800.648.6058 for directions on how to
obtain warranty coverage in your area.
• Iftheproductisoutsidetherstyearwarrantyperiod,
Wine Enthusiast Customer Service can provide recom-
mendations of service centers in your area.
• In all correspondence regarding service, be sure to
give the service number, serial number, located on your
product’s serial plate, and proof of purchase.
• Try to have information or description of nature of the
problem, how long the unit has been running, the room
temperature, and any additional information that may
be helpful in quickly solving the problem.
• Table D is provided for recording pertinent information
regarding your product for future reference.
For Your Records
Date of Purchase
Dealer’s name
Dealer’s Address
Dealer’s City
Dealer’s State
Dealer’s Zip Code
Appliance Serial Number
Appliance Service Number
Table D
The service number and serial number can be found on the
serial plate which is located inside the wine cellar on the left
side toward the top of the liner. See Figure 14.
Figure 14

Length of Warranty:
This Limited Warranty lasts for one (1) year from date of
receipt of purchase of the wine cellar (“Limited Warranty
Period”). Extended warranties may be available for an
additional cost at the time of purchase or up to the seventh
month from date of purchase. These extended warran-
ties would extend this one (1) year limited warranty to two
(2),three(3),orve(5)years.Detailsaboutourextended
protection plans can be found @ WineEnthusiast.com.
Who is Protected:
This Limited Warranty protects the original purchaser dur-
ing the Limited Warranty Period, provided that such pur-
chaser can present appropriate proof of original purchase.
What is Covered:
This Limited Warranty covers any defects in workmanship
or materials in your new wine cellar under normal use.
What is Not Covered:
The following are not covered by this Limited Warranty
damage due to such things as accident, misuse, abuse,
mishandling, neglect, unauthorized repair, failure to prop-
erly maintain, acts of God or any other cause beyond the
reasonable control of the Wine Enthusiast whether similar
or dissimilar to the foregoing.
Purchaser understands and acknowledges that the wine
cellar is a wine refrigerator, which houses wine. Purchaser
assumes all the risk of using these units, including risk of
spoilage, humidity variations, temperature variations, leaks,
res,waterdamage,mold,mildew,drynessandsimilar
perils that may occur.
What We Will Do:
During the Limited Warranty Period, Wine Enthusiast and/
or the manufacturer will, at its sole discretion, repair or
replace any wine cellar not operating within the manufactur-
er’sspecications.Allcostsforlaborandmaterialsthereto
shall be covered during the Limited Warranty Period. If
Wine Enthusiast deems the wine cellar is not repairable,
Wine Enthusiast will use the value of your original order to-
ward a replacement; provided, however, that the purchaser
will be responsible for all shipping and handling costs with
respect to the replacement after the initial ninety (90) days
after the date of receipt of original purchase. After the
initial ninety (90) day period after the date of receipt
of purchase, purchaser must pay any shipping and
handling charges that are incurred in shipping or trans-
porting the wine cellar for service under this Limited
Warranty. Wine Enthusiast reserves the right to substitute
materials of substantially similar quality in the event that
identical materials are not available at the time the Lim-
ited Warranty services are performed. Wine Enthusiast
reserves the right to request that purchaser contact a local
refrigeration company to service the wine cellar.
How to get Warranty Service:
In the event your wine cellar is not operating within the
manufacturer’sspecications,duringtheWarrantyPeriod,
contact customer service by email at custserv@WineEnthu-
siast.net or by phone [phone].
Limitation of Implied Warranties:
All implied warranties, including warranties of merchant-
abilityandtnessforaparticularpurpose,arelimitedin
duration to the length of this Limited Warranty.
Exclusion of Certain Damages:
Wine Enthusiast’s liability is limited to replacement or repair
of the defective wine cellar. Wine Enthusiast shall not be
liable for any damages, whether incidental, consequential
or otherwise, because of any defective wine cellar.
How State Law Applies:
Some states do not allow limitations on how long an implied
warranty lasts and/or do not allow the exclusion of inciden-
tal or consequential damages, so the above limitations and
exclusions may not apply to you.
TheLimitedWarrantygivesyouspeciclegalrights,and
you may also have other rights which vary from state to
state.
LIMITED WARRANTY
17

Allspecicationsandproductdesignssubjecttochangewithoutnotice.Suchrevisionsdonoten-
title the buyer to corresponding changes, improvements, additions, replacements or compensation
for previously purchased products.
WineEnthusiast.com
Wine Enthusiast
333 N. Bedford Rd.
Mt. Kisco NY 10549
800.648.6058
41013119-EN Rev A
1/25/13





Caves à vins réfrigérées
45 Zone Bouteille unitaire
WES-45-SB
WES-45-SS
WES-45-S-GO
WES-45-S-SO

-


ATTENTION
NOTE
REMARQUE
CONTENU

 

 
 
 




 


 
 


 




 
 
 
 
 
 



Importantes instrucons de sécurité




Reconnaissance des symboles, des mots et des
équees concernant la sécurité.
3
3





6
7
7
8
8
9
9
10
13









16
17
2
REMARQUE - -

REMARQUE-

AVERTISSEMENT – Dangers ou pratiques dan-
gereuses avec une forte probabilité de blessures corpo-
relles et/ou de dommages pour le produit.
AVERTISSEMENT
