Winton WHB Series User manual

WINTON HOLE BORER
WHB SERIES
PLEASE READ THIS MANUAL BEFORE OPERATING MACHINERY
OWNERS MANUAL

V2 2Winton WHB
Congratulaons on purchasing your new Winton machine!
Before you get started, we have provided a helpful space to jot down a few important
details about your new Winton machine.
Model Number: WHB
Serial Number:
Date of purchase:
Factory Reference: HMD-L
This manual should be considered a permanent part of this machine and should remain with it even if
the machine is subsequently sold.
Winton connually seeks advancements in its product design and quality. Therefore, while this manual
contains the most current product informaon available at the me of prinng, there may be minor
discrepancies between your machine and this manual.
If you have any quesons concerning this manual, please consult your local dealer.
First Published: May 2021

V2 1Winton WHB
General Safety Informaon
Ensure all potenal operators read this manual thoroughly before using the machine.
Safety: Ensure tractor and machine is staonary and keys out of ignion before set-up/maintenance.
Safety: Failure to follow good safety standards could result in severe injury or even death.
Misuse: This machine is designed for use with compact tractors, and should be used only for the
indicated purpose. Winton does not take responsibility if the machine is used for any other
purpose. Children must not operate the machine under any circumstance.
Modicaon: Do not modify equipment in any way. This may impair the operaon and overall
safety of the machine.
Tractor requirements: Use only with compact tractors within power range specied.
Misuse transport: Do not use machinery to transport personnel or livestock.
Condion: For the safety of personnel and opmum performance of the machine, you should
check the condion of the machine and the tractor before starng. Before use check all nuts and
bolts are ght.
Spaal awareness: Always check the operang area is safe before starng machinery.
Operator clothing: The operator should not wear loose clothing while operang machinery.
Safety wear: Always use appropriate ear protecon when running a tractor and machinery.
Ensure you are wearing protecve gloves when servicing and using machinery.
Bystander safety: Ensure bystanders keep away from the machine when it is in use. Do not
touch moving parts when the machine is at work.
Public places: When travelling on the road/public places, always keep the PTO turned o.
Maintenance: Always keep the machine maintained and in a good state. Where necessary,
repair or replace any defecve parts. Do not modify the machine.
Sharp objects: Pay aenon to the sharp/pointed parts while servicing the machine.
Safety guards: All protecve parts should be in good condion before operang machinery.
Safety signs/sckers: Keep all safety signs clean and legible. Replace any which are missing or
illegible. If a component with safety sign(s) is replaced, make sure new safety sign(s) are
aached in the same locaons.
Operang speeds: Machinery and PTO should be operated at the recommended speed at all
mes.
Safety awareness: Good safety requires that you familiarise yourself with various safety signs,
the type of warning and the area, or parcular funcon related to that area.
Alertness: Never consume alcohol or drugs as these can hinder alertness/coordinaon. Consult
your doctor about using this machine while taking prescripon medicaons.

V2 2Winton WHB
General Safety Informaon (Connued)
Machinery Pre-Use Checks
On receipt of your new Winton machine and again within the rst 4 hours of use, or the ‘shake in
period’, we always recommend checking over the machine.
• Check all bolts, nuts and screws are ght on the unit.
• Tighten/check any bolts and nuts securing blades.
• If your machine has belts check the tension and adjust if required.
• Apply grease to grease points if necessary.
• Check gear oil level and top up if needed. Do not overll.
Tractor Pre-Use Checks
Check that the machine is properly aached to the tractor. Ensure that secure pins are used on
the linkage mounng pins.
Be sure to add extra weights to the front of the tractor or add wheel weights if required.
Check that the tractor PTO sha turns freely and that the machines PTO drive sha can extend
easily. Grease the PTO drive sha using the grease points.
The chain on the PTO sha should be checked and in a good condion. The universal joints
installed should be in a good state, with proper protecve parts.
Before installing the PTO sha, the tractor and machine should be stopped and the key removed.
Install and secure all safety guards, doors and covers before starng.
Bystanders should leave the immediate area before connecng the drive to the tractor.
Running/Operang Checks
• Always keep the PTO output from the tractor at 540 RPM when running machinery.
Post-Use Regular Checks
Check blades, belts and wearing parts. Be sure they are not damaged and blades swing freely in
their mount. Repair or replace as required.
Clean machinery and check for/clear any entangled material which may have got stuck around
the rotang parts.

V2 3Winton WHB
Contents
Pg.
General Safety informaon 1-2
1. Dimensions and Specicaons 4
2. Set Up 5-7
3. Operaon 8
4. Auger Blade & Tip Replacement 9
5. Gear Oil Change & Check 10
6. Servicing & Maintenance 11
7. Parts Diagram 12
8. Parts List 13
9. PTO Sha Resizing
10. Winton Product Warranty
11. Trouble Shoong

V2 4Winton WHB
1. Dimensions & Specicaons
Model WHB06 WHB09 WHB12
Weight 138kg 148kg 158kg
No. Of Blades 224
Working Width 6 inches 9 inches 12 inches
PTO Turning Speed 540 RPM 540 RPM 540 RPM
Recommended Tractor HP 20-50 HP 20-50 HP 20-50 HP
Dims 177x79cm 177x79cm 177x79cm
PTO Sha Size 130-160cm 130-160cm 130-160cm
Linkage Size Category 1 Category 1 Category 1

V2 5Winton WHB
2. Installaon & Set-Up
Safety: Ensure tractor and machine is staonary and keys out of ignion before set-up/maintenance.
Safety: Before aaching/detaching machinery ensure the hydraulic li system is in a neutral posion.
Safety: Make sure the PTO drive isn’t connected at any point unl instructed to do so.
You will need:
Your tractor, a 2nd set of hands to assist with ng, linkage pins, PTO sha, and PPE safety wear.
Aaching The Machine
Start by nding a flat piece of ground. Posion your tractor in line with the machine.
1. Connect the lower link points on the machine’s A frame (A) to the tractor’s lower linkage arms.
2. Aach the main support arm (B) to the tractor’s top link area using the top link pin. The top
point of the hole borer should x directly to the top linkage point on the tractor. If you have a
top linkage arm ed you will need to remove this to access the mounng point.
B
A
C
D

V2 6Winton WHB
2. Installaon & Set-Up (Connued)
Safety: Ensure tractor and machine is staonary and keys out of ignion before set-up/maintenance.
Safety: Before aaching/detaching machinery ensure the hydraulic li system is in a neutral posion.
Safety: Make sure the PTO drive isn’t connected at any point unl instructed to do so
3. Then connect the A frame (A) to the outer pivot hole ( pivot hole furthest from the tractor) un-
der the main boom (B).
4. Raise and lower the tractor’s linkage to check the range of movement. Moving the pivot pin
closer to the tractor will increase the height the arm (B) will li.
5. Then aach the gear box (C) (input PTO sha facing the tractor) to the arm (B) by aligning the
holes and inserng the mounng pin.
6. Check the length of the PTO drive sha by separang the telescopic sha and aaching one sec-
on to the tractor PTO and the other to the digger gear box. Hold both secons together and
parallel. Lower the main arm 1 so the gearbox input sha is aligned to the PTO sha. Ensure the
PTO sha has a clearance of at least 150mm. Repeat the process at the maximum li height of
the boom. The minimum overlap must be 300mm when working and the driveline must be able
to travel at least 30mm.This operaon will determine the correct operang length of the drive
sha. The sha may need to be cut to size.
7. Connect the PTO drive sha to the gear box (C) and other end to the tractor PTO. Check that it
correctly meshes at both ends. Always couple the two ends of the driveline and check they are
locked in place. Completely insert the sprung lock pins into the grooves in the PTO sha on both
the tractor and machine sides. If a shear bolt or slip clutch safety system is used on the PTO
sha this should be mounted on the implement end.
8. Connect the auger (D) to the output sha of the gear box (C) with the shear pins. Tighten the
nuts securely.
9. Raise and lower the linkage carefully to ensure sucient ground clearance can be maintained.
Adjust the tractor’s ‘sway chains’ or linkage adjusters to prevent any side-ways movement.

V2 7Winton WHB
1
2
3
4
5
6
7
8
8
8

V2 8Winton WHB
3. Operaon
Safety: Ensure tractor and machine is staonary and keys out of ignion before set-up/maintenance.
Check your PTO sha’s grease points and apply grease if needed. Then aach the PTO drive sha and
ensure the locking pin is secure on both the tractor and machine sides. Aach the chain to a secure
point on the tractor/implement.
Operate the machine with the tractor in low range gear and the PTO delivering 540 RPM.
Pre-Use Checklist
Before starng the machine, always check and adjust the following:
• Blade condion. [Secon 4]
• Gear oil level. [Secons 5]
• Lubricaon/grease points. [Secon 6]
• Tightness of all bolts, nuts and screws.
• All protecve guards are in place.
Working Condions
Compacted ground and denser soil types should be covered at a slower pace for the best nish and to
avoid any damage to the machine. The speed that the machine is lowered downwards should be
adjusted to suit the ground being worked.
First Use Advice
Lower the tractor li arms unl the blades are near the ground without touching the ground. Working
depth should only be regulated by the height of the tractor’s lower linkage arms. Then engage the PTO
drive to the rated speed (540 RPM).
Next, slowly lower the li arms to the ground to allow the blades to gradually cut into the soil (do not
drop the machine suddenly to the ground). If you nd the machine is struggling on the surface then
reduce the speed the auger is being lowered. Then li the auger back out of the soil to release any
loose soil and lower again, repeat this step as many mes as necessary.
General Safety Tips
Never run the PTO or machine when the tractor is in moon.
Do not reverse with the machine unless this is strictly necessary. If unavoidable rst disengage the PTO
and make sure that the manoeuvre area is clear.
Never li the implement more than 25cm from the ground with the PTO driveline engaged or the
driveline could be damaged.

V2 9Winton WHB
4. Auger Blade & Tip Replacement
Safety: Ensure tractor and machine is staonary and keys out of ignion before set-up/maintenance.
Safety: Always take care when handling and changing sharp blades.
You may wish to remove the auger from the machine to change blades. Do this by removing the pin
securing the auger. If the auger is to remain aached then suciently li the machine so that the
blades can be accessed easily. Always support the machine on rigid supports and ensure it is stable
before carrying out any work.
The blades must always be replaced if they are damaged, bent, worn or blunt.
Changing Blades
1. The blade teeth are held in using the rubber tube, pull the blade out from the unit to release
this.
2. Insert the new blade and rubber tube.
3. The auger p can be removed by unscrewing the securing nut and bolt.
4. Replace the blade and then replace the nut and screw.

V2 10 Winton WHB
5. Gear Oil Check & Change
Safety: Ensure tractor and machine is staonary and keys out of ignion before set-up/maintenance.
Safety: Always follow manufacturers instrucons for oils and lubricants.
Important Informaon
Do not mix old and new oils together or mix dierent types of oil. Always dispose of old oils safely and
in the correct manner.
Always make sure the gearbox flat and level when checking oil levels. The machine should be le at a
standsll to cool down for at least 10 minutes. Ensure the machine is stable before carrying out work
and will not upturn.
Oil Change/Check Gearbox
1. Remove breather/ller plug (1) and level plug (2).
2. If draining and replacing oil remove drain plug (3) and let the oil drain out. Replace drain plug
(3).
3. The oil level should be up to the edge of level plug (2).
4. Top up with oil (if required) using ller hole (1).
5. Replace both ller/breather plug (1) and level plug (2).
Gear Oil Grade 80w90 gear oil (or equivalent)
Gearbox Oil Level Approx. 0.5 litres to level plug
First Oil Change 50 hours use
Oil Change Frequency 250 hours/yearly (whichever is rst)
2
1
3

V2 11 Winton WHB
6. Servicing & Maintenance
Safety: Store all lubricants away from excessive heat, dust, moisture and contaminants.
Safety: Ensure tractor and machine is staonary and keys out of ignion before set-up/maintenance.
Greasing & Lubricaon Points
Wipe grease nipples with a clean cloth before greasing to avoid injecng any dirt or grit. Press grease
into each grease nipple three to ve mes. We recommend using a hand-held grease gun for best
results. If grease nipples will not take grease, remove and clean thoroughly. Also clean lubricant
passageway. If you noce any grease points are broken replace or repair them immediately.
Greasing The PTO Sha x2
Grease both grease points on either end of the PTO sha and apply grease to the inner sha.
Other Maintenance
Blades: Check condion of the blades and replace if worn/broken. Always take care when handling
blades, wear gloves and use suitable tools for changing blades. Always check blade bolts are secured
and blades are adjusted correctly.
PTO Sha: Check the condion of your PTO sha and replace if worn or damaged immediately.
Cleaning: Ensure the machine is cleaned of debris. Remove debris is from any moving parts to
prevent entanglement. Aer use, with the PTO sha detached, turn the sha by hand to make sure
there no obstrucons.
Paintwork: Re-coat any damaged paintwork to prevent corrosion.
Storage: Store the machine in a dry, level area and ensure it is stable and unable to move or
overturn. Remove dirt from blades and the roller.
Safety Guards: Prior to each use check the condion of the guards. Replace if damaged or worn.
*The periods recommended are based on normal operang condions. Severe or unusual condions
may require more frequent maintenance.
Grease Type Mul-purpose lithium based grease
Grease Frequency Check every 4-8 hours (top up if required)

V2 12 Winton WHB
7. Parts Diagram
17
18 19
20
16
1
2
3
4
5
678
9
10
11
12 13
14
15
(2)
(2)

V2 13 Winton WHB
8. Parts List
Dia. No. Number Part Number Part Descripon Qty
1703820090 RB-00.102 Lower linkage pin 2
2 700080010 200.56.011 Lock/linch pin 3
3803800002 WX-L-03-001 A frame bracket 1
4 703800010 WX-L-00-101 A frame top pin 1
5 501011099 GB/T 5783 M8 x 20 Bolt M8X20 4
6 506010055 GB/T 97.1 8 Plain washer 8 4
7 803820041 WX-HL-13-001 PTO protecon hood 1
8803820063 WX-HL-09-001 Gear box 1
9803800011 WX-L-02-001 Frame arm 50 1
10 703340017 ZL-25.104 Pin large 2
11 703830001 WX-HL50-00-101 Gear box to arm pin 1
12 501010762 GB/T 5782 M12 x 90 Bolt M12x90 2
13 503010763 GB/T 889.1 M12 Nut M12 2
14 506010057 GB/T 97.1 12 Plain washer M12 2
15 Auger (various sizes) 1
16 703820003 WX-HL-00-107 Securing rubber bar 2/4
17 703820002 WX-HL-00-106 Blade 2/4
18 501011102 GB5783-M8X35 Bolt M8x35 1
19 703820004 WX-HL-00-108 Auger p 1
20 503010761 DIN985-M8 Nut M8 1

V2 14 Winton WHB
PTO Sha Resizing
Safety: Ensure tractor and machine is staonary and keys out of ignion before carrying out any work.
If you are not condent in carrying out the work consult your local supplier or mechanic.
Most PTO driven implements are supplied with a standard sized PTO sha. As all tractors vary this
oen means cung it down to size. Always replace worn or damaged PTO shas.
Aach the machine to the tractor without the PTO sha, raise the linkage so the PTO sha is level/
horizontal. Measure the length between tractor PTO and the machine’s sha. If the compressed
(closed) PTO sha length exceeds the one measured here then the driveline will need to be cut.
1. PTO length adjustment, rst remove PTO sha shielding.
2. Shorten the driveline tubes to proper equal lengths.
3. Tidy edges of the drive tube with a le and clean all llings from the tubes.
4. Shorten the equally long guard tubes to the same length as the driveline tubes.
5. Grease the internal driveline tube.
6. Fit the guard on the sha.
7. Make sure that the length allows for at least 16cm (6 inches) of overlap.

V2 15 Winton WHB
Winton Product Warranty
We always strive to create great products, but when something does go wrong we have a strong
network of resellers on hand throughout the UK to help out.
Warranty Claims
Before you get in touch here are 5 pieces of informaon your Winton reseller will need to progress
your claim:
• Your invoice/order details - to include date of purchase
• Machine model number
• Machine serial number
• Details of the fault
• Images/videos of the fault
The Terms & Condions
All products purchased as new are covered under our 12 month warranty from the date of
purchase. During this period Winton will repair or replace defecve parts free of charge. This
warranty is given on the proviso that the product has been used and maintained according to the
Owner’s Manual.
Warranty is carried out on a return to reseller / manufacturer basis and excludes any labour or
delivery / collecon costs.
Exclusions
• Wearing parts are excluded; including but not limited to blades, belts and bearings.
• Modicaon of the product in any way will cease the manufacturers warranty.
• The machine is warranted for one year to the original purchaser, resale within the period
will cease the warranty.
• Damage in transit is not covered. Claims will need to be made through the courier or your
Winton reseller directly.
• Compensaon for down-me, labour or loss of earnings is not covered by the warranty.
• No warranty extension will be granted for replacement parts ed.
• Damage caused by connued use of a faulty machine will not be covered.
Your Winton reseller will provide their own terms and condions upon purchase, consult this for
any addional queries.

V2 16 Winton WHB
Trouble-Shoong
Safety: Ensure tractor and machine is staonary and keys out of ignion before set-up/maintenance.
Always consult your Winton dealer if you have any quesons about your machine.
WHB Problem Soluon
Noisy Machine
Check all nuts and bolts are ghtened
Check the oil level in gearbox and top up if required
Add grease to grease points
Run at PTO speed 540 RPM
Ensure nothing in entangled in the auger
Excessive Vibraon
Run at PTO speed 540 RPM
Check and remove any foreign objects from the auger area
Check blades are in good condion and replace if broken
Ensure blades are mounted correctly and bolts are ght
Check auger spins freely and is not warped or damaged
Blades Clogged
Wait unl soil has dried up if at all wet
Lower the auger part way down in to the soil then raise up to release
the soil, repeat unl the desired depth is achieved
Insucient Working
Depth
Lower the working speed of tractor
Lower the gear of the tractor if struggling with engine power
Make several runs on harder soil

V2 17 Winton WHB
Notes

www.wintonmachinery.co.uk
