Winton WRB Series User manual

WINTON BOX GRADER
WRB SERIES
OWNERS MANUAL
PLEASE READ THIS MANUAL BEFORE OPERATING THE MACHINE

Congratulaons on purchasing your new Winton machine
Before you get started, we have provided a helpful space to jot down a few important
details about your new Winton machine.
Model Number: WRB
Serial Number:
Date of purchase:
Factory Reference: RB4/4BS, RB5/5BS, RB6/6BS
This manual should be considered a permanent part of this machine and should remain with it even if
the machine is subsequently sold.
Winton connually seeks advancements in its product design and quality. Therefore, while this manual
contains the most current product informaon available at the me of prinng, there may be minor
discrepancies between your machine and this manual.
If you have any quesons concerning this manual, please consult your local dealer.
First Published: February 2021

V1 1Winton WRB
General Safety Informaon
Ensure all potenal operators read this manual thoroughly before using the machine.
Safety: Ensure tractor and machine is stopped & keys out of ignion before set-up/maintenance.
Safety: Failure to follow good safety standards could result in severe injury or even death.
Misuse: This machine is designed for use with compact tractors, and should be used only for the
indicated purpose. Winton does not take responsibility if the machine is used for any other
purpose. Children must not operate the machine under any circumstance.
Modicaon: Do not modify equipment in any way. This may impair the operaon and overall
safety of the machine.
Tractor requirements: Use only with compact tractors within power range specied.
Misuse transport: Do not use machinery to transport personnel or livestock.
Condion: For the safety of personnel and opmum performance of the machine, you should
check the condion of the machine and the tractor before starng. Before use check all nuts and
bolts are ght.
Spaal awareness: Always check the operang area is safe before starng machinery.
Operator clothing: The operator should not wear loose clothing while operang machinery.
Safety wear: Always use appropriate ear protecon when running a tractor and machinery.
Ensure you are wearing protecve gloves when servicing and using machinery.
Bystander safety: Ensure bystanders keep away from the machine when it is in use. Do not
touch moving parts when the machine is at work.
Public places: When travelling on the road/public places, always keep the PTO turned o.
Maintenance: Always keep the machine maintained and in a good state. Where necessary,
repair or replace any defecve parts. Do not modify the machine.
Sharp objects: Pay aenon to the sharp/pointed parts while servicing the machine.
Safety guards: All protecve parts should be in good condion before operang machinery.
Safety signs/sckers: Keep all safety signs clean and legible. Replace any which are missing or
illegible. If a component with safety sign/(s) is replaced, make sure new safety sign/(s) are
aached in the same locaons.
Operang speeds: Machinery and PTO should be operated at the recommended speed at all
mes.
Safety awareness: Good safety requires that you familiarise yourself with various safety signs,
the type of warning and the area, or parcular funcon related to that area.
Alertness: Never consume alcohol or drugs these can hinder alertness/coordinaon. Consult
your doctor about using this machine while taking prescripon medicaons.

V1 2Winton WRB
General Safety Informaon (connued)
Machinery Pre-Use Checks
On receipt of your new Winton machine and again within the rst 4 hours of use, or the ‘shake
in’ period as we like to call it, we always recommend checking over the machine.
• Check all bolts, nuts and screws are ght on the unit.
• Tighten/check any bolts and nuts securing blades.
• If your machine has belts check the tension and adjust if required.
• Apply grease to grease points if necessary.
• Remove support/storage stands before operang machinery.
• Check oil levels and top up if needed.
Tractor Pre-Use Checks
Check that the machine is properly aached to the tractor. Ensure that secure pins are used on
the linkage mounng pins.
Be sure to add extra weights to the front of the tractor or add wheel weights if required.
Install and secure all safety guards, doors and covers before starng.
Bystanders should leave the immediate area before connecng the drive from the tractor.
Running/Operang Checks
• Always keep the PTO output from the tractor at 540 RPM when running machinery.
• Never use machinery at excessive speeds.
Post-Use Regular Checks
Check blades, belts and wearing parts. Be sure they are not damaged and blades swing freely in
their mount. Repair or replace as required.
Clean machinery and check for/clear any entangled material which may have got stuck around
any rotang parts.

V1 3Winton WRB
Contents
Pg.
General Safety informaon 1-2
1. Dimensions and Specicaons 3
2. Set Up & Operaon 4
3. Adjusng Ripper Tines 5
4. Changing Blades 6
5. Maintenance 7
6. Parts Diagram 8
7. Parts List 9
Winton Product Warranty 10
Troubleshoong 11
1. DIMENSIONS & SPECIFICATIONS
*All specicaons are subject to change without noce.
Model WRB4 WRB5 WRB6
Weight 190kg 250kg 310kg
Recommended Tractor HP 16hp+ 20hp+ 25hp+
Working Width 120cm 150cm 180cm
Width 120cm 150cm 180cm
Depth 65cm 65cm 65cm
Height 95cm 95cm 95cm
Linkage Size Category 1 Category 1 Category 1
Lower Linkage Width 80cm 80cm 80cm
Number Of Tines 456
Ripper Tine Working Depth 3-12cm 3-12cm 3-12cm
Number Of Scraper Blades 2 Reversible 2 Reversible 2 Reversible
Scraper Blade Steel Thickness 40mm 40mm 40mm
Steel Thickness 20mm 20mm 20mm

V1 4Winton WRB
2. SET UP & OPERATION
Safety: Ensure tractor and machine is stopped & keys out of ignion before set-up/maintenance.
Safety: Check for underground wiring, pipes or other obstrucons before operang.
You will need:
Your tractor, tractor top link arm (adjustable), linkage pins and some elbow grease!
Aaching The Machine
Start by nding a at piece of ground. Lower the three point linkage on your tractor to its lowest
posion and aach the machine to the tractor using the three point linkage pins and linch pins.
Adjust the tractor’s lower linkage arms up or down to ensure the machine sits level on the ground at
both ends. Extend or retract the tractor’s top linkage arm to get the box level so the front to back are
also both touching the ground.
Pre-Use Checklist
Before starng the machine, always check and adjust the following;
Tine height is set [Secon 3]. Blades are in good condion [Secon 4].
Check work site for underground obstrucons. Tightness of all bolts, nuts and screws. Ensure all safety
guards are in place.
General Operang Instrucons
When grading or levelling the working speed of the machine should always be at a walking pace
(approx. 2 to 4 mph).
With the ripper nes raised all the way up and tractor in moon, simply lower the box scraper blade to
ground level and it will start shaving the soil surface. Any dirt or aggregate material should accumulate
in the box. Move the material by dragging it and then raising the scraper to deposit your load.
Alternavely, set the scraper to shave o high spots on uneven ground and the accumulated material
will ow out under the blade in low spots. It can also be used for backlling, simply lower your scraper
and back the rear facing grader blade into the pile of dirt you are using for backll.
Occasionally the ground or surface material will be very hard and will require ripping to loosen the soil
to allow the scraper blade to be eecve. If more aggressive ripping acon is desired, lower the nes
by 2” increments. If less aggressive ripping acon is desired, raise all of the nes.
Geng the right set up requires experimentaon and experience in your given condions. Box
scrapers generally perform beer in dry to slightly damp soil condions.

V1 5Winton WRB
3. ADJUSTING RIPPER TINES
Safety: Ensure tractor and machine is stopped & keys out of ignion before set-up/maintenance.
Safety: Always take care when handling and changing sharp blades.
Occasionally the ground or surface material will be very hard and will require ripping to loosen the soil
to allow the scraper blade to be eecve. If more aggressive ripping acon is desired, lower the nes
by 2” increments. If less aggressive ripping acon is desired, raise all of the nes.
Suciently li the machine so that the blades and nes can be accessed easily. Always support the
machine on rigid supports and ensure it is stable before carrying out any work.
Ripper Tine Height Adjustment
1. Remove the R clip (1) and remove the curved pin (2)
2. Move the ripper nes (3) up or down to the desired height and align the holes on the ne
and body
3. Then re-insert pin (2) in the slot and replace R clip (1)
4. Repeat the process for the remaining nes so they are all level
3
21

V1 6Winton WRB
4. CHANGING BLADES
Safety: Ensure tractor and machine is stopped & keys out of ignion before set-up/maintenance.
Safety: Always take care when handling and changing sharp blades.
The grader blades on the inside and outside of the box are both reversable. The blade ps on the ends
of the nes can also be easily removed and replaced.
Make sure to suciently li the machine so that the blades and nes can be accessed easily. Always
support the machine on rigid supports and ensure it is stable before carrying out any work.
Changing Grader Blades
1. Remove all bolts 1
2. Flip over the worn blade or replace with a new blade aligning with holes on the body
3. Replace all bolts
Changing Blade Tips
1. Knock out the roll/stretch pins 2 with a punch or remove bolts and nuts if bolts are used.
2. Remove old blade p 3 and insert the new blade.
3. Replace roll/stretch pins and knock in to place or replace bolt and nut if preferred.
2
1
3

V1 7Winton WRB
5. MAINTENANCE
Safety: Ensure tractor and machine is stopped & keys out of ignion before set-up/maintenance.
Safety: Always take care when handling and changing sharp blades.
General Maintenance Tasks
Bolts: Aer using your scraper for several hours, check all bolts to be sure they are ght.
Blades: Check blade ps before use and replace when broken or worn.
Scraper: Check the condion of the scraper blades. The front and rear blades have two cung edges
and are reversible. Replace the cung blades when both edges are worn out.
Cleaning: Ensure the machine is cleaned of mud and grass. Remove debris is from any moving parts.
Paintwork: Re-coat any damaged paintwork to prevent corrosion.
Storage: Store the machine in a dry, level area and ensure it is stable and unable to move or overturn.
At the end of the working season or when your box scraper will not be used for long period, it is good
pracce to clean o any dirt or grease that may have accumulated on the scraper and any of the
moving parts.
Inspect scraper for loose, damaged or worn parts and adjust or replace if needed.
*The periods recommended are based on normal operang condions. Severe or unusual condions
may require more frequent maintenance.

V1 8Winton WRB
6. PARTS DIAGRAM
TS 2020
1
234
5
6
789
10
11
12
13
14
15
16
17
18
19
(3)
(3) (4) (5)
(5)
(4)

V1 9Winton WRB
7. PARTS LIST
Dia No. Part Number Part Descripon Qty
16GB.00.101 Grader blade 6 2
5GB.00.101 Grader blade 5 2
4GB.00.101 Grader blade 4 2
2GB2674- M16x40 Screw M16 8/ 10/ 12
3GB97.1-16 Plain washer M16 11/ 13/ 15
4GB93-16 Lock washer M16 11/ 13/ 15
5GB6170- M16 Nut M16 11/ 13/ 15
66BS.00.010 Main frame weldment 6 1
5BS.00.010 Main frame weldment 5 1
4BS.00.010 Main frame weldment 4 1
76BS.00.102 Scarier ne 4/ 5/ 6
86BS.00.109 Replaceable blade p 4/ 5/ 6
96BS.00.105 Pin, Lock 4/ 5/ 6
10 6BS.00.108 Clip pin 4/ 5/ 6
11 6BS.00.107 Lower linkage pin 2
12 GB93-22 Lock washer M22 2
13 GB6170- M22x1.5 Nut M22 2
14 6BS.00.103 A frame bracket 2
15 6BS.00.106 Steel collar 2
16 GB5782- M16x110 Bolt M16 1
17 6BS.00.103 Supporng bracket 2
18 GB5783- M16x50 Bolt M16 2
19 GB/T879.1-2000 Sloed spring pin 10x35 4/ 5/ 6

V1 10 Winton WRB
WINTON PRODUCT WARRANTY
We always strive to create great products, but when something does go wrong we have a strong
network of resellers on hand throughout the UK to help out.
Warranty Claims
Before you get in touch here are 5 pieces of informaon your Winton reseller will need to progress
your claim:
• Your invoice/order details - to include date of purchase
• Machine model number
• Machine serial number
• Details of the fault
• Images/videos of the fault
The Terms & Condions
All products purchased as new are covered under our 12 month warranty from the date of
purchase. During this period Winton will repair or replace defecve parts free of charge. This
warranty is given on the proviso that the product has been used and maintained according to the
Owner’s Manual.
Warranty is carried out on a return to reseller / manufacturer basis and excludes any labour or
delivery / collecon costs.
Exclusions
• Wearing parts are excluded; including but not limited to blades, belts and bearings.
• Modicaon of the product in any way will cease the manufacturers warranty.
• The machine is warranted for one year to the original purchaser, resale within the period
will cease the warranty.
• Damage in transit is not covered. Claims will need to be made through the courier or your
Winton reseller directly.
• Compensaon for down-me, labour or loss of earnings is not covered by the warranty.
• No warranty extension will be granted for replacement parts ed.
• Damage caused by connued use of a faulty machine will not be covered.
Your Winton reseller will provide their own terms and condions upon purchase, consult this for
any addional queries.

V1 11 Winton WRB
TROUBLE SHOOTING
Safety: Ensure tractor and machine is stopped & keys out of ignion before set-up/maintenance.
Always consult your Winton dealer if you have any quesons about your machine.
WRB Problem Soluon
Insucient Working
Depth
Lower the nes
Reduce the working speed of tractor
Lower the gear of the tractor if struggling with engine power
Make several runs on harder soil, starng at a reduced depth
Ground may be too hard, await rain fall and re-aempt
Box Not Collecng
Ensure the box is level le to right by adjusng the tractor’s lower
linkage arms
Check box is level front to back by adjusng the tractor’s top link arm
length
Ensure tractor linkage is at lowest point so the box touching the
ground
Tine Tips/ Blades
Breaking O
Reduce the working speed of tractor
Ground may be too hard, await rain fall and re-aempt
Check the ne ps/blades are secured prior to starng

V1 12 Winton WRB
NOTES

V1 13 Winton WRB

www.wintonmachinery.co.uk
