[FunctionInstruction]
²Multi-languagesvoice(default:EnglishandChinese);systemvolumeis
adjustable(low,medium andhigh);
²99 RFIDcardstoarm,disarm,andcontroltherelay;
²SMSnotification fordisarmbyRFIDcard;SMScontent(ofthefirst10
cards)iseditable;
²12-second voicemessage:bycontrol panel orremotely;
²Broadcastsystem timeandplayvoicemessage;
²Usepanelasatelephonetomakecalls;
²Setthesystembycontrol panel, SMSorremotecalls;
²10 remotecontrols,99wirelessand2wireddefensezones;
²Sensorlowpoweralertand tamperalert;
²SomeofSMSalarmcontentsareeditable;
²SMSalertforcontrol paneltamper, lowpower,powerfailure/recovery;
²Remotecontroltherelay.
[ControlPanel]
Inordertomakethecontrolpanelgetthewirelesssignalwellforall wireless
accessories,pleaseputthecontrolpanelatthecentralplaceofyourdefense
area.Makesureit sawayfromlargemetalobjectsand householdappliances
whichmaycausehighfrequencyinterference,aswellasbarrierssuchas
reinforcedconcretewall orfiredoor, etc.
Control Panel frontschematicdiagram:
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn
4
LEDindicator:
LED LEDStatus Systemworkingstatus
POWER ON Powersupplyisnormal
Flashper0.5second CheckingSIMcard
Comfort LEDflashing CheckingGSMnetwork
SIGNAL
Flashevery3seconds GSMnetworkisnormal
ON Alarming
Flashper0.5second Alarmingdelay
Flashevery3seconds Remotecall control
ALARM
Flashveryquickly Receive SMSwithcorrect
password
Comfort LEDflashing Recording
Flashtwice RFIDcardreadingsuccessfully
ON Playingvoicemessage
RECORD
Flashtwiceevery2
seconds
Newvoicemessage
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn
6
Note:
1. Pleasepayattentiontothesirenconnection.Positivesideto “ALARM
SPK”andnegativeto “GND”.Donotmixthetwocablestogetherwhen
connecting. Otherwise,it willdamagethetransistorinthecontrolpanel.
2. Wiredsensorconnection:connectonecableofthewiredsensortoGND
and theotherto “Z1orZ2”.ThedefaultSMScontentforZ1and Z2is
“01/02wirezonealarm!”.Thecontent couldbeedited.
[DoorContact]
Doorcontactisusedfordetectingthestatusofopenandcloseofwindowsand
doors. It willdetectitandsendthesignaltocontrol panel.
²Tearapartthedouble-sideadhesivetapeonthemagnetandthe
transmitter. Thenadherethemtotheappropriateposition.
²Magnetshouldbeneartothe
sideoftransmitterwithindicator.
Thetwoshouldalignwitheach
otherand thedistanceshould
not exceed10mm.
²Pleaseplugouttheantennafor
bettersignal.
²If thelow-powerindicatorison,pleasechangethebattery.
[PIRDetector]
PIRdetectorsareused
todetectthemovement
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn
7
withinacertainrange.
²Fixtheadjustmentbracketonthewall withtheprovidedscrewsand
attachthedetectortothebracket.Itisrecommendedtomountit ata
heightof2-2.2mabovethefloor.
²EffectofthePIRdetectionisbestwhenthedetectiondirectionisin90°
anglewiththewalkingdirection oftheintruder.Choosethemost
suitableinstallationplaceandangleaccordingtoactualsituation and
takingthefollowinginstallationdiagramasreferencetoensurethe
detectioneffect isbest.
²Pleasedonotfixitunderdirectsunlightorotherstronglightsandalso
keepit awayfromplaceswithfrequentstrongairstream.
²If thelow-powerindicatorison,pleasechangethebattery.
[Initialization]
-PleaseinsertSIMcard.Makesurethecardhasenoughbalancetomakecall
and send SMS.
-Connect thesiren, wiredsensors, orrelay
-Pluginpoweradaptor, andturnonthepowerswitch.Youwillhear “welcome
tousesmartalarmsystem”.ThePOWERindicatorwillbeonandthe
STATUSLEDflashesinorange.ThesystemstartscheckingtheGSM
network.
-setthelanguage(EnglishorChinese):00*0#(English);00*1#(Chinese).
Aftersetting,allthevoicepromptand SMSwillbeinthelanguageyouset.
(Pleasereferto[command chart])
ThesystemdefaultlanguageisEnglish.
[SystemAlarm]
Alarmcouldbetriggeredbyseveraldifferentways,includingSOSbuttonon
thepanel, emergencybuttonon theremotecontrols,wireless sensorsand
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn
8
wiredsensors.
Parttotrigger
alarm Howtotrigger
SOSbuttononthe
panel Pressitinstandbystatus,nomatterunder
armordisarm
Tamperalarm Thetamperalarmbuttononthebacksideof
thepanelisbouncedup (notinsetting
status)
SMScontent:Paneltamperalarm!
Emergencybuttonon
theremotecontrols Pressit(notinsettingstatus)
Wirelessandwired
sensors For “realtime”defensezone,triggerthe
sensorinarmstatus;
For “urgent”defensezone, triggerthesensor
inawayarm/ disarm/ orhomearm status;
For “delay”defensezone,triggerthesensor
inarmstatus;
For “close”defensezone,triggerthesensor,
itwillnotmakealarm.
[SystemSettings]
1. EnterSettings
Indisarmstatus,keeppressing until youhearthevoiceprompt “please
enterpassword”.Theninputthesettingpassword(systemdefault:123123).
If thepasswordiscorrect,youwillhear “passwordok.Nowpleasemake
choice:1.systemsetting;2.remotecontrolspairing;3.defensezonepairing;
4.cardpairing;5.deletesystemsettings.”Press thenumberofthesetting,and
toconfirm. It entersthecorrespondentsettingstatus.
If thepasswordiswrong,youwillhear “wrongpassword,pleasere-enter”.If
it swrongfor3times,orifthere snooperationover60seconds,thesystem
willexit settingmodeandreturntodisarm status.
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn
9
2. PairRemoteControls
Extraremotecontrolshastobepairedtothecontrolpanelinorderto
performnormally.Theoneinthestandardpackagehasbeenpaired.
Thisalarmsystemsupportsmaximum10remotecontrols.
Insetup state,press2tochooseremotecontrolspairingand toconfirm.
Thepanelwillmaketwobeeps. Thenpressanybuttonoftheremotecontrols.
Thepanelwillmakevoiceprompt “pairingcompleted;remotecontrolsXX”
afteritreceivesthesignalfromthecontrol.(XX meanstheserialnumberof
theremotecontrols).
3. PairWirelessSensors
Wirelesssensorshave tobepairedtothecontrolpanelinordertotriggerit
alarm.ThewirelessPIRanddoorcontactinthestandardpackagehave
beenpaired.
Thisalarmsystemhas99wirelessdefensezones.
Insetup state,press 3tochoosedefensezonepairingand toconfirm. The
panelwillmaketwobeeps.Thentriggerthewirelesssensoryouwanttoset.
Thepanelwill makevoiceprompt “pairingcompleted;XXwirelessdefense
zone”afterit receivesthesignalfromthesensor(XX meansthedefensezone
number).And thenyouwillhear “pleasechoosezonetype:1.RealTime;2.
Urgent;3.Delay;4.Close”.Choosethezonetypeandthenpress to
confirm. Ifyoudonotchoosethedefensezonetypeand press toconfirm.
Thezonetypewill beregardedasreal timezone.
4. PairRFIDCard
RFIDcardreferstoRadioFrequencyIdentificationcard.Itcanbeused
todisarmthealarmsystem,controltherelay,etc.Thissystemsupports
maximum99cards.
Insetup state,press 4tochoosedefensezonepairingand toconfirm. The
panelwillmaketwobeeps.Thenswipethecardoverthecardreadingarea.
Thepanelwillmakevoiceprompt “pairingcompleted;XX card”. (XX means
thecardserialnumber).
Forabovepairingofremotecontrols,wirelesssensor,and RFIDcard,the
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn
10
systemwill exitand returntodisarmstatusifthere snooperationover
30seconds.Iftheremotecontrolsorwireless sensororcardhasbeenpaired
before,youwill hear “repeatpairing”.
5. LeaveVoiceMessage
Thissystemsupportsvoicerecordingbythecontrolpanelorbyremotecall.
Themaximumtimeforrecordingis12seconds.
a. Leavemessagebythecontrol panel
Keeppressing onthepaneluntil youhear “starttoleavemessage”.12
secondslater,thepanelwillmakeabeepindicatingtherecordingstops.If
yourrecordingislessthan12s,youcanpress tostop.
b. Leavemessagebyremotecall
Pleaseenterremotecontrolmode(refertothepart[RemoteControl]).Press
“0#”tomakevoicerecord.
TheRECORDLEDwillflashifthere snewmessage.
6. PlaytheMessage
Instandbystatus,press . Thesystemwill broadcastthepresenttimeand
playtherecordedmessage.
7. VoiceMessageTimelyAlert
Userscansetacertaintime,atwhichthealarmpanelwillbroadcastthetime
and playtherecordedvoicemessageautomatically.Itsupportsmaximum3
groupsoftime.
Settingmethod:
1. Activatethisfunction:06*A*B#
A:1~3;referstothefirsttothirdgroup oftime
B:0/1;activate/ deactivatethisfunction(1:activate)
2. Setthetime:07*A*XXXX#
A:1~3;referstothefirsttothirdgroup oftime
XXXX:0000~2359,thetime
Forexample:setthefirstgroup timeas08:30
Operation:06*1*1#,07*1*0830#
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn
11
8. RelayControl
Userscancontroltherelayby3differentways.
1) RFIDcard
Instandbystatus,swipetheRFIDcardoverthecardreadingarea.Youwill
hear “awayarm”.Thenpress1toopentherelay(thewireports “COM”and
“PUSH”areconnected),andpress2tocloseit(“COMand “PUSH”
disconnected).
2) SMS
UserscansendSMStothealarmpaneltocontroltherelay.
Opentherelay:remotecontrolpassword+[#5#]
Closetherelay:remotecontrolpassword+[#6#]
Note:thedefault remotecontrolpasswordis123456.
3) Remotecall
Userscanalsocontroltherelaybyremotecall.(Pleaserefertothepart
[RemoteControl])
9. MonitorPanel Power
Thissystemhasthefunction ofSMSalertforexternalpowerfailure,power
recoveryandbatterylowpower.Whentheexternalpoweriscutoff,the
built-inLIbatterywill keepthesystemworking.You canchoosetoactivate/
deactivatethisfunction.Systemdefault:deactivated
Settingmethod:02*X#(X:0/1;0:deactivate; 1:activate)
TheSMScontent forexternalpowerdisconnection:Powerchargeroff;
powerrecovery:Powerchargeron;
batterylowpower:Systemlowpower.
10. ConnectOutdoorSiren
Thealarmpanelhasbuilt-intransmitterwhichcanworktogetherwith
wirelesssirens.
Insetup status,press1toenter “systemsetting”and toconfirm.Then
press44*1#.
Setthewirelesssireninpairingstatus.Thenpressarm/disarm/ SOSbuttonon
thealarmpanel.Thepaneltransmitterwillsendwirelesssignal.And thesiren
will makeabeepafterreceivingthissignal.
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn
12
Aftersettingthewirelesssiren,it srecommendedtoencryptittoavoid
interference.Thesignalcodesentfromthepaneltransmitterofthismodel
fromourcompanyarethesame.Ifyouand yourneighborbothareusingthis
model,thealarmsignalfromyourneighbormaycauseyoursirentosound.
In “systemsetting”status,press45*XXXX#.XXXX isa4-digit number
whichcouldbeinput randomly(0000~9999). Thedefault is1111.
11. CheckSystemStatus
UserscansendSMStothepaneltocheckthesystemstatus.SMSformat:
remotecontrol password+command
Command SMSreply
System status 100# Thesystemstatus:arm/ home
arm/ disarm.
IMEIcode 101# IMEI:(15-digit number)
Alarmphone
number 102# Call1:XXXXXXXXXX
Call2:XXXXXXXXXX
Call3:XXXXXXXXXX
Call4:XXXXXXXXXX
Call5:XXXXXXXXXX
AlarmSMS
number103# SMS1:XXXXXXXXXX
SMS2:XXXXXXXXXX
SMS3:XXXXXXXXXX
SMS4:XXXXXXXXXX
SMS5:XXXXXXXXXX
12. Command Chart
Insetup status,press1tochoose “systemsetting”andpress toconfirm.
Thendothesettingsaccordingtothefollowingcommand.All thefollowing
settingscanbefinishedbythecontrolpanel, SMSandremotecallexcept
speciallymarked.
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn
13
FunctionSetting Command Description
Languagesetting 00*[0/1]# 0:English, 1:Chinese
Voicevolume 01*X# X:1~3;1:low,2:medium,3:
high
Panelpowerfailure
/recovery/battery
lowpoweralert
02*[0/1]# 0:off, 1:on. Systemdefault:off.
SMSreplyfor
setting 03*[0/1]# 0:off, 1:on. Systemdefault:on.
SMSalert forRFID
carddisarm04*[0/1]# 0:off, 1:on. Systemdefault:off.
Timesetting 05*XXXX# XXXX:time0000~2359
Voice message
timelyalert 06*A*B# A:1~3,B:0/1
Voicemessagealert
time 07*A*XXXX# A:1~3,XXXX:time0000~2359
Phonecall time
setting 08*XX# XX:time00~60minutes.When
usersreceivealarmcall,or
remotelycallthealarmpanel, the
callwill beautomaticallyhung
up ifthere snooperation within
thistime.
Tamper alarm
setting 09*[0/1]# 0:off, 1:on. Systemdefault:off.
Wirelessdefense
zonetypesetting 10*XX*Y# XX:defensezonenumber01~99,
Y:zonetype1.Realtime;2.
Urgent;3. Delay;4. Close
Wirelesszone
“homearm”setting
11*XX*Y# XX:defensezonenumber01~99,
Y:1.Activate,0.Deactivate.
Afteractivatethisfunction,in
homearmstatus,whenthesensor
inthisdefensezoneistriggered,
itwill triggeralarm.
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn
14
Wirelesszone
alarm ring 12*XX*Y# XX:defensezonenumber01~99,
Y:0:off, 1:on.
e.g.:12*01*1#thesirenwill ring
whenzone01 istriggered.
Wireddefensezone
typesetting 13*XX*Y# XX:defensezonenumber01~02,
Y:zonetype1.Realtime;2.
Urgent;3. Delay;4. Close
Wiredzone “home
arm”setting 14*XX*Y# XX:defensezonenumber01~99,
Y:1.Activate,0.Deactivate.
Afteractivatethisfunction,in
homearmstatus,whenthesensor
inthisdefensezoneistriggered,
itwill triggeralarm.
Wiredzonealarm
ring 15*XX*Y# XX:defensezonenumber01~02,
Y:0:off, 1:on.
e.g.:12*02*1#thesirenwill ring
whenzone02 istriggered.
Wiredzonetrigger
method 16*XX*Y# XX:defensezonenumber01~02,
Y:1. NO, 0.NC.
Delete remote
controls 17*0#
Deletewireless
sensor 18*0#
DeleteRFIDcard 19*0#
Couldonlybesetbythealarm
panel.
Changeremote
control password 30*XXXXXX# XXXXXX:newpassword
(6-digit). Systemdefault:123456
Changesetting
password 31*XXXXXX# XXXXXX:newpassword
(6-digit). Systemdefault:123123.
Note:remotecontrolpassword
and settingpasswordcouldnotbe
thesame.
Alarmcallcircle
time 40*XX# XX:00~99,systemdefault:03.
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn
15
Alarmingtimeof
siren 41*XX# XX:00~30minutes.0meansno
sound whenalarming.System
default:03.
Delayarm time 42*XX# XX:00~99seconds. System
default:0(nodelay)
Delayalarm time 43*XX# XX:00~99seconds. System
default:40
Wireless
transmission 44*[0/1]# 0:off, 1:on. Systemdefault:off.
Wirelesssiren
encryption 45*XXXX# XXXX:0000~9999. System
default:1111
Storealarmphone
number 50*X*Y# X:serialnumber1~5.Y:phone
number(maximum20digits)
Deletephone
number 50*X*# X:serialnumber1~5
Alarm SMS
number 51* X*Y# X:serialnumber1~5.Y:phone
number(maximum20digits)
DeleteSMS
number 51*X*# X:serialnumber1~5
Wiredzonealarm
SMScontent
(Thiscouldonlybe
setbySMS.)
90*XX*content#
XX:zonenumber01~02.
e.g.:123123#90*01*Alarm!#
Thismeanswhenwiredzone01
istriggered,userswillreceive
thisSMS: Alarm!
SMScontentcouldnot exceed48
Englishlettersor12Chinese
characters.
Wirelesszone
alarmSMScontent
(Thiscouldonlybe
setbySMS.)
91*XX*content#
(SMScontent
couldnotexceed
48 English
lettersor12
XX:zonenumber01~16.
e.g.:123123#91*04*Door
Alarm!#
Thismeanswhenwirelesszone
04 istriggered,userswillreceive
thisSMS:DoorAlarm!
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn
16
Chinese
characters.)
SMScontentfor
RFIDcarddisarm 92*XX*content#
(SMScontent
couldnotexceed
48 English
lettersor12
Chinese
characters.)
XX:RFIDcardserialnumber
01~10.
e.g.:123123#91*02*Tom
disarm#
Thismeanswhenthesystemis
disarmedbythesecond RFID
card,userswillreceivetheSMS:
Tomdisarm.
13. SystemSettingbySMS
All theabovesettingscouldbefinishedbySMS.
Useamobilephonetosend messagetothealarmpanel.TheSMSformat:
settingpassword+command (defaultpassword:123456).Aftersuccessful
setting,youcanreceiveamessagefeedback:ok,programsuccessfully.Ifthe
settingSMSiswrong, youwillreceive:FORMATERROR!
Note:SMSsettingiseasilyaffectedbyGSMnetworkwhichmaycausedelay,
soit srecommendedtodothesettingsbythepanel orremotecall.
14. SystemSettingbyRemoteCall
Mostoftheabovesettingscouldbesetbyremotelycallthealarmpanel.Call
thealarmpanelwithamobilephoneorlandlinephone;youwillhearvoice
prompt “pleaseenterpassword”whenthecallgetsthrough.Inputthesetting
password(default:123123)and “#”.
If thepasswordiswrong,youwillhear “wrongpassword,pleasere-enter”.If
it swrongfor3times,orifthere snooperationover30 seconds,thecall
wouldbehungupautomatically.
15. DeleteSettings
Insetupstate,press5tochoose “deletesystemsettings”andpress to
confirm.Thenyouwill heartwobeeps.All settingsbyuserswillbedeleted
and returntofactorydefaultsetting,but thecodingrecordwill notbedeleted.
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn
17
16. FactoryReset
Instandbystatus, pressdisarm buttononthepanel.Afterhearing “pleaseenter
passwordtodisarm”,input “95175308246”andpress toconfirm.The
panel willmakevoice “backtofactoryreset”indicatingsettingfinished.
Afterthisoperation,allthesettingsarereturnedtofactorydefaultand allthe
codingwillbedeleted.
[OperationInstructions]
1. SystemStatus. Thereare4statusasfollowing:
lAwayArm: defensezone1~99 willalarmwhendetectorsare
triggered
lHomeArm: inhomearmstatus,thedefensezonewhichissetas
[HomeArm]willalarmwhendetectorsaretriggered
lDisarm: defensezone1~99 willnotalarmwhendetectortriggered
(exceptimmediatedefensezone)
lSystemsetupstatus:Inthisstatus,all defensezoneswill notalarm
whendetectorsaretriggered.
2. RemoteControlsOperation
UserscanuseremotecontrolstosetsystemasAwayArm,HomeArm,
EmergencyAlarm, Disarm andetc.
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn
18
3. AwayArm
TheAwayArmfunctionwill armthealarmsystemall around yourhouse,
includingthesensors,whileeveryoneisgoingout. Whenthedetectoris
triggeredeitherbyunauthorizedentry,firesorsmokegasleak,etc., the
alarm systemwill triggerthealarm.
Operationbythecontrolpanel: Press buttononkeypad,systemwill
enterarmstatus40secondslaterordelaytimesetbytheuser.Foreach
second ofthedelaytime,thepanelwill makeabeep.
OperationbyRFIDcard: swipethecardoverthecardreadingarea,the
RecordingLEDwill flashtwice andthesystem entersawayarm status.
OperationbySMS: remotecontrolpassword(default:123456)+[#1#].
Thecontrolpanel willsend amessageback “->OK, systemarmed”.
4. HomeArm
Thisalarmmodewillallowthesystemtobesetupsothealarmsareonly
triggeredthroughtheexternalsensors,whenthereissomeoneinsidethe
property.Itwillenabletheperipheraldoor,window,balconyand
boundarydetectorsofthealarmsystemwhiledisablingtheindoor
detectors. Iftheinternal sensorsareenabledit maycausefalsealarmsand
unwantedalarm triggerwarnings.
Firstlyyouneedtoactivatethewirelesszonehomearmsetting(please
refertothe[command chart]).
Operationbythecontrol panel: Press button
5. Disarm
Thiswill stopthealarmalertwhenthealarmhasbeentriggered,oritwill
disablethesystem.Afterdisarming,evenifyoutriggerthedetector,the
mainunitwouldnotsoundalarm(excludingimmediatedefensezones).
Operationbythecontrolpanel: press button andtheninputthe
password(default:123456)andfinallypress
OperationbyRFIDcard: swipethecardoverthecardreadingarea.Do
not takeit awayuntilyouhearalongbeepandtwoshortbeeps.
OperationbySMS: remotecontrolpassword(default:123456)+[#2#].
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn
19
Thecontrolpanel willsend amessageback “->OK, systemdisarmed”.
6. EmergencyHelp
Press buttononthecontrolpanelforabout3seconds.Nomatterthe
systemisinarmordisarmstatus,it willmakealarmimmediately.
7. AnswerAlarmCall
Whenthecontrolpanelsoundsthealarm,itwilldialthepresetnumbers.
If nooneanswersthecall,thesystemwillcallthenextusernumber
automatically.Thesystemwillcall eachpresetnumbersfor3timesin
order.(This “Alarmcallcircletime”couldbesetreferringto[command
chart])
If youanswerthecall,youwillhearthealarmvoice(e.g.Ifzone01is
triggered,youwill hear"01wirelesszonealarming").Youcansetsystem
viayourtelephoneormobilephonekeypad.
If youhang-up directlywithoutansweringthecall,thesystemwill keep
callingthenextnumber.
Press[1#]:SystemstopsalarmingandArm; it stopscallingusers.
Press[2#]:SystemstopsalarmingandDisarm; itstopscallingusers.
Press[3#]:Turnssirenoffand monitorsthescene.
Press[4#]:Systemstartstwo-wayintercom.Itcannotbecontrolledby
themobileduringthetimeofintercom.
Press[5#]:Turnrelayon.
Press[6#]:Turnrelayoff.
Press[#]:Playthealarmmessageagain.
8. RemotelyControl
Dialthenumberassociatedtothecontrol panelbyphone(mobilephone),
and afteroneringingcycle,youcanhearavoiceprompt “Pleaseenter
password”.Inputtheremotecontrolpassword(default:123456)and “#”.
If thepasswordisright, youwill hear “passwordok,pleaseenter
command”.Ifthepasswordiswrong,youwillhearapromptvoice
“wrongpassword,pleasere-enter”.
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn
20
Press[1#]:arm,iffinishedsuccessfully,youwill hearavoiceprompt
“arm”.
Press[2#]:disarm, iffinishedsuccessfully,youwill hearavoiceprompt
“disarm”.
Press[3#]:monitorthescene.
Press[4#]:two-wayintercom.Youcan toperatethesystemduringthis
time.
Press[5#]:Turnrelayon.
Press[6#]:Turnrelayoff.
Press[0#]:Leavevoicemessage.Youwillhearvoiceprompt “please
leavemessageafterbeep”.12secondslater,it prompts “message
finished”andexits.
[Note]
Foreachpressing,therewillbeashortbeepsound.Ifthere snobeep
sound,pleasere-enter.And therewillbethree shortbeepsforwrong
operation.
9. SystemDialingFunction
Indisarmstatus,youcanusethemainunit tomakeanycalljustlikea
land-linetelephone.Press buttonon thepanel,youwill hearvoice
prompt “pleaseinputphonenumber”.Dialthetelephonenumberonthe
keypadandthenpress . Press candeletethenumberinput.And
keeppressing foralongtimecanexitorhangupthecall.
[TechnicalParameters]
Powersupply:AC=100V~240V,DC=12V,1.2A
Built-inbattery:7.4V, 1000mALIbattery
Standbycurrent:<70mA
Alarmingcurrent:<450mA
GSMband:850/900/1800/1900MHz
Wirelessfrequency:433MHz ±0.5MHz
Wirelessreceivingsensitivity:5mV/m
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn
Table of contents
Other Wolf-Guard Security System manuals
