Gas Multi-Function Cooktop
For true wok cookin , the burner of the
Wolf multi-function cooktop sculpts the
as flame into a plume, focusin heat in
the center of the wok, then dispersin it
outward for precisely controlled cookin .
The low-profile rate fits nicely with any
Wolf as cooktop and can accommodate
your lar est stockpot. The powerful
burner exceeds 22,000 Btu. The Wolf
multi-function cooktop is available natural
or LP as.
FEATURES
•Integrated design allows for installation of
multiple cooktops or modules.
•Stainless steel top construction.
•High output 22,000 Btu dual-stacked
sealed burner.
•Automatic electronic reignition system.
•Illuminated control panel.
•Individual spark ignition system.
•Two interchangeable cast iron burner
grates with matte porcelain finish—wok
grate and low-profile continuous grate.
•Deep drawn burner pan.
ACCESSORIES
•Filler strip for installation of multiple
cooktops or modules.
•Bracket supports for installation of two
integrated modules with downdraft
(model DD30 only).
•High altitude conversion kit.
Accessories are available t roug your aut orized
Wolf dealer. For local dealer information, visit t e
find a s owroom section of our website,
wolfappliance.com.
Model IM15/S s own
wit wok grate.
Model IM15/S s own. Also s own is model CT15G/S
gas cooktop and model DD30 downdraft ventilation system.
Control panel.

INSTALLATION NOTES
Natural gas installations above 10,250' and
L gas installations above 8,600' require the
high altitude conversion kit.
Complete installation specifications can be
found on our website, wolfappliance.com.
Sown wit wok grate.
Unit dimensions may vary by ± 1/8".
SPECIFICATIONS
Exterior Finish Stainless Steel
Overall Width 15"
Overall Height 5"
Overall Depth 21"
Burner Rating 22,000 Btu
Minimum Cabinet Depth 223/4"
Minimum Height Clearance* 5"
Countertop Cut-Out Width 14"
Countertop Cut-Out Depth 191/4"
Electrical Requirements 120 V AC, 60 Hz
15 amp circuit
ower Cord 6' cord with grounded plug
Gas Rating 22,000 Btu
Shipping Weight 30 lbs
*A minimum eig t clearance of 5 1 /2" is required
between countertop and any combustible surface
directly below t e cooktop.
INSTALLATION SPECIFICATIONS
OVERALL DIMENSIONS
Gas Multi-Function Cooktop
Dimensions in parent eses are in
millimeters unless ot erwise specified.
1/2"(13)
SIDES
1" (25) FRONT / BACK
5" (127)
21" (533)
15"
(381)
36" (914)
FLOOR TO
COUNTERTOP
30" (762) min
COUNTERTOP
TO COMBUSTIBLE
MATERIALS
SEE COUNTERTOP
CUT-OUT BELOW
14" (356)
CUT-OUT
WIDTH
COUNTERTOP CUT-OUT
FRONT
191/4"(489)
CUT-OUT
DEPTH
21/2"(64) min
7" (178) TO
COMBUSTIBLE*
7" (178) TO
COMBUSTIBLE*
SIDE
CABINET
13" (330)
max
*Minimum clearance from cooktop cut-out to combustible materials up to 18" (457) above countertop.
NOTE: Application shown allows for installation of two 15" (381) modules side by side.
E
15" (381)
15"
(381)
4"
(102)
18" (457) min
5"
(127)
LOCATION OF GAS
AND ELECTRICAL
EXTENDS ON FLOOR
G
21/2"
(64)*
Countertop Cut-Out Dimensions
