Wood Stone Mt. Chuckanut WS-MS-4 User manual

PG 1 OF 4
M0330.00 DECEMBER 2020
An ongoing program of product improvement may
require us to change specifications without notice.
WOOD STONE CORPORATION
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
TOLL FREE 800.988.8103
TEL [phone]
FAX [phone]
E-MAIL [e-mail]
woodstone-corp.com
OUTDOOR CHIMNEY
INSTALLATION INSTRUCTIONS
BL/BH/MS/MH/TS Ovens
123456
A
B
C
D
123456
A
B
C
D
BL 3030 / MS 4
CHIMNEY KIT 8 INCH GALV
WOOD STONE CORPORATION
1801 W. BAKERVIEW RD. BELLINGHAM, WA 98226
360.650.1111 - WOODSTONE-CORP.COM
PART NO.
000-CHIMNEY-KIT-01
SIZE
B
REV
0
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF WOOD STONE CORPORATION.
ANY REPRODUCTION OR USE IN PART OR AS A WHOLE WITHOUT EXPRESS WRITTEN PERMISSION OF WOOD STONE CORP. IS PROHIBITED.
FINISH: N/A
MATL: N/A SCALE: NTS
DECIMAL: ± 0.030
ANGULAR: ± 2°
UNLESS OTHERWISE SPECIFIED
DIMENSIONS ARE IN INCHES
TOLERANCES:
FRACTIONAL: ± 1/16
HOLES/SLOTS
Ø : ± 0.010
SHEET: 1 OF 1
REV PROJ DESCRIPTION & JUSTIFICATION ZN-SH REV BY DATE
05107 INITIAL RELEASE -MRM 11/12/2020
NOTES:
SPECIFICATIONS NOT SHOWN ON THIS DRAWING SHALL BE
OBTAINED FROM THE REFERENCED SOURCES OF SUPPLY.
1.
ENGR CHECK
MFG CHECK
DATE: 11/12/2020
CREATED BY: MARKM
PROJECT: 5107
32.260
32 1/4
O
15.000
15
13.671
13 11/16
11.558
11 9/16
9.930
9 15/16
ITEM PART NO REV DESCRIPTION MATERIAL QTY
1* 4000-0049 0JOINT SEALANT HIGH TEMP 3 OZ 1
25310-1430 0CHIMNEY ADAPTER WELDMENT 1
37000-1953 0DURAVENT CAP 8" 1
47000-1954 0DURAVENT DUCT 8IN_24L GALV 1
57000-1961 0DURAVENT SPARK ARRESTER 8 INCH 1
69000-0151 0#12 X 1 TEK-5 SCREW SS STAINLESS STEEL 11
7* M0330 0CHIMNEY INSTALLATION INSTRUCTIONS 1
3
4
6
2
5
8" ID Chimney Cap
8" ID Chimney Section
8" ID Chimney Adapter
123456
A
B
C
D
123456
A
B
C
D
BL 4343 / 4355 / 4836
CHIMNEY KIT 10 INCH GALV
WOOD STONE CORPORATION
1801 W. BAKERVIEW RD. BELLINGHAM, WA 98226
360.650.1111 - WOODSTONE-CORP.COM
PART NO.
000-CHIMNEY-KIT-03
SIZE
B
REV
0
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF WOOD STONE CORPORATION.
ANY REPRODUCTION OR USE IN PART OR AS A WHOLE WITHOUT EXPRESS WRITTEN PERMISSION OF WOOD STONE CORP. IS PROHIBITED.
FINISH: N/A
MATL: N/A SCALE: NTS
DECIMAL: ± 0.030
ANGULAR: ± 2°
UNLESS OTHERWISE SPECIFIED
DIMENSIONS ARE IN INCHES
TOLERANCES:
FRACTIONAL: ± 1/16
HOLES/SLOTS
Ø : ± 0.010
SHEET: 1 OF 1
REV PROJ DESCRIPTION & JUSTIFICATION ZN-SH REV BY DATE
05107 INITIAL RELEASE -MRM 11/12/2020
NOTES:
SPECIFICATIONS NOT SHOWN ON THIS DRAWING SHALL BE
OBTAINED FROM THE REFERENCED SOURCES OF SUPPLY.
1.
ENGR CHECK
MFG CHECK
DATE: 11/12/2020
CREATED BY: MARKM
PROJECT: 5107
ITEM PART NO REV DESCRIPTION MATERIAL QTY
1* 4000-0049 0JOINT SEALANT HIGH TEMP 3 OZ 1
25300-1432 0CHIMNEY ADAPTER WELDMENT 1
37000-1950 0DURAVENT CAP 10" 1
47000-1951 0DUCT 10" X 24" L GALV 1
59000-0151 0#12 X 1 TEK-5 SCREW SS STAINLESS STEEL 11
6* M0330 0CHIMNEY INSTALLATION INSTRUCTIONS 1
O
22.000
22
17.646
17 5/8
13.773
13 3/4
35.160
35 3/16
12.000
12
3
4
5
2
8" ID Chimney 10" ID Chimney
10" ID Chimney Cap
10" ID Chimney Section
10" ID Chimney Adapter
THIS ASSEMBLY IS FOR OUTDOOR USE ONLY FOR OPEN AIR INSTALLATIONS
Note that Galvalume (matte finish) chimney sections must be painted with a suitable high-temp coating (rated for
500°F min.) such as Rustoleum V200 Series prior to installation. Other suitable coating may be used. Consult the
coating manufacturer's instructions to ensure suitability for this application. Polished stainless components are ready for
installation without additional prep or painting.

PG 2 OF 4
M0330.00 DECEMBER 2020
An ongoing program of product improvement may
require us to change specifications without notice.
WOOD STONE CORPORATION
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
TOLL FREE 800.988.8103
TEL [phone]
FAX [phone]
E-MAIL [e-mail]
woodstone-corp.com
OUTDOOR CHIMNEY
INSTALLATION INSTRUCTIONS
BL/BH/MS/MH/TS Ovens
QUESTIONS? Give us a call at 800.988.8103
Our normal service hours are 8am to 5pm Pacific Time, Mon–Fri. If calling after hours, follow the
recorded instructions for emergency service and a Wood Stone technician will get back to you promptly.
INSTALLING THE OUTDOOR CHIMNEY
8" ID CHIMNEYS--WS-BL-3030, WS-BH-3030, WS-MS-4, WS-
MH-4 MODELS
The proper adapter plate for your oven looks like Figure 1.
Note: If your oven was ordered with the chimney kit, this plate
may already be installed. If so, skip to step #3 below.
1. Remove flanged adapter plate (See Figure 3 below) from oven
if installed.
2. Install new adapter plate as shown.
3. Place 8-inch ID chimney section onto the starter collar on
the adapter. Twist clockwise until it locks into place.
NOTE:
Apply the supplied Engineered Grade Ceramic
Sealing Compound to the underside of the
adapter with an unbroken bead around the
perimeter, and around each individual screw
hole, as shown in Figure 2 to the right.
Line up screw holes
Attach w/ #10 self-tapping screws + washer
(provided) in each screw hole.
4. Place the chimney cap onto the top of the 8-inch ID
chimney section. Twist clockwise until it locks into
place. Installation is complete.
NOTE: Fit the mesh
spark arrestor
screen into the
chimney cap before
placing on chimney.
123456
A
B
C
D
123456
A
B
C
D
BL 3030 / MS 4
CHIMNEY ADAPTER WELDMENT
WOOD STONE CORPORATION
1801 W. BAKERVIEW RD. BELLINGHAM, WA 98226
360.650.1111 - W OODSTONE-CORP.COM
PART NO.
5310-1430
SIZE
B
REV
0
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF WOOD STONE CORPORATION.
ANY REPRODUCTION OR USE IN PART OR AS A WHOLE WITHOUT EXPRESS WRITTEN PERMISSION OF WOOD STONE CORP. IS PROHIBITED.
FINISH: N/A
MATL: N/A SCALE: NTS
DECIMAL: ± 0.030
ANGULAR: ± 2°
UNLESS OTHERW ISE SPECIFIED
DIMENSIONS ARE IN INCHES
TOLERANCES:
FRACTIONAL: ± 1/16
HOLES/SLOTS
Ø : ± 0.010
SHEET: 1 OF 1
REV PROJ DESCRIPTION & JUSTIFICATION ZN-SH REV BY DATE
05107 INITIAL PRODUCTION RELEASE -MRM 10/29/2020
NOTES:
SPECIFICATIONS NOT SHOWN ON THIS DRAWING SHALL BE
OBTAINED FROM THE PROVIDED 3D MODEL, UNLESS OTHERWISE
NOTED. INFORMATION SHOWN ON THIS DRAWING SHALL
PRECEDE THAT WHICH IS DERIVED FROM THE 3D MODEL.
SPECIFICATIONS OMITTED FROM WELD NOTES SHALL BE
DETERMINED AT FABRICATOR'S DISCRETION, UNLESS
OTHERWISE NOTED.
ALL WELDS MUST BE SOLID AND FREE OF SURFACE HOLES.
RESURFACE ALL WELDS TO BLEND WITH FINISH.
1.
2.
3.
4.
ENGR CHECK
MFG CHECK
DATE: 10/29/2020
CREATED BY: MARKM
PROJECT: 5107
TYP 3/32
CENTER DUCT ON HOLE
O
8.000
8
13.671
13 11/16
11.558
11 9/16
4.375
4 3/8
1.375
1 3/8
ITEM PART NO REV DESCRIPTION MATERIAL QTY
11560524 1TRANSITION CHIMNEY BASE STAINLESS STEEL, 304 1
25310-1429 0CHIMNEY ADAPTER 8 INCH 1
1
2
TYP
NO VISIBLE
LIGHT
3/32 1/2 - 2
Figure 1--8" twist-lock collar weldment
Figure 3--flanged adapter that must be removed from
oven before installing the chimney, if it is currently
installed on your oven.
Figure 2--Underside of adapter
showing where Ceramic Sealing
Compound should be applied

PG 3 OF 4
M0330.00 DECEMBER 2020
An ongoing program of product improvement may
require us to change specifications without notice.
WOOD STONE CORPORATION
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
TOLL FREE 800.988.8103
TEL [phone]
FAX [phone]
E-MAIL [e-mail]
woodstone-corp.com
OUTDOOR CHIMNEY
INSTALLATION INSTRUCTIONS
BL/BH/MS/MH/TS Ovens
INSTALLING THE OUTDOOR CHIMNEY
10" ID CHIMNEYS--WS-BL-4343, WS-BH-4343, WS-BL-4355, WS-
BH-4355, WS-MS-5, WS-MH-5, WS-MS-6, WS-MS-7 MODELS
The proper adapter plate for your oven looks like Figure 4.
Note: If your oven was ordered with the chimney kit, this plate
may already be installed. If so, skip to step #3 below.
1. Remove flanged adapter plate from oven if installed.
2. Install new adapter plate as shown.
3. Place 10-inch ID chimney section onto the starter collar on
the adapter plate. Use the 6 #8 self-tapping screws (pro
vided )to secure the chimney to the adapter at the base.
NOTE:
Apply the supplied Engineered Grade Ceramic
Sealing Compound to the underside of the
adapter with an unbroken bead around the
perimeter, and around each individual screw
hole, as shown in Figure 2 to the left.
Line up screw holes
Attach w/ #10 self-tapping screws + washer
(provided) in each screw hole.
4. Place the chimney cap on to the top of the 10-inch ID
chimney section. Use the 6 #8 self-tapping screws
(provided) to secure the chimney cap to the chimney
section. Installation is complete.
123456
A
B
C
D
123456
A
B
C
D
BISTRO 4343 / 4355 / 4836
CHIMNEY ADAPTER WELDMENT
WOOD STONE CORPORATION
1801 W. BAKERVIEW RD. BELLINGHAM, WA 98226
360.650.1111 - W OODSTONE-CORP.COM
PART NO.
5300-1432
SIZE
B
REV
0
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF WOOD STONE CORPORATION.
ANY REPRODUCTION OR USE IN PART OR AS A WHOLE WITHOUT EXPRESS WRITTEN PERMISSION OF WOOD STONE CORP. IS PROHIBITED.
FINISH: N/A
MATL: N/A SCALE: NTS
DECIMAL: ± 0.030
ANGULAR: ± 2°
UNLESS OTHERW ISE SPECIFIED
DIMENSIONS ARE IN INCHES
TOLERANCES:
FRACTIONAL: ± 1/16
HOLES/SLOTS
Ø : ± 0.010
SHEET: 1 OF 1
REV PROJ DESCRIPTION & JUSTIFICATION ZN-SH REV BY DATE
05107 INITIAL PRODUCTION RELEASE -MRM 10/29/2020
NOTES:
SPECIFICATIONS NOT SHOWN ON THIS DRAWING SHALL BE
OBTAINED FROM THE PROVIDED 3D MODEL, UNLESS OTHERWISE
NOTED. INFORMATION SHOWN ON THIS DRAWING SHALL
PRECEDE THAT WHICH IS DERIVED FROM THE 3D MODEL.
SPECIFICATIONS OMITTED FROM WELD NOTES SHALL BE
DETERMINED AT FABRICATOR'S DISCRETION, UNLESS
OTHERWISE NOTED.
ALL WELDS MUST BE SOLID AND FREE OF SURFACE HOLES.
RESURFACE ALL WELDS TO BLEND WITH FINISH.
1.
2.
3.
4.
ENGR CHECK
MFG CHECK
DATE: 10/29/2020
CREATED BY: MARKM
PROJECT: 5107
13.773
13 3/4
17.646
17 5/8
O
10.000
10
1.250
1 1/4
4.500
4 1/2
CENTER DUCT ON HOLE
TYP 3/32
ITEM PART NO REV DESCRIPTION MATERIAL QTY
11560590 2CHIMNEY BASE STAINLESS STEEL, 304 1
25300-1431 0CHIMNEY ADAPTER 10 INCH 1
2
1
TYP
NO VISIBLE
LIGHT 3/32 1/2 - 2
Figure 4-- 10" collar weldment
Figure 2--Underside of adapter
showing where Ceramic Sealing
Compound should be applied

PG 4 OF 4
M0330.00 DECEMBER 2020
An ongoing program of product improvement may
require us to change specifications without notice.
WOOD STONE CORPORATION
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
TOLL FREE 800.988.8103
TEL [phone]
FAX [phone]
E-MAIL [e-mail]
woodstone-corp.com
OUTDOOR CHIMNEY
INSTALLATION INSTRUCTIONS
BL/BH/MS/MH/TS Ovens
123456
A
B
C
D
123456
A
B
C
D
TS 5 / 6 / 7
CHIMNEY KIT 10 INCH GALV
WOOD STONE CORPORATION
1801 W. BAKERVIEW RD. BELLINGHAM, WA 98226
360.650.1111 - WOODSTONE-CORP.COM
PART NO.
000-CHIMNEY-KIT-07
SIZE
B
REV
0
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF WOOD STONE CORPORATION.
ANY REPRODUCTION OR USE IN PART OR AS A WHOLE WITHOUT EXPRESS WRITTEN PERMISSION OF WOOD STONE CORP. IS PROHIBITED.
FINISH: N/A
MATL: N/A SCALE: NTS
DECIMAL: ± 0.030
ANGULAR: ± 2°
UNLESS OTHERWISE SPECIFIED
DIMENSIONS ARE IN INCHES
TOLERANCES:
FRACTIONAL: ± 1/16
HOLES/SLOTS
Ø : ± 0.010
SHEET: 1 OF 1
REV PROJ DESCRIPTION & JUSTIFICATION ZN-SH REV BY DATE
05107 INITIAL RELEASE -MRM 11/12/2020
NOTES:
SPECIFICATIONS NOT SHOWN ON THIS DRAWING SHALL BE
OBTAINED FROM THE REFERENCED SOURCES OF SUPPLY.
1.
ENGR CHECK
MFG CHECK
DATE: 11/12/2020
CREATED BY: MARKM
PROJECT: 5107
ITEM PART NO REV DESCRIPTION MATERIAL QTY
15300-1431 0CHIMNEY ADAPTER 10 INCH 1
27000-1950 0DURAVENT CAP 10" 1
37000-1951 0DUCT 10" X 24" L GALV 1
47000-1952 0DURAVENT STORM COLLAR 10" 1
57000-1955 0DURAVENT V BAND 10 INCH 1
6* 7000-1962 0SILICONE PERMATEX 650F 1
7* M0330 0CHIMNEY INSTALLATION INSTRUCTIONS 1
O
22.000
22
12.000
12
2
3
34.859
34 7/8
10.350
10 3/8
22.991
23
4
1
5
10" ID Chimney Adapter
10" ID Chimney Cap
10" ID Chimney Section
10" Storm Collar
10" V Band
SPECIAL INSTRUCTIONS FOR INSTALLING THE OUTDOOR
CHIMNEY ON A TS-SERIES OVEN
10" ID CHIMNEYS--WS-TS-5, WS-TS-6, WS-TS-7 MODELS
1. Use the 10" V Band to attach the 10" ID Chimney Adapter to
the existing flange on the oven outlet
2. Place 10-inch ID chimney section onto the starter collar on
the adapter plate. Use the self-tapping screws to secure the
chimney to the adapter at the base
3. Place the chimney cap on to the top of the 10-inch ID
chimney section. Use the self-tapping screws provided to
secure the chimney cap to the chimney section. Installation is
complete.
4. Install storm collar to cover connection joint. Seal the top
and bottom edges using the high temp RTV sealant provided.
Installation is complete.
