Wood Stone PHOENIX 4343 PITA OVEN WS-BL-4343-RFG-LR User manual

Tel [phone]
Fax [phone]
www.woodstone-corp.com
WOOD STONE CORPORATION
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
PHOENIX OVEN
Stone Hearth Oven
Dual Radiant Flame Burners, Gas-Fired Models
PHOENIX 4343 PITA OVEN WS-BL-4343-RFG-LR
PHOENIX 4355 PITA OVEN WS-BL-4355-RFG-LR
PHOENIX 4836 PITA OVEN WS-BL-4836-RFG-LR
DOC NO M0030.07 REVISED APRIL 2017
Installation and
Operation Manual

Dual Burner Phoenix Installation
and Operation Manual
PG 2 OF 32
M0030.07 APRIL 2017
An ongoing program of product improvement may
require us to change specifications without notice.
WOOD STONE CORPORATION
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
TEL [phone]
FAX [phone]
E-MAIL [e-mail]
woodstone-corp.com
TABLE OF CONTENTS
TABLE OF CONTENTS
TABLE OF CONTENTS
DUAL BURNER PHOENIX OVEN � � � � � � � � � � 3
CAUTIONS & WARNINGS � � � � � � � � � � � � � � 4
PX-4343-LR SPECIFICATIONS � � � � � � � � � � 6
PX-4355-LR SPECIFICATIONS � � � � � � � � � � 7
PX-4836-LR SPECIFICATIONS � � � � � � � � � � 8
MOVING & PLACING THE OVEN� � � � � � � � � � 9
INSTALLATION CLEARANCES � � � � � � � � � � 10
VENTING � � � � � � � � � � � � � � � � � � � � � � � � � 11
LIFTING THE OVEN � � � � � � � � � � � � � � � � � � 12
EXPLODED PARTS DIAGRAM � � � � � � � � � � 14
ASSEMBLY � � � � � � � � � � � � � � � � � � � � � � � 15
UTILITY CONNECTIONS � � � � � � � � � � � � � � 20
STORAGE BOX INSTALLATION � � � � � � � � � 22
CONTROLLER � � � � � � � � � � � � � � � � � � � � � 23
INITIAL START-UP � � � � � � � � � � � � � � � � � � 24
INITIAL START-UP � � � � � � � � � � � � � � � � � � 24
OVEN OPERATION � � � � � � � � � � � � � � � � � � 25
DAILY MAINTENANCE� � � � � � � � � � � � � � � � 26
DAILY MAINTENANCE� � � � � � � � � � � � � � � � 26
TROUBLESHOOTING GUIDE � � � � � � � � � � � 27
100-120 VAC ELECTRICAL DIAGRAM � � � � 28
200-240 VAC ELECTRICAL DIAGRAM � � � � 29
INTERLOCK DIAGRAM � � � � � � � � � � � � � � � 30
LIMITED WARRANTY � � � � � � � � � � � � � � � � 31

INSTALLATION AND OPERATION MANUAL FOR
THE WOOD STONE DUAL BURNER PHOENIX
NATURAL GAS OR PROPANE FUELED DUAL BURNER STONE HEARTH OVEN
WS-PX-4343-RFG-LR, WS-PX-4355-RFG-LR AND WS-PX-4836-RFG-LR
ADDITIONAL COPIES AVAILABLE UPON REQUEST
Dual Burner Phoenix Installation
and Operation Manual
PG 3 OF 32
M0030.07 APRIL 2017
An ongoing program of product improvement may
require us to change specifications without notice.
WOOD STONE CORPORATION
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
TEL [phone]
FAX [phone]
E-MAIL [e-mail]
woodstone-corp.com
DUAL BURNER PHOENIX OVEN
PHOENIX DUAL BURNER OVEN
Shown: WS-PX-4343-RFG-LR

IMPORTANT: Consult your local gas supplier for a statement outlining a procedure to be followed in the
event you smell gas. Post the statement in a prominent location.
When this oven is not properly installed, a fire may result. To reduce the risk of fire,
follow the installation instructions. It is recommended that this oven be installed, maintained
and serviced by authorized professionals.
WARNING: Improper installation, adjustment, alteration, service or maintenance can result in property
damage, injury or death. Read the installation, operation and maintenance instructions thoroughly before
installing or servicing this equipment.
AVERTISSEMENT: L’installation, le réglage, la modification, la réparation ou l’entretien incorrect de
cet appareil peut causer des dommages matériels, de blessures ou la mort. Lire attentivement les
instructions d’installation, de fonctionement et d’entretien avant de procéder à son installation ou
entretien.
INSTALLATION AND OPERATION MANUAL FOR THE WOOD STONE PHOENIX
NATURAL GAS (NG) OR PROPANE (LP) FUELED DUAL BURNER STONE HEARTH OVEN
WS-PX-4343-RFG-LR-(NG OR LP), WS-PX-4355-RFG-LR-(NG OR LP)
ADDITIONAL COPIES AVAILABLE UPON REQUEST
READ ALL INSTRUCTIONS BEFORE INSTALLING AND USING THIS APPLIANCE
Please read this entire manual before you install the oven. Failure to follow instructions may result
in property damage, bodily injury or even death. Contact your local building or fire officials about
restrictions and installation inspection in your area.
RETAIN THIS MANUAL FOR FUTURE REFERENCE
Additional copies of this manual are available at woodstone-corp�com�
For prompt responses to service/maintenance questions, call your local distributor�
Dual Burner Phoenix Installation
and Operation Manual
PG 4 OF 32
M0030.07 APRIL 2017
An ongoing program of product improvement may
require us to change specifications without notice.
WOOD STONE CORPORATION
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
TEL [phone]
FAX [phone]
E-MAIL [e-mail]
woodstone-corp.com
CAUTIONS & WARNINGS
CAUTIONS AND WARNINGS

SAVE THE INSTRUCTIONS
FOR YOUR SAFETY: Do not store or use gasoline or other flammable vapors or liquids in the vicinity of
this or any other appliance.
POUR VOTRE SÉCURITÉ: Ne pas entreposer ni utiliser d’essence ou d’autres vapeurs de liquides
inflammables ou des liquides dans les environs de ce ou de tout autre appareil.
This appliance is for professional use by qualified personnel. This appliance must
be installed by qualified persons in accordance with the regulations in force. This
appliance must be installed with sufficient ventilation to prevent the occurrence of
unacceptable concentrations of substances harmful to health in the room in which
it is installed. This appliance needs an unobstructed flow of fresh air for satisfactory
combustion and must be installed in a suitably ventilated room in accordance with
current regulations. This appliance should be serviced by qualified personnel at least
every 12 months, or sooner if heavy use is expected.
!
A MAJOR CAUSE OF OVEN RELATED FIRES IS A
FAILURE TO MAINTAIN REQUIRED CLEARANCES
TO COMBUSTIBLE MATERIAL. IT IS OF UTMOST
IMPORTANCE THAT THIS OVEN BE INSTALLED ONLY
IN ACCORDANCE WITH THESE INSTRUCTIONS.
Dual Burner Phoenix Installation
and Operation Manual
PG 5 OF 32
M0030.07 APRIL 2017
An ongoing program of product improvement may
require us to change specifications without notice.
WOOD STONE CORPORATION
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
TEL [phone]
FAX [phone]
E-MAIL [e-mail]
woodstone-corp.com
CAUTIONS & WARNINGS
CAUTIONS AND WARNINGS

UTILITIES SPECIFICATIONS
Gas: 19mm (3/4") FNPT gas inlet
105,000 BTU/hr Natural Gas (NG)
OR
105,000 BTU/hr Propane (LP)
Maximum gas inlet pressure
1/2 psi (14 inches W�C�)
Electrical
120 VAC, 2 A, 60 Hz
Optional: 240 VAC, 1 A, 60 Hz
All utility connections made on the back
of the oven control box� Remove front or
rear panel for access Use utility knockouts
(provided) to route gas and electrical
supplies� Refer to data plate when installing�
Air intake: Do not
facade or cover over
Must be left
removable for service
Venting
The Phoenix must be vented using an approved
chimney, or an exhaust hood constructed and
installed in accordance with all relevant local and
national codes�
Actual weight: 748 kg
1650 lbs.
Ship weight: 953 kg
2100 lbs.
Side view
Rear view
Plan view
REV:
LEGEND:
PART #:
WS-BL-4355 shown
BL-RFG-LR (Pita Oven) - All Sizes
General Arrangement
5/30/2013 bena
1
DWN BY:
SHEET:
Bellingham, WA 360/650-1111 www.woodstone-corp.com
DIMENSIONS ARE IN INCHES
TOLERANCES: LINEAR ±1/2 [±10mm], ANGULAR ±2°
UNLESS NOTED OTHERWISE
\\woodstone.net\dfs\CAD\0 Pn\WS Top Level\WS-BL-PITA_All_Sizes_General_Arrangement-1.dft
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF WOOD STONE CORPORATION
ANY REPRODUCTION OR USE IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF WOOD STONE IS
PROHIBITED
AN ONGOING PROGRAM OF PRODUCT IMPROVEMENT
MAY REQUIRE US TO CHANGE SPECIFICATIONS
WITHOUT NOTICE.
DATE:
1 of 1
AIR INTAKE
G
D
24 1/2"
620mm
6"
150mm
6 1/2"
160mm
6 1/2"
160mm
1 1/2"
40mm
7 1/2"
190mm
47"
1200mm
37"
940mm
7 1/2"
190mm
40"
1020mm
2 1/2"
70mm
W
7 1/2"
190mm
9 3/4"
250mm
O
10
250mm OD
4 1/4"
110mm
10 1/2"
270mm
69 3/4"
1770mm
9 1/2"
240mm
G
120VAC, 4A
GAS INLET:
3/4" NPT
Model D W BTU/hr
WS-BL-4343 42 1/4 in - 1080 mm 42 1/4 in - 1070 mm 105,000 NG - 100,000 LP
WS-BL-4355 54 1/4 in - 1380 mm 42 1/4 in - 1070 mm 151,000 NG - 151,000 LP
REV:
LEGEND:
PART #:
WS-BL-4355 shown
BL-RFG-LR (Pita Oven) - All Sizes
General Arrangement
5/30/2013 bena
1
DWN BY:
SHEET:
Bellingham, WA 360/650-1111 www.woodstone-corp.com
DIMENSIONS ARE IN INCHES
TOLERANCES: LINEAR ±1/2 [±10mm], ANGULAR ±2°
UNLESS NOTED OTHERWISE
\\woodstone.net\dfs\CAD\0 Pn\WS Top Level\WS-BL-PITA_All_Sizes_General_Arrangement-1.dft
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF WOOD STONE CORPORATION
ANY REPRODUCTION OR USE IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF WOOD STONE IS
PROHIBITED
AN ONGOING PROGRAM OF PRODUCT IMPROVEMENT
MAY REQUIRE US TO CHANGE SPECIFICATIONS
WITHOUT NOTICE.
DATE:
1 of 1
AIR INTAKE
G
D
24 1/2"
620mm
6"
150mm
6 1/2"
160mm
6 1/2"
160mm
1 1/2"
40mm
7 1/2"
190mm
47"
1200mm
37"
940mm
7 1/2"
190mm
40"
1020mm
2 1/2"
70mm
W
7 1/2"
190mm
9 3/4"
250mm
O
10
250mm OD
4 1/4"
110mm
10 1/2"
270mm
69 3/4"
1770mm
9 1/2"
240mm
G
120VAC, 4A
GAS INLET:
3/4" NPT
Model D W BTU/hr
WS-BL-4343 42 1/4 in - 1080 mm 42 1/4 in - 1070 mm 105,000 NG - 100,000 LP
WS-BL-4355 54 1/4 in - 1380 mm 42 1/4 in - 1070 mm 151,000 NG - 151,000 LP
REV:
LEGEND:
PART #:
WS-BL-4355 shown
BL-RFG-LR (Pita Oven) - All Sizes
General Arrangement
5/30/2013 bena
1
DWN BY:
SHEET:
Bellingham, WA 360/650-1111 www.woodstone-corp.com
DIMENSIONS ARE IN INCHES
TOLERANCES: LINEAR ±1/2 [±10mm], ANGULAR ±2°
UNLESS NOTED OTHERWISE
\\woodstone.net\dfs\CAD\0 Pn\WS Top Level\WS-BL-PITA_All_Sizes_General_Arrangement-1.dft
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF WOOD STONE CORPORATION
ANY REPRODUCTION OR USE IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF WOOD STONE IS
PROHIBITED
AN ONGOING PROGRAM OF PRODUCT IMPROVEMENT
MAY REQUIRE US TO CHANGE SPECIFICATIONS
WITHOUT NOTICE.
DATE:
1 of 1
AIR INTAKE
G
D
24 1/2"
620mm
6"
150mm
6 1/2"
160mm
6 1/2"
160mm
1 1/2"
40mm
7 1/2"
190mm
47"
1200mm
37"
940mm
7 1/2"
190mm
40"
1020mm
2 1/2"
70mm
W
7 1/2"
190mm
9 3/4"
250mm
O
10
250mm OD
4 1/4"
110mm
10 1/2"
270mm
69 3/4"
1770mm
9 1/2"
240mm
G
120VAC, 4A
GAS INLET:
3/4" NPT
Model D W BTU/hr
WS-BL-4343 42 1/4 in - 1080 mm 42 1/4 in - 1070 mm 105,000 NG - 100,000 LP
WS-BL-4355 54 1/4 in - 1380 mm 42 1/4 in - 1070 mm 151,000 NG - 151,000 LP
REV:
LEGEND:
PART #:
WS-BL-4355 shown
BL-RFG-LR (Pita Oven) - All Sizes
General Arrangement
5/30/2013 bena
1
DWN BY:
SHEET:
Bellingham, WA 360/650-1111 www.woodstone-corp.com
DIMENSIONS ARE IN INCHES
TOLERANCES: LINEAR ±1/2 [±10mm], ANGULAR ±2°
UNLESS NOTED OTHERWISE
\\woodstone.net\dfs\CAD\0 Pn\WS Top Level\WS-BL-PITA_All_Sizes_General_Arrangement-1.dft
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF WOOD STONE CORPORATION
ANY REPRODUCTION OR USE IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF WOOD STONE IS
PROHIBITED
AN ONGOING PROGRAM OF PRODUCT IMPROVEMENT
MAY REQUIRE US TO CHANGE SPECIFICATIONS
WITHOUT NOTICE.
DATE:
1 of 1
AIR INTAKE
G
D
24 1/2"
620mm
6"
150mm
6 1/2"
160mm
6 1/2"
160mm
1 1/2"
40mm
7 1/2"
190mm
47"
1200mm
37"
940mm
7 1/2"
190mm
40"
1020mm
2 1/2"
70mm
W
7 1/2"
190mm
9 3/4"
250mm
O
10
250mm OD
4 1/4"
110mm
10 1/2"
270mm
69 3/4"
1770mm
9 1/2"
240mm
G
120VAC, 4A
GAS INLET:
3/4" NPT
Model D W BTU/hr
WS-BL-4343 42 1/4 in - 1080 mm 42 1/4 in - 1070 mm 105,000 NG - 100,000 LP
WS-BL-4355 54 1/4 in - 1380 mm 42 1/4 in - 1070 mm 151,000 NG - 151,000 LP
Front view
Knockouts provided
on rear
for gas/electrical
42 1/4"
1080mm
42 1/4"
1080mm
Dual Burner Phoenix Installation
and Operation Manual
PG 6 OF 32
M0030.07 APRIL 2017
An ongoing program of product improvement may
require us to change specifications without notice.
WOOD STONE CORPORATION
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
TEL [phone]
FAX [phone]
E-MAIL [e-mail]
woodstone-corp.com
PX-4343-LR SPECIFICATIONS
4343 (CS-REC-9) SPECIFICATIONS

Air intake: Do not
facade or cover over
Must be left
removable for service
UTILITIES SPECIFICATIONS
Gas: 19mm (3/4") FNPT gas inlet
151,000 BTU/hr Natural Gas (NG)
OR
151,000 BTU/hr Propane (LP)
Maximum gas inlet pressure
1/2 psi (14 inches W�C�)
Electrical
120 VAC, 2 A, 60 Hz
Optional: 240 VAC, 1 A, 60 Hz
All utility connections made on the back
of the oven control box� Remove front or
rear panel for access Use utility knockouts
(provided) to route gas and electrical
supplies� Refer to data plate when installing�
Venting
The Phoenix must be vented using an approved
chimney, or an exhaust hood constructed and
installed in accordance with all relevant local and
national codes�
Actual weight: 998 kg
2200 lbs.
Ship weight: 1134 kg
2500 lbs.
Side view
Rear view
Plan view
REV:
LEGEND:
PART #:
WS-BL-4355 shown
BL-RFG-LR (Pita Oven) - All Sizes
General Arrangement
5/30/2013 bena
1
DWN BY:
SHEET:
Bellingham, WA 360/650-1111 www.woodstone-corp.com
DIMENSIONS ARE IN INCHES
TOLERANCES: LINEAR ±1/2 [±10mm], ANGULAR ±2°
UNLESS NOTED OTHERWISE
\\woodstone.net\dfs\CAD\0 Pn\WS Top Level\WS-BL-PITA_All_Sizes_General_Arrangement-1.dft
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF WOOD STONE CORPORATION
ANY REPRODUCTION OR USE IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF WOOD STONE IS
PROHIBITED
AN ONGOING PROGRAM OF PRODUCT IMPROVEMENT
MAY REQUIRE US TO CHANGE SPECIFICATIONS
WITHOUT NOTICE.
DATE:
1 of 1
AIR INTAKE
G
D
24 1/2"
620mm
6"
150mm
6 1/2"
160mm
6 1/2"
160mm
1 1/2"
40mm
7 1/2"
190mm
47"
1200mm
37"
940mm
7 1/2"
190mm
40"
1020mm
2 1/2"
70mm
W
7 1/2"
190mm
9 3/4"
250mm
O
10
250mm OD
4 1/4"
110mm
10 1/2"
270mm
69 3/4"
1770mm
9 1/2"
240mm
G
120VAC, 4A
GAS INLET:
3/4" NPT
Model D W BTU/hr
WS-BL-4343 42 1/4 in - 1080 mm 42 1/4 in - 1070 mm 105,000 NG - 100,000 LP
WS-BL-4355 54 1/4 in - 1380 mm 42 1/4 in - 1070 mm 151,000 NG - 151,000 LP
REV:
LEGEND:
PART #:
WS-BL-4355 shown
BL-RFG-LR (Pita Oven) - All Sizes
General Arrangement
5/30/2013 bena
1
DWN BY:
SHEET:
Bellingham, WA 360/650-1111 www.woodstone-corp.com
DIMENSIONS ARE IN INCHES
TOLERANCES: LINEAR ±1/2 [±10mm], ANGULAR ±2°
UNLESS NOTED OTHERWISE
\\woodstone.net\dfs\CAD\0 Pn\WS Top Level\WS-BL-PITA_All_Sizes_General_Arrangement-1.dft
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF WOOD STONE CORPORATION
ANY REPRODUCTION OR USE IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF WOOD STONE IS
PROHIBITED
AN ONGOING PROGRAM OF PRODUCT IMPROVEMENT
MAY REQUIRE US TO CHANGE SPECIFICATIONS
WITHOUT NOTICE.
DATE:
1 of 1
AIR INTAKE
G
D
24 1/2"
620mm
6"
150mm
6 1/2"
160mm
6 1/2"
160mm
1 1/2"
40mm
7 1/2"
190mm
47"
1200mm
37"
940mm
7 1/2"
190mm
40"
1020mm
2 1/2"
70mm
W
7 1/2"
190mm
9 3/4"
250mm
O
10
250mm OD
4 1/4"
110mm
10 1/2"
270mm
69 3/4"
1770mm
9 1/2"
240mm
G
120VAC, 4A
GAS INLET:
3/4" NPT
Model D W BTU/hr
WS-BL-4343 42 1/4 in - 1080 mm 42 1/4 in - 1070 mm 105,000 NG - 100,000 LP
WS-BL-4355 54 1/4 in - 1380 mm 42 1/4 in - 1070 mm 151,000 NG - 151,000 LP
REV:
LEGEND:
PART #:
WS-BL-4355 shown
BL-RFG-LR (Pita Oven) - All Sizes
General Arrangement
5/30/2013 bena
1
DWN BY:
SHEET:
Bellingham, WA 360/650-1111 www.woodstone-corp.com
DIMENSIONS ARE IN INCHES
TOLERANCES: LINEAR ±1/2 [±10mm], ANGULAR ±2°
UNLESS NOTED OTHERWISE
\\woodstone.net\dfs\CAD\0 Pn\WS Top Level\WS-BL-PITA_All_Sizes_General_Arrangement-1.dft
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF WOOD STONE CORPORATION
ANY REPRODUCTION OR USE IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF WOOD STONE IS
PROHIBITED
AN ONGOING PROGRAM OF PRODUCT IMPROVEMENT
MAY REQUIRE US TO CHANGE SPECIFICATIONS
WITHOUT NOTICE.
DATE:
1 of 1
AIR INTAKE
G
D
24 1/2"
620mm
6"
150mm
6 1/2"
160mm
6 1/2"
160mm
1 1/2"
40mm
7 1/2"
190mm
47"
1200mm
37"
940mm
7 1/2"
190mm
40"
1020mm
2 1/2"
70mm
W
7 1/2"
190mm
9 3/4"
250mm
O
10
250mm OD
4 1/4"
110mm
10 1/2"
270mm
69 3/4"
1770mm
9 1/2"
240mm
G
120VAC, 4A
GAS INLET:
3/4" NPT
Model D W BTU/hr
WS-BL-4343 42 1/4 in - 1080 mm 42 1/4 in - 1070 mm 105,000 NG - 100,000 LP
WS-BL-4355 54 1/4 in - 1380 mm 42 1/4 in - 1070 mm 151,000 NG - 151,000 LP
REV:
LEGEND:
PART #:
WS-BL-4355 shown
BL-RFG-LR (Pita Oven) - All Sizes
General Arrangement
5/30/2013 bena
1
DWN BY:
SHEET:
Bellingham, WA 360/650-1111 www.woodstone-corp.com
DIMENSIONS ARE IN INCHES
TOLERANCES: LINEAR ±1/2 [±10mm], ANGULAR ±2°
UNLESS NOTED OTHERWISE
\\woodstone.net\dfs\CAD\0 Pn\WS Top Level\WS-BL-PITA_All_Sizes_General_Arrangement-1.dft
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF WOOD STONE CORPORATION
ANY REPRODUCTION OR USE IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF WOOD STONE IS
PROHIBITED
AN ONGOING PROGRAM OF PRODUCT IMPROVEMENT
MAY REQUIRE US TO CHANGE SPECIFICATIONS
WITHOUT NOTICE.
DATE:
1 of 1
AIR INTAKE
G
D
24 1/2"
620mm
6"
150mm
6 1/2"
160mm
6 1/2"
160mm
1 1/2"
40mm
7 1/2"
190mm
47"
1200mm
37"
940mm
7 1/2"
190mm
40"
1020mm
2 1/2"
70mm
W
7 1/2"
190mm
9 3/4"
250mm
O
10
250mm OD
4 1/4"
110mm
10 1/2"
270mm
69 3/4"
1770mm
9 1/2"
240mm
G
120VAC, 4A
GAS INLET:
3/4" NPT
Model D W BTU/hr
WS-BL-4343 42 1/4 in - 1080 mm 42 1/4 in - 1070 mm 105,000 NG - 100,000 LP
WS-BL-4355 54 1/4 in - 1380 mm 42 1/4 in - 1070 mm 151,000 NG - 151,000 LP
Front view
Knockouts provided
on rear
for gas/electrical
42 1/4"
1080mm
54 1/4"
1380mm
Dual Burner Phoenix Installation
and Operation Manual
PG 7 OF 32
M0030.07 APRIL 2017
An ongoing program of product improvement may
require us to change specifications without notice.
WOOD STONE CORPORATION
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
TEL [phone]
FAX [phone]
E-MAIL [e-mail]
woodstone-corp.com
PX-4355-LR SPECIFICATIONS
PX-4355-LR SPECIFICATIONS
4355 (CS-REC-11) SPECIFICATIONS

UTILITIES SPECIFICATIONS
Gas: 3/4 inch FNPT gas inlet
105,000 BTU/hr Natural Gas (NG)
OR
100,000 BTU/hr Propane (LP)
Maximum gas inlet pressure
1/2 psi (14 inches W�C�)
Side view
Rear view
Plan view
REV:
LEGEND:
PART #:
WS-BL-4355 shown
BL-RFG-LR (Pita Oven) - All Sizes
General Arrangement
5/30/2013 bena
1
DWN BY:
SHEET:
Bellingham, WA 360/650-1111 www.woodstone-corp.com
DIMENSIONS ARE IN INCHES
TOLERANCES: LINEAR ±1/2 [±10mm], ANGULAR ±2°
UNLESS NOTED OTHERWISE
\\woodstone.net\dfs\CAD\0 Pn\WS Top Level\WS-BL-PITA_All_Sizes_General_Arrangement-1.dft
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF WOOD STONE CORPORATION
ANY REPRODUCTION OR USE IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF WOOD STONE IS
PROHIBITED
AN ONGOING PROGRAM OF PRODUCT IMPROVEMENT
MAY REQUIRE US TO CHANGE SPECIFICATIONS
WITHOUT NOTICE.
DATE:
1 of 1
AIR INTAKE
G
D
24 1/2"
620mm
6"
150mm
6 1/2"
160mm
6 1/2"
160mm
1 1/2"
40mm
7 1/2"
190mm
47"
1200mm
37"
940mm
7 1/2"
190mm
40"
1020mm
2 1/2"
70mm
W
7 1/2"
190mm
9 3/4"
250mm
O
10
250mm OD
4 1/4"
110mm
10 1/2"
270mm
69 3/4"
1770mm
9 1/2"
240mm
G
120VAC, 4A
GAS INLET:
3/4" NPT
Model D W BTU/hr
WS-BL-4343 42 1/4 in - 1080 mm 42 1/4 in - 1070 mm 105,000 NG - 100,000 LP
WS-BL-4355 54 1/4 in - 1380 mm 42 1/4 in - 1070 mm 151,000 NG - 151,000 LP
REV:
LEGEND:
PART #:
WS-BL-4355 shown
BL-RFG-LR (Pita Oven) - All Sizes
General Arrangement
5/30/2013 bena
1
DWN BY:
SHEET:
Bellingham, WA 360/650-1111 www.woodstone-corp.com
DIMENSIONS ARE IN INCHES
TOLERANCES: LINEAR ±1/2 [±10mm], ANGULAR ±2°
UNLESS NOTED OTHERWISE
\\woodstone.net\dfs\CAD\0 Pn\WS Top Level\WS-BL-PITA_All_Sizes_General_Arrangement-1.dft
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF WOOD STONE CORPORATION
ANY REPRODUCTION OR USE IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF WOOD STONE IS
PROHIBITED
AN ONGOING PROGRAM OF PRODUCT IMPROVEMENT
MAY REQUIRE US TO CHANGE SPECIFICATIONS
WITHOUT NOTICE.
DATE:
1 of 1
AIR INTAKE
G
D
24 1/2"
620mm
6"
150mm
6 1/2"
160mm
6 1/2"
160mm
1 1/2"
40mm
7 1/2"
190mm
47"
1200mm
37"
940mm
7 1/2"
190mm
40"
1020mm
2 1/2"
70mm
W
7 1/2"
190mm
9 3/4"
250mm
O
10
250mm OD
4 1/4"
110mm
10 1/2"
270mm
69 3/4"
1770mm
9 1/2"
240mm
G
120VAC, 4A
GAS INLET:
3/4" NPT
Model D W BTU/hr
WS-BL-4343 42 1/4 in - 1080 mm 42 1/4 in - 1070 mm 105,000 NG - 100,000 LP
WS-BL-4355 54 1/4 in - 1380 mm 42 1/4 in - 1070 mm 151,000 NG - 151,000 LP
REV:
LEGEND:
PART #:
WS-BL-4355 shown
BL-RFG-LR (Pita Oven) - All Sizes
General Arrangement
5/30/2013 bena
1
DWN BY:
SHEET:
Bellingham, WA 360/650-1111 www.woodstone-corp.com
DIMENSIONS ARE IN INCHES
TOLERANCES: LINEAR ±1/2 [±10mm], ANGULAR ±2°
UNLESS NOTED OTHERWISE
\\woodstone.net\dfs\CAD\0 Pn\WS Top Level\WS-BL-PITA_All_Sizes_General_Arrangement-1.dft
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF WOOD STONE CORPORATION
ANY REPRODUCTION OR USE IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF WOOD STONE IS
PROHIBITED
AN ONGOING PROGRAM OF PRODUCT IMPROVEMENT
MAY REQUIRE US TO CHANGE SPECIFICATIONS
WITHOUT NOTICE.
DATE:
1 of 1
AIR INTAKE
G
D
24 1/2"
620mm
6"
150mm
6 1/2"
160mm
6 1/2"
160mm
1 1/2"
40mm
7 1/2"
190mm
47"
1200mm
37"
940mm
7 1/2"
190mm
40"
1020mm
2 1/2"
70mm
W
7 1/2"
190mm
9 3/4"
250mm
O
10
250mm OD
4 1/4"
110mm
10 1/2"
270mm
69 3/4"
1770mm
9 1/2"
240mm
G
120VAC, 4A
GAS INLET:
3/4" NPT
Model D W BTU/hr
WS-BL-4343 42 1/4 in - 1080 mm 42 1/4 in - 1070 mm 105,000 NG - 100,000 LP
WS-BL-4355 54 1/4 in - 1380 mm 42 1/4 in - 1070 mm 151,000 NG - 151,000 LP
REV:
LEGEND:
PART #:
WS-BL-4355 shown
BL-RFG-LR (Pita Oven) - All Sizes
General Arrangement
5/30/2013 bena
1
DWN BY:
SHEET:
Bellingham, WA 360/650-1111 www.woodstone-corp.com
DIMENSIONS ARE IN INCHES
TOLERANCES: LINEAR ±1/2 [±10mm], ANGULAR ±2°
UNLESS NOTED OTHERWISE
\\woodstone.net\dfs\CAD\0 Pn\WS Top Level\WS-BL-PITA_All_Sizes_General_Arrangement-1.dft
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF WOOD STONE CORPORATION
ANY REPRODUCTION OR USE IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF WOOD STONE IS
PROHIBITED
AN ONGOING PROGRAM OF PRODUCT IMPROVEMENT
MAY REQUIRE US TO CHANGE SPECIFICATIONS
WITHOUT NOTICE.
DATE:
1 of 1
AIR INTAKE
G
D
24 1/2"
620mm
6"
150mm
6 1/2"
160mm
6 1/2"
160mm
1 1/2"
40mm
7 1/2"
190mm
47"
1200mm
37"
940mm
7 1/2"
190mm
40"
1020mm
2 1/2"
70mm
W
7 1/2"
190mm
9 3/4"
250mm
O
10
250mm OD
4 1/4"
110mm
10 1/2"
270mm
69 3/4"
1770mm
9 1/2"
240mm
G
120VAC, 4A
GAS INLET:
3/4" NPT
Model D W BTU/hr
WS-BL-4343 42 1/4 in - 1080 mm 42 1/4 in - 1070 mm 105,000 NG - 100,000 LP
WS-BL-4355 54 1/4 in - 1380 mm 42 1/4 in - 1070 mm 151,000 NG - 151,000 LP
Front view
Electrical
120 VAC, 2 A, 50/60 Hz
Optional: 240 VAC, 1 A, 50/60 Hz
All utility connections made on the back
of the oven control box� Remove front or
rear panel for access Use utility knockouts
(provided) to route gas and electrical
supplies� Refer to data plate when installing�
Knockouts provided
on rear
for gas/electrical
Actual weight
1,650 lbs.
Shipping weight
1,800 lbs.
Air intake: Do not
facade or cover over
Must be left
removable for service
Venting
The Phoenix must be vented using an approved
chimney, or an exhaust hood constructed and installed in
accordance with all relevant local and national codes�
47 1/4"
1200mm
35 1/4"
900mm
PX-4836-LR SPECIFICATIONS
Dual Burner Phoenix Installation
and Operation Manual
PG 8 OF 32
M0030.07 APRIL 2017
An ongoing program of product improvement may
require us to change specifications without notice.
WOOD STONE CORPORATION
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
TEL [phone]
FAX [phone]
E-MAIL [e-mail]
woodstone-corp.com
PX-4836-LR SPECIFICATIONS

Model
Shipping
Weight
Required Forklift
Capacity
Minimum
Fork Length
PX-4343-LR 953 kg
(2,100 lbs)
1450 kg
(3,200 lbs)
1.5m
(5')
PX-4355-LR 1134 kg
(2,500 lbs)
1600 kg
(3,500 lbs)
PX-4836-LR 816 kg
(1,800 lbs)
1450 kg
(3,200 lbs)
The oven should only
be moved using a
Pallet Jack on a LEVEL
FLOOR. Use a forklift
or other suitable
means if the oven
must be moved over
an inclined surface.
LEVELING AND SHIMMING THE OVEN
The installed oven must be level� Use metal shims to level the oven if necessary� Because the weight of the oven is carried by the full
perimeter of the oven stand, make certain there no gaps larger than approximately 13mm (1/2") where the oven stand is unsupported
by shims� Seal any small gaps between the oven and the floor with silicone� Failure to solidly support the full perimeter of the oven
stand can result in costly damage to the oven and will void the warranty� The floor design and construction must be adequate to
handle the weight of the oven�
Please see woodstone-corp�com/resources/downloads/loads-footprints for floor loading information�
FORKLIFT REQUIREMENTS
Bistro ovens are very top-heavy� If the oven tips it can cause
severe injury or death. Never use a Hand Truck to move
the oven. The oven should only be moved using a Pallet
Jack on a LEVEL FLOOR. If the oven must be moved over
an inclined surface, a Forklift or other suitable means should
be employed� If the installer does not have the equipment or
experience required to move the oven safely, we recommend
securing the services of a qualified rigging company�
ÜÜ
Make sure the
Pallet Jack wheels
do not contact the
underside of the
fork pocket when
lifting to avoid
damaging the stand.
PICKEYE CAPACITIES PER BEAM
2,000 lbs: Middle holes (PX-4343-LR, PX-4355-LR)
2,700 lbs: Outer holes (PX-4836-LR)
INNER INNER
MIDDLE MIDDLE
OUTER OUTERBOLT POSITIONS
Never use a Hand Truck
to move the oven.
MOVING THE OVEN
Bistro models are shipped fully assembled� The oven can be moved into place with a Pallet Jack using the forklift pockets�
If the oven is to be installed against a wall, leave access to the back of the oven to complete the utility connections�
If you need to disassemble the oven to move it through a narrow door or passageway,
see the DISASSEMBLY section in this manual.
LOAD
Orient Spreader Bar
as shown in fig. 1
50°MIN Angle
Pickeye
Beam
Shown:
PX-4343-LR
fig. 1
USING A CRANE
The oven arrives with Pickeyes attached� When craning a Wood Stone oven, use a Spreader Bar with a
two-legged sling rigged on each end� The spreader bar should be of a sufficient length to keep the sling
from contacting the oven, and oriented as shown in fig. 1�
Dual Burner Phoenix Installation
and Operation Manual
PG 9 OF 32
M0030.07 APRIL 2017
An ongoing program of product improvement may
require us to change specifications without notice.
WOOD STONE CORPORATION
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
TEL [phone]
FAX [phone]
E-MAIL [e-mail]
woodstone-corp.com
MOVING & PLACING THE OVEN
MOVING & PLACING THE OVEN

CLEARANCES
1. The Wood Stone Phoenix oven must have a minimum 25 mm (1") clearance to combustibles from all sides, 152 mm
(6") clearance to combustibles from the top and 152 mm (6") from the flue collar. If building a facade that will contact
the oven, use completely non-combustible materials� Any facade wall built 152 mm (6") to either side of the doorway and
above must be of non-combustible construction� Please note that standard Drywall (or Sheetrock) is considered a limited
combustible� Any walls perpendicular to the front of the oven in the area 762 mm (30") to either side of the doorway and 914
mm (36") in front of the oven should have a non-combustible surface�
2. The oven must be installed on a non-combustible floor surface� The non-combustible floor surface must extend 914 mm
(36") in front of and 914 mm (30") to either side of the oven doorway�
NOTICE: For stucco-ready appliances (model numbers ending in “-S”), the same clearances as described above apply� Non-
combustible stucco mix must be used and applied to a minimum thickness of 25mm (1")�
!WARNING: Installation and servicing of this product could expose you to glasswool/ceramic
fibers as well as Calcium Silicate dust. ALWAYS WEAR RESPIRATORY AND EYE PROTECTION
WHEN INSTALLING OR SERVICING THIS APPLIANCE. Please read this entire manual before
you install the oven. Failure to follow instructions may result in property damage, bodily
injury or even death. Contact your local building or fire officials about restrictions and
installation inspection in your area.
!WARNING: Do not pack required air spaces (clearance) with insulation or other material.
EN AVERTISSANT - n’emballez pas les espaces aériens requis avec l’isolation ou tout autre
matériel.
When non-combustible building materials contact the body of the oven, the clearances to
combustibles are transferred to those non-combustibles.
Ruled area (152 mm
(6") to either side of
doorway and above)
represents space where
facade materials must
be non-combustible.
Hatched area must
be left accessible
and unobstructed
after installation for
air intake and routine
service of the oven
burner.
Maintain
152 mm (6")
clearance from
the flue outlet
25 mm (1")
minimum side
clearance to
combustible
construction
Non-combustible
floor, 914 mm (36")
in front and 762
(30") mm
to either side of
oven doorway
Dual Burner Phoenix Installation
and Operation Manual
PG 10 OF 32
M0030.07 APRIL 2017
An ongoing program of product improvement may
require us to change specifications without notice.
WOOD STONE CORPORATION
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
TEL [phone]
FAX [phone]
E-MAIL [e-mail]
woodstone-corp.com
INSTALLATION CLEARANCES

All of the combustion products and cooking vapors from the Wood Stone Phoenix oven pass through the 10-inch diameter flue
collar located on top of the oven at the front� The oven can be connected to a power-ventilated, grease-rated chimney, or placed
under a Listed Type 1 exhaust hood� Installation of the exhaust hood should be in accordance with all relevant local and national
codes�
THIS OVEN IS NOT INTENDED TO BURN SOLID FUEL. DO NOT BURN
ANY TYPE OF SOLID FUEL IN THIS OVEN.
The following are the manufacturer’s recommendations for venting Wood Stone Phoenix model ovens� It is never appropriate to
use “B vent” in any part of an exhaust system connected to a Wood Stone oven� All duct material must be manufactured to the
specifications of a grease duct� The venting system should be cleaned and inspected at least every 3 months�
THERE ARE TWO VENTING OPTIONS:
1. A grease rated duct connected directly to the oven flue collar and provided with a power ventilator suitable for restaurant
appliance exhaust and rated for operation at a minimum of 149 °C (300 °F), 232 °C (450 °F) for units burning solid fuel�
Use a stack or curb mounted fan� Wood Stone does not recommend the use of an in-line fan� A static pressure of 0�25 mbar
(-0�1 inches) water column is necessary at the oven flue collar to ensure proper flue temperatures at the fan� The airflow
required to attain this static pressure will depend on the configuration of your particular installation but will be approximately
400 CFM� The exhaust fan must be turned on any time the oven is running� See instructions for optional interlocking of the
oven to the fan at the end of this manual�
2. Wood Stone offers eyebrow-type hoods designed specifically for Wood Stone ovens by Gaylord Industries�
Wood Stone ovens should be vented in accordance with
NFPA 96 and/or all pertinent national, regional and local
codes concerning such appliances; check venting plans
with the authority having jurisdiction before proceeding
with installation�
Flue collar
Note: Flue gas temperatures at the oven
flow can reach 260 °C (500 °F)
Dual Burner Phoenix Installation
and Operation Manual
PG 11 OF 32
M0030.07 APRIL 2017
An ongoing program of product improvement may
require us to change specifications without notice.
WOOD STONE CORPORATION
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
TEL [phone]
FAX [phone]
E-MAIL [e-mail]
woodstone-corp.com
VENTING
OVEN VENTING

Dual Burner Phoenix Installation
and Operation Manual
PG 12 OF 32
M0030.07 APRIL 2017
LIFTING THE OVEN
1. Use a forklift or other suitable lifting means to set the
oven body onto 4x4" blocks oriented as shown� Refer
to DISASSEMBLY section of manual for disassembly
instructions�
Oven cut-
away view
showing
right Pickeye
Insert of
Lifting
System
in forklift
pocket
Bolt through
forklift
pocket into
lifting arm
2. Insert the left & right Pickeye Inserts of the Lifting
System into the forklift pockets from the oven front�
3. Loosely bolt each Pickeye Insert to the forklift
pocket as shown in the cut-away view to above�
MOVING A DISASSEMBLED BISTRO OVEN THROUGH A NARROW DOOR OR PASSAGEWAY
USING THE OPTIONAL LIFTING SYSTEM
An optional Lifting System is available from Wood Stone to facilitate tipping the oven body onto its back or side (as shown below)�
When turned on its side, the upper oven portion of Bistro or Phoenix models 4343, 4355 and 4836 will be approximately 32 inches
wide� This will allow for easier access through small passages� Note: The 3030 is 30" wide without tilting�
4. Attach the Crosspiece using the hardware provided�
See drawing below for placement of bolts on various
models�
Tighten all Pickeye and Crosspiece bolts�
Bolt
placement
for various
models
4343-RFG, 4355-RFG
or 4836-RFG
4343-RFG-LR, 4355-RFG-LR
(Dual Burner)
4836-RFG-LR (Dual Burner)
Clevises
5. Install a clevis in the Top Hole of each Pickeye
Insert of the Lifting System�

Dual Burner Phoenix Installation
and Operation Manual
PG 13 OF 32
M0030.07 APRIL 2017
LIFTING THE OVEN
6. Attach strap to the clevises at the top of each
Pickeye Insert� Using an appropriate hoist or lift,
tilt the oven on its back, onto 4x4" blocks�
7. Change the position of the clevises to the Lifting
Holes on the Crosspiece and attach straps�
Lifting Holes
on Crosspiece
8. Lift the oven straight up and position pallet jack
under the oven�
Lower the oven, on its back, onto the pallet jack�
9. The oven can now be moved through a narrow
doorway or passageway�
DANGER: Never attempt to move the oven in this
manner on any type of incline or sloped floor�
10. Once the oven is on the other
side of the passageway,
attach strap to the clevises
at the Lifting Holes on the
Crosspiece and, with a gantry
crane, lift the oven straight
up�
Remove pallet jack�
Lower the oven onto 4x4"
blocks�
11. Move strap to the clevises
at the top of the Pickeye
Inserts and tilt the oven
down onto the 4x4"
blocks positioned as
shown�
Remove the Lifting
System from the oven�
12. Run straps through forklift
pockets and up to a
Spreader Bar�
Note: The Spreader Bar
must be wide enough so
the straps clear the body
of the oven�
Lift the oven straight up
and remove the 4x4"
blocks�
13. Maneuver oven stand into
position under the oven
using pallet jack�
Lower oven and secure
oven to stand with bolts�

Dual Burner Phoenix Installation
and Operation Manual
PG 14 OF 32
M0030.07 APRIL 2017
An ongoing program of product improvement may
require us to change specifications without notice.
WOOD STONE CORPORATION
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
TEL [phone]
FAX [phone]
E-MAIL [e-mail]
woodstone-corp.com
EXPLODED PARTS DIAGRAM
EXPLODED PARTS DIAGRAM
With the exception of the temporary Shipping Panel, all parts shown
below, including the Rear Panel, MUST be installed to ensure the safe and
proper operation of the oven.
Oven Body
Control Box
Flame Guards
Front Panel
Toe Kick
Rear
Panel
Shipping Panel
(Only on export ovens
shipped disassembled.
Discard once removed.)
Side Panel
Mantle
Side Panel

Dual Burner Phoenix Installation
and Operation Manual
PG 15 OF 32
M0030.07 APRIL 2017
An ongoing program of product improvement may
require us to change specifications without notice.
WOOD STONE CORPORATION
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
TEL [phone]
FAX [phone]
E-MAIL [e-mail]
woodstone-corp.com
ASSEMBLY
ASSEMBLY
Follow these instructions only if the oven was shipped disassembled, or disassembled to move through a narrow door
or passageway.
The oven must be installed on a flat level surface� The weight of the oven is carried by the full perimeter of the oven stand� If it is
necessary to shim the oven for leveling purposes, it is critical that the shim material be metal, and that the shims are installed in
such a way that the full perimeter of the stand is solidly supported� Any gaps created by shimming between the oven and the floor
must be sealed for proper ventilation� Failure to solidly support the full perimeter of the oven stand can result in costly
damage to the oven and will void the warranty.
The floor design and construction must be adequate to handle the weight of the oven�
Please see woodstone-corp.com/installation_footprints.htm for floor loading information�
2. Use the 9�5 mm x 25 mm (3/8" x 1") carriage
bolts to assemble the stand� Be sure to use the
washers provided and to tighten nuts and bolts
securely�
1. Lay out pieces�
Carriage bolts
9�5 x 25mm (3/8 x 1")
3030 only: 9�5 x 19mm (3/8 x 3/4")

Dual Burner Phoenix Installation
and Operation Manual
PG 16 OF 32
M0030.07 APRIL 2017
An ongoing program of product improvement may
require us to change specifications without notice.
WOOD STONE CORPORATION
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
TEL [phone]
FAX [phone]
E-MAIL [e-mail]
woodstone-corp.com
ASSEMBLY
ASSEMBLY
3. Using a forklift or other suitable lifting device, carefully
lower the body of the oven on to the stand so that the
bolt holes line up� While supporting the oven with the
lift, install the 10 mm x 25 mm (3/8" x 1") carriage
bolts� Use the washers provided and tighten all nuts
securely� Be sure to use the forklift pockets when
lifting the body of the oven�
4. After the oven body is bolted to the stand, the oven can be moved into place with a pallet jack using the LOWER forklift
pockets� If the oven is to be installed against a wall, leave access to the back of the oven until the assembly is completed�
CAUTION: The 4343 & 4836 model Phoenix weighs approximately 930 kg. The 4355 model Phoenix weighs
approximately 1134 kg. The oven is very top-heavy. If the oven tips, it can cause severe injury or death! The oven
should only be moved in this manner (pallet jack) on a LEVEL FLOOR. Do not attempt to move the oven with a hand
truck. If the oven must be moved over an inclined surface, a forklift or other suitable means should be employed. If the
installer does not have the equipment or experience required to move the oven safely, we recommend you secure the
services of a qualified rigging company.
Make sure the pallet jack
wheels do not contact
the underside of the fork
pocket when lifting to avoid
damaging the stand�
Never attempt to use a hand
truck to move the oven�
The oven should only be moved
using a pallet jack on a LEVEL
FLOOR� If the oven must be moved
over an inclined surface, a forklift
or other suitable means should be
employed�

Dual Burner Phoenix Installation
and Operation Manual
PG 17 OF 32
M0030.07 APRIL 2017
An ongoing program of product improvement may
require us to change specifications without notice.
WOOD STONE CORPORATION
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
TEL [phone]
FAX [phone]
E-MAIL [e-mail]
woodstone-corp.com
ASSEMBLY
5. Remove the shipping
panel from beneath the
oven� The shipping panel
is secured with 2 screws
in the front, and 2 screws
in the back� Discard the
shipping panel�
ASSEMBLY
7. Install Burner Assemblies�
A. Position burner as
shown� Note: Gas
connections will
be towards front of
oven�
B. Raise burner(s) up
into burner slot(s)�
Secure with the
1/4-20 bolts
provided� Tighten
nuts securely�
6. Attach the Control Box to the oven using
(4) 1/4-20 screws� The Control Box should
be oriented so the Flame Height Control
Knob is on the left side�
(4) 1/4-20
screws
Ü
Ü
Ü
Ü
Ü
Ü
Gas
connections
towards front
of oven
Three 1/4-20
bolts on each side
of left and right
burners

Dual Burner Phoenix Installation
and Operation Manual
PG 18 OF 32
M0030.07 APRIL 2017
An ongoing program of product improvement may
require us to change specifications without notice.
WOOD STONE CORPORATION
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
TEL [phone]
FAX [phone]
E-MAIL [e-mail]
woodstone-corp.com
ASSEMBLY
NOTE: Once oven is assembled and installed, be sure to leak-check all gas connections�
ASSEMBLY
8. Connect Burner Assembly
components and
Thermocouple at the rear
of the Control Box�
Plug in Thermocouple
Wire here.
Attach flexible Pilot Tubes between
the SV-2 & SV-3 Gas Valves and left &
right Burners. Tighten the fitting firmly.
Use Flexible Gas Pipe
provided to connect
the Burner, left and
right.
Plug in Igniter Wires from
the Burners into the SV-2
and SV-3 Gas Valves.
9. Install the Mantle� Fasten using 3 bolts
/ washers and 2 carriage bolts (see
illustration)�
If the oven has been supplied with a
granite mantle, affix the granite slab to the
mounting bracket using a generous amount
of the adhesive provided�
Mantle Bolts /
Washers
Carriage Bolts
Mantle Faceplate
Cover Screws
10. Place the Mantle Faceplate Cover over the
open area under the top of the Mantle�
Install the cover plate using the 4 screws
provided�

Dual Burner Phoenix Installation
and Operation Manual
PG 19 OF 32
M0030.07 APRIL 2017
An ongoing program of product improvement may
require us to change specifications without notice.
WOOD STONE CORPORATION
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
TEL [phone]
FAX [phone]
E-MAIL [e-mail]
woodstone-corp.com
ASSEMBLY
ASSEMBLY
11. Run a bead of high temperature silicone (provided)
along visible joints where the mantle and the oven
intersect—in the front and down both sides of the
oven (right side not shown)�
12. Reinstall the Burner Guards� The lower tab of the
guard fits into the front of the burner opening�
Lower tab of Burner
Guard fits into the
front of the burner
opening

13. Make gas connection at the rear of the Control Box� Gas and electrical connections must comply with all relevant national
and local codes, and in a manner acceptable to the authority having jurisdiction�
Knockouts are provided on the rear of the oven stand for the incoming gas and electrical supplies� If necessary, holes may
be drilled in a side panel for the incoming gas and electrical� Gas and electrical supplies should be routed in such a way that
they do not interfere with the removal of the oven burner, or block the access to the space under the oven for service� The
area beneath the burner needs to be kept clear of conduit and piping to allow for removal of the burner for service� The rear
panel must be installed! A 3/4-inch full-flow gas shut-off valve should be installed on the gas supply near the oven in such
a way that it is readily accessible�
This appliance must be electrically grounded in accordance with local code, or in the absence of local code, with the
national electrical code, ANSI/NFPA 70, or the Canadian Electrical Code, CSA C22.2, as applicable.
An electrical diagram is provided inside the bottom cover of the Control Box, and at the end of this manual�
Connect the incoming
gas supply to the
3/4-inch FNPT gas inlet.
For non-plug models, make the electrical connection
to the terminals in Junction Box. Correct voltage is
specified on the Junction Box and the Equipment
Data Plate.
Dual Burner Phoenix Installation
and Operation Manual
PG 20 OF 32
M0030.07 APRIL 2017
An ongoing program of product improvement may
require us to change specifications without notice.
WOOD STONE CORPORATION
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
TEL [phone]
FAX [phone]
E-MAIL [e-mail]
woodstone-corp.com
UTILITY CONNECTIONS
ASSEMBLY-CONNECTIONS
