Woodendot Alba Floating nightstand User manual

Alba Floating nightstand
ASSEMBLY INSTRUCTIONS

1x OR
1x
1x
1x
6x
1x1x
7x 11x
(A)
(D)
(B) (C)
(E)
1x 1x
(F)
2x
8 DIFFERENT POSSIBILITIES
4 DIFFERENT POSSIBILITIES
You will need a manual drill
for the wall holes
We recommend two people
for the installation
For the hole to be the exact depth, measure 50mm/1.96”
on the drill bit and place tape around it to mark the
distance. Stop drilling when it reaches that depth.
The drill bit required is Ø 6 mm or 15/64”
Depth of the hole in wall: 50 mm / 1.96”

1º
Use the level tool
Mark the holes with a pencil
2º
3º
4º
(A)
(B)
5º
6º
7º
8º
Make the hole in the wall
9º (A)
Place the double-sided
adhesives (x2) on the metal flap
10º
11º
12º
(F)
Screw the “U” piece to the wall
with the help of the Allen key.
Screw the table cover
13º
(E)
(D)
14º
(C)
(C)
Screw the “U” piece to the back
panel (x2 screws)
Place the “U” piece between the
wall and the back panel.
Mark the three holes with a pencil

15º Introduce the small
wooden piece
16º
Make a line at the intersection of
the small piece of wood on the
back
Take out the
small
wooden piece
17º
Screw on the L-shaped metal
piece using the marked line
18º
(C)
19º
Introduce the small wooden piece
with the metal piece towards the
back
Screw to the set
and finish
18º
