woodmizer PD200 Series Guide

WARNING! Read and understand this
manual before using this machine.
!
Electric Pallet Dismantler
Safety, Operation,
Maintenance & Parts Manual
PD200 rev A2.02
Standard and rear drop tables
Safety is our #1 concern!
Form #2232
Models Effected:
PD200A10-RU PD200C10-RU
PD200A10-SU PD200C10-RU-HS
PD200A10-SUW PD200C10-RUW72
PD200A10-SUW72 PD200C10-SU
PD200A10-SUW84 PD200C10-SU-HS
PD200A10-SUW96 PD200C10-SUW
PD200C10-SUW72
PD200B10-RU PD200C10-SUW72-HS
PD200B10-RU-HS PD200C10-SUW84
PD200B10-RUW72 PD200C10-SUW96
PD200B10-SU PD200C10-SUW-HS
PD200B10-SU-HS
PD200B10-SUW PD200K10-RU
PD200B10-SUW72 PD200K10-SU
PD200B10-SUW84 PD200K10-SUW72
PD200B10-SUW96

Active Patents assigned to Wood-Mizer, LLC
Wood-Mizer, LLC has received patents that protect our inventions which are a result of a dedication to
research, innovation, development, and design. Learn more at: woodmizer.com/patents
©2021 Wood-Mizer LLC
Printed in the United States of America, all rights reserved. No part of this manual may be reproduced in any form by any
photographic, electronic, mechanical or other means or used in any information storage and retrieval system without
written permission from
Wood-Mizer, LLC
8180 West 10th Street
Indianapolis, Indiana 46214
TOC
California
Proposition 65 Warning
For more information go to www.P65Warnings.ca.gov/wood.
WARNING: Drilling, sawing, sanding or machining wood products can expose you to
wood dust, a substance known to the State of California to cause cancer. Avoid inhaling
wood dust or use a dust mask or other safeguards for personal protection.

Table of Contents Section-Page
Table of Contents WM doc 6/18/21 iii
PD200 Pallet Dismantler
SECTION 1 INTRODUCTION
1.1 About this manual .................................................................................. 1-1
1.2 Getting service ....................................................................................... 1-1
1.3 Warranty................................................................................................. 1-4
SECTION 2 GENERA L SAFETY
Owner’s Responsibility .........................................................2-1
2.1 Safety symbols ....................................................................................... 2-1
2.2 Electrical Lockout Procedures ............................................................... 2-4
SECTION 3 SETUP AND OPERATION
3.1 Site Preparation...................................................................................... 3-1
3.2 Onsite setup............................................................................................ 3-1
3.3 Operation................................................................................................3-2
One-person operation ...........................................................3-2
Two-person operation ...........................................................3-4
SECTION 4 MAINTENANCE
4.1 General maintenance after each use....................................................... 4-1
4.2 Tracking the blade.................................................................................. 4-1
4.3 Changing the blade................................................................................. 4-2
4.4 Remove the drive hub ............................................................................ 4-4
SECTION 5 GENERAL INFORMATION
5.1 How To Use The Parts List.................................................................... 5-1
5.2 Pallet Dismantler Assembly................................................................... 5-2
5.3 Airbag Assembly.................................................................................... 5-3
After 10/28/2019....................................................................5-3
Prior to 10/28/2019 .............................................................5-4
5.4 Pallet Dismantler Parts (Drive Side)...................................................... 5-5
5.5 Motor Usage........................................................................................... 5-7
5.6 Pallet Dismantler Parts (Idle Side)......................................................... 5-8
5.7 Pallet Dismantler Table Parts............................................................... 5-10
5.8 Table Control Assembly ...................................................................... 5-12
5.9 Motor Control Assembly ................................................................ 5-14
PD200 rev A2.00+ .....................................................5-14
PD200 (rev A1.00 - A2.00) ......................................5-15
5.10 Control Box Insert................................................................................ 5-17
5.11 Blade Guide Assembly......................................................................... 5-19
5.12 Decals................................................................................................... 5-20
5.13 Slide Bracket Assembly ....................................................................... 5-22

Table of Contents Section-Page
iv WM doc 6/18/21 Table of Contents
5.14 Board Catcher (Optional) .....................................................................5-23
5.15 Table Extensions (Optional).................................................................5-24

About this manual
doc061821 1-1
1
SECTION 1 Introduction
1.1 About this manual
Congratulations on your purchase of a Wood-Mizer Pallet Dismantler Conveyor!
When properly maintained and operated, your pallet dismantler conveyor should give you
many years of dependable service.
CAUTION! Read this entire manual before
operating the equipment. Take notice of all safety
warnings throughout this manual and those
posted on the equipment. Keep this manual with
this equipment at all times, regardless of owner-
ship.
Read all additional manufacturer’s manuals and observe any
applicable safety instructions including dangers, warnings, and
cautions.
Only persons who have read and understood the entire operator's manual should operate
the Wood-Mizer Pallet Dismantler Conveyor. The pallet dismantler conveyor is not
intended for use by or around children.
1.2 Getting service
Wood-Mizer is committed to providing you with the latest technology, highest quality
equipment, and strongest customer service available on the market today. We continually
evaluate our customers’ needs to ensure we’re meeting current wood-processing
demands. Your comments and suggestions are welcome.
GENERAL CONTACT INFORMATION
Toll free phone numbers are listed below for the continental U.S. and Canada. See the
next page for contact information for more Wood-Mizer locations.
United States Canada
Sales 1-800-553-0182 1-877-866-0667
Service 1-800-525-8100 1-877-866-0667
Website www.woodmizer.com www.woodmizer.ca

Getting service
1
1-2 doc061821
Office Hours: All times are Eastern Standard Time.
Please have your vehicle identification number and your customer number ready when
you call.
Wood-Mizer will accept these methods of payment:
Visa, Mastercard, or Discover
COD
Prepayment
Net 15 (with approved credit)
Be aware that shipping and handling charges may apply. Handling charges are based on
size and quantity of order. In most cases, items will ship on the day they are ordered.
Second Day and Next Day shipping are available at additional cost.
If your pallet dismantler conveyor was purchased outside of the United States or Canada,
contact the distributor for service.
WOOD-MIZER LOCATIONS
E-mail [e-mail] [e-mail]
Monday - Friday Saturday
(Indianapolis Office Only)
Sunday
8a.m. to 5 p.m. 8 a.m. to 12 p.m. Closed
USA World Headquarters Canadian Headquarters
Serving North & South America, Oceania, East
Asia
Wood-Mizer LLC
8180 West 10th Street
Indianapolis, IN 46214
Phone: [phone] or 800.553.0182
Customer Service: 800.525.8100
Fax: [phone]
Email: [e-mail]
Serving Canada
Wood-Mizer Canada
396 County Road 36, Unit B
Lindsay, ON K9V 4R3
Phone: [phone] or 877.357.3373
Fax: [phone]
Email: [e-mail]

Getting service
doc061821 1-3
1
Brazilian Headquarters European Headquarters
Serving Brazil
Wood-Mizer do Brasil
Rua Dom Pedro 1, No: 205 Bairro: Sao Jose
Ivoti/RS CEP:93.900-000
Tel: [phone]/ +55 51
3563-4784
Email: [e-mail]
Serving Europe, Africa, West Asia
Wood-Mizer Industries Sp z o.o.
Nagorna 114
62-600 Kolo, Poland
Phone: [phone]
Fax: [phone]
Branches & Authorized Sales Centers
For a complete list of dealers, visit www.woodmizer.com

Warranty
1
1-4 doc061821
1.3 Warranty
Wood-Mizer® LLC
Limited Product Warranty
Wood-Mizer LLC (“Warrantor”), an Indiana corporation with its principal place of business
at 8180 West Tenth Street, Indianapolis, IN 46214-2400 USA, warrants to the purchaser
(“Purchaser”) that for the time periods specifically stated herein and subject to the terms,
conditions and limitations stated herein, the equipment manufactured by the Warrantor
will be free from defects in material and workmanship attributable to Warrantor so long as,
during the warranty periods stated herein, the equipment is installed, operated and main-
tained in accordance with the instructions provided by Warrantor.
EXCLUSIONS FROM 90 DAY, LIMITED ONE YEAR AND TWO YEAR WARRANTY
Warrantor shall have no responsibility under this warranty for any wear components,
including, but not limited to: belts, blade guides, blades, electric motor brushes, drum
switches, filters, fuses, hoses, bearings (excluding cylindrical drive bearings), bushings,
cable carriers, and spark plugs. All wear components are furnished “as is”, without any
warranty from Warrantor. This limited warranty does not cover any defects caused by
PRODUCT MODEL CLASS
LENGTH OF WARRANTY
EFFECTIVE DATE
USA & CANADA NON USA &
CANADA
Portable s, Resaws, Edgers LT, HR, EG, LX Two years One year
Date of purchase
Portable s with Chassis LT28, LT35, LT40,
LT50, LT70, LX450
Two years, excluding
the chassis; chassis
shall have a five year
warranty
One year
Industrial s, Resaws, Edgers WM, HR, EG, TVS,
SVS, FS One year One year
Date of purchase or date
of installation / training (if
applicable), whichever
occurs first, not to exceed
6 months from date of
purchase
Material Handling TWC, IC, TD, LD,
GC, CR, CB, CC One year One year
Pallet Dismantler PD One year One year
Date of purchase
Blade Maintenance Equipment BMS, BMT, BMST One year One year
Options and Accessories Various One year* One year 1
1 Warranty on Options will match the warranty on the primary equipment when purchased on same invoice.
Moulders, Kilns MP, SD One year One year
Replacement Parts Various 90 days 90 days

Warranty
doc061821 1-5
1
misuse, negligence, alterations, damage due to overload, abnormal conditions, excessive
operation, accident, or lack of performance of normal maintenance services.
Several components which are used in the manufacture of the equipment but not manu-
factured by Warrantor, such as cant hooks, power plants, laser sights, batteries, tires, and
trailer axles have warranties provided by the original equipment manufacturer (written
copies available upon request). Warrantor does not separately warrant such items. Com-
ponents or equipment manufactured by third parties are not covered by this warranty.
Warrantor, however, will provide reasonable assistance to the Purchaser to make claims
against any warranties applicable to such component parts as provided by such original
equipment manufacturers. Components or equipment manufactured by third parties are
not covered by this Warranty.
FIVE YEAR LIMITED CHASSIS WARRANTY
The limited five year chassis warranty, described above, DOES NOT extend to (a) any
damage stemming from accident, improper towing, overload, abuse, misuse, abnormal
conditions, negligence, excessive operation, or lack of maintenance, (b) rust caused by
exposure to corrosive atmospheric conditions, or (c) the head, carriage, axle, brakes, or
any hydraulic or electrical components attached to the chassis.
WARRANTOR’S OBLIGATIONS AS TO DEFECTS
In the event that the equipment fails to perform due to defective materials or workmanship
attributable to Warrantor under normal use and service within the established warranty
period, Purchaser’s sole and exclusive remedy and Warrantor’s sole liability shall be to
replace or repair, in Warrantor’s sole and subjective discretion, any defective part at War-
rantor’s principal place of business without cost to the Purchaser if such defect exists.
The determination of whether a product is defective shall be made by Warrantor in War-
rantor’s sole and subjective discretion. The Purchaser must notify Warrantor prior to ship-
ping any defective part. Warrantor, at its sole discretion, may cover expenses incurred in
shipping the defective part to Warrantor for evaluation; provided, however, that Warrantor
will not be responsible for labor, travel time, mileage, removal, installation, and/or inciden-
tal or consequential damages. However, any part in excess of 140 pounds must be
returned by the Purchaser to the Warrantor’s nearest authorized facility at the Pur-
chaser’s expense, if return is requested by Warrantor. Warrantor shall have a reasonable
time within which to repair or replace the defective part. If Warrantor determines that the
product is not defective under the terms of this warranty in Warrantor’s sole and subjec-
tive discretion, then Purchaser shall be responsible for any expenses incurred by Warran-
tor in returning the equipment to the Purchaser.
LIMITATIONS AND DISCLAIMERS OF OTHER WARRANTIES
EXCEPT FOR THE EXPRESS WARRANTY PROVISIONS STATED ABOVE, WARRAN-
TOR DISCLAIMS ALL WARRANTIES, EXPRESS AND/OR IMPLIED, INCLUDING AND
WITHOUT LIMITATION, THE IMPLIED WARRANTIES OF MERCHANTABILITY, AND
FITNESS FOR A PARTICULAR PURPOSE, NONINFRINGEMENT AND TITLE. No rep-

Warranty
1
1-6 doc061821
resentation or other affirmation of fact by representatives of Warrantor, whether verbal or
in writing, including photographs, brochures, samples, models, or other sales aids, shall
constitute a warranty, or any other basis, for any legal action against Warrantor. There are
no other representations, promises, agreements, covenants, warranties, guarantees, stip-
ulations or conditions, expressed or implied, by Warrantor, except as expressly set forth
herein. THE ORIGINAL PURCHASER AND ANY INTENDED USER OR BENEFICIARY
OF THIS EQUIPMENT, SHALL NOT BE ENTITLED TO RECOVER ANY INDIRECT,
SPECIAL, PUNITIVE, EXEMPLARY, CONSEQUENTIAL, SPECIAL, OR INCIDENTIAL
DAMAGES OR LOSES, INCLUDING BUT NOT LIMITED TO, DAMAGES OF LOST
PRODUCTION, LOST REVENUE, LOST PRODUCT, LOST PROFITS, LOST BUSI-
NESS, LOSS OF USE, LOSS OF GOODWILL, OR BUSINESS INTERRUPTION, FROM
WARRANTOR FOR ANY REASON WHATSOEVER INCLUDING, WITHOUT LIMITA-
TION, WARRANTY OR DEFECT IN THE PRODUCT REGARDLESS OF THE SOLE,
JOINT, AND/OR CONCURRENT NEGLIGENCE, BREACH OF CONTRACT, BREACH
OF WARRANTY, STRICT LIABILITY IN TORT OR STATUTORY CLAIMS, OR OTHER
LEGAL FAULT, OR RESPONSIBILITY OF EITHER WARRANTOR OR PURCHASER OR
ITS EMPLOYEES OR AGENTS. Warrantor does not warrant that its equipment meets or
complies with the requirements of any particular safety code or governmental require-
ments.
Defective items, replaced under the terms of this warranty, become the property of War-
rantor.
DESIGN CHANGES
Warrantor reserves the right to change the design of its products from time to time without
notice and without obligation to make corresponding changes in or to its products previ-
ously manufactured.
RIGHTS OF PURCHASERS
The validity and effect of this limited warranty, as well as its interpretation, operation and
effect, shall be determined exclusively by the principles of law and equity of the State of
Indiana, USA. This limited warranty gives Purchaser specific legal rights. Purchaser may
also have other rights, which may vary from state to state. Some states may not allow lim-
itations as to the duration of implied warranties or to the exclusion or limitation of inciden-
tal or consequential damages, therefore some of the limitations and exclusions detailed
set forth above may not apply. In the event that any one or more of the provisions of this
warranty shall be or become invalid, illegal or unenforceable in any respect, the validity,
legality and enforceability of the remaining provisions of this warranty shall not be
affected thereby.
INTERPRETATIONS
This Warranty constitutes the entire warranty agreement between Warrantor and Purchaser and
supersedes any prior understandings or agreements pertaining to the same subject matter. This

Warranty
doc061821 1-7
1
warranty cannot be amended, except in writing, which refers to this warranty that is signed by both
Warrantor and Purchaser.
Effective: January 1, 2018
© 2013 Wood-Mizer LLC – 8180 West 10th Street, Indianapolis, IN 46214

General Safety
Owner’s Responsibility
2
2-1 doc061821 General Safety
SECTION 2 Genera l Safety
Owner’s Responsibility
IMPORTANT! It is always the owner's responsibility to comply
with all applicable safety instructions, as well as federal, state and
local laws, rules and regulations regarding the ownership and oper-
ation equipment. All owners should be thoroughly familiar with all
applicable safety instructions and laws and comply with them fully
while using or transporting the equipment.
WARNING! Clean sawdust from all guards, vents, con-
trol boxes, or any area where sawdust may gather after
every shift. Failure to do so may result in fire.
NOTE: ONLY safety instructions regarding personal injury
are listed in this section. Safety instructions regarding only equipment
damage appear where applicable throughout the manual.
2.1 Safety symbols
The following symbols and signal words call your attention to instructions concerning your
personal safety. Be sure to observe and follow these instructions.
DANGER! indicates an imminently hazardous situation which, if
not avoided, will result in death or serious injury.
WARNING! suggests a potentially hazardous situation which, if not
avoided, could result in death or serious injury.
CAUTION! refers to potentially hazardous situations which, if not
avoided, may result in minor or moderate injury or damage to
equipment.
IMPORTANT! indicates vital information.
NOTE: gives helpful information.

General Safety
Safety symbols
General Safety doc061821 2-2
2
OBSERVE SAFETY INSTRUCTIONS
IMPORTANT!
Keep children away from the area.
Read the entire operator's manual before operating the equip-
ment.
Take notice of all safety warnings throughout this manual and those posted on the
machine.
Keep this manual with this machine at all times, regardless of ownership.
Read all additional manufacturer’s manuals.
Obey all applicable safety instructions including dangers, warnings, and cautions.
Only persons who have read and understood the entire operator's manual should
operate the equipment.
WEAR SAFETY CLOTHING
WARNING! Secure all loose clothing and jewelry before operating
the equipment. Failure to do so may result in death or serious
injury.
WARNING! Always wear hand, eye, ear,
and foot protection when operating or ser-
vicing the equipment. Failure to do so may
result in death or serious injury.
EQUIPMENT SETUP
DANGER! Do not operate the equipment
without all covers and guards in place. Fail-
ure to do so may result in death or serious
injury.
WARNING! Set up the equipment on solid, level ground. Failure to
do so may result in death or serious injury.
WARNING! Check that the tire pressures are between 50-55 psi.
Failure to do so may result in death or serious injury.

General Safety
Safety symbols
2
2-3 doc061821 General Safety
KEEP HANDS AWAY
DANGER! Keep hands 12” away from the blade. Failure to do so
will result in death or serious injury.
DANGER! Remove power before clearing debris or any other
maintenance activity. Failure to do so will result in death or serious
injury.
WARNING! Avoid contact with any hot parts (engines or motors).
Failure to do so may result in death or serious injury.
Allow the system to cool sufficiently before beginning any
service function, including debris removal.
WARNING! Avoid contact with sharp edges of
the cutting blade. Failure to do so may result in
death or serious injury.
KEEP EQUIPMENT AND AREA AROUND EQUIPMENT
CLEAN
DANGER! Maintain a clean and clear path for
all necessary movement around the equipment and stacking
areas. Failure to do so will result in death or serious injury.
WARNING! Do not allow children in the area of the equipment.
Failure to do so may result in death or serious injury
DISPOSE OF WOOD BY-PRODUCTS PROPERLY
IMPORTANT! Properly dispose of all wood by-products, including
sawdust, chips, and other debris, including operation waste such
as coolant, oil, fuel, oil filters, fuel filters, etc.
KEEP SAFETY LABELS IN GOOD CONDITION
IMPORTANT! Ensure that all safety decals are clean and read-
able. Replace all damaged safety decals to prevent personal injury
or damage to the equipment. Contact your local distributor, or call
your Customer Service Representative to order more decals.
IMPORTANT! If replacing a component that has a safety decal
affixed to it, ensure the new component also has the safety decal
affixed.

General Safety
Electrical Lockout Procedures
General Safety doc061821 2-4
2
2.2 Electrical Lockout Procedures
RULES FOR USING LOCKOUT PROCEDURE
The equipment shall be locked out to protect against accidental or inadvertent operation
when such operation could cause injury to personnel. Do not attempt to operate any
switch or valve bearing a lock. Lockout procedures must be used during:
Maintenance hazards include:
Failure to lockout may result in:
To control maintenance dangers:
Lockout procedures must be followed (see OSHA regulation 1910.147).
Never rely on machine stop control for maintenance safety (emergency stops, on/off
buttons, interlocks).
Table 1:
Changing or adjusting blades Electrical maintenance
Unjamming operations Retrieval of tools/parts from work area
Cleaning Activities where guards or electrical
panel guard is open or removed
Mechanical repair
Table 2:
Blade contact Missiles (thrown blades/wood chips)
Pinch points Electrical
Kickbacks
Table 3:
Cut Serious injury and death
Crush Amputation
Blindness Burn
Puncture Shock
Electrocution

General Safety
Electrical Lockout Procedures
2
2-5 doc061821 General Safety
Do not reach into moving blades or feed systems. Allow all coasting parts to come
to a complete stop.
Electrical power supply and air supply must both be locked out.
Where established lockout procedures cannot be used (electrical troubleshooting or
mechanical dynamic troubleshooting), alternative effective protective techniques
shall be employed which may require special skills and planning.
Always follow safe operations practices in the workplace.
S LOCKOUT PROCEDURE
Lockout procedures per OSHA regulation 1910.147, appendix A:
GENERAL
The following simple lockout procedure is provided to assist owner/operators in develop-
ing their procedures so they meet the requirements of OSHA regulation 1910.147. When
the energy isolating devices are not lockable, tagout may be used, provided the
owner/operator complies with the provisions of the standard which require additional
training and more rigorous periodic inspections. When tagout is used and the energy iso-
lating devices are lockable, the owner/operator must provide full operator protection (see
OSHA regulation 1910.147, paragraph (c)(3)) and additional training and more rigorous
periodic inspections are required. For more complex systems, more comprehensive pro-
cedures may need to be developed, documented, and utilized.
PURPOSE
This procedure establishes the minimum requirements for the lockout of energy isolating
devices whenever maintenance or servicing is done on machines or equipment. It shall
be used to ensure that the machine or equipment is stopped, isolated from all potentially
hazardous energy sources and locked out before personnel perform any servicing or
maintenance where the unexpected energization or start-up of the machine or equipment
or release of stored energy could cause injury.
COMPLIANCE WITH THIS PROGRAM
All personnel are required to comply with the restrictions and limitations imposed upon
them during the use of lockout. The authorized personnel are required to perform the
lockout in accordance with this procedure. All operators, upon observing a machine or
piece of equipment which is locked out to perform servicing or maintenance shall not
attempt to start, energize, or use that machine or equipment.

General Safety
Electrical Lockout Procedures
General Safety doc061821 2-6
2
SEQUENCE OF LOCKOUT
1. Notify all affected personnel that servicing or maintenance is required on a machine or
equipment and that the machine or equipment must be shut down and locked out to per-
form the servicing or maintenance.
2. The authorized employee shall refer to the company procedure to identify the type and
magnitude of the energy that the machine or equipment utilizes, shall understand the haz-
ards of the energy, and shall know the methods to control the energy.
3. If the machine or equipment is operating, shut it down by the normal stopping procedure
(depress the stop button, open switch, close valve, etc.).
4. De-activate the energy isolating device(s) so that the machine or equipment is isolated
from the energy source(s).
5. Lock out the energy isolating device(s) with assigned individual lock(s).
6. Stored or residual energy (such as that in capacitors, springs, elevated machine mem-
bers, rotating flywheels, hydraulic systems, and air, gas, steam, or water pressure, etc.)
must be dissipated or restrained by methods such as grounding, repositioning, blocking,
bleeding down, etc.
7. Ensure that the equipment is disconnected from the energy source(s) by first checking
that no personnel are exposed, then verify the isolation of the equipment by operating the
push button or other normal operating control(s) or by testing to make certain the equip-
ment will not operate.
CAUTION! Return operating control(s) to neutral or "off" position
after verifying the isolation of the equipment.
8. The machine or equipment is now locked out.
RESTORING EQUIPMENT TO SERVICE
When the servicing or maintenance is completed and the machine or equipment is ready
to return to normal operating condition, the following steps shall be taken.
1. Check the machine or equipment and the immediate area around the machine to ensure
that nonessential items have been removed and that the machine or equipment compo-
nents are operationally intact.
2. Check the work area to ensure that all personnel have been safely positioned or removed
from the area.
3. Verify that the controls are in neutral.

General Safety
Electrical Lockout Procedures
2
2-7 doc061821 General Safety
4. Remove the lockout devices and reenergize the machine or equipment.
NOTE: The removal of some forms of blocking may require
re-energization of the machine before safe removal.
5. Notify affected personnel that the servicing or maintenance is completed and the machine
or equipment is ready for use.
PROCEDURE INVOLVING MORE THAN ONE PERSON
In the preceding steps, if more than one individual is required to lock out the equipment,
each shall place his own personal lock on the energy isolating devices.

Setup and Operation
Site Preparation
Setup and Operation doc061821 3-1
3
SECTION 3 SETUP AND OPERATION
3.1 Site Preparation
An outside source of compressed air adjustable from 80-120 psi (5.6-8.4 Kg/cm) is
required.
WARNING! Have a certified electrician install the power to your
machine. Failure to do so may result in death or serious injury.
WARNING! Be sure the power supply cables are not a trip hazard.
Failure to do so may result in death or serious injury.
CAUTION! Improper voltage will cause damage to the motor and
electronic components. Have a qualified electrician install the
power supply to begin using your pallet dismantler.
IMPORTANT! The power supply must meet the motor specifica-
tions concerning wire size, fused disconnect, and voltage, which
are provided in the motor’s manual. The electrical installation must
also meet local codes.
IMPORTANT! Ensure the blade spins in the proper direction. If not,
have the electrician change the engine rotation.
3.2 Onsite setup
DANGER! Maintain a clean and clear path for all necessary move-
ment around the pallet dismantler and stacking areas. Failure to do
so will result in death or serious injury.
WARNING! Do not allow children in the area of the pallet disman-
tler. Failure to do so may result in death or serious injury.
WARNING! Do not set up the pallet dismantler on ground with
more than a 10 degree incline. Failure to do so may result in death
or serious injury.
FOR GAS ENGINES
DANGER! Do not operate this unit indoors or in an enclosed area;
carbon monoxide poisoning will occur. Failure to do so will result in
death or serious injury.

Setup and Operation
Operation
3
3-2 doc061821 Setup and Operation
3.3 Operation
DANGER! Keep hands 12” away from the blade. Failure to do so
will result in death or serious injury.
WARNING! Do not load pallets greater than 60”
(1.5 m). Failure to do so may result in death or
serious injury.
WARNING! Avoid contact with sharp edges of
the cutting wedges. Failure to do so may result in
death or serious injury.
WARNING! Check that the tire pressures are
between 50-55 psi. Failure to do so may result in death or serious
injury.
FOR GAS ENGINES
DANGER! Do not operate this unit indoors or in an enclosed area;
carbon monoxide poisoning will occur. Failure to do so will result in
death or serious injury.
One-person operation
IMPORTANT! Before starting, ensure the blade is tensioned prop-
erly. Failure to do so may result in drive wheel tire damage.
6. Tighten the tension by ratcheting the device handle until the pivot arm is touching the stop
bolt.
NOTE: If a new blade is required see Section 4.3 Changing the
blade.
