Woods DS8.30 User manual

OPERATOR'S MANUALOPERATOR'S MANUAL (Rev 07/25/2023)
MAN1167
ROTARY CUTTER
DS8.30
DS10.40

2 Introduction MAN1167
(07/25/2023)
TO THE DEALER:
Assembly and proper installation of this product is the responsibility of the Woods®dealer. Read manual instructions
and safety rules. Make sure all items on the Dealer’s Pre-Delivery and Delivery Checklists in the Operator’s Manual are
completed before releasing equipment to the owner.
The dealer must complete the online Product Registration form at the Woods Dealer Website which certies that
all Dealer Checklist items have been completed. Dealers can register all Woods product at dealer.WoodsEquipment.com
under Product Registration.
Failure to register the product does not diminish customer’s warranty rights.
TO THE OWNER:
Read this manual before operating your Woods equipment. The information presented will prepare you to do a better
and safer job. Keep this manual handy for ready reference. Require all operators to read this manual carefully and
become acquainted with all adjustment and operating procedures before attempting to operate. Replacement man-
uals can be obtained from your dealer. To obtain complete warranty details, visit WoodsEquipment.com/warranty.
You may also request a hard copy by calling 1-800-319-6637 or mail your request to: Woods Equipment Company,
Attn: Warranty Dept. 2606 South Illinois Route 2, Oregon, IL 61061. To locate your nearest dealer, check the Dealer
Locator at www.WoodsEquipment.com, or in the United States and Canada call 1-800-319-6637.
The equipment you have purchased has been carefully engineered and manufactured to provide dependable and sat-
isfactory use. Like all mechanical products, it will require cleaning and upkeep. Lubricate the unit as specied. Observe
all safety information in this manual and safety decals on the equipment.
For service, your authorized Woods dealer has trained mechanics, genuine Woods service parts, and the necessary
tools and equipment to handle all your needs.
Use only genuine Woods service parts. Substitute parts will void the warranty and may not meet standards required
for safe and satisfactory operation. Record the model number and serial number of your equipment in the spaces
provided:
Model: Date of Purchase:
Serial Number: (see Safety Decal section for location)
Provide this information to your dealer to obtain correct repair parts.
Throughout this manual, the term NOTICE is used to indicate that failure to observe can cause damage to equipment.
The terms CAUTION, WARNING, and DANGER are used in conjunction with the Safety-Alert Symbol (a triangle with
an exclamation mark) to indicate the degree of hazard for items of personal safety.
This is the safety alert symbol. It is used to alert you to potential physical
injury hazards. Obey all safety messages that follow this symbol to avoid
possible injury or death.
Indicates a hazardous situation that, if not avoided, will result in death or
serious injury.
Indicates a hazardous situation that, if not avoided, could result in death
or serious injury.
Indicates a hazardous situation that, if not avoided, could result in minor
or moderate injury.
Is used to address practices not related to physical injury.
Indicates helpful information.
DANGER
WARNING
CAUTION
or NOTICE
IMPORTANT
NOTE

Introduction 3
MAN1167
(07/25/2023)
This Operator’s Manual should be regarded as part of the machine.
Suppliers of both new and second-hand machines must make sure
that this manual is provided with the machine.
TABLE OF CONTENTS
INTRODUCTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
GENERAL INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
MOWER SAFETY VIDEO. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
SAFETY RULES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
TRAINING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
PREPARATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
TRANSPORTATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
STORAGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
SAFETY & INSTRUCTIONAL DECALS . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
TRACTOR STABILITY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
CONNECT CUTTER TO TRACTOR (PULL-TYPE) . . . . . . . . . . . . . . .13
CONNECT CUTTER TO TRACTOR (MOUNTED) . . . . . . . . . . . . . . . .14
DRIVELINE ADJUSTMENT. . . . . . . . . . . . . . . . . . . . . . . . . . . .15
CUTTING HEIGHT ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . .17
ATTITUDE ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
TRACTOR OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
OPERATING TECHNIQUE . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
TRANSPORTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
STORAGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
PRE-OPERATION CHECKLIST . . . . . . . . . . . . . . . . . . . . . . . . .19
OWNER SERVICE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
OWNER SERVICE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
BLOCKING METHOD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
LUBRICATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
BLADE SERVICING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
SLIP CLUTCH ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . .22
RUBBER DISK REPLACEMENT . . . . . . . . . . . . . . . . . . . . . . . . .23
SHIELDING REPAIR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
SERVICING TIRES SAFELY . . . . . . . . . . . . . . . . . . . . . . . . . . .24
CLEANING CUTTER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
TROUBLESHOOTING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
DEALER SERVICE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
DEALER SERVICE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
GEARBOX MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . .27
SEAL REPLACEMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
SEAL INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
GEARBOX REPAIR - DS8.30 . . . . . . . . . . . . . . . . . . . . . . . . . .28
SEAL REPAIR - DS8.30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
SPINDLE GEARBOX REPAIR - DS10.40 . . . . . . . . . . . . . . . . . . . .30
SEAL REPAIR - DS10.40 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
SPLITTER GEARBOX REPAIR . . . . . . . . . . . . . . . . . . . . . . . . .32
SIDE DRIVE SERVICE . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
CROSSBAR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
UNIVERSAL JOINT REPAIR . . . . . . . . . . . . . . . . . . . . . . . . . . .37
SERVICING TIRES SAFELY . . . . . . . . . . . . . . . . . . . . . . . . . . .38
ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
DEALER SET-UP INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . .39
ASSEMBLE - DS8.30 & DS10.40 PULL- TYPE CUTTER . . . . . . . . . . . .39
ASSEMBLE DS8.30 & DS10.40 3-POINT MOUNTED CUTTER . . . . . . . .41
FILL GEARBOXES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
INSTALL CHAIN OR RUBBER SHIELDING . . . . . . . . . . . . . . . . . . .43
DEALER CHECKLISTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
PARTS INDEX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
APPENDIX. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
BOLT TORQUE CHART . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
BOLT SIZE CHART & ABBREVIATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
INDEX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

4 Introduction MAN1167
(07/25/2023)
SPECIFICATIONS
DS8.30 DS10.40
Cutting Height 2" - 12"
Cutting Width 96" 120"
Overall Width 100.5" 124.5"
Overall Length: Pull Type (25" Tires) 142" 155"
Overall Length: Mounted 96" 106"
Minimum Tractor HP: Pull-Type 35 HP 40 HP
Minimum Tractor HP: Mounted 45 HP 60 HP
Tractor PTO RPM 540
Number of Blade Spindles 2
Blade Overlap 4"
Number of Blades 4
Driveline w/Slip Clutch: Pull-Type Cat 4 CV Cat 4 CV
Driveline w/Slip Clutch: Mounted Cat 4 Cat 5
Side Frame Thickness 7 Ga 7 Ga
Weight (w/ Belting): Pull-Type 1,440 lbs 1,820 lbs
Weight (w/ Belting): Mounted 1,215 lbs 1,575 lbs
Blade Speed (Feet per Minute) 15,200 16,700
Blade Rotation Left Spindle: CCW; Right Spindle: CW
Wheel Size: Pull-Type 15"Rims
21"Laminated
25"Severe Duty
15"Rims
21"Laminated
25"Severe Duty
Wheel Size: Mounted 16" Laminated 16" Laminated
Torsion Protection Slip Clutch and Flex Couplers
GENERAL INFORMATION
■Some illustrations in this manual show the
mower with safety shields removed to provide a
better view. The mower should never be operat-
ed with any safety shielding removed.
The purpose of this manual is to assist you in oper-
ating and maintaining your cutter. Read it carefully.
It furnishes information and instructions that will help
you achieve years of dependable performance. These
instructions have been compiled from extensive eld
experience and engineering data. Some information
may be general in nature due to unknown and vary-
ing operating conditions. However, through experience
and these instructions, you should be able to develop
procedures suitable to your particular situation.
The illustrations and data used in this manual were cur-
rent at the time of printing but, due to possible inline
production changes, your machine may vary slightly in
detail. We reserve the right to redesign and change the
machines as may be necessary without notication.
Throughout this manual, references are made to right
and left directions. These are determined by standing
behind the equipment facing the direction of forward
travel. Blade rotation is clockwise (left wing) and coun-
terclockwise (right wing and center section) as viewed
from the top of the cutter.
WARNING
NOTICE:
If you would like to receive a free Spanish language translation of the Safety Rules section of this
manual, plus a set of Spanish language safety decals, please contact your local Woods dealer.
AVISO:
Si desea recibir una traducción al español gratuita de la sección de Reglas de seguridad de
este manual y un juego de etiquetas de seguridad en español, por favor comuníquese con su
concesionario local de Woods.
¡LEA EL INSTRUCTIVO!
Si no lee Ingles, pida ayuda a
alguien que si lo lee para que le
traduzca las medidas de seguridad.

Safety 5
MAN1167
(07/25/2023)
Watch a Mower Safety Video Online
The AEM (Association of Equipment Manufacturers) offers a safety
training video, Industrial and Agricultural Mower Safety Practices. The
22-minute video can be viewed online for free at TheAEMStore,
https://youtu.be/EuktqJNAjhc
It reinforces the proper procedures to follow while operating your mowing
equipment. The video does not replace the information contained in the
Operator’s Manual, so please review this manual thoroughly before
operating your new mowing equipment.
Safety Training
Does Make a Difference.
BE SAFE!
BE ALERT!
BE ALIVE!
BE TRAINED
Before Operating Mowers!
ASSOCIATION OF
EQUIPMENT
MANUFACTURERS

6 Safety MAN1167
(07/25/2023)
Also, available from the Association of Equipment Manufacturers:
A large variety of training materials (ideal for groups) are available for a nominal
charge from AEM. Following is a partial list:
Training Package for Rotary Mowers/Cutters-English
Contains: DVD & VHS (English)
Guidebook for Rotary Mowers/Cutters (English)
AEM Industrial/Agricultural Mower Safety Manual (English)
AEM Agricultural Tractor Safety Manual (English)
Training Package for Rotary Mowers/Cutters-English/Spanish
Contains: DVD & VHS (English/Spanish)
Guidebook for Rotary Mowers/Cutters (English/Spanish)
AEM Industrial/Agricultural Mower Safety Manual (English/Spanish)
AEM Agricultural Tractor Safety Manual (English/Spanish)
AEM training packages are available through:
AEM at: www.aem.org
or
Universal Lithographers, Inc.
Email: [email protected]
800-369-2310 tel
866-541-1668 fax

Safety 7
MAN1167
(07/25/2023)
TRAINING
■Safety instructions are important! Read all
attachment and power unit manuals; follow
all safety rules and safety decal information.
(Replacement manuals and safety decals are
available from your dealer. To locate your
nearest dealer, check the Dealer Locator at
www.WoodsEquipment.com, or in the United
States and Canada call 1-800-319-6637.) Failure
to follow instructions or safety rules can result
in serious injury or death.
■If you do not understand any part of this manual
and need assistance, see your dealer.
■Know your controls and how to stop engine and
attachment quickly in an emergency.
■Operators must be instructed in and be capa-
ble of the safe operation of the equipment, its
attachments, and all controls. Do not allow any-
one to operate this equipment without proper
instructions.
■Keep hands and body away from pressurized
lines. Use paper or cardboard, not hands or
other body parts to check for leaks. Wear safe-
ty goggles. Hydraulic uid under pressure can
easily penetrate skin and will cause serious in-
jury or death.
■Make sure that all operating and service person-
nel know that if hydraulic uid penetrates skin,
it must be surgically removed as soon as possi-
ble by a doctor familiar with this form of injury
or gangrene, serious injury, or death will result.
CONTACT A PHYSICIAN IMMEDIATELY IF FLUID
ENTERS SKIN OR EYES. DO NOT DELAY.
■Never allow children or untrained persons to op-
erate equipment.
PREPARATION
■Check that all hardware is properly installed.
Always tighten to torque chart specications
unless instructed otherwise in this manual.
■Air in hydraulic systems can cause erratic opera-
tion and allows loads or equipment components
to drop unexpectedly. When connecting equip-
ment or hoses or performing any hydraulic
maintenance, purge any air in hydraulic sys-
tem by operating all hydraulic functions several
times. Do this before putting into service or al-
lowing anyone to approach the equipment.
■ Make sure all hydraulic hoses, ttings, and
valves are in good condition and not leaking
before starting power unit or using equipment.
Check and route hoses carefully to prevent
damage. Hoses must not be twisted, bent sharp-
ly, kinked, frayed, pinched, or come into contact
with any moving parts. Operate moveable com-
ponents through full operational range to
check clearances. Replace any damaged hoses
immediately.
■Always wear relatively tight and belted clothing
to avoid getting caught in moving parts. Wear
sturdy, rough-soled work shoes and protec-
tive equipment for eyes, hair, hands, hearing,
and head; and respirator or lter mask where
appropriate.
■Make sure attachment is properly secured, ad-
justed, and in good operating condition.
■Make sure spring-activated locking pin or collar
slides freely and is seated rmly in tractor PTO
spline groove.
■If equipped with driveline guard tether chains,
make sure they are attached to the tractor and
equipment as shown in the pamphlet that ac-
com-panies the driveline. Replace if damaged
or broken. Check that driveline guards rotate
freely on drive-line before putting equipment
into service.
■Power unit must be equipped with ROPS or
ROPS cab and seat belt. Keep seat belt secure-
ly fastened. Falling off power unit can result in
death from being run over or crushed. Keep
foldable ROPS system in “locked up” position
at all times.
■Inspect chain or rubber belt shielding before
each use. Replace if damaged.
■Remove accumulated debris from this equip-
ment, power unit, and engine to avoid re
hazard.
■Make sure all safety decals are installed.
Replace if damaged. (See Safety Decals section
for location.)
Safety is a primary concern in the design and man-
ufacture of our products. Unfortunately, our efforts
to provide safe equipment can be wiped out by an
operator’s single careless act.
In addition to the design and conguration of
equipment, hazard control and accident preven-
tion are dependent upon the awareness, concern,
judgement, and proper training of personnel in-
volved in the operation, transport, maintenance,
and storage of equipment.
It has been said, “The best safety device is an in-
formed, careful operator.” We ask you to be that
kind of operator.
SAFETY RULES
ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED!

8 Safety MAN1167
(07/25/2023)
■Make sure shields and guards are proper-
ly installed and in good condition. Replace if
damaged.
■Do not put this equipment into service unless
all side skids are properly installed and in good
condition. Replace if damaged.
■A minimum 20% of tractor and equipment
weight must be on the tractor front wheels when
attachments are in transport position. Without
this weight, front tractor wheels could raise up
resulting in loss of steering. The weight may
be attained with front wheel weights, ballast in
tires, front tractor weights or front loader. Weigh
the tractor and equipment. Do not estimate.
■Inspect and clear area of stones, branches, or
other hard objects that might be thrown, caus-
ing injury or damage.
■Connect PTO driveline directly to power unit
PTO shaft. Never use adapter sleeves or adapt-
er shafts. Adapters can cause driveline failures
due to incorrect spline or incorrect operating
length and can result in personal injury or death.
OPERATION
■Full chain shielding must be installed when op-
erating in populated areas or other areas where
thrown objects could injure people or damage
property.
• If this machine is not equipped with full chain
shielding, operation must be stopped.
• This shielding is designed to reduce the risk
of thrown objects. The mower deck and pro-
tective devices cannot prevent all objects
from escaping the blade enclosure in every
mowing condition. It is possible for objects
to ricochet and escape, traveling as much as
300 feet (92m).
■Do not allow bystanders in the area when op-
erating, attaching, removing, assembling, or
servicing equipment.
■Never direct discharge toward people, animals,
or property.
■Do not operate or transport equipment while
under the inuence of alcohol or drugs.
■ Operate only in daylight or good articial light.
■Keep hands, feet, hair, and clothing away from
equipment while engine is running. Stay clear of
all moving parts.
■Always comply with all state and local lighting
and marking requirements.
■Never allow riders on power unit or attachment.
■Power unit must be equipped with ROPS or
ROPS cab and seat belt. Keep seat belt secure-
ly fastened. Falling off power unit can result in
death from being run over or crushed. Keep
foldable ROPS system in “locked up” position
at all times.
■Always sit in power unit seat when operating
controls or starting engine. Securely fasten
seat belt, place transmission in neutral, engage
brake, and ensure all other controls are disen-
gaged before starting power unit engine.
■Operate tractor PTO at 540 RPM. Do not exceed.
■Look down and to the rear and make sure area is
clear before operating in reverse.
■Do not operate or transport on steep slopes.
■Do not stop, start, or change directions sudden-
ly on slopes.
■Use extreme care and reduce ground speed on
slopes and rough terrain.
■Watch for hidden hazards on the terrain during
operation.
■Stop power unit and equipment immediately
upon striking an obstruction. Turn off engine,
remove key, inspect, and repair any damage be-
fore resuming operation.
■Leak down or failure of mechanical or hydraulic
system can cause equipment to drop.
TRANSPORTATION
■The maximum transport speed for towed and
semi-mounted machines is 20 mph (32 km/h).
Regardless of the maximum speed capability
of the towing tractor, do not exceed the imple-
ment’s maximum transport speed. Doing so
could result in:
• Loss of control of the implement and tractor
• Reduced or no ability to stop during braking
• Implement tire failure
• Damage to the implement or its components.
■Use additional caution and reduce speed when
under adverse surface conditions, turning, or
on inclines.
■Never tow this implement with a motor vehicle.
■Do not operate PTO during transport.
■Do not operate PTO during transport.
■Do not operate or transport equipment while
under the inuence of alcohol or drugs.
■Always comply with all state and local lighting
and marking requirements.
■Never allow riders on power unit or attachment.
SAFETY RULES
ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED!

Safety 9
MAN1167
(07/25/2023)
MAINTENANCE
■Before dismounting power unit or perform-
ing any service or maintenance, follow these
steps: disengage power to equipment, lower
the 3-point hitch and all raised components to
the ground, operate valve levers to release any
hydraulic pressure, set parking brake, stop en-
gine, remove key, and unfasten seat belt.
■Before performing any service or maintenance,
disconnect driveline from tractor PTO.
■Before working underneath, raise mower, in-
stall transport lock, and block mower securely.
Hydraulic system leak down and failure of
mechanical or hydraulic system can cause
equipment to drop.
■Do not modify or alter or permit anyone else to
modify or alter the equipment or any of its com-
ponents in any way.
■Your dealer can supply original equipment hy-
draulic accessories and repair parts. Substitute
parts may not meet original equipment speci-
cations and may be dangerous.
■Always wear relatively tight and belted clothing
to avoid getting caught in moving parts. Wear
sturdy, rough-soled work shoes and protec-
tive equipment for eyes, hair, hands, hearing,
and head; and respirator or lter mask where
appropriate.
■Do not allow bystanders in the area when op-
erating, attaching, removing, assembling, or
servicing equipment.
■Never go underneath equipment (lowered to the
ground or raised) unless it is properly blocked
and secured. Never place any part of the body
underneath equipment or between moveable
parts even when the engine has been turned off.
Hydraulic system leak down, hydraulic system
failures, mechanical failures, or movement of
control levers can cause equipment to drop or
rotate unexpectedly and cause severe injury or
death. Follow Operator’s Manual instructions
for working underneath and blocking require-
ments or have work done by a qualied dealer.
■Make sure attachment is properly secured, ad-
justed, and in good operating condition.
■Keep all persons away from operator control
area while performing adjustments, service, or
maintenance.
■Make certain all movement of equipment com-
ponents has stopped before approaching for
service.
■Frequently check blades. They should be sharp,
free of nicks and cracks, and securely fastened.
■Do not handle blades with bare hands. Careless
or improper handling may result in serious
injury.
■Your dealer can supply genuine replacement
blades. Substitute blades may not meet orig-
inal equipment specications and may be
dangerous.
■Tighten all bolts, nuts, and screws to torque
chart specications. Check that all cotter pins
are installed securely to ensure equipment is in
a safe condition before putting unit into service.
■Make sure all safety decals are installed.
Replace if damaged. (See Safety Decals section
for location.)
■Make sure shields and guards are proper-
ly installed and in good condition. Replace if
damaged.
■Do not disconnect hydraulic lines until machine
is securely blocked or placed in lowest position
and system pressure is released by operating
valve levers.
■Leak down or failure of mechanical or hydraulic
system can cause equipment to drop.
■Explosive separation of tire and rim parts can
cause serious injury or death. Release all air
pressure before loosening bolts on wheel.
STORAGE
■Keep children, bystanders and animals away
from the equipment and the storage area.
■Follow manual instructions for storage.
ON MOUNTED CUTTERS:
■Disconnect cutter driveshaft and secure up off
ground. Raise cutter with 3-point hitch. Place
blocks under cutter side skids. Lower cutter
onto blocks. Disconnect hydraulic lines to op-
tional cylinder. Disconnect cutter from tractor
3-point hitch and carefully drive tractor away
from cutter.
ON PULL-TYPE CUTTERS:
■Raise cutter and block securely. Block wheels
and raise tongue with jack. Disconnect hydraulic
lines to optional cylinder. Disconnect driveline
and secure up off the ground.
SAFETY RULES
ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED!

10 Safety MAN1167
(07/25/2023)
1
2
3
45
5
6
7
8
9
9
10
11
12
12
12
13
14
15
(UNDER SHIELD)
15
(UNDER SHIELD)
9
9
9
CD8559
WARNING
18877 AH
4" x 5.5"
Black and PMS 151
TO AVOID SERIOUS
INJURY OR DEATH:
nRead Operator's Manual (available
from dealer) and follow all safety
precautions.
nKeep all shields in place and in good
condition.
nOperate mower from tractor seat only.
nLower mower, stop engine and remove
key before dismounting tractor.
nAllow no children or untrained persons
to operate equipment.
nDo not transport towed or semi-
mounted units over 20 mph (30 km/h).
FAILURE TO OPERATE SAFELY
CAN RESULT IN
INJURY OR DEATH.
1 - SERIAL NUMBER PLATE 4 - PN 188772 - PN 5669
3 - PN 12777
SAFETY & INSTRUCTIONAL DECALS
ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED!
Replace Immediately If Damaged!
10 - PN 57123
RED REAR REFLECTOR 9"
11 - PN 1002940
AMBER FRONT REFLECTOR 9"
BE CAREFUL!
Keep safety decals clean and visible.
Use a clean, damp cloth to clean safety decals.
Avoid spraying too close to decals when using a pressure washer;
high-pressure water can enter through very small scratches or un-
der edges of decals causing them to peel or come off.
Replace safety decals if they are missing or illegible.
Replacement safety decals can be ordered free from your Woods
dealer, or in the United States and Canada call 1-800-319-6637.

Safety 11
MAN1167
(07/25/2023)
SAFETY & INSTRUCTIONAL DECALS
ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED!
Replace Immediately If Damaged!
WARNING
FALLING OFF CAN RESULT IN BEING RUNOVER.
■Tractor must be equipped with ROPS (or ROPSCAB) and seat
belt. Keep foldable ROPS systems in “locked up” position at
all times.
■Buckle Up! Keep seat belt securely fastened.
■Never allow riders on mower or tractor.
RAISED EQUIPMENT CAN DROP AND CRUSH.
■Before working underneath, follow all instructions and safety
rules in operator’s manual and securely block up all corners
of equipment with jack stands.
■Securely blocking prevents equipment dropping from
hydraulic leakdown, hydraulic system failures or mechanical
component failures.
FALLING OFF OR FAILING TO BLOCK SECURELY CAN
RESULT IN SERIOUS INJURY OR DEATH.
18865
DO NOT EXCEED PTO SPEED OF
WARNING
18866
n PTO speeds higher than 540 RPM can cause equipment
failure and personal injury.
n Tractor PTO master shield, PTO drive shaft guarding
and PIC guards are to be kept in place.
540
2.25" x 3.5"
Black and PMS 151
9 - PN 18864
7 - PN 18865 8 - PN 18866
5 - PN 1003751 6 - PN 15503
12 - PN 1004114
1004114
If shaft connection is visible, shield
is missing. Replace shield before
operating equipment.
DANGER

12 Safety MAN1167
(07/25/2023)
14 - PN 1004991
SAFETY & INSTRUCTIONAL DECALS
ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED!
Replace Immediately If Damaged!
15 - PN 33347
PN 1006348 (LOCATED ON WHEEL RIMS)
PN 603626 (LOCATED ON A-FRAMES)
13 - PN W19924
RELEASE ALL AIR PRESSURE BEFORE LOOSENING BOLTS.
FAILURE TO DO SO COULD RESULT IN SERIOUS INJURY OR DEATH.
MAX. SPEED: 20 MPH, MAX. WEIGHT: 4000 LBS., MAX. AIR PRESSURE: 40 PSI.
1006348
EXPLOSION
HAZARD
WARNING

Operation 13
MAN1167
(07/25/2023)
OPERATION
The operator is responsible for the safe operation
of the cutter. The operator must be properly trained.
Operators should be familiar with the cutter, the tractor,
and all safety practices before starting operation. Read
the safety rules and safety decals on pages 7 to 12.
This medium-duty cutter is designed for grass and
weed mowing and shredding.
Recommended mowing speed for most conditions is
from 2 to 5 mph.
■Full chain or rubber shielding must be installed
when operating in populated areas or other
areas where thrown objects could injure people
or damage property.
• If this machine is not equipped with full
chain or rubber shielding, operation must be
stopped when anyone comes within 300 feet
(92 m).
• This shielding is designed to reduce the risk
of thrown objects. The mower deck and pro-
tective devices cannot prevent all objects
from escaping the blade enclosure in every
mowing condition. It is possible for objects
to ricochet and escape, traveling as much as
300 feet (92 m).
■Never allow riders on power unit or attachment.
■Make sure spring-activated locking pin or collar
slides freely and is seated rmly in tractor PTO
spline groove.
■Operate tractor PTO at 540 RPM. Do not exceed.
■Do not allow bystanders within 25 feet of the
area when operating, attaching, removing, as-
sembling, maintaining, or servicing equipment.
■Stop power unit and equipment immediately
upon striking an obstruction. Turn off engine,
set parking brake, remove key, inspect, and re-
pair any damage before resuming operation.
■Always wear relatively tight and belted clothing
to avoid getting caught in moving parts. Wear
sturdy, rough-soled work shoes and protec-
tive equipment for eyes, hair, hands, hearing,
and head; and respirator or lter mask where
appropriate.
■Safety tow chain must be hooked-up to both the
implement and tractor during operation or trans-
port. A loose, dragging chain could be struck by
the blades causing serious injury.
TRACTOR STABILITY
■A minimum 20% of tractor and equipment weight
must be on the tractor front wheels when attach-
ments are in transport position. Without this
weight, tractor could tip over, causing personal
injury or death. The weight may be attained with
front wheel weights, ballast in tires or front trac-
tor weights. Weigh the tractor and equipment.
Do not estimate.
Figure 1. Tractor Stability
CONNECT CUTTER TO TRACTOR
(PULL-TYPE)
■The horizontal distance between the end of the
tractor PTO shaft and the drawbar hitch point
should be 14" for 540 RPM cutters. This dis-
tance must not vary more than plus or minus
(1") or the drive may be damaged when turning.
1. Adjust tractor drawbar to obtain the desired drawbar
hitch point distance.
NOTE: On some tractors, a drawbar kit must be
used to obtain the required dimension. Check with
your tractor dealer for assistance.
2. Attach parking jack to cutter tongue. Raise tongue
to tractor drawbar height.
3. Secure cutter to tractor using a 3/4" clevis pin and
clip for category 1, or 1-1/8" clevis pin and clip for
category 2.
4. Attach safety tow chain to drawbar support. Leave
enough slack for turning.
5. Connect cutter driveline to tractor PTO shaft, mak-
ing sure the spring-activated lock pin slides freely
and is seated in tractor PTO splined groove.
6. Remove parking jack from the tongue and attach it
to the storage post on the front of the cutter.
DANGER
WARNING
CAUTION
WARNING
CD1564-2
NOTICE

14 Operation MAN1167
(07/25/2023)
Hydraulic Connection
1. Inspect hydraulic hoses to ensure they are in good
condition.
2. Clean the ttings before connecting them to the
tractor hydraulic ports.
3. Attach the hydraulic hose to the tractor.
4. Route the hose through the hose holder at the hitch
and be sure the hose can slide freely in the holder.
Do not allow hose slack to drag on the ground or
become caught on tractor protrusions.
5. From the operator position, start tractor and raise
and lower deck several times to purge trapped air
from the hydraulic cylinder.
Interference Check
1. Be sure that tractor 3-point lift links do not inter-
fere with hydraulic hoses, cutter driveline, or cutter
frame.
2. Check for straight-ahead operation and at full-
turning angles. If there is any interference, remove
the lower lift links.
3. Contact between tractor lift links and cutter parts
can cause damage, especially when turning.
CV Driveline Turning Limits
■You must not exceed a turning angle of 80 de-
grees at the head of the Constant Velocity
driveline or damage will occur.
To check for potential excessive turn angle:
1. Disconnect driveline from tractor, start engine and
turn as far right or left as possible.
2. Shut engine off, set parking brake, remove key, and
try to connect CV driveline to tractor. If it cannot be
connected, the angle is too severe.
3. Restart engine and straighten angle slightly. Repeat
step 2 until driveline can be connected. The point at
which the driveline can be connected is the maxi-
mum turn that should be made.
CONNECT CUTTER TO TRACTOR
(MOUNTED)
■A minimum 20% of tractor and equipment
weight must be on the tractor front wheels when
attachments are in transport position. Without
this weight, front tractor wheels could raise up
resulting in loss of steering. The weight may
be attained with front wheel weights, ballast in
tires, front tractor weights or front loader. Weigh
the tractor and equipment. Do not estimate.
Tractor Adjustments
Before attaching tractor to cutter, install sway blocks or
sway chains, or adjust stabilizer bars. Refer to the trac-
tor operator’s manual for instructions.
Install tractor front end weights as recommended by
the tractor manufacturer to provide 20% of weight on
front wheels.
DS8.30 Category 1 Standard Hitch
1. Position tractor lower lift arms between hitch mast
plates.
2. Insert lower hitch pins (1) through mast plates and
tractor lower lift arms. Use sleeves (2) to keep lift
arms in position. Secure with 7/16" klik pins (4).
3. Connect the tractor top link to the cutter A-frame
using the middle holes and 3/4" pin (5), cotter pin
(6), and 1/4" klik pin (7). See Figure 2.
DS8.30 Category 2 Standard Hitch
1. Position tractor lower lift arms between hitch mast
plates.
2. Insert lower hitch pins (1) and 1-1/8" OD sleeves (2)
through mast plates and tractor lower lift arms. Use
sleeves (3) to keep lift arms in position. Secure with
7/16" klik pin (4).
3. Connect the tractor top link to the cutter A-frame
using the top holes and 1" pin supplied with tractor
top link. See Figure 2.
DS8.30 Category 1 & 2 Quick Hitch
1. Insert lower hitch pins (1), 1-1/8" OD sleeves (2),
and 1-7/16" OD sleeves (3) through mast plates.
Secure with 7/16" klik pins (4). Note the sleeve ori-
entation in Figure 2.
2. The upper hook on quick hitch will engage 1-1/4"
sleeve (8) between break links (9).
3. Attach tractor to cutter and secure hitch according
to hitch manufacturer’s instructions.
NOTICE
WARNING

Operation 15
MAN1167
(07/25/2023)
Figure 2. DS8.30 Standard and
Quick Hitch Connection
DS10.40 Category 2 Standard Hitch
1. Position tractor lower lift arms between hitch mast
plates.
2. Insert lower hitch pins (1) to Position B, Figure 3,
through mast plates and tractor lower lift arms.
3. Secure with klik pins (2).
4. Connect the tractor top link to the cutter A-frame
using the middle holes and 3/4" pin (3), 1" OD
sleeve (4),cotter pin (5), and 1/4" klik pin (6).
DS10.40 Category 3 Standard Hitch
1. Position tractor lower lift arms between hitch mast
plates.
2. Insert lower hitch pins (1) to Position A, Figure 3.
3. Secure with klik pins (2).
4. Connect the tractor top link to the cutter A-frame
using top holes and 3/4" pin (3), 1-1/4" OD sleeve
(not shown), cotter pin (5), and 1/4" klik pin (6).
DS10.40 Category 2 & 3 Quick Hitches
1. Position lower hitch pins (1) to Position A, Figure 3.
2. The upper hook on the quick hitch will engage the
1-1/4" sleeve (7) between break links (8) as shown
for Category 2. Break links and sleeve will need to
be moved up to the middle hole of the A-frame for
Category 3.
3. Attach tractor to cutter and secure hitch according
to hitch manufacturer’s instructions.
Figure 3. DS10.40 Standard and
Quick Hitch Connection
DRIVELINE ADJUSTMENT
(MOUNTED DS8.30 & DS10.40)
Attach the cutter to the tractor 3-point hitch (or quick
hitch if available). Do not attach driveline at this time.
■If attaching cutter using a Quick Hitch the dis-
tance between the tractor PTO and the gearbox
input shaft will increase. Follow steps as you
would for the 3-point hitch to insure proper
engagement.
Raise and lower cutter and measure the maximum and
minimum distance between the tractor PTO shaft and
the gearbox input shaft. Separate the driveline into two
halves and lay them side-by-side with U-joints at oppo-
site ends.
Set the two u-joints at the maximum distance mea-
sures (this is the cutters lowest point of operation) and
check the amount of overlap between the two drive
halves. There must be at least 4 inches of overlap. If
the driveline is too short (less than 4" overlap) contact
your Woods dealer for a longer drive.
Set the two U-joints to the minimum distance measured
(this is the cutters highest point) and check to see if the
driveline bottoms out. If driveline is too long follow the
instructions to shortening the drive.
NOTICE
1
1
1
CATEGORY 1
QUICK HITCH
CATEGORY 2
QUICK HITCH
2
2
2
3
3
4
4
5
6
7
8
9
CD8641
1
POSITION “B”
1
POSITION “A”
2
2
34
56
7
8
CD8642

16 Operation MAN1167
(07/25/2023)
Figure 4. 4 Inch Minimum Overlap
Shortening Driveline
1. Separate driveline into two halves and connect
them to the tractor PTO and gearbox.
2. Place driveline halves parallel to one another to de-
termine how much to shorten the driveline.
Figure 5. Drive Halves Placed Parallel
3. Measure from end of the upper shield to the base of
the bell on the lower shield (A). Add 1-9/16" to di-
mension (A). See Figure 6.
Figure 6. Determine Shield Length
4. Cut the shield to the overall dimension.
Figure 7. Cut Shield
5. Place the cutoff portion of the shield against the end
of the shaft and use it as a guide. Mark and cut the
shaft.
Figure 8. Cut Shaft to Length
6. Repeat step 5 for other half of drive.
7. File and clean ends of both drive halves.
Driveline Interference Check
1. Check for proper clearance between driveline and
mower deck.
2. Slowly lift mower and observe driveline. If clearance
between driveline and mower deck is less than 1
inch, shorten top link or limit upper travel of lower
hitch arms. Refer to tractor operator’s manual for
instructions.
A
1-9/16"
4"
CD7155-1
Maximum Distance Between
Tractor PTO Shaft and
Gearbox Input Shaft

Operation 17
MAN1167
(07/25/2023)
CUTTING HEIGHT ADJUSTMENT
■Avoid ground contact with blades. Striking
ground with blades produces one of the most
damaging shock loads a cutter can encounter. If
this occurs repeatedly, the cutter, driveline, and
gearboxes will be damaged.
Cutting height range is from 2" to 12".
When selecting a cutting height, you should consider
the area of operation. If the ground is rolling and has
mounds the blades could contact, set the cutting height
accordingly.
Pull-Type Units
To adjust cutter for normal mowing, select a cutting
height (example: 4 inches). Blades are approximately
1-3/4" above bottom of cutter. Dimension A plus 1-1/4"
equals the cutting height.
Using hydraulic cylinder, raise or lower the tailwheel
and set position A to 2-3/4 inches to achieve a 4" cut-
ting height.
Loosen the jam nut on the attitude rod that runs from
the tongue to the tailwheel. Adjust rod in or out until
position B is approximately 1/4 to 1/2 inches more than
position A. Refer to Figure 9.
Figure 9. Cutting Height Adjustment
Mounted Units
To adjust cutter for normal mowing, select a cutting
height (example: 4"). Blades are approximately 1-1/4"
above the bottom of cutter. Dimension A plus 1-1/4"
equals cutting height.
Adjust tractor 3-point hitch to obtain a distance of 2-3/4
inches at position “A” to obtain a 4" cutting height. See
Figure 9.
Adjust the position of the tailwheel arms between the
tailwheel height adjustment brackets to obtain a dis-
tance greater than 2-3/4" at position “B”
Adjust top link to provide 1-1/2" of clearance between
the break link (2) and the rear lift links. See Figure 9.
This clearance will allow the cutter to oat over uneven
terrain.
ATTITUDE ADJUSTMENT
(PULL-TYPE)
Normal Mowing
For the most economical power use and best cutting
results, the cutter should be from 1/2" to 3/4" higher at
the rear than at the front.
For grass and weed mowing, adjust cutter to run level
or with the front slightly lower.
Shredding
For shredding, it is better to set rear of cutter slight-
ly lower than the front. How much lower depends on
the material to be shredded. Determine the best setting
for your situation by experimenting. Use a slow ground
speed for better shredding.
BLADE SELECTION
There are two blade options: standard suction blades
and at double-edge blades.
The standard suction blade is a general use, multi-
purpose blade.
The double-edge blade requires less power because it
does not mulch or recut material. It is designed for use
in areas where blade wear is a problem. Sandy soils
are extremely hard on blades.
Blade rotation, viewed from top of cutter, is clockwise
for the right crossbar, and counter-clockwise for the left
crossbar.
When one cutting surface of a double-edge blade is
worn, the opposite one may be used by placing the
blade on a crossbar of the opposite rotation. Blades
from the right may be used on the left. Blades from the
left may be used on the right.
Blades must be moved in pairs. Never use one new
blade and one used blade on a crossbar.
NOTICE
A
B
1.5
32
1
4
SIDE SKIDS
5
6
GROUND
CD8643
1. Tractor Lower Link
Attachment Point
2. Tractor Top Link
Attachment Point
3. Break Link
4. Lift Arms
5. Tailwheel Height
Adjustment Arms
6. Tailwheel Arms

18 Operation MAN1167
(07/25/2023)
TRACTOR OPERATION
Use care when operating around tree limbs and other
low objects.
Use care and reduce ground speed on rough terrain.
Always watch for hidden hazards.
Being knocked off or falling off tractor can result in seri-
ous injury or death.
Only use a tractor with a Roll Over Protective Structure
(ROPS) and seat belt. Securely fasten seat belt before
starting tractor.
The cutter is operated with tractor controls. Engage the
PTO at a low rpm to prevent excessive loads on the
cutter drive system. Increase throttle to proper PTO
speed (540 rpm).
Be sure operator is familiar with all controls and can
stop tractor and cutter quickly in an emergency. The
operator should give complete, undivided attention to
operating tractor and cutter.
OPERATING TECHNIQUE
Power for operating the cutter is supplied by the tractor
PTO. Operate PTO at 540 rpm. Know how to stop the
tractor and cutter quickly in an emergency.
Engage PTO at a low engine rpm to minimize stress
on the drive system and gearbox. With PTO engaged,
raise PTO speed to 540 rpm and maintain throughout
cutting operation.
Gearbox protection is provided by a slip clutch with re-
placement ber disc. The slip clutch is designed to slip
when excessive torsional loads occur.
Move slowly into material. Adjust tractor ground speed
to provide a clean cut without lugging the tractor en-
gine. Use a slow ground speed for better shredding.
Proper ground speed will depend on the terrain and the
material’s height, type, and density.
Normally, ground speed will range from 2 to 5 mph.
Tall, dense material should be cut at a low speed; thin,
medium-height material can be cut at a faster ground
speed.
Always operate tractor PTO at 540 rpm to maintain
blade speed and to produce a clean cut.
Under certain conditions tractor tires may roll down
some grass and prevent cutting at the same height as
the surrounding area. When this occurs, reduce your
ground speed but maintain PTO at 540 rpm. The lower
ground speed will permit grass to rebound partially.
Cutter Operation
When beginning operation of the cutter, make sure that
all persons are in a safe location. Slowly move into the
material with the tractor PTO set at 540 rpm.
Mowing Tips
■Look down and to the rear and make sure area is
clear before operating in reverse.
■Do not operate or transport on steep slopes.
■Do not stop, start, or change directions sudden-
ly on slopes.
■Use extreme care and reduce ground speed on
slopes and rough terrain.
■Watch for hidden hazards on the terrain during
operation.
■Stop power unit and equipment immediately
upon striking an obstruction. Turn off engine,
remove key, inspect, and repair any damage be-
fore resuming operation.
Maximum recommended ground speed for cutting or
shredding is 6 miles per hour. Adjust tractor ground
speed by using higher or lower gears to provide a clean
cut without lugging tractor engine.
Tall material should be cut twice. Cut material higher
the rst pass. Cut at desired height at 90 degrees the
second pass.
Remember, sharp blades produce cleaner cuts and
use less power.
Before entering an area, analyze it to determine the
best procedure. Consider the height and type of mate-
rial to be cut and the terrain type (hilly, level or rough,
etc.).
WARNING
CAUTION

Operation 19
MAN1167
(07/25/2023)
TRANSPORTING
■The maximum transport speed for towed and
semi-mounted machines is 20 mph (32 km/h).
Regardless of the maximum speed capability
of the towing tractor, do not exceed the imple-
ment’s maximum transport speed. Doing so
could result in:
• Loss of control of the implement and tractor
• Reduced or no ability to stop during braking
• Implement tire failure
• Damage to the implement or its components.
■Use additional caution and reduce speed when
under adverse surface conditions, turning, or
on inclines.
■Never tow this implement with a motor vehicle.
1. Always transport with cutter in raised, locked
position.
2. Raise cutter with hydraulic cylinder.
3. Rotate transport lock over cylinder rod.
4. Lower cylinder against transport lock.
5. To lower cutter for operation, extend hydraulic cylin-
der. Rotate transport lock back away from cylinder
rod. Lower to desired cutting height.
Figure 10. Transport Lock Operation
STORAGE
■Keep children, bystanders and animals away
from the equipment and the storage area.
ON MOUNTED CUTTERS:
■Disconnect cutter driveshaft and secure up off
ground. Raise cutter with 3-point hitch. Place
blocks under cutter side skids. Lower cutter
onto blocks. Disconnect hydraulic lines to op-
tional cylinder. Disconnect cutter from tractor
3-point hitch and carefully drive tractor away
from cutter.
ON PULL-TYPE CUTTERS:
■Raise cutter and block securely. Block wheels
and raise tongue with jack. Disconnect hydraulic
lines to optional cylinder. Disconnect driveline
and secure up off the ground.
PRE-OPERATION CHECKLIST
(OWNER’S RESPONSIBILITY)
Review and follow all safety rules and safety de-
cal instructions on pages 7 through 12.
Check that all safety decals are installed and in
good condition. Replace if damaged.
Check that equipment is properly and securely
attached to tractor.
Make sure driveline spring-activated locking pin
or collar slides freely and is seated rmly in trac-
tor PTO spline groove.
Set tractor PTO at correct rpm for your
equipment.
Lubricate all grease tting locations. Make sure
PTO shaft slip joint is lubricated.
Check that all hydraulic hoses and ttings are in
good condition and not leaking before starting
tractor. Check that hoses are not twisted, bent
sharply, kinked, frayed, or pulled tight. Replace
any damaged hoses immediately.
Raise and lower equipment to make sure air is
purged from hydraulic cylinders and hoses.
Check that all hardware is properly installed and
secured.
Check to ensure blades are sharp, in good condi-
tion, and installed correctly. Replace if damaged.
Make sure tractor ROPS or ROPS cab and seat
belt are in good condition. Keep seat belt secure-
ly fastened during operation.
Check that shields and guards are proper-
ly installed and in good condition. Replace if
damaged.
Check cutting height, front-to-rear attitude, and
top link adjustment.
Before starting engine, operator must be in
tractor seat with seat belt fastened. Place trans-
mission in neutral or park, engage brake and
disengage tractor PTO.
Inspect area to be cut and remove stones,
branches, or other hard objects that might be
thrown and cause injury or damage.
Check that belt or chain shielding is in good con-
dition and replace any damaged parts.
Make sure tractor 3-point lift links do not interfere
with hydraulic hoses or driveline throughout full
turning range.
WARNING
WARNING

20 Owner Service MAN1167
(07/25/2023)
OWNER SERVICE
The information in this section is written for operators
who possess basic mechanical skills. If you need help,
your dealer has trained service technicians available.
For your protection, read and follow the safety informa-
tion in this manual.
■Keep all persons away from operator control
area while performing adjustments, service, or
maintenance.
■If you do not understand any part of this manual
and need assistance, see your dealer.
■Always wear relatively tight and belted clothing
to avoid entanglement in moving parts. Wear
sturdy, rough-soled work shoes and protec-
tive equipment for eyes, hair, hands, hearing,
and head; and respirator or lter mask where
appropriate.
BLOCKING METHOD
■Never go underneath equipment (lowered to the
ground or raised) unless it is properly blocked
and secured. Never place any part of the body
underneath equipment or between moveable
parts even when the engine has been turned off.
Hydraulic system leak down, hydraulic system
failures, mechanical failures, or movement of
control levers can cause equipment to drop or
rotate unexpectedly and cause severe injury or
death. Follow Operator’s Manual instructions
for working underneath and blocking require-
ments or have work done by a qualied dealer.
To minimize the potential hazards or working under-
neath the cutter, follow these procedures:
1. Jackstands with a load rating of 1000 lbs. or more
are the only approved blocking device for this cutter.
Install jackstands (shown by Xs in Figure 11) under
the cutter before working underneath unit.
Do not position jackstands under wheels, axles, or
wheel supports. Components can rotate and cause
cutter to fall.
2. Consider the overall stability of the blocked unit.
Just placing jackstands underneath will not ensure
your safety.
The working surface must be level and solid to
support the weight on the jackstands. Make sure
jackstands are stable, both top and bottom. Make
sure cutter is approximately level.
3. With full cutter weight lowered onto jackstands, test
blocking stability before working underneath.
4. If cutter is attached to tractor when blocking, set the
brakes, remove key, and block cutter before work-
ing underneath.
5. Securely block rear tractor wheels, in front and be-
hind. Tighten tractor lower 3-point arm anti-sway
mechanism to prevent side-to-side movement.
LUBRICATION
Do not let excess grease collect on or around parts,
particularly when operating in sandy areas.
See Figure 11 for lubrication points and frequency
or lubrication based on normal operating conditions.
Severe or unusual conditions may require more fre-
quent lubrication.
Use a lithium grease of #2 consistency with a MOLY
(molybdenum disulde) additive for all locations unless
otherwise noted. Be sure to clean ttings thorough-
ly before attaching grease gun. One good pump of
most guns is sufcient when the lubrication schedule
is followed.
Gearbox Lubrication
1. For gearbox, use a high quality gear oil with a vis-
cosity index of 80W or 90W and an API service
rating of GL–4 or –5 in gearboxes.
2. Fill gearbox until oil is above lower line on dipstick.
Check gearbox daily for evidence of leakage, and
contact your dealer if leakage occurs.
Driveline Lubrication
1. Lubricate the driveline slip joint every ten operating
hours. Failure to maintain proper lubrication could
result in damage to U-joints, gearbox, and driveline.
2. Lower cutter to ground, disconnect driveline from
tractor PTO shaft, and slide halves apart but do not
disconnect from each other.
3. Apply a bead of grease completely around male half
where it meets female half. Slide drive halves over
each other several times to distribute grease.
4. Grease side drive yoke where yoke attaches to side
gearbox.
WARNING
CAUTION
WARNING
