Woods TSG50 User manual

OPERATOR'S MANUALOPERATOR'S MANUAL (Rev 03/15/2023)
MAN0495
STUMP GRINDER
TSG50
MAN0495_2023-03.indd 1MAN0495_2023-03.indd 1 4/17/23 2:58 PM4/17/23 2:58 PM

2 Introduction MAN0495
(03/15/23)
TO THE DEALER:
Assembly and proper installation of this product is the responsibility of the Woods®dealer. Read manual instructions
and safety rules. Make sure all items on the Dealer’s Pre-Delivery and Delivery Checklists in the Operator’s Manual are
completed before releasing equipment to the owner.
The dealer must complete the online Product Registration form at the Woods Dealer Website which certies that
all Dealer Checklist items have been completed. Dealers can register all Woods product at dealer.WoodsEquipment.com
under Product Registration.
Failure to register the product does not diminish customer’s warranty rights.
TO THE OWNER:
Read this manual before operating your Woods equipment. The information presented will prepare you to do a better
and safer job. Keep this manual handy for ready reference. Require all operators to read this manual carefully and be-
come acquainted with all adjustment and operating procedures before attempting to operate. Replacement manuals can
be obtained from your dealer. To locate your nearest dealer, check the Dealer Locator at www.WoodsEquipment.com,
or in the United States and Canada call 1-800-319-6637.
The equipment you have purchased has been carefully engineered and manufactured to provide dependable and sat-
isfactory use. Like all mechanical products, it will require cleaning and upkeep. Lubricate the unit as specied. Observe
all safety information in this manual and safety decals on the equipment.
For service, your authorized Woods dealer has trained mechanics, genuine Woods service parts, and the necessary
tools and equipment to handle all your needs.
Use only genuine Woods service parts. Substitute parts will void the warranty and may not meet standards required
for safe and satisfactory operation. Record the model number and serial number of your equipment in the spaces
provided:
Model: Date of Purchase:
Serial Number: (see Safety Decal section for location)
Provide this information to your dealer to obtain correct repair parts.
Throughout this manual, the term NOTICE is used to indicate that failure to observe can cause damage to equipment.
The terms CAUTION, WARNING, and DANGER are used in conjunction with the Safety-Alert Symbol (a triangle with
an exclamation mark) to indicate the degree of hazard for items of personal safety.
This is the safety alert symbol. It is used to alert you to potential physical
injury hazards. Obey all safety messages that follow this symbol to avoid
possible injury or death.
Indicates a hazardous situation that, if not avoided, will result in death or
serious injury.
Indicates a hazardous situation that, if not avoided, could result in death
or serious injury.
Indicates a hazardous situation that, if not avoided, could result in minor
or moderate injury.
Is used to address practices not related to physical injury.
Indicates helpful information.
DANGER
WARNING
CAUTION
or NOTICE
IMPORTANT
NOTE
MAN0495_2023-03.indd 2MAN0495_2023-03.indd 2 4/17/23 2:58 PM4/17/23 2:58 PM

Introduction 3
MAN0495
(03/15/23)
This Operator’s Manual should be regarded as part of the machine.
Suppliers of both new and second-hand machines must make sure
that this manual is provided with the machine.
¡LEA EL INSTRUCTIVO!
Si no lee Ingles, pida ayuda a
alguien que si lo lee para que le
traduzca las medidas de seguridad.
TABLE OF CONTENTS
INTRODUCTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
GENERAL INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
SAFETY RULES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
TRAINING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
PREPARATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
MAINTENANCE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
STORAGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
SAFETY & INSTRUCTIONAL DECALS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
STUMP GRINDER PREPARATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
ATTACH STUMP GRINDER TO TRACTOR . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
TRACTOR STABILITY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
OPERATING TECHNIQUE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
STUMP GRINDER STORAGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
CLEANING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
PRE-OPERATION CHECKLIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
OWNER SERVICE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
LUBRICATION INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
STUMP GRINDER TOOTH REPLACEMENT . . . . . . . . . . . . . . . . . . . . . . . . . 13
SLIP CLUTCH ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
DEALER SERVICE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
GEARBOX MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
SEAL REPAIR. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
GEARBOX REPAIR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
CYLINDER SERVICE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
LIFT CYLINDER REPAIR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
SWING CYLINDER REPAIR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
UNIVERSAL JOINT REPAIR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
DEALER SET-UP INSTRUCTIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
DRIVELINE INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
OPTIONAL EQUIPMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
DRIVELINE INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
DEALER CHECKLISTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
PARTS INDEX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
INDEX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
APPENDIX. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
BOLT TORQUE CHART . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
BOLT SIZE CHART . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
ABBREVIATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
PRODUCT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
REPLACEMENT PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
MAN0495_2023-03.indd 3MAN0495_2023-03.indd 3 4/17/23 2:58 PM4/17/23 2:58 PM

4 Introduction MAN0495
(03/15/23)
TSG50 SPECIFICATIONS
3-Point hitch Category 1 or Category 2
Weight 540 lbs
Cutting wheel diameter 20 inches
Speed of wheel 1037 rpm
Cutting speed 5428 ft/min
Required horsepower 15 to 50 HP
Cutting teeth 24 carbide steel teeth
Maximum stump height 16 inches
Maximum cutting depth 16 inches
Horizontal cut 32 inches
Hub torque
15 HP 76 lbs-ft
50 HP 253 lbs-ft
Force @ tooth tip
15 HP 91 lbs
50 HP 304 lbs
GENERAL INFORMATION
The purpose of this manual is to assist you in operating
and maintaining your grinder. Read it carefully. It fur-
nishes information and instructions that will help you
achieve years of dependable performance. These in-
structions have been compiled from extensive eld
experience and engineering data. Some information
may be general in nature, due to unknown and varying
operating conditions. However, through experience
and these instructions, you should be able to develop
procedures suitable to your particular situation.
■Some illustrations in this manual show the
grinder with safety shields removed to provide
a better view. The equipment should never be
operated with any safety shielding removed.
The illustrations and data used in this manual were
current at the time of printing. However, due to possi-
ble inline production changes, your machine may vary
slightly in detail. We reserve the right to redesign and
change the machines as may be necessary without
notication.
Throughout this manual, references are made to right
and left directions. These are determined from the op-
erator’s position in the tractor seat.
WARNING
MAN0495_2023-03.indd 4MAN0495_2023-03.indd 4 4/17/23 2:58 PM4/17/23 2:58 PM

Safety 5
MAN0495
(03/15/23)
TRAINING
■Safety instructions are important! Read all at-
tachment and power unit manuals; follow
all safety rules and safety decal information.
(Replacement manuals and safety decals are
available from your dealer. To locate your
nearest dealer, check the Dealer Locator at
www.WoodsEquipment.com, or in the United
States and Canada call 1-800-319-6637.) Failure
to follow instructions or safety rules can result in
serious injury or death.
■If you do not understand any part of this manual
and need assistance, see your dealer.
■Know your controls and how to stop engine and
attachment quickly in an emergency.
■Operators must be instructed in and be capa-
ble of the safe operation of the equipment, its
attachments, and all controls. Do not allow any-
one to operate this equipment without proper
instructions.
■Keep hands and body away from pressurized
lines. Use paper or cardboard, not hands or
other body parts to check for leaks. Wear safe-
ty goggles. Hydraulic uid under pressure can
easily penetrate skin and will cause serious in-
jury or death.
■Make sure that all operating and service person-
nel know that if hydraulic uid penetrates skin,
it must be surgically removed as soon as possi-
ble by a doctor familiar with this form of injury
or gangrene, serious injury, or death will result.
CONTACT A PHYSICIAN IMMEDIATELY IF FLUID
ENTERS SKIN OR EYES. DO NOT DELAY.
PREPARATION
■Check that all hardware is properly installed.
Always tighten to torque chart specications
unless instructed otherwise in this manual.
■Always wear relatively tight and belted clothing
to avoid entanglement in moving parts. Wear
sturdy, rough-soled work shoes and protec-
tive equipment for eyes, hair, hands, hearing,
and head; and respirator or lter mask where
appropriate.
■Make sure attachment is properly secured, ad-
justed, and in good operating condition.
■Power unit must be equipped with ROPS or
ROPS cab and seat belt. Keep seat belt secure-
ly fastened. Falling off power unit can result in
death from being run over or crushed. Keep
foldable ROPS systems in “locked up” position
at all times.
■Make sure all safety decals are installed.
Replace if damaged. (See Safety Decals section
for location.)
■Make sure shields and guards are proper-
ly installed and in good condition. Replace if
damaged.
OPERATION
■Do not allow bystanders within 25 feet of the
area when operating, attaching, removing, as-
sembling, maintaining, or servicing equipment.
■Consult local utilities before working. Know
location of all underground cables, pipelines,
overhead wires, and other hazards in working
area and avoid contact.
■Do not put stump grinder into service unless
all shields and guards are in place and in good
condition. Replace if damaged.
■Keep bystanders at least 100 feet away from
equipment.
■Do not operate or transport equipment while
under the inuence of alcohol or drugs.
■ Operate only in daylight or good articial light.
■Avoid contact with electrical wires.
■Keep hands, feet, hair, and clothing away from
equipment while engine is running. Stay clear of
all moving parts.
■Always comply with all state and local lighting
and marking requirements.
■Never allow riders on power unit or attachment.
Safety is a primary concern in the design and man-
ufacture of our products. Unfortunately, our efforts
to provide safe equipment can be wiped out by an
operator’s single careless act.
In addition to the design and conguration of
equipment, hazard control and accident preven-
tion are dependent upon the awareness, concern,
judgement, and proper training of personnel in-
volved in the operation, transport, maintenance
and storage of equipment.
It has been said “The best safety device is an in-
formed, careful operator.” We ask you to be that
kind of operator.
SAFETY RULES
ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED!
MAN0495_2023-03.indd 5MAN0495_2023-03.indd 5 4/17/23 2:58 PM4/17/23 2:58 PM

6 Safety MAN0495
(03/15/23)
■Power unit must be equipped with Roll Over
Protection System (ROPS) or ROPS cab and
seat belt. Keep seat belt securely fastened.
Falling off power unit can result in death from
being run over or crushed. Keep foldable ROPS
system in “locked up” position at all times.
■Always sit in power unit seat when operating
controls or starting engine. Securely fasten
seat belt, place transmission in neutral, engage
brake, and ensure all other controls are disen-
gaged before starting power unit engine.
■Shift tractor transmission into park or neu-
tral and set brakes before engaging PTO and
grinding.
■Do not operate PTO during transport.
■Connect PTO driveline directly to power unit
PTO shaft. Never use adapter sleeves or adapt-
er shafts. Adapters can cause driveline failures
due to incorrect spline or incorrect operating
length and can result in personal injury or death.
■Do not operate auxiliary hydraulics during
transport.
■Look down and to the rear and make sure area is
clear before traveling in reverse.
■Use extreme care when working close to fences,
ditches, other obstructions, or on hillsides.
■Do not operate or transport on steep slopes.
■Do not stop, start, or change directions sudden-
ly on slopes.
■Use extreme care and reduce ground speed on
slopes and rough terrain.
MAINTENANCE
■Service and maintenance work not covered in
OWNER SERVICE must be done by a qualied
dealership. Special skills, tools, and safety pro-
cedures may be required. Failure to follow these
instructions can result in serious injury or death.
■Before performing any service or maintenance,
disconnect driveline from tractor PTO.
■Do not modify or alter or permit anyone else to
modify or alter the equipment or any of its com-
ponents in any way.
■Always wear relatively tight and belted clothing
to avoid getting caught in moving parts. Wear
sturdy, rough-soled work shoes and protec-
tive equipment for eyes, hair, hands, hearing,
and head; and respirator or lter mask where
appropriate.
■Do not allow bystanders within 25 feet of the
area when operating, attaching, removing, as-
sembling, maintaining, or servicing equipment.
■Make sure attachment is properly secured, ad-
justed, and in good operating condition.
■Never perform cleaning, service or maintenance
with engine running.
■Keep all persons away from operator control
area while performing adjustments, service, or
maintenance.
■Tighten all bolts, nuts, and screws to torque
chart specications. Check that all cotter pins
are installed securely to ensure equipment is in
a safe condition before putting unit into service.
■Make sure shields and guards are proper-
ly installed and in good condition. Replace if
damaged.
■When lubricating telescoping PTO drives, keep
ngers out of shield access slots to prevent
injury.
STORAGE
■Do not climb or lean on equipment stored on
stand.
■Keep children, bystanders and animals away
from equipment and storage area.
SAFETY RULES
ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED!
MAN0495_2023-03.indd 6MAN0495_2023-03.indd 6 4/17/23 2:58 PM4/17/23 2:58 PM

Safety 7
MAN0495
(03/15/23)
4
10
1
2
5
1
23
3
7
8
6
9
CD7026
SAFETY & INSTRUCTIONAL DECALS
ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED!
Replace Immediately If Damaged!
3 - PN 18869
1 - PN 1018364
2 - PN 1018365
4 - PN 1004114
If shaft connection is visible, shield
is missing. Replace shield before
operating equipment.
DANGER
1004114
BE CAREFUL!
Keep safety decals clean and visible.
Use a clean, damp cloth to clean safety decals.
Avoid spraying too close to decals when using a pressure washer; high-pressure water can enter
through very small scratches or under edges of decals causing them to peel or come off.
Replace safety decals if they are missing or illegible.
Replacement safety decals can be ordered free from your Woods dealer. To locate your near-
est dealer, check the Dealer Locator at www.WoodsEquipment.com, or in the United States and
Canada call 1-800-319-6637.
KEEP AWAY!
FLYING DEBRIS
FROM CUTTING
WHEEL
Thrown objects can
cause serious injury
or death. 1018364
4.75"W x 2.38"H
incl .125 White
Border 4 Sides
DECAL 1018364
CTGY 3006
DCL, DNGR, SG THROWN OBJECT
11/9/05 CAW
DANGER
KEEP AWAY!
nOperate from tractor
seat only.
n Keep others away from
stump grinder while in
operation.
Contact will cause
serious injury or death.
DANGER
5.0"W x 3.25"H
incl .125 White
Border 4 Sides
DECAL 1018365
CTGY 3006
DCL, DNGR, SG CONTACT
11/9/05 CAW
1018365
MAN0495_2023-03.indd 7MAN0495_2023-03.indd 7 4/17/23 2:58 PM4/17/23 2:58 PM

8 Safety MAN0495
(03/15/23)
SAFETY & INSTRUCTIONAL DECALS
ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED!
Replace Immediately If Damaged!
DO NOT EXCEED PTO SPEED OF
WARNING
18866
n PTO speeds higher than 540 RPM can cause equipment
failure and personal injury.
540
n Tractor PTO master shield, PTO drive shaft guarding
and PIC guards are to be kept in place.
3 - Serial Number Plate
6 - PN 18866 10 - PN 33347
5 - PN W19924 7 - PN 1021070
9 - PN 18864
14.62"H x 2.75"W
DECAL 1021070 (Ref 1004620)
CTGY 3004
DCL, WRNG, SAFETY RULES
4/7/06 CAW
CRUSHING AND
PINCHING HAZARD
Handle machine parts
carefully. Body parts could
be crushed or pinched
between tractor and
implement.
 Operate tractor controls
from tractor seat only.
 Do not stand between
tractor and implement
when tractor is in gear.
Make sure parking brake is
engaged before going
between tractor and
implement.
Stand clear of machine
while in operation or when
it is being raised or
lowered.
TO AVOID SERIOUS
INJURY OR DEATH:
Read Operator's Manual
before operating, servicing,
or repairing equipment.
Follow all safety rules and
instructions. (Manuals are
available from dealer or
call 1-800-319-6637.)
Lower equipment to
ground, stop engine,
remove key, and set brake
before dismounting
tractor.
Never allow children or
untrained persons to
operate equipment.
Never allow riders.
Keep bystanders away
from equipment during
operation.
Keep all shields in place
and in good condition.
FALLING OFF CAN RESULT
IN BEING RUN OVER.
 Tractor must be equipped
with ROPS (or ROPS CAB)
and seat belt. Keep foldable
ROPS systems in "locked
up" position at all times.
 Buckle Up! Keep seat belt
securely fastened.
FAILURE TO FOLLOW
THESE INSTRUCTIONS
CAN RESULT IN SERIOUS
INJURY OR DEATH.
WARNING
WARNING
WARNING
1021070
DANGER
GUARD MISSING.
DO NOT OPERATE.
33347
DANGER
DANGER
GUARD MISSING.
DO NOT OPERATE.
MAN0495_2023-03.indd 8MAN0495_2023-03.indd 8 4/17/23 2:58 PM4/17/23 2:58 PM

Operation 9
MAN0495
(03/15/23)
OPERATION
The operator is responsible for the safe operation of
the grinder. The operator must be properly trained.
Operators should be familiar with the grinder, the trac-
tor, and all safety practices before starting operation.
Read the Safety Rules and Safety Decals on page 5
through page 8.
■Do not allow bystanders in the area when op-
erating, attaching, removing, assembling, or
servicing equipment.
■Keep bystanders at least 100 feet away from
equipment.
Figure 1. 100 ft. Hazard Zone
■Do not put stump grinder into service unless
all shields and guards are in place and in good
condition. Replace if damaged.
■Keep hands and body away from pressurized
lines. Use paper or cardboard, not hands or
other body parts to check for leaks. Wear safe-
ty goggles. Hydraulic uid under pressure can
easily penetrate skin and will cause serious in-
jury or death.
■Make sure that all operating and service person-
nel know that if hydraulic uid penetrates skin,
it must be surgically removed as soon as possi-
ble by a doctor familiar with this form of injury
or gangrene, serious injury, or death will result.
CONTACT A PHYSICIAN IMMEDIATELY IF FLUID
ENTERS SKIN OR EYES. DO NOT DELAY.
■Make sure spring-activated locking pin or collar
slides freely and is seated rmly in tractor PTO
spline groove.
■Know your controls and how to stop engine and
attachment quickly in an emergency.
■Operators must be instructed in and be capa-
ble of the safe operation of the equipment, its
attachments, and all controls. Do not allow any-
one to operate this equipment without proper
instructions.
■Never allow children or untrained persons to op-
erate equipment.
■Make sure attachment is properly secured, ad-
justed, and in good operating condition.
■Always wear relatively tight and belted clothing
to avoid getting caught in moving parts. Wear
sturdy, rough-soled work shoes and protec-
tive equipment for eyes, hair, hands, hearing,
and head; and respirator or lter mask where
appropriate.
STUMP GRINDER PREPARATION
NOTE: For operation of this stump grinder, references
to right, left, forward, and rearward directions are deter-
mined from the operator’s position in the tractor seat.
■ Gearbox comes lled with oil. Check oil level be-
fore operating.
Instructions for checking gearbox oil level can be found
on page 12 in gearbox lubrication section.
ATTACH STUMP GRINDER TO TRACTOR
■Lift cylinder must be completely raised to avoid
driveline damage before raising 3-point lower
lift arms.
1. Attach tractor 3-point lower lift arm to stump grinder
hitch pins and secure.
2. Attach tractor top link to stump grinder clevis and
secure with tractor top link pin.
3. Connect driveline to tractor PTO shaft.
4. Slide lock collar back (Figure 2) or push lock pin in
to make connection.
WARNING
100 ft. RADIUS
CD5955
CAUTION
NOTICE
NOTICE
MAN0495_2023-03.indd 9MAN0495_2023-03.indd 9 4/17/23 2:58 PM4/17/23 2:58 PM

10 Operation MAN0495
(03/15/23)
Figure 2. Lock Collar Connection
5. Make sure connection is secure. Lock collar or lock
pin should snap back into original position.
6. Adjust the tractor 3-point arm anti-sway devices to
prevent stump grinder from swaying side-to-side
during transport.
7. Adjust tractor drawbar so that it will not interfere with
stump grinder or driveline.
8. Attach quick couplers to tractor hydraulic source.
TRACTOR STABILITY
■A minimum 20% of tractor and equipment weight
must be on the tractor front wheels when attach-
ments are in transport position. Without this
weight, front tractor wheels could raise up re-
sulting in loss of steering. The weight may be
attained with front wheel weights, ballast in
tires, front tractor weights or front loader. Weigh
the tractor and equipment. Do not estimate.
Figure 3. Tractor Stability
OPERATING TECHNIQUE
■DO NOT ENGAGE PTO WITH STUMP
GRINDER MAIN FRAME OFF THE GROUND.
Always lower tractor 3-point arms until main
frame crossbrace is on the ground and the cut-
ting head is in the raised position. Adjust 3-point
anti-sway links to prevent stump grinder from
moving during operation.
■Make sure lift cylinder is completely retracted
before backing up to a stump. If cylinder is ex-
tended, debris guard may get pushed into the
cutting wheel and be destroyed.
1. Power for operating the stump grinder is supplied by
the tractor PTO. Know how to stop the tractor and
stump grinder quickly in an emergency.
2. Position stump grinder above stump to be removed
with the main frame crossbrace on the ground and
the cutting wheel in the raised position.
3. Engage PTO at low engine rpm to minimize stress
on the drive system and gearbox. With PTO en-
gaged, increase PTO speed to 540 rpm and
maintain throughout grinding operation.
4. Activate lift cylinder to lower the cutting wheel onto
the stump to desired depth.
NOTE: The amount of material removed may vary
depending on tractor size and hardness of wood.
5. Start cutting wheel on left edge of stump and slow-
ly activate swing cylinder to begin grinding. Cutting
wheel can pivot 44-degrees from side to side.
6. With pass across stump completed, lower cutting
wheel on the right edge of the stump and slowly
activate the swing cylinder to the left. The cutting
wheel has cutting teeth on both sides to perform the
cut.
NOTE: If stump is too large to remove in one pass, re-
position tractor and start operating procedures over.
■Lift cylinder must be completely retracted to
avoid driveline damage before raising 3-point
lift arms.
■Always raise cutting head to avoid pushing
the debris guard into the cutting wheel during
repositioning.
When nished grinding stump, disengage PTO, raise
lift cylinder, and raise stump grinder main frame off the
ground with the 3-point lower lift arms.
STUMP GRINDER STORAGE
1. Lower stump grinder with 3-point lower lift arms until
main frame crossbrace is on the ground. Activate lift
cylinder and lower cutting head to the ground.
2. Disconnect driveline from tractor and place in stor-
age bracket.
WARNING
CD1564-2
NOTICE
NOTICE
Lock
Collar
LA2
NOTICE
MAN0495_2023-03.indd 10MAN0495_2023-03.indd 10 4/17/23 2:58 PM4/17/23 2:58 PM

Operation 11
MAN0495
(03/15/23)
Figure 4. Stump Grinder in Storage Position
CLEANING
After Each Use
■Remove large debris such as clumps of dirt,
grass, crop residue, etc. from machine.
■Inspect machine and replace worn or damaged
parts.
■Replace any safety decals that are missing or
not readable.
Periodically or Before Extended Storage
■Clean large debris such as clumps of dirt, grass,
crop residue, etc. from machine.
■Remove the remainder using a low-pressure
water spray.
1. Be careful when spraying near scratched or torn
safety decals or near edges of decals as water
spray can peel decal off surface.
2. Be careful when spraying near chipped or scratched
paint as water spray can lift paint.
3. If a pressure washer is used, follow the advice of the
pressure washer manufacturer.
■Inspect machine and replace worn or damaged
parts.
■Sand down scratches and the edges of areas of
missing paint and coat with Woods spray paint
of matching color (purchase from your Woods
dealer).
■Replace any safety decals that are missing
or not readable (supplied free by your Woods
dealer). See Safety Decals section for location
drawing.
PRE-OPERATION CHECKLIST
(OWNER’S RESPONSIBILITY)
Review and follow all safety rules and safety de-
cal instructions on page 5 through page 8.
Check that all safety decals are installed and in
good condition. Replace if damaged.
Check that all shields and guards are properly
installed and in good condition. Replace if dam
aged.
Check all lubrication points and grease as in-
structed in “Lubrication Information” on page 12.
NOTE: For operation of this stump grinder, ref-
erences to right, left, forward, and rearward
directions are determined from the operator’s
position in the tractor seat.
Check that all hardware is properly installed and
secured.
Check that equipment is properly and securely
attached to tractor.
Inspect area and remove stones, branches or
other hard objects that might be thrown, causing
injury or damage.
Make sure driveline spring-activated locking
pin or collar slides freely and is seated rmly in
tractor PTO spline groove and in gearbox spline
groove.
Check condition of stump grinder teeth before
operation. Check for dull or chipped teeth. Make
sure jam nuts are torqued to 170 lbs-ft.
MAN0495_2023-03.indd 11MAN0495_2023-03.indd 11 4/17/23 2:58 PM4/17/23 2:58 PM

12 Owner Service MAN0495
(03/15/23)
OWNER SERVICE
The information in this section is written for operators
who possess basic mechanical skills. If you need help,
your dealer has trained service technicians available.
For your protection, read and follow the safety informa-
tion in this manual.
■Keep hands and body away from pressurized
lines. Use paper or cardboard, not hands or
other body parts to check for leaks. Wear safe-
ty goggles. Hydraulic uid under pressure can
easily penetrate skin and will cause serious in-
jury or death.
■Make sure that all operating and service person-
nel know that if hydraulic uid penetrates skin,
it must be surgically removed as soon as possi-
ble by a doctor familiar with this form of injury
or gangrene, serious injury, or death will result.
CONTACT A PHYSICIAN IMMEDIATELY IF FLUID
ENTERS SKIN OR EYES. DO NOT DELAY.
■Do not allow bystanders in the area when op-
erating, attaching, removing, assembling, or
servicing equipment.
■Before performing any service or maintenance,
lower equipment to ground or block securely,
turn off engine, remove key, and disconnect
driveline from tractor PTO.
■Never perform service or maintenance with en-
gine running.
■Keep all persons away from operator control
area while performing adjustments, service, or
maintenance.
■If you do not understand any part of this manual
and need assistance, see your dealer.
LUBRICATION INFORMATION
1. Do not let excess grease collect on or around parts,
particularly when operating in sandy areas.
2. Use a lithium grease of #2 consistency with a MOLY
(molybdenum disulde) additive for all locations un-
less otherwise noted.
NOTE: Be sure to clean ttings thoroughly before
attaching grease gun. One good pump of most
guns is sufcient when the lubrication schedule is
followed.
3. Grease stump grinder pivot points every 8 hours.
Gearbox Lubrication
For gearbox, use a high quality gear oil with a viscosity
index of 80W or 90W and an API service rating of GL–
4 or GL–5.
Fill gearbox until the oil runs out the side plug on gear-
box. Check gearbox daily for evidence of leakage, and
contact your dealer if leakage occurs.
Driveline Lubrication
1. Lubricate the driveline slip joint every eight oper-
ating hours. Failure to maintain proper lubrication
could result in damage to the U-joints, gearbox, and
driveline. See Figure 5.
2. Lower stump grinder to ground, disconnect driveline
from tractor PTO shaft, and slide halves apart but
do not disconnect from each other.
3. Apply a bead of grease completely around male half
where it meets female half. Slide drive halves over
each other several times to distribute grease.
Figure 5. Lubrication Points
WARNING
CAUTION
Grease
Fittings
(2 Places)
Grease
Fittings
(4 Places)
Grease
Fitting
CD7027-1
MAN0495_2023-03.indd 12MAN0495_2023-03.indd 12 4/17/23 2:58 PM4/17/23 2:58 PM

Owner Service 13
MAN0495
(03/15/23)
STUMP GRINDER TOOTH REPLACEMENT
Replace teeth whenever they become damaged, bro-
ken, or excessively worn. Excessively worn cutting
edges greatly decrease cutting efciency.
■Never operate the stump grinder with missing
teeth.
1. Use a 15/16 socket wrench and remove the 5/8"
jam nuts as shown in Figure 6.
2. Remove hex nut from tooth and remove tooth.
3. When installing new teeth, torque the 5/8" jam nuts
to 170 lbs-ft (230 N-m).
Figure 6. Tooth Installed
SLIP CLUTCH ADJUSTMENT
The slip clutch is designed to slip so that the gear-
box and driveline are protected if the cutter strikes an
obstruction.
A new slip clutch or one that has been in storage over
the winter may seize. Before operating the grind-
er, make sure it will slip by performing the following
operation:
1. Turn off tractor engine and remove key.
2. Loosen eight 10 mm cap screws (6) to remove all
tension from pressure plate (5). Springs should ro-
tate freely.
3. Place a mark on edge of lining rings (3).
4. Hold anged hub (4) solid and rotate driveline to
make sure clutch slips. Check marks on edge of lin-
ing rings to see if they have moved.
5. If clutch does not slip freely, disassemble and clean
surface of anged hub (4), ange yoke (1), and
pressure plate (5).
6. Reassemble clutch.
7. Tighten springs (7) until they are compressed to the
1.26 inches shown in Figure 7.
8. If a clutch continues to slip when the springs are
compressed to the 1.26 inch dimension, check
lining rings (3) for excessive wear. Rings are 1/8"
when new. Replace rings after 1/32" wear to ensure
proper operation.
Figure 7. Slip Clutch Assembly
NOTICE
CD7100
1
234356
7
6
1.26
7.09
Lining Rings
1. Flange yoke
2. Bushing
3. Lining ring
4. Flanged hub
5. Pressure plate
6. Bolt and nut M10 x 80
7. Spring
MAN0495_2023-03.indd 13MAN0495_2023-03.indd 13 4/17/23 2:58 PM4/17/23 2:58 PM

14 Dealer Service MAN0495
(03/15/23)
DEALER SERVICE
The information in this section is written for dealer ser-
vice personnel. The repair described here requires
special skills and tools. If your shop is not properly
equipped or your mechanics are not properly trained in
this type of repair, you may be time and money ahead
to replace complete assemblies.
■Keep hands and body away from pressurized
lines. Use paper or cardboard, not hands or
other body parts to check for leaks. Wear safe-
ty goggles. Hydraulic uid under pressure can
easily penetrate skin and will cause serious in-
jury or death.
■Make sure that all operating and service person-
nel know that if hydraulic uid penetrates skin,
it must be surgically removed as soon as possi-
ble by a doctor familiar with this form of injury
or gangrene, serious injury, or death will result.
CONTACT A PHYSICIAN IMMEDIATELY IF FLUID
ENTERS SKIN OR EYES. DO NOT DELAY.
■Never perform service or maintenance with en-
gine running.
■Keep all persons away from operator control
area while performing adjustments, service, or
maintenance.
■Check that all hardware is properly installed.
Always tighten to torque chart specications
unless instructed otherwise in this manual.
■Always wear relatively tight and belted clothing
to avoid getting caught in moving parts. Wear
sturdy, rough-soled work shoes and protec-
tive equipment for eyes, hair, hands, hearing,
and head; and respirator or lter mask where
appropriate.
GEARBOX MAINTENANCE
NOTE: Read this entire section before starting any re-
pair. Many steps are dependent on each other.
NOTE: Repair to this gearbox is limited to replacing
bearings, seals, and gaskets. Replacing gears, shafts,
and a housing is not cost effective. Purchasing a com-
plete gearbox is more economical.
Inspect gearbox for leakage and bad bearings.
Leakage is a very serious problem and must be cor-
rected immediately.
Bearing failure is indicated by excessive noise and
side-to-side or end-play in gear shafts.
Cutting Wheel Removal
1. Position stump grinder on a hard level surface with
main frame crossbrace rmly on the ground.
2. Remove hardware and side shield from the right
side of the cutter frame.
3. Remove cotter pin and slotted hex nut from end of
horizontal gearbox shaft and remove wheel and hub
(Figure 10).
NOTE: You will need to use a heavy-duty puller to
remove cutting wheel and hub from gearbox shaft.
Cutting Wheel Installation
Slide cutting wheel onto gearbox shaft. Install washer
and nut. Torque nut to 200 ft-lbs. Replace cotter pin.
Replace side shield.
Figure 10. Cutting Wheel and Hardware
Gearbox Removal
1. Disconnect and remove the driveline from the
tractor.
2. Disconnect and remove the driveline from the
gearbox.
3. Remove the four bolts that attach gearbox to stump
grinder and remove gearbox.
Seal Replacement
Recommended sealant for gearbox repair is Permatex®
Aviation 3D Form-A-Gasket or equivalent.
Leakage can occur at the input or output gaskets and
shaft seals.
WARNING
CAUTION
MAN0495_2023-03.indd 14MAN0495_2023-03.indd 14 4/17/23 2:58 PM4/17/23 2:58 PM

Dealer Service 15
MAN0495
(03/15/23)
Seal Installation
NOTE: Proper seal installation is important. An improp-
erly installed seal will leak.
1. Clean area in housing where seal outer diameter
(OD) seats. Apply a thin coat of Permatex.
2. Inspect area of shaft where seal seats. Remove any
burrs or nicks with an emery cloth.
3. Lubricate gear shaft and seal lips.
4. Place seal squarely on housing, spring-loaded lip
toward housing. Select a piece of pipe or tubing with
an OD that will sit on the outside edge of the seal
but will clear the housing. Tubing with an OD that
is too small will bow seal cage and ruin seal. See
Figure 22.
5. Carefully press seal into housing, avoiding distor-
tion to the metal seal cage.
Figure 11. Seal Installation
Output Shaft Seal Repair
Refer to Figure 12.
1. Remove vent plug (9) and siphon gear lube from
housing through this opening.
2. Remove output shaft seal (16). Replace with new
seal (see Seal Installation, page 15).
Output seal should be recessed in housing. Input
seal should be pressed ush with outside of
housing.
NOTE: Distortion to seal cage or damage to seal lip
will cause seal to leak.
3. Remove and replace any seal damaged in
installation.
4. Fill gearbox with SAE 80W or 90W gear lube. Fill
instructions can be found on page 12 in gearbox lu-
brication section.
Input Shaft Seal Repair
Refer to Figure 12.
1. Remove vent plug (9) and siphon gear lube from
housing through this opening.
2. If the leak occurred at input shaft, remove oil seal
(4). Replace with new one (refer to Seal Installation,
page 15).
3. Fill gearbox with SAE 80W or 90W gear lube. Fill
instructions can be found on page 12 in gearbox lu-
brication section.
GEARBOX REPAIR
Refer to Figure 12.
NOTE: Repair to this gearbox is limited to replacing
bearings, seals, and gaskets. Replacing gears, shafts,
and a housing is not cost effective. Purchasing a com-
plete gearbox is more economical.
Gearbox Removal
Follow instructions page 14 to remove cutting wheel
and gearbox.
Disassemble Gearbox
1. Remove plug from side of gearbox and pour out re-
maining gear oil.
2. Support housing in vise in a vertical position.
3. Remove input seal (4) (to be replaced).
4. Remove retaining rings (6) and (8).
5. Remove the six cap screws (24), washers (23) and
top cover (2) from housing.
6. Remove retaining ring (6) behind gear (3).
7. Support gearbox in hand press and pull input shaft
(5) through gear (3). Remove ball bearing (21).
8. Remove ball bearing (20) and gear spacer (7) from
input shaft (5).
9. Support housing in vise in a horizontal position.
10. With the hub cutting wheel, castle nut, cotter pin,
wire and washer already removed, remove the four
cap screws (13), lock washers (12) and output cap
(17).
11. Remove output gaskets (11) and (10).
12. Push output shaft and pinion (19) down and remove
ball bearing (20), output bearing spacer (18), and
retaining ring (6). Remove output shaft and pinion
(19).
2
3
4
CD1094
1
CD1092
CD1092
1. Seal
2. Pipe or tube
3. Seal seat
4. Casting
Pipe or tube
must press at
outer edge of
seal
Incorrect
Installation
MAN0495_2023-03.indd 15MAN0495_2023-03.indd 15 4/17/23 2:58 PM4/17/23 2:58 PM

16 Dealer Service MAN0495
(03/15/23)
13. Inspect gears for broken teeth and wear. Some wear
is normal and will show on loaded side. Forged gear
surfaces are rough when new. Check that wear pat-
tern is smooth.
14. Inspect vertical and horizontal shafts for grooves,
nicks, or bumps in the areas where the seals seat.
Resurface any damage with emery cloth.
15. Inspect housing and caps for cracks or other
damage.
SEAL REPAIR
Refer to Figure 12.
Vertical Shaft Seal Repair
1. Disconnect and remove the driveline from the
gearbox.
2. Remove vent plug (9) and siphon gear lube from
housing through this opening.
3. Remove cutting wheel (see Cutting Wheel Removal,
page 14).
4. Remove output cap (17) and output seal (16) by
removing four cap screws (13) and washers (12).
Replace with new seal (see Seal Installation, page
15).
Vertical seal should be recessed in output cap.
NOTE: Distortion to seal cage or damage to seal lip
will cause seal to leak.
5. Secure output cap (17) on to bottom of gearbox
using four cap screws (13) and lock washers (12).
NOTE: Make sure output gasket (10) and (11) are
in place.
6. Fill gearbox with SAE 80W or 90W gear lube until it
runs out the side level plug.
7. Remove and replace any seal damaged in
installation.
Horizontal Seal Leak Repair
1. Disconnect and remove the driveline from the
gearbox.
2. Remove vent plug (9) and siphon gear lube from
housing through this opening.
3. Remove input seal (4). Replace with new one (refer
to Seal Installation, page 15).
Fill gearbox with SAE 80W or 90W gear lube until it
runs out the side level plug.
Reassemble Gearbox
Refer to Figure 12.
1. Clean housing, paying specic attention to areas
where gaskets will be installed.
2. Wash housing and all components thoroughly.
Select a clean area for gearbox assembly. Replace
all seals, bearings, and gaskets. All parts must be
clean and lightly oiled before reassembling.
3. Insert upper output bearing cups (20) in the hous-
ing and press using a round tube with the correct
diameter.
4. Slide shims (25) over output shaft (16). Use the
same thickness as removed as a starting point.
5. Push bearing cone (20) onto output shaft (16).
Shims maybe required between cone (20) and re-
taining ring (6) to eliminate any space.
NOTE: Make sure there is no endplay or gaps in
this assembly.
6. Insert output bearing spacer (18) and bearing cone
(20) over output shaft until seats against upper
bearing (20). Press lower bearing cup into position
as shown.
7. Secure output cap (17) with new output seal (16) in-
stalled to bottom of gearbox housing using the four
10mm x 1.5 x 25 cap screws (13) and lock washers
(12). Use shim gaskets (10) and (11) to adjust out-
put bearings to a rolling torque of 9 to 12 In-lbs.
NOTE: Be sure output gaskets (10 and 11) are in
place. Apply grease to output seal (16) lip for easy
installation.
8. Place ball bearing (21) at back of housing and press
in socket using a round tube of the correct diameter
and a hand press until fully seated.
9. Insert input shaft (5) part way through housing and
slide gear (3) and retaining ring (6) over input shaft
(5). Keep gear (3) and retaining ring (6) loose.
10. Insert input shaft (5) into roller bearing (21) until
seated against each other.
11. Slide gear (3) forward and attach retaining ring (6) in
groove closest to front of input shaft (5). Slide gear
(3) back against retaining ring (6).
12. Check that the gear backlash is between 0.006" and
0.016". You should not have to adjust the backlash.
13. Slide gear spacer (7) and ball bearing (20) on input
shaft (5) and secure with retaining rings (6) and (8).
14. Slide input seal (4) onto input shaft (5) and press
into housing ush with front using a tube of correct
diameter. Be careful not to damage seal lip.
15. Check gearbox housing for leaks by plugging all
holes except one. Apply 4 psi compressed air and
immerse the gearbox in water to verify that there
are no leaks.
Remove gearbox from water and dry off with com-
pressed air. Add SAE 80W or 90W EP oil until it runs
out of side level hole. Tighten all plugs.
MAN0495_2023-03.indd 16MAN0495_2023-03.indd 16 4/17/23 2:58 PM4/17/23 2:58 PM

Dealer Service 17
MAN0495
(03/15/23)
Gearbox Installation
Gearbox is heavy; do not attempt to move without me-
chanical assistance.
Attach gearbox to stump grinder with bolts and nuts
previously removed. Torque bolts to 170 lbs-ft.
24
23
3
2
22 9
54
20
Use Silicone Sealer
Between Cap and Housing
18
19
1
21
17
16
15
14
13 12 11
10
25 20 8
7
6
CD7690A
6
1. Housing
2. Inspection cover
3. 22 Tooth gear
4. Input seal
5. Input shaft
6. Retaining ring
7. Gear spacer
8. Retaining ring
9. Vent Plug and Washer
10. Output gasket (0.30)
11. Output gasket (0.13)
12. Lock washer
13. M10 x 1.5 x 25 Cap screw
14. 1” - 14 Slotted ange nut
15. Cotter pin
16. Output seal
17. Output cap
18. Output bearing spacer
19. Output shaft & pinion
20. Ball bearing
21. Ball bearing
22. Sealing washer
23. M8 Lock washer
24. M8 x 1.5 x 25 Cap screw
25. Shim Kit
Figure 12. Gearbox Assembly
MAN0495_2023-03.indd 17MAN0495_2023-03.indd 17 4/17/23 2:58 PM4/17/23 2:58 PM

18 Dealer Service MAN0495
(03/15/23)
CYLINDER SERVICE
The cylinders are designed to be reliable and easy
to service. If a cylinder should malfunction during the
warranty period, return the complete cylinder assem-
bly, without disassembling, to your authorized service
department or contact your authorized service depart-
ment for instructions. Unauthorized disassembly of a
cylinder in the warranty period will VOID WARRANTY.
NOTE: Repair to cylinders is limited to replacing seals,
wear rings, and O-rings. Replacing rod, barrel, or
pistons is not cost effective. Purchasing a complete cyl-
inder is more economical.
The lift cylinder on the stump grinder was assembled
with either a spanner nut assembly or threaded rod
guide assembly. See Figure 13 and Figure 14 to deter-
mine the style of cylinder on your loader. Spanner nut
cylinders can also be identied by the letter “J” includ-
ed in the stamping located at the base end port. Follow
repair procedures for each style of cylinder.
Figure 13. Spanner Nut Cylinder
Figure 14. Threaded Rod Gland Cylinder
LIFT CYLINDER REPAIR
Spanner Nut Cylinders
Disassemble
Figure 15. Spanner Nut Cylinder Assembly
On spanner nut style cylinders, unscrew spanner nut
(4) using a spanner wrench, or carefully use a punch
and hammer. (Spanner wrench 1021841 is available
from Woods to help with these procedures.)
Tap rod guide (5) into barrel (8) about 1/2". Remove
round retaining ring (3B). Pull on rod (1) to remove
parts from barrel.
Clamp cross pin end of rod assembly (1) in a vise with
protective jaws. Remove lock nut (7) from rod assem-
bly. Remove piston (6), stop tube (2), and rod guide (5)
from rod.
Remove and discard all seals, wear rings and O-rings.
Clean all components in solvent and blow dry with low
pressure air.
Inspect inside diameter of barrel (8). Replace cylinder
if damaged.
Assemble
Lubricate O-rings and seals with clean hydraulic uid.
Install back-up washer (3E) on rod guide (5), then in-
stall O-ring (3F) in exterior O-ring groove of rod guide.
Install rod seal (3D) into inner groove of rod guide with
open portion of V-groove toward piston.
Place rod wiper (3C) in outer rod guide groove. Slide
rod guide assembly (5) onto rod (1). Place crown pis-
ton seal (3G) in piston groove.
Lightly coat rod threads with hydraulic oil and slide O-
ring (3A) over threads and into groove. Install stop tube
and piston (6) onto rod (1) as shown in Figure 16.
Spanner
Nut
DP1
Threaded
Rod Gland
DP2
8
7
6
3G
3F
3E
5
3D
3C
3B
4
3A
1
CD4861
MAN0495_2023-03.indd 18MAN0495_2023-03.indd 18 4/17/23 2:58 PM4/17/23 2:58 PM

Dealer Service 19
MAN0495
(03/15/23)
Figure 16. Spanner Nut Cylinder Assembly
Completely clean threads of hydraulic oil, apply
Locquic®Primer 7649 and Loctite®242 to the rod
threads, and install lock nut (7). Torque to 175 lbs-ft.
Compress crown piston seal and carefully insert piston
and rod assembly into barrel. Use care to prevent dam-
age while installing.
Carefully push or tap rod guide (5) into barrel (8) just
past groove inside barrel. Insert retaining ring (3B) into
groove and pull rod (1) to seat rod guide (5) against
ring. Apply Loctite 242 to rod guide threads. Screw
spanner nut (4) into rod guide (5) using a spanner
wrench, or carefully use a punch and hammer.
Threaded Rod Guide Cylinders
Figure 17. Seal Kit
Disassemble
On threaded guide type cylinders, unscrew guide (5)
using a spanner wrench, or carefully use a punch and
hammer. (Spanner wrench 1021841 is available from
Woods to help with these procedures.) Pull on rod (1)
to remove parts from barrel.
Clamp cross pin end of rod assembly (1) in a vise with
protective jaws. Unscrew piston (6) from end of rod
assembly using a spanner wrench, or carefully use a
punch and hammer. Remove rod guide (5) from rod.
Remove and discard all seals, wear rings and O-rings.
Clean all components in solvent and blow dry with low
pressure air.
Inspect inside diameter of barrel. Replace cylinder if
damaged.
Assemble
For these assembly instructions the front surface of the
threaded rod guide with two holes will be referred to as
the “rod guide face”.
Lubricate O-rings and seals with clean hydraulic u-
id. Install back-up washer (3D) on rod guide (5), and
then install O-ring (3E) in exterior O-ring groove of rod
guide. See Figure 17 or Figure 18. Make sure that the
back-up ring is located closest to the rod guide face.
Place rod wiper (3B) in outer rod guide groove. Install
rod seal (3C) into the second groove from the rod guide
face with the open portion of V-groove toward piston.
With all of the rod guide seals installed, slide the rod
guide assembly (5) onto rod (1).
Place O-ring (3F) into narrow deep groove in piston
(6). Install piston seal (3G) around O-ring (3F) in pis-
ton groove. Install guide ring (3H) into wide groove of
piston (6).
Install crown piston seal (3J) onto piston (6). Install off-
set rings (3H) on both sides of the crown piston seal
(3J) in the large groove on the piston (6). The prole
of the offset ring (3H) should mate with the lip on the
crown piston seal (3J). Place the “L” shaped guide ring
(3G) on the outside of each offset ring (3H).
1
3A
3G
6
7
3C
3D
5
3F
3E 3B
4
2
8
CD7075C
1. Piston rod
2. Stop tube
3A. O-Ring
3B. Retaining ring
3C. Wiper ring
3D. Rod seal
3E. Back-up ring
3F. O-Ring
3G. Crown piston seal
4. Spanner nut
5. Rod guide
assembly
6. Piston
7. Lock nut
8. Cylinder barrel
MAN0495_2023-03.indd 19MAN0495_2023-03.indd 19 4/17/23 2:58 PM4/17/23 2:58 PM

20 Dealer Service MAN0495
(03/15/23)
Figure 18. 1021509 Hydraulic Cylinder
Lightly coat rod threads with hydraulic oil and slide
O-ring (3A) over threads and into groove. Completely
clean threads of hydraulic oil, apply Locquic Primer
7649 and Loctite 242 to the rod threads, and thread
piston (6) onto rod (1) with the two holes in the piston
orientated away from the rod. Torque the piston (6) to
100 lbs-ft.
Compress wear rings and piston seals and carefully in-
sert piston and rod assembly into barrel. Use care to
prevent damage while installing. Carefully screw rod
guide (5) into barrel (8) using a spanner wrench, or
carefully use a punch and hammer.
SWING CYLINDER REPAIR
Repair to cylinders is limited to replacing seals, wear
rings, and O-rings. Replacing rod, barrel, or pistons is
not cost effective. Purchasing a complete cylinder is
more economical.
Disassembly
Remove retaining ring (G) from barrel (2). Slide rod
assembly (3) out of barrel. Inspect inside of cylinder
barrel and rod surface for any scratches or scouring.
Small scratches can be removed with ne crocus cloth.
If scratches cannot be repaired, replace entire cylinder.
Clamp tube end of rod assembly in vise. Use a small
torch to heat nut (4) and break down the thread-locking
compound. Remove nut. Remove piston (5) and rod
guide (1) from rod assembly. Clean threads on rod as-
sembly and nut. Discard all seals.
Figure 19. Swing Cylinder Components
Assembly
Lubricate new seals with clean oil. Install O-ring (D)
and back up ring (E) in the outer groove of guide (1).
Note the position of the backup ring. Install rod seal
(F) in inner groove of rod guide. Note that the lips of
the seal should be toward the piston side of the guide.
Install wiper (H) with lip pointed outward from guide.
Slide rod guide onto rod assembly.
Install O-ring (B) and seal (A) on piston (5). Apply oil to
threads on rod assembly. Slide O-ring (C) over threads.
Install piston. Apply permanent type thread-locking
compound to rod threads and install nut. Torque nut to
125-135 lbs-ft.
3H
1
3C
3B
3D
3E
5
3A
6
83G
3J
3H
3G
CD7075A
1. Piston rod
3A. O-Ring
3B. Wiper ring
3C. Rod seal
3D. Back-up ring
3E. O-Ring
3G. Guard ring
3H. Offset ring
3J. Crown piston seal
5. Rod guide assembly
6. Piston
8. Cylinder barrel
2
3
4
5
1
AB
C
DEF
GH
CD6443-2
1. Rod guide
2. Barrel
3. Rod assembly
4. Nut
5. Piston
A. Seal
B. O-ring
C. O-ring
D. O-ring
E. Backup ring
F. Rod seal
G. Retaining ring
H. Wiper
MAN0495_2023-03.indd 20MAN0495_2023-03.indd 20 4/17/23 2:58 PM4/17/23 2:58 PM
