Woodward easYgen-3000 User manual

37223A
Installation
Software Version 1.xxxx
Manual 37223A
easYgen-3000
Genset Control

Manual 37223A easYgen-3000 Series - Genset Control
Page 2/54 © Woodward
WARNING
Read this entire manual and all other publications pertaining to the work to be performed before install-
ing, operating, or servicing this equipment. Practice all plant and safety instructions and precautions.
Failure to follow instructions can cause personal injury and/or property damage.
The engine, turbine, or other type of prime mover should be equipped with an overspeed (overtempera-
ture, or overpressure, where applicable) shutdown device(s), that operates totally independently of the
prime mover control device(s) to protect against runaway or damage to the engine, turbine, or other
type of prime mover with possible personal injury or loss of life should the mechanical-hydraulic gov-
ernor(s) or electric control(s), the actuator(s), fuel control(s), the driving mechanism(s), the linkage(s),
or the controlled device(s) fail.
Any unauthorized modifications to or use of this equipment outside its specified mechanical, electrical,
or other operating limits may cause personal injury and/or property damage, including damage to the
equipment. Any such unauthorized modifications: (i) constitute "misuse" and/or "negligence" within
the meaning of the product warranty thereby excluding warranty coverage for any resulting damage,
and (ii) invalidate product certifications or listings.
CAUTION
To prevent damage to a control system that uses an alternator or battery-charging device, make sure
the charging device is turned off before disconnecting the battery from the system.
Electronic controls contain static-sensitive parts. Observe the following precautions to prevent dam-
age to these parts.
•Discharge body static before handling the control (with power to the control turned off, contact a
grounded surface and maintain contact while handling the control).
•Avoid all plastic, vinyl, and Styrofoam (except antistatic versions) around printed circuit boards.
•Do not touch the components or conductors on a printed circuit board with your hands or with
conductive devices.
OUT-OF-DATE PUBLICATION
This publication may have been revised or updated since this copy was produced. To verify that you
have the latest revision, be sure to check the Woodward website:
http://www.woodward.com/pubs/current.pdf
The revision level is shown at the bottom of the front cover after the publication number. The latest
version of most publications is available at:
http://www.woodward.com/publications
If your publication is not there, please contact your customer service representative to get the latest
copy.
Important definitions
WARNING
Indicates a potentially hazardous situation that, if not avoided, could result in death or serious injury.
CAUTION
Indicates a potentially hazardous situation that, if not avoided, could result in damage to equipment.
NOTE
Provides other helpful information that does not fall under the warning or caution categories.
Woodward reserves the right to update any portion of this publication at any time. Information provided by Woodward is believed to be
correct and reliable. However, Woodward assumes no responsibility unless otherwise expressly undertaken.
© Woodward
All Rights Reserved.

Manual 37223A easYgen-3000 Series - Genset Control
© Woodward Page 3/54
Revision History
Rev. Date Editor Changes
NEW 06-11-23 TP Release
A 07-06-29 TP Minor corrections
Content
CHAPTER 1. GENERAL INFORMATION.........................................................................................7
CHAPTER 2. ELECTROSTATIC DISCHARGE AWARENESS.............................................................8
CHAPTER 3. HOUSING ...............................................................................................................9
Panel Cutout ...........................................................................................................................................9
Dimensions ...........................................................................................................................................10
Terminal Arrangement ..........................................................................................................................11
Clamp Fastener Installation..................................................................................................................12
Screw Kit Installation.............................................................................................................................13
CHAPTER 4. WIRING DIAGRAMS ..............................................................................................14
CHAPTER 5. CONNECTIONS.....................................................................................................16
Power Supply........................................................................................................................................17
Charging Alternator...............................................................................................................................18
Voltage Measuring (FlexRange)...........................................................................................................19
Voltage Measuring: Generator ...................................................................................................19
Voltage Measuring: Mains..........................................................................................................23
Voltage Measuring: Busbar (System 1) 1Ph 2W........................................................................27
Current Measuring ................................................................................................................................29
Generator Current.......................................................................................................................29
Mains Current 1-Phase...............................................................................................................31
Ground Current...........................................................................................................................32
Power Measuring..................................................................................................................................33
Power Factor Definition.........................................................................................................................33
MPU (Pickup)........................................................................................................................................35
Discrete Inputs......................................................................................................................................36
Discrete Inputs: Signal Polarity...................................................................................................36
Discrete Inputs: Operation Logic................................................................................................38
Relay Outputs (LogicsManager)...........................................................................................................39
Analog Inputs (FlexIn)...........................................................................................................................40
Wiring Two-Pole Senders...........................................................................................................40
Wiring Single-Pole Senders........................................................................................................41
Wiring Single and Two-Pole Senders Simultaneously...............................................................42
Analog Outputs .....................................................................................................................................43
Controller Wiring.........................................................................................................................43
Interfaces ..............................................................................................................................................44
RS-485 Serial Interfaces.............................................................................................................44
RS-232 Serial Interface (Serial Interface #1, Interface #1) ........................................................45
CAN Bus Interfaces (FlexCAN) ..................................................................................................45
CHAPTER 6. TECHNICAL DATA ................................................................................................47
CHAPTER 7. ENVIRONMENTAL DATA........................................................................................50

Manual 37223A easYgen-3000 Series - Genset Control
Page 4/54 © Woodward
CHAPTER 8. ACCURACY ......................................................................................................... 51
APPENDIX A. USEFUL INFORMATION ....................................................................................... 52
Suitable D-SUB Connector Housings................................................................................................... 52
CAN Bus Pin Assignments of Third-Party Units................................................................................... 52
D-SUB DE9 Connector............................................................................................................... 52
RJ45/8P8C Connector ............................................................................................................... 53
IDC / Header Connector............................................................................................................. 53

Manual 37223A easYgen-3000 Series - Genset Control
© Woodward Page 5/54
Figures and Tables
Figures
Figure 3-1: Housing - panel-board cutout .................................................................................................................................. 9
Figure 3-2: Housing easYgen-3000 - dimensions .................................................................................................................... 10
Figure 3-3: easYgen-3200 - terminal arrangement - rear view ................................................................................................ 11
Figure 3-4: Housing - drill plan ............................................................................................................................................... 13
Figure 4-1: Wiring diagram – overview................................................................................................................................... 14
Figure 5-1: Power supply......................................................................................................................................................... 17
Figure 5-2: Power supply - crank waveform at maximum load ............................................................................................... 17
Figure 5-3: Charging alternator input/output ........................................................................................................................... 18
Figure 5-4: Voltage measuring (FlexRange) - generator......................................................................................................... 19
Figure 5-5: Voltage measuring (FlexRange) -generator, 3Ph 4W........................................................................................... 20
Figure 5-6: Voltage measuring (FlexRange) - generator, 3Ph 3W.......................................................................................... 21
Figure 5-7: Voltage measuring (FlexRange) - generator, 1Ph 3W.......................................................................................... 21
Figure 5-8: Voltage measuring (FlexRange) - generator, 1Ph 2W (phase-neutral)................................................................. 22
Figure 5-9: Voltage measuring (FlexRange) - generator, 1Ph 2W (phase-phase)................................................................... 22
Figure 5-10: Voltage measuring (FlexRange) - mains ............................................................................................................ 23
Figure 5-11: Voltage measuring (FlexRange) - mains, 3Ph 4W ............................................................................................. 24
Figure 5-12: Voltage measuring (FlexRange) - mains, 3Ph 3W ............................................................................................. 25
Figure 5-13: Voltage measuring (FlexRange) - mains, 1Ph 3W ............................................................................................. 25
Figure 5-14: Voltage measuring (FlexRange) - mains, 1Ph 2W (phase-neutral) .................................................................... 26
Figure 5-15: Voltage measuring (FlexRange) - mains, 1Ph 2W (phase-phase) ...................................................................... 26
Figure 5-16: Voltage measuring (FlexRange) - busbar (system 1) 1Ph 2W (phase-phase)..................................................... 27
Figure 5-17: Voltage measuring (FlexRange) - busbar, 1Ph 2W (phase-neutral) ................................................................... 28
Figure 5-18: Voltage measuring (FlexRange) - busbar, 1Ph 2W (phase-phase) ..................................................................... 28
Figure 5-19: Current measuring - generator............................................................................................................................. 29
Figure 5-20: Current measuring - generator, L1 L2 L3............................................................................................................ 30
Figure 5-21: Current measuring - Generator, phase Lx ........................................................................................................... 30
Figure 5-22: Current measuring - mains current ...................................................................................................................... 31
Figure 5-23: Current measuring - mains, phase Lx.................................................................................................................. 31
Figure 5-24: Current measuring - ground current .................................................................................................................... 32
Figure 5-25: Power measuring - direction of power ................................................................................................................ 33
Figure 5-26: MPU - principle overview................................................................................................................................... 35
Figure 5-27: MPU input........................................................................................................................................................... 35
Figure 5-28: Minimal necessary input voltage depending on frequency ................................................................................. 35
Figure 5-29: Discrete inputs - alarm/control input - positive signal......................................................................................... 36
Figure 5-30: Discrete inputs - alarm/control input - negative signal........................................................................................ 37
Figure 5-31: Discrete inputs - alarm/control inputs - operation logic ...................................................................................... 38
Figure 5-32: Relay outputs....................................................................................................................................................... 39
Figure 5-33: Analog inputs (FlexIn) - wiring two-pole senders.............................................................................................. 40
Figure 5-34: Analog inputs (FlexIn) - wiring single-pole senders .......................................................................................... 41
Figure 5-35: Analog inputs (FlexIn) - wiring single- and two-pole senders ........................................................................... 42
Figure 5-36: Analog controller output - Wiring and external jumper setting........................................................................... 43
Figure 5-37: RS-485 interface #1 - overview........................................................................................................................... 44
Figure 5-38: RS-485 Modbus - connection for half-duplex operation ..................................................................................... 44
Figure 5-39: RS-485 Modbus - connection for full-duplex operation...................................................................................... 44
Figure 5-40: RS-232 interface - overview................................................................................................................................ 45
Figure 5-41: CAN bus #1 - overview....................................................................................................................................... 45
Figure 5-42: CAN bus #2 - overview....................................................................................................................................... 45
Figure 5-43: Interfaces - CAN bus - termination ..................................................................................................................... 46
Figure 8-1: CAN bus pin assignment - D-SUB DE9 connector............................................................................................... 52
Figure 8-2: CAN bus pin assignment - RJ45/8P8C connector ................................................................................................. 53
Figure 8-3: CAN bus pin assignment - IDC / Header .............................................................................................................. 53

Manual 37223A easYgen-3000 Series - Genset Control
Page 6/54 © Woodward
Tables
Table 1-1: Manual - overview.................................................................................................................................................... 7
Table 3-1: Housing - panel cutout ............................................................................................................................................. 9
Table 5-1: Conversion chart - wire size ................................................................................................................................... 16
Table 5-2: Power supply - terminal assignment....................................................................................................................... 17
Table 5-3: Charging alternator input/output - terminal assignment ......................................................................................... 18
Table 5-4: Voltage measuring (FlexRange) - terminal assignment - generator voltage.......................................................... 19
Table 5-5: Voltage measuring (FlexRange) - terminal assignment - generator, 3Ph 4W......................................................... 20
Table 5-6: Voltage measuring (FlexRange) - terminal assignment - generator, 3Ph 3W......................................................... 21
Table 5-7: Voltage measuring (FlexRange) - terminal assignment - generator, 1Ph 3W......................................................... 21
Table 5-8: Voltage measuring (FlexRange) - terminal assignment - generator, 1Ph 2W (phase-neutral)................................ 22
Table 5-9: Voltage measuring (FlexRange) - terminal assignment - generator, 1Ph 2W (phase-phase).................................. 22
Table 5-10: Voltage measuring (FlexRange) - terminal assignment - mains voltage ............................................................. 23
Table 5-11: Voltage measuring (FlexRange) - terminal assignment - mains, 3Ph 4W ............................................................ 24
Table 5-12: Voltage measuring (FlexRange) - terminal assignment - mains, 3Ph 3W ............................................................ 25
Table 5-13: Voltage measuring (FlexRange) - terminal assignment - mains, 1Ph 3W ............................................................ 25
Table 5-14: Voltage measuring (FlexRange) - terminal assignment - mains, 1Ph 2W (phase-neutral) ................................... 26
Table 5-15: Voltage measuring (FlexRange) - terminal assignment - mains, 1Ph 2W (phase-phase) ..................................... 26
Table 5-16: Voltage measuring (FlexRange) - terminal assignment - busbar (system 1) 1Ph 2W (phase-phase)................... 27
Table 5-17: Voltage measuring (FlexRange) - terminal assignment - busbar, 1Ph 2W (phase-neutral) .................................. 28
Table 5-18: Voltage measuring (FlexRange) - terminal assignment - busbar, 1Ph 2W (phase-phase) .................................... 28
Table 5-19: Current measuring - terminal assignment - generator current .............................................................................. 29
Table 5-20: Current measuring - terminal assignment - generator, L1 L2 L3 ......................................................................... 30
Table 5-21: Current measuring - terminal assignment - generator, phase Lx .......................................................................... 30
Table 5-22: Current measuring - terminal assignment - mains current.................................................................................... 31
Table 5-23: current measuring - terminal assignment - mains, phase Lx................................................................................. 31
Table 5-24: Current measuring - terminal assignment - ground current .................................................................................. 32
Table 5-25: MPU - terminal assignment.................................................................................................................................. 35
Table 5-26: Discrete input - terminal assignment .................................................................................................................... 37
Table 5-27: Relay outputs - terminal assignment .................................................................................................................... 39
Table 5-28: Analog inputs (FlexIn) - terminal assignment - wiring two-pole senders............................................................ 40
Table 5-29: Analog inputs (FlexIn) - terminal assignment - wiring single-pole senders ........................................................ 41
Table 5-30: Analog inputs (FlexIn) - terminal assignment - wiring single- and two-pole senders ......................................... 42
Table 5-31: Bias signal outputs - analog or PWM................................................................................................................... 43
Table 5-32: RS-485 interface #1 - pin assignment................................................................................................................... 44
Table 5-33: RS-232 interface - pin assignment........................................................................................................................ 45
Table 5-34: CAN bus #1 - pin assignment............................................................................................................................... 45
Table 5-35: CAN bus #2 - pin assignment............................................................................................................................... 45
Table 5-36: Maximum CAN bus length................................................................................................................................... 46
Table 8-1: CAN bus pin assignment - D-SUB DE9 connector ................................................................................................ 52
Table 8-2: CAN bus pin assignment - RJ45/8P8C connector .................................................................................................. 53
Table 8-3: CAN bus pin assignment - IDC / Header ............................................................................................................... 53

Manual 37223A easYgen-3000 Series - Genset Control
© Woodward Page 7/54
Chapter 1.
General Information
Type English German
easYgen-3000 Series
easYgen-3000 - Installation this manual Ö37223 GR37223
easYgen-3000 - Configuration 37224 -
easYgen-3000 - Operation 37225 GR37225
easYgen-3000 - Application 37226 -
easYgen-3000 - Interfaces 37383 -
Table 1-1: Manual - overview
Intended Use The unit must only be operated in the manner described by this manual. The prerequisite for a
proper and safe operation of the product is correct transportation, storage, and installation as well as careful op-
eration and maintenance.
NOTE
This manual has been developed for a unit fitted with all available options. Inputs/outputs, functions,
configuration screens, and other details described, which do not exist on your unit, may be ignored.
The present manual has been prepared to enable the installation and commissioning of the unit. Due to
the large variety of parameter settings, it is not possible to cover every combination. The manual is
therefore only a guide. In case of incorrect entries or a total loss of functions, the default settings may
be taken from the list of parameters in the configuration manual 37224 or from ToolKit and the respec-
tive *.SID file.

Manual 37223A easYgen-3000 Series - Genset Control
Page 8/54 © Woodward
Chapter 2.
Electrostatic Discharge Awareness
All electronic equipment is static-sensitive, some components more than others. To protect these components
from static damage, you must take special precautions to minimize or eliminate electrostatic discharges.
Follow these precautions when working with or near the control.
1. Before doing maintenance on the electronic control, discharge the static electricity on your body to
ground by touching and holding a grounded metal object (pipes, cabinets, equipment, etc.).
2. Avoid the build-up of static electricity on your body by not wearing clothing made of synthetic materials.
Wear cotton or cotton-blend materials as much as possible because these do not store static electric char-
ges as easily as synthetics.
3. Keep plastic, vinyl, and Styrofoam materials (such as plastic or Styrofoam cups, cigarette packages, cello-
phane wrappers, vinyl books or folders, plastic bottles, etc.) away from the control, modules, and work
area as much as possible.
4. Opening the control cover may void the unit warranty.
Do not remove the printed circuit board (PCB) from the control cabinet unless absolutely necessary. If
you must remove the PCB from the control cabinet, follow these precautions:
•Ensure that the device is completely voltage-free (all connectors have to be disconnected).
•Do not touch any part of the PCB except the edges.
•Do not touch the electrical conductors, connectors, or components with conductive devices or with
bare hands.
•When replacing a PCB, keep the new PCB in the plastic antistatic protective bag it comes in until you
are ready to install it. Immediately after removing the old PCB from the control cabinet, place it in the
antistatic protective bag.
CAUTION
To prevent damage to electronic components caused by improper handling, read and observe the pre-
cautions in Woodward manual 82715, Guide for Handling and Protection of Electronic Controls, Printed
Circuit Boards, and Modules.
NOTE
The unit is capable to withstand an electrostatic powder coating process with a voltage of up to 85 kV
and a current of up to 40 µA.

Manual 37223A easYgen-3000 Series - Genset Control
© Woodward Page 9/54
Chapter 3.
Housing
Panel Cutout
≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡
h' h H
b
B
b'
Figure 3-1: Housing - panel-board cutout
Measure Description Tolerance
H Height Total 217 mm ---
h Panel cutout 183 mm + 1.0 mm
h' Housing dimension 181 mm
B Width Total 282 mm ---
b Panel cutout 249 mm + 1.1 mm
b' Housing dimension 247 mm
Depth Total 99 mm ---
Table 3-1: Housing - panel cutout
The maximum permissible corner radius is 4 mm.
Refer to Figure 3-4 on page 13 for a cutout drawing.

Manual 37223A easYgen-3000 Series - Genset Control
Page 10/54 © Woodward
Dimensions
≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡
282 mm
217 mm
99 mm
87 mm
181 mm
247 mm
Figure 3-2: Housing easYgen-3000 - dimensions

Manual 37223A easYgen-3000 Series - Genset Control
© Woodward Page 11/54
Terminal Arrangement
≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡
6162636465666768697071727374757677787980
MPU -
MPU +
24 V +
24 V -
D+
DI 12
DI 11
DI 10 DI 09 DI 08 DI 07 DI 06 DI 05 DI 04 DI 03 DI 02 DI 01
605958 5756 55545352 515049 4847 46454443 4241
RS-232
21
RS-485
100 V
2012345678910 11 1213 141516 171819
s2 s1 +
+ -
2223 2425 262728 2930 31 32333435 3637 3839 40
400 V 100 V 400 V 100 V 400 V 100 V 400 V 100 V 400 V 100 V 400 V 100 V 400 V 100 V 400 V 100 V 400 V 100 V 400 V
L1 L2 L3 NL1 L2 L3 NL1 L2/N
AO 02
+ -
AO 01AI 03AI 02
+
AI 01
+
L1 L2 L3
s2 s1 s2 s1 s2 s1
L1
Pickup Power supply Engine ground Protective earth PE Auxiliary excitation
DI Common
Discrete Inputs Relay Outputs
CAN bus #2
Relay R09 Relay R10
Relay R11
Relay R12 Relay R08 Relay R07 Relay R06 Relay R05 Relay R01 Relay R02 Relay R03 Relay R04
Ground/Mains CT
Generator CT Analog Inputs
0 to 500 Ohm
0/4 to 20 mA
Analog Outputs
+/-10 Vdc
+/- 20 mA
PWM
PWM
V
Out
PWM
V
Out
Mains PT Generator PT Busbar PT
CAN bus #1
Common Common
Figure 3-3: easYgen-3200 - terminal arrangement - rear view

Manual 37223A easYgen-3000 Series - Genset Control
Page 12/54 © Woodward
Clamp Fastener Installation
≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡
For installation into a door panel with the fastening clamps, proceed as follows:
1. Panel cut-out
Cut out the panel according to the dimensions in Table 3-1.
Note:
Don't drill the holes if you want to use the clamp fasteners. If the holes
are drilled into the panel, the clamp fasteners cannot be used anymore!
cut-out
186,0
138,0
R 3,5
Rmax:
2. Remove terminals
Loosen the wire connection terminal screws on the back of the unit and
remove the wire connection terminal strip if required (1).
1
3. Loosen clamping screws
Loosen the four clamping screws (1) until they are almost flush with the
clamp inserts and tilt the clamp inserts down by 45° (2) to remove them
from the housing. Do not completely remove the screws from the clamp
inserts.
12
4. Insert unit into cut-out
Insert the unit into the panel cutout. Verify that the unit fits correctly in
the cutout. If the panel cutout is not big enough, enlarge it accordingly.
5. Attach clamp inserts
Re-install the clamp inserts by tilting the insert to a 45° angle. (1) Insert
the nose of the insert into the slot on the side of the housing. (2) Raise the
clamp insert so that it is parallel to the control panel.
1
2
6. Tighten clamping screws
Tighten the clamping screws (1) until the control unit is secured to the
control panel (2). Over tightening of these screws may result in the clamp
inserts or the housing breaking. Do not exceed the recommended tighten-
ing torque of 0.1 Nm.
1
2
7. Reattach terminals
Reattach the wire connection terminal strip (1) and secure them with the
side screws.
1

Manual 37223A easYgen-3000 Series - Genset Control
© Woodward Page 13/54
Screw Kit Installation
≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡
NOTE
Don't drill the holes if you want to use the clamp fasteners. If the holes are drilled into the panel, the
clamp fasteners cannot be used anymore!
In order to enhance the protection to IP 66, it is possible to fasten the unit with a screw kit instead of the clamp
fastener hardware.
Proceed as follows to install the unit using the screw kit:
1. Cut out the panel and drill the holes according to the dimensions in Figure 3-4.
2. Insert the unit into the panel cutout. Verify that the unit fits correctly in the cutout. If the panel cutout is not
big enough, enlarge it accordingly.
3. Insert the screws and tighten to 0.6 Nm (5.3 pound inches) of torque. Tighten the screws with a crosswise
pattern to ensure even pressure distribution.
NOTE
If the thickness of the panel sheet exceeds 2.5 mm, be sure to use screws with a length of the panel
sheet thickness + 4 mm.
Cut-out dimension:
249mm (+1,1mm) x 183mm (+1,0mm)
249.0
183.0
5.0 254.0
24.5
124.5
224.5
21.5
91.5
161.5
194.4
259.0
5.7
ø 4.5
12 x
Rmax: R 4.0
Figure 3-4: Housing - drill plan

Manual 37223A easYgen-3000 Series - Genset Control
Page 14/54 © Woodward
Chapter 4.
Wiring Diagrams
[refer to next page for wiring diagram]
Figure 4-1: Wiring diagram – overview

Manual 37223A easYgen-3000 Series - Genset Control
© Woodward Page 15/54
FlexCAN
2007-06-28 | easYgen-3000 Wiring Diagram eYg3000ww-2607-ap.SKFSubject to technical mocifications.
Generator voltage L3
Generator voltage L2
Generator voltage L1
Generator voltage N
FlexRange
LogicsManager
(Genset Control)
Busbar voltage (system 1) L2/N
400 Vac
100 Vac
Busbar voltage (system 1) L1
FlexRange
FlexIn
[R 05]
[R 06]
[R 07]
[R 08]
[R 09]
easYgen-3200
Interface #3
CAN bus #1
Guidance/system level (isolated)
Interface #4
CAN bus #2
Engine level (isolated)
Interface #2
RS-485 (isolated) #1
Serial #2
FlexCAN
9-pin male
submin-D-connector
9-pin male
submin-D-connector
Interface #1
RS-232 (isolated)
Serial #1
MPU (pickup)
9-pin male
submin-D-connector
Mains voltage L3
Mains voltage L2
Mains voltage L1
Mains voltage N
FlexRange
+
+
-
+
-
Ground current
(or mains current)
(isolated)
Generator current
(isolated)
s1
s2
[DI 03]
[DI 04]
[DI 05]
[DI 06]
[DI 07]
[DI 08]
[DI 09]
[DI 10]
[DI 11]
[DI 12]
[DI 01]
[DI 02]
Power supply
isolated, 8 to 40 Vdc
Engine ground
Protective Earth PE
[R 12]
[R 11]
[R 10]
[R 01]
[R 04]
[R 03]
[R 02]
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
80 79 78 77 76 75 74 73 72 71 70 69 68 67 66 65 64 63 62 61 60 59 58 57 56 55 54 53 52 51 50 49 48 47 46 45 44 43 42 41
-
+
-
+
PWM DC current DC voltage PWM
GND GND GNDPWM
V
N/C
I
A
GND
V
GNDN/C
I
A
9-pin male
submin-D-connector
Auxiliary excitation D+ (isolated)
(isolated)
(isolated)
GNDPWM
2: RxD
3:TxD
5: GND
7: RTS
8: CTS
2: CAN-L
3: GND
7: CAN-H
2: CAN-L
3: GND
7: CAN-H
Analog output [AO 02]
(+/-10Vdc / +/-20mA/ PWM)
Analog output [AO 01]
(+/-10Vdc / +/-20mA/ PWM)
Analog input [AI 03]
(0 to 500 Ohm / 0/4 to 20 mA)
Analog input [AI 02]
(0 to 500 Ohm / 0/4 to 20 mA)
Analog input [AI 01]
(0 to 500 Ohm / 0/4 to 20 mA)
2: B
4: B'
7:A
9:A'
Out Out
400 Vac
100 Vac
400 Vac
100 Vac
400 Vac
100 Vac
400 Vac
100 Vac
400 Vac
100 Vac
400 Vac
100 Vac
400 Vac
100 Vac
400 Vac
100 Vac
400 Vac
100 Vac
+
+
L3
s1
s2
L2
s1
s2
L1
s1
s2
L1
DI Common for terminals 67-78
Discrete Input 01: Configurable (isolated)
Default: Emergency Stop
Discrete Input 02: Configurable (isolated)
Default: Start inAUTO
Discrete Input 03: Configurable (isolated)
Default: Low oil pressure
Discrete Input 04: Configurable (isolated)
Default: Coolant temperature
Discrete Input 05: Configurable (isolated)
Default: External alarm acknowledgement
Discrete Input 06: Configurable (isolated)
Default: Enable MCB
Discrete Input 07: Reply: MCBopen (isol.)
Discrete Input 08: Reply: GCBopen (isol.)
Discrete Input 09: Configurable (isolated)
Discrete Input 10: Configurable (isolated)
Discrete Input 11: Configurable (isolated)
Discrete Input 12: Configurable (isolated)
Relay 12: LogicsManager configurable
Default: Alarm class C, D, E, or F
Relay 11: LogicsManager configurable
Default: Alarm class Aor B
Relay 10: LogicsManager configurable
Default: Auxiliary services
Relay 09: Command: open MCB
(only in {2oc} application mode)
or
LogicsManager configurable
Relay 08: Command: close MCB
(only in {2oc} application mode)
or
LogicsManager configurable
Relay 07: Command: open GCB
(only in {1o}, {1oc}, or {2oc} app. mode)
or
LogicsManager configurable
Relay 06: Command: close GCB
(only in {1oc} or {2oc} application mode)
or
LogicsManager configurable
Relay 05: LogicsManager configurable
Default: Preglow
Relay 04: LogicsManager configurable
Default: Fuel solenoid / gas valve
Relay 03: LogicsManager configurable
Default: Starter
Relay 02: LogicsManager configurable
Default: Centralized alarm
Relay 01: LogicsManager configurable
Fixed to: Ready for operation
-
-
-

Manual 37223A easYgen-3000 Series - Genset Control
Page 16/54 © Woodward
Chapter 5.
Connections
WARNING
All technical data and ratings indicated in this chapter are not definite! Only the values indicated in
Chapter 6: Technical Data on page 47 are valid!
The following chart may be used to convert square millimeters [mm²] to AWG and vice versa:
AWG mm² AWG mm² AWG mm² AWG mm² AWG mm² AWG mm²
30 0.05 21 0.38 14 2.5 4 25 3/0 95 600MCM 300
28 0.08 20 0.5 12 4 2 35 4/0 120 750MCM 400
26 0.14 18 0.75 10 6 1 50 300MCM 150 1000MCM 500
24 0.25 17 1.0 8 10 1/0 55 350MCM 185
22 0.34 16 1.5 6 16 2/0 70 500MCM 240
Table 5-1: Conversion chart - wire size

Manual 37223A easYgen-3000 Series - Genset Control
© Woodward Page 17/54
Power Supply
≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡
WARNING – Protective Earth
Protective Earth (PE) must be connected to the terminal 61 on the back of the unit to reduce the risk of
electric shock. This connection will be made using the screw-plug-terminal. The conductor providing
the connection must have a wire larger than or equal to 2.5 mm² (14 AWG). The connection must be
performed properly.
Power supply
63
64
0 Vdc
12/24Vdc (8 to 40.0 Vdc)
8 to 40.0 Vdc
61
PE
Figure 5-1: Power supply
Terminal Description Amax
61 PE (protection earth) 2.5 mm²
63 12/24Vdc (8 to 40.0 Vdc) 2.5 mm²
64 0 Vdc 2.5 mm²
Table 5-2: Power supply - terminal assignment
[ms] -50 0 50 100 150 200 250 300 350
[V]
9.0
10.0
11.0
12.0
P
o
w
er Supply
8.0
7.0
6.0
5.0
4.0
3.0
2.0
1.0
0.0
Time
Initial voltage = 10.5 Vdc
0.0 Vdc for 10 ms
Continuous voltage = min. 8.0 Vdc
Continuous voltage range =
8.0 to 40.0 Vdc
Figure 5-2: Power supply - crank waveform at maximum load
NOTE
Woodward recommends to use one of the following slow-acting protective devices in the supply line to
terminal 63:
• Fuse NEOZED D01 6A or equivalent
or
• Miniature Circuit Breaker 6A / Type C (for example: ABB type: S271C6 or equivalent)

Manual 37223A easYgen-3000 Series - Genset Control
Page 18/54 © Woodward
Charging Alternator
≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡
Auxiliary excitation
63
65
8 to 40 Vdc
D+
B+ D+
+
-
G~
Figure 5-3: Charging alternator input/output
Terminal Description Amax
63 Battery B+ 2.5 mm²
65 Auxiliary excitation output D+ 2.5 mm²
Table 5-3: Charging alternator input/output - terminal assignment
NOTE
The charging alternator D+ acts as an output for pre-exciting the charging alternator during engine
start-up only. During regular operation, it acts as an input for monitoring the charging voltage.

Manual 37223A easYgen-3000 Series - Genset Control
© Woodward Page 19/54
Voltage Measuring (FlexRange)
≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡
NOTE
DO NOT use both sets of voltage measuring inputs. The control unit will not measure voltage correctly
if the 100 V and 400 V inputs are utilized simultaneously.
NOTE
Woodward recommends protecting the voltage measuring inputs with slow-acting fuses rated for 2 to
6 A.
Voltage Measuring: Generator
L1
L2
L3
N
Generator voltage
(phase voltage)
GCB
32
N / Vcom
31
30
29 L1 / Va
L2 / Vb
L3 / Vc
35
34
33
36
100 Vac
400 Vac
100 Vac
400 Vac
G
3~
100 Vac
400 Vac
100 Vac
400 Vac
100 Vac
400 Vac
100 Vac
400 Vac
100 Vac
400 Vac
100 Vac
400 Vac
Figure 5-4: Voltage measuring (FlexRange) - generator
Terminal Description Amax
29 100 Vac 2.5 mm²
30 Generator voltage - phase L1 / Va 400 Vac 2.5 mm²
31 100 Vac 2.5 mm²
32 Generator voltage - phase L2 / Vb 400 Vac 2.5 mm²
33 100 Vac 2.5 mm²
34 Generator voltage - phase L3 / Vc 400 Vac 2.5 mm²
35 100 Vac 2.5 mm²
36 Generator voltage - phase N / Vcom 400 Vac 2.5 mm²
Table 5-4: Voltage measuring (FlexRange) - terminal assignment - generator voltage
NOTE
The 100 V input terminals must used, if parameter 1800 (refer to Configuration Manual 37224) is config-
ured with a value between 50 and 130 V for proper measurement.
The 400 V input terminals must used, if parameter 1800 (refer to Configuration Manual 37224) is config-
ured with a value between 131 and 480 V for proper measurement.

Manual 37223A easYgen-3000 Series - Genset Control
Page 20/54 © Woodward
Voltage Measuring: Generator, Parameter Setting '3Ph 4W' (3-phase, 4-wire)
L1
L2
N
L3
N
A1
A2
A
B
B2
B1
C
C2
C1
L1
L2
N
L3
N
A1
A2
A
B
C6
C5
B6
B5
A5
A6
B2
B1
C
C2
C1
L1
L2
N
L3
N
A1
A2
A
B
B6
B5
A
5
A
6
C
C6
C5
B2
B1
C2
C1
L1
L2
L3
N
N
B1B2
C6
C5
A1
A2
B5B6
A
B
C
C2
C1
A5
A6
Figure 5-5: Voltage measuring (FlexRange) -generator, 3Ph 4W
3Ph 4W Wiring terminals Note
Rated voltage (range) 100 Vac (50 to 130 V) 400 Vac (131 to 480 V)
Measuring range (max.) 0 to 150 Vac 0 to 600 Vac 1
easYgen 29 31 33 35 30 32 34 36
Phase L1 L2 L3 N L1 L2 L3 N
Table 5-5: Voltage measuring (FlexRange) - terminal assignment - generator, 3Ph 4W
1For different voltage systems, different wiring terminals have to be used. Incorrect measurements are possible if both voltage systems use
the same N terminal.
