Sony RCP-TX7 User manual

1997 by Sony Corporation
Operating Instructions
Before operating the unit, please read this manual
thoroughly and retain it for future reference.
Remote Control
Panel
3-859-859-13(1)
RCP-TX7

For the customers in the USA
This equipment has been tested and found to comply with the
limits for a Class A digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment
is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case the
user will be required to correct the interference at his own
expense.
You are cautioned that any changes or modifications not
expressly approved in this manual could void your authority
to operate this equipment.
This device requires shielded interface cables to comply with
FCC emission limits.
2

3
Table of Contents
Overview ............................................................................4
Location and Function of Parts .......................................5
Operation Panel and Connector........................................... 5
1Main Operation Section................................................ 5
2Menu Operation/Setting Display Section..................... 7
3Paint section and CALL button .................................... 8
Menu Operations.............................................................12
Displaying menus.............................................................. 12
Basic Menu Operations ..................................................... 14
Menu Contents .................................................................. 15
File Operations ................................................................21
Operating Scene Files........................................................ 23
Operating Setup Files (for DXC-D30/D30P Only)........... 24
Skin Detail Correction/Skin Matrix Adjustment
(for DXC-D30/D30P Only) ...........................................25
Multi-Camera Control......................................................26
Operating Multiple Cameras from One RCP Unit
— Command Link........................................................ 26
Adjusting the Iris and Master Black of Multiple Cameras
at One Time .................................................................. 27
Data Transfer Among Multiple Cameras .......................... 27
Specifications..................................................................28

Overview
4
Overview
The RCP-TX7 Remote Control Panel enables remote
operation of the DXC-D30/D30P or DXC-637 series
Color Video Camera.
This unit’s features are described below.
Connectable to camera control unit or
camera head
When a CCU (CCU-TX7/TX7P Camera Control Unit)
has been connected to a CA (CA-TX7/TX7P Camera
Adaptor) that is docked with a camera head, this unit
can be connected to the CCU to enable remote
operation of the camera via the CCU.
When the DXC-D30/D30P is docked with a CA-537/
537P Camera Adaptor or VCR, this unit can be
connected to the DXC-D30/D30P to enable direct
operation of the camera.
Full control of shooting operations
Besides controlling camera adjustments and settings,
this unit can control tripod operations (pan and tilt) and
lens settings (focus and zoom).
Confirmation of camera conditions and
operation status
This unit’s LCD panel indicates camera conditions
such as the optical filter position, value, and lens
extender setting. The results of the camera’s self-
diagnosis tests are also displayed on the LCD panel.
Scene file
The unit provides memory to hold data on shooting
conditions for 16 different scenes, to enable easy
readjustment of the camera for any memorized scenes.
Coordination of settings among several
cameras
In a system that includes several cameras that are
connected via CCUs, connecting the CCUs allows this
unit to set up all of the cameras into the same color
condition.
High-precision and high-speed control
Commands can be issued at high speed, which means
that remote operation with the unit’s knobs can be
performed more smoothly than with previous remote
control devices. Also, high-precision data transfer
raises control precision.

5
Location and Function of Parts
Operation Panel and Connector
The following figure shows external views of this unit.
1Main Operation Section
REMOTE CONTROL PANEL

Operation panel
1Main operation section
2Menu operation/setting display
section (see page 7)
3Paint section and CALL button
(see page 8)
CCU/camera connector
(10-pin): Use the
supplied cable to connect
this unit to a CCU or
camera head. The power
supply to this unit and the
signal exchange are both
carried out via this
connector.
STANDARD
SKIN
DETAIL
MASTER SLAVE CAM POWER BARS
AUTO SETUP
OPERATE MONITOR SELECT
LEVEL WHITE BLACK
RGB
SEQ
PULL PAINT
BLACK
LOCK
IRIS/M.
ENC
1TALLY indicator
2STANDARD button
3MASTER and SLAVE buttons
4CAM POWER switch
5BARS button
6AUTO SETUP buttons
7MONITOR SELECT buttons
8OPERATE knob

Location and Function of Parts
6
1TALLY indicator
Lights in red when a red tally signal from the CA or
CCU is received and lights in green when a green tally
signal is received.
2STANDARD button
Press to automatically set up the camera for use under
standard shooting conditions.
3MASTER and SLAVE buttons (only when this
unit is connected to CCU)
When using several remote control panels connected to
CCUs, press the MASTER button on the unit to be
used as the master unit and press the SLAVE button on
all other units (slave units). Both buttons light when
pressed.
Once a unit has been set as the master unit, the
MASTER button on any other unit cannot be operated.
To select other unit for master unit, press the
MASTER button on the current master unit again.
(The button goes out.)
For details, see “Multi-Camera Control” on page 26.
4CAM (camera) POWER switch (only when this
unit is connected to CCU)
When the power supply is on for the CCU, CA and
camera head, this switch lights. You can then turn the
power supply for the camera on or off by pressing the
switch. The switch lights when the power is on, and
goes out when the power is off. It takes a moment
until the power is being turned on or off after the
switch is pressed. (The switch blinks meanwhile.)
5BARS (color bars) button
Press to output color bars from the camera when this
unit has been connected to a camera. When this unit
has been connected to a CCU, press this button to
output color bars from the CCU’s internal color bar
generator.
6AUTO SETUP buttons
Press one of these buttons to set up the camera
automatically for the corresponding item. The buttons
will blink when pressed.
Operations of the button are as follows:.
a)Skin gate area: target color range of skin detail correction
or skin matrix adjustment
7MONITOR SELECT buttons (only when this
unit is connected to CCU)
Press one of these buttons to select the type of signal
output via the PIX and WFM connectors on the CCU’s
rear panel. The buttons will light when pressed.
The following signals can be selected.
8OPERATE knob
Locks some of the buttons and knobs on the control
panel.
FULL: No locking.
PAINT: Locks the buttons and knobs except for
those in the paint section 3, CALL button 3,
AUTO SETUP buttons 6(excluding LEVEL
button) and MONITOR SELECT buttons 7.
IRIS/M.BLACK: Locks the buttons and knobs
except for those in the iris adjustment block and
master black adjustment block in the paint section
3, CALL button 3, and MONITOR SELECT
buttons 7.
LOCK: Locks the buttons and knobs except for the
CALL button 3and MONITOR SELECT
buttons 7.
Button Operation
SKIN DETAIL
(only for DXC-
D30/D30P)
Recalls the AUTO SKIN menu and
performs automatic designation of the
skin gate area.a)
LEVEL Performs auto white balance or auto
black balance adjustments. (During
adjustment, indications appear on the
LCD panel in the menu operation/setting
display 2.) When using a DXC-D30/
D30P, the R/B gamma is set to the
standard value.
WHITE Performs auto white balance adjustment.
(During adjustment, indications appear on
the LCD panel in the menu operation/
setting display 2.)
BLACK Performs auto black balance adjustment.
(During adjustment, indications appear on
the LCD panel in the menu operation/
setting display 2.)
Button Output signal
R R signal (The G and B signals can be selected at
the same time.)
GG signal (The R and B signals can be selected
at the same time.)
B B signal (The R and G signals can be selected at
the same time.)
SEQ WFM connector: R, G and B sequence signal
PIX connector: signal selected last
ENC Composite video signal

7
2Menu Operation/Setting Display Section
INDICATION
DETAIL GAMMA
PAGE
KNEE FLARE RECALL STORE
SHADING MATRIX FILTER
PREV
NEXT
LENSE PAN/TILT SKIN
GATE SKIN DETAIL
TLCS
BRIGHT
CONTR
AUTO
FUNCTION
BLACK
STRETCH
DYNA
LATITUDE
DIAG OTHERS
1Menu selection buttons
2LCD panel
3INDICATION button
4PAGE buttons
5Setting knobs
1Menu selection buttons
Press one of these buttons to have the corresponding
menu displayed on the LCD panel 2.
For details, see “Basic Menu Operations” page 14.
2LCD panel
Displays menus, messages reporting the progress or
results of operations, current settings, etc.
3INDICATION button
Press this button to change indications on the LCD
panel in the following order:
Current settings of detail level, gamma and knee n
Current setting of white balance nCurrent setting of
black balance nCurrent setting of flare (when the
FLARE button in the black balance adjustment/flare
correction block is lit) nNo indications and back to
current settings of detail level, gamma and knee
If you press this button while a menu is indicated, the
menu indication disappears and then current settings of
detail level, gamma and knee appear.
4PAGE buttons
Press the PREV button to display the previous menu
page or the NEXT button to display the next menu
page. (Each press goes back or forward one page.)
Pressing both buttons simultaneously displays the first
menu page.
For details, see “Basic Menu Operations” on page 14.
5Setting knobs
Use these knobs to change the settings in various
menus.
For details, see “Basic Menu Operations” on page 14.
6CONTR (contrast) knob
Adjusts the contrast of the LCD panel 2display.
7BRIGHT (brightness) knob
Adjusts the brightness of the LCD panel 2display.
8Setting buttons
Use these buttons to select functions or settings in
various menus.
For details, see “Basic Menu Operations” on page 14.
6CONTR knob
7BRIGHT knob
8Setting buttons

Location and Function of Parts
8
REMOTE CONTROL PANEL
DETAIL
WHITE
IRIS
BLACK/FLARE
MASTER BLACK
KNEE
MASTER
GAMMA
SHUTTER MASTER GAIN
C.SCAN
ON/OFF
DPR
AUTO
AUTO
BLACK
AUTO
AUTO
CALL
IRIS/M.BLACK
LINK
EXT
FLARE
MANUAL
PRESET MANUAL
SKIN
DETAIL
SENS
COARSE
CLOSE OPEN
3Paint section and CALL button
1Master gain setting block
Includes the buttons, a display window, and a DPR
indicator described below.
The setting that can be performed via this block differ
according to the connected camera.
When using a DXC-D30/D30P: Select the gain
value from –3, 0, +3, +6, +9, +12, +18, +24 dB,
and HYPER GAIN. (HYPER GAIN equals 30 dB
+ DPR, but the DPR indicator will not light if it is
selected.)
When using a DXC-637 series camera: Select the
gain level from LOW, MID and HIGH. The gain
value corresponding to each value is set by
camera.
Name Operation
4(up) button Each press of this button raises the
setting value by one step.
When using the DXC-D30/D30P, press
the up and down buttons simultaneously
to set the master gain to 0 dB.
$(down) button Each press of this button lowers the
setting value by one step.
When using the DXC-D30/D30P, press
the up and down buttons simultaneously
to set the master gain to 0 dB.
DPR button and
indicator When the master gain is set at 18 or 24 dB, press this button to activate DPR
function a).
Display window Displays the current master gain value.
a)DPR (Dual Pixel Readout) function: When this function is
active, CCD output signal readout is performed one pair
of two adjacent pixels after another instead of one pixel
after another. Sensitivity increases (but resolution
decreases) as signal readout take place at a time for the
two pixels in each pair.
2SKIN DETAIL button (only when using DXC-
D30/D30P)
Press to perform skin detail correction. (The button
will light when pressed.)
For details, see “Skin Detail Correction/Skin Matrix
Adjustment (for DXC-D30/D30P Only) ”on page 25.
1Master gain setting block
2SKIN DETAIL button
3Knee correction block
4White balance adjustment
block
5Black balance adjustment/
flare correction block
6Iris adjustment block
7IRIS/M.BLACK LINK button
8CALL button
0MASTER GAMMA knob
!¡ DETAIL knob
!™ Shutter setting block
9Master black adjustment
block

9
When using the DXC-637 series:
a)To manually adjust the black balance, use the BLACK/
FLARE R, G, and B knobs. See “5Black balance
adjustment/flare correction block” on next page.
3Knee correction block
Press the AUTO button to activate the auto knee
circuit. The button will light when pressed. However,
when the DynaLatitude function is set to on (see
DYNA LATITUDE on page 16), the auto knee circuit
automatically activates and the AUTO button lights.
When the AUTO button is not lit and “VARIABLE” is
selected in the KNEE menu, you can use the knob in
this block to manually adjust the knee point value.
To use the preset value, select “PRESET” in the
KNEE menu.
For details of the KNEE menu, see page 15 (for DXC-D30/
D30P) or 19 (for DXC-637 series).
4White balance adjustment block
Use the following buttons and knobs to automatically
or manually adjust the white balance. The buttons and
knobs operate differently according to the connected
camera.
When using the DXC-D30/D30P:
a)ATW (Auto Tracing White balance) function: This
function automatically adjusts the white balance when
lighting conditions change.
Name Operation
AUTO (auto
adjust) button Press this button (which lights when pressed) to perform automatic white and
black balance adjustments.
While the ATW function is operating
(see
the ATW in the AUTO FUNCTION menu
on page 20)
, only automatic black
balance adjustment is performed.
PRESET button Press this button (which lights when
pressed) to perform automatic black
balance adjustment with using the preset
white balance settings.
While the ATW function is operating
(see
the ATW in the AUTO FUNCTION menu
on page 20)
, only automatic black
balance adjustment is performed.
MANUAL button When this button is pressed and lit, the
white and black balance can be manually
adjusted.a) The white balance cannot be
manually adjusted while the ATW
function is operating
(see the ATW in the
AUTO FUNCTION menu on page 20)
.
WHITE (white
balance) R
knob
When the MANUAL button is lit, use this
knob to adjust the R signal gain.
WHITE (white
balance) B knob When the MANUAL button is lit, use this knob to adjust the B signal gain.
Name Operation
AUTO (auto
adjust) button Press this button (which lights when pressed) to perform automatic white
balance adjustment.
This button does not operate while the
ATW functiona) is operating.
(See the
ATW in the AUTO FUNCTION menu on
page 16.)
PRESET
button Press this button (which lights when pressed) to use the preset white balance
settings.
This button does not operate while the
ATW function is operating.
(See the ATW
in the AUTO FUNCTION menu on page
16.)
MANUAL button When this button is pressed and lit, the
white balance can be manually adjusted.
This button does not operate while the
ATW function is operating.
(See the ATW
in the AUTO FUNCTION menu on page
16.)
WHITE (white
balance) R
knob
When the MANUAL button is lit, use this
knob to adjust the R signal gain.
WHITE (white
balance) B knob When the MANUAL button is lit, use this
knob to adjust the B signal gain.

Location and Function of Parts
10
5Black balance adjustment/flare correction block
Use the buttons and knobs described below to perform
automatic or manual adjustment of black balance and
to perform flare correction.
The buttons and knobs operate differently according to
the connected camera.
When using the DXC-D30/D30P:
When using the DXC-637 series:
6Iris adjustment block
Use the following buttons and knobs to automatically
or manually adjust the iris setting.
Name Operation
FLARE button Press this button (which lights when
pressed) to perform flare correction using
the BLACK/FLARE knobs when it is
allowed in the FLARE menu
(see page
15)
.
BLACK AUTO
(black balance
auto adjust)
button
Press this button (which lights when
pressed) to perform automatic black
balance adjustments.
BLACK
MANUAL (black
balance manual
adjust) button
When this button is pressed and lit, the
black balance can be manually adjusted.
BLACK FLARE
R knob When the BLACK MANUAL button is lit, use this knob to adjust the R signal level.
When the FLARE button is lit, use this
knob to perform flare correction of the R
signal.
BLACK FLARE
B knob When the BLACK MANUAL button is lit, use this knob to adjust the B signal level.
When the FLARE button is lit, use this
knob to perform flare correction of the B
signal.
BLACK FLARE
G knob When the BLACK MANUAL button is lit, use this knob to adjust the G signal level.
When the FLARE button is lit, use this
knob to perform flare correction of the G
signal.
Name Operation
FLARE button This button does not operate (because
manual flare correction is disallowed on
the DXC-637 series).
BLACK AUTO
(black balance
auto
adjustment)
button
This button does not operate.
BLACK
MANUAL (black
balance manual
adjustment)
button
This button does not operate.
BLACK FLARE
R knob When the MANUAL button in the white balance adjustment block 4is lit, use
this knob to adjust the R signal level.
BLACK FLARE
B knob When the MANUAL button in the white balance adjustment block 4is lit, use
this knob to adjust the B signal level.
BLACK FLARE
G knob When the MANUAL button in the white balance adjustment block 4is lit, use
this knob to adjust the G signal level.
Name Operation
AUTO (auto
adjust) button Press this button (which lights when pressed) to activate auto iris function.
EXT (extender)
indicator Lights when a lens extender is used. (This indicator does not operate when
using the DXC-637 series).
Display window The current F-stop value is shown in this
window. (When using the DXC-637
series, only manual adjustment values
are shown.)
IRIS knob Use this knob to manually adjust the iris
when the AUTO button is not lit. When
the AUTO button is lit, use this knob to
manually adjust the iris override.
COARSE (iris
coarse adjust)
knob
Use this knob to coarsely adjust the iris
when the AUTO button is not lit. If the
AUTO button is lit, use this knob to
manually adjust the iris override.
SENS
(sensitivity
adjust) knob
Use this knob to adjust how many
rotations of the IRIS knob are required to
set the full iris range from open to closed.
MIN: About four rotations
CENTER: About one rotation
MAX: About 1/2 rotation

11
!™ Shutter setting block
Use the buttons described below to set the shutter’s
operation mode, speed, and CLS (clear scan)
frequency.
7IRIS/M.BLACK LINK (iris/master black
adjustment link) button
Press this button (which lights when pressed) to
perform linked adjustments of iris and master black for
several cameras.
For details, see “Adjusting the Iris and Master Black of
Multiple Cameras at One Time” on page 27.
8CALL button
Press this button (which lights when pressed) to light
the CALL button and red tally indicator on the camera,
CA, and CCU. This button lights when the unit
receives a tally signal from the CA or CCU.
9Master black adjustment block
Use the knob to adjust the master black. During
adjustment, adjustment value is shown in the display
window here.
0MASTER GAMMA knob
Use this knob to adjust the master gamma. During
adjustment, adjustment value is shown on the LCD
panel in the menu operation/setting display section 2.
!¡ DETAIL knob
Use this knob to adjust the master detail. During
adjustment, adjustment value is shown on the LCD
panel in the menu operation/setting display section 2.
Name Operation
C. SCAN (clear
scan) button Press this button (which lights when pressed) to set the CLS frequency. This
button does not operate when the TLCS
(total level control system) is operating.
SHUTTER ON/
OFF button Press this button (which lights when pressed) to set the shutter speed. This
button does not operate when the
camera’s TLCS is operating.
4(up) button Each press of this button raises the CLS
frequency or shutter speed setting value
by one step. (The CLS frequency value
changes continuously while the button is
being pressed.)
Press the up and down buttons
simultaneously to select the minimum
value.
$(down) button Each press of this button lowers the CLS
frequency or shutter speed setting value
by one step. (The CLS frequency value
changes continuously while the button is
being pressed.)
Press the up and down buttons
simultaneously to select the minimum
value.
Display window Displays the current CLS frequency when
the C.SCAN button is lit.
Displays the current shutter speed when
the ON button is lit.

Location and Function of Parts
12
Menu Operations
Displaying menus
Press one of the menu selection buttons to have the
corresponding menu displayed in the LCD panel. To
access the AUTO SKIN menu (see peges 17 and 19),
however, press the AUTO SETUP SKIN DETAIL
button (see page 6).
The menus that correspond to the buttons are listed
below.
Most of menus consist of several pages which are
divided into two types: normal setting pages and
advanced setting pages. This unit is allowed to access
only normal setting pages when it is powered on.
To access advanced setting pages, follow the
procedure described below and set the unit to the
advanced setting mode.
Setting the unit to the advanced setting
mode
1Set the OPERATE knob to “PAINT”.
“ADV>” appears on the LCD panel.
2Set the OPERATE knob to “FULL” while pressing
down the setting button on the right of the
“ADV>” indication.
Note
During menu operations, the message “ITEM NOT
AVAILABLE” appears on the LCD panel under the
following situations. Wait until the message
disappears and perform correct operations.
•When using the DXC-D30/D30P, trying to access a
menu consisting of only advanced setting pages (such
as the GAMMA or SHADING menu) without setting
the unit to the advanced setting mode
•When using the DXC-637 series, pressing a menu
selection button which does not operate for the DXC-
637 series (such as the DETAIL button)
ADV>
PAINT
OPERATION
1,2
2

13
a) When the unit is set to the advanced setting mode, both the normal and advanced settings can be performed.
b) The menu title is “BLACK STR”.
c) This button is not a menu selection button (see 6AUTO SETUP buttons on page 6). The menu title is “AUTO SKIN”.
Button/menu title Principle settings
When using DXC-D30/D30P
Normal settingsa) Advanced settingsa)
When using DXC-637 series
DETAIL Detail correction-1 (page 15) • Detail correction-2 (page 17)
• Aperture correction (page
17)
–
GAMMA – Gamma correction (page 18) –
KNEE Knee correction (page 15) White clip circuit on/off (page
18) Knee correction (page 19)
FLARE Flare correction (page 15) – –
RECALL Recall scene file/setup file
(page 15) – Recall scene file (page 19)
STORE Store scene file/setup file
(page 15) – Store scene file (page 19)
SHADING – Shading correction (page 18) –
MATRIX • Matrix adjustment-1
(page 16)
• Skin matrix adjustment
(page 16)
Matrix adjustment-2 (page 18) Matrix adjustment mode (page 19)
FILTER Filter position indication (page
16) ––
LENS Focus/zoom control (page 16) – Focus/zoom control (page 20)
PAN/TILT Pan/tilt operation (page 16) – Pan/tilt operation (page 20)
SKIN GATE Skin gate setting-1 (page 16) Skin gate setting-2 (page 18) –
SKIN DETAIL Skin detail correction (page
16) ––
DYNA LATITUDE DynaLatitude function (page
16) ––
BLACK STRETCHb) Black stretch/compress-1
(page 16) Black stretch/compress-2 (page 18) –
TLCS (total level
control system) TLCS function (page 16) – –
AUTO FUNCTION • Auto iris mode (page 16)
• ATW function (page 16) – • Auto iris mode (page 20)
• ATW function (page 20)
DIAG (diagnosis) – Displaying camera self-
diagnosis results (page 18) –
OTHERS • EVS/ECS (page 16)
• Camera ID (page 16)
• Clock indication (page 17)
• Center marker (page 17)
• Safety zone marker (page
17)
• Data transfer (page 18)
• 1 kHz-tone signal (page 18)
• Color bars type (page 18)
• Screen mode display
(page 18)
• Items set by command link
operation (page 19)
• EVS (page 20)
• Title (page 20)
• Clock indication (page 20)
Advanced settingsa)
• Data transfer (page 20)
• Items set by command link
operation (page 20)
AUTO SETUP SKIN
DETAILC) • Automatic designation of the skin gate (page 17)
• Skin gate setting-1 (page 17)
Skin gate setting-2 (page 19) –

Menu Operations
14
DETAIL
FREQ H/V
M +01
Adjustment value set
by FREQ knob Adjustment value set by H/V knob
FREQ knob H/V knob
Basic Menu Operations
Changing pages
Press a menu selection button to display the first page
of the corresponding menu.
If your desired item is not on the first page, press the
NEXT button to go to the next page. You can also
change the pages by pressing the menu selection
button repeatedly.
To go back one page, press the PREV button.
Pressing both buttons simultaneously recalls the first
menu page.
When the unit is set to the advance setting mode (see
page 12), the advanced setting pages can be displayed
in addition to the normal setting pages.
Using the knobs and buttons
Three knobs and four buttons are used to make settings
via menu operations.
The following figure shows how these knobs and
buttons are used.
How to use the buttons
Functions of the buttons vary according to menu.
Menu title
Example: KNEE menu (KNEE MODE setting
page)
In this case, the upper left button operates as PRESET
button, and the lower left button operates as
VARIABLE button. The PRESET button is lit because
the preset mode is currently selected.
Press the VARIABLE button to select the variable
mode.
How to use the knobs
Functions of the knobs vary according to menu.
Example: DETAIL menu
In this case, the left knob operates as FREQ
(frequency) knob, and the right knob operates as H/V
knob.
To set the frequency, turn the FREQ knob. To set the
H/V, turn the H/V knob.
KNEE
<VARIABLE
MANUAL KNEE
<PRESET
Setting buttons
VARIABLE button: Not lit
PRESET button: Lit
<A B>
<C D>
MENU TITLE

15
(continued)
Note
The adjustment values displayed on the LCD panel
may be relative values (not real values). Slight turn of
a knob sometimes causes undesirable sudden change
of values.
Even in the case that they are real values, values may
change while they are transferred to the camera.
Menu Contents
The contents of each menu, which vary according to
the camera, are listed in the table below.
Menu title Knob/button Setting or operation
DETAIL FREQ knob: LL/M/H/HH Boost frequency for the detail correction
H/V knob: –99 to 00 to 99 Ratio of V (vertical) detail to H (horizontal) detail (As the
value becomes larger, the V detail ratio increases.)
KNEE (1/2) PRESET button Setting the knee point (level at which the knee correction
starts) and knee slope (amount of the knee correction)
manually using the preset values
(see page 9).
VARIABLE button Setting the knee point and knee slope manually (see page
9).
Values can be set by the knob in the knee correction
block or the POINT and SLOPE knobs on page 2/2 of the
KNEE menu.
KNEE (2/2) POINT knob: –99 to 00 to 99 Knee point (As the value becomes larger, the start level
lowers, which enhances the knee correction effect.)
SLOPE knob: –99 to 00 to 99 Knee slope
FLARE ON/OFF buttons Select whether or not you will perform flare correction.
RED/GREEN/BLUE knobs: –99 to 00 to
99 Amounts of flare correction for R, G and B signals.
RECALL (1/2)
See page 23 for
details.
SCENE F. RECALL button Press to recall a scene file stored in this unit’s memory.
SEL knob: USR01 to USR16 Select a scene file that you will recall.
RECALL (2/2)
See page 24 for
details.
SETUP F. RECALL button Press to recall a setup file stored in the camera’s memory.
SEL knob: PRE1 to PRE5 and USR1 to
USR3 Select a setup file that you will recall.
When using the DXC-D30/D30P
The list for the case of using the DXC-637 series is on page
19.
Normal setting pages
Underlined values or settings are selected at the
shipping of the camera.
See page 17 for advanced setting pages.
STORE (1/2)
See page 23 for
details.
SCENE F. STORE button Press to store a scene file onto this unit’s memory. Use
the SEL knob to number the file.
CUR knob Move the cursor to enter a file name (eight characters).
SEL knob: USR01 to USR16 Select a number for the file that you will store.
CHR knob: Select characters to enter a file name.
STORE (2/2)
See page 24 for
details.
SETUP F. STORE button Press to store a setup file onto the camera’s memory. Use
the SEL knob to number the file.
CUR knob Move the cursor to enter a file name (eight characters).
SEL knob: USR1 to USR3 Select a number for the file that you will store.
CHR knob: Select characters to enter a file name.

Menu Operations
16
Menu title Knob/button Setting or operation
MATRIX (2/2: SKIN) ON/OFF buttons Select whether or not you will perform matrix adjustment of
the skin gate area.
SAT/HUE knob: –99 to 00 to +99 Saturation and hue of the skin gate area
FILTER – Displays the current filter position (1, 2, 3, or 4).
LENSa) ON/OFF buttons Activate optional control function 1 or not.
FOCUS knob: –99 to 00 to +99 Focus
ZOOM knob: –99 to 00 to +99 Zoom
PAN/TILTb) ON/OFF buttons Activate optional control function 2 or not.
PAN knob: –99 to 00 to +99 Rotation of the tripod head
TILT knob: –99 to 00 to +99 Tilt of the tripod head
SKIN GATE (1/2) ON/OFF buttons Select whether or not you will display the skin gate area
(color range designated as skin tone) using the PIX output
from the CCU-TX7/7P.
SKIN GATE (2/2:
SIZE) R-Y knob: –99 to 00 to +99 R–Y range of the skin gate area
B-Y knob: –99 to 00 to +99 B–Y range of the skin gate area
SKIN DETAIL LEVEL knob: –99 to 00 to +99 Amount of skin detail correction (As the value becomes
larger, the detail level lowers.)
DYNA LATITUDE OFF button Do not use the DynaLatitude function.
LOW/MID/HI buttons Select the DynaLatitude level.
BLACK STR LEVEL knob: –99 to 00 to +99 Black stretch level
TLCS ON/OFF button Select whether or not you will use the TLCS (total level
control system) function.
AGC knob: F5.6/F4/F2.8/F1.8 F-stop value at which the auto iris control is switched to the
AGC (auto gain control)
GAIN knob: 0/3/6/9/12dB Upper limit value for the AGC
AE knob: F5.6/F8/F11/F16 F-stop value at which the auto iris control is switched to the
AE (auto exposure).
AUTO FUNCTION
(1/2: ATW) ON/OFF buttons Select whether or not you will use the ATW (auto tracing white balance) function.
MATRIX (1/2) ON/OFF buttons Select whether or not you will perform linear matrix
adjustment.
SAT/HUE knobs: –99 to 00 to +99 Saturation and hue
GATE SIZE knob: –99 to 00 to +99 R–Y and B–Y ranges of the skin gate area (for setting
each range to the same value at the same time)
AUTO FUNCTION
(2/2: A.IRIS MODE) STD button Standard auto iris mode
SPOT.L button Auto iris mode for shooting spot-lit subjects
AI button Intelligent auto iris mode
BACK.L button Auto iris mode for shooting back-lit subjects
OTHERS (1/6:
SHUTTER) EVS button Set the shutter to the EVS mode. If you do not use the EVS mode, set the C.SCAN button or SHUTTER ON/OFF button
to ON in the shutter setting block !™
(see page 11).
OTHERS (2/6: CAM ID
SET) CUR knob Move the cursor to enter a camera ID (eight characters).
CHR knob Select characters to enter a camera ID (alphanumerics,
symbols, and space).
OTHERS (3/6: CAM ID
IND) ON/OFF buttons Select whether or not you will display a camera ID.

17
a) Lens control requires a focus and zoom servo interface unit (not supplied) and camera adaptor interface unit for lens control
(not supplied).
b) Use an electrical tripod head for remote pan/tilt operation. A camera adaptor interface unit for tripod head control (not
supplied) is required.
c) This menu is recalled with the AUTO SETUP SKIN DETAIL button on page 6.
Menu title Knob/button Setting or operation
AUTO SKINc)
Menu title Knob/button Setting or operation
DETAIL (2/8) ON/OFF buttons Select whether or not you will perform detail correction.
DETAIL (3/8) CRISP knob: –99 to 00 to +99
(Factory setting: –96) Crispening level (at which details of noise signals are
removed)
LEV DEP knob: –99 to 00 to +99
(Factory setting: 63) Level dependence (level at which the detail signal starts being suppressed.)
V-DTL LIMIT knob: –99 to 00 to +99
(Factory setting: –71) Limit value of the vertical detail
DETAIL (4/8) HIGHLIGHT knob: –99 to 00 to +99 Highlight detail (amount of detail suppression to highlight
areas)
AFTER GAMMA knob: –99 to 00 to +99
(Factory setting: –71) Amount of detail added after gamma correction
DETAIL (5/8:
APERTURE) ON/OFF buttons Select whether or not you will perform aperture correction.
LEVEL knob: –99 to 00 to +99 Amount of aperture correction
DETAIL (6/8: KNEE
APERTURE) ON/OFF buttons Select whether or not you will perform detail correction to the levels higher than the knee point.
LEVEL knob: –99 to 00 to +99
(Factory setting: 51) Amount of the detail correction to the levels higher than the knee point.
DETAIL (7/8: CROSS
COLOR SUPPRESS) CROSS COLOR SUPPRESS knob: –99 to 00 to +99 Amount of cross color suppression
DETAIL (8/8: COMB
FILTER) RED ON/OFF buttons Select whether or not you will activate the red comb filter in the detail circuit. If you select OFF, clarity improves but
cross color increases.
GRN ON/OFF buttons Select whether or not you will activate the green comb filter
in the detail circuit. If you select OFF, clarity improves but
cross color increases.
GAMMA (1/2) ON/OFF buttons Select whether or not you will perform gamma correction.
RED/BLUE knobs: –99 to 00 to +99 Amount of R and B gamma
MAST knob: –99 to 00 to +99 Amount of master gamma
Advanced setting pages
For each menu, the advanced setting pages as
described below are displayed in addtition to the
normal setting pages (listed on page 15). In this menu
display mode, the page numbering system is serial,
that is, the total number refers to the sum of both
normal and advanced setting pages.
Underlined values or settings are selected as factory
settings for the camera. (Factory settings are otherwise
indicated in some menus.)
(continued)
OTHERS (4/6: CLOCK
IND) CAM button Display the date/time.
OFF button Do not display the date/time.
BARS button Display the date/time only when camera color bars are
displayed.
OTHERS (5/6:
CENTER MARKER) ON/OFF buttons Select whether or not you will display the center marker.
OTHERS (6/6:
SAFETY ZONE) 80%/90% buttons Select safety zone marker size.
OFF button Do not display the safety zone marker.
GATE SIZE knob: –99 to 00 to +99 R–Y and B–Y ranges of the skin gate area (for setting
each range to the same value at the same time)

Menu Operations
18
GAMMA (2/2: GAMMA
INIT GAIN) 3.5/4.0 buttons Select the slope of the initial part of the gamma curve for low-brightness.
KNEE (3/3: WHITE
CLIP) ON/OFF buttons Select whether or not you will activate the white clip circuit.
LEVEL knob: –99 to 00 to +99 Amount of white clip (As the value becomes larger, the
output level lowers.)
SHADING (WHITE V
SAW) RED/GREEN/BLUE knobs: –99 to 00 to +99 Amount of vertical white shading for R, G and B signals
R-G knob: –99 to 00 to +99
(Factory setting: +65 for DXC-D30 or
+38 for DXC-D30P )
MATRIX (3/4) R–G level of the linear matrix
B-G knob: –99 to 00 to +99
(Factory setting: +28 for DXC-D30 or
+22 for DXC-D30P )
R–B level of the linear matrix
G-R knob: –99 to 00 to +99
(Factory setting: +31 for DXC-D30 or
+12 for DXC-D30P )
G–R level of the linear matrix
Menu title Knob/button Setting or operation
MATRIX (4/4) G-B knob: –99 to 00 to +99
(Factory setting: +32 for DXC-D30 or
+15 for DXC-D30P )
G–B level of the linear matrix
B-R knob: –99 to 00 to +99
(Factory setting: +22 for DXC-D30 or
+12 for DXC-D30P )
B–R level of the linear matrix
B-G knob: –99 to 00 to +99
(Factory setting: +6 for DXC-D30 or
+15 for DXC-D30P )
B–G level of the linear matrix
SKIN GATE (3/3) POSI R-Y/B-Y knobs: –99 to 00 to +99 R–Y and B–Y levels of the skin gate
POINT 1 knob: –99 to 00 to +99
(Factory setting: –39)
BLACK STR (2/3:
STRETCH LEVEL) Lower limit of the signal levels which activate the black stretch function
POINT 2 knob: –99 to 00 to +99
(Factory setting: –41) Upper limit of the signal levels which activate the black stretch function
BLACK STR (3/3:
COMPRESS LEVEL) POINT 1 knob: –99 to 00 to +99 (Factory setting: –77) Lower limit of the signal levels which activate the black compress function
POINT 2 knob: –99 to 00 to +99 Upper limit of the signal levels which activate the black
compress function
DIAG RESET button Reset (erase) the camera’s self-diagnosis data.
REQ button Press to request camera’s self-diagnosis data. If an
abnormality has been detected, the data will be transferred
to the RCP and displayed. Change the menu page to
change data indications. (If there is no abnormality, no data
will be displayed.)
OTHERS (2/11: COPY
TO SLAVES)
For details, see page
27.
COPY TO SLAVES button Copy the settings of the master unit to the slave units.
OTHERS (8/11: TONE/
BARS TYPE) ON/OFF buttons Select whether or not you will allow the camera to output a
1-kHz audio signal when color bars are displayed.
BARS TYPE knob: SMPTE/SNG/FULL
FIELD 75%/FULL FIELD 100%(For
DXC-D30) or SPLIT/SNG/EBU 75%/
EBU 100% (For DXC-D30P)
Select color bars output from the camera (not from the
CCU-TX7/7P).
OTHERS (9/11:
SCREEN MODE) – Display the screen mode (4:3).

19
a) This menu is recalled with the AUTO SETUP SKIN DETAIL button on page 6.
Menu title Knob/button Setting or operation
OTHERS (10/11:
COMM LINK ITEM-1)
For details, see page
27.
GAIN button Activate command link operation of gain setting among
several cameras.
SHUTTER button Activate command link operation of shutter setting among
several cameras.
OTHERS (11/11:
COMM LINK ITEM-2)
For details, see page
27.
WHITE button Activate command link operation of manual white balance
adjustment among several cameras.
BLACK button Activate command link operation of manual black balance
adjustment among several cameras.
FLARE button Activate command link operation of manual flare correction
among several cameras.
AUTO SKIN (2/3)a) ON/OFF buttons Select whether or not you will display the window specifying
the skin gate on the viewfinder screen. (When the AUTO
SKIN menu is recalled, the ON button is automatically
selected.)
HI-POSI knob: –99 to 00 +99 Horizontal position of the window
V-POSI knob: –99 to 00 +99 Vertical position of the window
AUTO SKIN (3/3)a) ON/OFF buttons Select whether or not you will display the window specifying
the skin gate on the viewfinder screen. (When the AUTO
SKIN menu is recalled, the ON button is automatically
selected.)
WIDTH knob: –99 to 00 +99 Width of the window
HEIGHT knob: –99 to 00 +99 Height of the window
Underlined values or settings are selected at the
shipping of the camera.
When using the DXC-637 series
Only the OTHERS menu contains the advanced setting
pages.
Menu title Knob/button Setting or operation
KNEE (1/2) PRESET button Setting the knee point (level at which the knee correction
starts) manually using the preset values
(see page 9).
VARIABLE button Setting the knee point manually (see page 9) . A value can
be set by the knob in the knee correction block or the
MANUAL KNEE knob on page 2/2 of the KNEE menu.
KNEE (2/2) MANUAL KNEE knob:
–99 to 00 to +99 Knee point (As the value becomes larger, the start level
lowers, which enhances the knee correction effect.)
RECALL
See page 23 for
details.
SCENE F. RECALL button Press to recall a scene file stored in this unit’s memory.
SEL knob: USR01 to USR16 Select a scene file that you will recall.
STORE
See page 23 for
details.
SCENE F. STORE button Press to store a scene file onto this unit’s memory. Use the
SEL knob to number the file.
CUR knob Move the cursor to enter a file name (eight characters).
SEL knob: USR01 to USR16 Select a number for the file that you will store.
CHR knob: Select characters to enter a file name.
MATRIX STD/FL/H.SAT buttons Select color matrix adjustment mode.
STD: standard
FL: for shooting under fluorescent lighting
H.SAT: high saturation (increasing the saturation of primary
colors)
(continued)

Menu Operations
20
a)Lens control requires a focus and zoom servo interface unit (not supplied) and camera adaptor interface unit for lens contrtol
(not supplied).
b)Use an electrical tripod head for remote pan/tilt operation. A camera adaptor interface unit for tripod head control (not
supplied) is required.
LENSa) ON/OFF buttons Activate optional control function 1 or not.
FOCUS knob: –99 to 00 to +99 Focus
ZOOM knob: –99 to 00 to +99 Zoom
PAN/TILTb) ON/OFF buttons Activate optional control function 2 or not.
PAN knob: –99 to 00 to +99 Rotation of the tripod head
TILT knob: –99 to 00 to +99 Tilt of the tripod head
AUTO FUNCTION
(1/2: ATW) ON/OFF buttons Select whether or not you will use the ATW (auto tracing white balance) function.
AUTO FUNCTION
(2/2: A.IRIS MODE) STD button Standard auto iris mode
SPOT.L button Auto iris mode for shooting spot-lit subjects
BACK.L button Auto iris mode for shooting back-lit subjects
Menu title Knob/button Setting or operation
OTHERS (1/3: EVS) EVS button Set the shutter to the EVS mode. If you do not use the EVS
mode, set the C.SCAN button or SHUTTER ON/OFF button
to ON in the shutter setting block !™
(see page 11).
OTHERS (2/3: TITLE
IND) ON/OFF buttons Select whether or not you will display the title set on the camera.
OTHERS (3/3: CLOCK
IND) ON/OFF buttons Select whether or not you will display the date and time.
Advanced setting pages (OTHERS menu)
The following advanced setting pages are displayed in
addition to the normal setting pages. In this menu
display mode, the page numbering system is serial,
that is, the total number refers to the sum of both
normal and advanced setting pages.
Menu title Knob/button Setting or operation
OTHERS (4/6: COPY
TO SLAVES)
For details, see page
27.
COPY TO SLAVES button Copy the settings of the master unit to the slave units.
OTHERS (5/6: COMM
LINK ITEM-1)
For details, see page
27.
GAIN button Activate command link operation of gain setting among
several cameras.
SHUTTER button Activate command link operation of shutter setting among
several cameras.
OTHERS (6/6: COMM
LINK ITEM-2)
For details, see page
27.
WHITE button Activate command link operation of manual white balance
adjustment among several cameras.
BLACK button Activate command link operation of manual black balance
adjustment among several cameras.
