X10 SR227 User manual

Live
Neutral
Black
White
Green
A
I
EM
••
••
1
9
513
••
••
CONTROLLED
Ground
X10 Wireless Technology, Inc. Limited One Year Warranty
X10.com, a division of X10 Wireless Technology, Inc. (X10) warrants X10
products to be free from defective material and workmanship for a period of
one (1) year from the original date of purchase at retail. X10 agrees to repair
or replace, at its sole discretion, a defective X10 product if returned to X10
within the warranty period and with proof of purchase. If service is required
under this warranty:
Call 1-800-442-5065, visit www.x10.com, or e-mail [email protected].
For help or more information on setup, please visit:
http://www.x10.com/support
SR227-11/02
Check Out our Web site at:
http://www.x10.com
For more information on X10 products and
special promotional offers.
Wall Receptacle Module, Model SR227
The Wall Receptacle Module is designed to control unrestricted loads up to 15
Amps. It has two outlets, the upper one is X10 controlled and the lower one is
always on. The Wall Receptacle Module does not respond to All Lights On.
Installation
• Turn the power off at the circuit
breaker panel.
• Remove the existing wall plate and
unscrew the receptacle from its box.
• Disconnect the wiring to the existing
receptacle.
• Connect the black wire on the Wall Receptacle Module to Live (black wire),
connect the white wire on the Wall Receptacle Module to Neutral (white wire),
and connect the green wire on the Wall Receptacle Module to ground (or to a
metal wall box) using the wire nuts provided. Refer to the diagram above.
• Refit the Wall Receptacle Module in the wall box and finish off with the trim
plate provided. Turn the power back on at the circuit breaker panel.
Setting up the Wall Receptacle Module
• Using a small screwdriver, set the Unit Code dial to an unused code that can be
controlled from your X10 Controller(s).
• Set the House Code dial to the same letter as your X10 controller(s).
• Plug an appliance (or a lamp) into the top outlet.
Testing the Wall Receptacle Module
Make sure the appliance’s switch is on. Plug an X10 Controller into the bottom
outlet. Press the On and Off buttons on the Controller that correspond to the
Unit Code setting on the Wall Receptacle Module. If the appliance turns on and
off you can unplug the Controller and move it to its permanent location. If you
can’t control the Wall Receptacle Module with the Controller in another
location, try several locations, or visit http://www.x10.com/support for help.
