XAVi X7968r User manual

User Manual
X7968r
Broadband Wireless Gateway
ADSL2+ Bridge/Router
with integrated 802.11b/g WLAN AP
and 4-port Fast Ethernet switch
Issue 1.0
16th Jan. 2008

I
T
Ta ab bl le e
o
of f
C
Co on nt te en nt ts s
1Introduction.................................................................................................1
Features................................................................................................................................1
Device Requirements...........................................................................................................2
Using this Document.............................................................................................................2
Notational conventions.................................................................................................................. 2
Typographical conventions............................................................................................................2
Special messages..........................................................................................................................2
2Getting to know the device........................................................................3
Parts Check...........................................................................................................................3
X7968r Front Panel...............................................................................................................4
X7968r Rear Panel...............................................................................................................5
3Connecting your device.............................................................................6
Connecting the Hardware.....................................................................................................6
Step 1. Connect the DSL cable and optional telephone line ........................................................7
Step 2. Connect the Ethernet cable ..............................................................................................7
Step 3. Attach the power connector.............................................................................................. 7
Step 4. Configure your Ethernet PCs............................................................................................7
Step 5. Install a Wireless card and connect Wireless PCs........................................................... 7
Next step........................................................................................................................................7
4Getting Start with the Web pages.............................................................8
Accessing the Web pages....................................................................................................8
Commonly used buttons.....................................................................................................10
Help information..................................................................................................................11
Testing your Setup..............................................................................................................11
Default device settings........................................................................................................12
5Home..........................................................................................................13
Overview Page....................................................................................................................13
Basic Overview............................................................................................................................13
Advanced Overview..................................................................................................................... 14
Status – Routing Table................................................................................................................16
Status – DHCP Table..................................................................................................................16
Status – Wireless Connection.....................................................................................................16
Status – ARP Table.....................................................................................................................17
Status – Traffic Statistics .............................................................................................................17
Trouble Shooting.................................................................................................................18
6Configuration ............................................................................................19

X7968r User’s Guide
II
Quick Setup.........................................................................................................................19
Configuring ATM PVC.................................................................................................................20
Configuring the Connection Type................................................................................................20
Configuring the WAN IP Settings if PPP over ATM (PPPoA) or PPP over Ethernet (PPPoE).. 20
Configuring the WAN IP Settings if RFC1483 (Routed) .............................................................23
Configuring the WAN IP Settings if Bridging...............................................................................24
Wireless Network................................................................................................................25
Basic Settings..............................................................................................................................25
Advanced Settings....................................................................................................................... 27
WDS Settings ..............................................................................................................................28
MAC Filtering...............................................................................................................................29
Registrar.......................................................................................................................................29
Internet Connection Page...................................................................................................30
Connections.................................................................................................................................30
ADSL Configuration.....................................................................................................................31
MAC Spoofing..............................................................................................................................32
Local Network (LAN) Page.................................................................................................33
IP Address ...................................................................................................................................33
DNS Client...................................................................................................................................34
DNS Relay...................................................................................................................................34
DNS Local Host...........................................................................................................................35
DHCP server Page.............................................................................................................36
Global Settings.............................................................................................................................36
Server Settings ............................................................................................................................37
VLAN Configuration............................................................................................................39
Port - PVC Page.................................................................................................................40
7Security......................................................................................................41
IP Filtering...........................................................................................................................41
IP Filter Settings...........................................................................................................................41
Port Filters....................................................................................................................................42
IP Filters....................................................................................................................................... 42
Domain Filtering..................................................................................................................43
Port Forwarding Configuration ...........................................................................................44
Virtual Server ......................................................................................................................45
MAC Filtering ......................................................................................................................46
8Services.....................................................................................................47
IGMP Proxy.........................................................................................................................47
IP Routing............................................................................................................................47
Static Routing...............................................................................................................................47
Dynamic Routing .........................................................................................................................48
Dynamic DNS.....................................................................................................................49
Quality of Service................................................................................................................51

X7968r User’s Guide
III
Classifier ......................................................................................................................................51
QoS Setting..................................................................................................................................52
UPnP...................................................................................................................................53
9Port Statistics............................................................................................54
DSL (A1)..............................................................................................................................54
Basic: ...........................................................................................................................................54
Advanced:....................................................................................................................................55
Wireless...............................................................................................................................56
Basic: ...........................................................................................................................................56
Advanced:....................................................................................................................................57
Raw-Ethernet......................................................................................................................58
Basic: ...........................................................................................................................................58
Advanced:....................................................................................................................................58
Ethernet...............................................................................................................................59
Basic: ...........................................................................................................................................59
Advanced:....................................................................................................................................59
10 Admin.........................................................................................................60
Firmware Upgrade..............................................................................................................60
Backup & Restore...............................................................................................................61
Reboot.................................................................................................................................62
Remote Access...................................................................................................................63
Change Password..............................................................................................................64
Time Zone...........................................................................................................................65
SNTP Client:................................................................................................................................65
SNTP Server:...............................................................................................................................66
11 Appendix A - Configuring the Internet Settings....................................67
Configuring Ethernet PCs...................................................................................................67
Before you begin.......................................................................................................................... 67
Windows Vista PCs.....................................................................................................................67
Windows XP PCs ........................................................................................................................67
Windows 2000 PCs.....................................................................................................................68
Windows Me PCs........................................................................................................................68
Windows 95, 98 PCs................................................................................................................... 69
Windows NT 4.0 workstations.....................................................................................................70
Assigning static Internet information to your PCs .......................................................................70
Configuring Wireless PCs...................................................................................................71
Positioning the wireless PCs.......................................................................................................71
Wireless PC cards and drivers....................................................................................................71
Configuring PC access to your Wireless device......................................................................... 71
12 Appendix C - IP Addresses, Network Masks, and Subnets.................72
IP Addresses.......................................................................................................................72
Structure of an IP address...........................................................................................................72

X7968r User’s Guide
IV
Network classes...........................................................................................................................72
Subnet masks.....................................................................................................................73
13 Appendix D - Troubleshooting................................................................74
Troubleshooting Suggestions.............................................................................................74
Diagnosing Problem using IP Utilities................................................................................76
Ping..............................................................................................................................................76
nslookup.......................................................................................................................................76
14 Appendix E - Advanced DSL port attributes .........................................78
15 Appendix F - Glossary .............................................................................83
16 Appendix G - Specification......................................................................92
17 Appendix I - Regulation............................................................................94

X7968r User’s Guide
1 Introduction
Congratulations on becoming the owner of the X7968r, ADSL router. You will now be able to access
the Internet using your high-speed DSL connection.
This User Guide will show you how to connect your X7968r DSL Modem, and how to customize its
configuration to get the most out of your new product.
The following specific model is covered by this user manual:
X7968r : ADSL2+, WLAN 802.11b/g AP and 4 port switch.
WARNING: Telefonica de España can not be held responsible for the device
configuration using this manual. The present manual is sole responsibility of
Amper/Xavi
Features
The list below contains the main features of the device and may be useful to users with
knowledge of networking protocols. If you are not an experienced user, the chapters
throughout this guide will provide you with enough information to get the most out of your
device.
The features include:
zHigh Speed Asymmetrical Data Transmission on Twisted Copper Pair Wire
zService providers can deploy ADSL rapidly over existing wire infrastructure
(POTS or ISDN line)
zCompatible and interoperable with most central office site ADSL DSLAM or
Multi-service Access Systems.
zRFC 1483 Bridging and Routing over ATM over ADSL
zPPPoE, IPoA and PPPoA routing over ADSL
zInterchangeable between Bridge and Router mode
zNetwork address translation (NAT) functions to provide security for your LAN
zNetwork configuration through DHCP Server and DHCP Client
zServices including IP route and DNS configuration, RIP, and IP and DSL
performance monitoring
zBuilt-in four-port 10/100BaseTX Ethernet switch for PC or LAN connection
z802.11b/g WLAN supports up to 54Mbps
zProvides Allow/Deny Wireless MAC address list for wireless access control
z64 and 128-bit WEP key lengths are supported
zSupports Wi-Fi WPA and WPA2 in PSK mode
zSupports 802.1Q tagged VLAN and 802.1p as well as standard compliant IP
QoS for multiple services and triple play deployment.
zConfiguration and management with Telnet through the Ethernet interface, and
remote Telnet through ADSL interface
zFirmware upgradeable through TFTP or HTTP
zUser-friendly configuration program accessed via a web browser
1

X7968r User’s Guide
Device Requirements
In order to use the X7968r, you must have the following:
DSL service up and running on your telephone line
Instructions from your ISP on what type of Internet access you will be using, and
the addresses needed to set up access
One or more computers, each containing an Ethernet card (10Base-T/100Base-T
network interface card (NIC)).
For system configuration using the supplied web-based program: a web browser
such as Internet Explorer v4 or later, or Netscape v4 or later. Note that version 4
of each browser is the minimum version requirement – for optimum display
quality, use Internet Explorer v5, or Netscape v6.1
Note
You do not need to use a hub or switch in order to connect more than one
Ethernet PC to the device. Instead, you can connect up to four Ethernet
PCs directly to the device using the ports labeled LAN1 to LAN4 on the
rear panel.
Using this Document
Notational conventions
Acronyms are defined the first time they appear in the text and also in the glossary.
For brevity, the X7968r is referred to as “the device”.
The term LAN refers to a group of Ethernet-connected computers at one site.
Typographical conventions
Italic text is used for items you select from menus and drop-down lists and the names
of displayed web pages.
Bold text is used for text strings that you type when prompted by the program, and to
emphasize important points.
Special messages
This document uses the following icons to draw your attention to specific instructions or
explanations.
Note Provides clarifying or non-essential information on the current topic.
Definition
Explains terms or acronyms that may be unfamiliar to many readers.
These terms are also included in the Glossary.
WARNING
Provides messages of high importance, including messages relating to
personal safety or system integrity.
2

X7968r User’s Guide
2 Getting to know the device
Parts Check
In addition to this document, your package should arrive containing the following:
The device (X7968r)
Ethernet cable
Standard phone/DSL line cable
Power adapter
User Manual CD
X7968r
ADSL device unit
RJ-45 Cable
RJ-11 Cable
Power adapter
User’s Manual CD
Figure 1: DSL Modem Package Contents
3

X7968r User’s Guide
X7968r Front Panel
The front panel contains lights called Light Emitting Diodes (LEDs) that indicate the status of
the unit.
Figure 2: Front Panel and LEDs
Label Color Function
Ethernet Green On: LAN link established and active
Off: No LAN link
Blink: Data being transmitted
WLAN Green
On: Wireless function enabled
Off: Wireless function disabled
Blink: Data being transmitted
On: device is powered on
Off: device is powered off
Green
ADSL Green
On: DSL link reaches showtime, which means
that your device has successfully connected
to your ISP’s DSL network.
Off: DSL link not in showtime, your device has
not successfully connected to your ISP’s DSL
network.
Slow blink: Try to connect to ISP’s DSL
network
PPP Green On: There is a PPPoA or PPPoE connection.
Off: There is no PPPoA or PPPoE connection.
Blink: There is traffic on PPP connection
IMPORTANT: A simultaneous rithmic blink of ADSL and PPP LEDs means that flash memory
is being writen. Router shouldn’t be unpowered in this state!
4

X7968r User’s Guide
X7968r Rear Panel
The X7968r rear panel contains the ports for the unit's data and power connections.
Figure 3: Rear Panel Connections
Label Function
ON/OFF switch
12V-1A Connects to the supplied power adapter
Connects the device via Ethernet to your devices in
LAN
1X ~ 4X Ethernet
Press and hold this button for 1 second to enable
Wireless AP function or disable it
A reset button to reset the device or reset to default
settings. Press and hold for 5 seconds.
RESET
ADSL Connects to the ISP DSL network
5

X7968r User’s Guide
3 Connecting your device
This chapter provides basic instructions for connecting the device to a computer or LAN and
to the Internet.
In addition to configuring the device, you need to configure the Internet properties of your
computer(s). For more details, see the following sections in Appendix A:
Configuring Ethernet PCs section
Configuring Wireless PCs section
This chapter assumes that you have already established a DSL service with your Internet
service provider (ISP). These instructions provide a basic configuration that should be
compatible with your home or small office network setup. Refer to the subsequent chapters
for additional configuration instructions.
Connecting the Hardware
This section describes how to connect the device to the power outlet and your computer(s)
or network.
WARNING
Before you begin, turn the power off for all devices. These include
your computer(s), your LAN hub/switch (if applicable), and the device.
The diagram below illustrates the hardware connections. The layout of the ports on your
device may vary from the layout shown. Refer to the steps that follow for specific
instructions.
Figure 4: Overview of Hardware Connections for X7968r
6

X7968r User’s Guide
Step 1. Connect the DSL cable and optional telephone line
Connect one end of the provided phone cable to the port labeled DSL on the rear panel of the
device. Connect the other end to ADSL spliter.
Step 2. Connect the Ethernet cable
Connect up to four single Ethernet computers or to a HUB/Switch directly to the device via
Ethernet cable(s).
Note that the cables do not need to be crossover cables.
Step 3. Attach the power connector
Connect the AC power adapter to the Power connector on the back of the device and plug
the adapter into a wall outlet or power strip. Turn on and boot up your computer(s) and any
LAN devices such as hubs or switches.
Step 4. Configure your Ethernet PCs
You must also configure the Internet properties on your Ethernet PCs. See Configuring
Ethernet PCs section.
Step 5. Install a Wireless card and connect Wireless PCs
You can attach a Wireless LAN that enables Wireless PCs to access the Internet via the
device.
You must configure your Wireless computer(s) in order to access your device. For complete
instructions, see Configuring Wireless PCs section.
Next step
After setting up and configuring the device and PCs, you can log on to the device by
following the instructions in “Getting Started with the Web pages” on chapter 4. The chapter
includes a section called Testing your Setup, which enables you to verify that the device is
working properly.
7

X7968r User’s Guide
4 Getting Start with the Web pages
The DSL Modem includes a series of Web pages that provide an interface to the
software installed on the device. It enables you to configure the device settings to
meet the needs of your network. You can access it through a web browser on a PC
connected to the device.
Accessing the Web pages
To access the web pages, you need the following:
A laptop or PC connected to the LAN or WLAN port on the device.
A web browser installed on the PC. The minimum browser version requirement is
Internet Explorer v4 or Netscape v4. For the best display quality, use latest version of
Internet Explorer, Netscape or Mozilla Firefox.from any of the LAN computers, launch
your web browser, type the URL, http://192.168.1.1 in the web address (or location)
box, and press [Enter]. Then enter the default username and password: admin/admin
to access the configuration web page, if you have not changed the username and
password.
The home page opens displaying the overview of device:
Figure 5: Overview –Home
8

X7968r User’s Guide
The Menu comprises:
Home (My DSL Modem):provides overview and troubleshooting of the system. It
includes the sub menus Overview and Troubleshooting. By default, the page
Overview is displayed after the login.
Configuration: provides information about the current configuration of various system
features with options to change the configuration. It includes the sub menus Quick
Setup, Wireless Network, Internet Connection, Local Network, DHCP Server, VLAN
Config and Port-PVC.
Security: provides filtering, forwarding, and setting up the virtual server. It includes
the sub menus IP Filtering, Domain Filtering, Port Filtering, Virtual Server, and MAC
Filtering.
Service: provides services such as IGMP Proxy (enabling the system to issue IGMP
host messages on behalf of hosts that the system discovered through standard IGMP
interfaces), IP Routing, Dynamic DNS, Qualify of Service and UPnP.
9

X7968r User’s Guide
Port Statistics: Let you view the values of port parameters (DSL, Wireless,
Raw_ethernet, and Ethernet).
Admin: provides the administration utilities such as firmware upgrade, backup &
restore, reboot, remote access, change password and Time Zone.
Commonly used buttons
The following buttons are used throughout the web pages:
Button Function
You may need to configure the default settings on
more than one Web page. Click on this button once
you have changed the configuration on your current
page and are ready to move on to the next.
This button appears on every configuration page.
Click on this button if at any time you decide that you
do not want to change the existing settings.
Radio buttons – these appear on many configuration
pages. You will be asked to select one radio button
from the selection of two or more available. You
cannot select more than one radio button at a time.
This button appears on every configuration page.
Click on this button once you are through with the
changes and decide to apply the made changes.
You may need to browse to find a file which needs to
be uploaded for new configuration.
This button allows you to upgrade to the new
configuration file attached using the Browse button.
The following terms are used throughout this guide in association with these buttons:
Click – point the mouse arrow over the button, menu entry or link on the screen and click the
left mouse button. This performs an action, such as displaying a new page or performing the
action specific to the button on which left mouse button is clicked.
Select – usually used when describing which radio button to select from a list, or which entry
to select from a drop-down list. Point the mouse arrow over the entry and left-click to select it.
10

X7968r User’s Guide
This does not perform an action – you will also be required to click on a button, menu entry
or link in order to proceed.
Help information
To view the help, click the desired menu or submenu. The related help information appears
in the right pane.
Testing your Setup
Once you have connected your hardware and configured your PCs, any computer on your
LAN should be able to use the device’s DSL connection to access the Internet.
To test the connection, turn on the device, wait for 30 seconds and then verify that the LEDs
are illuminated as follows:
LED Behavior
Solid green to indicate that the device is turned on. If
this light is not on, check the power cable
attachment.
Encendido
Solid green to indicate that the Wireless LAN
function is operational.
WLAN
Solid green to indicate that the device can
communicate with your LAN.
LAN
Flashing on/off while trying to SYNC UP with ISP CO
site. Solid green to indicate that the device has
successfully established a connection with your ISP.
ADSL
PPP On: There is a PPPoA or PPPoE connection.
Off: There is no PPPoA or PPPoE connection.
Table 1. LED Indicators
If the LEDs illuminate as expected, test your Internet connection from a LAN computer. To
do this, open your web browser, and type the URL of any external website (such as
http://www.yahoo.com).
If the LEDs do not illuminate as expected, you may need to configure your Internet access
settings using the information provided by your ISP. If the LEDs still do not illuminate as
expected or the web page is not displayed, see Troubleshooting section or contact your ISP
for assistance.
11

X7968r User’s Guide
Default device settings
In addition to handling the DSL connection to your ISP, the DSL Modem can provide a
variety of services to your network. The device is preconfigured with default settings for use
with a typical home or small office network.
The table below lists some of the most important default settings; these and other features
are described fully in the subsequent chapters. If you are familiar with network configuration,
review these settings to verify that they meet the needs of your network. Follow the
instructions to change them if necessary. If you are unfamiliar with these settings, try using
the device without modification, or contact your ISP for assistance.
WARNING
We strongly recommend that you contact your ISP prior to changing the
default configuration.
Option Default Setting Explanation/Instructions
User name and password to
access the device
User/Password admin/admin
DSL Port IP
Address Unnumbered interface:
192.168.1.1
Subnet mask:
255.255.255.255
This is the temporary public IP
address of the WAN port on the
device. It is an unnumbered
interface that is replaced as soon
as your ISP assigns a ‘real’ IP
address. See Quick Setup
section.
LAN Port
IP Address Assigned static IP
address:
192.168.1.1
Subnet mask:
255.255.255.0
This is the IP address of the LAN
port on the device. The LAN port
connects the device to your
Ethernet network. Typically, you
will not need to change this
address. See Local Network
section.
DHCP
(Dynamic Host
Configuration
Protocol)
DHCP server enabled
with the following pool
of addresses:
192.168.1.2
through
192.168.1.21
(Please be noted that
the default DHCP IP
address pool may be
different in each
firmware version.)
The device maintains a pool of
private IP addresses for dynamic
assignment to your LAN
computers. To use this service,
you must have set up your
computers to accept IP
information dynamically, as
described in DHCP Server
section.
12

X7968r User’s Guide
5 Home
The Home web page menu includes the following submenus:
Overview
Trouble Shooting
Overview Page
The overview of the device contains most of the basic information like
System Information (equipment vendor, model number, chipset part number, chipset
version number),
Internet Information (ADSL port, downstream rate, upstream rate, default Gateway, Primary
DNS Server, Secondary DNS server),
Wireless Setting Information (Status, SSID, Channel, Security),
LAN Port information (MAC address, IP address, Subnet Mask and DHCP server).
Basic Overview
Figure 6: Overview – Basic
13

X7968r User’s Guide
Advanced Overview
Figure 7: Overview – Advanced
The Advanced information of the device includes the following:
System Information – In addition to the information displayed as under Basic, it
also displays the DSL Firmware Version and Wireless Version.
Internet Connection – In addition to the information displayed as under Basic, it
also displays Last Failed internet connection, SNR (Downstream), SNR
(Upstream), Line Attenuation (Downstream), LineAttenuation (Upstream), and
the Connected Standard.
14

X7968r User’s Guide
Wireless Settings - displays the wireless settings for the modem.
LAN Port – displays the same information as displayed under Basic.
Status – displays the status of Routing, DHCP, ARP, Wireless Connection, and
Traffic.
15
