Xenarc 892 Series User manual

892 INSTALLATION MANUAL

2│Table of Contents
Features ……………………………………………03
Specifications ……………………………………04
Quick – Start ……………………………………..05
Remote Control ………………………………….07
Capacitive Touch ………………………………..10
Hardware Installation …………………………11
Additional Info. …………………………………..15
Owner’s Record. ………………………………….16

3│Features
Model Comparison Chart
892CFH 892GFC
HDMI Input 2 2
TYPE-C Input ○●
DC3.5mm Audio Output ●●
Sunlight Readable ●●
Touch Screen Capacitive
Capacitive
Optical Bonding
IP grade Front IP65 Front IP65
●Standard ○Not Available
Features
•Front IP65 / NEMA6P Rated Water and Dust Resistance
•Extreme Operating Temperature range of -31°F ~ 185°F (-35°C ~
85°C)
•1,000NIT Sunlight Readable with Long Life LED Backlight
•Wide Viewing Angle IPS (In-Plane Switching) LCD Panel
•Automatic Backlight Adjustment through Built-in Ambient Light
Sensor
•Projected Capacitive Multi-Touch Touchscreen (USB)
•Optical Bonding, Anti-Reflective and Anti-Fingerprint Coating
•Plug-N-Play with Windows 7 and up and Android devices
(Downloadable drivers for other OS)
•Multi-Monitor Touchscreen Support
•HDMI Input x 2 (HDCP), USB-C 3.2 x 1
•DVI Input through included DVI to HDMI Adaptor
•Built-In Speaker
•1280x720 Native Resolution, 16x9 Aspect Ratio
•Solid Capacitors for Improved Durability
•High Performance Image and Video Signal Processor
•AISS - Advanced Image-Scaling and Shaping
•Last Input and Power Setting Memory
•IR Remote Control
•Auto Power-On upon signal detection
•Vertical Image Flip
•Function to Disable Front Button(s) and On Screen Text
•VESA 75mm Mounting Holes
•Panel Mountable with included hardware
•Connector Locking through included metal bracket to secure
connectors against vibration
•Supports 9V DC ~ 36V DC
•"E" Mark Certified for Automotive use
•FCC, CE, E49 Certification
•ROHS Compliant
•36 Month/3 Year Warranty
•30 Day No dead Pixel Guarantee

4│Specification
Specifications
•Screen Size: Diagonal 8" (16:9)
•Physical Resolution: 1280 (H) x 720 (V) HD
•Supported Resolution: 640 x 480 ~ 1920 x 1080
•Dot Resolution: 1280 x 800 = 1,024,000 (dots)
•Brightness: 1000 cd/m²
•Contrast Ratio: 1000:1
•Viewing Angle: 170° Horizontal, 170° Vertical
•Response Time (Tr/Tf): 15/10ms (Typ.)
•Touch Screen Interface: USB port
•Operating Voltage Range: DC 9V ~ 36V
•Power Supply: DC 12V
•Power Consumption: ≤ 20W
•Operating Temperature: -31°F ~ 185°F (-35°C ~ 85°C)
•Storage Temperature: -40°F ~ 203°F (-40°C ~ 90°C)
•MTBF (Mean Time Between Failures): > 55,000 Hours
•Dimension (mm): 220.7W x 142.7H x 33D
•Weight (lb): 1.89

5│Quick - Start
(HDMI interface)
Attach the HDMI plug to the monitor’s HDMI input
connector. Based on your installation requirement
you can choose to use the straight plug or the 90-
degree plug. Attach the HDMI plug on the other
side of the cable to your device’s HDMI output
connector.
(Touchscreen interface)
Attach the USB-A plug to your monitor’s USB-A
connector. Based on your installation requirement
you can choose to use the straight plug or the
90-degree plug. Attach the USB plug on the
other side of the cable to your computer’s
USB-A connector.
(USB-C - 892GFC Only)
The USB-C supports transferring of video signal,
touchscreen coordinates, and power over one
cable if supported by your device. Attach the
USB-C plug to your monitor’s USB-C Connector and
the USB-C plug on the other side of the cable to
your device’s USB-C connector. Our USB-C cable
must be used to ensure compatibility.
Attach the DC power plug to the monitor’s DC power
input connector and connect the other side to your
power source. (If you are using USB-C and your
device has enough power output through USB-C,
then it can power the monitor directly through
USB-C. If DC power is provided to the monitor
through the DC power input connector, then the
monitor can provide 5V/2A 10W of power to your
device over USB-C)
Install the included metal connector bracket to
secure the cables against vibration if your
usage application requires it. Our cables need to
be used because our cable plugs are specially
designed to work with this bracket.

6│Quick - Start
Touchscreen Driver Installation (Optional)
Please download and install the Touchscreen
driver for your operating system from our
website WWW.XENARC.COM if needed. It is
normally plug and play with Windows 7 and 10,
and Android so most of the time, the driver
would not be necessary.

7│Remote Control
1. Power Button : Turn the monitor ON or OFF.
2. Mirror Button : Enable or Disable the reverse of the display.
3. Dimmer Button : Dim the brightness of the display by pressing this key
continuously to set the brightness level of the display.
( Only available when auto sensor is disabled. )
4. Display Button : Display the current input signal on the screen.
5. Sleep Button : Enable or Disable the sleep timer. Press this button to
select and set the time to turn off the monitor automatically.
6. Picture Button : Enable or select the picture mode you prefer.
Press this button and then you can select standard, mild, user, dynamic.
7. PC auto Button : Enable to adjust the picture automatically, only
available in VGA mode.
8. Menu Button : Enable the OSD menu. Press this button again to exit.
9. Source Button : Enable to switch to different source input.
10. Up / Down Button ( ▲ / ▼ ) : Navigate Up or Down in OSD menu.
11. Left / Right Button ( ◄ / ► ) : Navigate Left or Right in OSD menu, as
well as decreasing or increasing the value of setting in OSD.
12. Enter Button : Confirm the setting or selection.

8│Remote Control
Instructions for remote control shortcuts
1. Dimmer ( Adjust the brightness )
By pressing the Dimmer button, it will adjust the brightness level from 0,
20, 40, 60, 80 and 100.
Default is 100 ( Only available when smart light sensor is disabled )
2. Sleep ( Set the sleep time out )
Select the time to automatically turn off the monitor.
The minimum is 10 minutes and the maximum is 240 minutes.
3. Picture ( Set the modes of the picture )
Enable to select the picture modes you prefer.
Press this button and then you can select Standard, Mild, User, or Dynamic.
4. PC AUTO ( Auto adjust, only on VGA )
By pressing PC AUTO, it will auto adjust the image.
5. Source ( Select the source )
Press this button to select the input signal to display.
If one of these modes is disabled in OSD menu, please setup under
( ADJUST →Source Enable )

9│Remote Control
6. Mirror (Vertical Image Flip)
Enable or Disable vertical image flip. Choose the direction you wish to
display.
7. Mute
Mute the speaker.
Press again to restore the sound of the speaker.
8. Display ( Display mode )
Display the current input signal on the screen.
9. VOL- / VOL+
Volume adjustment.

10 │Capacitive Touch
1. Supports plug and play for Windows 7 and
up. Touchscreen driver might need to be installed
for other operating systems.
2. Supports below operating systems
OS Touch Function
WINDOWS
10
Available for multi-touch
8
7
CE 7 & 8
VISTA
Only supports single mouse point
XP
MAC
OS10.13
Only supports single mouse point
X
Linux
Kernel 2.6.36 Upwards Available for multi-touch
Kernel 2.6.35 Downward
Only supports single mouse point
Kernel 2.4.X
Android
V2.3 Upwards Available for multi-touch
V2.0 ~ V2.2 No support touch
3. Operation
Touch & type
To select or activate something, touch it.
To type something, such as a name, password, or search term, just touch
where you want to type. A keyboard pops up that lets you type into the
field.
Other common gestures include:
• Touch & hold. Touch & hold an item on the screen by touching it and not
lifting your finger until an action occurs.
• Drag. Touch & hold an item for a moment and then, without lifting your
finger, move your finger on the screen until you reach the target
position. For example, you can move object or icon around on the Home
screen.
• Swipe or slide. Quickly move your finger across the surface of the screen,
without pausing when you first touch (so you don’t drag something
instead). For example, you can slide a Home screen left or right to view
the other Home screens.
• Double-tap. Tap quickly twice on a webpage, map, or other screen to
zoom. For example, double-tap a picture in Chrome to zoom in, and
double-tap again to zoom out. (This function depends on Win7 or Win8
function)
• Pinch. In some apps (such as Maps, Chrome, and Gallery), you can zoom
in and out by placing two fingers on the screen at once and pinching
them together (to zoom out) or spreading them apart (to zoom in). (This
function depends on Win7, Win8 or WIN10 function)

11 │Hardware Installation
Buttons description:
1. Power Button : Press to turn ON or OFF the monitor.
2. Select Button : Press to select the input signal to display. Press
the left ( ◄ ) or right ( ► ) to highlight the input source desired and then
wait 2 seconds to make the selection.
3. Menu Button : Press the button to show the OSD menu. And then
press the left ( ◄ ) or right ( ► ) to navigate through the menu. Press
“ Select “ button to go through a list of settings and options. Press the
left ( ◄ ) or right ( ► ) buttons to change the values of settings. Press
Menu button again to leave the OSD menu.
4. Right Button : Press this button to the value of settings inside the
OSD menu.
5. Left Button : Press this button to the value of settings inside the
OSD menu.
Ambient Light Sensor
Ambient light sensor can be enabled or disabled in the OSD by going into
the “ SETUP ” category, and selecting the option “ Smart Light Sensor ”.
When Auto Sensor is enabled, the LCD backlight brightness will be
adjusted automatically according to the ambient lighting condition.
Note
The brightness cannot be adjusted manually through the dimmer button
or through the OSD menu when the Smart Light Sensor function is
enabled.
OSD ( On-screen display ) Menu
Press MENU button to bring up the OSD menu onto the screen. Press
LEFT / RIGHT button (Or UP / DOWN button on the remote) to navigate the
OSD menu or to Increase / Decrease the value of a selected item. Press
SELECT Button (or ENTER button on the remote) to select a category or
an item. Press MENU button to go back.
The settings and options in the OSD menu are categorized into 5
Categories : PICTURE, DISPLAY, ADJUST, SETUP, FUNCTION

12 │Hardware Installation
1. PICTURE
• Picture Mode : Set the color mode to the desired setting : Standard, Mild,
User, Dynamic.
• Backlight : Adjust backlight by pressing Left ( ◄ ) or Right ( ► ) buttons.
Increase the number for a higher level of backlight output. Decrease the
number for a lower level of backlight output. Only works when Smart Light
sensor is turned off.
• Brightness : Adjust brightness by pressing Left ( ◄ ) or Right ( ► ) buttons.
Increase the number for a higher level of brightness. Decrease the number
for a lower level of brightness.
• Contrast : Adjust contrast by pressing Left ( ◄ ) or Right ( ► ) buttons.
Increase the number for a higher level of contrast. Decrease the number
for a lower level of contrast.
• Sharpness : Adjust sharpness by pressing left or right buttons. Press left
to decrease sharpness and right to increase the level of sharpness.
• Noise Reduction : To adjust the level of noise reduction
• DLC : To enable or disable Dynamic Luminance Control (Dynamically
boosting display contrast)
2. DISPLAY
• Color Temp : Set the color temp to the desired setting :
Medium, Warm, Cool and User.
• RGB Color Range : Set the RGB color range to the desired setting :
Auto, 0-255, 16-235
• Gamma : Set the gamma to the desired setting :
Gamma_S, Cut White, IncreaseBlack, Enhance Blue and Liner.
• Aspect Ratio : Select the display mode ( 16:9, 4:3 and Auto )
• OverScan Select : Adjustment to compensate for overscan.
• Display Mirror : Adjust the vertical mirroring position.
• Auto Adjust : Adjust display automatically.

13 │Hardware Installation
3. ADJUST
• Source Info : Display the source of input signal, if it is ON.
• Resolution Info : Select to turn OFF or turn ON displaying of On Screen
Source Information.
• Source Enable : Select to enable or disable the input signal. If an input
signal is turned off, the source will automatically be disabled.
• KeyPad Enable : Allows you to disable or enable the buttons on the front
of the monitor. Power, Menu, Select, Left, and Right buttons can be
disabled or enabled. (only operated with remote)
• User Reset : Reset to factory default setting.
4. Setup
• Smart Light sensor : Enable or disable the auto sensor of surrounding
environment.
─“ On ”means the monitor can automatically adjust the backlight of
the display according to the surrounding environment.
─Please note : While smart light sensor is enabled, the option of dimmer
or backlight inside the OSD can not work until smart light sensor is
disabled.
• Screen Power Saving : Adjust the time out of the monitor backlight,
When there is no signal input. (Default is On 10 Sec)
• Left/Right Key : Set front Left/Right buttons as Dimmer or Volume
Control.
• Digital Audio Source : Select the audio source while in HDMI input.
When set to Digital, the built-in speaker will output the digital audio signal
from HDMI. When set to Analog, the built-in speaker will output the analog
audio signal from the mini stereo jack marked as “ PC Audio ”
When set to AUTO, the built-in speaker will output the digital audio if the
HDMI source includes audio signal. Otherwise, the speaker will output the
analog audio signal from the mini stereo jack marked as “ PC Audio ”

14 │Hardware Installation
• Touch Panel : Not available.
• Charger Icon : Not available.
• Key LED BackLight : Not available.
• OPS Power Press : Not available.
5. FUNCTION
• CCD FIRST : Set whether to have monitor switch to CCD signal
automatically if a signal is present. (Default is OFF)
• CVBS WIFI SW : Not available.
• CH Select : Not available.

15 │Additional Info
NOTE:
NOTE 1 :
Depending on your Operating System, the Touch Screen device driver
might need to be installed onto your computer in order for the Touch
Screen to become operational. Touch Screen drivers and software for
different operating systems can be downloaded from our website at
WWW.XENARC.COM.
NOTE 2 :
The maximum voltage supported by the monitor is 36V DC. Feeding the
monitor with higher voltage will damage the monitor and void the
warranty. Please use a fused power source if you decide to wire the
monitor directly to your vehicle’s electrical system. It is also crucial that
you check the polarity on the connection.
For Technical Support , please contact us at:
Xenarc Technologies Corp.
Toll Free : 888 - 656 - 6536
E - Mail : support @ xenarc.com
Website : www.xenarc.com
Length of VESA mounting screw. 【M4 x 8 mm (max) 】

16 │Owner’s Record
Owner’s Record
The model and serial number are located on the rear of the unit. Please
record these numbers in the spaces provided below, as well as the dealer
name, address, and telephone number.
Please refer to these records whenever speaking to your dealer regarding
this product.
Model Number :
Serial Number :
Dealer Name :
Street Address :
City :
State :
Zip :
Phone Number :
Purchase Date :
All rights reserved. Reproduction in whole or in part without permission is prohibited.
