Xerox DocuPrint P1202
Service Manual
720P15700
egl_421a
www.printcopy.info
www.printcopy.info

3/99
Copyright Information ii Xerox DocuPrint P1202 Service Manual
This Service Manual contains information that
applies to the Xerox DocuPrint P1202 Electronic
Laser Printer.
NOTICE
This manual is for use by Xerox Technicians and
Xerox trained technicians only.
NOTICE
While every care has been taken in the
preparation of this manual, no liability will be
accepted by Xerox arising out of any inaccuracies
or omissions.
All service documentation is supplied to Xerox
external customers for informational purposes
only. Xerox service documentation is intended for
use by certified, product trained service personnel
only. Xerox does not warrant or represent that
such documentation is complete. Nor does Xerox
represent or warrant that it will notify or provide to
such customer any future changes to this
documentation. Customer’s service of equipment,
or modules, components, or parts of such
equipment may void any otherwise applicable
Xerox warranties. If Customer services such
equipment, modules, components, or parts
thereof, Customer releases Xerox from any and
all liability for Customer’s actions, and Customer
agrees to indemnify, defend, and hold Xerox
harmless from any third party claims which arise
directly or indirectly from such service.
Prepared by:
Xerox Corporation
PSD&E
701 S. Aviation Blvd. Mail Stop: ESM1-058
El Segundo, CA.90245
Prepared for:
Xerox Channels Group
Personal Printer
555 S. Aviation Blvd.
El Segundo, California 90245
Copyright 1998 by Xerox Corporation. Xerox and
DocuPrint P1202 are registered trademarks of
Xerox Corporation.
Copyright 1998 Xerox Corporation. All rights
reserved.
Copyright protection claimed includes all forms of
matters of copyrightable materials and information
now allowed by statutory or judicial law or
hereinafter granted, including without limitation,
material generated from the software programs
which are displayed on the screen such as styles,
templates, icons, screen displays, looks, etc.
Xerox, Xerox Limited, and all product names and
product numbers mentioned in this publication are
trademarks.
PCL, HP LaserJet, and Intellifont are trademarks
of Hewlett-Packard Company. IBM is a trademark
of International Business Machines Corporation.
Microsoft, Microsoft Windows, Microsoft Word,
MS, and MS-DOS are trademarks of Microsoft
Corporation. Univers is a trademark of Linotype
AG or its subsidiaries. WordPerfect is a trademark
of WordPerfect Corporation. Centronics is a
trademark of Centronics Corporation. Macintosh
and TrueType are trademarks of Apple Computer,
Incorporated. All other product names are
trademarks/tradenames of their respective
owners.
The Xerox DocuPrint P1202 uses PCL 5e and
PCL6 emulation.
PCL 5e and PCL6 are trademarks of Hewlett
Packard Company. These printers contain an
emulation of the Hewlett Packard PCL 5e and
PCL6 command language, recognizes HP PCL
PCL 5e and PCL6 commands, and processes
these commands in a manner compatible with
Hewlett Packard LaserJet printer products.
www.printcopy.info
www.printcopy.info

3/99
Xerox DocuPrint P1202 Service Manual iii Product Safety
Warning
This equipment complies with the
requirements in Part 15 of FCC rules for a
class A computing device. Operation of the
equipment in a residential area may cause
unacceptable interference to radio and TV
reception, requiring the operator to take
whatever steps are necessary to correct the
interference.
Product Safety
Electrostatic Discharge
This caution indicates that there are components
which are sensitive to damage caused by
electrostatic discharge.
Shock Hazard
This symbol indicates the presence of potentially
hazardous voltages.
CLASS 1 LASER PRODUCT
The Xerox DocuPrint P1202 laser printers are
certified to comply with Laser Product
Performance Standards set by the U.S.
Department of Health and Human Services as a
Class 1 Laser Product. This means that this is a
class of laser product that does not emit
hazardous laser radiation; this is possible only
because the laser beam is totally enclosed during
all modes of customer operation.
The laser and output of the laser scanner unit
produces a beam that, if looked into, could cause
eye damage. Service procedures must be
followed exactly as written without change.
When servicing the machine or laser module,
follow the procedures specified in the manual and
there will be no hazards from the laser.
Laser (FDA): Any laser label visible to service
must be reproduced in the service manual with
location shown or indicated. Safe working
procedures and clear warnings concerning
precautions to avoid possible exposure must also
be included.
The Laser contained in the DocuPrint P1202
meets the following standard: Laser class 3B,
maximum 5mW, wavelength 780nm.
The following LASER symbol will be displayed at
the start of any procedure where possible
exposure to the laser beam exists.
LUOKAN 1 LASERLAITE
KLASS 1 LASER APPARAT
Each P1202 laser printer has the following laser
warning label on the Laser Assembly.
DP8_001
DP8_006
DP8_009
CAUTION
These components are susceptible
to electrostatic discharge. Observe
all ESD procedures to avoid
damage.
www.printcopy.info
www.printcopy.info

3/99
Product Safety iv Xerox DocuPrint P1202 Service Manual
The Laser Label is visible when the Top Cover is removed (Figure 1).
Figure 1. Laser Safety Label
Laser Label.
Finland Laser Safety
DP8_034
www.printcopy.info
www.printcopy.info

3/99
Xerox DocuPrint P1202 Service Manual v Contents
Table of Contents
Title Page
Introduction ..............................................v
Organization ............................................vi
Service Call Procedures.......................1-1
Printer Specifications ...........................2-1
Parts Lists..............................................3-1
Repair Procedures ................................4-1
General Procedures..............................5-1
Wiring Data ............................................6-1
Repair Analysis Procedures.................7-1
Introduction
The Xerox DocuPrint P1202 Service Manual is the
primary document used for repairing and
maintaining the P1202 Laser Printers.
This manual contains Service Call Procedures,
Diagnostic Procedures, General Information,
Repair Analysis Procedures, Copy Quality
Analysis Procedures, Wiring Data, and Parts Lists
that will enable the Service Representative to
repair P1202 failures.
NOTE: In some of the DocuPrint P1202
documentation the Print Cartridge is
referred to as the Image Cartridge. Print
Cartridge is the correct term.
www.printcopy.info
www.printcopy.info

3/99
Contents vi Xerox DocuPrint P1202 Service Manual
Organization
This manual is divided into seven sections. The
title and description of each section of the manual
is as follows:
Section 1 - SERVICE CALL PROCEDURES
This section is used to identify a suspected
problem. It contains Call Flow, Initial Actions, and
Final Actions. This part of the service manual
should always be used to start the service call.
Section 2 - PRINTER SPECIFICATIONS
This section contains all the specifications for the
P1202 printers.
Section 3 - PARTS LISTS
This section contains illustrations of disassembled
subsystems and a listing of the spared parts.
Part names are listed in this section of the manual
even if the part itself is not spared. All the parts
that are spared will have the part number listed.
Parts that are not spared will not have a number
listed.
Section 4 - REPAIR PROCEDURES
This section contains the instructions for removal,
replacement, and adjustment of the spared parts.
Section 5 - GENERAL PROCEDURES
This section contains diagnostic routines, printer
setup procedures, and a listing of tools and
supplies.
Section 6 - WIRING DATA
This section contains illustrations of the plug/jack
locations and the routing of power and signal
cables.
Section 7 - REPAIR ANALYSIS PROCEDURES
(RAPs)
This section contains the procedures necessary to
repair failures in the printer. This section also
contains the procedures necessary to
troubleshoot print quality problems.
www.printcopy.info
www.printcopy.info

3/99
Xerox DocuPrint P1202 Service Manual vii Revision Control List
Product Manual Title Part Number
P1202 Laser Printer Xerox DocuPrint P1202 Service Manual 720P15700
Page Date Page Date Page Date Page Date
Title 3/99
ii 3/99
iii 3/99
iv 3/99
v3/99
vi 3/99
vii 3/99
viii 3/99
1-1 3/99
1-2 3/99
1-3 3/99
1-4 3/99
2-1 3/99
2-2 3/99
2-3 3/99
2-4 3/99
2-5 3/99
2-6 3/99
2-7 3/99
2-8 3/99
3-1 3/99
3-2 3/99
3-3 3/99
3-4 3/99
3-5 3/99
3-6 3/99
3-7 3/99
3-8 3/99
3-9 3/99
3-10 3/99
3-11 3/99
3-12 3/99
3-13 3/99
3-14 3/99
3-15 3/99
3-16 3/99
3-17 3/99
3-18 3/99
3-19 3/99
3-20 3/99
3-21 3/99
3-22 3/99
4-1 3/99
4-2 3/99
4-3 3/99
4-4 3/99
4-5 3/99
4-6 3/99
4-7 3/99
4-8 3/99
4-9 3/99
4-10 3/99
4-11 3/99
4-12 3/99
4-13 3/99
4-14 3/99
4-15 3/99
4-16 3/99
4-17 3/99
4-18 3/99
4-19 3/99
4-20 3/99
4-21 3/99
4-22 3/99
4-23 3/99
4-24 3/99
4-25 3/99
4-26 3/99
4-27 3/99
4-28 3/99
4-29 3/99
4-30 3/99
4-31 3/99
4-32 3/99
4-33 3/99
4-34 3/99
4-35 3/99
4-36 3/99
4-37 3/99
4-38 3/99
4-39 3/99
4-40 3/99
4-41 3/99
4-42 3/99
4-43 3/99
4-44 3/99
4-45 3/99
4-46 3/99
5-1 3/99
5-2 3/99
5-3 3/99
5-4 3/99
5-5 3/99
5-6 3/99
5-7 3/99
5-8 3/99
5-9 3/99
5-10 3/99
5-11 3/99
5-12 3/99
5-13 3/99
5-14 3/99
5-15 3/99
5-16 3/99
5-17 3/99
5-18 3/99
5-19 3/99
5-20 3/99
5-21 3/99
5-22 3/99
5-23 3/99
5-24 3/99
5-25 3/99
5-26 3/99
5-27 3/99
5-28 3/99
5-29 3/99
5-30 3/99
5-31 3/99
5-32 3/99
5-33 3/99
5-34 3/99
5-35 3/99
5-36 3/99
6-1 3/99
6-2 3/99
6-3 3/99
6-4 3/99
6-5 3/99
6-6 3/99
6-7 3/99
6-8 3/99
6-9 3/99
6-10 3/99
6-11 3/99
6-12 3/99
6-13 3/99
6-14 3/99
7-1 3/99
7-2 3/99
7-3 3/99
7-4 3/99
7-5 3/99
7-6 3/99
7-7 3/99
7-8 3/99
7-9 3/99
7-10 3/99
7-11 3/99
7-12 3/99
7-13 3/99
7-14 3/99
7-15 3/99
7-16 3/99
7-17 3/99
7-18 3/99
www.printcopy.info
www.printcopy.info

3/99
Revision Control List viii Xerox DocuPrint P1202 Service Manual
Product Manual Title Part Number
P1202 Laser Printer Xerox DocuPrint P1202 Service Manual 720P15700
Page Date Page Date Page Date Page Date
www.printcopy.info
www.printcopy.info

3/99
Xerox DocuPrint P1202 Service Manual 1-1 Service Call Procedures
Section 1
Service Call Procedures 1
1.1 Call Flow Diagram ..........................................................................1-2
1.2 Initial Actions..................................................................................1-3
1.3 Corrective Actions..........................................................................1-3
1.4 Final Actions...................................................................................1-4
www.printcopy.info
www.printcopy.info

3/99
Service Call Procedures 1-2 Xerox DocuPrint P1202 Service Manual
1.1 Call Flow Diagram
The basic troubleshooting steps are outlined in the Call Flow Diagram (Figure 1.1). All service calls
begin with Initial Actions and end with Final Actions.
Figure 1.1 Call Flow Diagram.
Initial Actions
Corrective Actions
RAPsParts List Repair Procedures
Wiring Data General Procedures
Final Actions Correct Any
Secondary Problems
Image Quality
www.printcopy.info
www.printcopy.info

3/99
Xerox DocuPrint P1202 Service Manual 1-3 Service Call Procedures
1.2 Initial Actions
1Question the operator and verify the problem.
2Check that the printer paper path is clear of foreign matter such as staples, paper clips, and
paper scraps.
3After you have identified the problem symptom, check the following items:
• The printer is connected to a wall power outlet, and the outlet is supplying the correct volt-
age.
• The printer power cord is not frayed or broken.
• The printer is correctly grounded / earthed.
• The printer is in an appropriate operating environment, with no extremes of heat, humidity,
or dirt.
• The printer is not exposed to direct sunlight.
• The printer is on a level and stable surface.
1.3 Corrective Actions
1If the printer has an obvious failure or fault, you can go directly to the appropriate Repair
Procedure (Section 4) or Repair Analysis Procedure (RAP) (Section 7) and begin corrective
action.
2If the fault is not obvious, follow the Entry Level RAP (Section 7) to identify the problem and begin
corrective action.
3After all corrective actions have been made, perform Final Actions.
www.printcopy.info
www.printcopy.info

3/99
Service Call Procedures 1-4 Xerox DocuPrint P1202 Service Manual
1.4 Final Actions
1Run Test Prints to evaluate print quality.
2Perform the Image Quality Checkout procedures in section 7 to correct any print quality defects.
3Correct any secondary problems (return to Corrective Actions, if necessary).
4Reinstall the machine covers.
5Clean the machine and the work area.
6Ask the customer to send a print job to verify printer operation.
7Provide operator training as required.
8Close the call.
www.printcopy.info
www.printcopy.info

3/99
Xerox DocuPrint P1202 Service Manual 2-1 Printer Specifications
Section 2
Printer Specifications 2
2.1 Electrical Specifications ................................................................2-3
2.1.1 Power Sources and Consumption...........................................2-3
2.1.2 Power On/Off...........................................................................2-3
2.1.3 Power Saver............................................................................2-3
2.1.4 Mechanical...............................................................................2-3
2.1.5 Consumables...........................................................................2-3
2.2 Physical Location...........................................................................2-4
2.3 Functional Specifications..............................................................2-4
2.4 Environment....................................................................................2-5
2.5 Options............................................................................................2-5
2.5.1 PostScript Simms ....................................................................2-5
2.6 Paper Specifications ......................................................................2-5
2.6.1 Paper limitations ......................................................................2-6
2.7 Operating Language and Emulation.............................................2-7
2.8 Communication Interfaces ............................................................2-7
www.printcopy.info
www.printcopy.info

3/99
Printer Specifications 2-2 Xerox DocuPrint P1202 Service Manual
2.9 Status Display / Controls ...............................................................2-8
www.printcopy.info
www.printcopy.info

3/99
Xerox DocuPrint P1202 Service Manual 2-3 Printer Specifications
2.1 Electrical Specifications
Video Controller (Video I/F)
Video Controller Board (Video I/F) is installed in the printer.
Video Interface Specification to be provided, if necessary.
2.1.1 Power Sources and Consumption
The Xerox P1202 printers are available in either a 110 or a 220 volt configuration.
2.1.2 Power On/Off
The Xerox P1202 printers have an on/off power switch located on left rear corner of machine. The
machine is equipped with a grounded power socket. Printer will power down automatically, (default
condition, which can be disabled by the customer), when not used for a period of time (see Power
Saver).
2.1.3 Power Saver
The Power Saver reduces power automatically when the printer does not receive data for a period of
time. Power Saver is a menu selection in the Remote Control Panel (RCP) software which provides the
user with the ability to control, when the printer enters the power saver state. The default value is 30
minutes. In Power Save mode, the power consumption is under 30 watts.
2.1.4 Mechanical
2.1.5 Consumables
PRINTER CARTRIDGE: 6000 pages at 5% coverage; more with use of the toner saving Econo Mode.
The starter kit cartridge shipped with the printer is 3.0 K pages with 5% coverage.
Line
Voltage Line Voltage Tolerance Frequency Frequency Tolerance Running Power Consumption Power Saver
100/127 VAC 90 - 137 VAC 60 Hz 57 - 63 Hz 300 Watts (Average) 30 Watts
200/240 VAC 189 - 264 VAC 50 Hz 47 - 53 Hz 300 Watts (Average) 30 Watts
Unit Width Depth Height Weight
Metric 360 mm 426 mm 220 mm (One Paper Tray)
327 mm (Two Paper Trays) 11 Kg
SAE 14.2 in. 16.8 in. 8.7 in (One Paper Tray)
12.9 in (Two Paper Trays) 15.4 lbs
www.printcopy.info
www.printcopy.info

3/99
Printer Specifications 2-4 Xerox DocuPrint P1202 Service Manual
2.2 Physical Location
Place your printer on a flat, stable surface near your workstation. Leave enough space around the
printer, so that you can easily:
• open the printer cover
• load the paper
• retrieve paper
• open the front single sheet output tray and retrieve the paper in the front output tray
• allow air circulation around the vents to prevent the printer from overheating
2.3 Functional Specifications
Warm Up Time First Print Out Print Speed - ppm
(pages per minute) Resolution - dpi (Dots per inch)
From Sleep mode to
Standby mode
under 45 seconds
From Standby mode
20 seconds
From Power save mode
30 seconds
12 ppm True 600 x 600 dpi
RET of 1200 x 1200
egl_419a
14.2 inches
(360mm)
8.7 inches
(220mm)
16.8 inches
(426mm)
12.9 inches
(327mm)
www.printcopy.info
www.printcopy.info

3/99
Xerox DocuPrint P1202 Service Manual 2-5 Printer Specifications
2.4 Environment
The printer must not be exposed to:
• abrupt changes in temperature or humidity
• any condensation
• direct sunlight
• chemicals
• vibration
• dusty or dirty environments.
2.5 Options
MEMORY/DRAM: 4MB on board memory standard.
• With the one available memory expansion slot, memory can expand to include a 4, 8, 16, or 32MB
SIMM. Maximum memory is 36 MB.
• The SIMM is a customer supplied item (72 pin, 60ns or 50ns, 32 bit, No Parity, EDO SIMM).
2.5.1 PostScript SIMMs
• PostScript requires a total of 12 MB of printer memory. The P1202 comes with 4 MB standard.
NOTE: The PostScript SIMM is an option. (The customer is required to provide the PostScript SIMM).
2.6 Paper Specifications
Papers that meet the specifications may be fed either through the Multipurpose Paper Feeder, or the
Manual Single Sheet Feeder. If you use thick paper (from the RCP menu) with a weight of more than 90
g/m2(40lb), or envelope, you must insert paper into the Manual Single Sheet Feeder and select Thick
Paper.
The Multipurpose Paper Feeder will hold 100 sheets of 60 - 126 g/m2(16 - 43 lb), or 10 envelopes, 25
labels, 30 transparency films and 25 paper labels.
Temperature Humidity Noise Level
Operating 10o- 32.5oC
50o- 90.5oF 20 - 80% RH Sleep (Power Saver) - Background
Standby - Under 29 dB
Printing - Under 47 dB
Within 5o
Shipping -20o- 40oC
-4o- 104oF 10 - 95% RH - - - - - - - - - - - -
www.printcopy.info
www.printcopy.info

3/99
Printer Specifications 2-6 Xerox DocuPrint P1202 Service Manual
The Manual Single Sheet Feeder capacity is 1 sheet 60 - 135 g/m2.
2.6.1 Paper Limitations
The following are recommended for optimum performance:
• Adhesive label sheets specifically designed for laser printers.
• Transparencies specifically designed for laser printers
• Envelopes with peel-off adhesive strips or more than one fold-over flap to seal must have
adhesives compatible with the heat and pressure of the printer's fusing process.
• Avoid:
— Paper with embossed lettering, perforations, or rough texture.
— Paper to which color was added after the paper was made.
— Printed forms whose ink is not for laser printing.
Most papers that meet the above specifications may be fed either through the multisheet or the single
sheet paper feeder. Some media meets the specifications but is not ideal for feeding, e.g., paper that is
either highly textured, thicker than normal for its weight, or unusually smooth.
Paper types
Size
Input Source/Capacity *
Tray 1 or 2 MPF
Paper
Letter (8.5 x 11 in.)
Legal (8.5 x 14 1n.)
Executive (7.25 x 10.5 in.)
Foilo (8.5 x 13 in.)
A4 (210 x 297 mm)
ISO-B5 (176 x 250 mm)
A5 (148 x 210 mm)
250
250
250
250
250
250
--
100
100
100
100
100
100
100
Envelopes
Com-10 (4.125 x 9.5 in.)
Monarch (3.875 x 7.5 in.)
C5 (162 x 229 mm)
DL (110 x 220 mm)
C6 (114 x 162 mm)
--
--
--
--
--
10
10
10
10
10
Cards
Transparency film
Labels
-- 1 at a time
* Depending on paper thickness, maximum capacity may be reduced
www.printcopy.info
www.printcopy.info

3/99
Xerox DocuPrint P1202 Service Manual 2-7 Printer Specifications
2.7 Operating Language and Emulation
The Xerox P1202 uses the PCL5e and PCL6 language.
The Xerox P1202 emulates the HP 6P and previous
(PCL6).
2.8 Communication Interfaces
NOTE:IEEE 1284 EPP is not supported.
Parallel port - Centronics IEEE P1284 compatible bi-directional (Nibble, Byte and ECP).
Serial port - RS-232C; supports data transfer up to 11.52K bps.
Auto Interface Switching (AIS), when the serial interface is installed.
LocalTalk - Macintosh Host Interface, 230.4 bps, SDLC, FMO Coding, RS-232C
USB (Universal Serial Bus) port is standard with the P1202 printer.
www.printcopy.info
www.printcopy.info

3/99
Printer Specifications 2-8 Xerox DocuPrint P1202 Service Manual
2.9 Status Display/Controls
The printer’s status is controlled and displayed by both:
• a panel with a Front Panel Key and four LED's
1) Error Light
2) Paper light
3) On-Line light
4) On-Line / Reset Key
• software programs that enable the user to:
— monitor the printer's status on the computer screen (the Status Monitor). The Status Monitor is
a program that runs in background and automatically displays a message(s) on your computer
screen whenever the printer status changes (not available for NT 4.0).
— change printer settings from the computer screen (Remote Control Panel). The Remote
Control Panel (RCP) program allows you to view and change print settings for the following
operating systems; DOS, Windows 3.1, Windows 95, Windows 98, and NT 4.0.
Table 1:
READY
Green LED
Steady On Online and Ready to Print
Blinking Receiving data, processing, or printing
Double blink every 2 or 3 seconds Waiting with data in printer
PAPER
Amber LED Blinking Out of Paper
Steady On,(ERROR steady on) Paper Jam
MANUAL
Amber LED Blinking Manual Feed
Steady On (with ERROR LED on) N/A
ERROR
Red LED
Blinking Recoverable error,
Press Panel Key or wait for timeout
Steady On Unrecoverable error or cover open
