Xinje XC Series User manual

1 Summary Of XC Series PLC
XC series PLC include diverse CPU units and expansions with powerful functions. This chapter
will mainly tell the main specifications, the whole products range, each part's description and
name template composing this four items.
1-1．Products Specifications
1-2．Model Composing and Model List
1-3．Each Part's Description

1-1．Products Specifications
1-1-1．CPU Units
XC series PLC's CPU units has many subsidiary products line, the combination can be make
freely.
lI/O Points: 10、14、16、24、32、48、60 points
lOutput Type: Transistor、Relay、R/T mixed type
lInput Type: PNP、NPN
lPower Supply Type: AC220V、DC24V
lSubsidiary※1XC1、XC2、XC3、XC5、XCM
Series Type Description
XC1 Economic Type
Include 10I/O、16I/O、24I/O、32I/O
Suitable for common simple applications which has less I/O
requirement, Do not support free communication, expansion, BD
cards.
XC2 Basic Type
Include 14I/O、16I/O、24I/O、32I/O、48I/O、60I/O
Equipped XC series PLC's basic functions, the CPU unit can't work
with expansions, but can work with BD card. Equipped with high
speed operation ability.
XC3 Standard Type
Include 14I/O、24I/O、32I/O、48I/O、60I/O
XC series standard models, equipped with full functions, fulfill the
user's diverse requirements
XC5 Strength Type
Include 24I/O、32I/O、48I/O、60I/O
Besides XC3 series functions, XC5 series PLC added following
functions:
24I/O, 32I/O models have 4CH pulse output;
48I/O, 60I/O support CAN-bus, users can realize CAN bus network
functions
XCM
Motion Control
Type
Include 24I/O、32I/O
Besides XC series basic functions, XCM models support powerful
pulse output functions and rich motion control instruction. The
models are designed especially for motion control.
lSpecial Type XC3-19AR-E (Combine analogue I/O with digital I/O in one body）
※2
※1：For each subsidiary series's model list and functions, please refer to Appendix 4;
※2：XC3-19AR is not included in this manual. For the using method, please refer to《XC3-19AR-E manual》。
Diverse Models 1

XC series PLC have abundant basic functions and diverse special functions. Each subsidiary series
faces to different application field.
Abundant Basic Functions
lHigh Speed Operation
Basic operation instruction 0.2～0.5us, the scan time is 10,000 steps per 5ms, the
program space reaches to 160K.
lAbundant expansions
The CPU units usually support 7 different expansions and 1 BD card.
lMultiple Communication Ports
The CPU units have 1～4 communication ports, support RS232、RS485、CAN bus; can
work with many peripheral devices like inverters, instruments, printers etc.
lRich soft device space
The five subsidiary series of XC series PLC are equipped with different internal
resource to apply different requirements.
The resource space reaches: 1024 points flow S、8768 points middle relayM、544 points
input relay、544 points output relay、640 points Timer T、640 points counter C、9024
points data register D、2048 points FD、36864 points expansion register ED。
l2 types of program form
XC series PLC support 2 types of program form, i.e instruction list and ladder chart. The
two types can switch to each other;
lAbundant instructions
Abundant instructions, besides the basic order control, data transfer and compare,
arithmetic, data loop and shift, the PLC also support pulse output, high speed counter,
interruption, PID etc.
lReal time clock
XC series PLC are equipped with real time clock, for time control;
lCompact size, convenient to install
XC series PLC has compact size, convenient to install. User can choose DIN or screw
installation style.
Strength Special Functions
lHigh Speed Pulse Counter can reach 80KHz
The CPU units of XC2/XC3/XC5 are equipped with 3 channels, 2 phases high speed
counter and high speed counter comparator; can realize single phase, pulse+direction,
AB phase count, the frequency can reach 80KHz.
lPowerful communication&network ability
With multiple communication port and diverse communication protocol like Modbus
protocol、free communication protocol etc, it's easy to build the different network; In
Strong Functions2

Modbus network, PLC can be master or slave; XC5 series can build CAN bus; via
T-BOX module can build Ether net; via G-BOX can work with GPRS network;
lHigh Speed Pulse Output can reach 400Hz
XC series PLC※1 are generally equipped 2 pulse output terminals, can output 400KHz
pulse; the special model※2has 4 channels pulse output functions
lInterruption Function
XC series PLC have interruption function, including external interruption, time
interruption and high speed counter interruption; they can meet different requirements.
lSwitch I/O points freely
XC series PLC has special switch I/O points function, that is developed in case of
terminals broken, there is no need to change the program;
lC language function block
Write the function block with C language, the program is more secured. Meantime, with
the abundant operation functions, the PLC can realize more functions, which saves great
internal space, improve the program efficiency;
lPID function on CPU units
The CPU units of XC series PLC※1 has PID control and auto tune function.
lSequential Function Block (BLOCK)
In sequential function Block, users can realize the sequential action of instructions. This
function is suitable to apply on pulse output, communication, motion control, inverter's
read/write etc. This function simplify the program editing greatly.
l24 segments high speed counter interruption
There are 24 segments 32 bits initial value in high speed counter of XC series PLC※1 .
Each segment can generate interruption with perfect real time ability, realize electric
cam function;
lPWM pulse width modulation
XC series PLC※1 have PWM pulse width modulation function, this function can apply
to DC motor control;
lFrequency testing
XC series PLC※1can realize frequency testing
lPrecise Time
XC series PLC※1can realize precise time, the precise timer is a 32 bits timer of 1ms
lMotion Control
XCM series PLC※1are motion control models, can realize circular interpolation, position
control etc.
※1：Here XC series PLC refer to the PLC which can realize the mentioned functions. That's to say, not all XC
series PLC can realize the mentioned function. For details, please refer toAppendix 4.
※2：here the special model refers to XC5-32T-E

When program the PLC via XCPPro, users can feel it Humanism and easy to get familiar.
lSwitch ladder and instruction list freely
lOffer soft device comment, ladder comment, instruction hint functions etc.
lOffer many types of program interface for special instructions, convenient to write the
instructions.
lPerfect monitor mode: ladder monitor, free monitor, soft devices monitor
lMany windows in one interface, convenient to manage.
※1：For the detailed XCP Pro software application, please refer to 《XC series PLC user manual【software】》.
1-1-2．Expansions
To fulfill the field control requirements better, XC series PLC can work with expansions, each
CPU units can link 7 expansions.
lDiverse Types
Digital I/O expansions, analogue I/O modules, temperature control modules and
function mixed modules etc.
lCompact Size
lDC24V power supply (32I/O modules areAC220V power supply).
lAnalogue、temperature modules all include PID tune function.
Easy to Program3
Expansion Modules1
Digital I/O
Modules
Power Supply: DC24V
AC220V
Input points: 8-32
Output points: 8-32
Output Type: Relay
Transistor
Analogue I/O
Modules
Power Supply: DC24V
Type: DA、AD
AD/DA
DAchannel Nr.：2、4
AD channel Nr.: 4、8
Temperature
Control Modules
Power Supply: DC24V
Temperature: PT100
thermocouple
Temp. Channel Nr.: 6
PID Control: Included
Function Mixed
Modules
Power Supply: DC24V
AD: 3CH
Temperature: 4CH PT100
DA: 2CH

Besides the expansion modules, XC series PLC can also expand by the BD cards. The BD cards
are small PCB cards which can insert into PLC from the BD port (on CPU unit), so this kind of
expansion doesn't take extra space.
lAnalogue and temperature type: XC-2AD2PT-BD
lCommunication: XC-COM-BD
※1: User should install and configure before using the BD cards. For details, please refer to:《XC series BD cards
user manual》.
1-2．Model Composing and Model List
1-2-1．Name Principle and Model list of CPU units
1：Series Name XC1、XC2、XC3、XC5、XCM
2：Input/Output Point 10、14、16、24、32、48、60
3：If Input is NPN R：Relay output
T：Transistor output
RT：Relay/Transistor mix output (Y0、Y1 are Transistor)
If Input is PNP PR：Relay output
PT：Transistor output
PRT ：Relay/Transistor mix output (Y0 、
Y1 are
Transistor)
4：Power Supply E：AC Power Supply（220V）
C：DC Power Supply（24V）
BD Card2
Name principle of XC series PLC CPU units:
XC3
1 2 3 4 5
Name Principle of CPU units1

※1：Generally, clock and RS485 are standard configuration on communication port. But some models are not
included. Please refer to Appendix 4.
lXC1 Series Model List
Model
AC Power Supply DC Power Supply
Relay output Transistor
output Relay output
Transistor
output
Input points
(DC24V)
Output
points
(R，T)
XC1-10R-E XC1-10T-E XC1-10R-C XC1-10T-C 5 5
XC1-16R-E XC1-16T-E XC1-16R-C XC1-16T-C 8 8
XC1-24R-E XC1-24T-E XC1-24R-C XC1-24T-C 12 12
N
P
N
XC1-32R-E
XC1-32T-E XC1-32R-C XC1-32T-C 16 16
XC1-10PR-E XC1-10PT-E XC1-10PR-C XC1-10PT-C 5 5
XC1-16PR-E XC1-16PT-E XC1-16PR-C XC1-16PT-C 8 8
XC1-24PR-E XC1-24PT-E XC1-24PR-C XC1-24PT-C 12 12
P
N
P
XC1-32PR-E
XC1-32PT-E XC1-32PR-C XC1-32PT-C 16 16
lXC2 Series Model List
Model
AC Power Supply DC Power Supply
Relay output Relay
output
Transistor
output
R/T Type
Input
points
(DC24V)
Output
points
(R，T)
XC2-14R-E XC2-14T-E XC2-14RT-E XC2-14R-C XC2-14T-C XC2-14RT-C 8 6
XC2-16R-E XC2-16T-E XC2-16RT-E XC2-16R-C XC2-16T-C XC2-16RT-C 8 8
XC2-24R-E XC2-24T-E XC2-24RT-E XC2-24R-C XC2-24T-C XC2-24RT-C 14 10
XC2-32R-E XC2-32T-E XC2-32RT-E XC2-32R-C XC2-32T-C XC2-32RT-C 18 14
XC2-48R-E XC2-48T-E XC2-48RT-E XC2-48R-C XC2-48T-C XC2-48RT-C 28 20
N
P
N
XC2-60R-E
XC2-60T-E XC2-60RT-E XC2-60R-C XC2-60T-C XC2-60RT-C 36 24
XC2-14PR-E XC2-14PT-E XC2-14PRT-E XC2-14PR-C XC2-14PT-C XC2-14PRT-C 8 6
XC2-16PR-E XC2-16PT-E XC2-16PRT-E XC2-16PR-C XC2-16PT-C XC2-16PRT-C 8 8
XC2-24PR-E XC2-24PT-E XC2-24PRT-E XC2-24PR-C XC2-24PT-C XC2-24PRT-C 14 10
XC2-32PR-E XC2-32PT-E XC2-32PRT-E XC2-32PR-C XC2-32PT-C XC2-32PRT-C 18 14
P
N
P
XC2-48PR-E XC2-48PT-E XC2-48PRT-E XC2-48PR-C XC2-48PT-C XC2-48PRT-C 28 20
CPU Units List
2

XC2-60PR-E XC2-60PT-E XC2-60PRT-E XC2-60PR-C XC2-60PT-C XC2-60PRT-C 36 24
lXC3 Series Model List
Model
AC Power Supply DC Power Supply
Relay output Relay
output
Transistor
output
R/T Type
Input
points
(DC24V)
Output
points
(R，T)
XC3-14R-E XC3-14T-E XC3-14RT-E XC3-14R-C XC3-14T-C XC3-14RT-C 8 6
XC3-24R-E XC3-24T-E XC3-24RT-E XC3-24R-C XC3-24T-C XC3-24RT-C 14 10
XC3-32R-E XC3-32T-E XC3-32RT-E XC3-32R-C XC3-32T-C XC3-32RT-C 18 14
XC3-48R-E XC3-48T-E XC3-48RT-E XC3-48R-C XC3-48T-C XC3-48RT-C 28 20
N
P
N
XC3-60R-E XC3-60T-E XC3-60RT-E XC3-60R-C XC3-60T-C XC3-60RT-C 36 24
XC3-14PR-E XC3-14PT-E XC3-14PRT-E XC3-14PR-C XC3-14PT-C XC3-14PRT-C 8 6
XC3-24PR-E XC3-24PT-E XC3-24PRT-E XC3-24PR-C XC3-24PT-C XC3-24PRT-C 14 10
XC3-32PR-E XC3-32PT-E XC3-32PRT-E XC3-32PR-C XC3-32PT-C XC3-32PRT-C 18 14
XC3-48PR-E XC3-48PT-E XC3-48PRT-E XC3-48PR-C XC3-48PT-C XC3-48PRT-C 28 20
P
N
P
XC3-60PR-E XC3-60PT-E XC3-60PRT-E XC3-60PR-C XC3-60PT-C XC3-60PRT-C 36 24
lXC5 Series Model List
Model
AC Power Supply DC Power Supply
Relay output Relay
output
Transistor
output R/T Type
Input
points
(DC24V)
Output
points
(R，T)
- XC5-24T-E - - XC5-24T-C - 14 10
- XC5-32T-E - - XC5-32T-C - 18 14
XC5-48R-E XC5-48T-E XC5-48RT-E XC5-48R-C XC5-48T-C XC5-48RT-C 28 20
N
P
N
XC5-60R-E XC5-60T-E XC5-60RT-E XC5-60R-C XC5-60T-C XC5-60RT-C 36 24
- XC5-24PT-E - - XC5-24PT-C - 14 10
- XC5-32PT-E - - XC5-32PT-C - 18 14
XC5-48PR-E XC5-48PT-E XC5-48PRT-E XC5-48PR-C XC5-48PT-C XC5-48PRT-C 28 20
P
N
P
XC5-60PR-E XC5-60PT-E XC5-60PRT-E XC5-60PR-C XC5-60PT-C XC5-60PRT-C 36 24
lXCM Series Model List
Model
AC Power Supply DC Power Supply
Input
points
Output
points

Relay output Relay
output
Transistor
output R/T Type
(DC24V)
(R，T)
- XCM-24T-E - - XCM-24T-C - 14 10
- XCM-32T-E - - XCM-32T-C - 18 14
N
P
N
- XCM-48T-E - - XCM-48T-C - 28 20
- XCM-24PT-E - - XCM-24PT-C - 14 10
- XCM-32PT-E - - XCM-32PT-C - 18 14
P
N
P
- XCM-48PT-E - - XCM-48PT-C - 28 20
※1：XC1 can also have special 20 I/O model
※2：XCM-48 is in developing
1-2-2．Expansion's name principle and module list
1：Series name XC
2：For Expansion E
3：Input points 8、16、32
4：For Input NPN Type: X
PNPType: PX
5：Output points 8、16、32
6：For output YR：relay output
YT：transistor output
lI/O expansions list:
Model
Output
Input
relay output transistor output
I/O
Points
Input
points
(DC24V)
Output
points
(R, T)
XC-E8X - - 8 8 -N
P
- XC-E8YR XC-E8YT 8 - 8
I/O
Expansion
1
The I/O expansions' name principle:
XC
1 2 3 4
E5 6

① For Expansion E
② Analogue Input 4AD：4CH analogue input
8AD：8CH analogue input
③
Analogue Output 2DA：2CH analogue output
4DA：4CH analogue output
④ PT100 Temperature 6PT：6CH PT100
⑤
K type thermocouple 6TCA：6CH thermocouple input (V3.1or above)
⑥ P、I、D tune P：with PID tune
- XC-E8X8YR XC-E8X8YT 16 8 8
XC-E16X - - 16 16 -
- XC-E16YR XC-E16YT 16 - 16
- XC-E16X16YR XC-E16X16YT 32 16 16
XC-E32X - - 32 32 -
N
- XC-E32YR - 32 - 32
XC-E8PX - - 8 8 -
- XC-E8YR XC-E8YT 8 - 8
- XC-E8PX8YR XC-E8PX8YT 16 8 8
XC-E16PX - - 16 16 -
- XC-E16YR XC-E16YT 16 - 16
- XC-E16PX16YR XC-E16PX16YT 32 16 16
XC-E32PX - - 32 32 -
P
N
P
- XC-E32YR - 32 - 32
Analogue&Temperature
Expansion
2
Analogue、Temperature model name Principle:
XC－E 4AD 4DA 6PT 6TCA – P
①②③④⑤⑥

Blank：without PID tune
lAnalogue、temperature modules list:
①
Analogue Input 4AD：4CH analogue input
8AD：8CH analogue input
② PT100 Temperature 6PT：6CH PT100 temperature Testing
③ K Type thermocouple 6TC：6CH thermocouple testing
④
P、I、D Tune P：with PID tune
Blank：without PID tune
⑤ For BD card BD
lBD card list
Model Description
XC-E8AD 8CH analogue input
XC-E4AD 4CH analogue input
Analogue
Input XC-E4AD2DA 4CH analogue input, 2CH analogue output
XC-E2DA 2CH analogue output
Analogue
Output XC-E4DA 4CH analogue output
XC-E6PT-P 6CH PT100 testing with PID tune
XC-E6TCA-P 6CH K type thermocouple testing, each channel's PID tune separately
XC-E3AD4PT2DA 3CH analogue input, 4CH PT100 testing, 2CH analogue output
Temperature
Testing
XC-E2AD2PT2DA 2CH analogue input, 2CH PT100 testing, 2CH analogue output
The BD card name principle:
XC－4AD 6PT 6TC– P– BD
①②③④⑤
BD Card
3

1-3．Each Part's Description
FG COM COM X0X1X2 X3X4X5X6X7 X15
X16X14
X13
X12
X11
X10 X17 X20
X21
PWR
Y
X
PORT1 PORT2
Y15
Y14
Y13
Y12COM3
Y5 Y7 Y6 Y11
COM4
Y10
Y4
Y3COM2
Y2
COM1
Y1
COM0
Y0
AB
24V0V
10 4 532
RUN
ERR
XC3-32R-E
67
76 23 5401
AO1
AO0
VO0 VO1
C1
C0
VI3
AI3
C0VI0 AI1
AI0 VI1 C2 AI2C3
VI2C1
PWR
AI
AO
1
2
3
4
5
6
7
89
10 11
12
13
14
15 16
17
19
18
Each part's name is listed below:
Number
Name Number Name
1 Input&power supply terminals 11 Installation holes (2)
2 Input terminal label 12 Screws to install/remove the terminals
3 Port to install BD card 13 Input LED
4 COM2 14 Action LED: PWR (power); RUN
(RUN); ERR (Error)
5 COM1 15 Expansion cable
6 Cover plate for COM port 16 Output terminals
7 Output terminal label 17 Action LED: PWR (power);
8 Output& 24V power terminals 18 Port to connect with expansion
9 Output LED 19 Input&power supply terminals
10 Port to connect with expansion
Model Description
Temperature XC-2AD2PT-BD 2CH analogue input, 2CH PT100 temperature testing
Communication
XC-COM-BD RS-485/232 communication
CPU Unit Expansion

2 The Specifications and Parameters of CPU
D0~D99
【D100~D149】※5
For Special Use※6D8000~D8029
For Special Use※6D8060~D8079
For Special Use※6D8120~D8179
For Special Use※6D8240~D8249
For Special Use※6D8306~D8313
Data Register (D) 288 words
For Special Use※6D8460~D8469
FD0~FD411
For Special Use※6FD8000~FD8011
For Special Use※6FD8202~FD8229
For Special Use※6FD8306~FD8315
For Special Use※6FD8323~FD8335
FlashROMRegister (FD) 510 words
For Special Use※6FD8350~FD8384
High Speed Dispose
Ability No
Password Protection 6 bits ASCII
Self-diagnose Function Power on self-check、monitor the timer、grammar check

2 The Specifications and Parameters of CPU
Items Specifications
Program Executing Form Loop scan form
Program Form Instruction、Ladder
Dispose Speed 0.5 us
Power Off Retentive Use FlashROM
User's program space※1128K
Total I/O 14 16 24 32 48 60
Input 8
X0~X7
8
X0~X7
14
X0~X15
18
X0~X21
28
X0~X33
36
X0~X43
I/O points
※2
Output 6
Y0~Y5
8
Y0~Y7
10
Y0~Y11
14
Y0~Y15
20
Y0~Y23
24
Y0~Y27
Internal Coils (X)※3X0~X777 (512)
Internal Coils (Y)※4Y0~Y777 (512)
M0~M2999
【M3000~M7999】※5Internal Coils (M) 8768
points For Special Use※6M8000~M8767
Flow (S) 1024
points
S0~S511
【S512~S1023】
T0~T99：100ms not accumulate
T100~T199：100ms accumulate
T200~T299：10ms not accumulate
T300~T399：10ms accumulate
T400~T499：1ms not accumulate
T500~T599：1ms accumulate
points 640
points
T600~T639：1ms precise time
Timer
Spec. 100mS timer: set time 0.1~3276.7sec. 10mS timer: set time 0.01~327.67sec.
1mS timer: set time 0.001~32.767sec.
C0~C299: 16 bits sequential counter
C300~C598: 32 bits sequential/inverse counter
C600~C619: single phase high speed counter
C620~C629: dual-phase high speed counter
points 640
points
C630~C639：AB phase high speed counter
Counter (C)
Spec. 16 bits counter: set value K0~32,767
32 bits counter: set value -2147483648~＋2147483647
D0~D999
【D4000~D4999】※5
Data Register (D) 2612
Words
For Special Use※6D8000~D8511
2 XC2 Series

2 The Specifications and Parameters of CPU
For Special Use※6D8630~D8729
FD0~FD255
FlashROM Register (FD) 512
words For Special Use※6FD8000~FD8255
High Speed Dispose
Ability High speed counter, pulse output, external interruption
Password Protection 6 bits ASCII
Self-diagnose Function Power on self-check、monitor the timer、grammar check
Items Specifications
Program Executing Form Loop scan form
Program Form Instruction、Ladder
Dispose Speed 0.5 us
Power Off Retentive Use FlashROM and Li battery
User's program space※1128K
Total I/O 14 24 32 48 60
Input 8
X0~X7
14
X0~X15
18
X0~X21
28
X0~X33
36
X0~X43
I/O points
※2
Output 6
Y0~Y5
10
Y0~Y11
14
Y0~Y15
20
Y0~Y23
24
Y0~Y27
Internal Coils (X)※3X0~X777 (512)
Internal Coils (Y)※4Y0~Y777 (512)
M0~M2999
【M3000~M7999】※5Internal Coils (M) 8768
points For Special Use※6M8000~M8767
Flow (S) 1024
points
S0~S511
【S512~S1023】
T0~T99：100ms not accumulate
T100~T199：100ms accumulate
T200~T299：10ms not accumulate
T300~T399：10ms accumulate
T400~T499：1ms not accumulate
T500~T599：1ms accumulate
points 640
points
T600~T639：1ms precise time
Timer
Spec. 100mS timer: set time 0.1~3276.7sec. 10mS timer: set time 0.01~327.67sec.
1mS timer: set time 0.001~32.767sec.
C0~C299: 16 bits sequential counterCounter (C) points 640
points C300~C598: 32 bits sequential/inverse counter
3 XC3 Series

2 The Specifications and Parameters of CPU
C600~C619: single phase high speed counter
C620~C629: dual-phase high speed counter
C630~C639：AB phase high speed counter
Spec. 16 bits counter: set value K0~32,767
32 bits counter: set value -2147483648~＋2147483647
D0~D3999
【D4000~D7999】※5Data Register (D) 9024
words For Special Use※6D8000~D9023
FD0~FD1535
FlashROM Register (FD)
2048
words For Special Use※6FD8000~FD8512
Expansion's Register (ED)
※7
16384
words ED0~ED16383
High Speed Dispose
Ability High speed counter, pulse output, external interruption
Password Protection 6 bits ASCII
Self-diagnose Function Power on self-check、monitor the timer、grammar check
Items Specifications
Program Executing Form Loop scan form
Program Form Instruction、Ladder
Dispose Speed 0.5 us
Power Off Retentive Use FlashROM
User's program space※196K
Total I/O 24 32 48 60
Input 14
X0~X15
18
X0~X21
28
X0~X33
36
X0~X43
I/O points
※2
Output 10
Y0~Y11
14
Y0~Y15
20
Y0~Y23
24
Y0~Y27
Internal Coils (X)※3512 points: X0~X777
Internal Coils (Y)※4512 points: Y0~Y777
M0~M3999
【M4000~M7999】※5Internal Coils (M) 8768
points For Special Use※6M8000~M8767
Flow (S) 1024
points
S0~S511
【S512~S1023】
4 XC5 Series

2 The Specifications and Parameters of CPU
T0~T99：100ms not accumulate
T100~T199：100ms accumulate
T200~T299：10ms not accumulate
T300~T399：10ms accumulate
T400~T499：1ms not accumulate
T500~T599：1ms accumulate
points 640 points
T600~T639：1ms precise time
Timer
Spec. 100mS timer: set time 0.1~3276.7sec. 10mS timer: set time 0.01~327.67sec.
1mS timer: set time 0.001~32.767sec.
C0~C299: 16 bits sequential counter
C300~C598: 32 bits sequential/inverse counter
C600~C619: single phase high speed counter
C620~C629: dual-phase high speed counter
points 640
points
C630~C639：AB phase high speed counter
Counter (C)
Spec. 16 bits counter: set value K0~32,767
32 bits counter: set value -2147483648~＋2147483647
D0~D999
【D4000~D4999】※5
For Special Use※6D8000~D8511
Data Register (D) 9024
words
For Special Use※6D8630~D8729
FD0~FD5119
FlashROM Register (FD)
6144
words For Special Use※6FD8000~FD9023
Expand the internal
registers (ED)※7
36864
words ED0~ED36863
High Speed Dispose
Ability High speed counter, pulse output, external interruption
Password Protection 6 bits ASCII
Self-diagnose Function Power on self-check、monitor the timer、grammar check
Items Specifications
Program Executing Form Loop scan form
Program Form Instruction、Ladder
Dispose Speed 0.5 us
Power Off Retentive Use FlashROM and Li battery
User's program space※1160K
I/O points Total I/O 24 32 48
5 XCM Series
