XPR Access WS4-1D-E Instruction manual

www.xprgroup.com 1
EN
ON
1
2
OFF
WS4ꢀ1DꢀE 1 Door access control unit with web access
DESCRIPTION
SPECIFICATIONS
FACTORY RESET
CHANGE PASSWORD
SOFTWARE SETTINGS
METHOD 1
ADDING READERS
METHOD 2
ADDING USERS
ADDING SLAVE CONTROLLERS
FIRST CONNECTION AND CONFIGURATION
If you can not connect, it is because your network does not recognize the name of the
WS4ꢀ2DꢀE controller. In this case, go to our web site http://www.xprgroup.com/prod-
ucts/ws4/ and download the tool called “Device Finder”.
The “Device Finder” will enable you to ind out the IP address of the WS4ꢀ1DꢀE controller.
Run the “Device Finder” and you will get a list of all the WS4 controllers connected in
your network, including their IP addresses, just like the picture below.
To add 2 readers on 1 Door, select the reader (ig.2) and ther e, for “Type of Access”
select “Access with 2 readers” (ig 5). F ill the form for both readers and they will
merge in one door (ig. 6)
WS4 system can manage up to 10 WS4 boards in the same installation (with up to 20
doors, whether single or double). One WS4ꢀ1DꢀE must be master, the others must be
slaves. The master/slave selection is made with Dip-switch 2: OFF - Master (factory
setting), ON - Slave.
Go to “Doors” and click on the link “Add slave”(ig. 1). Enter the serial number of the
WS4ꢀ1DꢀE to be added and click Search. If it inds it, the s ystem directly adds this slave
into the installation and you can conigur e its doors (ig.2).
In case of error, a message is displayed in red.
Go to Users (ig. 1), select “New”(ig.2) and then ill the f orm (Name, category, card
number...)(ig. 3).
Open a browser and type the IP of the WS4ꢀ1D controller and you will be prompted to
the login page.
User Name: admin
Password: WS4 followed by Dash and the Serial Number (ex. WS4ꢀ110034) just like the
image below, all in capital letters without space.
QUICK USER GUIDE
• Capacity: 2500 Users
• Events: 50000 max.
• Doors: 1 (max. 20 doors in same network)
• Readers: 2
• Door contact inputs: 1
• Push button inputs: 1
• Supply for the readers: 250 mA each max.
• Supply for the locks: 600 mA each max.
• Relay characteristics: 2A/48 VAC/DC
• Processor: ARM A5 - 528 Mhz
• Memory: 64 MB Ram DDR2 133 Mhz
• TCP/IP connection: 10/100/1000 Base-T – HTTP or HTTPS
• Dimensions (mm): 130 x 86 x 18 mm
• Operating temperature: 0 °C to +50 °C
• Humidity: 0% to 85% (non-condensing)
• Tamper: Yes
• Wiegand readers connection: Yes, via Wiegand to RS485 converter - WS4ꢀCNV
• Elevator feature: Yes, 2 elevators per installation, each - 24 loor s
• Interlock, Anti pass back, people counter, presence, system logs, reports in CSV
DIPSwitch
pos. 1
1
2
3
The WS4ꢀ1DꢀE does not have default IP address. By default is set to DHCP. There are 2
methods to connect to and conigur e WS4ꢀ1DꢀE - LAN and Standalone method.
In this conigur ation, the network’s DHCP server will assign an IP address to your WS4ꢀ1DꢀE
In this conigur ation, the WS4ꢀ1DꢀE will assign an IP address to your PC. The PC must be set to obtain IP
address automatically.
(For use in a home or business LAN network)
(For standalone use - without LAN network)
1. Put the DIP switch 1 in position OFF.
2. Connect a cable from your network to the ethernet connector of Ws4ꢀ1DꢀE.
3. Open a web browser and enter http://ws4 followed dash and the serial number of
the WS4ꢀ1DꢀE controller
1. Put the DIP switch 1 in position ON.
2. Connect a cable from your PC directly to the ethernet connector of WS4ꢀ1DꢀE.
3. Open a web browser and enter the following IP - 192.168.50.100, then put the login
credentials like explained above
DIP Switch 1, 2 and the tamper allows a complete re-initialization of the system.
1. Unplug the TCP/IP network cable (Rj45).
2. Set the two dip switches to position ON.
3. Wait until the green COMM LED lashe s.
4. Close and reopen the Tamper 3 times in 10 seconds.
DIP Switch 1 and 2 allows to log into the system as an administrator if login
or password is forgotten.
1. Unplug the TCP/IP network cable (Rj45).
2. Set the two dip switches to position ON.
3. Wait until the green COMM LED lashe s.
4. To log into the system as an administrator: close the Tamper for
15 seconds, then release it.
Go to “Doors”, select the reader(ig.2) and then select the type of the r eader in the
ield ” Card”. (ig. 3). While o¨ line, red LED blinks fast and buzzer beeps continuously.
Once communication is established, the red LED and the buzzer stop. Green LED
starts to blink continuously. If you want to stop the green LED, go to Settings/System
Options and select for the backlight ON or OFF (not default) ig. 4
ON
1
2
OFF
ON
1
2
OFF
ig.1
ig. 3
ig. 5
ig.1
ig.2
Switch
Master
DIP switch 2
OFF
Slave 1
DIP switch 2
ON
Slave 9
DIP switch 2
ON
ig. 3
ig.6
ig. 4
ig.2
ig.1
ig.2
WS4ꢀ1DꢀE is a 1 door control unit designed to operate with readers with RS485 output.
There is no need to install any software. There is no need to have a dedicated PC
either. Everything is available online and the operators just need to register with
controller’s serial number to start using the software application.
Serial number
DIP Switch pos. 1
Factory reset
Change
password
Master/
Slave DIP switch 2 - ON
NLDE
ES
IT
FR
EN

www.xprgroup.com 2
EN
V+
V- +
-
5
5
7
6
ON
1 2
OFF
Connection example of 1 door
This product herewith complies with requirements of EMC directive 2014/30/EU.
In addition it complies with RoHS2 directive EN50581:2012
Run Led Box Tamper
Led Comm
Net
Reader
Reader
Door contact
Electromagnetic Lock 12V/600mA max
Power supply 14,2VDC
Push button
Address 0
Address 1
See user manual
12V battery
- For doors equipped with 2 readers, one must be at address 0 and the other at address 1. If there is
only 1 reader, then it is recommended to be put with address 0.
- LIYCY cable, twisted pair, up to 80m. (5)
If more than 80 m. are needed, then termination resistors(120 ohm) may be required at both ends of
the RS485 line, while taking into consideration the lengths proposed on our web site.
- Alarm cable 2x0,22 (6)
- The cross section of the cable depends on the current needed by the lock (7)
Note: The elevators relay boards (WS4ꢀRBꢀ12) are connected on the same RS485 lines as the readers.
OFF ON
1Lan Autonomous
2Master Slave
Dip Switch
