Xterra SB440r User manual

OWNER’S MANUAL

Xterra SB440r Bike
1
Product Registration…………………………………………………………………………..2
Important Safety Instructions…………………………………………………………………3
Important Electrical Information………………………………………………………………4
Important Operation Instructions……………………………………………………………..4
Assembly Instructions………………………………………………………………………….5
Features………………………………………………………………………………………..13
Operation of Your New Bike……………………………………………………………..…..14
Maintenance……………………………………………………………………………………20
Manufacturer’s Limited Warranty…………………………………………………………….21
Serial number sticker location
Table of Contents

Xterra SB440r Bike
2
Thank you for your purchase of this quality recumbent bike trainer from Xterra. Your new
bike has been manufactured by one of the leading fitness manufacturers in the world and
is backed by one of the most comprehensive warranties available. Xterra will do all we
can to make your ownership experience as pleasant as possible for many years to come.
If you have questions, or if parts are missing or damaged, or you require customer
service, call [phone]. Please have your Model number and serial number handy
when you call.
Please take a moment at this time to record below the name of the store, their telephone
number, and the date of purchase for easy contact in the future. We appreciate your
confidence in Xterra and we will always remember that you are the reason that we are in
business. Please complete and mail your registration card today and enjoy your new
bike.
Yours in Health,
The folks at Xterra Fitness
Name of Dealer______________________________________
Telephone Number of Dealer___________________________
Purchase Date_______________________________________
RECORD YOUR SERIAL NUMBER
Please record the Serial Number of this fitness product in the space provided below.
Serial Number_______________________________________
REGISTER YOUR PURCHASE
The self-addressed product registration card must be completed in full and returned to Xterra
fitness, or visit: www.xterrafitness.com to register online.
SB440r_Ver.B
Product Registration
CONGRATULATIONS ON YOUR
NEW BIKE AND WELCOME
TO THE
XTERRA
FAMILY!

Xterra SB440r Bike
3
WARNING - Read all instructions before using this appliance.
■ Do not operate unit on deeply padded, plush or shag carpet. Damage to both carpet and
bike may result.
■ Before beginning this or any exercise program, consult a physician. This is especially
important for persons over the age of 35 or persons with pre-existing health conditions.
■ Keep children away from the bike. There are obvious pinch points and other caution areas
that can cause harm.
■ Keep hands away from all moving parts.
■ Never operate the bike if it has a damaged cord or plug. If the bike is not working properly,
call your dealer.
■ Keep the cord away from heated surfaces.
■ Do not operate where aerosol spray products are being used or where oxygen is being
administered. Sparks from the motor may ignite a highly gaseous environment.
■ Never drop or insert any object into any openings.
■ Do not use outdoors.
■ To disconnect, turn all controls to the off position, then remove the plug from the outlet.
■ Do not attempt to use your bike for any purpose other than for the purpose it is intended.
■ The hand pulse sensors are not medical devices. Various factors, including the user’s
movement, may affect the accuracy of heart rate readings. The pulse sensors are intended
only as exercise aids in determining heart rate trends in general.
■ Wear proper shoes. High heels, dress shoes, sandals or bare feet are not suitable for use on
your bike. Quality athletic shoes are recommended to avoid leg fatigue.
SAVE THESE INSTRUCTIONS - THINK SAFETY!
Important Safety Instructions

Xterra SB440r Bike
4
WARNING!
■ NEVER remove any cover without first disconnecting AC power supply.
■ If A.C. voltage varies by ten percent (10%) or more, the performance of your bike may be
affected. Such conditions are not covered under your warranty. If you suspect the voltage
is low, contact your local power company or a licensed electrician for proper testing.
■ NEVER expose this bike to rain or moisture. This product is NOT designed for Use outdoors,
near a pool or spa, or in any other high humidity environment. Maximum environmental
ratings are 40-120 degrees Fahrenheit, 95% humidity non-condensing (no water droplets
forming on surfaces).
■ NEVER operate this bike without reading and completely understanding the results of any
operational change you request from the computer.
■ Understand that changes in resistance do not occur immediately. Set your desired level on
the computer console and release the adjustment key. The computer will obey the command
gradually.
■ NEVER use your bike during an electrical storm. Surges may occur in your household power
supply that could damage bike components.
■ Use caution while participating in other activities while using your bike such as watching
television, reading, etc. These distractions may cause you to lose balance, resulting in
serious injury.
Important Electrical Information
Important Operation Instructions

Xterra SB440r Bike
5
#95 - 5/16" × 3/4"
Button Head Socket Bolt (6pcs)
#96 - 3/8" × 3-1/2" Carriage Bolt (2pcs)
#70 - 5/16" × 18 mm
Flat Washer (6pcs)
#97 - 3/8" × 23mm
Curved Washer (2pcs)
Step 2
#80. 3/8"
Nyloc Nut (4pcs)
ASSEMBLY PACK CHECK LIST
Step 1
#100 - 3/8"× 3" Hex Head Bolt (4pcs)
#99 - M6 × 15mm
Phillips Head Screw (4pcs)
#98 - 3/8"
Cap Nut (2pcs)
#71 - 3/8" × 19mm
Flat Washer (4pcs)
#73 - 5/16” Split
Washer (6pcs)
#90 - 5/16" × 1 - 1/4"
Hex Head Bolt (4pcs)
#81 - M5 × 12mm
Phillips Head Screw (4pcs)

Xterra SB440r Bike
6
Step 4
ASSEMBLY PACK CHECK LIST
Step 3
#101 - 3/8" ×3/4"
Self Tapping Screw (6pcs)
#71 - 3/8" × 19mm
Flat Washer (6pcs)
#81 - M5 × 12mm
Phillips Head Screw (4pcs)
#70 - 5/16" × 18 mm
Flat Washer (4pcs)
#95 - 5/16" × 3/4"
Button Head Socket Bolt (6pcs)
#102 - 5/16" × 19mm
Curved Washer (2pcs)
#70 - 5/16" × 18 mm
Flat Washer (2pcs)
#95 - 5/16" × 3/4"
Button Head Socket Bolt (2pcs)
#73 - 5/16”
Split Washer (2pcs)

Xterra SB440r Bike
7
#105 - Phillips Screw Driver (1 pc)
#104 - 14/15mm Wrench (1pc)
#103 - 12/14mm Wrench (1pc)
Tools
#106 - M5 Allen Wrench (1pc)

Xterra SB440r Bike
8
Before assembling the seat carriage to the bike, in Step 1 of the assembly instructions, you
need to slide the seat carriage forward on the chrome tube so it is a few inches away from
the end of the tube.
Seat carriage position as shipped.
Push handle down, Shipping position
Slide seat carriage forward
Seat carriage position for assembly.
Seat carriage position for assembly, a few inches from tube end
Important Assembly Information

Xterra SB440r Bike
9
STEP 1: SEAT ASSEMBLY & REAR STABILIZER
•Install the rear stabilizer tube(18) and secure with two 3/8” Carriage bolts (96), 3/8”
curved washers (97) and 3/8” cap nuts (98).
•Sitting next to the unit with the seat post (11) in your lap, connect the two wires together
(109 & 110). Secure the seat post to the main frame – be careful to not pinch the wires –
with the six 5/16” x 3/4” bolts (95), 5/16” split washers (73) and 5/16” flat washers (70).
•Lay the seat cushion (52) on the floor, cushion side down, and then lay the seat carriage
assembly (4 &14) on top of the seat cushion. Align the holes and secure the seat cushion
with four M6 x 15mm screws (99). Make sure seat cushion is facing the right direction.
•Secure the seat carriage assembly (4 &14) to the seat post with four 5/16” x 1-1/4” bolts
(90). Make sure these bolts are very tight. Assemble the plastic end caps (42) to the seat
carriage with four M5 x 12mm screws (81).
Assembly Instructions for Xterra SB440r

Xterra SB440r Bike
10
STEP 2: Rear Handle Bars
•Install the handlebars (6 & 7) to the seat carriage with four 3/8” x 3” bolts (100), 3/8” flat
washers (71) and 3/8” nuts (80). Be careful that the wires do not get pinched while
assembling the handlebars. The wires for the pulse sensors (111 & 112) will be connected in
step 4; just leave them hanging for now.

Xterra SB440r Bike
11
STEP 3: Console Mast & Seat Back
•Secure the seat back assembly (5) to the seat carriage with six 3/8” x 3/4” bolts (101) and
3/8” flat washers (71). Make sure these bolts are very tight.
•Run the two wires (107 & 109) through the bottom of the console mast and out the hole at
the top. Slide the console mast into the mating tube; pull slightly on the two wires while you
install the console mast so they do not get pinched. Secure the mast with six 5/16” x 3/4”
bolts, four 5/16” Washers (70) on the side bolts and two 5/16” curved washers (102) on the
two front bolts. Make sure to start all six bolts first before tightening all the way.

Xterra SB440r Bike
12
STEP 4: Console, Handle Bars and Pedals
•Install the front handlebars (3) and secure with two 5/16” x 3/4” bolts (95), 5/16” split
washers (73) and flat washers (70).
•Connect the two wires (107 & 109) to the mating connectors on the back of the console
(94) and secure the console with four M5 x 12mm screws (81). Be careful not to pinch the
wires between the console and mounting plate.
•Install the two pedals onto the crank arms. The left pedal (35) is a reverse thread so as you
turn the pedal bolt into the crank arm turn it counter-clockwise as if you are loosening it.
The right side pedal (36) is a normal thread so tighten it clockwise. Make sure the pedals
are as tight as you can possibly get them. It may be necessary to re-tighten them again
after a few hours of use.

Xterra SB440r Bike
13
Foot pedals
Through research performed with a leading sports scientist and physical rehabilitation expert the
engineers at Xterra have developed a breakthrough in pedal design. Typical stationary exercise
bikes are wider than a normal road bike to allow for the braking mechanism, pulleys, drive
components and beauty covers. Since the bike is wider, so is the distance between the pedals; this
width between the pedals is called the Q factor.
Xterra has designed our pedal system so the Q factor is the smallest in the industry, but we did not
stop there. We have also custom designed and tooled a new pedal that provides a two degree
inward tilt to compensate for the Q factor not being perfect. Having a small Q factor in addition to
the two degree inward tilt of the pedals puts the user into a biomechanical neutral alignment. This
means that your feet, ankles, knees and hips are lined up properly so you can workout more
comfortably for a longer time.
Transportation
The bike is equipped with two transport wheels, which are engaged when rear of the Bike is lifted.
POWER CONNECTOR LOCATED ON
FRONT, RIGHT HAND SIDE OF UNIT.
Features

Xterra SB440r Bike
14
Power up
The Bike is supplied with an external power supply. When power is connected to the Bike, the
console will automatically power up. If there is no input to the console for 20 minutes the console
will go to stand-by mode to save energy. To turn the console on press any key.
When initially powered on the console will perform an internal self-test. During this time all the lights
will turn on. When the lights go off the dot matrix display will show a software version (i.e.: VER 1.0)
and the time and distance windows will display an odometer reading. The odometer reading
displays how many hours the bike has been used and how many virtual miles the bike has gone.
The odometer will remain displayed for only a few seconds then the console will go to the start up
display. The dot matrix display will be scrolling through the different workout profiles of the
programs and operating instructions. You may now begin to use the console.
Operation of Your Bike Console

Xterra SB440r Bike
15
Console Operation
Quick Start mode
This is the quickest way to start a workout. After the console powers up you just press the Start key
to begin. In Quick Start the Time will count up from zero and the workload may be adjusted
manually by pressing the Up or Down keys. The dot matrix display will show a 1/4-mile track with a
lap counter in the center to monitor your progress (initially shows “¼ Mi”, the lap counter starts after
the first lap). Pressing the Enter key will switch the display from track to a hill type profile. To the
right of the dot matrix is a number that indicates your work level.
Basic information and functions:
The Data displays:
•Calories show an accumulation of calories burned (Kcal). The number shown is just an
estimate; your actual calorie burn most likely will be different. The only way to get an
accurate calorie reading is in a laboratory setting connected to a host of machines.
•Time shows elapsed time unless you set the timer to count down.
•Segment Time counts down the time left in the current segment (column) of the profile.
•Pulse indicates your heart rate if you are grasping the hand pulse sensors.
•RPM displays your pedaling speed in revolutions per minute.
•Speed shows your speed in miles per hour if there is an ‘M’ displayed in the distance
window and kilometers per hour if ‘Km’ is displayed.
•Distance displays accumulated mileage.
The Bike has a built in heart rate monitoring system. Simply grasping the hand pulse sensors on
the stationary handle bars will start the heart Icon blinking (this may take a few seconds). The Pulse
Display Window will display your heart rate, or Pulse, in beats per minute.
The Stop/Reset button actually has several functions. Pressing the Stop/Reset key once during a
program will Pause the program for 5 minutes. If you need to get a drink, answer the phone or any
of the many things that could interrupt your workout, this is a great feature. To resume your workout
during Pause just press the Start key. If the Stop/Reset button is pressed twice during a workout the
program will end and a summary of your workout is displayed. If the Stop/Reset key is held down
for 3 seconds the console will perform a complete Reset.
There is an Audio Input Jack on the front of the console and built-in speakers. You may plug any
low-level audio source signal into this port. Audio sources include MP3, Ipod, portable radio, CD
player or even a TV or computer audio signal.
Programming the console
Each of the programs can be customized with your personal information and changed to suit your
needs. Some of the information asked for during programming is necessary to ensure the readouts
are correct. You will be asked for your Age and Weight. Entering your Age is necessary during the
Heart Rate control program to ensure the correct settings are entered in the program. Entering your
Weight aides in calculating a more correct Calorie reading; although we cannot provide an exact
calorie count we do want to be as close as possible.

Xterra SB440r Bike
16
A message about Calories: Calorie readings on every piece of exercise equipment, whether it is
in a gym or at home, are not accurate and tend to vary widely. They are meant only as a guide to
monitor your progress from workout to workout. The only way to measure your calorie burn
accurately is in a clinical setting connected to a host of machines. This is because every person is
different and burns calories at a different rate.
Entering a program/Changing Settings
Press the program keys to scroll through the program selections. The profile for each program will
be displayed in the dot matrix window. Press the enter key to select a program and begin
customizing the settings. If you want to workout without entering new settings then just press the
Start key. This will bypass the programming of data and take you directly to the start of your
workout. If you want to change the personal settings then just follow the instructions in the
message window. If you start a program without changing the settings, the default settings will be
used.
NOTE: Age and Weight default settings will change when you enter a new number. So the last Age
and Weight entered will be saved as the new default settings. If you enter an age and weight the
first time you use the Bike you will not have to enter it every time you work out unless either your
age or weight changes or someone else enters a different age and weight.
Programming:
Manual
The Manual program works as the name implies, manually. This means that you control the
workload yourself and not the computer.
1. Press the Manual program button then press the Enter key.
2. The message window will ask you to enter your Age. You may adjust the age setting using
the Up and Down keys, then press enter to continue.
3. The message window will ask you to enter your Weight. You may adjust the weight setting
using the Up and Down keys, then press the Enter key to accept the new number and
proceed on to the next screen.
4. Next is the Time. You may adjust the Time and press enter to continue.
5. Now you are finished editing the settings and can begin your workout by pressing the Start
key.
6. Once the program starts the bike will be set to level one. This is the easiest level and it is a
good idea to stay at level one for a while to warm up. If you want to increase the work load at
any time press the Up key; the Down key will decrease the workload.
7. During the Manual program you will be able to switch between a quarter mile track or profile
display in the dot matrix window by pressing the enter key.
8. When the program ends the message window will show a summary of your workout. The
summary will be displayed for a short time then the console will return to the start-up display.

Xterra SB440r Bike
17
Preset Programs
The Bike has seven different programs that have been designed for a variety of workouts. These
seven programs have factory preset profiles for achieving different goals.
P-1 Sunrise
The Sunrise program simulates going up and down a gentle hill early in the morning. The
resistance in the pedals will steadily increase and then decrease during the program.
P-2 Journey
The Journey program is designed to maximize the burning of fat, a lifelong journey for some of us.
There are many schools of thought on the best way to burn fat, but most experts agree that a lower
exertion level that stays at a steady workload is the best. The absolute best way to burn fat is to
keep your heart rate at around 60% to 70% of its maximum potential. This program does not use
heart rate but simulates a lower, steady exertion workout.
P-3 Wild Ride
The Wild Ride program is designed to increase your cardio vascular function; this is exercise for
your heart and lungs. It will build up your heart muscle and increase blood flow and lung capacity.
This is achieved by incorporating a higher level of exertion with slight fluctuations in work….a real
Wild Ride!
P-4 Xtreme
The Xtreme program is designed to increase muscular strength in your lower body with extreme
resistance. This program will steadily increase in resistance to a high level and then keeps you
there. This is designed to strengthen and tone your legs and glutes.

Xterra SB440r Bike
18
P-5 Canyons
The Canyons program takes you through high levels of intensity followed by periods of low intensity.
This program increases your endurance by depleting your oxygen level followed by periods of
recovery to replenish oxygen. Your cardio vascular system gets programmed to use oxygen more
efficiently this way.
P-6 Thrill Hill
The Thrill Hill program combines a few types of workout in one, with variations of cardio and
strength portions to give you a thrill.
P-7 X-Country
The X-Country program simulates a cross country run across uneven terrain.
Programming Preset Programs:
1. Select the desired program then press the Enter key.
2. The message window will ask you to enter your Age. You may adjust the age setting, using the Up and
Down keys, then press the Enter key to accept the new number and proceed on to the next screen.
3. You are now asked to enter your Weight. You may adjust the weight number using the Up and Down
keys, then press enter to continue.
4. Next is Time. You may adjust the Time and press enter to continue.
5. Now you are asked to adjust the Max Level. This is the peak exertion level you will experience during
the program (work level at the top of the hill). Adjust the level and then press enter.
6. Now you are finished editing the settings and can begin your workout by pressing the Start key.
7. If you want to increase or decrease the workload at any time during the program press the Up or Down
key. This will change only the work level during the current segment.
8. During the program you will be able to switch between a quarter mile track or profile display in the
dot matrix window.
9. When the program ends the message window will show a summary of your workout. The summary will
be displayed for a short time then the console will return to the start-up display.

Xterra SB440r Bike
19
Custom User Defined Programs
The customizable User programs allow you to build and save your own workout. You can build your
own custom program by following the instructions below.
1. Select the User program (U1 or U2) then press enter.
2. The message window will ask you to enter your Age. You may enter your age using the Up
and Down keys, then press the Enter key to accept the new number and proceed on to the
next screen.
3. You are now asked to enter your Weight. You may adjust the weight number using the Up and
Down keys, then press enter to continue.
4. Next is Time. You may adjust the total program time and press enter to continue.
5. Now the message window will ask you to adjust the first segment level; use the up & down
keys to adjust. When you finish adjusting the first segment, or if you don’t want to change it,
then press enter to continue to the next segment.
6. The next segment will show the same level as the previously adjusted segment. Repeat the
same process as the last segment then press enter. Continue this process until all twenty
segments have been set.
7. The message window will ask you to press enter to save the program. After saving the
program, press start to begin.
8. If you want to increase or decrease the workload at any time during the program press the Up
or Down key. This will only affect the workload for the present position in the profile. When the
profile changes to the next column it will return to the preset work level.
9. During the User program you will be able to switch between a quarter mile track or profile
display in the dot matrix window by pressing the enter key.
10.When the program ends the message window will show a summary of your workout. The
summary will be displayed for a short time then the console will return to the start-up display.
Heart Rate Control Program operation
To start the HRC program follow the instructions below or just select the HRC program then the
Enter button and follow the directions in the message window.
1. Select the HRC program then press the Enter key.
2. The message window will ask you to enter your Age. You may enter your age using the Up and
Down keys then press the Enter key to accept the new number and proceed.
3. You are now asked to enter your Weight. You may adjust the weight number using the Up and
Down keys.
4. Next is Time. You may adjust the Time and press enter to continue.
5. You are now asked to select the Target heart rate Level. This is the heart rate level you will
experience during the program. Adjust the level and then press enter.
6. Now you are finished editing the settings and can begin your workout by pressing the Start key.
You can also go back and modify your settings by pressing the Stop key to go back one level, or
screen.
7. If you want to increase or decrease the target heart rate at any time during the program press
the Up or Down key.
When the program ends the message window will show a summary of your workout. The summary
will be displayed for a short time then the console will return to the start-up display
