Xterra 1640855 User manual

Retain For Future Reference
Owner’s Manual
Model No.
1640855
- Assembly
- Operation
- Adjustments
- Parts
- Warranty
CAUTION:
Read and
understand this
manual before
operating unit

CUSTOMER SERVICE 1-888-707-1880 Maurice Pincoffs Canada©2012
1
TABLE OF CONTENTS
Important Safety Instructions…………………………………………………………….. 2
Before you begin …………………….………………………………………………….. 4
Hardware list …………………………………………………………………………….. 5
Assembly instructions…………….……………………………………………………… 6
Treadmill operation ……………………………………………………………………… 9
Operation of the monitor ……………………………………….………………..………. 10
Folding Instructions ………………………………………………………………………..14
Part list ………………………………………………………………………………………15
Parts diagram ………………………………………………………………………………19
Belt adjustment ……………………………………………………………………………. 20
General Maintenance.……………….………………………………………….………… 22
Service check list ………………………………………………………………………….. 25
Manufacturer’s Limited Warranty………………………………………………………… 26

CUSTOMER SERVICE 1-888-707-1880 Maurice Pincoffs Canada©2012
2
IMPORTANT SAFETY INFORMATION
THIS UNIT IS INTENDED FOR HOUSEHOLD USE ONLY
READ ALL INSTRUCTIONS BEFORE USING THIS TREADMILL
▲CAUTION: Before starting any exercise program, it is recommended that you consult
your physician.
▲WARNING: Connect this unit to a properly grounded outlet only.
▲DANGER: To reduce the risk of electric shock, always unplug the treadmill from the
electrical outlet immediately after using and before cleaning.
WARNING
To reduce the risk of burns, fire, electric shock, or injury to persons:
1. Use 120 volt a.c. household current on a dedicated circuit.
Grounding Instructions
This product must be grounded. If it should malfunction or breakdown, grounding provides a path of least
resistance for electric current to reduce the risk of electric shock. This product is equipped with a cord
having an equipment-grounding conductor and a grounding plug. The plug must be plugged into an
appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances.
See diagram below for grounding methods.
2. It is the responsibility of the owner to ensure that all users of this treadmill are adequately
informed of all warnings and precautions.
3. The use of an extension cord with this product is not recommended. If an extension cord is
needed, use a short (less than 10 feet) heavy gauge (14 gauge or better) extension cord with a
three prong (grounded) plug and receptacle.
4. Never leave the treadmill unattended when plugged in. Remove the safety key and unplug the
unit from the outlet when not in use and before removing or replacing parts.
5. Never operate the treadmill if it has a damaged cord or plug, if it is not working properly, if it has
been dropped, damaged, or exposed to water. Never move the treadmill belt while the power is
turned off.
6. Do not pull the treadmill by the power supply cord or use cord as a handle. Keep cord away
from heated surfaces and open flames.
7. Fitness equipment must always be installed and used on a flat surface. Do not use outdoors or
near water. Do not place the unit on a loose rug or uneven surface. It is recommended to use
an equipment mat to prevent the unit from moving while it is being used, which could possibly
scratch or damage the surface of your floor. It is recommended to have a minimum of 3 metres
safe clearance on all sides of the treadmill while in use.
8. Keep the treadmill indoors, away from moisture and dust. Do not put the treadmill in a garage,
covered patio or near water.
9. Do not operate the treadmill where aerosol products are used or where oxygen is being
administered.
10. Read, understand and test the emergency stop procedure before using the treadmill (see
operation and adjustment section)
11. Do not insert any objects into any openings.
12. Inspect and properly tighten all parts of the treadmill regularly.
13. Keep children and pets away from this equipment at all times while exercising.

CUSTOMER SERVICE 1-888-707-1880 Maurice Pincoffs Canada©2012
3
14. Handicapped individuals should have medical approval and close supervision when using this
treadmill.
15. Do not place hands or feet under the treadmill. Always keep hands and legs off of the treadmill
when others are using it.
16. Never turn on treadmill while standing on treadbelt. Always hold the handrails while using the
treadmill. Always return the treadmill to the slowest speed to provide for safe dismount and
low speed restart.
17. To disconnect, turn all controls to the off position, then remove plug from outlet.
18. Do not attempt to raise, lower or move the treadmill until it is properly assembled. See
the assembly and how to fold and move the treadmill section. Care must be taken when lifting
or moving the equipment, so as not to injure your back. Always use proper lifting techniques.
19. Use the treadmill only for its intended use as described in this manual. Do not use any
attachments that are not recommended by the manufacturer.
20. User weight should not exceed 350 lbs (159 kg).
21. Never allow more than one person on the treadmill at once.
22. Warm up 5 to 10 minutes before each workout and cool down 5 to 10 minutes afterward. This
allows your heart rate to gradually increase and decrease and will help prevent straining
muscles.
23. Never hold your breath while exercising. Breathing should remain at a normal rate in
conjunction with the level of exercise being performed.
24. Start your program slowly and very gradually increase your speed and distance.
25. Always wear suitable clothing and footwear while exercising. Do not wear loose fitting clothing
that could become entangled with the moving parts of your treadmill. Do not walk or jog
barefoot, in stocking feet or loose fitting shoes or slippers.
26. This treadmill is intended for in-home use only. Do not use the treadmill in any commercial,
rental or institutional setting.
27. Never use your treadmill during electrical storms. Surges may occur in your household power
supply that could damage the treadmill components.
28. Use caution while participating in other activities while walking on your treadmill; such as
watching television, reading etc. These distractions may cause you to lose your balance or
stray from walking in the center of the belt; which may result in serious injury.
▲WARNING: Before beginning any exercise program consult your physician. This is especially important for
individuals over the age of 35 or persons with pre-existing health problems. Read all instructions before
using any fitness equipment. We assume no responsibility from personal injury or property damage
sustained by or through the use of this product.
SAVE THESE INSTRUCTIONS

CUSTOMER SERVICE 1-888-707-1880 Maurice Pincoffs Canada©2012
4
Before you begin.
Thank you for purchasing our product. Even though we go to great efforts to ensure the quality of each
product we produce, occasional errors and /or omissions do occur. In any event should you find this
product to have either a defective or a missing part please contact us for a replacement.
This product has been designed for home use only. Product liability and guarantee conditions will not be
applicable to products being subjected to professional use or products being used in a gym center.
This exercise equipment was designed and built for optimum safety. However, certain precautions apply
whenever you operate a piece of exercise equipment. Be sure to read the entire manual before
assembly and operation of this machine.
Before reading further, please familiarize yourself with the parts that are labeled in the drawing below.
MAX. USER WEIGHT LIMIT 159 KGS (350 LBS)
Safety Key
Handpulse
Locking
Knob
Console
Upright
Main Frame
Wheel
Breaker
On/off switch
Motor cover
Foot rail
Adjustment bolts
Walking belt
Speed adjusting switch
Incline adjusting switch

CUSTOMER SERVICE 1-888-707-1880 Maurice Pincoffs Canada©2012
5
HARDWARE LIST
#148.Ø8 × 1.5T
Split Washer (4pcs) #88.5 × 16m/m
Tapping Screw (4pcs)
#94.Ø5/16" × 19 × 1.5T
Curved Washer (2pcs)
#132. M5
Speed Nut Clip (4pcs)
#93.5/16" × 15m/m
Button Head Socket Bolt
(8pcs)
#33.Safety Key (1pc)
#90.5/16" × 3/4"
Button Head Socket Bolt
(4pcs)
#95.M5 × 10m/m
Phillips Head Screw (2pcs)
#58. Lubricant (1pc)
#97.M6 (66 × 86)
L Allen Wrench (1pc)
#96. Combination M5 Allen
Wrench & Phillips Head
Screw Driver (1pc)

CUSTOMER SERVICE 1-888-707-1880 Maurice Pincoffs Canada©2012
6
ASSEMBLY INSTRUCTIONS
■STEP 1
Remove all the parts from the carton and lay the main base frame on a flat level surface.
■STEP 2
Slide the right frame base cover (42) on the right upright (4).
Connect the lower computer cable (39) to the computer extension cable (38).
Slide the left frame base cover (43) on the left upright (5).
39
38
42
43
4
5

CUSTOMER SERVICE 1-888-707-1880 Maurice Pincoffs Canada©2012
7
■STEP 3
It will take two people for this step.
Insert the right upright (4) into the Frame Base (2). Secure with two speed nut clips
(132), four 5/16" × 15m/m button head socket bolts (93) and one Ø5/16" × 19 × 1.5T
Curved Washer (94) using the combination M5 allen wrench & phillips head screwdriver
(96) Repeat for the left upright (5).
94
93
93
94
93 93
5
4
96
132
132
132
132
■ STEP 4
Secure the right base cover (42) to the main frame (1) with two 5 × 16m/m Tapping
Screws (88) and one M5 × 10m/m phillips head screw (95) using the combination M5
allen wrench & phillips head screwdriver (96). Repeat for the left base cover (43).
88
95
88
88
88
95
43
42
96

CUSTOMER SERVICE 1-888-707-1880 Maurice Pincoffs Canada©2012
8
■ STEP 5
Connect the Computer Cable (Middle)(38) with the Computer Cable (Upper)(37).
Connect the Speed/Hand Pulse Complex W/Cable (127) with the Speed/Hand Pulse
Complex (53).
Connect the Incline/Hand Pulse Complex W/Cable (128) with the Incline/Hand Pulse
Complex (54).
Connect Connecting Cable (Upper) (152) and Connecting Cable (Lower) (131)
38
37
127
128
54
53
152
131
\
■STEP 6
Use four 5/16" × 3/4" Button Head Socket Bolts (90) and four Ø8 × 1.5T Split Washers
(148) to secure the console assembly.
148
90
148
90
NOTE: Ensure that all bolts are tightened.

CUSTOMER SERVICE 1-888-707-1880 Maurice Pincoffs Canada©2012
9
TREADMILL OPERATION
Your treadmill features a walking belt coated with a lubricant.
IMPORTANT: Never apply silicone spray or other substances to the walking belt or
walking board. Such substances will deteriorate the walking belt and cause excessive
wear.
How to plug in the power cord.
GROUNDING INSTRUCTIONS.
This product must be grounded. No plug adapter
should be used with this product.
▲WARNING: Improper connection of the
equipment grounding conductor can result in a
risk of an electric shock. Check with a qualified
electrician if you are in doubt as to whether the
product is properly grounded. Do not modify
the plug provided with the product, if it will not fit
the outlet; have a proper outlet installed by a
qualified electrician. The use of an extension
cord with this product is not recommended. If an
extension cord is needed, use a short (less than
10 feet) heavy gauge (14 gauge or better)
extension cord with a three prong (grounded)
plug and receptacle. IMPORTANT: If the
power cord is damaged, it must be replaced with
a manufacturer recommended power cord.
1. Plug the indicated end of the power
cord into the socket of the treadmill.
See drawing below.
2. Plug the power cord into an
appropriate outlet that is properly
installed and gounded. See drawing
below. Important: The treadmill is not compatible with GFCI-equipped
outlets.
Note: Your power cord and outlet may appear different

CUSTOMER SERVICE 1-888-707-1880 Maurice Pincoffs Canada©2012
10
Operation of the monitor
GETTING STARTED:
▲CAUTION: Before operating the console, read the following precautions:
•Do not stand on the walking belt when turning on the treadmill
•Always wear the safety key. Pulling the safety key will stop tread-belt movement.
•Adjust the speed in small increments to avoid sudden jumps in speed
•To reduce the possibility of electric shock, keep the console dry. Avoid spilling
liquids on the console and place only sealed water bottles in the water bottle
holders.
•Do not use excessive pressure on console control keys. They are precision set
to function properly with little finger pressure. Pushing harder is not going to
make the unit go faster or slower.
•Understand that changes in speed and incline do not occur immediately. Set your
desired speed on the computer console and release the adjustment key. The
computer will obey the command gradually.
How to use the safety key
1. Place the magnet into position on the round metal portion of the console control
head. Your treadmill will not start and operate without this. Removing the magnet
also secures the treadmill from unauthorized use.
2. Fasten the plastic clip onto your clothing securely to assure good holding power.
Note: The magnet has strong enough power to minimize accidental, unexpected
stopping. The clip should be attached securely to make certain it does not come off.
The treadmill will stop, depending on speed, with a one to two step coast anytime
the magnet is pulled off the console. Use the red Stop / Pause switch in normal
operation.

CUSTOMER SERVICE 1-888-707-1880 Maurice Pincoffs Canada©2012
11
TO OPERATE TREADMILL
▲CAUTION: To avoid injury, hold onto the handrails while mounting and dismounting
the treadmill. Hold onto the handrails and place feet on siderails before starting. Step
onto the walking belt only a slowest speed. Always hold on to a handrail or hand bar
while making control changes (incline, speed, etc.).
Before operating the console make sure that the power cord (34) is properly plugged in
and the on / off button (123) is on. Attach the magnet end of the safety key (33) onto the
monitor and attach the clip end of the safety key (33) to your clothing (ie: waistband). If
you should slip or fall while exercising the safety key will pull out of the console, shutting
off the treadmill.
Getting started:
Power the treadmill on by plugging it into an appropriate wall outlet, then turn on the
power switch located at the front of the treadmill below the motor hood.
QUICK START:
After the treadmill is powered on and the safety key is in place simply press the START
key. The treadmill will start at the minimum speed of 0.5 mph, the time will count up from
zero and all data will begin to accrue. You can adjust the speed manually by pressing the
Fast and Slow buttons and you can adjust the Incline with the Up and Down buttons.
WINDOW DISPLAYS:
After the console powers on the display will show the Time. When you start a program the
display will show Speed. Pressing the Display key next to the display will allow you to
view other data.
PACE: Time required to finish 1 km or 1 mile with current speed.
CALORIES: Total calories consumed during the training.
TIME: Time required for the training.
DISTANCE: Total distance finished during the training.
PULSE: Pulse at the time of training.
INCLINE: Incline level at the time of training.
SPEED: Speed in Km/H or MPH at the time of training.
LUBE: To remind the user to lubricate the deck after 90 hours of use.
KM: The unit of the speed.
MW: Message Window.
Button Functions
SPEED ▲：(1) To increase the speed with increment of 0.1 KMH / MPH.
(2) To adjust the value during program setting.
SPEED ▼：(1) To decrease the speed with 0.1 KMH / MPH less for each press.
(2) To adjust the value during program setting.

CUSTOMER SERVICE 1-888-707-1880 Maurice Pincoffs Canada©2012
12
INCLINE ▲：To increase the incline level with increment of 0.5.
INCLINE ▼：To decrease the incline level with 0.5 less for each press.
QUICK SPEED：To change the speed rapidly. Quick speed buttons are 2, 4, 6, 8 and 10 KMH /
MPH.
QUICK INCLINE：To change the incline rapidly. Quick incline buttons are 2, 4, 6, 8 and 10.
DISPLAY: Switch between speed and incline program patterns and lap.
FAN：Fan switch
STOP：The button to pause or stop the treadmill.
START：The button to start the treadmill.
ENTER：To set the training parameter. The button is used to choose program name, lap, average
speed, average pulse, elevation and program scanning mode selection.
SAFETY KEY：The treadmill can not operate without safety key. In case of emergency, pulling off
the safety key stops the treadmill immediately.
This safety implement is extremely important. Please make sure to wear the safety key.
When it is not in use, keep it in a place without the reach of children.
Program Instructions
MANUAL: Manual mode
Press MANUAL to choose manual mode and press START to begin the workout. All parameters,
TIME,DISTANCE,CILORIES… increase, or press ENTER to enter settings such as age, weight
and workout time. Time counts down. When time resets, the training ends. If time is not preset,
the time counts up and STOP must be pressed to end the training.. The speed and incline may be
adjusted any time in the training. When the training ends, the parameters may be saved for next
use.
Preset Programs:
There are seven preset programs, Adventure, Interval, Glute Blast, Xtreme, Xcountry, Fitness and
Ascent.
A> Choose the program and press the button. You may press START button to directly the
treadmill or press ENTER to set parameters age, weight and time.
B> If program is directly started, then all parameters are preset value. The weight wil affect the
calculation of calorie. The preset time is 30:00. The training ends after counting down to zero.
C> If ENTER is pressed, then age, weight time, max. speed and max incline level will be set in
sequence. Use FAST/SOLW buttons to adjust the value. Press ENTER to set the value and
goes to next parameter setting. If returning to previous parameter is required, press STOP to
set the previous parameter.
D> Press START to begin the workout without setting parameters, the default value will be used.
After start, either the speed or incline can be changed as you wish.
E> There are 3 minutes of warming up after program is started. If warming up is not necessary,
press START to skip warm-up. There are 3 minutes of cooling down. If cooling down is not
necessary, Press STOP to end the training immediately.
F> When the training ends, you can save the parameters for next use.

CUSTOMER SERVICE 1-888-707-1880 Maurice Pincoffs Canada©2012
13
USER1, USER2: User define modes
Press USER to switch the USER1 and USER2.
A>The program may start directly with all preset value parameters. The program pattern may be
stored at the end of the training.
B>You may also press ENTER to set age, weight, time and continue to program 18 segments of
speed by using FAST/SLOW buttons and then 18 segments of incline levels by using
UP/DOWN buttons. ENTER button must be pressed when each setting is finished and to go
on for next setting.
C> Press START button to start the treadmill after finishing setting. The treadmill will run the
training according to the program. It is suggested to program high speed with low incline level
or low speed with high incline level depending on your own physical conditions.
D> There are 3 minutes of warming up after program is started. If warming up is not necessary,
press START to skip warm-up. There are 3 minutes of cooling down. If cooling down is not
necessary, Press STOP to end the training immediately.
E>When program ends, you may save the program or just neglect the current training and save
the original program.
HR control mode:
Press HR button to switch HR1(60%) or HR2(80%) mode. (Must have pulse signal to perform
these modes.)
A>Press HR1 or HR2 to choose HR1(60%) or HR2(80%) mode.
B>Set the user’s age, weight, time and target heart rate value. It must have pulse signal input to
start the program.
C>The target heart rate value is (220–age) ×(60% or 80%). This value is adjustable depending
on the personal physical conditions.
D>The system will detect the pulse during the training and automatically increase or decrease the
incline level according to the detected heart rate value and give advice of increasing or
decreasing the speed to the user.
E> When program ends, you may save the program or just neglect the current training and save
the original program.
Error Messages:
LUBE: After 90 hours of usage, it reminds the user to apply belt lubricant.
Deleting the message: (1) In “Lube Reset” of “Function” under the engineering mode, press
ENTER to delete the message.
(2)Turn on and off to delete this message.
LS：No speed signal is received. Check and make sure the magnet is imbedded in the front
roller and the gap between speed sensor and the roller is within 3mm.
E2: Incline error. Check the cable and connecting terminals are ok then run the calibration
procedure once.

CUSTOMER SERVICE 1-888-707-1880 Maurice Pincoffs Canada©2012
14
FOLDING AND MOVING YOUR TREADMILL
Before folding the treadmill, ensure that the treadmill is at its lowest incline position. Turn the
power switch off, located on the front of the motor cover and unplug the power cord.
CAUTION: You must be able to safely lift 20 kg (45lbs) in order to raise and lower the treadmill.
To decrease the possibility of injury, bend your legs and keep your back straight
while you are raising or lowering your treadmill.
To protect the floor or carpet from damage, place a mat under the treadmill. Keep
the treadmill out of direct sunlight. Do not leave the treadmill in the storage
position in temperatures above 85 degrees Fahrenheit.
Unfolding
Hold the treadmill running deck with left hand. Pull the locking knob with your right hand and
slowly lower the treadmill running deck. The deck will lower unassisted when it reaches about
waist high.
Folding
Lift the treadmill running deck with your left hand and slowly raise the treadmill running deck until
the treadmill is locked by the locking knob.
Moving
Before moving the treadmill, fold the treadmill to the stored position as described above. Hold the
handgrip tubes and carefully move the treadmill to your desired location. To reduce the risk of
injury, use extreme caution while moving the treadmill, do not attempt to move the treadmill over
an uneven surface.

CUSTOMER SERVICE 1-888-707-1880 Maurice Pincoffs Canada©2012
15
PARTS LIST
NO. PART NO DESCRIPTION Q'TY
1 085501 Main Frame 1
2 085502 Frame Base 1
3 085503 Incline Bracket 1
4 085504 Right Upright 1
5 085505 Left Upright 1
6 085506 Console Support 1
9 085509 Outer Slide 1
10 085510 Inner Slide 1
11 085511 Locking Knob 1
12 085512 Top Frame Cover 1
13 085513 Bottom Frame Cover 1
14 085514 Motor Bracket 1
16 085516 Rear Wheel Sleeve 2
17 085517 Belt Guide 2
18 085518 Running Deck 1
19 085520 Running Belt 1
20 085520 Drive Belt 1
21 085521 Front Roller W/Pulley 1
21~2 085521-2 Magnet 2
22 085522 Rear Roller 1
23 085523 Sleeve for Frame Base Front Wheel 2
24 085524 Cylinder 1
25 085525 PVC Handgrip 2
26 085526 Wire Tie Mount 6
27 085527 Motor 1
28 085528 Incline Motor 1
29 085529 Motor Controller 1
30 085530 Folding Assembly Bracket 1
31 085531 1000m/m_Sensor W/Cable 1
32 085532 Power Socket 1
33 085533 800m/m_Square Safety Key 1
34 085534 Power Cord 1
35 085535 300m/m_Connecting Wire (White) 1
36 085536 300m/m_Connecting Wire (Black) 1
37 085537 1200m/m_Computer Cable (Upper) 1
38 085538 1150m/m_Computer Cable (Middle) 1
39 085539 1200m/m_Computer Cable (Lower) 1
40 085540 Console Assembly 1
40~1 085540-1 Console Inner Cover 1
40~2 085540-2 Console Outer Cover 1
40~6 085540-6 Drink Bottle Holder 2
40~7 085540-7 Speaker Cover (L) 1
40~8 085540-8 Speaker Cover (R) 1

CUSTOMER SERVICE 1-888-707-1880 Maurice Pincoffs Canada©2012
16
NO. PART NO DESCRIPTION Q'TY
40~9 085540-09 Top Fan Cover 1
40~10 085540-10 Bottom Fan Cover 1
40~11 085540-11 Fan Assembly 1
40~12 085540-12 500m/m_Safety Key 1
40~15 085540-15 Speaker Grill Anchor 6
40~16 085540-16 600m/m_Speaker W/Cable 2
40~17 085540-17 Amplifier Controller 1
40~18 085540-18 300m/m_Amplifier Cable 1
40~22 085540-22 300m/m_Earphone socket with cable 1
40~24 085540-24 3.0 × 8m/m_Sheet Metal Screw 6
40~25 085540-25 3.5 × 12m/m_Sheet Metal Screw 30
40~26 085540-26 FAN Key 1
40~27 085540-27 STOP Key 1
40~28 085540-28 START Key 1
40~29 085540-29 ENTER Key 1
40~30 085540-30 Ø22.2_Console Mounting Plate 4
40~31 085540-31 Ø32_Console Mounting Plate 2
41 085541 Handgrip End Cap 2
42 085542 Frame Base Cover (R) 1
43 085543 Frame Base Cover (L) 1
44 085544 Frame Base Front Wheel 2
45 085545 Frame Base Rear Wheel 2
46 085546 □30 × 60m/m_Square End Cap 2
47 085547 Motor Cover Anchor 5
48 085548 Motor Top Cover 1
49 085549 1420m/m_Foot Rail 2
50 085550 Cushion 6
51 085551 Rear Adjustment Base (L ) 1
52 085552 Rear Adjustment Base (R ) 1
53 085553 Speed/Hand Pulse Complex 1
54 085554 Incline/Hand Pulse Complex 1
56 085556 Rear Up/Down Adjustable Foot 2
57 085557 Sensor Rack 1
58 085558 Lubricant 1
59 085559 Ø10 × Ø24 × 3T_Nylon Washer 5
60 085560 Ø50 × Ø13 × 3T_Nylon Washer 2
61 085561 1/2" × 23m/m_Carriage Bolt 2
62 085562 1/2" × 60m/m_Hex Head Bolt 2
63 085563 3/8" × 1-1/2"_Hex Head Bolt 1
64 085564 M10 × 63m/m_Hex Head Bolt 1
65 085565 3/8" × 3/4"_Hex Head Bolt 4
66 085566 5/16" × 1"_Button Head Socket Bolt 2
67 085567 Frame Base End Cap 2
68 085568 3 × 10m/m_Sheet Metal Screw 2
69 085569 3/8" × 2"_Flat Head Socket Bolt 2
71 085571 M8 × 60m/m_Hex Head Bolt 1

CUSTOMER SERVICE 1-888-707-1880 Maurice Pincoffs Canada©2012
17
NO. PART NO DESCRIPTION Q'TY
72 085572 M8 × 80m/m_Socket Head Cap Bolt 2
73 085573 M8 × 30m/m_Flat Head Countersink Bolt 8
74 085574 1/2" × 8T_Nyloc Nut 4
75 085575 3/8" × 7T_Nyloc Nut 7
76 085576 5/16" × 6T_Nyloc Nut 4
77 085577 M8 × 8T_Nyloc Nut 1
78 085578 3/8" × 7T_Nut 3
79 085579 3 × 75m/m_Sheet Metal Screw 2
80 085580 Ø25 × Ø10 × 2.0T_Flat Washer 4
81 085581 Ø19 × Ø 10 × 1.5T_Flat Washer 8
82 085582 3/8" × 2T_Split Washer 4
83 085583 Ø6.5 × 25 × 1T_Concave Washer 8
84 085584 M5_Split Washer 3
85 085585 4 × 12m/m_Sheet Metal Screw 12
86 085586 5 × 16m/m_Tapping Screw 31
88 085588 5 × 16m/m_Tapping Screw 13
90 085590 5/16" × 3/4"_Button Head Socket Bolt 4
91 085591 3.5 × 16m/m_Tapping Screw 6
92 085592 M5_Split Washer 4
93 085593 5/16" × 15m/m_Button Head Socket Bolt 8
94 085594 Ø5/16" × 19 × 1.5T_Curved Washer 2
95 085595 M5 × 10m/m_Phillips Head Screw 6
96 085596 Combination M5 Allen Wrench & Phillips Head Screw Driver 1
97 085597 M6 ( 66 × 86 )_L Allen Wrench 1
98 085598 3/8" × 1-1/2"_Hex Head Bolt 1
99 085599 3/8" × 1-1/2"_Hex Head Bolt 1
100 0855100 3/8" × 1-3/4"_Hex Head Bolt 1
104 0855104 □21.4 × 21.4m/m_Square End Cap 1
105 0855105 □25.4 × 25.4m/m_Square End Cap 1
123 0855123 On/Off Switch 1
124 0855124 100m/m × 764 × 764_Connecting Wire 1
125 0855125 Breaker 1
127 0855127 1000m/m_Speed/Hand Pulse Complex W/Cable 1
128 0855128 1000m/m_Incline/Hand Pulse Complex W/Cable 1
129 0855129 Receiver, HR Assembly 1
130 0855130 1820m/m_Audio Cable 1
131 0855131 500m/m_Connecting Cable (Lower) 1
132 0855132 M5_Speed Nut Clip 4
133 0855133 Drink Bottle 1
134 0855134 M10 × 8.0T_Nyloc Nut 1
135 0855135 Wire Clamp 1
136 0855136 1000m/m_Ground Wire 1
137 0855137 400m/m_Ground Wire 1
138 0855138 □30 × 30m/m_Square End Cap 2
139 0855139 Slide Wheel , Urethane 2
140 0855140 Ø6.5 × Ø25 × 10L_Rubber Foot Pad 3

CUSTOMER SERVICE 1-888-707-1880 Maurice Pincoffs Canada©2012
18
NO. PART NO DESCRIPTION Q'TY
141 0855141 Ø4.5 × Ø25 × 15L_Rubber Foot Pad 2
142 0855142 Incline Motor Cover 1
144 0855144 3/8" × 2-1/4"_Flat Head Socket Bolt 2
145 0855145 Foot Rail Back Plate 2
146 0855146 4 × 19m/m_Sheet Metal Screw 2
147 0855147 4 × 6m/m_Phillips Head Trilobular Screw 2
148 0855148 Ø8 × 1.5T_Split Washer 4
149 0855149 5 × 19m/m_Tapping Screw 5
150 0855150 3 × 8m/m_Sheet Metal Screw 2
151 0855151 Controller Back Plate 1
152 0855152 1000m/m_Connecting Cable (Upper) 1
157 0855157 M8 × 12m/m_Hex Head Bolt 2
158 0855158 M8_Split Washer 2

CUSTOMER SERVICE 1-888-707-1880 Maurice Pincoffs Canada©2012
19
PARTS DIAGRAM
