Xterra TRX3500 User manual

TRX3500 Treadmill
OWNER’S MANUAL
PLEASE CAREFULLY READ THIS ENTIRE MANUAL BEFORE OPERATING YOUR NEW TREADMILL
FITNESS

Table Of Contents
1
2
3
5
9
17
21
ATTENTION
THIS TREADMILL IS INTENDED FOR RESIDENTIAL USE ONLY AND IS
WARRANTED FOR THIS APPLICATION. ANY OTHER APPLICATION VOIDS
THIS WARRANTY IN ITS ENTIRETY.
Product Registration
Important Safety Instructions
Important Electrical Instructions
TRX3500 Assembly Instructions
Operation of Your Console
General Maintenance
Manufacturer’s Limited Warranty

TRX3500 Treadmill
1
Record Your Serial Number
Please record the Serial Number of this tness product
in the space provided below.
Serial Number
Register Your Purchase
The self-addressed product registration card must be completed in full and returned to
XTERRA Fitness. You can also go to www.xterratness.com/warrantyreg.html
to register online.
Thank you for your purchase of this quality Treadmill from XTERRA Fitness. Your new
Treadmill has been manufactured by one of the leading tness manufacturers in the world.
XTERRA Fitness will do all we can to make your ownership experience as pleasant as
possible for many years to come. If you have questions, or if parts are missing or damaged,
or you require customer service, call [phone]. Please have your model number and
serial number handy when you call.
Please take a moment to record where you purchased your machine, as well as the date of
purchase for future reference. We appreciate your condence in XTERRA Fitness and we
will always remember that you are the reason that we are in business. Please complete and
mail your registration card today and enjoy your new Treadmill.
Yours in Health,
XTERRA Fitness
Congratulations On Your New Treadmill and Welcome to the XTERRA Fitness Family!
Product Registration
TRX3500_20170712
FITNESS
Purchase Location
Purchase Date

2
TRX3500 Treadmill
• To disconnect, turn all controls to the off position, then remove the plug from the outlet.
• Do not operate equipment on deeply padded, plush or shag carpet. Damage to both carpet and
equipment may result. You can purchase a oor mat directly from www.xterratness.com.
• Before beginning this or any exercise program, consult a physician. This is especially important for
persons over the age of 35 or persons with pre-existing health conditions.
• Keep hands away from all moving parts.
• The pulse sensors are not medical devices. Various factors, including the user’s movement, may affect the
accuracy of heart rate readings. The pulse sensors are intended only as exercise aids in determining heart
rate trends in general.
• Do not attempt to use your equipment for any purpose other than for the purpose it is intended.
• Wear proper shoes. High heels, dress shoes, sandals or bare feet are not suitable for use on your
equipment. Quality athletic shoes are recommended to avoid leg fatigue.
• User Weight Limit: 300 lbs.
Important Safety Instructions
When using an electrical appliance, basic precautions should always be followed, including the following:
Read all instructions before using this appliance.
DANGER - To reduce the risk of electric shock:
Always unplug this appliance from the electrical outlet immediately after using and before cleaning.
WARNING - To reduce the risk of burns, re electric shock, or injury to persons:
1. An appliance should never be left unattended when plugged in. Unplug from outlet when not in use, and
before putting on or taking off parts.
2. Do not operate under blanket or pillow. Excessive heating can occur and cause re, electric shock, or injury
to persons.
3. Close supervision is necessary when this appliance is used by, on, or near children, invalids, or disabled
persons.
4. Use this appliance only for its intended use as described in this manual. Do not use attachments not
recommended by the manufacturer.
5. Never operate this appliance if it has a damaged cord or plug, if it is not working properly, if it has been
dropped or damaged, or dropped into water. Return the appliance to a service center for examination and
repair.
6. Do not carry this appliance by supply cord or use cord as a handle.
7. Keep the cord away from heated surfaces.
8. Never operate the appliance with the air openings blocked. Keep the air openings free of lint, hair, and the
like.
9. Never drop or insert any object into any opening.
10. Do not use outdoors.
11. Do not operate where aerosol (spray) products are being use or where oxygen is being administered.
12. Connect this appliance to a properly grounded outlet only. See Grounding Instructions.
13. The appliance is intended for household use.
SAVE THESE INSTRUCTIONS - THINK SAFETY!
SAVE THESE INSTRUCTIONS - THINK SAFETY!
Fitness Equipment Safety Instructions
Failure to follow all guidelines may compromise the effectiveness of the exercise experience, expose
yourself (and possibly others) to injury, and reduce the longevity of the equipment.

TRX3500 Treadmill
3
WARNING!
NEVER use a ground fault circuit interrupt (GFCI) wall outlet with this treadmill. As with any appliance
with a large motor, the GFCI will trip often. Route the power cord away from any moving part of the
treadmill including the elevation mechanism and transport wheels.
NEVER remove any cover without rst disconnecting AC power. If voltage varies by ten percent (10%)
or more, the performance of your treadmill may be affected. Such conditions are not covered under your
warranty. If you suspect the voltage is low, contact your local power company or a licensed electrician
for proper testing.
NEVER expose this treadmill to rain or moisture. This product is NOT designed for use outdoors, near a
pool or spa, or in any other high humidity environment. The operating temperature specication is 40 to
120 degrees Fahrenheit, and humidity is 95% non-condensing (no water drops forming on surfaces).
Circuit Breakers: Some circuit breakers used in homes are not rated for high inrush currents that can
occur when a treadmill is rst turned on or even during use. If your treadmill is tripping the house circuit
breaker (even though it is the proper current rating) but the circuit breaker on the treadmill itself does
not trip, you will need to replace the home breaker with a high inrush type. This is not a warranty defect.
This is a condition we as a manufacture have no ability to control. This part is available through most
electrical supply stores. Examples: Grainger part # 1D237, or available online at www.squared.com part
#QO120HM.
This product must be grounded. If the treadmill should malfunction or breakdown, grounding pro-
vides a path of least resistance for electric current, reducing the risk of electric shock. This product is
equipped with a cord having an equipment-grounding plug. The plug must be plugged into an appropri-
ate outlet that is properly installed and grounded in accordance with all local codes and ordinances.
DANGER - Improper connection of the equipment-grounding conductor can result in a risk of electric
shock. Check with a qualied electrician or serviceman if you are in doubt as to whether the product
is properly grounded. Do not modify the plug provided with the product if it will not t the outlet; have a
proper outlet installed by a qualied electrician.
This product is for use on a nominal 110-volt circuit, and has a grounding plug that looks like the plug
illustrated below. A temporary adapter that looks like the adapter illustrated below may be used to con-
nect this plug to a 2-pole receptacle as shown below if a properly grounded outlet is not available. The
temporary adapter should be used only until a properly grounded outlet, (shown below) can be installed
by a qualied electrician. The green colored rigid ear-lug, or the like, extending from the adapter, must
be connected to a permanent ground such as a properly grounded outlet box cover. Whenever the
adapter is used, it must be held in place by a metal screw.
Grounding Instructions

4
TRX3500 Treadmill
A safety tether cord is provided with this unit. It is a simple magnetic design that should be used
at all times. It is for your safety should you fall or move too far back on the tread-belt. Pulling this
safety tether cord will stop tread-belt movement. To Use:
1. Place the magnet into position on the round metal portion of the console control head. Your
treadmill will not start and operate without this. Removing the magnet also secures the treadmill
from unauthorized use.
2. Fasten the plastic clip onto your clothing securely to assure good holding power. Note: The
magnet has strong enough power to minimize accidental, unexpected stopping. The clip should
be attached securely to make certain it does not come off. Be familiar with its function and
limitations. The treadmill will stop, depending on speed, with a one to two step coast anytime
the magnet is pulled off the console. Use the Stop / Pause switch in normal operation.
NEVER operate this treadmill without reading and completely understanding the results of any
operational change you request from the computer.
Understand that changes in speed and incline do not occur immediately. Set your desired work
level on the computer console and release the adjustment key. The computer will obey the
command gradually.
NEVER use your treadmill during an electrical storm. Surges may occur in your household power
supply that could damage treadmill components. Unplug the treadmill during an
electrical storm as a precaution.
Use caution while participating in other activities while walking on your treadmill; such as watching
television, reading, etc. These distractions may cause you to lose balance which may result in
serious injury.
Do not use excessive pressure on console control keys. They are precision set to function properly
with little nger pressure.
SAVE THESE INSTRUCTIONS - THINK SAFETY!
SAFETY TETHER CORD
Failure to follow all guidelines may compromise the effectiveness of the exercise experience, expose
yourself (and possibly others) to injury, and reduce the longevity of the equipment.
Please read before unpacking your folding treadmill. Serious injury could occur if this folding treadmill
is not unpacked properly.
There is a Velcro strap installed around the treadmill base that prevents the treadmill from unfolding
accidentally during shipping. If this strap is not removed properly the treadmill could spring open unex-
pectedly and cause injury if someone is standing near the treadmill when the strap is removed.
To ensure your personal safety during removal of the shipping strap please make sure the treadmill
is positioned at on the ground, in the orientation it would be in if you were using the treadmill. Do not
turn the treadmill up on its side while removing the shipping strap. This could cause the treadmill’s
folding mechanism to spring open. If the end of the Velcro strap (that you need to grab to remove it)
happens to be under the treadmill deck, reach under the deck to grab it, but do not tilt the treadmill up
to gain access to the strap end.
Pre-Assembly

TRX3500 Treadmill
5
TRX3500 Assembly Pack Checklist
Cut the banding straps with a short box cutter (razor knife); separate the carton from the one under-
neath it by prying up on the staples (if applicable). Pull the carton over the treadmill parts and locate
the hardware pack. The hardware pack is separated into ve sections; one section containing tools
and four sections labeled steps 1-4 which contain the hardware needed for assembly of each step.
The assembly steps below are numbered one through four and correspond to the hardware in the
numbered sections of the hardware pack. Remove only the hardware for the step you are currently
assembling to avoid confusion and mix ups.
Pull the carton over the treadmill parts and lay it on a level surface.
ASSEMBLY PACK CHECKLIST
# 102.Combination M5 Allen Wrench &
Phillips Head Screw Driver (1pc)
# 103.M6_
L Allen Wrench (1pc)
#99. 5/16" × 1/2"_
Hex Head Bolt (8pcs)
# 90.13L_Wrench (1pc)
# 80. Ø8 × 1.5T_
Split Washer (4pcs)
#100.Ø5/16" × Ø18 × 1.5T_
Flat Washer (8pcs)
#125.5/16" × 3/4"_
BoltHex Head Bolt (8pcs)

6
TRX3500 Treadmill
TRX3500 Assembly Instructions
Remove Deck From Box
Left and Right Uprights
1
2
1. Take Treadmill deck out of the carton and place it on level
and clean ground.
1. You may need assistance holding the Uprights for this step.
2. Connect the Computer Cable (Middle) (54) to the Computer Cable (Lower) (55) then insert
Right and Left Uprights (4) and (5) into the Frame Base (2) and use the 13mm Wrench (90) to
tighten 8 Hex Head Bolts (99) and 8 Flat Washers (100). Be careful not to pinch the Computer
Cables as this may cause damage to them.
#90. 13mm Wrench
#99. 5/16”x1/2” Hex Head
Bolts (8pcs)
#100. Ø 5/16” × Ø 18 ×
1.5T Flat Washers (8pcs)
Hardware Step 2

TRX3500 Treadmill
7
1. Connect the Computer Cable (Middle) (54) and Computer Cable (Upper) (53).
2. Connect the Speed Adjustment Switch W/Cable (Upper) (114) and Speed/Hand Pulse
Complex (28).
3. Connect the Incline Adjustment Switch W/Cable (Upper) (115) and Incline/Hand Pulse
Complex (29).
4. Be careful not to pinch cables, as it may cause damage to them.
5. Insert the Console (21) onto the right and left Uprights (4) and (5) and secure with 4
Button Head Socket Bolts (125) with 4 Split Washers (80) by using Combination M5 Allen
Wrench & Phillips Head Screw Driver (102).
TRX3500 Assembly Instructions
Console Attachment
3#102. Combination M5
Allen Wrench & Phillips
Head Screw Driver
#125. 5/16” × 3/4” Button
Head Socket Bolts (4pcs)
#80. Ø 8 × 1.5T Split
Washers (4pcs)
Hardware Step 3

8
TRX3500 Treadmill
4
Crossbar Installation
1. Install Handrail Support (9) between left and right Uprights (5) and (4) and use
Combination M5 Allen Wrench & Phillips Head Screw Driver (102) to tighten 4 Button
Head Socket Bolts (125).
NOTE: Make sure to tighten all screws after all components have been assembled.
#102. Combination M5
Allen Wrench & Phillips
Head Screw Driver
#125. 5/16” × 3/4”
Button Head Socket
Bolts (4pcs)
Hardware Step 4
Folding Instructions
1. Pull Release Pin to lower deck from folded position until it locks.
2. Pull Release Pin and raise deck into locking position to fold.

TRX3500 Treadmill
9
Operation of Your Console
TRX3500 Console
Power Up
Power the treadmill on by plugging it into an appropriate wall outlet, then turn on the power
switch located at the front of the treadmill below the motor hood. Ensure that the Safety Key
is installed, as the treadmill will not power on without it.
When the power is turned on a message will scroll across the dot matrix showing the current
software version. Then the Time and Distance windows will display Odometer readings for a
short time. The Time window will show how many hours the treadmill has been in use and the
Distance window will show how many miles (or Kilometers if the treadmill is set to metric
readings) the treadmill has gone. The treadmill will then enter idle mode, which is the starting
point for operation.

10
TRX3500 Treadmill
Quick Start Operation
Pause / Stop / Reset
Incline Features
Dot Matrix Center Display
1/4 Mile Track
Functions
1. Attach the Safety Key to enable the display (if not already on).
2. Press the Start/Stop key to begin belt movement. Adjust to the desired speed using the
speed ▲ and ▼ keys (console or handgrip). You may also use the Quick Speed Keys 1 -
10 to adjust the speed.
3. To adjust deck incline, press the ▲/▼ incline key (console or handgip) to the desired
incline level. You may also press the Quick Incline Keys 0 - 12 to adjust.
4. To stop the treadmill, press Start/Stop Key or pull out the Safety Key, though we
encourage you to use the Start/Stop Key.
1. When the treadmill is running, the pause feature may be utilized by pressing the Start/
Stop key once. This will slowly decelerate the tread-belt to a stop. The incline will go to
zero percent. The Time, Distance and Calorie readings will also stop.
2. To resume your workout, press the Start/Stop key. The speed and incline will return to
their previous settings.
3. If the ENTER key is pressed while paused, the console will reset and return to the idle
mode (start up) screen.
1. Incline may be adjusted anytime after the belt begins to move.
2. Press and hold the adjust Incline ▲/▼ keys on the left side (console or handgrip) to
achieve your desired incline. You may also choose a more rapid increase / decrease by
selecting a Quick Incline Key 0 - 12 on left hand side of console (incline).
3. The display will indicate incline position as adjustments are made.
Eighteen rows of dots (8 high) indicate each segment of a workout. The dots are only to show
an approximate level(speed/incline) of effort. They do not necessarily indicate a specic value
- only an approximate percent to compare levels of intensity. In operation the Speed /Incline
dot matrix window will build a prole “picture” as values are changed during a workout.
You may change the Dot Matrix prole view that you desire by pressing the PROGRAM
button. Pressing the PROGRAM button switches among the incline, speed and 1/4-mile track
images.
The 1/4-mile track will be displayed around the dot matrix window. Pressing PROGRAM
button switches to 1/4-mile track in mile. The ashing dot indicates your progress. Once the
1/4-mile is complete this feature will begin again.

TRX3500 Treadmill
11
To Turn Treadmill Off
Manual Program
Pulse Grip Feature
Calorie Display
Program Operation
1. Remove Safety Key.
2. Turn of the main switch on the front of the treadmill, below the motor cover.
Note: Do not leave in Safety Key in treadmill when not in use. Always turn off machine.
1. Select Manual Program via the Program key then press Enter. The display will prompt
you through the programming or you can just press Start to begin the program with default
values.
2. The Message window will now be blinking an Age value. Adjust the age and press Enter.
3. The Message window will now be displaying a Weight value. Entering the correct body
weight will affect the calorie count. Use Speed ▲ / ▼ keys to adjust then press Enter.
A note about the Calorie display: No exercise machine can give you an exact calorie
count because there are too many factors which determine exact calorie burn for a
particular person. Even if someone is the exact same body weight, age and height, their
calorie burn may be very different than yours. The Calorie display is to be used as a
reference only to monitor improvement from workout to workout.
4. If Enter was pressed, the Message window will display with the default Time value of 30
minutes. You may use any of the Speed ▲ / ▼ keys to adjust the time. After adjusting, or
to accept the default value, press Enter. (Note: You may press Start at any time during the
programming to start the program.).
5. Press Start to begin your workout.
The Pulse (Heart Rate) readout will display your current heart rate in beats per minute during
the workout. You must use both stainless steel sensors on the handlebar to display your
pulse. Pulse value displays anytime the upper display is receiving a pulse signal.
Displays the cumulative calories burned at any given time during your workout.
Note: This is only a rough guide used for comparison of different exercise sessions,
which cannot be used for medical purposes.

12
TRX3500 Treadmill
Built-in Programs
User Programs
HRC (Heart Rate Control)
1. Use the program keys to select the desired program, and then press the Enter key. The
display will prompt you through the programming or you can just press Start to begin the
program with default values.
2. The Calorie window will now be blinking an Age value. Adjust the age and press Enter.
3. The Message window will now be displaying a Weight value. Entering the correct body
weight will affect the calorie count. Use Speed ▲ / ▼keys to adjust then press Enter.
4. If Enter was pressed, the Message window will display with the default Time value of 30
minutes. You may use any of the Speed ▲ / ▼ keys to adjust the time. After adjusting, or
to accept the default value, press Enter. (Note: You may press Start at any time during
the programming to start the program.).
5. The Message window will show the maximum speed, you can use any speed plus or
minus keys to adjust. Adjust or accept the default value, and then press ENTER.
6. The Message window will show the maximum value of the lift, you can use any raise and
minus keys to adjust. Adjust or accept the default value, and then press ENTER
7. Press Start to begin your workout.
1. Select User 1 or User 2 via the Program key then press Enter. Note that the dot matrix
display portion will have a single row of dots at the bottom (Unless there is a previously
stored program).
2. The Message window will now be blinking an age value. Adjust the age and press Enter.
3. The Message window will now be blinking a body weight value. Enter your body weight
and press Enter.
4. The Message window will now be blinking an time value. Adjust the Time and press Enter.
5. The rst column (segment) will now be blinking. Use speed ▲ / ▼ to adjust then press
Enter. The second column will now be blinking. Repeat the above process until all
segments have been programmed. Then press ENTER to conrm and enter incline
programming. Repeat the above process to program all segments for incline.
6. Press the START button to begin the workout and also save the programmed speed and
incline values.
1. Select HRC via the Program key then press Enter.
2. The console displays ”Adjust age, Age> 35”. Press ENTER after age has been adjusted.
3. The console displays ”Adjust weight. Weight> 150”. Press ENTER after weight has been
adjusted.
4. The console displays ”Adjust time. Time> 30:00”. Press ENTER after time has been
adjusted.
5. The console displays “Adjust target heart rate”. The console will console will calculate
target heart rate according to the formula (220-age) x 0.6. If the user changes the target
heart rate percentage, new target heart rate percentage will be displayed. When target
heart rate is adjusted, press Enter.

TRX3500 Treadmill
13
Preset Program Displays
6. If the user presses START without wearing HR stripe, MC will display “This program must
wear HR strap”.
7. If the user presses START and the heart rate signal is detected, the manual control
begins.
8. Use the existing heart rate control software, except use the Incline adjustments only.
When the software would normally adjust the Speed setting, do not change the speed
but instead display in the message window what the user should set the speed to. For
example, if the software would make a speed change to 2.3 MPH then just show in the
MW: “SET SPEED TO 2.3 MPH.
P1 P9
P3 P11
P5 P13
P7 P15
P2 P10
P4 P12
P6 P14
P8 P16
Speed Speed
Speed Speed
Speed Speed
Speed Speed
Speed Speed
Speed Speed
Speed Speed
Speed Speed
Incline Incline
Incline Incline
Incline Incline
Incline Incline
Incline Incline
Incline Incline
Incline Incline
Incline Incline

14
TRX3500 Treadmill
P17 P25
P28
P19 P27
P30
P21
P23
P18 P26
P29
P20
P22
P24
Speed Speed
Speed
Speed Speed
Speed
Speed
Speed
Speed Speed
Speed
Speed
Speed
Speed
Incline Incline
Incline
Incline Incline
Incline
Incline
Incline
Incline Incline
Incline
Incline
Incline
Incline

TRX3500 Treadmill
15
The old motto, “no pain, no gain”, is a myth that has been overpowered by the benets of
exercising comfortably. A great deal of this success has been promoted by the use of heart rate
monitors. With the proper use of a heart rate monitor, many people nd that their usual choice of
exercise intensity was either too high or too low and exercise is much more enjoyable by
maintaining their heart rate in the desired benet range.
To determine the benet range in which you wish to train, you must rst determine your predicted
Maximum Heart Rate. This can be accomplished by using the following formula: 220 minus your
age. This will give you the predicted Maximum Heart Rate (MHR) for someone of your age. To de-
termine the effective heart rate range for specic goals you simply calculate a percentage of your
MHR. Your heart rate training zone is 50% to 90% of your maximum heart rate. 60% of your MHR
is the zone that burns fat, while 80% is for strengthening the cardio vascular system. This 60% to
80% is the zone to stay in for maximum benet.
For someone who is 40 years old their
predicted target heart rate zone is calculated:
220 – 40 = 180 (maximum heart rate)
180 x .6 = 108 beats per minute
(60% of maximum)
180 X .8 = 144 beats per minute
(80% of maximum)
So for a 40 year old the training zone would be
108 to 144 beats per minute.
The two most popular reasons for, or goals, of ex-
ercise are cardiovascular tness (training for the
heart and lungs) and weight control. The black
columns on the chart above represent the MHR
for a person whose age is listed at the bottom of each column. The training heart rate, for either
cardiovascular tness or weight loss, is represented by two different lines that cut diagonally
through the chart. A denition of the lines’ goal is in the bottom left-hand corner of the chart. If your
goal is cardiovascular tness or if it is weight loss, it can be achieved by training at 80% or 60%,
respectively, of your MHR on a schedule approved by your physician. Consult your physician
before participating in any exercise program.
Heart Rate

16
TRX3500 Treadmill
Heart rate is important but listening to your body also has a lot of advantages. There are
more variables involved in how hard you should workout than just heart rate. Your stress
level, physical health, emotional health, temperature, humidity, the time of day, the last
time you ate and what you ate all contribute to the intensity at which you should
workout. If you listen to your body it will tell you all of these things.
The rate of perceived exertion (RPE), also known as the Borg scale, was developed by
Swedish physiologist G.A.V. Borg. This scale rates exercise intensity from 6 to 20
depending upon how you feel or the perception of your effort.
The scale is as follows:
Rating Perception of Effort
6 Minimal
7 Very,very light
8 Very,very light +
9 Very light
10 Very light +
11 Fairly light
12 Comfortable
13 Somewhat hard
14 Somewhat hard +
15 Hard
16 Hard +
17 Very hard
18 Very hard +
19 Very,very hard
20 Maximal
You can get an approximate heart rate level for each rating by simply adding a zero to
each rating. For example a rating of 12 will result in an approximate heart rate of 120
beats per minute. Your RPE will vary depending on the factors discussed earlier. If your
body is strong and rested, you will feel strong and your pace will feel comfortable. When
your body is in this condition, you are able to train harder and the RPE will support this. If
you are feeling tired and sluggish, it is because your body needs a break. In this
condition, your pace will feel difcult. Again, this will show up in your RPE and you
will train at the proper level for that day.
Rate of Perceived Exertion

TRX3500 Treadmill
17
The treadmill is designed so that the tread-belt
remains reasonably centered while in use. It is normal
for some belts to drift near one side while in use,
depending on a user’s gait and if they favor one leg.
But if during use the belt continues to move toward
one side, adjustments are necessary.
SETTING TREAD-BELT TRACKING
An 6mm Allen wrench is provided for this adjustment.
Make tracking adjustments on the left side bolt. Set belt speed at 3 mph. Be aware that a
small adjustment can make a dramatic difference which may not be apparent right away. If
the belt is too close to the left side, then turn the bolt only a 1/4 turn to the right (clockwise)
and wait a few minutes for the belt to adjust itself. Continue to make 1/4 turns until the belt
stabilizes in the center of the running deck.
If the belt is too close to the right side, turn the bolt counter-clockwise. The belt may require
periodic tracking adjustment depending on use and walking/running characteristics. Some
users may affect tracking differently. Expect to make adjustments as required to center the
tread-belt. Adjustments will become less of a maintenance concern as the belt is used. Proper
belt tracking is an owner responsibility common with all treadmills.
ATTENTION
Damage to the running belt resulting from improper tracking / tension adjustments is not
covered under the XTERRA Fitness warranty.
Treadbelt Tracking Adjustment
General Cleaning
Belt Adjustments
Tread-belt Tension Adjustment - Belt tension is not critical
for most users. It is very important though for joggers and
runners in order to provide a smooth, steady running surface.
Adjustment must be made from the rear roller with the 6mm Allen wrench provided in the parts
package. The adjustment bolts are located at the end of the step rails as shown in the diagram below.
Tighten the rear roller only enough to prevent slippage at the front roller. Turn the tread-belt tension
adjusting bolts 1/4 turn each and inspect for proper tension by walking on the belt and making sure it
is not slipping or hesitating with each step. When an adjustment is made to the belt tension, you must
be sure to turn the bolts on both sides evenly or the belt could start tracking to one side instead of
running in the middle of the deck.
Dirt, dust, and hair can block air inlets and accumulate on the running belt. Please vacuum
underneath your treadmill on a monthly basis to prevent excess build-up of dirt that can get sucked
up and get into the inner workings under the motor cover. Every other month, you should remove the
motor cover and carefully vacuum out dirt and hair that may accumulate.
UNPLUG THE POWER CORD BEFORE THIS TASK.

18
TRX3500 Treadmill
First, you want to clean between the belt and deck to remove any debris that may be trapped. Use a
clean, non-fraying rag, t-shirt, or light towel. Halfway between the end of the treadmill and motor cover,
shove the garment under the belt until you can grasp it on both sides of the belt. Drag the garment the
length of the entire belt 1-2 times. Remove the garment.
Do not lubricate with anything other than XTERRA Fitness approved lubricant. Your treadmill comes
with one tube of “Lube” and extra tubes can be ordered directly from:
www.xterratness.com.
Keeping the deck lubricated at the recommended intervals ensures the longest life possible for
your treadmill. If the lubricant dries out, the friction between the belt and deck rises and places
undue stress on the drive motor, drive belt and electronic motor control board, which could result in
catastrophic failure of these expensive components. Failure to lubricate the deck at
regular intervals may void the warranty.
The belt & deck come pre-lubricated and subsequent lubrication should be performed every 180
hours of use or if you notice that the deck is dry. It is recommended that you reach between the
belt and deck to verify there is lubrication present, every other month. If you check and there isn’t
any lubrication present, follow the procedure below even though the “Lube” indicator isn’t lit on the
console. Otherwise, lubricate when the console’s lubrication reminder lights after 180 hours of use.
Use the following procedure to apply the silicone lubricant:
1. Turn the power switch off and unplug the power cord from the wall outlet
2. Measure 18” from the edge of the motor cover; kneel down and reach under the belt approxi-
mately 4- 6” from one edge. Squirt a line of lubricant about 1/8” wide x 15” long in an “S” pattern
perpendicular to the motor cover.
3. Repeat the process on the opposite side.
4. Plug the electrical cord back into the outlet and turn the power switch on.
5. Walk on the belt at a moderate speed for ve minutes to evenly distribute the silicone lube.
Note: If the “Lube” message appears on the console, perform the following procedure to
reset the message:
1. In standby mode, hold the ENTER key for 3 seconds to reset the message.
Belt/Deck Lubrication Procedure
DO NOT OVERTIGHTEN – Over tightening will cause belt damage and premature bearing failure. If
you tighten the belt a lot and it still slips, the problem could actually be the drive belt - located under
the motor cover - that connects the motor to the front roller. If that belt is loose it feels similar to the
walking belt being loose. Tightening the motor belt should be done by a trained service person.
