Xylem e-MP User manual

Instruction manual
P7000005_1.0
e-MP
Multistage Pump

Table of Contents
1 Introduction and Safety........................................................................................................ 5
1.1 Introduction....................................................................................................................5
1.1.1 Target group........................................................................................................... 5
1.1.2 General information................................................................................................ 5
1.1.3 Warranty................................................................................................................. 6
1.2 Safety............................................................................................................................ 6
1.2.1 Common safety notes.............................................................................................6
1.2.2 Key to safety symbols/markings............................................................................. 6
1.2.3 Dangers of non-observance of safety instructions..................................................7
1.2.4 Personal qualification..............................................................................................8
1.2.5 Intended use........................................................................................................... 8
1.2.6 Safety awareness................................................................................................... 8
1.2.7 Safety information for the operator/user................................................................. 9
1.2.8 Safety information for maintenance, inspection, and installation............................9
1.2.9 Decals.....................................................................................................................9
1.2.10 Unauthorized modification and spare parts production.........................................9
1.2.11 Unauthorized modes of operation.......................................................................10
1.2.12 Explosion protection............................................................................................10
2 Transportation and Storage............................................................................................... 13
2.1 Inspect the delivery......................................................................................................13
2.1.1 Examine the unit................................................................................................... 13
2.2 Transportation guidelines............................................................................................ 13
2.3 Storage guidelines.......................................................................................................14
2.3.1 Long-term storage.................................................................................................15
2.3.2 Return to supplier..................................................................................................15
2.3.3 Disposal................................................................................................................ 15
3 Product Description............................................................................................................16
3.1 Product overview.........................................................................................................16
3.2 Types...........................................................................................................................17
3.3 Product name key........................................................................................................18
3.4 Name plate.................................................................................................................. 19
3.5 Design details..............................................................................................................20
3.6 Pressure rating and material....................................................................................... 27
3.7 Mechanical seal...........................................................................................................27
3.7.1 Mechanical seal selection - Pressure-/Temperature limits................................... 27
3.8 Expected noise values.................................................................................................28
3.9 Dimensions and weight............................................................................................... 29
4 Installation..........................................................................................................................30
4.1 Pump location..............................................................................................................31
4.2 Piping requirements.....................................................................................................32
4.3 Solids handling............................................................................................................ 34
4.4 Install the pump........................................................................................................... 34
4.4.1 Foundation requirements......................................................................................34
4.4.2 Install the pump set...............................................................................................35
4.4.3 Level the base on a concrete foundation..............................................................36
4.4.4 Grouting................................................................................................................ 37
4.4.5 Requirements for setting the base-frame..............................................................37
4.4.6 Permitted nozzle loads and torques at the pump nozzles.................................... 38
Table of Contents
e-MP Instruction manual 1

4.4.7 Auxiliary connection..............................................................................................40
4.5 Electrical requirements................................................................................................43
4.5.1 Maximum number of starts per hour.....................................................................45
4.6 Coupling...................................................................................................................... 46
4.6.1 Installation of the coupling.................................................................................... 46
4.6.2 Alignment of coupling ...........................................................................................47
4.6.3 Remove the coupling guard..................................................................................47
4.6.4 Control the alignment............................................................................................47
4.6.5 Permitted displacement for flexible couplings.......................................................49
4.6.6 Install the coupling guard......................................................................................49
4.7 Final check.................................................................................................................. 50
5 Commissioning, Startup, Operation, and Shutdown.......................................................... 51
5.1 Precautions..................................................................................................................51
5.2 Prerequirements for the start-up..................................................................................52
5.3 Lubrication...................................................................................................................52
5.3.1 Grease lubrication (Standard design)................................................................... 52
5.3.2 Oil lubrication of the pump.................................................................................... 52
5.3.3 Fill the oil...............................................................................................................53
5.3.4 Constant level oiler (Optional design)...................................................................54
5.4 Fill the pump................................................................................................................55
5.5 Check the rotation direction of the motor (three-phase motor)....................................58
5.6 Start up the pump set.................................................................................................. 59
5.7 Limits of operation....................................................................................................... 60
5.8 Hot water supply (Boiler feed or condensate water applications)................................61
5.9 Commissioning............................................................................................................61
5.10 Shutdown the system................................................................................................ 61
5.11 Temporary storage, longer periods of non-operation................................................ 62
5.12 Reshipment............................................................................................................... 63
6 Maintenance.......................................................................................................................64
6.1 Precautions..................................................................................................................64
6.2 Service.........................................................................................................................64
6.3 Checklist for inspections..............................................................................................65
6.4 Lubrication of the roller bearings................................................................................. 67
6.4.1 Grease lubrication.................................................................................................67
6.4.2 Changing the grease.............................................................................................67
6.4.3 Oil lubrication of the roller bearings...................................................................... 68
6.5 Mechanical seal...........................................................................................................68
6.6 Stuffing box..................................................................................................................69
6.7 Coupling...................................................................................................................... 70
6.8 Drainage......................................................................................................................71
6.9 Cleaning of the pump.................................................................................................. 71
6.10 Maintenance of flood damaged pump....................................................................... 71
7 Disassemble and Assemble the Pump.............................................................................. 72
7.1 Precautions..................................................................................................................72
7.2 Tools and maintenance resources.............................................................................. 73
7.3 Prepare the pump........................................................................................................74
7.4 Remove the motor.......................................................................................................74
7.5 Replace the bearings...................................................................................................74
7.5.1 Remove the coupling half..................................................................................... 74
7.5.2 Disassemble the grease lubricated roller bearings (all designs)...........................74
7.5.3 Assemble the grease lubricated roller bearings (all designs)............................... 76
7.5.4 Disassemble the oil lubricated roller bearings (all designs)..................................76
7.5.5 Assemble the oil lubricated roller bearings (all designs).......................................78
7.5.6 Disassemble the plain bearing MPA and MPR.....................................................78
Table of Contents
2 e-MP Instruction manual

7.5.7 Assemble the plain bearing MPA and MPR..........................................................81
7.6 Replace the shaft seal.................................................................................................82
7.6.1 Requirements........................................................................................................82
7.6.2 Disassemble the mechanical seal.........................................................................83
7.6.3 Assemble the mechanical seal............................................................................. 86
7.6.4 Disassemble the water-cooled mechanical seal...................................................87
7.6.5 Assemble the water-cooled mechanical seal........................................................90
7.6.6 Disassemble the cartridge seal.............................................................................91
7.6.7 Assemble the cartridge seal..................................................................................94
7.6.8 Replace the shaft sleeve of the stuffing box......................................................... 95
7.6.9 Assemble steps for all shaft seals.........................................................................99
7.7 Replace the balancing drum......................................................................................100
7.7.1 Disassemble the balancing drum........................................................................101
7.7.2 Assemble the balancing drum.............................................................................101
7.8 Replace the hydraulic parts.......................................................................................102
7.8.1 Disassemble the hydraulic part...........................................................................102
7.8.2 Disassemble the hydraulic part MPD..................................................................103
7.8.3 Disassemble the hydraulic part MPA, MPD, and MPR.......................................104
7.9 Assemble the hydraulic parts.................................................................................... 106
7.9.1 Assemble the hydraulic part MPA and MPR.......................................................108
7.9.2 Assemble the hydraulic part MPA, MPD, and MPR (mount the suction casing).108
7.10 Replace the wear ring..............................................................................................108
7.11 Assemble the complete disassembled pump.......................................................... 109
8 Troubleshooting............................................................................................................... 110
8.1 The main switch is on, but the electric pump does not start......................................110
8.2 The electric pump starts, but the thermal protection trips a varying time after..........110
8.3 The pump runs but delivers too little or no liquid.......................................................110
8.4 The main switch is on, but the electric pump does not start......................................110
8.5 The electric pump starts, but the thermal protector trips or the fuses blow
immediately after......................................................................................................... 110
8.6 The electric pump starts, but the thermal protector trips or the fuses blow a short
time after......................................................................................................................111
8.7 The electric pump starts, but the thermal protector trips a varying time after............111
8.8 The electric pump starts, but the system's general protection is activated............... 111
8.9 The electric pump starts, but the system's residual current device (RCD) is
activated...................................................................................................................... 111
8.10 The pump runs but delivers too little or no liquid.....................................................111
8.11 The electric pump stops, and then rotates in the wrong direction .......................... 112
8.12 The pump starts up too frequently...........................................................................112
8.13 The pump vibrates and generates too much noise................................................. 112
9 Technical Specification.................................................................................................... 113
9.1 Torque specification.................................................................................................. 113
9.1.1 Tightening torques of the pump screws..............................................................113
9.1.2 Anchor bolts........................................................................................................115
9.1.3 Impeller nuts....................................................................................................... 115
9.1.4 Plugs...................................................................................................................116
9.2 Pump data Mechanical Seals and Coupling sizes.....................................................116
9.3 Product name............................................................................................................ 117
10 Exploded View............................................................................................................... 118
10.1 Exploded view......................................................................................................... 118
11 Recommended spare parts and stand-by pumps.......................................................... 130
11.1 Ordering of spare parts............................................................................................130
11.2 Stand-by pumps...................................................................................................... 130
Table of Contents
e-MP Instruction manual 3

12 Product Warranty........................................................................................................... 132
Table of Contents
4 e-MP Instruction manual

1 Introduction and Safety
1.1 Introduction
Purpose of the manual
The purpose of this operating instruction manual is to provide necessary information for:
• Transport
• Storage
• Installation
• Operation
• Maintenance
• Disposal
Read and keep the manual
This operating instruction manual describes the correct and safe operation in all phases of
product life and should be kept in a safe place for future use.
The name plate indicates the type series, size and number of stages, the main operating
data and the order configuration number. The order configuration number uniquely identifies
the pump (set) and serves as identification for all further business processes.
1.1.1 Target group
This operating instruction manual is aimed at the target group of trained and qualified
specialist technical personnel.
1.1.2 General information
• This product corresponds with the requirements of the Machine directive 2006/42/EC.
• The operator is responsible for following the instructions and complying with the safety
requirements given in this operating instruction manual.
• Smooth operation of the pump or pump unit can only be achieved if installation and
maintenance are carried out carefully in accordance with the rules generally applied in
the field of engineering and electrical engineering.
• Safe operation of the delivered pump or pump unit can only be guaranteed when used as
designated according to the attached data sheet and / or Order Acknowledgement.
• If not all the information can be found in this operating instruction manual, please contact
the local sales and service representative.
• The manufacturer takes no responsibility for the pump or pump unit if the operating
instruction manual is not followed.
• If this pump or pump unit is handed on to any third party, it is essential that this operating
instruction manual and the operating conditions and working limits given in the data sheet
and / or Order Acknowledgement are also passed on in full.
• This operating instruction manual does not take into account all design details and
variants nor all the possible chance occurrences and events which might happen during
installation, operation and maintenance.
• We retain all copyright in this operating instruction manual; it is intended only for personal
use by the owner, or their designee, of the pump or the pump unit. The operating
instruction manual contain technical instructions and drawings which may not, as a whole
or in part, be reproduced, distributed or used in any unauthorized way for competitive
purposes or passed on to others.
1 Introduction and Safety
e-MP Instruction manual 5

1.1.3 Warranty
• Warranty information according Product Warranty on page 132.
• Repair work during the warranty period may only be carried out by Xylem or Xylem Inc.
Service Center, or subject to our written approval. Otherwise the warranty ceases to
apply.
• The warranty does not cover natural wear and tear and all parts subject to wear, such as
impellers, shaft sealing, shafts, shaft sleeves, bearings, wear rings etc. or damage
caused by transport or improper handling.
• In order for the warranty to apply, it is essential that the pump or pump unit is used in
accordance with the operating conditions given on the name plate, order
acknowledgement and in the data sheet.
• This applies particularly for the endurance of the materials and smooth running of the
pump and shaft sealing device.
• If one or more aspects of the actual operating conditions are different, Xylem should be
asked to confirm in writing that the pump is suitable for application.
1.2 Safety
1.2.1 Common safety notes
• This manual contains general installation, operating and maintenance instructions that
must be observed to ensure safe pump operation and prevent personal injury and
damage to property.
• For this reason, this operating instruction manual must be read by the skilled staff
responsible and/or by the operator of the plant before it is installed and commissioned,
and they must be kept permanently available at the place where the pump or pump unit
is in use.
• This operating instruction manual does not refer to the General Regulations on Accident
Prevention or local safety and/or operating regulations. The operator is responsible for
complying with these (if necessary by calling in additional installation staff).
• Equally, instructions and safety devices regarding handling and disposal of the pumped
media and/or auxiliary media for flushing, lubrication a.s.o., especially if they are
explosive, toxically, hot a.s.o., are not part of this operating instruction manual.
• For the competent and prescribed handling only the operator is responsible.
1.2.2 Key to safety symbols/markings
Safety symbols are published to help prevent these hazards:
• Personal accidents and health problems
• Damage of the product
• Product malfunction
Hazard levels
Hazard level Indication
DANGER:
A hazardous situation which, if not avoided, will
result in death or serious injury
WARNING:
A hazardous situation which, if not avoided, could
result in death or serious injury
CAUTION:
A hazardous situation which, if not avoided, could
result in minor or moderate injury
1 Introduction and Safety
6 e-MP Instruction manual

Hazard level Indication
NOTICE:
• A potential situation which, if not avoided, could
result in undesirable conditions
• A practice not related to personal injury
Explosion protection
This symbol identifies information about avoiding explosions in potentially explosive
atmospheres in accordance with EC Directive 2014/34/EU (ATEX).
• Operation in the EX-zone is allowed only if the data sheet and the order confirmation
show explicit allowed.
NOTICE:
• A potential situation which, if not avoided, could result in undesirable conditions.
• A practice not related to personal injury.
Danger classes
Special danger classes can show specific symbols, which replace the standard symbols.
DANGER: Danger by electricity
In conjunction with one of the signal words this symbol indicates a hazard involving electrical
voltage and identifies information about protection against electrical voltage.
Hot surface hazard
Hot surface hazards are indicated by a specific symbol that replaces the typical hazard level
symbols:
CAUTION:
Description of user and technician symbols
Specific information for all, who are responsible for the installation of the product (hydraulic
and/or electrical part) or for maintenance.
Specific information for the user.
Instructions
Instructions and warnings provided in this manual concern the standard version, as
described in the sales document. Special version pumps may be supplied with
supplementary instruction leaflets.
Refer to sales contract for any modifications or special version characteristics.
For instructions, situations, or events that is not considered in this operating instruction
manual or the sales document, contact the local sales and service representative.
1.2.3 Dangers of non-observance of safety instructions
Non-observance of the Safety Instructions can lead to loss of any claim for damages.
Further, non-observance can lead to following risks:
• Failure of important functions of the machine or facility.
• Failure of electronic appliances and measuring instruments by magnetic fields.
• Endangering of persons and their personal property by magnetic fields.
• Endangering of persons by electric, mechanic and chemical influences.
• Endangering of persons by electric, mechanic and chemical influences.
1 Introduction and Safety
e-MP Instruction manual 7

1.2.4 Personal qualification
• All personnel involved must be fully qualified to install, operate, maintain and inspect the
machinery this manual refers to.
• The responsibilities, competence and supervision of all personnel involved in transport,
installation, operation, maintenance and inspection must be clearly defined by the owner.
1.2.5 Intended use
NOTICE:
Never operate the pump without the fluid to be handled.
• The pump/pump set must only be operated within the operating limits described in the
other applicable documents.
• Only operate pump/pump set which are in perfect technical condition.
• Do not operate the pump/pump set in partially assembled condition.
• Only use the pump to handle the fluids described in the data sheet or product literature of
the pump model or variant.
• Observe the minimum flow rates indicated in the data sheet or product literature (to
prevent overheating, bearing damage, etc).
• Observe the maximum flow rates indicated in the data sheet or product literature (to
prevent overheating, mechanical seal damage, cavitation damage, bearing damage, etc).
• Do not throttle the flow rate on the suction side of the pump (to prevent cavitation
damage).
• Consult the manufacturer about any use or mode of operation not described in the data
sheet or product literature.
Prevention of foreseeable misuse
• Never open the discharge-side shut-off elements further than permitted.
– The maximum flow rates specified in the product literature or data sheet would be
exceeded.
– Risk of cavitation damage
• Never exceed the permissible operating limits specified in the data sheet or product
literature regarding pressure, temperature, etc.
• Observe all safety information and instructions in this manual.
• In the case of hazardous media or operating in higher than listed temperatures, ensure
the pump is taken out of operation if a barrier, flush or cooling system breaks down.
• Barrier, flush and cooling systems must always be in operation before start-up of the
pump. Shutdown only when the pump is at a standstill if this is permissible by the type of
operation.
• In plants where pumps operate in a closed system under pressure (gas cushion, vapor
pressure), the gas cushion is never allowed to be relieved via the pump, because the
return speed can be a multiple of the operating speed and can destroy the pump/pump
set.
1.2.6 Safety awareness
In addition to the safety information contained in this manual and the intended use, the
following safety regulations shall be complied with:
• Accident prevention, health and safety regulations
• Explosion protection regulations
• Safety regulations for handling hazardous substances
• Applicable standards, directives and laws
1 Introduction and Safety
8 e-MP Instruction manual

1.2.7 Safety information for the operator/user
• The operator shall fit contact guards for hot, cold and moving parts and check that the
guards function properly.
• Do not remove any contact guards during operation.
• Provide the personnel with protective equipment and make sure it is used.
• Contain leakages (e.g. at the shaft seal) of hazardous fluids handled (e.g. explosive,
toxic, hot) so as to avoid any danger to persons and the environment.
• Adhere to all relevant laws.
• Eliminate all electrical hazards. (In this respect refer to the applicable national safety
regulations and/or regulations issued by the local energy supply companies.)
• If the sound level of a pump or pump unit is above 85 dB (A) an ear protection has to be
used when staying near the pump for some time.
1.2.8 Safety information for maintenance, inspection, and installation
• The operator ensures that maintenance, inspection and installation are performed by
authorized, qualified specialist personnel who are thoroughly familiar with the manual.
• Only carry out work on the pump set during shutdown/standstill of the pump.
• The pump casing must have cooled down to ambient temperature.
• Pump pressure must have been released and the pump must have been drained.
• When taking the pump out of service always adhere to the procedure described in the
manual.
• Decontaminate pumps which handle fluids posing a health hazard.
• As soon as the work has been completed, re-install and/or re-activate any safety relevant
and protective devices. Before returning the product to service, observe all instructions
on commissioning.
1.2.9 Decals
Ensure this safety instruction decal is always clearly visible and readable. If the decal is
missing or illegible, contact your local sales and service representative for a replacement.
Figure 1: Grease lubricated pumps
Figure 2: Oil lubricated pumps
1.2.10 Unauthorized modification and spare parts production
• Alteration or changes of the machine are permitted after agreement with the
manufacturer.
• Original spare parts and accessory authorized by the manufacturer for safety measures.
• The use of other parts can lead to loss of liability.
1 Introduction and Safety
e-MP Instruction manual 9

1.2.11 Unauthorized modes of operation
• Never operate the pump (set) outside the limits stated in the data sheet and in this
manual.
• The warranty relating to the operating reliability and safety of the supplied pump (set) is
only valid if the equipment is used in accordance with its intended use.
• For more information, see Intended use on page 8.
1.2.12 Explosion protection
DANGER: Always observe the information on explosion protection given in this section when
operating the product in potentially explosive atmospheres
• Only pumps/pump sets marked as explosion-proof and identified as such in the data
sheet may be used in potentially explosive atmospheres.
•
Special conditions apply to the operation of explosion-proof pump sets to EU
Directive 2014/34/EU (ATEX).
• For this, the sections marked with the explosion protection symbol in this operating
manual and the following sections must be observed carefully.
• The explosion-proof status of the pump set is only assured if the pump set is used in
accordance with its intended use.
• Never operate the pump set outside the limits stated in the data sheet and on the name
plate. Prevent impermissible modes of operation at all times.
1.2.12.1 Marking
The marking on the pump refers to the pump end only. For coupling and motor or further
components a separate Declaration of Conformity, as well as a corresponding marking must
be available.
Example of such marking at pump: Ex II 2 G c T...
The marking shows the theoretically applicable range of temperature classes. The different
temperatures, permitted according to pump design, result as shown in Temperature limits on
page 10. The same is valid for the drive.
For a whole unit (pump, coupling, motor) with different temperature classes the lowest class
is valid.
1.2.12.2 Temperature limits
Under normal operating conditions the highest temperatures must be expected at the
surface of the pump casing and in the area of the bearings.
The surface temperature at pump casing corresponds with the temperature of the pumped
liquid. If the pump is heated (example heating jacket), care must be taken, that the
temperature classes, prescribed for the plant are observed.
In the area of the bearing bracket free contact from surface to surrounding must be given.
During operation of the pump it must be secured that an overabundant sedimentation of dust
is avoided (regular cleaning), to prevent heating of pump surface over the permitted
temperature.
The operator of the plant must ensure that the defined operating temperature is observed.
The max. allowed temperature of the pumped liquid at suction depends on the particular
temperature class.
The following table shows the theoretical temperature limits of the pumped liquid in
consideration of the temperature classes according to EN 13463-1.
1 Introduction and Safety
10 e-MP Instruction manual

Table 1:
Temperature class to EN 13463-1 Temperature limit of pumped liquid
T5 (212°F, 100°C) 212°F (100°C) (only after consultation with the
manufacturer)
T4 (275°F, 135°C) 275°F (135°C) 275°F (135°C)
T3 (392°F, 200°C) 275°F (135°C)
T2 (572°F, 300°C) Temperature limit of the pump
T1 (842°F, 450°C) Temperature limit of the pump
The particular allowed operating temperature of the pump is shown in the data sheet and / or
the Order Acknowledgement or the name plate on the pump.
In the area of the bearings the temperature class T4 is guaranteed, provided that the
ambient temperature is 113°F (45°C) and the machine is duly operated and maintained.
1.2.12.3 Operation of the pump
Filling
During operation of the pump the system of the suction and pressure pipe and the pump
itself must permanently be filled with the pumped liquid.
All sealing chambers, auxiliary systems of the shaft seal as well as heating and cooling
systems must be filled carefully.
If the operator cannot guarantee that, appropriate monitoring measures must be provided.
Operation
NOTICE:
The pump must start up with fully opened suction side and slightly opened pressure side
valve. The start-up against closed non-return valve, however, is possible. Immediately after
the start-up the discharge side valve must be adjusted to the operating point.
Barrier, flush and cooling systems must be in operation before the start-up of the pump.
Shutdown only when the pump stopped, if this is permitted by the nature of the operation.
For more information, see Start up the pump set on page 59.
Operation with closed valve in suction and / or discharge pipe is not permitted
In Limits of operation on page 60 the minimum flow is stated. Longer operating phases with
these flows and the named liquids do not cause additional increase of surface temperature
at the pump.
Furthermore the references in Commissioning, Startup, Operation, and Shutdown on page
51 must be taken into consideration.
On pumps with mechanical seals the permitted temperature limits can be exceeded due to
dry-run.
Dry run does not only occur on insufficiently filled seal cover, but also in case of excessively
high gas fractions in the medium.
Operation of the pump out of the permitted operating range can lead to dry-run, as well.
Maintenance
For a secure and reliable operation the pump unit must be maintained by regular inspections
and kept in good technical condition.
Example: Roller bearings.
By regular control of the lubricant and the running sound, the danger of going over
temperatures by bearings running hot or defect bearing seals is avoided. For more
information, see Lubrication on page 52 and Grease lubrication on page 67.
The function of the shaft sealing must be secured by regular control.
1 Introduction and Safety
e-MP Instruction manual 11

If auxiliary systems (e.g. external flushing, cooling, heating) are installed, it must be checked,
if monitoring devices are necessary to secure the function.
1.2.12.4 Electric switches and control devices, instrumentation, and accessories
Electric switches and control devices, instrumentation and accessories like e.g. flush tanks,
a.s.o., must correspond with the valid safety requirements and regulations for explosion
protection.
1.2.12.5 Intended use
Speed, pressure, and temperature
Suitable safety measures must be taken at the plant to ensure that the speed, pressure and
temperature of the pump and the shaft sealing do not exceed the limit values given in the
data sheet or order confirmation.
Further, pressure shocks, as can occur on too fast shut down of the operation, must be kept
away from the pump (e.g. by non-return valve at pressure side, fly wheel, air tanks). Quick
temperature changes must be avoided. They can cause a temperature shock and lead to
damage or impair the function of single components.
Permitted nozzle loads and torques
Basically the suction and discharge piping must be designed in such way, that as little forces
as possible are effective to the pump. If that is not possible, the values in Permitted nozzle
loads and torques at the pump nozzles on page 38 must not be exceeded under any
circumstances. This is valid for the operation as well as for the shutdown/standstill of the
pump and therefore for all possible pressures and temperatures of the unit.
NPSH
The pumped liquid must have a minimum pressure NPSH at the impeller inlet; so that
cavitation free work is secured or a "break off" of the pump flow is prevented. This condition
is fulfilled, when NPSH-value of the system (NPSHA) lies above NPSH-value of the pump
(NPSHR) under all operating conditions.
Attention must especially be paid to the NPSH-value on pumping liquids near the vapor
pressure. If the NPSH-value of the pump remains under, this can lead from damage of the
material due to cavitation to destruction by overheating.
The NPSH-value of the pump (NPSHR) is shown in the curves of every pump type.
Back flow
In systems where pumps are operating in closed circuits under pressure (gas cushions,
steam pressure), the pressure of the gas cushion must not be reduced via the pump, since
the back flow speed may be much higher than the operating speed, which would destroy the
unit.
1 Introduction and Safety
12 e-MP Instruction manual

2 Transportation and Storage
2.1 Inspect the delivery
• Check the outside of the package for evident signs of damage.
• Notify our distributor within eight days of the delivery date, if the product bears visible
signs of damage.
Unpack the unit
1. Follow applicable step:
– If the unit is packed in a carton, then remove the staples and open the carton.
– If the unit is packed in a wooden crate, then open the cover while paying attention to
the nails and straps.
2. Remove the securing screws or the straps from the wooden base.
2.1.1 Examine the unit
1. Remove packing materials from the product.
Dispose of all packing materials in accordance with local regulations.
2. To determine whether any parts have been damaged or are missing, examine the
product.
3. If applicable, unfasten the product by removing any screws, bolts, or straps.
Use care around nails and straps.
4. If there is any issue, then contact a sales representative.
2.2 Transportation guidelines
Precautions
WARNING:
• Observe accident prevention regulations in force.
• Crush hazard. The unit and the components can be heavy. Use proper lifting methods
and wear steel-toed shoes at all times.
Check the gross weight that is indicated on the package in order to select proper lifting
equipment.
Position and fastening
Keep the pump / pump unit in the same position in which it was supplied from the factory.
Make sure that the pump or pump unit is securely fastened during transportation and cannot
roll or fall over.
WARNING:
• Do not use eyebolts screwed on the motor for handling the whole electric pump unit.
• Do not use the shaft end of the pump or of the motor to handle the pump, the motor or
the unit.
• Eyebolts screwed onto the motor may be exclusively used to handle the individual motor
or, in case of a not balanced distribution of weights, to partially lift the unit vertically
starting from a horizontal displacement.
• To move the pump unit, use straps firmly linked to the rear of the motor.
• Lifting the pump unit with motor and base-frame should be done by utilizing a forklift.
• Pump unit must always be fixed and transported as shown.
2 Transportation and Storage
e-MP Instruction manual 13

• Always take extra precaution to ensure the weight is balanced and equally distributed
across both forks.
• Pump without motor must be fixed and transported as shown.
Figure 3: Transport of pump Figure 4: Transport of pump
Figure 5: Transport of pump unit
Unit without motor
WARNING: A pump and motor that are purchased separately and then coupled together
results in a new machine under the Machinery directive 2006/42/EC. The person making the
coupling is responsible for all safety aspects of the combined unit.
2.3 Storage guidelines
Short term storage
The product must be stored in a covered and dry location free from heat, dirt, and vibrations.
If the pump is stored longer than 8 weeks, the shaft must be rotated manually from this time
and once every month.
Pump must be drained of all fluids from all cavities before it is put into storage.
NOTICE:
Protect the product against humidity, heat sources, and mechanical damage.
2 Transportation and Storage
14 e-MP Instruction manual

NOTICE:
Do not place heavy weights on the packed product.
2.3.1 Long-term storage
If the unit is stored for more than 6 months, these requirements apply:
• Drain the pump of all fluids from all cavities.
• Store in a covered and dry location.
• Store the unit free from heat, dirt, and vibrations.
• Rotate the shaft by hand several times at least every three months.
When properly installed, protection is provided for a maximum of 12 months.
Treat bearing and machined surfaces so that they are well preserved.
Refer to the drive unit and coupling manufacturers for their long-term storage procedures.
For questions about possible long-term storage treatment services, please contact your local
sales and service representative.
Ambient temperature
The product must be stored at an ambient temperature from 23°F to 104°F (-5°C to +40°C).
2.3.2 Return to supplier
1. Drain the pump as per operating instructions.
For more information, see
Drainage on page 71.
2. Always flush and clean the pump, particularly if it has been used for handling noxious,
explosive, hot or other hazardous fluids.
3. If the pump set has handled fluids whose residues could lead to corrosion damage in the
presence of atmospheric humidity or could ignite upon contact with oxygen, the pump set
must also be neutralised, and anhydrous inert gas must be blown through the pump to
ensure drying.
4. Always complete and enclose a certificate of decontamination when returning the pump
or pump unit.
2.3.3 Disposal
WARNING:
Fluids, consumables and supplies which are hot and/or pose a health hazard to persons and
the environment !
• Collect and properly dispose of flushing fluid and any residues of the fluid handled.
• If required, wear safety clothing and a protective mask.
• Observe all legal regulations on the disposal of fluids posing a health hazard.
1. Dismantle the pump/pump unit.
2. Collect the greases and other lubricants during dismantling.
3. Separate and sort the pump materials, in the following categories:
– Metal
– Plastics
– Electronic waste
– Greases and other lubricants
Dispose of materials in accordance with local regulations or in another controlled
manner.
2 Transportation and Storage
e-MP Instruction manual 15

3 Product Description
3.1 Product overview
The pump is a multistage centrifugal ring section pump with suction impeller for low NPSH
value.
Intended use
• Water supply and water treatment
• Cooling and hot water supply in industries and building services
• Irrigation and sprinkler systems
• Heating systems
• Snow making applications
• Nano filtrations
• Boiler feed
Improper use
WARNING:
Improper use of the pump may create dangerous conditions and cause personal injury and
damage to property.
An improper use of the product leads to the loss of the warranty.
Examples of improper use:
• Liquids not compatible with the pump construction materials
• Hazardous liquids (such as toxic, explosive, flammable, or corrosive liquids)
• Potable liquids other than water (for example, wine or milk)
Examples of improper installation:
• Hazardous locations (such as explosive, or corrosive atmospheres).
• Location where the air temperature is very high or there is poor ventilation.
• Outdoor installations where there is no protection against rain or freezing temperatures.
DANGER:
Do not use this pump to handle flammable and/or explosive liquids.
NOTICE:
• Do not use the pump for flow rates beyond the specified flow rates on the data sheet or
Order Acknowledgement.
For more information, see Limits of operation on page 60.
• Do not use this pump to handle liquids containing abrasive, solid, or fibrous substances.
Special applications
Contact the local sales and service representative in the following cases:
• If the density or viscosity value of the pumped liquid exceeds the value of water, such as
water with glycol; as it may require a more powerful motor.
• If the pumped liquid is chemically treated (for example softened, deionized,
demineralized etc.).
• Any situation that is different from the ones that is described and relate to the nature of
the liquid.
3 Product Description
16 e-MP Instruction manual

3.2 Types
Figure 6: MPA and MPAE
• Horizontal shaft design
• Axial suction nozzle
• Radial discharge nozzle (left, top, right)
• Drive on discharge side
• Radial or Axial roller bearing on drive side
• Plain bearing on suction side
• Axial thrust balancing by drum design
• Shaft sealing on discharge side only
• Bare shaft pump or pump unit
• Driver: electric motor - NEMA standard or IEC
• Temperature range: 14°F to 284°F (-10°C to
140°C)
• Inlet pressure: up to 145 psi (10 bar)
Figure 7: MPD and MPDE
• Horizontal shaft design
• Radial suction nozzle (left, top, right)
• Radial discharge nozzle (left, top, right)
• Drive on discharge side (optional suction side
drive)
• Radial or Axial roller bearing on discharge side
• Radial roller bearing on suction side
• Axial thrust balancing by drum design
• Shaft sealing on suction and discharge side
• Bare shaft pump or pump unit
• Driver: electric motor - NEMA standard or IEC
• Temperature range: 14°F to 284°F (-10°C to
140°C)
• Inlet pressure: up to 580 psi (40 bar)
Figure 8: MPR and MPRE
• Horizontal shaft design
• Radial suction nozzle (left, top, right)
• Radial discharge nozzle (left, top, right)
• Drive on discharge side
• Radial or Axial roller bearing on drive side
• Slide bearing on suction side
• Axial thrust balancing by drum design
• Shaft sealing on discharge side only
• Bare shaft pump or pump unit
• Driver: electric motor - NEMA standard or IEC
• Temperature range: 14°F to 284°F (-10°C to
140°C)
• Inlet pressure: up to 145 psi (10 bar)
3 Product Description
e-MP Instruction manual 17

Figure 9: MPDP
• Horizontal shaft design
• Radial suction nozzle (left, top, right)
• Radial discharge nozzle (left, top, right)
• Drive on discharge side (optional on suction side)
• Pump feet in axis
• Radial or Axial roller bearing on discharge side
• Radial roller bearing on suction side
• Axial thrust balancing by drum design
• Shaft sealing on suction and discharge side
• Bare shaft pump or pump unit
• Driver: electric motor - NEMA standard or IEC
• Temperature range: 284°F to 365°F (140°C to
180°C)
• Inlet pressure: up to 580 psi (40 bar)
Optional -13°F (-25°C) pump design on demand.
The pump can be used for handling:
• Cold and warm water
• Clean liquids
• Aggressive liquids which are not chemically and mechanically aggressive to the pump
materials.
The product can be supplied as a pump unit (pump, base-frame and electric motor) or pump
end only.
NOTICE:
If you have purchased a pump without motor, make sure that the motor is suitable for
coupling to the pump.
3.3 Product name key
12 3 45678910
11
12
13
14 15
16
17
18
19
1. Pump type (2 characters)
2. Configuration (1 character)
3. Pump size (3 to 4 characters)
4. Number of stages/ impellers (2 characters)
5. Combination of full diameter and trimmed impellers (1 character)
6. Flange orientation (1 character)
7. ANSI suction flange class (1 character)
8. ANSI discharge flange class (1 character)
9. Motor HP (2 to 4 characters)
10.Motor enclosure (1 character)
11.Frame size (1 character)
12.Motor type (1 character)
13.No. of poles (1 character)
14.Motor frequency and voltage (2 characters)
15.Casing material (1 character)
16.Impeller material (1 character)
17.Diffuser material (1 character)
3 Product Description
18 e-MP Instruction manual
