Yakima LightMate User manual

9802701-Rev1.0 1/4
• Please read instructions carefully before installation.
• Check the contents of kit. Contact your YAKIMA dealer if any parts appear missing or damaged.
• Place these instructions in the vehicle’s glove box after installation is complete.
FIRST TIME INSTALLATION
KIT CONTENTS
ITEM COMPONENT QTY
1. LightMate L&R
with Plug x1
2. Steel Bracket x1
3. M6 8 mm Screw x5
4. M6 8 mm Washer x5
5. M6 8 mm Nuts x5
6. Velcro Straps x2
7. M6 14 mm Screw x4
8. M6 14 mm Washer x4
9. M6 14 mm
Dome Nut x4
10. Plastic Stopper x2
11. Cable Tie x4
®LightMate™
079YA K
LIGHTBOARD NUMBER PLATE
1
2
3
4
5
6
7
8
9
10 11
TOOLS REQUIRED:
• 4 mm Ball End Allen Key

9802701-Rev1.0 2/4
INSTALLATION
Assemble the
left and right
LightMate
sides together
using the
Steel Bracket,
the 5x M6 8
mm Screws,
Washers and
Nuts as shown.
Tighten all
Screws to 2
Nm using a 4
mm Ball End
Allen Key.
1
SECURE CABLE
Hook cable to clips
on rear of LightMate
as pictured and using
a sharp tool, break
the perforation to
allow the cable to
come through the
bottom of the light
board as shown.
2
THREAD VELCRO
STRAPS
Thread the Velcro
Straps through
the buckle loops on
back of LightMate
as shown.
3
ASSEMBLE LIGHT BOARD SIDES

9802701-Rev1.0 3/4
SECURE NUMBER PLATE
Checking the orientation of your number plate is correct, secure your plate using
the 2x Plastic Stoppers, the 4x M6 14 mm Screws, Washers and Dome Nuts as
shown.
Tighten all Screws to 2 Nm using a 4 mm Ball End Allen Key.
4
ATTACH LIGHTMATE
Secure LightMate to your bike carrier or bike frames using the Velcro Straps
as pictured.
Ensure the lights and number plate are not obstructed from view.
5

9802701-Rev1.0 4/4
www.yakima.com.au
www.yakima.co.nz
YAKIMA PRODUCTS, INC.
4101 Kruse Way
Lake Oswego, OR
97035-2541
USA
888 925 4621
YAKIMA AUSTRALIA PTY. LTD
17 Hinkler Court
Brendale, QLD 4500
Australia
1800 143 548
CONNECT LIGHT CABLE
Connect light cable as shown.
6
079YA K
LIGHTBOARD NUMBER PLATE
• Remove LightMate prior to entering a car wash.
• Replace Velcro straps if they become worn or damaged.
• Test lights are working correctly before the start of any journey.
MAINTENANCE AND SAFETY
TEST LIGHT FUNCTION
Test the vehicle’s tail light, brake, and indicator functions to ensure the equivalent
lights on LightMate illuminate.
7
079YA K
LIGHTBOARD NUMBER PLATE
