Read this manual carefully before operating this vehicle. This manual
should stay with this vehicle if it is sold.
U8JV70E0.book Page 1 Monday, April 6, 2015 11:49 AM

Introduction
ESU10122
Congratulations on your purchase of a
Yamaha snowmobile. This model is the result
of Yamaha’s vast experience in the produc-
tion of fine sporting and touring snowmo-
biles. It represents the high degree of
craftsmanship and reliability that have made
Yamaha a leader in these fields.
This manual will give you an understanding of
the operation, inspection, and basic mainte-
nance of this snowmobile. If you have any
questions concerning the operation or main-
tenance of your snowmobile, please consult
a Yamaha dealer.
Yamaha continually seeks advancements in
product design and quality. Therefore, while
this manual contains the most current prod-
uct information available at the time of print-
ing, there may be minor discrepancies
between your snowmobile and this manual. If
there is any question concerning this manual,
please consult a Yamaha dealer.
WARNING
EWS00671
Please read this manual carefully before
operating this snowmobile. Do not at-
tempt to operate this snowmobile until
you have attained adequate knowledge of
its controls and operating features.
Regular inspections and careful mainte-
nance, along with good operating tech-
niques, will help ensure that you safely
enjoy the capabilities and reliability of this
snowmobile.
RST90G
RST90TFG
RST90TFLG
RST90TFYG
OWNER’S MANUAL
©2015 by Yamaha Motor Corporation,
U.S.A.
1st Edition, March 2015
All rights reserved.
Any reprinting or unauthorized use
without the written permission of
Yamaha Motor C orporation, U.S.A.
is expressly prohibited.
Printed in Japan.
P/N LIT-12628-03-24
U8JV70E0.book Page 1 Monday, April 6, 2015 11:49 AM

Important manual information
ESU10152
Particularly important information is distin-
guished in this manual by the following nota-
tions.
This is the safety alert symbol. It is used
to alert you to potential personal injury haz-
ards. Obey all safety messages that follow
this symbol to avoid possible injury or death.
WARNING
EWS00022
A WARNING indicates a hazardous situa-
tion which, if not avoided, could result in
death or serious injury.
NOTICE
ECS00012
A NOTICE indicates special precautions
that must be taken to avoid damage to the
snowmobile or other property.
TIP
A TIP provides key information to make pro-
cedures easier or clearer.
U8JV70E0.book Page 1 Monday, April 6, 2015 11:49 AM

Contents
Location of the important labels...... 1
Safety information............................. 6
Description.........................................8
Control functions............................. 10
Main switch ................................... 10
Starter (choke) lever (RST90) ........ 10
Throttle lever ................................. 10
Throttle override system
(T.O.R.S.).................................... 11
Multi-function meter unit............... 11
D-mode (drive mode) (RST90TF /
RST90TFL / RST90TFY)............. 16
High beam indicator light ............. 16
Low coolant temperature indicator
light ........................................... 17
Fuel meter and grip/thumb
warmer level indicator ................ 17
Fuel level warning indicator ......... 20
Oil level warning indicator
(RST90) ...................................... 20
Oil level/pressure warning
indicator (RST90TF /
RST90TFL / RST90TFY)............. 21
Coolant temperature warning
indicator .................................... 22
Electric power steering warning
indicator “EPS” (RST90TF /
RST90TFL / RST90TFY)............. 22
Self-diagnosis device.................... 22
Engine stop switch ....................... 23
Headlight beam switch
“LIGHTS” ................................... 23
Grip/thumb warmer adjusting
switch......................................... 23
Auxiliary DC jack ........................... 24
Helmet shield heater jack
(RST90TF / RST90TFL /
RST90TFY) ................................. 25
Brake lever .................................... 25
Parking brake lever ....................... 26
Shift lever ...................................... 26
Drive guard ................................... 27
V-belt holders ............................... 28
Passenger grips (RST90TF /
RST90TFL / RST90TFY) ............ 29
Passenger grip warmer switch ..... 29
Passenger footrests...................... 30
Backrest........................................ 30
Storage compartment (RST90TF /
RST90TFL / RST90TFY) ............ 31
Storage areas (RST90).................. 32
Tow hitch (RST90TF / RST90TFL /
RST90TFY) and tow hitch
bracket (RST90) ......................... 35
Fuel ............................................... 35
Suspension ................................... 37
Performance damper
(RST90TFL) ................................ 42
Pre-operation checks ..................... 43
Pre-operation check list................ 43
Operation ......................................... 45
Starting the engine........................ 45
Break-in ........................................ 47
Riding your snowmobile ............... 47
Maximizing drive track life ............ 51
Driving........................................... 52
Stopping the engine ..................... 53
Transporting.................................. 53
Periodic maintenance and
adjustment....................................... 55
Periodic maintenance chart for
the emission control system...... 56
General maintenance and
lubrication chart ......................... 57
Tool kit .......................................... 59
Recommended equipment ........... 60
U8JV70E0.book Page 1 Monday, April 6, 2015 11:49 AM

Contents
Removing and installing the
shroud and covers (RST90TF /
RST90TFL / RST90TFY)............. 60
Opening and closing the shroud
and removing and installing the
right side cover (RST90)............. 62
Checking the spark plugs ............. 63
Adjusting the engine idling speed
(RST90) ...................................... 64
Adjusting the throttle lever free
play............................................. 65
Checking the throttle override
system (T.O.R.S.) ....................... 66
Checking the air filter .................... 67
Carburetors (RST90) ..................... 70
High-altitude settings .................... 70
Valve clearance ............................. 70
Engine oil and oil filter cartridge.... 71
Cooling system ............................. 76
V-belt............................................. 79
Drive chain housing....................... 82
Brake and parking brake............... 83
Extrovert drive sprocket
(RST90TF / RST90TFL /
RST90TFY) ................................. 86
Skis and ski runners...................... 86
Steering system ............................ 87
Drive track and slide runners ........ 89
Lubrication .................................... 92
Replacing a headlight bulb ........... 93
Adjusting the headlight beams ..... 95
Fittings and fasteners.................... 96
Battery........................................... 96
Replacing a fuse ........................... 97
Troubleshooting............................ 103
Storage .......................................... 108
Specifications................................ 110
Consumer information ................. 112
Identification number records..... 112
Vehicle Emission Control
Information label ...................... 113
YAMAHA SNOWMOBILE
LIMITED WARRANTY 2015
and Later Models..................... 114
YAMAHA EXTENDED SERVICE
(Y.E.S.) FOR U.S.A.
CUSTOMERS .......................... 117
YAMAHA PROTECTION PLUS
(YPP) FOR CANADIAN
CUSTOMERS .......................... 118
Index............................................... 119
U8JV70E0.book Page 2 Monday, April 6, 2015 11:49 AM

Location of the important labels
1
ESU10217
Read and understand all of the labels on your vehicle. They contain important information for
safe and proper operation of your vehicle. Never remove any labels from your vehicle. If a label
becomes difficult to read or comes off, a replacement label is available from your Yamaha
dealer.
1
3
7
2
6
5
4
6
5
4
3
2
1
7
RST90TF / RST90TFL / RST90TFY
RST90
U8JV70E0.book Page 1 Monday, April 6, 2015 11:49 AM

Location of the important labels
2
810
89
13
16
11 12
9
16
12 15
13
16
15 14 16
11
10
RST90TF / RST90TFL / RST90TFY
RST90
14
U8JV70E0.book Page 2 Monday, April 6, 2015 11:49 AM

Location of the important labels
3
ATTENTION
8ET-2815K-10
TUNE-UP SPECIFICATIONS
ENGINE
1.SPARK PLUG
2.SPARK PLUG GAP
3.IDLE SPEED
SPECIFICATIONS DE LA MISE AU POINT
MOTEUR
1.TYPE DE BOUGIE
2.ECARTEMENT DES ÉLECTRODES
3.RÉGIME DE RALENTI
CR8E(NGK)
0.7 ~ 0.8 mm (0.028 ~ 0.031 in)
1300 ± 50 r/min
CR8E(NGK)
0.7 ~ 0.8 mm
1300 ± 50 r/min
8HF
8HF-1417E-00
NOTICE
8ET-2815K-00
SEVERE INJURY OR DEATH MAY RESULT IF YOU IGNORE ANY OF
THE FOLLOWING:
• Read the Owner’s Manual and all labels before operating this vehicle.
• This vehicle is a high performance machine.
It should be operated by an experienced operator.
•
Check throttle, brake, and steering for proper operation before starting engine.
• Set parking brake before attempting to start engine.
Never run this vehicle with the parking brake applied.
•
To stop engine in an emergency, push the engine stop switch down.
• Do not operate engine without drive belt or drive guard.
• Make sure the fuel tank cap is closed securely after refueling.
• Do not operate this vehicle on public roads.
You could collide with another vehicle.
• Check lever position (Forward or Reverse) before moving.
• Weal an approved helmet, eye protection, and adequate clothing
for snowmobiling.
AFIN D’ÉVITER TOUT RISQUE DE BLESSURE SÉRIEUSE OU MÊME MORTELLE,
VEUILLEZ SUIVRE LES RECOMMANDATIONS SUIVANTES:
• Avant d’utiliser ce véhicule, lire le manuel du propriétaire et toutes les étiquettes.
• Ce véhicule est une machine à haute performance.
Elle doit être conduite par un conducteur expérimenté.
•
Avant de démarrer le moteur, vérifier l’opération du frein, de l’accélérateur
et de la direction.
• Le frein de sécurité doit être appliqué lors du démarrage.
Ne pas rouler avec le frein de sécurité actionné.
• En cas d’urgence, utiliser l’interrupteur d’arrêt du moteur.
• Ne pas laisser tourner le moteur sans la courroie ou sans son garde.
•
S’assurer que le bouchon du réservoir soit bien refermé après le remplissage.
• Afin d’éviter tout risque de collision, ne pas rouler sur un chemin public.
• Vérifier la position du levier (marche avant ou arrière) avant d’être en marche.
• Toujours porter un casque approuvé et un habillement de motoneigiste.
Prévoir une protection pour les yeux.
WARNING AVERTISSEMENT
8HF-77761-E0
TUNE-UP SPECIFICATIONS
ENGINE
1.SPARK PLUG
2.SPARK PLUG GAP
3.IDLE SPEED
SPECIFICATIONS DE LA MISE AU POINT
MOTEUR
1.TYPE DE BOUGIE
2.ECARTEMENT DES ÉLECTRODES
3.RÉGIME DE RALENTI
CR8E(NGK)
0.7 ~ 0.8 mm (0.028 ~ 0.031 in)
1400 ± 100 r/min
CR8E(NGK)
0.7 ~ 0.8 mm
1400 ± 100 r/min
8ES
8ES-1417E-00
8ER-E0
8ER-77763-E0
8HF-77763-E0
DRIVE
1. CHAIN CASE OIL Q’TY
2. CHAIN CASE OIL TYPE
3. TRACK TENSION
* FOR MORE INFO: SEE SERVICE MANUAL FOR THIS
MODEL.
* SPECIFICATIONS SUBJECT TO CHANGE WITHOUT
NOTICE.
ENTRAÎNEMENT
1. CAPACITÉ D’HUILE DU CARTER DE CHAÎNE
2. TYPE D’HUILE DU CARTER DE CHAÎNE
3. FLÈCHE DE LA CHENILLE
* POUR PLUS DE DÉTAIL: VOIR LE MANUEL D’ATELIER
POUR CE MODÈLE.
* LES CARACTÉRISTIQUE TECHNIQUES SONT
SUSCEPTIBLES DE CHANGER SANS NOTIFICATION
PRÉALABLE.
250 cm³ (8.5 oz)
GL-3 75W or 80W
30 ~ 35 mm (1.18 ~ 1.38 in)/100 N (10 kg, 22 lb)
250 cm³
GL-3 75W or 80W
8ES-47578-00
30 ~ 35 mm/100 N (10 kg)
TUNE-UP SPECIFICATIONS SPECIFICATIONS DE LA MISE AU POINT
21 RST90
3
1 RST90TF / RST90TFL / RST90TFY
4
6 RST90TF / RST90TFL / RST90TFY
6 RST90
5
7 RST90 7 RST90TF / RST90TFL / RST90TFY
U8JV70E0.book Page 3 Monday, April 6, 2015 11:49 AM

Location of the important labels
4
•
C
M
V
S
S
•
C
A
N
A
D
A
•
N
S
V
A
C
•
T
R
A
N
S
P
O
R
T
506
This spark ignition system meets all requirements of the
Canadian Interference Causing Equipment Regulations.
Ce système d’allumage par étincelle de véhicule
respecte toutes les exigences du Règlement sur le
matériel brouilleur du Canada.
3JK-82377-10
88C-77769-00
JUMPER CABLE CONNECTION LEADS
• For connecting procedures, refer to
Owner’s Manual.
FILS DE BRANCHEMENT DES CÂBLES
DE DÉMARRAGE
• Effectuer le branchement des câbles
de démarrage conformément aux
instructions du Manuel du propriétaire.
8FA-E0
8FA-2389C-E0
• NEVER stand behind or near
a rotating track.
• Debris or a broken track could
be thrown back with great force
which could cause severe leg
or other injuries, or death.
• Ne JAMAIS se tenir à proximité ou à
l’arrière d’une chenille en mouvement.
• Des débris ou une chenille cassée
pourraient être projetés violemment et
entraîner des blessures sévères aux
jambes ou autre, voire la mort.
8JT-77765-E0
WARNING AVERTISSEMENT
20kg {44lbs}
LOAD LIMIT / CHARGE LIMITE
8FM-24897-01
10kg {22lbs}
LOAD LIMIT / CHARGE LIMITE
8ET-24897-00
MAX. TOWING FORCE
FORCE DE REMORQUAGE MAX.
1176 N (120 kgf), 264 lbf
MAX. VERTICAL FORCE
FORCE VERTICALE MAX.
147 N (15 kgf), 33 lbf
8GS-2817S-E0
10
1312
8
9
11
14
U8JV70E0.book Page 4 Monday, April 6, 2015 11:49 AM

Location of the important labels
5
WARNING
AVERTISSEMENT
The unit contains nitrogen gas under high pressure.
Do not incinerate, puncture, open, doing so may cause
explosion and result in serious injury. See Owner’s manual.
L’unité contient de I’azote sous haute pression. Ne pas
lncinérer, perforer, ouvrir, car ceci pourrait causer une
explosion et de graves blessures.Voir le Manuel utilisateur.
K7R-22259-00
15 RST90TFL 16
U8JV70E0.book Page 5 Monday, April 6, 2015 11:49 AM

Safety information
6
ESU10204
As the vehicle’s owner, you are responsible
for the safe and proper operation of your
snowmobile. When you ride your snowmo-
bile, you must know and use the following for
your safety. Severe injury or death may result
if you ignore any of the following.
Before you operate your snowmobile
Read the Owner’s Manual and all labels.
Become familiar with all of the operating
controls and their function. Consult a
Yamaha dealer about any control or func-
tion you do not understand.
Wear protective clothing. Wear an ap-
proved helmet, and a face shield or gog-
gles. Also, wear a good quality snowmobile
suit, boots, and a pair of gloves or mittens
that will permit use of your thumbs and fin-
gers for operation of the controls.
Do not operate the snowmobile after or
while drinking alcohol or taking drugs. Your
ability to operate the snowmobile is re-
duced by the influence of alcohol or drugs.
Prepare your snowmobile
Perform the pre-operation checks each
time you use the vehicle to make sure it is
in safe operating condition. Failure to in-
spect or maintain the vehicle properly in-
creases the possibility of an accident or
equipment damage. See page 43 for a list
of pre-operation checks.
Apply the parking brake before starting the
engine. Never drive the snowmobile with
the parking brake applied. This may over-
heat the brake disc and reduce braking
ability.
While using your snowmobile
This snowmobile was not manufactured for
use on public streets, roads, or highways.
Such use is prohibited by law, and you
could collide with another vehicle.
Be careful where you ride. There may be
obstacles hidden beneath the snow. Stay
on established trails to minimize your expo-
sure to hazards. Ride slowly and cautiously
when you ride off of established trails. Hit-
ting a rock or stump, or running into wires
could cause an accident and injury.
This snowmobile is not designed for use on
surfaces other than snow or ice. Use on
dirt, sand, grass, rocks, or bare pavement
may cause loss of control and may dam-
age the snowmobile.
Always ride with other snowmobilers when
going on a ride. You may need help if you
run out of fuel, have an accident, or dam-
age your snowmobile.
Many surfaces such as ice and hard-
packed snow require much longer stop-
ping distances. Be alert, plan ahead and
begin decelerating early. The best braking
method on most surfaces is to release the
throttle and apply the brake gently—not
suddenly.
Avoid carbon monoxide poisoning
All engine exhaust contains carbon monox-
ide, a deadly gas. Breathing carbon monox-
ide can cause headaches, dizziness,
drowsiness, nausea, confusion, and eventu-
U8JV70E0.book Page 6 Monday, April 6, 2015 11:49 AM

Safety information
7
ally death. Carbon monoxide is a colorless,
odorless, tasteless gas which may be present
even if you do not see or smell any engine ex-
haust. Deadly levels of carbon monoxide can
collect rapidly and you can quickly be over-
come and be unable to save yourself. Also,
deadly levels of carbon monoxide can linger
for hours or days in enclosed or poorly-venti-
lated areas. If you experience any symptoms
of carbon monoxide poisoning, leave the
area immediately, get fresh air, and SEEK
MEDICAL TREATMENT.
Do not run the engine indoors. Even if you
try to ventilate engine exhaust with fans or
open windows and doors, carbon monox-
ide can rapidly reach dangerous levels.
Do not run the engine in poorly ventilated
or partially enclosed areas such as barns,
garages, or carports.
Do not run the engine outdoors where en-
gine exhaust can be drawn into a building
through openings such as windows and
doors.
Genuine Yamaha Accessories
Choosing accessories for your snowmobile is
an important decision. Genuine Yamaha Ac-
cessories, which are available only from a
Yamaha dealer, have been designed, tested,
and approved by Yamaha for use on your
snowmobile. Many companies with no con-
nection to Yamaha manufacture parts and
accessories or offer other modifications for
Yamaha vehicles. Yamaha is not in a position
to test the products that these aftermarket
companies produce. Therefore, Yamaha can
neither endorse nor recommend the use of
accessories not sold by Yamaha or modifica-
tions not specifically recommended by
Yamaha, even if sold and installed by a
Yamaha dealer.
Maintenance and storage
When laying the snowmobile on its side for
maintenance, use a suitable stand to keep
it in a stable and level position.
Do not leave the snowmobile on its left side
for an extended period of time. Fuel may
leak out from the fuel breather hose.
Do not allow anyone to stand behind the
snowmobile when starting, inspecting, or
adjusting the snowmobile. A broken track,
track fittings, or debris thrown by the track
could be dangerous to the operator or by-
standers.
Modifications made to the snowmobile not
approved by Yamaha, or the removal of
original equipment may render your snow-
mobile unsafe for use, which may cause
severe personal injury. Modifications may
also make the snowmobile illegal to use.
Never store the snowmobile with fuel in the
fuel tank inside a building where ignition
sources are present such as hot water and
space heaters, an open flame, sparks,
clothes dryers, and the like. Allow the en-
gine to cool off before storing the snowmo-
bile in an enclosed space.
U8JV70E0.book Page 7 Monday, April 6, 2015 11:49 AM

Description
8
ESU10262
1,2,3 4 7 8 9 10,11,12 13
151617
5,6 14
RST90TF / RST90TFL / RST90TFY
RST90
10,12 1,2,3,4 5,620 7 8 9 1913 14
15 181617
1. Battery
2. Main fuse
3. Air filter
4. Oil filler cap
5. Fuse box
6. Coolant reservoir
7. Passenger grip warmer switch
8. Passenger grip
9. Backrest
10. Storage compartment
11. Storage pouch (RST90TF / RST90TFL /
RST90TFY)
12. Tool kit
13. Tail/brake light
14. Tow hitch (RST90TF / RST90TFL /
RST90TFY) / tow hitch bracket (RST90)
15. Slide rail suspension
16. Drive track
17. V-belt holder
18. Solo touring storage area (RST90)
19. Rear carrier (RST90)
20. Throttle stop screw (RST90)
U8JV70E0.book Page 8 Monday, April 6, 2015 11:49 AM

Description
9
TIP
The snowmobile you have purchased may differ slightly from those shown in the figures of
this manual.
Design and specifications are subjected to change without notice.
123 5 647
8
9
10
11
12311
13 810
4 76
9
12
12
RST90TF / RST90TFL / RST90TFYRST90
1. Brake lever
2. Parking brake lever
3. Grip warmer adjusting switch
4. Thumb warmer adjusting switch
5. Helmet shield heater jack (RST90TF /
RST90TFL / RST90TFY)
6. Engine stop switch
7. Throttle lever
8. Main switch
9. Shift lever
10. Auxiliary DC jack
11. Headlight beam switch
12. Shroud latch (RST90)
13. Starter (choke) lever (RST90)
U8JV70E0.book Page 9 Monday, April 6, 2015 11:49 AM

Control functions
10
ESU13741
Main switch
The main switch controls the ignition and
lighting systems. The various positions are
described below.
Off
The ignition circuit is switched off.
The key can be removed only in this position.
On
The ignition circuit is switched on.
Start
The starting circuit is switched on.
The starter motor cranks the engine.
NOTICE: Release the switch immediately
after the engine starts. [ECS00022]
TIP
RST90TF / RST90TFL / RST90TFY: The
headlights and taillight come on after the
engine is started.
RST90: The headlights, meter lighting, and
taillights come on after the engine is start-
ed.
ESU10302
Starter (choke) lever (RST90)
Use the starter (choke) lever when starting
and warming up a cold engine.
TIP
Refer to the “Starting the engine” section on
page 45 for proper operation.
ESU10313
Throttle lever
Once the engine is running cleanly, squeez-
ing the throttle lever will increase the engine
speed and cause engagement of the drive
train. Regulate the speed of the snowmobile
by varying the throttle position. Because the
throttle is spring-loaded, the snowmobile will
decelerate, and the engine will return to idle
when it is released.
1. Off
2. On
3. Start
13
2
1. Starter (choke) lever
1. When starting a cold engine.
2. Warming up
3. When the engine is warm.
U8JV70E0.book Page 10 Monday, April 6, 2015 11:49 AM

Control functions
11
ESU13751
Throttle override system
(T.O.R.S.)
WARNING
EWS00042
If the T.O.R.S. is activated, make sure that
the cause of the malfunction has been
corrected and that the engine can be op-
erated without a problem before restarting
the engine. Continuing to operate with a
malfunction could cause loss of control or
damage.
If the throttle valves or throttle cable malfunc-
tions during operation, the T.O.R.S. will be
activated when the throttle lever is released.
The T.O.R.S. is designed to override the fuel
injection (RST90TF / RST90TFL / RST90TFY)
or ignition (RST90) and limit the engine speed
to less than the clutch engagement speed if
the throttle valves fail to return to the idle po-
sition when the throttle lever is released. (See
page 110 for the clutch engagement speed.)
TIP
If the T.O.R.S. is activated, the warning light
and engine trouble warning indicator flash,
and the two-digit code “84” displays
(RST90TF / RST90TFL / RST90TFY) or flash-
es (RST90) in the meter display. If this occurs,
have a Yamaha dealer check the system as
soon as possible.
RST90TF / RST90TFL / RST90TFY
RST90
ESU14851
Multi-function meter unit
RST90TF / RST90TFL / RST90TFY
The multi-function meter unit is equipped
with the following:
1. Throttle lever
Idling Riding Malfunc-
tion
Throttle
lever Released Squeezed Released
Throttle
valve Closed Open Open
T.O.R.S.
Engine
runs
properly.
Engine
runs
properly.
T.O . R. S .
will be
activated.
1. Warning light “ ”
2. Engine trouble warning indicator “ ”
3. Two-digit code “84”
1. Warning light “ ”
2. Engine trouble warning indicator “ ”
3. Two-digit code “84”
U8JV70E0.book Page 11 Monday, April 6, 2015 11:49 AM

Control functions
12
a digital speedometer
a tachometer
an odometer
two tripmeters
a fuel reserve tripmeter
an oil change tripmeter
a clock
a drive mode display
warning indicators
a warning light
a low coolant temperature indicator light
a high beam indicator light
a fuel meter
a grip/thumb warmer level indicator
a display brightness control function
When the key is turned to the on position, the
tachometer needle makes one sweep, and
the low coolant temperature indicator light,
the warning light, and all segments of the me-
ter unit display come on and go off.
The grip warmer level is initially displayed for
5 seconds, then the display switches to the
fuel meter.
TIP
To switch the speedometer, odometer, and
tripmeter displays between kilometers and
miles, select the odometer mode “ODO”, and
then push the “SELECT” button for at least
10 seconds while the snowmobile is stopped.
Odometer and tripmeter modes
Odometer shows the total distance that the
vehicle has run.
Tripmeter A and tripmeter B show the dis-
tance traveled since they last reset.
Fuel reserve tripmeter shows the distance
traveled since the fuel level warning indicator
and warning light came on.
Pushing the “SELECT” button switches the
display between the odometer mode “ODO”
and the tripmeter modes “TRIP A” and “TRIP
B” in the following order:
ODO →TRIP A →TRIP B →ODO
If the fuel level warning indicator and warning
light come on (see page 17), the odometer
display will automatically change to the fuel
reserve tripmeter mode “TRIP F” and start
counting the distance traveled from that
point. In that case, push the “SELECT” but-
1. “MODE” button
2. “RESET” button
3. “SELECT” button
4. Tachometer
5. Warning indicators
6. Clock
7. Low coolant temperature indicator
light “ ”
8. High beam indicator light “ ”
9. Warning light “ ”
10. Electric power steering warning indicator
“EPS”
11. Drive mode display
12. Meter display
12
10
7
9
23 4 5 61
8
11
1. Odometer/tripmeter/fuel reserve tripmeter
1
U8JV70E0.book Page 12 Monday, April 6, 2015 11:49 AM

Control functions
13
ton to switch the display between the various
tripmeter and odometer modes in the follow-
ing order:
TRIP F →ODO →TRIP A →TRIP B →TRIP F
To reset a tripmeter, select it by pushing the
“SELECT” button, and then push the “RE-
SET” button for at least 1 second. If you do
not reset the fuel reserve tripmeter manually,
it will reset itself automatically, and the dis-
play will return to the prior mode after the
snowmobile has been refueled and traveled 5
km (3 mi).
TIP
Odometer resets and continues counting
when it reaches 99999 while riding. How-
ever on the 10th time, the odometer will
lock at 99999.
Tripmeter A and tripmeter B reset and con-
tinue counting when they reach 999.9 while
riding.
Oil change tripmeter
Oil change tripmeter shows the distance trav-
eled since the periodic oil change interval
was reached.
When the periodic oil change interval is
reached at the initial 800 km (500 mi), then at
every 4000 km (2500 mi) thereafter, the oil
change tripmeter and “OIL” flash alternately
in the odometer display, and the tripmeter
starts counting the distance traveled from
that point. When this occurs, change the en-
gine oil as soon as possible. (See page 71 for
the oil change procedure.)
TIP
The oil change tripmeter will flash only
when the snowmobile is stopped.
To return to the previous display mode,
push the “SELECT” button. To display the
oil change tripmeter again, turn the key to
the off position, then back to the on posi-
tion.
After changing the engine oil, reset the oil
change tripmeter as follows.
To reset the oil change tripmeter (when the
engine oil was changed after the oil change
tripmeter appeared)
1. To display the oil change tripmeter, turn
the key to the on position.
2. Push the “RESET” button for at least 1
second while the oil change tripmeter
and “OIL” are flashing alternately in the
odometer display. The distance traveled
since the last oil change and “OIL” will
flash alternately in the odometer display.
3. Push the “RESET” button for approxi-
mately 3 seconds. “00000” and “OIL” will
flash alternately in the odometer display
3 times, and then the display will return
to the previous display mode.
If the engine oil is changed before the oil
change tripmeter appears in the display (i.e.,
before the periodic oil change interval has
U8JV70E0.book Page 13 Monday, April 6, 2015 11:49 AM

Control functions
14
been reached), the tripmeter must be reset
after the oil change for the next periodic oil
change to be indicated at the correct time.
In that case, reset the oil change tripmeter as
follows.
To reset the oil change tripmeter (when the
engine oil was changed before the oil change
tripmeter appeared)
1. Push the “SELECT” button until “ODO”
is displayed, and then push the “RESET”
button for at least 1 second. The dis-
tance traveled since the last oil change
and “OIL” will flash alternately in the
odometer display.
2. Push the “RESET” button for approxi-
mately 3 seconds. “00000” and “OIL” will
flash alternately in the odometer display
3 times, and then the display will return
to the previous display mode.
Clock
The clock uses a 12-hour time system.
To set the clock
1. Turn the key to the on position.
2. Push the “SELECT” button and “RESET”
button simultaneously until the hour dig-
its start flashing.
3. Push the “RESET” button to change the
hour setting, and then push the “SE-
LECT” button. The minute digits will start
flashing.
4. Push the “RESET” button to change the
minute setting, and then push the “SE-
LECT” button. The clock starts when the
“SELECT” button is released.
TIP
The clock must be set again when the battery
is disconnected.
Drive mode display
This display indicates which drive mode has
been selected: “S”, “T” or “E”. For more de-
tails on the modes and on how to select
them, refer to page 16.
Display brightness control
This function allows you to adjust the bright-
ness of the meter unit display to suit the out-
door lighting conditions.
To adjust the display brightness
1. Turn the key to the off position.
1. Clock
F
E
1
1. Drive mode display
1. Display brightness level
1
1
U8JV70E0.book Page 14 Monday, April 6, 2015 11:49 AM
