Yard force YF60VRX2.5-BAT User manual

YF60VRX2.5-BAT
YF60VRX4.0-BAT
60v Lithium-Ion Battery Pack
OPERATOR’S MANUAL
Our Customer Service staff is ready to provide assistance.
In the case of a damaged or missing part, most replacement parts ship directly from
Merotec USA in Atlanta or from one of our service partners in the US.
For immediate help with assembly, or for additional product information, email
[email protected] or call 866-902-9690 M-F 8:30am – 5:00pm ET. More
information can be found on www.YardForceUSA.com.
SAVE THIS MANUAL FOR REFERENCE
You will need this manual for safety
instructions, operating procedures, and Warranty.
The original sales receipt is required for warranty service.

2
TABLE OF CONTENTS
Product features ....................................................................................................................3
Technical data……………......................................................................................................3
Intended use………........................................................................................……...……......3
Warning symbols…....................................................................................……………..…....3
Product description and specications…........………………...........................................…..4
Safety notes…........................................................................……………………….........…..4
Operation……………………................................................................................…....………5
To obtain the best life from the battery ...…………..........................................................……6
Maintenance and service .................................................................…………………….……6
Disposal ................................................................................................................................6
Warranty ................................................................................................................................7

3
WARNING SYMBOLS
PRODUCT FEATURES
1. Green LED lamps
2. Indicator button
TECHNICAL DATA
Model Voltage Capacity
YFVRX2.5-BAT 60 V d.c. 2.5 Ah
YFVRX4.0-BAT 60 V d.c. 4.0 Ah
INTENDED USE
The battery pack YFVRX2.5-
BAT/ YFVRX4.0-BAT only can be
matched for Yard force 60V Li-ion
battery Charger YF60VRX4A-CHG/
YF60VRX2A-CHG. max. 113 ˚F
Before any use, refer to the
corresponding paragraph in
the present manual.
Batteries contain Li-ion.
Waste batteries should
be sorted for eco-friendly.
Do not dispose of waste
batteries as unsorted
municipal waste.
Do not throw into water
Do not litter to re.
Do not subject the battery
to strong sunlight over long
periods and do not leave it
on a heater (Max. 113 ˚F).
Do not expose and operate
the tool in rain.
2
1

4
PRODUCT DESCRIPTION AND
SPECIFICATIONS
WARNING:Read all safety warnings
and all instructions. Failure to follow the
warnings and instructions may result in
electric shock, re and/or serious injury.
Save these instructions for later
use. Use the battery pack only when
you fully understand and can perform
all functions without limitation, or have
received appropriate instructions.
SAFETY NOTES
1. Use only YardForce 60V Li-ion
battery charger YF60VRX4A-CHG
& YF60VRX2A-CHG. The Li-ion
battery pack is not fully charged at
the factory. Before attempting to
use it, it must be fully charged rst.
2. The battery pack should be
recharged when it fails to produce
su󰀩cient power for the operation
of the tool. DO NOT CONTINUE
using product with its battery in a
depleted condition.
3. Do not charge the battery in an air
temperature below below 32° F or
above 113° F.
This is important and will prevent
serious damage to the battery.
Longest life and best performance
can be obtained if the battery is
charged when air temperature is
about 68° F.
4. When the machine continues to be
used and the battery temperature
is above 113° F, the battery
cannot be charged, even you put
on the charger. Let the machine
cool for some times and wait the
temperature reduced, it can be
charged again.
5. Protect the battery pack against
heat, e.g. including against
continuous sun exposure and re.
There is a danger of explosion.
6. Do not carry individual battery
packs in your pockets or bags,
as they could short-circuit against
other metal items.
7. If an exposed li-ion battery pack
does start a re, it will burn even
more violently if it comes into
contact with water or even the
moisture in the air. Do Not throw
water on a burning li-ion battery! A
re extinguisher must be used.
8. If the battery pack becomes
too hot to the touch during
charging, disconnect and switch
o󰀨 immediately. Contact service
center directly.
9. Do not open the battery yourself.
There is danger of a short circuit.
10. When the battery pack is not in
use, keep it away from other metal
objects, lie paperclips, coins,
keys, nails, screws or other small
metal objects, which can make
a connection from one terminal
to another. Shorting the battery
terminals together may cause
burns or a re.
11. This tool is not intended for use
by persons (including children)
with reduced physical, sensory
or mental capabilities, or lack of
experience and knowledge, unless
they have been given supervision
or instruction concerning use of the

5
appliance by a person responsible
for their safety.
Children should be supervised to
ensure that they do not play with
the appliance.
12. Cleaning and user maintenance of
the battery pack shall not be made
by children without supervision.
13. Recharge only with the charger
specied by the manufacturer. A
charger that is suitable for one type
of battery pack may create a risk of
re when used with another battery
pack.
14. Recharge only with the charger
specied by the manufacturer. A
charger that is suitable for one type
of battery pack may create a risk of
re when used with another battery
pack.
15. Do not use a battery pack or
appliance that is damaged or
modied. Damaged or modied
batteries may exhibit unpredictable
behavior resulting in re, explosion
or risk of injury.
16. Do not expose a battery pack
or appliance to re or excessive
temperature. Exposure to re or
temperature above 130°C may
cause explosion. The temperature
of 130°C can be replaced by the
temperature of 265°F.
17. Follow all charging instructions
and do not charge the battery
pack or appliance outside of the
temperature range specied in the
instructions. Charging improperly
or at temperatures outside of the
specied range may damage the
battery and increase the risk of re.
18. Have servicing performed by a
qualied repair person using only
identical replacement parts. This
will ensure that the safety of the
product is maintained.
19. Do not modify or attempt to repair
the appliance or the battery pack
(as applicable) except as indicated
in the instructions for use and care.
WARNING: Battery posts,
terminals and related accessories
contain lead and lead compounds,
chemicals known to the State of
California to cause cancer and
birth defects or other reproductive
harm. Wash hands after handling.
For more information, go to www.
P65Warnings.ca.gov.
OPERATION
1. When you push the power indicator
button, the green LED lights will
show the power remaining.
2. Once the battery pack is correctly
located in the charger, the 4
green LED lights of the battery
pack will continuously be lighted

6
MAINTENANCE AND SERVICE
- Occasionally clean the battery
using a soft, clean and dry
brush.
When the charger is no longer
operative, please refer to an
authorized after-sales service
centre.
DISPOSAL
Battery packs, accessories and
packaging should be sorted for
environmental-friendly recycling.
Do not dispose of battery chargers into
household waste!
on to indicate the charging
process. At the same time the
green LED light of the charger will
ash continuously during normal
charging.
TO OBTAIN THE BEST LIFE
FROM THE BATTERY
- Avoid the battery from discharging
completely. If the battery is to be
unused for a long period, charge
it to 80% capacity at least before
storage.
- Avoid carrying out short battery
charges. Make sure that the battery
is fully charged every time by
allowing the charger to complete
its full charging cycle.
- Avoid allowing lose items like
screws or nails etc. to be stored
with battery packs as these or
similar items can make the battery
packs short-circuited which causes
a re or explosion
- Always unplug the charger when
not in use and store in a dry secure
place.
Avoid charging or storing your
battery in temperatures below 32°
F and above 113° F.
- Cool down hot battery pack from a
just-operated tool for approximately
30 minutes before attempting to
recharge.
Li-Ion

7
WARRANTY
Product Warranty
Please keep your original purchase receipt in a safe place as proof of purchase.
Warranty coverage for this product must be veried by the original purchase
receipt.
The warranty period begins on the day that the product was purchased from an
authorized retailer of Yard Force products. Warranty coverage only applies to the
original purchaser and is not transferrable. Warranty coverage is only provided on
products purchased from authorized Yard Force retailers.
Warranty only applies to products purchased and OPERATED in the USA. Any
product purchased or operated outside of the USA is not covered by any warranty.
(1) Five-Year Warranty on Yard Force Outdoor Power Equipment and
Three- Year Warranty on 60vRX Battery Pack and Adapter
The Yard Force Outdoor Power Equipment has a 5-Year Limited Warranty and
60vRX Battery Pack and charger has a 3-Year Limited Warranty from the date
of purchase against manufacturer defects for residential use only. Commercial
use voids the warranty. This warranty does not cover accidental damage,
unreasonable use, normal wear and tear, neglect or non-compliance with the
Operating, Safety and Maintenance Instructions. All service, outside of normal
maintenance as described in this manual, must be done by an authorized service
technician. Any unauthorized service or changes to the original conguration of
this product will void the warranty. All parts and accessories used on and with this
product must be manufactured and/or authorized by Merotec Inc.
(2) Ninety-Day Warranty – Accessories
The accessories included are warranted against manufacturer defects for
residential use only for a period of 90 days from date of purchase. Warranty does
not cover loss of use or other consequential damages arising from any of the
above, nor does it cover repairs made or attempted by unauthorized persons.
This warranty is void if the product is used for commercial, rental or industrial
purposes.
Certain parts, attachments and accessories are subject to normal wear and tear
and are excluded from the warranty.

8
Service and Warranty Claims Process
Contact the Yard Force Support Center toll-free at [phone] Monday-
Friday between 8:30 AM and 5:00 PM Eastern Time for service and warranty
support.
Yard Force Service Support agents can help you troubleshoot problems over
the phone to get you back up and running as quickly as possible. In the situation
where service or warranty inspection is needed, please follow these steps:
1. Call Yard Force at [phone] Monday-Friday between 8:30 AM and 5:00
PM Eastern Time.
2. Send in proof-of-purchase and serial number (if applicable) to conrm warranty
Coverage as directed by Yard Force.
3. If service or a warranty evaluation is requested, Yard Force will provide an RGA
number that should be used in all communications with Yard Force and is required
to be indicated on the product itself and on the outside of the box.
4. All shipments to Yard Force must have an RGA number. Any shipment received
that does not have an RGA number clearly marked on the outside of the box will
be refused.
5. All shipments must be sent pre-paid, Yard Force does not pay for any shipping
costs for service or warranty evaluation. Yard Force is not responsible for any
packages that are lost by carrier. We recommend that shipments are made by a
carrier that provides tracking and delivery conrmation.
For more information or to ask questions, please call toll-free [phone]
Monday-Friday between 8:30 AM and 5:00 PM Eastern Time.
SAVE THESE INSTRUCTIONS

Need Help?
Please do not return the product to the place of purchase yet.
We’re here to help and take care of all your needs.
Contact our Customer Care Center in
Atlanta, GA for help with:
Product assembly or use
Missing or damaged parts
Troubleshooting
You can also visit our website to download
owner's manuals and get additional product information.
Visit www.YardForceUSA.com, or call our
toll free hotline: [phone] M-F 8:30am – 5:00pm ET
1-866-902-9690 [email protected]
Merotec Inc.
3655 Kennesaw NorthIndustrial Parkway, Kennesaw, GA30144
© Copyright 2020 Merotec Inc.
Made in China at a SUMEC manufacturing facility.
MADE IN CHINA
