YASKAWA CIMR-ZU A Series Owner's manual

YASKAWA AC Drive Z1000
AC Drive for HVAC Fan and Pump
Programming Manual
MANUAL NO. SIEP C710616 45E
Models: 200 V Class: 2.2 to 110 kW (3 to 150 HP)
400 V Class: 2.2 to 370 kW (3 to 500 HP)
To properly use the product, read this manual thoroughly and retain
for easy reference, inspection, and maintenance. Ensure the end user
receives this manual.
Type: CIMR-ZUA
Parameter Details
Periodic Inspection &
Maintenance
Parameter List
BACnet Communications
APOGEE FLN (P1)
Communications
Metasys N2
Communications
MEMOBUS/Modbus
Communications
7
8
A
B
C
D
E
1
2
A
B
C
D
E

Copyright © 201YASKAWA ELECTRIC CORPORATION
All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or
transmitted, in any form or by any means, mechanical, electronic, photocopying, recording, or otherwise,
without the prior written permission of Yaskawa. No patent liability is assumed with respect to the use of the
information contained herein. Moreover, because Yaskawa is constantly striving to improve its high-quality
products, the information contained in this manual is subject to change without notice. Every precaution has
been taken in the preparation of this manual. Yaskawa assumes no responsibility for errors or omissions.
Neither is any liability assumed for damages resulting from the use of the information contained in this
publication.
