YOKOGAWA AQ2200 Series User manual

User’s
Manual AQ2200 Series
Multi Application Test System
Startup Guide
IM 735101-01EN
13th Edition

Product Registration
Thank you for purchasing YOKOGAWA products.
YOKOGAWA provides registered users with a variety of information and services.
Please allow us to serve you best by completing the product registration form
accessible from our website.
http://tmi.yokogawa.com/
PIM 103-04E

Thank you for purchasing this AQ2200 Series Multi Application Test System. The AQ2200
Series Multi Application Test System consists of the AQ2211/AQ2212 Frame Controller
and multiple measurement modules. The frame controllers are capable of holding and
controlling measurement modules.
This user’s manual explains the features, operating procedures, and handling precautions
of the AQ2200 Series. To ensure correct use, please read this manual thoroughly before
operation. Keep this manual in a safe place for quick reference in the event a question
arises.
List of Manual The following manuals, including this one, are provided as manuals for the AQ2200
Series. Please read all manuals.
Manual Title Manual No. Description
AQ2200 Series
Multi Application Test System
User’s Manual Startup Guide
IM 735101-01EN This manual. The supplied CD contains
the PDF file of this manual. This manual
describes the handling precautions for, the
names and functions of all parts of, and the
firmware upgrade procedure for the AQ2200
Series.
AQ2200 Series
Multi Application Test System
Frame and Module Operation
User’s Manual
IM 735101-03EN The supplied CD contains the PDF file of
this manual. This manual describes all the
features of the AQ2200 Series and how to
use them, with the exception of some of the
application and communication features.
AQ2200 Series
Multi Application Test System
Application Operation
User’s Manual
IM 735101-04EN The supplied CD contains the PDF file of
this manual. This manual describes the
AQ2200 Series application features and
how to use them.
AQ2200 Series
Multi Application Test System
Communication Interface
User’s Manual
IM735101-17EN The supplied CD contains the PDF file of
this manual. This manual describes the
AQ2200 Series communication interface
features and how to use them.
64 Mbit Program Pattern Option
User’s Manual
IM 810518801-61E This manual describes how to create
program patterns for the AQ2200-601
10 Gbit/s BERT module with the /M option.
SDH/SONET Frame Option
User’s Manual
IM 810518801-62E This manual describes how to create SDH/
SONET patterns for the AQ2200-601
10 Gbit/s BERT module with the /P1 option.
AQ2200 Series Modules
Checking the Contents of
the Package and Handling
Precautions of the Modules
IM 810518901-04E This is included with AQ2200 Series
modules. It explains the handling
precautions of the module and lists the
package contents.
Connector Adapter
for Multi-Fiber Cable
User’s Manual
IM AQ9340-01EN This manual explains the handling
precautions of the connector adapters and
how to use them.
The “EN” and “E” in the manual numbers are the language codes.
Contact information of Yokogawa offices worldwide is provided on the following sheet.
Manual No. Description
PIM 113-01Z2 List of worldwide contacts
13th Edition: February 2019 (YMI)
All Rights Reserved, Copyright ©2009, Yokogawa Electric Corporation
All Rights Reserved, Copyright ©2012, Yokogawa Test & Measurement Corporation
i
IM 735101-01EN

Notes • The contents of this manual are subject to change without prior notice as a result of
continuing improvements to the instrument’s performance and functions.
The figures given in this manual may differ from those that actually appear on your
screen.
• Every effort has been made in the preparation of this manual to ensure the accuracy
of its contents. However, should you have any questions or find any errors, please
contact your nearest YOKOGAWA dealer.
• Copying or reproducing all or any part of the contents of this manual without the
permission of YOKOGAWA is strictly prohibited.
Trademarks • Adobe and Acrobat are registered trademarks or trademarks of Adobe Systems
Incorporated.
• Microsoft and Windows are registered trademarks or trademarks of Microsoft
Corporation in the United States and/or other countries.
• In this manual, the ® and TM symbols do not accompany their respective registered
trademark or trademark names.
• Other company and product names are registered trademarks or trademarks of their
respective holders.
Revisions • 1st Edition: August 2009
• 2nd Edition: November 2009
• 3rd Edition: January 2010
• 4th Edition: March 2010
• 5th Edition: November 2012
• 6th Edition: September 2014
• 7th Edition: May 2015
• 8th Edition: November 2015
• 9th Edition: May 2017
• 10th Edition: October 2017
• 11th Edition: February 2018
• 12th Edition: September 2018
• 13th Edition: February 2019
ii IM 735101-01EN

Checking the Package Contents
After receiving the product and opening the package, check the items described below.
If the wrong items have been delivered, if items are missing, or if there is a problem with
the appearance of the items, contact your nearest YOKOGAWA dealer. When contacting
the dealer from which you purchased the instrument, please give them the instrument
number.
Also, check that the model name and suffix code given on the name plate on the side
panel of the module are the same as those on your order.
IN
OUT
REMOTE
TRIGGER
INTERLOCK
100-240 V AC
170 VA MAX 50/60 Hz
LINK/ACT
USB ETHERNET
100 LINK
GP-IB
(IEEE488)
WARNING
Do not operate without reading
the safety precautions in the
user's manual.
DATEOF
MANUFACTURE
□□□□ □□ □□
MODEL
SUFFIX
NO
Madein Japan
AQ2211 Frame Controller AQ2212 Frame Controller
IN
OUT
REMOTE
TRIGGER
INTERLOCK
100-240 V AC
580 VA MAX 50/60 Hz
LINK/ACT
USB ETHERNET
100 LINK
GP-IB
(IEEE488)
WARNING
Do not operate without reading the
safety precautions in the user's manual.
DATEOF
MANUFACTURE
□□□□ □□ □□
MODEL
SUFFIX
NO
Madein Japan
—
—
—
—
AQ2211/AQ2212 Frame Controller
MODEL SUFFIX1Description
735101 AQ2211 Frame Controller (Three slots)
735102 AQ2212 Frame Controller (Nine slots)
Power cord2-D UL/CSA standard and PSE compliant, Maximum rated voltage: 125 V
-F VDE/Korean standard, Maximum rated voltage: 250 V
-R Australian standard, Maximum rated voltage: 250 V
-Q British standard, Maximum rated voltage: 250V
-H Chinese standard, Maximum rated voltage: 250 V
-N Brazilian standard, Maximum rated voltage: 250 V
-T Taiwanese standard, Maximum rated voltage: 125 V
-B Indian standard, Maximum rated voltage: 250 V
-U IEC Plug Type B, Maximum rated voltage: 250 V
-Y No power cord included.3
1 For products whose suffix code contains “Z,” an exclusive manual may be included.
Please read it along with the standard manual.
2 Make sure that the attached power cord meets the designated standards of the country and area
that you are using it in.
3 Prepare a power cord that complies with the standard specified by the country or region that the
instrument will be used in.
No. (Instrument Number)
When contacting the dealer from which you purchased the instrument, please give them
the instrument number.
iii
IM 735101-01EN

Standard Accessories
The standard accessories below are supplied with the instrument. Check that all contents
are present and that they are undamaged.
DF R
U
H
NT
Q
B
UL/CSA standard
A1006WD
VDE/Korian standard
A1009WD
Australian standard
A1024WD
Chinese standard
A1064WD
Brazilian standard
A1088WD
Taiwanese standard
A1100WD
British standard
A1054WD
Indian standard
A1101WD
IEC Plug Type B
A1102WD
Power cord (one cord that matches the suffix code is included)
1
Interlock connector plug
A1288JA 1 piece
Manuals2
• Manual CD
Rubber feet
A9088ZM 1 set • Printed manuals
Standard accessories are not covered by warranty of this instrument.
1 Make sure that the attached power cord meets the designated standards of the country and area
that you are using it in. If the suffix code is -Y, a power cord is not included.
2 Manuals
Item Model or Part No. Quantity Specifications and Notes
Printed manuals IM 735101-01EN 1 Startup Guide (this guide)
PIM 113-01Z2 1 List of worldwide contacts
IM 810518801-61E 1 For the AQ2200-601 10 Gbit/s BERT module
with the /M option
IM 810518801-62E 1 For the AQ2200-601 10 Gbit/s BERT module
with the /P1 option
IM 810518901-04E 1 For the AQ2200 series modules.
Manual CD B8085NZ 1 Contains PDFs of the user’s manuals
(For the types of manuals that CD contains,
see the next page.)
Printed manuals can be purchased separately.
Contact your nearest YOKOGAWA dealer to
purchase a copy.
Optional Accessories (Sold separately)
The optional accessories below are available for purchase separately. For information
about ordering accessories, contact your nearest YOKOGAWA dealer.
Item Model or Part No. Specifications
AQ2200-901 blank panel 810518926 1-slot size
AQ2211 rack mount kit 735182-03 For mounting one AQ2211 to the left side of an EIA-
standard rack.
AQ2212 rack mount kit 735182-09 For mounting one AQ2212 to an EIA-standard rack.
Optional accesories(sold separately) are not covered by warranty of this instrument.
Checking the Package Contents
iv IM 735101-01EN

Manual CD
The English folder in the manual CD contains the PDF files shown below. The CD also
contains Japanese manuals.
Manual Title Manual No.
AQ2200 Series Multi Application Test System
User’s Manual Startup Guide
IM 735101-01EN
AQ2200 Series Multi Application Test System
Frame and Module Operation User’s Manual
IM 735101-03EN
AQ2200 Series Multi Application Test System
Application Operation User’s Manual
IM 735101-04EN
AQ2200 Series Multi Application Test System
Communication Interface User’s Manual
IM 735101-17EN
To view the manuals above, you need Adobe Reader.
WARNING
Never play this manual CD in an audio CD player.
Doing so may cause loss of hearing or speaker damage due to the high-volume
sound that may be produced.
French
AVERTISSEMENT
Ce CD contient les manuels d’utilisation. Ne jamais insérer ce CD dans un lecteur
de CD audio. Cela pourrait entraîner une perte d’audition ou l’endommagement
des enceintes en raison du volume potentiellement élevé des sons produits.
Checking the Package Contents
v
IM 735101-01EN

Safety Precautions
This product is designed to be used by a person with specialized knowledge.
This instrument is an IEC safety class I instrument (provided with a terminal for protective
earth grounding).
The general safety precautions described herein must be observed during all phases
of operation. If the instrument is used in a manner not specified in this manual, the
protection provided by the instrument may be impaired. This manual is part of the
product and contains important information. Store this manual in a safe place close to the
instrument so that you can refer to it immediately. Keep this manual until you dispose of
the instrument.
YOKOGAWA assumes no liability for the customer’s failure to comply with these
requirements.
The following symbols are used on this instrument.
Handle with care. Refer to the user’s manual or service manual. This symbol
appears on dangerous locations on the instrument which require special
instructions for proper handling or use. The same symbol appears in the
corresponding place in the manual to identify those instructions.
Alternating current
Power-on state
Power-off state
Laser radiation hazard
Power on
Power off
French
À manipuler délicatement. Toujours se reporter aux manuels d’utilisation et
d’entretien. Ce symbole a été apposé aux endroits dangereux de l’instrument pour
lesquels des consignes spéciales d’utilisation ou de manipulation ont été émises.
Le même symbole apparaît à l’endroit correspondant du manuel pour identifier les
consignes qui s’y rapportent.
Courant alternatif
Marche
Arrêt
Danger : Appareil laser à rayonnement.
Marche (alimentation)
Arrêt (alimentation)
vi IM 735101-01EN

Failure to comply with the precautions below could lead to injury or death or
damage to the instrument.
WARNING
Use the Instrument Only for Its Intended Purpose
This optical measuring instrument is designed to measure the optical characteristics
of light sources and evaluate their performance. Do not use this instrument for
anything other than as an optical measuring instrument.
Check the Physical Appearance
Do not use the instrument if there is a problem with its physical appearance.
Use the Correct Power Supply
Make sure that the power supply voltage matches the instrument’s rated supply
voltage and that it does not exceed the maximum voltage range of the power cord
to use.
Use the Correct Power Cord and Plug
To prevent electric shock or fire, be sure to use the power cord for the instrument.
The main power plug must be plugged into an outlet with a protective earth terminal.
Do not invalidate this protection by using an extension cord without protective earth
grounding. Further, do not use this power cord with other instruments.
Connect to a Protective Earth Terminal
To prevent electric shock, be sure to connect to a protective earth terminal before
turning on the frame controller’s power. The power cord to use is a three-prong
cord. Connect the power cord to a properly grounded three-prong outlet.
Do Not Impair the Protective Grounding
Never cut off the frame controller’s internal or external protective earth wire or
disconnect the wiring to the protective earth terminal. Doing so may result in
electric shock or damage to the instrument.
Do Not Operate with Defective Protective Grounding or Fuses
Do not operate the frame controller if its protective grounding or one of its fuses
might be defective. Check the grounding and the fuses before operating the frame
controller.
Do Not Operate in an Explosive Atmosphere
Do not operate the instrument in the presence of flammable gasses or vapors.
Doing so is extremely dangerous.
Do Not Remove the Covers or Disassemble or Alter the Instrument
Only qualified YOKOGAWA personnel may remove the covers and disassemble or
alter the instrument. The inside of the frame controller is dangerous because parts
of it have high voltages.
Ground the Instrument before Making External Connections
Securely connect the protective grounding before connecting to the item under
measurement or to an external control unit. Before touching a circuit, turn off its
power and check that it has no voltage.
Safety Precautions
vii
IM 735101-01EN

Avoid Electric Shock When Using the Modules
Do not apply an input voltage that exceeds the maximum input voltage, withstand
voltage, or allowable surge voltage.
To prevent the possibility of electric shock, be sure to fasten the screws that are at
the bottom of the front panel of 2-slot and 3-slot modules. Otherwise, the electrical
and mechanical protection functions will not be activated.
Do not leave the modules connected to the instrument in environments in which a
voltage equal to or greater than the allowable surge voltage may occur.
Dispose the Instrument Properly
Do not throw this instrument into a fire to dispose of it. Doing so may cause the
instrument to explode, resulting in fire or personal injury.
The devices used in this instrument contain gallium arsenide (GaAs) and indium
phosphide (InP). When you dispose this instrument, you must separate it from
general industrial waste and household garbage, and dispose of it according to
local regulations.
Additionally, gallium arsenide powder and vapor are dangerous substances. Do not
burn, cut, crush, chemically disassemble, or otherwise destroy this instrument.
Install or Use the Instrument in Appropriate Locations
• Do not install or use the instrument outdoors or in locations subject to rain or
water.
• Install the instrument so that you can immediately remove the power cord if an
abnormal or dangerous condition occurs.
CAUTION
Operating Environment Limitations
This is a class A instrument designed for an industrial environment. Operation of
this equipment in a residential area can cause radio interference, in which case
users will be required to correct the interference.
French
AVERTISSEMENT
Utiliser l’instrument aux seules fins prévues
Cet instrument de mesure optique est prévu pour mesurer les caractéristiques
optiques des sources lumineuses et évaluer leur performance. Ne pas utiliser cet
instrument à d’autres fins que celles de mesure optique.
Inspecter l’apparence physique
Ne pas utiliser l’instrument si son intégrité physique semble être compromise.
Vérifier l’alimentation
Assurez-vous que la tension d’alimentation correspond à la tension d’alimentation
nominale de l’appareil et qu’elle ne dépasse pas la plage de tension maximale du
cordon d’alimentation à utiliser.
Utiliser le cordon d’alimentation et la fiche adaptés
Pour éviter tout risque de choc électrique, utiliser exclusivement le cordon
d’alimentation prévu pour cet instrument. La fiche doit être branchée sur une prise
secteur raccordée à la terre. En cas d’utilisation d’une rallonge, celle-ci doit être
impérativement reliée à la terre. Par ailleurs, ne pas utiliser ce cordon d’alimentation
avec d’autres instruments.
Safety Precautions
viii IM 735101-01EN

Brancher la prise de terre
Avant de mettre l’instrument sous tension, penser à brancher la prise de terre
pour éviter tout choc électrique. Le cordon d’alimentation à utiliser est un cordon
d’alimentation à trois broches. Brancher le cordon d’alimentation sur une prise de
courant à trois plots et mise à la terre.
Ne pas entraver la mise à la terre de protection
Ne jamais neutraliser le fil de terre interne ou externe, ni débrancher la borne
de mise à la terre. Cela pourrait entraîner un choc électrique ou endommager
l’instrument.
Ne pas utiliser avec un conducteur de terre ou un fusible défectueux
Ne pas utiliser l’instrument si le conducteur de terre ou le fusible est défectueux.
Vérifier le conducteur de terre et le fusible avant d’utiliser l’instrument.
Ne pas utiliser dans un environnement explosif
Ne pas utiliser l’instrument en présence de gaz ou de vapeurs inflammables.
Cela pourrait être extrêmement dangereux.
Ne pas retirer le capot, ni démonter ou modifier l’instrument
Seul le personnel YOKOGAWA qualifié est habilité à retirer le capot et à démonter
ou modifier l’instrument. Certains composants à l’intérieur de l’instrument sont à
haute tension et par conséquent, représentent un danger.
Relier l’instrument à la terre avant de le brancher sur des connexions
externes
Toujours relier l’instrument à la terre avant de le brancher aux appareils à mesurer
ou à une commande externe. Avant de toucher un circuit, mettre l’instrument hors
tension et vérifier l’absence de tension.
Éviter les chocs électriques lors de l’utilisation des modules.
Ne pas dépasser les valeurs maximales de tension d'entrée, de tension de
maintien ou de surtension admissible.
Pour éviter tout risque de choc électrique, veiller à serrer les vis situées au bas du
panneau avant des modules à 2 et 3 emplacements, à défaut de quoi les fonctions
de protection électrique et mécanique ne seront pas activées.
Ne pas laisser les modules branchés à l'instrument dans des environnements dans
lesquels la tension pourrait être égale ou supérieure à la surtension admissible.
Mettre l’instrument au rebut de manière adéquate.
Ne pas mettre l’instrument au rebut en le jetant au feu. Il risquerait d’exploser et de
provoquer un incendie ou de blesser quelqu’un.
Les dispositifs utilisés avec cet instrument contiennent de l’arséniure de gallium
(AsGa) et du phosphure d’indium (InP). Lors de la mise au rebut de l’instrument,
vous ne devez pas l’associer aux déchets industriels généraux ni aux déchets
domestiques, mais l’éliminer conformément aux réglementations locales.
De plus, la poudre et les vapeurs d’arséniure de gallium sont des substances
dangereuses. Ne pas brûler, couper, écraser, démonter chimiquement ou détruire
cet instrument.
Safety Precautions
ix
IM 735101-01EN

Installer et utiliser l’instrument aux emplacements appropriés
• Ne pas installer, ni utiliser l’instrument à l’extérieur ou dans des lieux exposés à
la pluie ou à l’eau.
• Installer l’instrument de manière à pourvoir immédiatement le débrancher du
secteur en cas de fonctionnement anormal ou dangereux.
ATTENTION
Limitations relatives à l’environnement opérationnel
Ce produit est un produit de classe A (pour environnements industriels).
L’utilisation de ce produit dans un zone résidentielle peut entraîner une interférence
radio que l’utilisateur sera tenu de rectifier.
Safety Precautions for Laser Products
This instrument uses a laser light source. This instrument is a Class 1M laser product as
defined by IEC 60825-1:2007 Safety of Laser Products—Part1: Equipment Classification
and Requirements. In addition, this instrument complies with 21 CFR 1040.10 and
1040.11 except for deviations pursuant to Laser Notice No. 50, dated June 24, 2007.
AQ2200-112, AQ2200-131, and AQ2200-132 Modules
Laser Class 1M Label
Laser Class 1 Label
Using an optical instrument, such as a
loupe, magnifying glass, or microscope,
when observing the laser beam from a
distance of less than 100 mm may cause
eye injury.
Do not expose users of binoculars or
telescopes.
Skin exposure near aperture may cause
burns.
Model Class Laser Type 1Center Wavelength Maximum
Output Power 2
Mode Field
Diameter
Beam Divergence
(full angle at 1/e2)
Pulse Duration and
Repetition Rate
AQ2200112 1, 1M DFB-Laser 1310 to 1650 nm 40 mW 9 μm 11.5 degree CW
AQ2200131 1, 1M ITLA 1527.60 to 1608.76 nm 63 mW 9 µm 11.5 degree CW
AQ2200132 1, 1M ITLA 1527.60 to 1608.76 nm 63 mW 9 µm 11.5 degree CW
1 Class 1: EN 60825-1:2014
Class 1M: IEC 60825-1:2007, GB 7247.1-2012
2 Under single fault conditions.
Note
Laser classes differ depending on the standard number and the year of the standard.
Take safety measures according to the laser class corresponding to the standard of the country
or region that the instrument will be used in.
Safety Precautions
xIM 735101-01EN

AQ2200-111, AQ2200-141, AQ2200-142, and AQ2200-136 Modules
Laser Class 1 Label
Laser Class 1M Label
Using an optical instrument, such as a loupe,
magnifying glass, or microscope, when
observing the laser beam from a distance of
less than 100 mm may cause eye injury.
Do not expose users of binoculars or
telescopes.
Skin exposure near aperture may cause
burns.
CLASS 1 LASER PRODUCT
(IEC 60825-1:2007)
Model Class Laser Type Center Wavelength Maximum
Output Power 1
Mode Field
Diameter
Beam Divergence
(full angle at 1/e2)
Pulse Duration and
Repetition Rate
810518901 1M DFB-Laser 1310 to 1650 nm 40 mW 9 μm11.5 degree CW
810518902 1 FP-Laser 1310/1550 nm 10 mW 9 μm11.5 degree CW
810518903 1 FP-Laser 1310/1550 nm 10 mW 9 μm11.5 degree CW
810518904 1M EC-Laser 1440 to 1640 nm 50.2 mW 9 μm11.5 degree CW
1 Under single fault conditions.
Note
• Commercially available XFP transceivers installed in the AQ2200-641 XFP Interface Module
are not covered under warranty.
• For save handling of the laser, consult the user’s manual that came with the XFP
transceiver.
Safety Precautions
xi
IM 735101-01EN

Sales in Each Country or Region
Waste Electrical and Electronic Equipment
Waste Electrical and Electronic Equipment (WEEE), Directive
(This directive is valid only in the EU.)
This product complies with the WEEE directive marking requirement. This marking
indicates that you must not discard this electrical/electronic product in domestic
household waste.
Product Category
With reference to the equipment types in the WEEE directive, this product is
classified as a “Monitoring and control instruments” product.
When disposing of products in the EU, contact your local Yokogawa Europe B.V.
office. Do not dispose in domestic household waste.
EU Battery Directive
EU Battery Directive
(This directive is valid only in the EU.)
Batteries are included in this product. This marking indicates they shall be sorted
out and collected as ordained in the EU battery directive.
Battery type: Lithium battery
You cannot replace batteries by yourself. When you need to replace batteries,
contact your local Yokogawa Europe B.V. office.
Authorized Representative in the EEA
Yokogawa Europe B.V. is the authorized representative of Yokogawa Test & Measurement
Corporation for this product in the EEA. To contact Yokogawa Europe B.V., see the
separate list of worldwide contacts, PIM 113-01Z2
About Environmental Standard
This instrument complies with environmental standard EN50581, but it will not comply
with the standard if an incompliant module is installed.
For details on compliant modules, see section 5.1.
關於在台灣銷售
This section is valid only in Taiwan.
關於在台灣所販賣的符合其相關規定的電源線 A1100WD 的限用物質含量信息，請至下麵
的網址進行查詢
https://tmi.yokogawa.com/support/service-warranty-quality/product-compliance/
xii IM 735101-01EN

Symbols and Notation Used in This Manual
Notes and Cautions
The notes and cautions in this manual are categorized using the following symbols.
Improper handling or use can lead to injury to the user or damage
to the instrument. This symbol appears on the instrument to indicate
that the user must refer to the user’s manual for special instructions.
The same symbol appears in the corresponding place in the user’s
manual to identify those instructions. In the manual, the symbol is
used in conjunction with the word “WARNING” or “CAUTION.”
WARNING Calls attention to actions or conditions that could cause serious or
fatal injury to the user, and precautions that can be taken to prevent
such occurrences.
CAUTION Calls attentions to actions or conditions that could cause light injury to
the user or damage to the instrument or user’s data, and precautions
that can be taken to prevent such occurrences.
French
AVERTISSEMENT Attire l’attention sur des gestes ou des conditions
susceptibles de provoquer des blessures graves (voire
mortelles), et sur les précautions de sécurité pouvant
prévenir de tels accidents.
ATTENTION Attire l’attention sur des gestes ou des conditions
susceptibles de provoquer des blessures légères ou
d’endommager l’instrument ou les données de l’utilisateur,
et sur les précautions de sécurité susceptibles de prévenir
de tels accidents.
Note Calls attention to information that is important for proper operation of
the instrument.
Character Notations
Bold characters in procedural explanations are used to indicate panel keys and soft keys
that are used in the procedure and menu items that appear on the screen.
xiii
IM 735101-01EN

Contents
List of Manual.....................................................................................................................................i
Checking the Package Contents...................................................................................................... iii
Safety Precautions...........................................................................................................................vi
Sales in Each Country or Region.................................................................................................... xii
Symbols and Notation Used in This Manual.................................................................................. xiii
Module Model Name, Su󰀩x Code, and Accessories ..................................................................... xvi
Chapter 1 Component Names and Functions
1.1 Frame Controller .............................................................................................................. 1-1
1.2 Light Source Modules....................................................................................................... 1-5
1.3 Optical Sensor Modules ................................................................................................. 1-10
1.4 ORL Module ................................................................................................................... 1-14
1.5 Attenuator Modules ........................................................................................................ 1-15
1.6 Optical Switch Modules .................................................................................................. 1-18
1.7 BERT Module ................................................................................................................. 1-21
1.8 Optical Modulator Modules............................................................................................. 1-22
1.9 Optical Receiver Module ................................................................................................ 1-23
1.10 XFP Interface Module..................................................................................................... 1-24
1.11 Transceiver I/F Module................................................................................................... 1-25
1.12 SG Module ..................................................................................................................... 1-26
Chapter 2 Making Preparations for Measurements
2.1 Handling Precautions ....................................................................................................... 2-1
2.2 Installing the Instrument ................................................................................................... 2-3
2.3 Attaching and Removing Blank Panels ............................................................................ 2-7
2.4 Installing and Uninstalling Modules .................................................................................. 2-9
2.5 Connecting Cables ......................................................................................................... 2-12
2.6 Connecting and Disconnecting Connector Adapters...................................................... 2-21
2.7 Connecting Optical Fiber Cables.................................................................................... 2-24
2.8 Connecting to the Power Supply .................................................................................... 2-25
Chapter 3 External Input and Output
3.1 Frame Controller .............................................................................................................. 3-1
3.2 Optical Sensor Modules ................................................................................................... 3-3
3.3 BERT Module ................................................................................................................... 3-4
3.4 Optical Modulator Module ................................................................................................ 3-8
3.5 Optical Receiver Module .................................................................................................. 3-9
3.6 XFP Interface Module..................................................................................................... 3-10
3.7 Transceiver I/F Module................................................................................................... 3-12
3.8 SG Module ..................................................................................................................... 3-15
xiv IM 735101-01EN

1
2
3
4
5
Index
Alertv mark 2.5, 2.7, 2.8, 3.1, 3.3 to 3.8
Chapter 4 Troubleshooting, Maintenance, and Inspection
4.1 Troubleshooting................................................................................................................ 4-1
4.2 Error Messages ................................................................................................................ 4-6
4.3 Changing Modules ......................................................................................................... 4-16
4.4 Updating the Firmware ................................................................................................... 4-19
4.5 Routine Maintenance ..................................................................................................... 4-27
4.6 Recommended Replacement Parts ............................................................................... 4-34
4.7 Calibration ...................................................................................................................... 4-35
4.8 Disposing of the Instrument............................................................................................ 4-35
Chapter 5 Specications
5.1 AQ2211/AQ2212 Frame Controller .................................................................................. 5-1
5.2 AQ2200-111 DFB-LD Module........................................................................................... 5-4
5.3 AQ2200-112 LS Module ................................................................................................... 5-7
5.4 AQ2200-141/142 FP-LD Module...................................................................................... 5-8
5.5 AQ2200-131/132 Grid TLS Module.................................................................................. 5-9
5.6 AQ2200-136 TLS Module................................................................................................5-11
5.7 AQ2200-201 Interface Module ....................................................................................... 5-12
5.8 AQ2200-202 Interface Module ....................................................................................... 5-13
5.9 AQ2200-231/241 Optical Sensor Head.......................................................................... 5-14
5.10 AQ2200-232/242 Optical Sensor Head.......................................................................... 5-16
5.11 AQ2200-211 Sensor Module .......................................................................................... 5-18
5.12 AQ2200-215 Sensor Module.......................................................................................... 5-20
5.13 AQ2200-221 Sensor Module.......................................................................................... 5-22
5.14 AQ2200-271 ORL Module .............................................................................................. 5-24
5.15 AQ2200-311 ATTN Module............................................................................................. 5-25
5.16 AQ2200-311A/312 ATTN Module ................................................................................... 5-26
5.17 AQ2200-331/332 ATTN Module ..................................................................................... 5-27
5.18 AQ2200-342 DUAL ATTN Module.................................................................................. 5-28
5.19 AQ2200-411/412 OSW Module...................................................................................... 5-29
5.20 AQ2200-421 OSW Module............................................................................................. 5-30
5.21 AQ2200-601 10 Gbit/s BERT Module ............................................................................ 5-31
5.22 AQ2200-621/622 10 Gbit/s Optical Modulator ............................................................... 5-34
5.23 AQ2200-631 10 Gbit/s Optical Receiver ........................................................................ 5-35
5.24 AQ2200-641 XFP Interface Module ............................................................................... 5-36
5.25 AQ2200-642 Transceiver I/F Module ............................................................................. 5-37
5.26 AQ2200-651 SG Module................................................................................................ 5-39
5.27 External Dimensions ...................................................................................................... 5-40
Index
Contents
xv
IM 735101-01EN

Module Model Name, Suffix Code, and Accessories
AQ2200-111 DFB-LD Module
Model Suffix Code Description
810518901 —
Wavelength -Mxxxx See section 5.2 for the list of supported
wavelengths
-W1310 1310 nm
-W1490 1490 nm
Optical connector -FCA FC/Angled PC connector
Optical output level -P10 10 mW optical output
-P20 20 mW optical output
Optical fiber -SMF SM fiber
-PMF PM fiber
External modulation -MODN No external modulation
-MODS External modulation (sine)
-MODC External modulation (chop)
Standard Accessories
The standard accessories below are supplied with the instrument.
Item Model or Part No. Quantity Notes
Protective cap* — 1 Green
Protective cap* — 1 White (for use with the external
modulation option)
User’s manual IM 810518901-04E 1 Read before using the instrument
*: Already attached to the module
AQ2200-112 LS Module (Firmware version 3.08 and later)
Model Suffix Code Description
AQ2200112 —
Wavelength -D300 DFB-LD, 1310 nm
-D500 DFB-LD, 1550 nm
-D600 DFB-LD, 1625 nm
-D700 DFB-LD, 1650 nm
-D3D3 DFB-LD, Ch1: 1310 nm, Ch2: 1310 nm
-D3D5 DFB-LD, Ch1: 1310 nm, Ch2: 1550 nm
-D3D6 DFB-LD, Ch1: 1310 nm, Ch2: 1625 nm
-D3D7 DFB-LD, Ch1: 1310 nm, Ch2: 1650 nm
-D5D5 DFB-LD, Ch1: 1550 nm, Ch2: 1550 nm
-D5D6 DFB-LD, Ch1: 1550 nm, Ch2: 1625 nm
-D5D7 DFB-LD, Ch1: 1550 nm, Ch2: 1650 nm
-D6D6 DFB-LD, Ch1: 1625 nm, Ch2: 1625 nm
-D6D7 DFB-LD, Ch1: 1625 nm, Ch2: 1650 nm
-D7D7 DFB-LD, Ch1: 1650 nm, Ch2: 1650 nm
Standard Accessories
The standard accessories below are supplied with the instrument.
Item Model or Part No. Quantity Notes
Protective cap* — 1 1-channel model (-D300, -D500,
-D600, -D700)
2 2-channel model (-D3D3, -D3D5,
-D3D6, -D3D7, -D5D5, -D5D6,
-D5D7, -D6D6, -D6D7, -D7D7)
User’s manual IM 810518901-04E 1 Read before using the instrument
*: Already attached to the module
xvi IM 735101-01EN

AQ2200-141 FP-LD Module
Model Suffix Code Description
810518902 —
Wavelength -W1310 1310 nm
-W1550 1550 nm
Optical connector /FCC AQ9441 (FC) universal adapter
/SCC AQ9441 (SC) universal adapter
Standard Accessories
The standard accessories below are supplied with the instrument.
Item Model or Part No. Quantity Notes
Protective cap* — 1
User’s manual IM 810518901-04E 1 Read before using the instrument
*: Already attached to the module
Optional Accessories
The optional accessories below are available for purchase separately.
Item Model Notes
AQ9441 (FC) universal adapter 813917321-FCC FC connector
AQ9441 (SC) universal adapter 813917321-SCC SC connector
AQ2200-142 DUAL FP-LD Module
Model Suffix Code Description
810518903 —
Wavelength -W135D 1310/1550 nm
Optical connector /FCC AQ9441 (FC) universal adapter
/SCC AQ9441 (SC) universal adapter
Standard Accessories
The standard accessories below are supplied with the instrument.
Item Model or Part No. Quantity Notes
Protective cap* — 1
User’s manual IM 810518901-04E 1 Read before using the instrument
*: Already attached to the module
Optional Accessories
The optional accessories below are available for purchase separately.
Item Model Notes
AQ9441 (FC) universal adapter 813917321-FCC FC connector
AQ9441 (SC) universal adapter 813917321-SCC SC connector
Module Model Name, Suffix Code, and Accessories
xvii
IM 735101-01EN

AQ2200-131 Grid TLS Module (-T2 and -T4:Firmware version 3.00 and later)
(-T6:Firmware version 3.05 and later)
Model Suffix Code Description
AQ2200131 —
Wavelength -C C-band
-L L-band
LD type -T4 Standard type
-T2 Advanced type (Fine tuning)
-T6 Advanced type (Fine tuning)
Optical fiber -PA PM fiber
Optical connector -FCC FC/PC connector
-FCA FC/Angled PC connector
Standard Accessories
The standard accessories below are supplied with the instrument.
Item Model or Part No. Quantity Notes
Protective cap* — 1
User’s manual IM 810518901-04E 1 Read before using the instrument
*: Already attached to the module
AQ2200-132 Grid TLS Module (-T2 and -T4:Firmware version 3.00 and later)
(-T6:Firmware version 3.05 and later)
Model Suffix Code Description
AQ2200132 —
Wavelength -CC CH1: C-band, CH2: C-band
-LL CH1: L-band, CH2: L-band
-CL CH1: C-band, CH2: L-band
LD type -T4 Standard type
-T2 Advanced type (Fine tuning)
-T6 Advanced type (Fine tuning)
Optical fiber -PA PM fiber
Optical connector -FCC FC/PC connector
-FCA FC/Angled PC connector
Standard Accessories
The standard accessories below are supplied with the instrument.
Item Model or Part No. Quantity Notes
Protective cap* — 1
User’s manual IM 810518901-04E 1 Read before using the instrument
*: Already attached to the module
AQ2200-136 TLS Module
Model Suffix Code Description
810518904 —
Optical connector -FCA FC/Angled PC connector
Optical fiber -SMF SM fiber
Wavelength -WLSTD Changeable
Standard Accessories
The standard accessories below are supplied with the instrument.
Item Model or Part No. Quantity Notes
Protective cap (small)* — 2 Green
Protective cap (large)* — 1
User’s manual IM 810518901-04E 1 Read before using the instrument
*: Already attached to the module
Module Model Name, Suffix Code, and Accessories
xviii IM 735101-01EN
