Yukon 58832 Assembly instructions
Visit our website at: http://www.harborfreight.com
58832
60" 3 DRAWER
WOOD WORKBENCH
Owner’s Manual & Safety Instructions
Save This Manual Keep this manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the
back of the manual (or month and year of purchase if product has no number). Keep this manual and the
receipt in a safe and dry place for future reference. 23c
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
Copyright©2022 by Harbor Freight Tools®. All rights reserved.
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
Page 2 For technical questions, please call 1-888-866-5797. Item 58832
SAFETY OPERATION MAINTENANCESETUP
Table of Contents
Important Safety Information ...................... 3
Specifications ............................................. 4
Assembly Instructions................................. 5
Parts List and Diagram.............................. 10
Warranty .................................................... 12
WARNING SYMBOLS AND DEFINITIONS
This is the safety alert symbol. It is used to alert you to potential
personal injury hazards. Obey all safety messages that
follow this symbol to avoid possible injury or death.
Indicates a hazardous situation which, if not avoided,
will result in death or serious injury.
Indicates a hazardous situation which, if not avoided,
could result in death or serious injury.
Indicates a hazardous situation which, if not avoided,
could result in minor or moderate injury.
Addresses practices not related to personal injury.
Page 3For technical questions, please call 1-888-866-5797.Item 58832
SAFETYOPERATIONMAINTENANCE SETUP
IMPORTANT SAFETY INFORMATION
Read all safety warnings and instructions.
Failure to follow the warnings and instructions may result in serious injury.
Save all warnings and instructions for future reference.
1. Do not exceed weight capacity for the
Workbench. Be aware of dynamic loading!
Sudden load movement may briefly create
excess load causing product failure.
2. Use only on flat, level and hard surface
capable of supporting the Workbench and
any item(s) placed on Workbench. Evenly
distribute load on Table to avoid tipping.
3. Use as intended only. Do not use Workbench to
perform task for which it was not designed.
4. For indoor use only.
5. Assemble only according to these instructions.
Improper assembly can create hazards.
6. Wear ANSI-approved safety goggles and heavy-
duty work gloves during assembly and use.
7. Keep assembly area clean and well lit.
8. Keep bystanders out of the area during assembly.
9. Do not assemble when tired or when under
the influence of drugs or medication.
10. This product is not a toy. Do not allow children
to play with, on or near Workbench.
11. Inspect before every use; do not use
if parts are loose or damaged.
12. Maintain product labels and nameplates.
These carry important safety information.
If unreadable or missing, contact
Harbor Freight Tools for a replacement.
SAVE THESE INSTRUCTIONS.
Page 4 For technical questions, please call 1-888-866-5797. Item 58832
SAFETY OPERATION MAINTENANCESETUP
Specifications
Total Combined Weight Capacity 600 lb.
Vise Capacity 7-1/4"
Table Top Thickness 2-1/2"
Assembly Video
Scan code using your phone.
https://hf.tools/yukon3drawer/
Page 5For technical questions, please call 1-888-866-5797.Item 58832
SAFETYOPERATIONMAINTENANCE SETUP
Assembly Instructions
Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this
manual including all text under subheadings therein before set up or use of this product.
Note: For additional information regarding the parts listed in the following
pages, refer to Parts List and Diagram on page 10.
Note: More than one person is needed for proper assembly.
Note: Additional tools for assembly not included .
1. Insert Connecting Nuts (17) into holes at ends of a
Cross Brace (5). Make sure that the slots on the
Nuts align horizontally. This will allow the Bolts to be
threaded into the Cross Brace in the next step.
Connecting
Nuts (17) Leg
(1)
Cross Brace (5)
2. Set the Cross Brace against Leg (1) and use the
Hex Key (18) and 6 x 90 mm Connecting Bolts (16)
to fasten the Cross Brace and Leg together.
Cross
Brace (5))
Leg
(1)
Hex
Key (18)
Bolt (16)
NOTE: Make sure the groove in the
Cross Brace is facing IN.
3. Repeat step 2 for the second Leg (3).
Cross
Brace (5) Leg (1)
Leg (3)
4. Once Legs (1,3) have been fastened to
the Cross Brace, slide the Bottom Shelf (6)
between the Legs so that the far edge
fits onto the groove on the Cross Brace.
Leg (1,3)
Bottom
Shelf (6)
Cross
Brace (5a)
5. Set the Second Cross Brace (5) against
the other edge of the Bottom Shelf.
Second Cross Brace (5b)
Bottom Shelf (6)
6. Once the Second Cross Brace is in
place use the Hex Key and Connecting
Bolts to fasten to Legs (1,3).
Cross Brace (5)
Bottom Shelf (6)
Leg (1)
Leg (3)
Page 6 For technical questions, please call 1-888-866-5797. Item 58832
SAFETY OPERATION MAINTENANCESETUP
7. With assistance, place the Table Top (2) face
down on a smooth, padded surface. This will
allow installation of the sliding drawers.
8. Set the Sliding Partition (8) into place by inserting
the tabs at the end of the Partition into the holes
at the center of the Table Top’s underside.
Sliding Partition (8)
Table Top (2)
Note: Verify that the Sliding Partition and
Table Top face the same direction.
Sliding Partition (8)
Table Top (2)
Front
9. Use 4 x 30 mm Wood Screws (24)
to fasten the Sliding Partition to the
middle of the Table Top’s underside.
Sliding Partition (8)
Table Top (2)
10. With assistance, set the assembled Legs and
Bottom Shelf onto the underside of the Table Top.
Note: When setting the assembled Legs onto
the Table Top, verify both Legs and Table
Top are facing the correct direction.
Note: Verify that the Drawer guide slots on
the Sliding Partition face the same way as
the Drawer guide slots on the Legs.
Leg (1,3)
Table Top (2)
11. Use the Hex Key and 6 x 50 mm Wood
Screws (15) to fasten the Legs to the Table
Top underside, using three Screws per side.
Legs (1,3)
Screw (15)Table Top (2)
12. Fasten Sliding Partition to the Table Top frame
using four 4 x 25 Wood Screws (22).
Screw (22)
Leg(1,3)
Screw (22)
Page 7For technical questions, please call 1-888-866-5797.Item 58832
SAFETYOPERATIONMAINTENANCE SETUP
13. Attach the Middle Cross Brace (7) above
Sliding Partition and fasten it to both
Legs (1.3) using Wood Screws (22).
Legs (1,3)
Middle Cross Brace (7)
Screw
(22)
Table
Top (2)
14. With assistance, set the assembled
frame right-side up where desired.
15. Remove the Vise Screw/Washer (21) from
the middle threaded rod of the Vise (4).
Vise (4)
Vise
Screw/Washer
(21)
Note: Install Vise with slots facing up.
16. With the Vise Screw/Washer removed, slide the Vise
into the three holes on the side of the Workbench.
Table Top
(2)
17. Use the Vise handle to thread the Vise
in all the way and install the Vise Screw/
Washer (21). This will keep the Vise locked
in place on the side of the Workbench.
Vise Screw/Washer (21)
Note: Each Drawer piece should have a sticker
designating what it is. Use the Parts List as a
reference to help ensure correct assembly.
18. Fasten a Left Drawer Slot Panel (11) and a Right
Drawer Slot Panel (12) to a Drawer Front Panel (9).
Small
Drawer
Front
Panel (9)
Wood
Screw
(22) Left Drawer
Slot Panel
(11)
Right Drawer
Slot Panel
(12)
19. Fasten Drawer Back Panel (10) to the
ends of the two Slot Panels.
Left Drawer Slot Panel
(11)
Screw (22)
Small Drawer
Back Panel
(10)
Right Drawer
Slot Panel
(12)
20. With the felt side up, slide Drawer Bottom (13)
into the grooves along the insides of the
assembled Left and Right Drawer Slot Panels
from the previous step, then fasten Drawer
Bottom to Drawer Back Panel with Screws (22).
Small Drawer
Bottom (13)
Small Drawer
Bottom (13)
Screw (22)
Small Drawer
Back Panel
(10)
Page 8 For technical questions, please call 1-888-866-5797. Item 58832
SAFETY OPERATION MAINTENANCESETUP
21. Use the Bolts (23) to fasten the Drawer Handles (14)
to the Drawer Front Panels (9).
Drawer Handle (14)
Small Drawer
Front
Panel (9) Bolt (23)
22. Repeat steps 17-20 to assemble second top drawer.
23. Place Left Drawer Slot panel (11) onto Large Drawer
Front Panel (27) and Secure with Screws (22).
24. Place Right Drawer Slot panel (12)
onto Large Drawer Front Panel (27)
and Secure with Screws (22).
Large Drawer Front Panel (27)
Left Drawer
Slot Panel (11)
Right Drawer
Slot Panel (12)
Screw (22)
25. Place Large Drawer Back Panel onto Left and
Right Slot Panels and secure with Screws (22).
Large Drawer Back Panel (26)
Screw (22)
Note: Use Screws (22) to fasten Drawer
Bottom (25) to Drawer Front Panel (27).
Screw (22)
Drawer Bottom (25)
Drawer Front Panel (27)
26. Repeat step 20 to install Handle (14)
onto Large Drawer Front Panel.
27. Once Drawers are fully assembled, verify
that the inside tracks along the legs and
Sliding Partition are pushed forward.
28. Insert the drawer horizontally along the inside
tracks, sliding the drawer back and forth
until the drawer is completely pushed in.
Drawer Front
Panel (9)
29. Once all Drawers are inserted, tap Wood
Pegs (19) and Anvil Pegs (20) into
desired holes on the Table Top.
Wood Pegs (19)
Anvil Pegs (20)
Table Top (2)
30. The Workbench is now fully
assembled and ready for use.
Page 9For technical questions, please call 1-888-866-5797.Item 58832
SAFETYMAINTENANCE SETUPOPERATION
Operation Instructions
1. Place Anvil Pegs (20) into Vise (4) slots and Table
Top (2) slots to firmly hold work piece into position.
Anvil Pegs can be used with Wood Pegs (19).
Wood piece
Wood Pegs
(19)
Anvil Pegs
(20)
2. Place Wood Pegs into Vise slots and Table
Top slots to firmly hold work piece into position.
Wood Pegs can be used with Anvil Pegs.
Wood Pegs (19)
Page 10 For technical questions, please call 1-888-866-5797. Item 58832
SAFETY OPERATION MAINTENANCESETUP
Part Description Qty
1 Left Leg 1
2Table Top 1
3 Right Leg 1
4 Vise 1
5a Cross Brace 1
5b Second Cross Brace 1
6 Bottom Shelf 1
7 Middle Cross Brace 1
8 Sliding Partition 1
9 Drawer Front Panel 3
10 Drawer Back Panel 3
11 Left Drawer Slot Panel 3
12 Right Drawer Slot Panel 3
13 Small Drawer Bottom 2
14 Drawer Handle 3
Part Description Qty
15 6 x 60 mm Wood Screw 6
16 6 x 90 mm Connecting Bolt 8
17 Connecting Nut 8
18 Hex Key 1
19 Wood Peg 4
20 Anvil Peg 4
21 Vise Screw / Washer 1
22 3.5 x 25 mm Wood Screw 62
23 4 x 30 mm Drawer Bolt 6
24 4 x 30 mm Wood Screw 6
25 Large Drawer Bottom 1
26 Large Drawer Back Panel 1
27 Large Drawer Front Panel 1
Maintenance and Servicing
Procedures not specifically explained in this manual must
be performed only by a qualified technician.
TO PREVENT SERIOUS INJURY FROM TOOL FAILURE:
Do not use damaged equipment. If abnormal noise or vibration
occurs, have the problem corrected before further use.
Cleaning, Maintenance, and Lubrication
1. BEFORE EACH USE, inspect the general condition of the Workbench. Check for:
• loose hardware
• misalignment or binding of parts
• cracked or broken parts
• any other condition that may affect its safe operation.
2. AFTER USE, wipe external surfaces of the Workbench with clean cloth.
Parts List and Diagram
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM
IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR
MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS
QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE
ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY
STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND
LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY
ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS
THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
Parts List
Note: A few pieces of extra hardware may be included.
Page 11For technical questions, please call 1-888-866-5797.Item 58832
SAFETYMAINTENANCE SETUPOPERATION
Assembly Diagram
1
2
3
4
5
5
6
7
8
9
27
9
10
26
10
11
11
11
12
25
12
12
13
13
14
14
15
16
17
18
19
20
21
22
23
24
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only, and are not available
individually as replacement parts. Specify UPC 193175504258 when ordering parts.
Limited 90 Day Warranty
Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards,
and warrants to the original purchaser that this product is free from defects in materials and workmanship for the
period of 90 days from the date of purchase. This warranty does not apply to damage due directly or indirectly,
to misuse, abuse, negligence or accidents, repairs or alterations outside our facilities, criminal activity, improper
installation, normal wear and tear, or to lack of maintenance. We shall in no event be liable for death, injuries
to persons or property, or for incidental, contingent, special or consequential damages arising from the use of
our product. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the
above limitation of exclusion may not apply to you. THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS.
To take advantage of this warranty, the product or part must be returned to us with transportation charges
prepaid. Proof of purchase date and an explanation of the complaint must accompany the merchandise.
If our inspection verifies the defect, we will either repair or replace the product at our election or we may
elect to refund the purchase price if we cannot readily and quickly provide you with a replacement. We will
return repaired products at our expense, but if we determine there is no defect, or that the defect resulted
from causes not within the scope of our warranty, then you must bear the cost of returning the product.
This warranty gives you specific legal rights and you may also have other rights which vary from state to state.
26677 Agoura Road • Calabasas, CA 91302 • 1-888-866-5797
Other manuals for 58832
1
Table of contents
Other Yukon Tools Storage manuals
