Zanussi ZHPTH1 Operator's manual

ZHPTH1 Hanging Heater Manual &
Safety Instructions
WARNING: PLEASE ENSURE YOU HAVE READ THROUGH THE
SAFETY AND OPERATING INSTRUCTIONS BEFORE USE.
PLEASE RETAIN INSTRUCTIONS FOR FUTURE REFERENCE
For Customer Services & Spare Parts please call 0330 1230 597
Or visit us at zanussiheatingandcooling.uk
Please scan the QR code for step by step video
assembly instructions. Alternatively, you can visit:
zanussiheatingandcooling.uk. From here, please select
the product that you are looking to build and view the
‘How To’ video located at the bottom of the page.

Safety Instructions
3-8
Parts List & Feature Diagram
9
Installation Instructions
10-14
Operating Instructions
15-17
Maintenance & Care Instructions
18
Troubleshooting
18
Specification
19
Guarantee and Customer Services
20
Notes
21-23
PATIO HEATER
2Revision 1.2

SAFETY INSTRUCTIONS
WARNING: IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
Before you start to build and use your patio heater, please
read these instructions thoroughly:
•Please dispose of all plastic bags carefully and keep them
away from children.
•Check all the parts provided against the list in this
instruction manual to make sure you have all of the parts
listed. If not, contact your customer services.
•Take a few moments to familiarize yourself with the
contents and before starting, check all holes are clear of
any paint residue.
•Extra packaging is added to some models for
transportation protection which must be removed before
assembly.
•When you are ready to start, make sure that you have
plenty of space and a clean dry area for assembly.
•Using the steps in order and the detailed drawings in the
steps to assemble the outdoor heater.
•Important - Whilst every care is taken in the manufacture
of this product, care must be taken during assembly in
case sharp edges are present.
Please read and follow this advice when assembling your
appliance:
•DO NOT connect the outdoor heater to the electrical
supply until the assembly is complete.
•DO NOT connect the outdoor heater to the electrical
supply if any of the components or power cord is
damaged in any way.
3Revision 1.2

SAFETY INSTRUCTIONS
•CAUTION - Risk of Electric Shock. DO NOT open or try
to repair the heater yourself.
•Please do not use substitute parts. Use only additional
or replacement parts supplied by Zanussi.
•In the unlikely event that this product has missing or
damaged parts, please visit our website
zanussiheatingandcooling.uk
Safety Warnings:
•Warning: This heater is not equipped with a device to
control the room temperature.
•DO NOT use this heater indoors or in small/confined
spaces that are occupied by persons not capable of
leaving on their own, unless constant supervision is
provided.
•Children of less than 3 years should be kept away
unless continuously supervised.
•Children under 8 years shall not plug in, regulate and
clean the appliance or perform user maintenance.
•This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities or lack of experience and
knowledge of how to use the appliance in a safe way or
do not understand the hazards involved.
•Children should not play with the appliance.
•Cleaning and user maintenance should not be made by
children without supervision.
4
WARNING: IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
Revision 1.2

•Do not use any other tools other than those
recommended to build this product.
•Caution: Some parts of this product can become very
hot and cause burns. Particular attention must be given
where children, vulnerable people and animals are
present.
•Risk of Electric Shock. DO NOT open or try to repair the
heater yourself.
•Any maintenance or repairs including replacing the
tube(s) should only be carried out by a qualified
electrician or by a qualified service centre.
•Site the heater outside or in a large open area and well
away from any obstructions such as branches or where
the heater is near any objects that can be affected by
heat, such as furniture, curtains or other inflammable
objects (minimum distance 1 metre).
•DO NOT use this heater in the immediate surroundings
of a bath, a shower or a swimming pool. Do not use
near water.
•DO NOT use in unventilated areas.
•DO NOT use where gas, petrol, paint or other surely
flammable goods are stored.
•DO NOT push any items through, obstruct or cover the
grill of the heater head.
•DO NOT position immediately above or below an
electrical socket.
•DO NOT move when connected to an electrical supply
and always wait for the patio heater to cool down
before cleaning / storing away.
5Revision 1.2

•DO NOT touch the heater head when in use.
•DO NOT leave turned on and unattended especially
when children and or animals are in the vicinity.
•The indication of the different positions of switches
shall be visible from a distance of 1M.
•The marking concerning covering should be visible after
the heater has been installed. It shall not be placed on
the back of portable heaters
•The unit must be placed with the clearance of 25cm
from side wall and 50cm from anything above.
•The unit must be correctly installed according to the
instructions.
•The unit is at high temperature during operation. It
keeps hot for a period after shut down. Potential danger
would occur when touching it during this period. Unplug
the unit and wait till it cools before cleaning.
•DO NOT place the unit close to curtain and/or other
flammable objects. Otherwise there will be a danger of
catching fire.
•DO NOT cover the unit with anything during operation or
a short time after it is shut down.
•DO NOT wrap the power supply cord on the unit.
•The unit must be handled with care, and avoid vibration
or hitting.
•An apparatus with CLASS I construction shall be
connected to a MAINS socket outlet with a protective
earthing connection.
•DO NOT use if the unit or power cable is damaged.
6Revision 1.2

•DO NOT attempt to repair or adjust any electrical or
mechanical functions on this unit. Doing so will void
your warranty. The inside of the unit contains no user
serviceable parts. Servicing / Repair should only be
performed by a qualified electrician or qualified service
centre.
•DO NOT use this unit in place where causticity or
volatile air exists, i.e. dust, steam, gas, etc.
•DO NOT use this unit as a cloth drier or towel drier.
•DO NOT use this unit as a sauna heater.
•DO NOT use this unit as a room heater.
•DO NOT use this unit in place of animal propagating
and raising.
•DO NOT immerse this unit into water for cleaning.
•The unit should be plugged in a socket, which is easily
visible and reachable.
•DO NOT use this heater with a programmer, timer or
any other device that switches the heater on
automatically, since a fire risk exists if the heater is
covered or positioned incorrectly.
•Children should be supervised to ensure that they do
not play with the appliance.
•When assembling, keep clear from any board or
flammable material.
•DO NOT insert or allow foreign objects to enter any
ventilation or exhaust opening as this may cause an
electric shock or fire, or damage the heater.
•The unit is for household use only. It is not safe to use
on a building site, greenhouse, barn or stable where
there’s flammable dust.
7Revision 1.2

•Use only for intended household use as described in
this manual. Any other use not recommended by the
manufacturer may cause fire, electric shock, or injury to
persons. The use of attachments not recommended or
sold by unauthorized dealers may cause hazards.
•Avoid the use of an extension cord because the
extension cord may overheat and cause a risk of fire.
However, if you must use an extension cord, the cord
shall be rated to 13A (Minimum conductor size
1.5mm2) and if the cord is on a reel it must be fully
unwound before use.
•Disconnect the power cable from the electrical supply
when the heater is not in use. If the power cord
becomes damaged, it must be replaced by a qualified
electrician.
•One dark point may exist on the surface of the heating
elements during the first few minutes after it is turned
on. This is normal, and will not affect the performance
of the unit.
•To avoid fire or shock hazard, plug the unit directly into
a 220-240V and 13A electrical socket outlet
•WARNING! These appliances must be earthed. Before
installing or replacing the bulb, the appliance must be
disconnected from the 220-240V mains supply.
8Revision 1.2

WHAT’S INCLUDED?
Here’s everything you need
9
1
4
1. Wire rope
2. Power cord
3. Heater cover
4. Safety net
5. LED light
6. Power switch
7. Power touch control
8. Remote control
3
2
5
6
7
8
Revision 1.2

INSTALLATION INSTRUCTIONS
•Place the heater on a firm, level ceiling surface.
•Installation of the heater must be to a strong rigid
support (such as strong wooden beam, metal rail,
etc.).
•The hook on the ceiling hanging the patio heater
must be able to take a weight 3 or 4 times that of the
heater itself.
•The patio heater must be installed on a firm, level
ceiling surface or on a strong rigid support (such as
strong wooden beams or metal rails etc).
•Only operate the patio heater when it is in the upright
position.
Minimum Required Distances:
•25cm from the side wall/any objects
•50cm from the ceiling
•There must be over 180cm from the bottom of
the patio heater to the floor
10 Revision 1.2

INSTALLATION INSTRUCTIONS
STEP 1
•Pull the wire and power cord upwards, and then
adjust the length of the wire to the appropriate height
(please check the minimum required distances on
the previous page).
•To adjust the height of the wire please see the next
step.
11 Revision 1.2

INSTALLATION INSTRUCTIONS
STEP 2
•Pull the metal toggle and the wire through the
bracket to reduce the length of the wire. To increase
the length, then press the release valve and pull the
wire through the bracket in the opposite direction.
•If required, the clip can be removed; this can be done
by unlocking the nut and removing the clip from the
bracket.
12
Clip
Metal toggle
Bracket
Nut
Release valve
Revision 1.2

INSTALLATION INSTRUCTIONS
STEP 3
•Unscrew the nut in the direction of the arrow.
•Then place the clip onto the required hook
that has been installed in your ceiling.
13 Revision 1.2

INSTALLATION INSTRUCTIONS
STEP 4
•Tighten the nut in the direction of the arrow to
secure your patio heater.
Note:
•The heater must be installed to a strong rigid
support (such as strong wooden beam, metal
rail, etc.).
•The hook on the ceiling hanging the patio
heater must be able to take a weight 3 or 4
times that of the heater itself.
14 Revision 1.2

OPERATING INSTRUCTIONS
•Connect the power cable to a 220-240V, 13 amp supply that
is located in a safe, dry area.
•The heater must be properly installed before it is used.
•Only operate the heater when it is in the upright position.
•This unit is equipped with three heat settings.
•Push the On/Off switch to the "I" position to activate the
heater; this is inside the hollow section in the centre of the
heater.
•Touch the touch switch once, the heater will be set to
1000W power.
•Touch the touch switch twice, the heater will be set to
1500W power.
•Touch the touch switch three times, the heater will be set to
2500W power.
•Touch the touch switch four times, the heater will be set to
2500W power and the LED light will be turned on.
•Touch the touch switch five times, the heater will be on
standby and just the LED light will be turned on.
•Touch the touch switch six times, the LED light will be turned
off.
•To completely turn off the patio heater, push the On/Off
switch to the “O" position.
15
Touch
Switch On/Off
Switch
Revision 1.2

OPERATING INSTRUCTIONS
Remote Control
•The patio heater comes with a button cell CR2450 battery
provided in the same plastic wallet as the instruction manual.
•To use the remote for the first time, remove the battery cover
at the back of the remote, and insert the battery with the
positive side facing up, and replace the battery cover.
•Push the On/Off switch to the "I" position to activate the
heater before using the remote.
•Press the LOW button to operate the heater on 1000W. Press
the LOW button again to turn it off.
•Press the HIGH button to operate the heater on 1500W. Press
the HIGH button again to turn it off.
•Press both the LOW and HIGH buttons to operate the heater
on 2500W. Press both the LOW and HIGH buttons again to
turn off the heater.
•To turn the LED light on, press the “Light” button on the
remote control. Press again to turn off.
Replacing the Battery
•To replace the battery follow the steps below:
1. Remove the battery cover at the back of the remote.
2. Use a flathead screwdriver to lift the battery up and out
of the remote.
3. Replace the button cell CR2450 battery and then
reinstall the battery cover onto the remote.
16
Low
Button
High
Button
Light Button
Revision 1.2

OPERATING INSTRUCTIONS
•WARNING: Chemical Burn Hazard –Keep batteries away
from children.
•This product contains a lithium button/coin cell battery. If a
new or used lithium button/cell battery is swallowed or
enters the body, it can cause severe internal burns and can
lead to death in as little as 2 hours. Always make sure you
completely secure the battery compartment. If the battery
compartment does not close securely, stop using the
product, remove the battery and keep it away from children.
If you think the battery might have been swallowed or placed
inside any part of the body, seek immediate medical
attention.
•The cells should be disposed of correctly, including keeping
them away from children, even used cells may cause injury.
•WARNING: Although the patio heater is shower proof, do not
use when raining or in wet conditions.
•WARNING: Always disconnect the power cable from the
electrical supply when the patio heater is not in use.
17 Revision 1.2

•Unplug the unit and let it cool completely.
•When disconnected from the electrical supply, clean
the outside of the patio heater with a damp cloth.
Never use corrosive or solvent cleaners or immerse
in water.
•Any maintenance or repairs including replacing the
halogen tube should only be carried out by a
qualified electrician or by a qualified service centre.
Storage
•If the heater will not be used for a long period of
time, store it in a cool, dry location when not in use.
To prevent dust and dirt build-up, use the original
packaging to repack the unit
MAINTAINANCE & CARE INSTRUCTIONS
WARNING: Ensure the appliance is cold before storing.
18
PROBLEM
POSSIBLE CAUSE/SOLUTION
Heater will not
operate
•
Check if the power cord is plugged
into an electrical outlet, if not plug in
•
Check if electricity to the main fuse
is working.
•Make certain the power switches are
turned on. If not, choose a setting
•
Try another mains socket.
TROUBLESHOOTING
If the heater will not operate, please check the following
before seeking repair of service:
Revision 1.2

SPECIFICATION
19
Power supply: 220-240V, 50-60Hz
Wattage: 2500W (max)
Insulation class: I
IP rating IP45
Dimensions (CMs) 10(H) x 61(W) x 61(D)
Revision 1.2

This product is guaranteed for 12 months from the
date of the original purchase. If any defect arises due
to faulty materials or workmanship, the faulty product
must be returned to the place of purchase.
Refund or replacement is at the discretion of the
retailer.
The following conditions apply:
•The product must be returned to the retailer with
the original proof of purchase.
•The product must be installed and used in
accordance with the instructions contained in this
instruction guide and any other instructions for use
which are supplied.
•It must be used for domestic purposes only and for
its intended use.
•This guarantee does not cover wear and tear,
damage, misuse or consumable parts.
This does not affect your statutory rights.
For Customer Services & Spare Parts please call:
0330 1230 597
Or visit us at zanussiheatingandcooling.uk
GUARANTEE AND CUSTOMER SERVICES
20 Revision 1.2
