ZENEC Z-E2050 User manual

Z-E2050
INFOTAINER
USER MANUAL
EN

2 Rev.B
SAFETY INSTRUCTIONS ..................................................................................................................04
TURN DEVICE ON AND OFF ............................................................................................................05
ANTI-THEFT PROTECTION...............................................................................................................05
MULTIFUNCTION STEERING WHEEL CONTROLS........................................................................06
Z-E2050 (FRONT PANEL) ..................................................................................................................07
MAIN MENU STRUCTURE ....................................................................................................................08
MAIN MENU ICONS................................................................................................................................09
MEDIA AUDIO SOURCES .................................................................................................................10
INPUT SOURCES................................................................................................................................ 11
STATUS BAR.......................................................................................................................................12
SEARCH AND INPUT FUNCTION ..................................................................................................... 13
FM RADIO ........................................................................................................................................... 14
FM BAR GRAPH MODE ..................................................................................................................... 15
MANUAL FM STATION SEARCH ......................................................................................................16
UKW STATION PRESET .................................................................................................................... 17
FM SETUP ........................................................................................................................................... 18
DAB+ RADIO SETUP ...................................................................................................................... ...19
DAB+ ENSEMBLE AND STATION LIST...........................................................................................20
DAB+ SETUP ......................................................................................................................................21
DAB+ STATION-PRESETS ................................................................................................................22
USB / BT A2DP / IPOD / DVD / SD (AUDIO) MEDIA ........................................................................23
USB / BT A2DP / IPOD / DVD / SD (AUDIO) MEDIA CONTROL AND OPERATION BAR.............24
BT-MUSIC (A2DP) .............................................................................................................................25
iPOD (AUDIO) .....................................................................................................................................26
PLAYLIST (AUDIO) ............................................................................................................................27
VIDEO MEDIA: HARDDISK ...............................................................................................................28
PLAYLIST (VIDEO).............................................................................................................................29
HDMI / AV/IN........................................................................................................................................30
CAMERA .............................................................................................................................................31
SMARTLINK DIRECT .........................................................................................................................32
SMARTLINK DIRECT CONTROL INTERFACE ................................................................................33
SMARTLINK DIRECT CONTROL BAR ICONS.................................................................................34
SMARTPHONE APP LINKING...........................................................................................................35
CONTENTS
Device user manual for ZENEC media system
We are delighted that you have chosen a product from ZENEC.
Please read this operating manual before you start your new ZENEC system. In this device user
manual you will find important instructions and information for the safe operation of the ZENEC
system, and to help you make the most of its technical advantages.
All the information in this manual corresponds to the state at the time of going to press, and applies
only to ZENEC systems in original condition. On account of possible updates to device software, the
illustrations and features shown in this operating manual may be different from your ZENEC system.
Differences in the information, illustrations or features cannot form a basis for any claims.
If you sell your vehicle with the ZENEC system still fitted, please ensure that this operating manual
stays with the vehicle, and that any personal data like a phonebook stored in the device is deleted.

3 Rev.B
SAFETY INSTRUCTIONS ..................................................................................................................04
TURN DEVICE ON AND OFF ............................................................................................................05
ANTI-THEFT PROTECTION...............................................................................................................05
MULTIFUNCTION STEERING WHEEL CONTROLS ........................................................................06
Z-E2050 (FRONT PANEL) ..................................................................................................................07
MAIN MENU STRUCTURE ....................................................................................................................08
MAIN MENU ICONS................................................................................................................................09
MEDIA AUDIO SOURCES .................................................................................................................10
INPUT SOURCES................................................................................................................................ 11
STATUS BAR.......................................................................................................................................12
SEARCH AND INPUT FUNCTION ..................................................................................................... 13
FM RADIO ........................................................................................................................................... 14
FM BAR GRAPH MODE ..................................................................................................................... 15
MANUAL FM STATION SEARCH ......................................................................................................16
UKW STATION PRESET .................................................................................................................... 17
FM SETUP ........................................................................................................................................... 18
DAB+ RADIO SETUP ...................................................................................................................... ...19
DAB+ ENSEMBLE AND STATION LIST...........................................................................................20
DAB+ SETUP ......................................................................................................................................21
DAB+ STATION-PRESETS ................................................................................................................22
USB / BT A2DP / IPOD / DVD / SD (AUDIO) MEDIA ........................................................................23
USB / BT A2DP / IPOD / DVD / SD (AUDIO) MEDIA CONTROL AND OPERATION BAR.............24
BT-MUSIC (A2DP) .............................................................................................................................25
iPOD (AUDIO) .....................................................................................................................................26
PLAYLIST (AUDIO) ............................................................................................................................27
VIDEO MEDIA: HARDDISK ...............................................................................................................28
PLAYLIST (VIDEO).............................................................................................................................29
HDMI / AV/IN........................................................................................................................................30
CAMERA .............................................................................................................................................31
SMARTLINK DIRECT .........................................................................................................................32
SMARTLINK DIRECT CONTROL INTERFACE ................................................................................33
SMARTLINK DIRECT CONTROL BAR ICONS.................................................................................34
SMARTPHONE APP LINKING...........................................................................................................35
BLUETOOTH (HANDS-FREE SYSTEM) ...........................................................................................36
CONTROL AND OPERATION BAR (RIGHT SIDE) ..........................................................................37
DEVICE MANAGER............................................................................................................................38
PAIRING ..............................................................................................................................................39
BLUETOOTH SETUP..........................................................................................................................40
BLUETOOTH STATUS BAR...............................................................................................................40
ACCEPTING/ENDING INCOMING CALLS (VIA DEVICE)............................................................... 41
OUTGOING CALL VIA NUMERIC PAD............................................................................................. 41
OUTGOING CALL VIA PHONEBOOK............................................................................................... 41
BLUETOOTH MENU...........................................................................................................................42
PHONEBOOK......................................................................................................................................43
CALL LISTS ........................................................................................................................................44
FAVORITES .........................................................................................................................................45
NAVIGATION.......................................................................................................................................46
NAVIGATION UPDATE .......................................................................................................................46
MAP VIEWS (EXAMPLES).................................................................................................................47
SETUP OPERATIONS ........................................................................................................................48
DISPLAY ICON (BRIGHTNESS) ........................................................................................................49
SETUP OF SOURCES ........................................................................................................................50
MISC SETUP ....................................................................................................................................... 51
AUDIO SETUP.....................................................................................................................................52
VOLUME SETUP.................................................................................................................................53
QUICK AUDIO SETUP (BAL/FAD_SUBWOOFER_LOUDNESS) ...................................................54
AUDIO SETUP: EXPERT MODE........................................................................................................55
AUDIO VOLUME – BASE LEVEL SETUP .........................................................................................56
BALANCE / FADER SETUP...............................................................................................................57
EQUALIZER SETUP ...........................................................................................................................58
TIME ALIGNMENT SETUP.................................................................................................................59
SUBWOOFER SETUP ........................................................................................................................60
NAVI-MIXER SETUP ..........................................................................................................................61
TFT DISPLAY CONFIGURATIONS....................................................................................................62
CAR (VEHICLE) SETUP.....................................................................................................................63
AIR CONDITIONING (AC INFO) ........................................................................................................64
CAR INFORMATION (VEHICLE STATUS) ........................................................................................65
SYSTEM SETUP .................................................................................................................................66
DYNAMIC INDICATION OF THE SEAT HEATER ........................................................................67-68
SOFTWARE VERSION ......................................................................................................................69
PASSWORD ........................................................................................................................................70
INSTALLATION NOTES ..................................................................................................................... 71
REMOVAL WORK AND PREPARATION .......................................................................................... 71
ABBREVIATIONS ...............................................................................................................................72
OVERVIEW ACCESSORIES ..............................................................................................................73
COMMISSIONING................................................................................................................................73
CONNECTION DIAGRAM Z-E2050................................................................................................... 74
STATUTORY RIGHTS AND WARRANTY .........................................................................................75

4 Rev.B
SAFETY INSTRUCTIONS
CAUTION
If the driver of the vehicle is distracted, this may lead to an accident or injury. Operating the
ZENEC system can distract attention from the general traffic situation! Equally, connecting,
changing or inserting data media can distract the driver from the general traffic situation.
CAUTION
Always choose loudspeaker settings such that acoustic signals coming from outside can always
be heard in the vehicle (e.g. signal horns or sirens).
CAUTION
Incorrect installation or commissioning of the ZENEC system may cause damage to the ZENEC
system or to the vehicle electronics. Only let qualified specialists authorized by ZENEC install the
device.
CAUTION
This ZENEC system is intended solely for operation at an on-board voltage of 12 V DC. Operating
the ZENEC system at any other voltage can cause damage to the ZENEC system or to the
vehicles electrical system.
CAUTION
Taking apart or modifying the ZENEC system can result in damage to the device or the vehicle.
Opening the device or modification by a person not authorized by ZENEC will render warranty
claims null and void.
In the event of a malfunction or defect please contact an authorized ZENEC dealer. Unauthorized
repairs will render warranty claims null and void.
CAUTION
Route recommendations and displayed traffic signs on the ZENEC system may differ from the
real situation. Traffic signs and traffic regulations have precedence over route recommendations
and indications of the ZENEC systems.
Speed data displayed in the navigation system corresponds to the permitted speed limit. Please
adjust your speed and driving behavior to the prevailing visibility, weather, road, and traffic
conditions.
CAUTION
The connection and charging leads of external mobile devices can get in the way of the driver.
Please run these so that the driver's freedom of movement is not hindered.
NOTE
The ZENEC system supports functions like multi-function steering wheel, display of air
conditioning settings or optical parking system and multi-function display support. All of them are
in dependence to the vehicle and can only be used, when they are provided by the vehicle.

5 Rev.B
TURN ON / OFF
Manual On / Off Z-E2050
Press the knob (fig. S/7 ), to turn the ZENEC system on, press and hold the button to
switch off the device.
The ZENEC system is equipped with an anti-theft protection function. If this is active, on restarting
the ZENEC system after interruption of the power supply you will be asked to enter your password.
To change the password:
Device User Manual → Setup → System Setup → Password
Z-E3726 5
GERÄTEBEDIENUNG –Z-E3726
GRUNDSÄTZLICHE BEDIENUNG
EIN-/AUSSCHALTEN
Manuelle Ein-/Ausschaltung
Drehregler links gedrückt halten, bis sich das ZENEC-System ein- oder ausschaltet
(Abb. S/01 )
Automatische Ein-/Ausschaltung
Fahrzeuge mit CAN-Bus Anbindung: Bei Einschalten der Zündung wird das ZENEC-System
aktiviert. Der Bootvorgang kann max. 1,5 Minuten in Anspruch nehmen. Dies kann zur Folge
haben, dass das System nur mit Verzögerung einsatzbereit ist. Das Ausschalten des ZENEC-
Systems wird durch das Ausschalten der Zündung oder Abziehen des Zündschlüssels aktiviert.
HINWEIS
Für eine Nutzung des Multifunktionslenkrads sowie weiterer Fahrzeugfunktionen wird ein
fahrzeugspezifisches CAN/Stalk Interface benötigt. Weitere Informationen erhalten Sie bei einem
autorisierten ZENEC-Fachhändler.
DIEBSTAHLSICHERUNG
Das ZENEC-System ist mit einer Diebstahlschutzfunktion ausgestattet. Ist diese aktiv, werden Sie nach
Trennung der Stromversorgung bei erneutem Einschalten des ZENEC-Systems aufgefordert, das von
Ihnen hinterlegte Password einzugeben.
Um das Passwort zu ändern:
Bedienungsanleitung  Einstellungen  Geräte Konfiguration  Help  Passwort
HINWEIS
Bewahren Sie das
Passwort sorgfältig auf.
Bei einem Verlust des
Passworts muss das
ZENEC-System ausgebaut
und zur Freischaltung des
Diebstahlschutzes an den
ZENEC-Service
eingesendet werden.
Dieser Dienst ist
kostenpflichtig!
ANTI-THEFT PROTECTION
NOTE
Keep your password safe. If the password is
lost the ZENEC system must be uninstalled,
and sent back in to ZENEC Service to
unblock the anti-theft protection. This service
is not free!
Automatic On / Off
The device automatically switches on/off by CAN bus interface ignition signal.
Switching on the ignition will activate the ZENEC system. The boot process can take up to 30sec.
This may result in some delay until the system is ready. The ZENEC system is shut down by
switching off the ignition, or removing the ignition key.

6 Rev.B
MULTIFUNCTION STEERING WHEEL
Item Icon Function
1Reduce volume
2Increase volume
3 Mute
4
|
Radio source Press to choose the next radio station.
Media
source
Press to choose the next track/title.
Press and hold to fast forward.
5
|

Radio source Press to choose the previous radio station.
Media
source
Press to choose the previous next track/title.
Press and hold to fast rewind.
6Accept call
7Reject / End call
8Voice (not supported)









7 Rev.B
Z-E2050 (FRONT PANEL)
Item Icon Function
1Tap to jump back to main menu
Press and hold jump to audio settings
2
Turn to increase or decrease playback volume
Press and hold to turn device ON or OFF
Tap to mute/- unmute device
3Tap to jump to navigation
Press and hold to open Quick Control Bar inside navigation source
4Tap to open DAB+ radio source
5Tap to jump to CAR
Press and hold jump to special CAR Menu
6Slot for the microSD with Media Files (Audio & Video)
7Tap, to eject the DVD
8Turn for list scrolling
9Tap to select preferred content or execute a function
Press and hold to jump to audio settings
10 Tap to change the source
11 Tap to open the Bluetooth hands-free page
12 microSD card slot for GPS navigation software behind „MAP“ cover
13 Hole in the panel for the reset pin
14 ○Internal microphone
15 ○IR receiver for remote control
Device Front Panel Control Options















8 Rev.B
MAIN MENU STRUCTURE
Display – touch sensitive operation Bedienung
Function Icon Operation
Sliden Swipe to navigate in the main menu by sliding to the left or right
Move Press, hold and move the icon into the desired position
Main menu with 3 Icons
Main menu with 6 Icons
The icon amount shown per main menu page can be adjusted in the setup (see page 51 „Main Menu
Style“).

9 Rev.B
Main menu with 3 Icons
Main menu with 6 Icons
Function Icon Operation
Navi Tap to open navigation App
Bluetooth Tap to open the Bluetooth hands-free page
FM Tuner Tap to open FM radio source
USB Tap to enter USB source
iPod Tap to open audio playback source (Apple)
BT-Music Tap to open BT-Music source
DAB+ Tap to open DAB+ radio source
CAR Tap to open CAR Infos
MAIN MENU ICONS
You can navigate through main menu pages by swiping or tapping on the orange page markers in
the bottom area of each page.

10 Rev.B
MEDIA AUDIO SOURCES
Function Icon Operation
USB Tap to enter USB source
iPod Tap to open audio playback source (Apple)
BT-Music Tap to open BT-Music source
Smartlink Tap to open Smartlink App
FM Tuner Tap to open FM radio source
DAB+ Tap to open DAB+ radio source (only for Z-N426)
HDMI Tap to open HDMI source
DVD Tap to open DVD source
SD Tap to open SD source
You can access / enter connected internal or external sources by tapping on the main icon according
to the following list.

11 Rev.B
INPUT SOURCES
Function Icon Operation
HDMI Tap to open HDMI source
Camera Tap to enter camera source
Smartlink Tap to open Smartlink App
AV-IN Tap to open AV-IN
CAR Tap to open CAR Info page
Input Sources
NOTE
Icons in the main menu remain greyed out for input source items not connected to device.
To select and open external sources like HDMI, Camera, AV-IN or Smartlink, they need to be paired
or physically connected to the device.

12 Rev.B
Function Icon Operation
Back Tap to jump one level up or back
Clock Time Display of time (no interaction possible)
Traffic
Announcement Traffic announcement (if function is set to active)
Volume Shows the current playback volume
ALT Tap to select / start a previously assigned function
Settings → Misc → ALT software button
Screenshot fehlt
STATUS BAR (”INFO BAR”)
The „info bar in the upper hand screen area shows TA, volume and time but also contains two
important controls for device operation: BACK (left side) and ALT (right side).

13 Rev.B
SEARCH AND INPUT FUNCTION
The input keyboard for search and input is a simple standard numeric layout.
Function Icon Operation
Search &
Input Field Input screen
Delete
Tap to delete a number
Press and hold to delete the full string
Back Tap to end the search or the input
Enter Tap to confirm the input

14 Rev.B
FM RADIO
The FM RDS source menu offers a control-/operating section on the right hand side, for fast and
convenient adjustments during the FM radio playback.
Function Icon Operation
Station forward Tap to start the auto FM station search, running up in the
frequency band
Station Station Name / Station Frequency
Station back Tap to start auto FM station search, running down in the
frequency band
Cover Shows radio station graphics or cover picture of artist
(Only with microSD card from Z-EMAP50 bundle)
Info display
area
Finger swiping left and right to access stored FM stations
previous / next
Function Icon Operation
FM/DAB+
Switch Tap to switch between FM/DAB+
Info Tap to show station information
Frequency
Scale Tap to open FM station frequency bar
Preset Tap to show the stored FM station list
Tuner Setup Tuner settings
TA Tap to activate or de-activate the auto switching of RDS based
traffic announcements
Control- and Operating Section
Center Section of Display

15 Rev.B
FM BAR GRAPH MODE
The FM setup mode (press gear icon) allows to assign two different operation modes to both station
frequency arrows: manual steps in 100kHz, or auto scan (stopping at next station). See page 18.
Function Icon Operation
Station Frequency
UP
Tap to start manual 100kHz jump, or FM station auto search
up
Station
Frequency Tap to open the direct frequency input mode keyboard
Station Frequency
DOWN
Tap to start manual 100kHz jump, or FM station auto search
down
Bar Graph Scale
Press and hold to slide the frequency pointer of the bar graph
into any position. Tap to set a desired frequency value on the
scale

16 Rev.B
MANUAL FM STATION SEARCH
Function Icon Operation
Station
Frequency UP Tap to auto seek / manual seek up, depending on setting
Station
Frequency Tap to open and close direct station frequency input via keypad
Station Frequency
DOWN Tap to auto seek / manual seek down, depending on setting
Scale Radio frequency scale display
Delete Tap to delete a number
Press and hold to delete the full number string
Keypad Direct frequency input option
OK Touch to confirm frequency
Hide Hide Keyboard / Keypad
When you tap to the frequency display area, the numeric input keyboard opens for a direct input of
the station frequency.

17 Rev.B
FM STATION-PRESET
Select a previously stored radio station by tapping on the station preset button.
Function Icon Operation
Previous
page Tap to switch to previous preset page
Next
page Tap to switch to next preset page
Stores Tap to select a stored station. Press and hold the station to save
the actual radio station on any of the station preset buttons
Store
register Tap to goto another store register (3 register each with 6 stores)

18 Rev.B
FM SETUP
Function Icon Operation
AF Alternative Frequency ON / OFF
REG Setting for search function sensitivity of auto scan
SCAN Setting to choose the automatic or manual station frequency
search.
TA Tap to activate or de-activate the auto switching of RDS traffic
announcements
Here you can set important FM RDS based settings such are AF and REG.
NOTE
Select DX to increase the general sensitivity during auto scan to stop at weaker, usually more
distant radio stations
Select LOC when you prefer to stop at local stations with a stronger signal level

19 Rev.B
DAB+ RADIO SETUP
Function Icon Operation
UKW / DAB+
Switch Tap to switch between FM / DAB +
Info Tap to show station information - main display
List Tap to open the station list (showing all currently receivable
radio stations in the environment)
Preset Tap to show the stored DAB station list
Setup Tap to change settings for DAB+ functions
Function Icon Operation
Station up Tap to jump to next station
Press and hold to jump to next Ensemble
Station Station Name / Ensemble Name
Station down Tap to jump to previous station
Press and hold to jump to previous Ensemble
Slideshow Radio station artwork / artist display (”MOT Slideshow”)
Info Display
Area Finger swiping left and right to switch between Preset stations
The DAB+ source menu offers a control- + operating section on the right side of the display, allowing
for simple and convenient direct adjustments in the playback menu.
Control- and Operating Section

20 Rev.B
DAB+ ENSEMBLE AND STATION LIST
A tap on each Ensemble opens the related DAB+ station list of the respective Ensemble. The station
list content follows exactly the original Ensemble display format and list sequence.
Function Icon Operation
Radio station
selection Tap to select one particular radio station out of the list
List scrolling Press and hold to move the slider of the station list up and down
Back Tap to jump back to Ensemble selection
Once the first DAB+ band scan has completed, device will show all DAB+ Ensembles and radio
stations of sufficient signal strength. The Ensemble list and its content is auto updated periodically (by
re-scaning).
Function Icon Operation
Ensemble list
selection
Tap to open an Ensemble, showing the assigned DAB+ radio
station list
List scrolling Press and hold to move the slider of the Ensemble list up and
down
