Zest 4 Leisure Isabel Planter User manual

Assembly Instructions
(W x D x H) 0.50m x 0.50m x 0.50m
Product Name: Isabel Planter
Pressure Treated products should not be treated with any other products for the first month.
PLEASE KEEP THESE INSTRUCTIONS
Zest4Leisure
01352 752555 option 1 –[e-mail]
V2-08.14

Isabel Planter Assembly Instructions
Requires 2 person assembly.
All screw holes to be pre-drilled.
Tools required: Cordless Drill & Pozi-drive Bit / Screwdriver, 3mm Drill Bit, Mallet.
Isabel Planter Pack List
Item Description Quantity
A1 Side Panel 2
A2 Side Panel 2
B Base Panel 1
Fixings
4x60mm Screws 20
www.zest4leisure.co.uk

Please take a few moments to check all pack contents listed.
Please contact “Zest4Leisure” directly if any of the pack contents are damaged
or missing. Contact telephone: [phone] option 1 or email:
[email protected]o.uk
Assembly requires 2 persons. All screw holes to be pre-drilled.
Tools required: Cordless Drill & Pozi-drive Bit / Screwdriver, 3mm Drill Bit,
Mallet.
Isabel Planter is now complete.
1. Interlock 2no Side PanelsA1 with 2no Side PanelsA2 to form a square planter
(Figs.1a & 1b).
2. Fix Side Panels in position using 3no 4x60mm Screws per corner (Figs. 2a & 2b).
3. Invert planter and place Base Panel B centrally. Fix in position using 8no 4x60mm
Screws –2 per side (Figs.3a & 3b)

www.zest4leisure.co.uk
1b1a
2a 2b
3a 3b
