Zest 4 Leisure Deep Root Planter 1.8m User manual

Assembly Instructions
(WxDxH) 1.8m x 0.7m x 0.8m
Item Code: Deep Root Planter 1.8m
PLEASE KEEP THIS INSTRUCTION
Zest4Leisure
01352 752555 option 1 –[e-mail]

Deep Root Planter 1.8m Assembly Instructions
Requires 2 person assembly.All screw holes to be pre-drilled.
Tools required: Corded/Cordless Drill, Pozidrive Bit/Screwdriver, 3mm Drill Bit.
Deep Root Planter 1.8m Pack List
Item Description Quantity
A End Panel 2
B Side Panel 2
C Base Board Support Rail 2
D Base Board 17
E Capping Trim 4
Fixings
35mm Screws 14
45mm Screws 32
www.zest4leisure.co.uk

Please take a few moments to check all pack contents listed on page 1 of the
Assembly Instructions.
Please contact “Zest4Leisure” directly if any of the pack contents are damaged
or missing. Contact telephone: [phone] option 1 or email:
[e-mail]
Assembly requires 2 persons. All screw holes to be pre-drilled.
Tools required: Corded/Cordless Drill, Pozidrive Bit/Screwdriver, 3mm Drill Bit.
The Deep Root 1.8m is now complete.
1. Attach one End Panel (A) to Side Panels (B) using 6no 45mm screws per end
panel, as shown in Figs1a & 1b. Repeat process with the second End Panel (A)
as shown in Fig 1c.
2. Attach Base Board Support Rails (C) to base of Side Panels using 14no 35mm
screws (7no per side) as shown in Figs 2a & 2b.
3. Loose fit ALL Base Boards (D) as shown in Fig 3a. A minimum of four central
boards to be screwed down to Base Board Support Rails using 45mm screws.
See Fig 3b.
4. Set out the 4no Capping Trims (E) on top of the planter and attach using the 12no
45mm screws (2no screws per short trim and 4no per long trim). See Figs 4a &
4b.

www.zest4leisure.co.uk
1b
1a 1c
2a 2b

www.zest4leisure.co.uk
3a 3b
4a 4b
