Zest 4 Leisure Snowdon Obelisk User manual

Assembly Instructions
(W x D x H) 0.60m x 0.60m x 2m
Product Name: Snowdon Obelisk
Pressure Treated products should not be treated with any other products for the first month.
PLEASE KEEP THESE INSTRUCTIONS
Zest4Leisure
01352 752555 option 1 –[e-mail]
V2-08.14

Snowdon Obelisk Assembly Instructions
Requires 2 person assembly.All screw holes to be pre-drilled.
Tools required: Corded / Cordless Drill, Pozi-drive Bit / Screwdriver, 3mm Drill Bit.
Snowdon Obelisk Pack List
Item Description Quantity
A Trellis Panel 4
B Cap 1
Fixings
30mm Screws 12
45mm Screws 4
www.zest4leisure.co.uk

Please take a few moments to check all pack contents listed on page 1 of the
Assembly Instructions.
Please contact “Zest4Leisure” directly if any of the pack contents are damaged
or missing. Contact telephone: [phone] Option 1 or email:
[e-mail]
Assembly requires 2 persons. All screw holes to be pre-drilled.
Tools required: Corded/Cordless Drill, Pozidrive Bit/Screwdriver, 3mm Drill Bit.
Snowdon Obelisk is now complete.
1. Align two Trellis Panels (A) together as shown in Fig 1a. Ensuring that predrilled
screw holes are positioned in overlap of horizontal batten (See arrows in Fig 1a),
and that horizontal battens face outwards, fix panels together using 3no 30mm
screws (See Figs.1b, 1c & 1d). Repeat to attach subsequent panels to form a
square (tapered) obelisk.
2. Locate Cap (B) into top of obelisk and fix in position using 4no 45mm screws
(See Figs 2a & 2b)

www.zest4leisure.co.uk
1b
1a
2a
1c
1d
2b
