Zest 4 Leisure Rustic Arch User manual

Assembly Instructions
(W x D x H) m1.83 x m0.54 x m2.77
Product Name: Rustic Arch
Pressure Treated products should not be treated with any other products for the first month.
PLEASE KEEP THESE INSTRUCTIONS
Zest4Leisure
01352 752555 option 1 –[e-mail]
V3-10.15

Rustic Arch Assembly Instructions
Requires 2 person assembly.
Tools required: Corded / Cordless Drill, Pozi-drive Bit / Screwdriver, 13mm Spanner. ,
3mm Drill Bit required in order for you to drill all screw holes before construction.
Rustic Arch Pack List
Item Description Quantity
A Roof Panel 2
B Side Panel 2
C Diagonal Bracings 4
Fixings
Bolt, Nut & Washer 2
100mm Screw 8
www.zest4leisure.co.uk

Please take a few moments to check all pack contents listed.
Assembly requires 2 persons.
Tools required: Corded/Cordless Drill, Pozi-drive Bit/Screwdriver, 13mm
Spanner, 3mm Drill Bit required in order for you to drill all screw holes before
construction.
Rustic Arch is now complete.
1. Align Roof PanelsA to form an apex (Fig.1a) and attach using 2no M8 Bolts, Nuts
and Washers (Fig.1b).
2. Position Side Panel B as shown in Fig.2.
3. Connect Side Panel B to Roof PanelA using 2no Diagonal Bracings C (Fig.3)
using 4no 100mm Screws –2no per bracing.
Repeat stages 2 & 3 for remaining Side Panel B and Bracings C.
1b1a
2 3
