Zimmer GPH8000 Series User manual

Installation
and operating
instructions
GPH8000 series
2-jaw parallel gripper, pneumatic
DDOC00289
THE KNOW-HOW FACTORY
www.zimmer-group.de

INSTALLATION AND OPERATING INSTRUCTIONS: 2-jaw parallel gripper, pneumatic, GPH8000 series
ZIMMER GmbH ●Im Salmenkopf 5 ●77866 Rheinau, Germany ●Phone: [phone] ● Fax: [phone] ●www.zimmer-group.de
2
DDOC00289/a EN/2019-02-14
Contents
1 Supporting documents.......................................................................................................................................................3
2 Safety notes .........................................................................................................................................................................3
3 Proper use............................................................................................................................................................................4
4 Personnelqualication .......................................................................................................................................................4
5 Function ...............................................................................................................................................................................4
6 Installation............................................................................................................................................................................5
6.1 Installing the gripper.................................................................................................................................................................................................. 5
6.2 Checking operational readiness............................................................................................................................................................................... 5
6.3 Setting the stroke adjustment screw........................................................................................................................................................................6
6.4 Installing the example GPH8000..............................................................................................................................................................................7
6.5 Installation of accessories.........................................................................................................................................................................................8
7 Technical data......................................................................................................................................................................8
7.1 Product designation .................................................................................................................................................................................................. 8
8 Maintenance ........................................................................................................................................................................8
9 Declaration of Incorporation...............................................................................................................................................9
10 Your notes ..........................................................................................................................................................................10

INSTALLATION AND OPERATING INSTRUCTIONS: 2-jaw parallel gripper, pneumatic, GPH8000 series
ZIMMER GmbH ●Im Salmenkopf 5 ●77866 Rheinau, Germany ●Phone: [phone] ● Fax: [phone] ●www.zimmer-group.de
3
DDOC00289/a EN/2019-02-14
1 Supporting documents
NOTE:
Read through the installation and operating instructions carefully before installing the product! The installation
and operating instructions contain important notes for your personal safety. They must be read and
understood by all persons who work with or handle the product during any phase of the product life time.
The following documents are available for download on our website. Only the documents currently available
on the website are valid.
• Catalogs, drawings, CAD data, performance data
• Information on accessories
• Detailed installation and operating instructions
• General Terms and Conditions of Business, including warranty information
2 Safety notes
CAUTION:
Non-compliance may result in severe injuries!
These installation and operating instructions are intended for installation and maintenance technicians as well as design
engineers requiring the gripper for applications. Please read through all of the installation and operating instructions
carefully before start-up and pay special attention to the following hazard warnings and notes.
1. Installation,commissioning,maintenanceandrepairsmayonlybeperformedbyqualiedexpertsinaccordance
with the installation and operating instructions.
2. Thegripperisstate-of-the-art.Itisttedtoindustrialmachinesandisusedtoholdworkpieces.Thefollowingare
examples of situations in which the gripper may cause a hazard:
• The gripper is not properly installed, used or maintained.
• The gripper is not used for its intended purpose.
• Local regulations (legislation, ordinances, guidelines), such as the EC Machinery Directive, accident prevention
regulations and the installation and operating instructions, are not observed.
3. The gripper may be used only in accordance with its proper use and technical data. ZIMMER GmbH shall accept no
liability for any damage caused by improper use.
4. Any use other than the intended use requires written approval from ZIMMER GmbH.
5. Do not reach into the operating range of the gripper.
6. Make sure that the transmission lines are disconnected before you install, retool, maintain or repair the gripper.
7. In case of maintenance, conversion or expansion work, remove the gripper from the machine and perform the work
outside the danger zone.
8. When commissioning or testing, make sure that the gripper cannot be actuated by mistake.
9. Modicationstothegripper,suchasaddingdrilledholesorthreads,maybemadeonlywithpriorapprovalfrom
ZIMMER GmbH.
10.Complywiththeprescribedmaintenanceintervalsandspecicationsforcompressed-airquality;alsorefertothe
"Maintenance" section. Please contact our Service hotline for this purpose.
11.Use of the gripper under extreme conditions, such as aggressive liquids and abrasive dusts, is subject to prior
approval from ZIMMER GmbH.

INSTALLATION AND OPERATING INSTRUCTIONS: 2-jaw parallel gripper, pneumatic, GPH8000 series
ZIMMER GmbH ●Im Salmenkopf 5 ●77866 Rheinau, Germany ●Phone: [phone] ● Fax: [phone] ●www.zimmer-group.de
4
DDOC00289/a EN/2019-02-14
3 Proper use
NOTE:
The GPH8000 series gripper should only be used in its original state with its original accessories, without any
unauthorizedchangesandwithinthescopeofitsdenedparametersforuse.
ZIMMER GmbH shall accept no liability for any damage caused by improper use.
The gripper is designed for operation with compressed air only. It is not suited for operation with other media such as
liquids or gases.
Thegripperisusedasdenedunder"Properuse"inenclosedroomsfortemporarilygripping,handlingandholding
workpieces.
It is not suitable for clamping workpieces during a machining process or for direct contact with perishable goods.
Proper use of the gripper also includes the forces and torques that may be acting in addition to the
gripping force (see product data sheets at www.zimmer-group.de).
4 Personnelqualication
Installation,commissioningandmaintenancemayonlybeperformedbyqualiedpersonnel.Theymusthavereadand
understood the installation and operating instructions in full.
5 Function
The gripper has a double-sided ventilated pneumatic piston. Alternate ventilation causes the jaw to move sideways. The
energy supply can be made one-way or two-way.
The GPH8000 series gripper is available in three versions:
• Synchronous without clamp
• Synchronous with one clamp
• Asynchronous with two clamps
One or more clamping elements are used to secure the positioning of the gripper jaws.
Fig. 1: GPH8000 gripper
Fig. 2: Cutaway view of the GPH8000 gripper
1Clamping element
2Drive
3Stroke setting
4Gripper jaw
5Power supply
6Mounting block
7Round guide
8Synchronization

INSTALLATION AND OPERATING INSTRUCTIONS: 2-jaw parallel gripper, pneumatic, GPH8000 series
ZIMMER GmbH ●Im Salmenkopf 5 ●77866 Rheinau, Germany ●Phone: [phone] ● Fax: [phone] ●www.zimmer-group.de
5
DDOC00289/a EN/2019-02-14
6 Installation
NOTE:
Non-compliance may result in damage to the system
Switchothepneumaticenergysupplybeforeanyassembly,installationormaintenancework.
CAUTION:
Non-compliance may result in damage to the system
• Risk of injury in case of unexpected movement of the gripper when pneumatic energy is connected.
• Switchothepneumaticenergybeforeallwork.
• Secure the pneumatic circuit against being switched on unintentionally.
• Checkthepneumaticcircuitforanyexistingresidualenergy;bleedifnecessary.
WARNING:
• Risk of injury in case of unexpected movement of the machine or system into which the gripper is to be
installed.
• Switchothepowersupplytothemachinebeforeallwork.
• Secure the machine against being switched on unintentionally.
• Check the machine for any residual energy.
The opening pressure for the gripper and the installed clamp amounts to at least 4 bar!
6.1 Installing the gripper
The gripper may only be mounted on a surface intended for this purpose. The mounting surface must correspond
tothenecessaryatness.
Depending on the design size, cylinder screws from M3 to M16 and of strength class 8.8 are used.
The following tightening torques must be observed during installation:
The following work steps are to be carried out to install the gripper:
► Insertcenteringsleevesorcylindricalpins(optional)intotheappropriatetsonthegripper.
►Position the gripper on the intended mounting surface using the centering sleeves.
►Fasten the gripper using cylinder screws.
• When doing so, use threadlocker to secure the cylinder screws.
• Threadlocker: Use a threadlocker suitable for the application area.
►Mount the pneumatic connection.
• Closeounusedpneumaticconnectionswithdummyplugs.
6.2 Checking operational readiness
After the gripper has been properly installed, use the following characteristics to check whether it is ready to be
operated:
►Look and listen for leaks in the pneumatic connections.
►Check all mounting screws for their prescribed tightening torque.
►Look and listen for leaks in the pressurized gripper.
►Check to make sure the gripping process is functioning properly by opening and closing the gripper manually.
Screw size M3 M4 M5 M6 M8 M10 M12 M14 M16
Tightening torques [Nm] 1,3 2,9 6,0 10,2 24,9 49,5 86,3 138,0 214,9

INSTALLATION AND OPERATING INSTRUCTIONS: 2-jaw parallel gripper, pneumatic, GPH8000 series
ZIMMER GmbH ●Im Salmenkopf 5 ●77866 Rheinau, Germany ●Phone: [phone] ● Fax: [phone] ●www.zimmer-group.de
6
DDOC00289/a EN/2019-02-14
6.3 Using the stroke adjustment screw
Synchronous:
► Settherstside.
►Move to the limit stop.
►Set the second side.
• Secure the stroke adjustment screw using a threadlocker suitable for such use.
Asynchronous:
►Each stroke can be set independent from one another.
• Secure the stroke adjustment screw using a threadlocker suitable for such use.
6.3.1 Installation of stroke limitation at the factory
The adjustment screws and end stops 3for the stroke setting are installed at the factory.
Thus, the two end positions can be reduced by up to 40 mm.
6.3.1 Adapter piece installation for stroke limitation
If you require a larger reduction of the stroke limitation, the stroke can be further reduced by the use of
additional spacers.
An example depiction of an adapter piece 9can be viewed in the following image.
Inner installation of the adapter piece 9for the inner end position.
• Secure the stroke adjustment screw and spacer with a screw locking device suitable for the application.

INSTALLATION AND OPERATING INSTRUCTIONS: 2-jaw parallel gripper, pneumatic, GPH8000 series
ZIMMER GmbH ●Im Salmenkopf 5 ●77866 Rheinau, Germany ●Phone: [phone] ● Fax: [phone] ●www.zimmer-group.de
7
DDOC00289/a EN/2019-02-14
An example depiction of an adapter piece 9can be viewed in the following image.
Outer installation of the adapter piece 9for the outer end position.
• Secure the stroke adjustment screw and spacer with a screw locking device suitable for the application.
6.4 Installing the example GPH8000
The drawing of an GPH8000 is shown as an example in
the adjacent image. A detailed dimensional drawing can
be
viewed on our website.
You can also obtain information on the installed
PowerStop and the clamp on our website.
The dimensions for the adjacent construction can be
found in the respective data sheet on our website.
You can download the necessary CAD data in all
common formats from our website:
www.zimmer-group.de
Make the following selections:
Handling technology/grippers/pneumatic/2-jaw parallel
grippers with long stroke/GPH8000 series
Mounting surface length [mm] Permissible unevenness [mm]
<100 <0,02
>100 <0,05
Air connections Permissible unevenness [mm]
Connection AClose gripper
Connection BOpen gripper
Mounting position Housing position number
Housing base 1
Straight pins 1

INSTALLATION AND OPERATING INSTRUCTIONS: 2-jaw parallel gripper, pneumatic, GPH8000 series
ZIMMER GmbH ●Im Salmenkopf 5 ●77866 Rheinau, Germany ●Phone: [phone] ● Fax: [phone] ●www.zimmer-group.de
8
DDOC00289/a EN/2019-02-14
6.5 Installation of accessories
INFORMATION:
• Beforeinstallingthegripperngers,checkthattheyareofasuitablelengthfortheselectedgrippervariant
Thegrippersaredeliveredwithoutgripperngersasstandard.
• Whileinstallingthegripperngers,observethatthecylinderscrewsareatasucientscrew-indepth
Usually: 1,6xd!
• Frontsidestrokelimitationinward/outwardbymeansofstrokeadjustmentscreworxedstop
Accessories:
• Sensors
• Sensor bracket with cam switch
• PowerStop
• Non-return throttle valve
• Pressure safety valve
• Stroke limitation - adapter piece
For further information on available accessories, refer to the product data sheets on our website. You can also
ndthenecessaryorderinginformationatwww.zimmer-group.de.
7 Technical data
INFORMATION:
For "technical data," please refer to our website www.zimmer-group.de.
Thisdatavarieswithinthetypeseriesdependingonthespecicdesign.Ifyoushouldhavefurtherquestions
about products or "technical data," please contact ZIMMER GmbH Customer Service
7.1 Product designation
8 Maintenance
Maintenance-free operation of the gripper is guaranteed for up to 5 million gripping cycles (at 6 bar).
The maintenance interval may shorten under the following circumstances:
• Operation with compressed air that does not comply with DIN ISO 8573-1 quality class 4.
• Dirty environment.
• Improper use and use that does not comply with the performance data.
• Ambienttemperatureofmorethan60°C;lubricantshardenfaster!
We recommend using the ZIMMER GmbH repair service for maintenance and the replacement of seals.
Dismantling and reassembling the gripper without authorization may result in complications, as special installation
equipment is required in some cases.
GPH 8 -  - 
Type designation
Design size
Stroke per gripper
jaw
Version
Special feature
Version control

INSTALLATION AND OPERATING INSTRUCTIONS: 2-jaw parallel gripper, pneumatic, GPH8000 series
ZIMMER GmbH ●Im Salmenkopf 5 ●77866 Rheinau, Germany ●Phone: [phone] ● Fax: [phone] ●www.zimmer-group.de
9
DDOC00289/a EN/2019-02-14
9 Declaration of incorporation
In terms of the EU Machinery Directive 2006/42/EC (Annex II 1 B).
Name and address of the manufacturer:
ZIMMER GmbH • Im Salmenkopf 5 • 77866 Rheinau, Germany • Phone: [phone] • Fax: [phone] •
www.zimmer-group.de
We hereby declare that the incomplete machine described below,
Product designation: Pneumatic gripper
Type designation: GPH8--
satisesthefollowingbasicrequirementsoftheMachineryDirective2006/42/EC:
No. 1.1.2., No. 1.1.3., No. 1.1.5., No. 1.3.2., No. 1.3.4., No. 1.3.7., No. 1.5.3., No. 1.5.4., No. 1.5.8., No. 1.6.4., No. 1.7.1.,
No. 1.7.4
WealsodeclarethatthespecictechnicaldocumentswereproducedinaccordancewithAnnexVIIPartBofthis
Directive.
We undertake to provide the market supervisory bodies with electronic versions of special documents for the
incomplete machine through our documentation department, should they have reason to request them.
The incomplete machine may only be commissioned if it has been ascertained, if applicable, that the machine or
systeminwhichtheincompletemachineistobeinstalledsatisestherequirementsofDirective2006/42/ECon
Machinery and an EC declaration of conformity has been drawn up in accordance with Annex II 1 A.
Authorized representative for the compilation of
relevant technical documents.
Kurt Ross See manufacturer's address Rheinau, Germany, 2018-06-25 Martin Zimmer, Managing Director
First name, last name Address (Place and date of issuance) (Legally binding signature)

INSTALLATION AND OPERATING INSTRUCTIONS: 2-jaw parallel gripper, pneumatic, GPH8000 series
ZIMMER GmbH ●Im Salmenkopf 5 ●77866 Rheinau, Germany ●Phone: [phone] ● Fax: [phone] ●www.zimmer-group.de
10
DDOC00289/a EN/2019-02-14
10 Your notes

INSTALLATION AND OPERATING INSTRUCTIONS: 2-jaw parallel gripper, pneumatic, GPH8000 series
ZIMMER GmbH ●Im Salmenkopf 5 ●77866 Rheinau, Germany ●Phone: [phone] ● Fax: [phone] ●www.zimmer-group.de
11
DDOC00289/a EN/2019-02-14

INSTALLATION AND OPERATING INSTRUCTIONS: 2-jaw parallel gripper, pneumatic, GPH8000 series
ZIMMER GmbH ●Im Salmenkopf 5 ●77866 Rheinau, Germany ●Phone: [phone] ● Fax: [phone] ●www.zimmer-group.de
12
DDOC00289/a EN/2019-02-14
