Zimmer GPP5025N-00-A User manual

INSTALLATION AND
OPERATING
INSTRUCTIONS
2-jaw parallel gripper, pneumatic
GPP5000
3-jaw concentric gripper,
pneumatic
GPD5000
DDOC00196
THE KNOW-HOW FACTORY
www.zimmer-group.com

3
1 Supporting documents ............................................................................................................................................................... 4
1.1 Notices and graphics in the installation and operating instructions ...............................................................................................................................4
2 Safety notices............................................................................................................................................................................... 5
3 Proper use .................................................................................................................................................................................... 6
4 Personnelqualication................................................................................................................................................................ 6
4.1 Electricians ...........................................................................................................................................................................................................................6
4.2 Specialists ............................................................................................................................................................................................................................6
4.3 Instructed personnel............................................................................................................................................................................................................6
4.4 Service personnel................................................................................................................................................................................................................6
4.5 Additionalqualications ......................................................................................................................................................................................................6
5 Product description ..................................................................................................................................................................... 7
5.1 Type plate .............................................................................................................................................................................................................................7
6 Functional description ................................................................................................................................................................. 7
7 Technical data .............................................................................................................................................................................. 7
8 Accessories/scope of delivery ................................................................................................................................................... 8
9 Transportation/storage/preservation......................................................................................................................................... 8
10 Installation .................................................................................................................................................................................... 9
10.1 Installing GPP5000 ............................................................................................................................................................................................................10
10.2 Installing GPD5000............................................................................................................................................................................................................11
10.3 Installing the energy supply ..............................................................................................................................................................................................12
10.4 Installing the sensors.........................................................................................................................................................................................................13
10.4.1 Adjustingthemagneticeldsensors.................................................................................................................................................................13
10.4.2 Setting the inductive sensors .............................................................................................................................................................................13
10.5 Installingthegripperngers .............................................................................................................................................................................................14
10.6 Installing the support structure.........................................................................................................................................................................................15
10.7 Installing accessories ........................................................................................................................................................................................................15
11 Maintenance............................................................................................................................................................................... 16
12 Decommissioning/disposal ...................................................................................................................................................... 17
13 Declaration of Incorporation ..................................................................................................................................................... 18
