Zip HydroTap G4 User manual

801599UK G4 Commercial Boiling Chilled User manual - Aug 2016 - V2.03 Page 1 of 24
Affix model number label
here
801599UK
ZIP HydroTap G4
User Manual
®

Page 2 of 24 801599UK G4 Commercial Boiling Chilled User manual - Aug 2016 - V2.03
Elite HydroTap®G4
Safety lock
Boiling
button
Chilled
button
Elite functionality
The Elite tap uses touch sensitive
controls to dispense boiling and
chilled water.
When operating the tap ensure the
touch surface is dry as moisture
may interfere with the sensor touch
control.
The safety lock can be controlled from either
the tap or from the touch screen display (See
page 21).
Filter light
Boiling water
light
Tap lights
Red BOILING water light
Continually illuminated
This indicates that the boiling water is ready.
Flashing slowly
This indicates that the boiling water is below the set dispense temperature.
Wait for the light to stop flashing before dispensing water. The light will
typically flash after switching on, or coming out of sleep mode.
Flashing quickly - warning light
When the indicator light flashes fast and continuous, a system fault has
occurred. Check for details on the faults screen (see page 12). If unable to
rectify, call a qualified service agent.
3. Table of contents
• Elite HydroTap
®
G4.................................... Page 2
• Classic HydroTap
®
G4............................... Page 4
• Arc and Cube HydroTap
®
G4.................... Page 7
• All-in-One HydroTap
®
G4.......................... Page 9
• Classic, Arc and Cube mixer taps.......... Page 9
• LCD screen & menu................................. Page 10
• Filter maintenance ................................... Page 22
• Home menu icons.................................... Page 24
• Cleaning.................................................... Page 22
• Contact details ......................................... Page 24
• Date of installation.........

801599UK G4 Commercial Boiling Chilled User manual - Aug 2016 - V2.03 Page 3 of 24
Tap safety
The safety lock feature is provided to prevent boiling water flowing if the red
BOILING control is inadvertently activated.
This function can be activated and deactivated from either the tap or from the
touch screen display (located on the Command-CentreTM).
White FILTER light
Filter light off
This indicates the filter is operating within its normal specified lifespan.
Filter light flashing slowly
The light will flash slowly when the filter is due for replacement and the LCD
will show ‘Filter Change. See ‘To change the filter’ page 22
Elite HydroTap®G4
• To allow the safety setting to be changed using the touch screen, (see
page 21).
• To enable or disable the tap safety lock, (see page 21).
• For hot isolation, (see page 21).
To dispense boiling water with the safety lock off
Touching the red BOILING button allows the dispensing of boiling water.
To dispense boiling water with the safety lock on
Place a finger on the safety lock, then touch the red BOILING button,keeping
both fingers in position to dispense boiling water.
To dispense chilled water
Touch the blue CHILLED button to dispense chilled water.
To activate the safety lock from the tap
(Ensure ‘Allow safety settings change’ is selected, see page 21).
First place a finger over the safety lock, then touch the CHILLED button, keep
both fingers in position for a period of approximately ten seconds.
To deactivate the safety lock from the tap
First place a finger over the safety lock, then touch the CHILLED button while
keeping both fingers in position for a period of approximately ten seconds.
To dispense water

Page 4 of 24 801599UK G4 Commercial Boiling Chilled User manual - Aug 2016 - V2.03
Classic HydroTap®G4 (inc. All -in One)
Safety Lock
Boiling lever Chilled lever
Classic functionality
The Classic tap uses lever switch
controls to operate the tap.
Lever controls can be pushed back to
dispense water manually, or pulled forward to
dispense water for a fixed time period, (see
page 22). Once pulled forward, levers need to
be manually returned to the OFF position.
The safety lock can be controlled from either
the tap or from the touch screen display (See
page 21).
Red
lights
Blue
lights
Tap lights
Red BOILING water lights
Continually illuminated
This indicates that the boiling water is ready.
Flashing slowly
This indicates that the boiling water is below the set dispense temperature.
Wait for the light to stop flashing before dispensing water. The light will
typically flash after switching on, or coming out of sleep mode.
Flashing quickly - warning light
When the indicator light flashes quickly and continuously, a system fault has
occurred.
Check for details on the faults screen (see page 12). If unable to rectify, call a
qualified service agent.
Filter
light
White FILTER light
Filter light off
This indicates the filter is operating within its normal specified lifespan.
Blue CHILLED water lights
Continually illuminated
This indicates that the temperature of the chilled water is within the set
temperature range.
Flashing slowly
This indicates that the chilled water is not within the set temperature range.
When the chilled water is at the set temperature, the light will stop flashing.
This could take several minutes.
During heavy usage, the temperature can rise out of this range.

801599UK G4 Commercial Boiling Chilled User manual - Aug 2016 - V2.03 Page 5 of 24
Tap safety
The safety lock feature is provided to prevent boiling water flowing if the red
BOILING control is inadvertently activated.
This function can be activated and deactivated from either the tap or from the
touch screen display (located on the Command-CentreTM).
To activate the safety lock from the tap
(Ensure ‘Allow safety settings change’ is selected, see page 21).
First place a finger over the safety lock, then depress the blue CHILLED lever,
keep both fingers in position for a period of approximately ten seconds. The
safety lock indicator light will illuminate.
To deactivate the safety lock from the tap
First place a finger over the safety lock, then depress the blue CHILLED
lever, while keeping both fingers in position for a period of approximately ten
seconds. The safety lock indicator light will extinguish.
• To allow the safety setting to be changed using the touch screen, (see
page 21).
• To enable or disable the tap safety lock, (see page 21).
• For hot isolation, (see page 21).
To dispense boiling water with the safety lock off
Press the red BOILING lever to dispense boiling water.
Pulling forward the red BOILING lever allows the tap to operate in a “no-
touch” mode. Water will flow from between 5 and 15 seconds (this is user
adjustable, see page 22).
To reset, return the lever to the OFF position and repeat the step. (The lever
has to be manually returned to the OFF position).
Classic HydroTap®G4 (inc. All -in One)
To dispense water
To dispense boiling water with the safety lock on
Depress the red BOILING lever, while simultaneously covering the safety lock
button with a second finger. These two actions need to occur within 2 seconds
to dispense boiling water.
Filter light flashing slowly
The light will flash slowly when the filter is due for replacement and the LCD
will show ‘Filter Change’. (See To change the filter, page 22).
To dispense chilled water
Press the blue CHILLED lever to dispense chilled water.
Pulling forward the blue CHILLED lever allows the tap to operate in a “no-
touch” mode. Water will flow from between 5 and 15 seconds (this is user
adjustable, see page 22).
To reset, return the lever to the OFF position and repeat the step. The lever
has to be manually returned to the OFF position.

Page 6 of 24 801599UK G4 Commercial Boiling Chilled User manual - Aug 2016 - V2.03
Classic HydroTap®G4 (inc. All -in One)
Pull both levers forward
Safety
sensor
Procedure
• Shield the HydroTap®G4 from any
direct sunlight.
• With the Command-CentreTM in
normal operating mode and safety
lock enabled, turn the power off.
• Pull both tap levers to the forward
position.
• Turn the power on.
• The Command-CentreTM will calibrate
the safety switch.
• Return the levers to the neutral
position.
Safety sensor calibration
Light intensity varies from site to site, therefore it is recommended that a
recalibration be performed at the time of the installation.
All direct sunlight must be shaded from the HydroTap®G4, during the
calibration. This can be achieved by closing any nearby curtains, blinds, etc.

801599UK G4 Commercial Boiling Chilled User manual - Aug 2016 - V2.03 Page 7 of 24
Arc and Cube HydroTap®G4
Indicator light
Select button
Safety button
Rotary
control
Arc / Cube functionality
On power up, wait 30secs. for the unit to
calibrate before selecting either the
BOILING red illuminated with safety, or
CHILLED blue illuminated water mode,
by touching the select button.
The Arc / Cube control may be
rotated in a forward or reverse
direction to dispense boiling or chilled water.
The rotary control is spring loaded in the forward
direction and when released, will return to the OFF
position.
When rotated in the reverse direction the tap
operates in a POT FILL mode. Water will flow from
between 5 and 15 seconds (This is user adjustable,
see page 22). To reset, return the control to the
OFF position and repeat the step. The control has to be manually returned to
the OFF position.
When unattended, the control light will automatically default to the CHILLED
(blue illuminated) mode after a short period.
Tap lights
Red BOILING water (safety, select and indicator) lights
Continually illuminated
This indicates that the boiling water is ready.
Flashing slowly
This indicates that the boiling water is below the set dispense temperature.
Wait for the light to stop flashing before dispensing water. The light will
typically flash after switching on, or coming out of sleep mode.
Flashing quickly - warning light
When the indicator light flashes quickly and continuously, a system fault has
occurred.
Check for details on the faults screen (see page 12). If unable to rectify, call a
qualified service agent.
Blue CHILLED water lights (safety, select and indicator)
Continually illuminated
This indicates that the temperature of the chilled water is within the set
temperature range.

Page 8 of 24 801599UK G4 Commercial Boiling Chilled User manual - Aug 2016 - V2.03
To dispense boiling water with the safety lock off
Touch the SELECT button until the indicator and select lights illuminate red.
Rotating the control when the indicator lights are illuminated red allows the
dispensing of boiling water.
To dispense boiling water with the safety lock on
Touch the select button until the indicator, select and safety buttons illuminate
red, then touch the safety button twice until the three red lights flash (the
lights will flash for approx. 2 seconds) if the tap control is not rotated, then
the select, safety and indicator lights will return to continually illuminated red
(and after a short period the select and indicator lights will return to continually
illuminated blue as a safety precaution).
Boiling water may be dispensed by rotating the control while the three red
illuminated lights are flashing.
While dispensing boiling water, all three red illuminated lights will continue to
flash.
Arc and Cube HydroTap®G4
To dispense chilled water
Rotating the control when the indicator light is illuminated blue allows the
dispensing of chilled water.
If illuminated red, touch the SELECT button until the indicator light illuminates
blue.
Filter lights
All three tap lights (Safety, Select and Indicator light) will flash white every
10 seconds, indicating a filter change is required.
Reset the filter light see page 14
Flashing slowly
This indicates that the chilled water is not within the set temperature range.
When the chilled water is at the set temperature, the light will stop flashing.
This could take several minutes.
During heavy usage, the temperature can rise out of this range.

801599UK G4 Commercial Boiling Chilled User manual - Aug 2016 - V2.03 Page 9 of 24
All-in One HydroTap®G4
Tap functionality and
operation
The top of the All-in-
One tap is operated in
the same manner as a
Classic HydroTap®G4.
The two levers are used
for dispensing boiling and
chilled water. The safety
lock also operating in the
same manner as the Classic
HydroTap®G4.
The mixer tap lever is
operated as a conventional
‘flick mixer’. The hot direction
is marked with a red dot and
the cold direction with a blue dot, for dispensing cold to warm water.
Moving the lever away from the tap will increase the flow rate and towards
the tap will decrease the flow rate.
When the lever is moved in the direction of the blue dot, the temperature is
decreased and when moved in the direction of the red dot, the temperature
is increased. The final temperature will be dependant on the temperature
of the incoming cold water. The spout may be swivelled, left or right, for
convenience.
Classic , Arc and Cube mixer taps
Tap functionality and operation
Classic, Arc and Cube mixer taps operate in the same manner as the All in One mixer
tap, detailed above.

Page 10 of 24 801599UK G4 Commercial Boiling Chilled User manual - Aug 2016 - V2.03
Zip HydroTap®G4 features a ‘TOUCH’ screen for easy setup and operation
adjustment.
(See page 24 for home menu icons).
Other possible messages in status window:
Status** Information Notes
Safety OFF Product is in normal operation
mode
-
Safety ON Safety lock is activated Refer to section
G - safety
System Fault Product has one or more system
faults
Refer to section B
- System info.
Sleep Mode System is in sleep mode. Boiling
water or hot water is not available.
Refer to section
G - Energy modes
Change Filter External/Internal filter needs to be
replaced
Refer to section C
- Installation
System Off System off in off mode. No boiling
water or chilled water available.
Refer to section
G - Energy modes
Hot Isolated Hot isolation has been activated.
Boiling water or hot water is not
available.
Refer to section
G - Safety
3LCD Screen
Note When selecting menu options, the screen will revert to the main menu,
if the screen remains inactive for a period in excess of 10 seconds.
Note As an energy saving feature, the home screen will turn off after
5 minutes of non use. Touching the darkened LCD panel will reactivate the
home screen.

801599UK G4 Commercial Boiling Chilled User manual - Aug 2016 - V2.03 Page 11 of 24
3LCD Screen menu
Main
menu
Sub menu Sub menu
options
Section
Language English / Deutsch
A
Information
• Product info.
• Filters log
• System faults
• Energy
• Module
Revision
Serial number
Product number
Calibration
• Filters
• Faults found
• Reset
B
Installation
• Filter flush
• Filter reset
• Boiling
calibration
• Booster
• Lux sensor
calibration
• Start/Stop
• Internal/External
• Calibration options
• Enable/Disable
C
Service Password
protected
D
Security
• Enable
password
• Set password
• Change password
E
Communication
• Remote monitor
• Remote control
• WiFi Options
F
Settings
• Date/Time
• Temperature
• Filter
• Energy modes
• Safety
• Dispense times
• 2hr/24hr Mode
• Hot/Cold setpoint
• Filter life (Litres)
Filter life (Months)
• Sleep mode options
On/Off modes
• Safety lock
Hot isolation
• Hot/Cold dispensing
G

Page 12 of 24 801599UK G4 Commercial Boiling Chilled User manual - Aug 2016 - V2.03
• Press the [MENU] button for
main menu.
• Press the [Language] button.
• Select the language.
• Press [<=] button for the
previous menu.
A. Set language
B. System information
In this section, you can find your product serial number, check system fault
messages or view the filter logs of your product.
LCD Screen operation - Section A
LCD Screen operation - Section B
• Press [Product Info] to view the
current product serial no.
• Press [<=] button for the
previous menu or press [HOME]
button to return to the home
screen.
• Press [System Faults] or [Recent
Fault Log] to check the fault
information.
• Press [<=] button for the
previous menu or press [HOME]
button to return to the home
screen.
• Press [Filter Log] to check the
filter resets.
• Press [<=] button for the
previous menu or press [HOME]
button to return to the home
screen.
• Press the [MENU] button for
main menu.
• Press the [Info] button to view
the product serial number and
other key information.
Total Energy
Zip Boiling Chilled 15:11 Tue 26, July 2016
Last Period
00010.4
004.4
(kWh)
Reset 00.00.00
HOME
• Press [Energy] to view Total
energy information.
• Press reset to view the energy
used for a new period.
• Press [<=] for the previous menu
or press [Home] to return to the
home screen.

801599UK G4 Commercial Boiling Chilled User manual - Aug 2016 - V2.03 Page 13 of 24
C. Install
1. Filter ush
Sub menu
1. - Filter flush.
2. - Filter reset.
3. - Boiling calibration.
4. - Booster.
5. - Lux sensor calibration.
LCD Screen operation - Section C
OPEN
Position
CLOSED
Position
ON
OFF
Once your Zip HydroTap®G4 unit has been installed, Go to the install menu to
configure the system settings for your product.
Have a bucket or similar container (not supplied) at the ready to hold a
quantity of water that will be ejected while the filter flush mode is in operation.
Open the filter access door on the front of the HydroTap®G4 and the filter
cartridge will be exposed. Located to the rear right hand side of the cartridge
is a flush line, approx 600mm long and the flush line stop cock. Place the
free end of the flush line into the bucket or container (not supplied).
• Press [MENU] button for main
menu.
• Press the [Install] button. Turn the
stop cock on.
• Press the [Filter Flush] button.
• Press [START] button to start
filter flush. Once the filter flush
is finished, turn the stop cock off
first (ensure the cock is properly
closed) then press [STOP] to end
filter flush mode.
• Press [<=] button for the previous
menu or press [HOME] button to
return to the home screen.
• After initial installation,turning
off the filter flush mode puts the
HydroTap®G4 into calibration
mode. With subsequent filter
changes, the system reverts to
the main menu.
Note Run at least 10 Litres of
water through to flush the filter
of any excess black carbon
particles (this is normal). Once
the filter flush has finished,
press the [STOP] button to
display the main menu.

Page 14 of 24 801599UK G4 Commercial Boiling Chilled User manual - Aug 2016 - V2.03
• Press the [MENU] button for main
menu.
• Press the [Install] button.
• Press the [Filter Reset] button.
• Press the [Reset Internal Filter] /
[Reset External Filter] button.
• If you need to flush the filter follow
the filter flush guide, see page 13.
• To cancel the filter reset program
press [HOME] or [<=].
• To set the filter life or edit filter
usage, see page 18.
After replacing the filter, the counters should be reset.
• Press the [MENU] button for main
menu.
• Press the [Install] button.
• Press the [Boiling Calibration]
button.
• In the next screen, press
[Calibrate] if you want to start
calibration.
3. Boiling calibration
• Press the [MENU] button for main
menu.
• Press the [Install] button.
• Press the [Boost] button.
• In the next screen, select [YES]
to enable the booster, dispense
boiling water for 30 seconds and
check the (insulated) outlet hose
from the booster is warm.
• If booster is not installed , ensure
NO is selected.
This function should only be used when a booster unit is installed.
4. Booster
Note Failing to make the correct
selection for [Boost] will affect product performance.
2. Filter reset
LCD screen operation - section C
Caution In general, boiling water units may vent steam from the tap spout.
Take care to avoid personal injury whenever this occurs.
The Zip HydroTap®G4 is equipped with a self-calibrating program. On start
up, the controls take the system through a calibration process. Once this
mode is completed the system reverts back to normal operation. If you would
like to calibrate the system anytime after installed, please follow the steps
below.

801599UK G4 Commercial Boiling Chilled User manual - Aug 2016 - V2.03 Page 15 of 24
Caution must be observed when changing any settings within the
service menu as any changes may affect the normal operation of
the unit. This can only be done by a Zip technician. Please contact
your Zip service provider for further assistance.
• Press the [MENU] button for
main menu.
• Press the [Service] button.
• A password is required to enter
service menu.
D. Service
LCD Screen operation - Section D
5. Lux sensor calibration
• Press the [MENU] button for
main menu.
• Press the [Install] button.
• Press the [Lux Sensor
Calibration] button.
• The lights on the tap head will
flash to confirm calibration.
LCD Screen operation - Section C
Note In UK call a licensed electrician / plumber,or call Zip on
0345 6 005 005, for assistance, service, spare parts or enquiries.
Note Correct operation of the Lux sensor can be verified by selecting Lux
Sensor - OFF. When the room is subsequently darkened, below the calibrated
light level, the lights will turn off after 24 seconds.
Note Do not calibrate the Lux sensor in dark lighting conditions.
E. Security
The Zip HydroTap®G4 allows the appliance coordinator to set up a password
to protect against users changing the preferred system settings.
To set a password
• Press the [MENU] button for main
menu.
• Press the [Security] button.
• Press [Enable Password].
• Enter a 4 digit password.
• Press [Enter].

Page 16 of 24 801599UK G4 Commercial Boiling Chilled User manual - Aug 2016 - V2.03
3. LCD Screen operation - Section E
To change a password
• Press the [MENU] button for main
menu.
• Press the [Security] button.
• Press [Change Password].
• Enter your old 4 digit password.
• Then enter your new 4 digit
password & press [Enter]. (Once
the password has been set you
will need to enter the password
to access the settings screen. If
you have forgotten the password,
please disconnect the power and
restart your HydroTap®G4).
F. Communication
LCD Screen operation - Section F
The Zip HydroTap®G4 allows the user to use Wi-Fi to operate the product
remotely.
• From the Home screen Press
[Menu].
• [Press] Comm’s
• Enter your 4 digit password to
access the WiFi set up.
• Follow the set up instructions in the
ZipAssist installation manual.
To disable the WiFi setup
Navigate to the WiFi screen (as above)
• Press [WiFi setup]
• In the next screen Press [Disable]
• Press [<=] button for the previous
menu.
WiFi Setup
Zip Boiling Chilled 15:11 Tue 26, July 2016
Cloud server
not registered
Status:
Hotspot disabled
Mode:
Disabled

801599UK G4 Commercial Boiling Chilled User manual - Aug 2016 - V2.03 Page 17 of 24
G. Settings
3. LCD Screen operation - Section G g Instructions
• Press the [MENU] button for main
menu.
• Press the [Settings] button.
• Enter your 4-digit password and
press [Enter].
• Once the password has been set
you will need to enter the
password to access the settings
screen. If you have forgotten the
password see page 16, LCD
screen operation - section E
security.
In the settings mode you will be able
to access the following:
• Press the [MENU] button.
• Press the [Setting] button.
• Enter your 4-digit password and
press [Enter].
• Press the [Date/Time] button.
• Choose ‘12 HOUR’ mode or
‘24 HOUR’ mode by pressing
the square button. The selected
mode will be displayed in dark
grey colour with a tick box on the
right.
• Press [NEXT] button to set time.
Set Date / Time
• Press the [MENU] button for main
menu.
• Press the [Settings] button.
• Enter your 4-digit password and
press [Enter].
• Press the [Temperature] button.
• To adjust the temperature, press
the relevant temperature button
and then use the up and down
arrows.
Zip HydroTap®G4s are designed to operate within 1ºC to 2ºC of set point for
boiling water and between 5ºC to 9ºC for chilled drinking water. All boiling
water units are self calibrating to 98ºC, which is the recommended setting.
Adjustments to the 98ºC setting are not recommended however under certain
circumstances adjustments may be made between 68º and 98ºC. See below.
Set temperature

Page 18 of 24 801599UK G4 Commercial Boiling Chilled User manual - Aug 2016 - V2.03
3. LCD Screen operation - Section G
Filter
Zip HydroTap®G4 allows the user to adjust filter life and edit filter usage.
To edit the filter life
Press the [MENU] button for main
menu.
• Press the [Settings] button.
• Enter your 4-digit password and
press [Enter].
• Press the [Filter] button.
• Press the [Int Filter Life] / [Ext
Filter Life] button.
• To change filter life, first select
(Litres) or (Months) then press the
up or down arrows to edit filter life.
Note
Filter life increases in 500 litres
increments to a maximum of 10000
litres. Factory set at 6000 litres.
To edit the filter usage
This function is to reset the filter change
display after a filter has reached the
end of its life (see page 22 Filter
maintenance).
• Press the [MENU] button for main
menu.
• Press the [Settings] button.
• Enter your 4-digit password and
press [Enter].
• Press the [Filter] button.
• Press the [Edit Int Filter] / [Edit
Ext Filter] button.
• To change filter usage, first select
(Litres) or (Days), then use the up
and down arrows to edit the filter
usage.
Note The filter life may be set as a
function of litres used, or in months
from the filter change. When the first of
these functions is reached (i.e. litres or
months expired), the filter warning light
will be illuminated on the tap.
Either of these functions may be
disabled.

801599UK G4 Commercial Boiling Chilled User manual - Aug 2016 - V2.03 Page 19 of 24
3. LCD Screen operation - Section G
This mode allows the HydroTap®G4 to go into energy saving mode. There
are two options available: sleep mode and on/off mode.
Energy modes
In sleep mode the unit will go to “Sleep” after a 2hr period of inactivity. The
boiling water will gradually drop to either 68°C or room temp, as shown in the
table below and the chilled water will be ON or OFF.
• Press the [MENU] button for main
menu.
• Press the [Settings] button.
• Enter your 4-digit password and
press [Enter].
• Press the [Energy Modes] button.
• Press the [Sleep Modes] button
then in the next screen, use the
up and down arrow to select sleep
mode from the 7 options in the
table below.
It is recommended to recalibrate the Lux sensor after selecting any of the
Lux sensor options from the sleep mode menu. (See page 15 ,Lux sensor
calibration).(Classic, Arc / Cube only).
Sleep Mode Light
level
Time
delay
State Boiler Chiller
2 Hours > 680CN/A 2 Hr Sleep 680C ON
2 Hours > OFF N/A 2 Hr OFF OFF OFF
Lux Sensor > 680CDark N/A Sleep 680C ON
Lux Sensor > OFF Dark N/A OFF OFF OFF
Lux Sensor or 2 Hr > 680CDark 2 Hr Sleep 680C ON
Lux Sensor or 2 Hr > OFF Dark 2 Hr OFF OFF OFF
Disable N/A N/A ON ON ON
To activate sleep mode

Page 20 of 24 801599UK G4 Commercial Boiling Chilled User manual - Aug 2016 - V2.03
LCD Screen operation - Section G
On/Off mode menu
Individual set screen
Group set screen
A
A
Note Any attempt, during off mode, to dispense water, will bring the unit out
of sleep mode. The unit will return to sleep mode after 2 hours of non use.
Please allow sufficient time for the water to reach the set temperature after
disabling the sleep mode.
This screen allows you to select the
individual days for programming.
Only one On/Off period is allowed for
each day.
On/Off mode allows the user to turn the
unit on or off at a specific time.
To activate On/Off mode
• Press the [MENU] button for main
menu.
Press the [Settings] button.
Enter your 4-digit password and
press [Enter].
• Press the [Energy Modes] button
then [On-Off Modes Menu] button.
• Select ‘Individual Set’ if you wish
to allocate a specific time for each
day.
• Select ‘Group Set 1’ if you wish to
allocate the same time to all seven
days.
• Select ‘Group Set 2’ if you wish
to allocate the same time to the
five working days (Mon-Fri) and
additional times for weekends
(Sat-Sun).
Note Any attempt, during off mode, to dispense water, will bring the unit out
of energy mode. The system will revert to the energy mode setting after 30
minutes of non use.
• Select ‘Group Set 1’ / ‘Group Set
2’ then press [NEXT].
• Press button to enable and
set the On/Off time by scrolling
with the up & down arrow keys.
