Ziton ZP3-ECU Guide

ZP3-ECU Extinguishing
Control Unit Installation
and Commissioning
Manual
P/N 503-0800ZE-I-04 • REV 04 • ISS 20MAR14

Copyright © 2014 UTC Fire & Security. All rights reserved.
Trademarks and
patents
The ZP3-ECU Extinguishing Control Unit name and logo are
trademarks of UTC Fire & Security.
Other trade names used in this document may be trademarks or
registered trademarks of the manufacturers or vendors of the
respective products.
Manufacturer UTC CCS Manufacturing Polska Sp. Z o.o.
Ul. Kolejowa 24. 39-100 Ropczyce, Poland
Authorized EU manufacturing representative:
UTC Fire & Security B.V.
Kelvinstraat 7, 6003 DH Weert, Netherlands
Certification
2002/96/EC (WEEE directive): Products marked with this symbol
cannot be disposed of as unsorted municipal waste in the European
Union. For proper recycling, return this product to your local supplier
upon the purchase of equivalent new equipment, or dispose of it at
designated collection points. For more information see:
www.recyclethis.info.
2006/66/EC (battery directive): This product contains a battery that
cannot be disposed of as unsorted municipal waste in the European
Union. See the product documentation for specific battery
information. The battery is marked with this symbol, which may
include lettering to indicate cadmium (Cd), lead (Pb), or mercury
(Hg). For proper recycling, return the battery to your supplier or to a
designated collection point. For more information see:
www.recyclethis.info.
Contact information
For contact information, see www.utcfssecurityproducts.eu.

ZP3-ECU Extinguishing Control Unit Installation and Commissioning Manual i
Content
Important Information ii
Preface iv
Safety Issues/Limitations iv
Chapter 1 System Wiring 1
Wiring Standards 2
Wiring Connections 2
Chapter 2 Physical Installation 11
Extinguishing Control Unit 12
Chapter 3 Commissioning 15
Introduction 16
Programming the Extinguishing Control Unit (ZP5 Mk2-5 and
ZP3 Panels) 20
Tests 25
Index 29

ii ZP3-ECU Extinguishing Control Unit Installation and Commissioning Manual
Important Information
Limitation of Liability
To the maximum extent permitted by applicable law, in no event will UTCFS be
liable for any lost profits or business opportunities, loss of use, business
interruption, loss of data, or any other indirect, special, incidental, or
consequential damages under any theory of liability, whether based in contract,
tort, negligence, product liability, or otherwise. Because some jurisdictions do not
allow the exclusion or limitation of liability for consequential or incidental
damages the preceding limitation may not apply to you. In any event the total
liability of UTCFS shall not exceed the purchase price of the product. The
foregoing limitation will apply to the maximum extent permitted by applicable law,
regardless of whether UTCFS has been advised of the possibility of such
damages and regardless of whether any remedy fails of its essential purpose.
Installation in accordance with this manual, applicable codes, and the instructions
of the authority having jurisdiction is mandatory.
While every precaution has been taken during the preparation of this manual to
ensure the accuracy of its contents, UTCFS assumes no responsibility for errors
or omissions.
Advisory Messages
Advisory messages alert you to conditions or practices that can cause unwanted
results. The advisory messages used in this document are shown and described
below.
WARNING: Warning messages advise you of hazards that could result in injury
or loss of life. They tell you which actions to take or to avoid in order to prevent
the injury or loss of life.
Caution: Caution messages advise you of possible equipment damage. They tell
you which actions to take or to avoid in order to prevent the damage.
Note: Note messages advise you of the possible loss of time or effort. They
describe how to avoid the loss. Notes are also used to point out important
information that you should read.

ZP3-ECU Extinguishing Control Unit Installation and Commissioning Manual iii
List of Abbreviations, Acronyms and Terms
Abbreviation Definition
DC Direct Current
ECU Extinguishing Control Unit
EOL End of Line
Extinguishant Generic term to describe an extinguishing agent used to combat fires; for
example water, dry chemical, foam etc.
GND Ground
LCD Liquid Crystal Display
LED Light Emitting Diode
mA milliampere
PC Personal Computer
RX Receive
SKNS Single Knock Non Silencing
SPDT Single Pole Double Throw
SW Switch
TX Transmit
V Volts
Associated Publications and References
The following documents, or parts thereof, are referenced from this manual.
Document Description Document Number
ZP3 Fire Control Panel Installation, Commissioning, and
Maintenance Manual 503-1160ZE-I-13
ZP5 Mk4 Fire Alarm Control Panel (Part 5: Commissioning) 501-0865 (UD865 Part 5 Iss 3)
ZP3-ECU Extinguishing Control Unit Maintenance Manual 503-0800ZE-M-03

iv ZP3-ECU Extinguishing Control Unit Installation and Commissioning Manual
Preface
This manual is intended for use by the ZP3-ECU Extinguishing Control System
installation and commissioning personnel. It provides the information required to
configure, install and commission the Extinguishing Control System and its
relevant equipment.
Safety Issues/Limitations
Installation Criteria
Do not attempt to install, service or operate the system until this manual has
been read and understood. Adherence to the manual recommendations ensures
a problem-free installation and long-term reliability.
System Power Supplies
During installation of the system or modification to the system, the DC power
supply and batteries should be disconnected to avoid damage to circuit.
Operating Environment
Make sure that all system components and peripheral equipment are located
within the limiting environment specified.
Power Transients
As with all electronic devices, the system is susceptible to damage by lightning
induced transients. Proper grounding reduces this susceptibility.
Physical Mounting
All electronic assemblies should be removed from cabinets prior to any drilling,
filing, reaming or punching of the enclosure. Before making modifications, verify
that they will not interfere with printed circuit board location.
Wiring
All wiring must fall within the limitations given in the wiring guide, with respect to
line resistance, line capacitance and cross talk from interfering signals.
Screw Terminals
Over tightening of screw terminals can damage threads, resulting in reduced
terminal contact pressure and difficulty with screw terminal removal.
Static Sensitive Components
Printed circuit boards contain static sensitive components. Retain loose printed
circuit boards in static suppressive packing.

ZP3-ECU Extinguishing Control Unit Installation and Commissioning Manual v
System Documentation
Comprehensive drawings of the system, signed off by the responsible engineer,
must be kept on record. The system design must take into account local codes
and requirements.
Limitations
Equipment Compatibility
The Extinguishant Cylinder release mechanism must be compatible with the
Extinguishing Control Unit activating circuit. Incompatibility can cause
malfunction.
Sensing Equipment Limitations
The Extinguishing Control System equipment is reliant on external detection
equipment such as detectors, call points and fire control panels in order to
activate effective fire alarms. Incorrect positioning of the detectors, limitations in
the detector itself or incorrect application can result in failure of the detection
process.
Bells and Sirens
When the Extinguishing Control System causes an extinguishing discharge, the
appropriate fire bells and sirens sound. These could prove useless unless they
are situated in close proximity to the people they are supposed to alert.

vi ZP3-ECU Extinguishing Control Unit Installation and Commissioning Manual

ZP3-ECU Extinguishing Control Unit Installation and Commissioning Manual 1
Chapter 1
System Wiring
Summary
This chapter gives information for wiring standards, connections and mounting.
Content
Wiring Standards 2
Wiring Connections 2
ZP3-ECU Surge Protection 2
ZP Loop Wiring 3
Connection to the ZP3-ECU Extinguishing Control Unit 8
Connection of the ZP3-ECU to Extinguishing Status Units ZP3-ECUS 9

Chapter 1: System Wiring
2 ZP3-ECU Extinguishing Control Unit Installation and Commissioning Manual
Wiring Standards
All wiring must be installed in compliance with local codes, and in accordance
with the requirements of the local authority having jurisdiction.
Fire alarm systems must remain operative during the initial phase of a fire. It is
therefore important that certain wiring practices are followed, and must comply to
British Standard BS5839: Part 1: 1988: Sections 17 and 24.
All wiring must be installed to the standards laid down in Ziton wiring guide
GA322.
WARNING: The wiring connection to the extinguishant cylinder actuator is a low
impedance circuit, which can draw up to 1 A during actuation. Make sure that
wiring to the actuator is of sufficient capacity to avoid wiring resistance voltage
loss.
Wiring Connections
The following wiring connections are described:
• Extinguishing Control Unit to ZP Address Line connection
• Connections to the ZP3-ECU Extinguishing Control Unit
• Connection of ZP3-ECU Extinguishing Control Unit to ZP3-ECUS
Extinguishing Status Units
• Connection of ZP3-ECU Extinguishing Control Unit to ZP3-ECUR
Extinguishing Repeater Units.
ZP3-ECU Surge Protection
The Extinguishing Control Unit is often connected to a power source, which has
fluctuations and surges outside of the recommended operating voltage limits.
The ZP3-ECU Extinguishing Control Unit main board as shown in Figure 1
incorporates surge suppression and low voltage detection to try to compensate
for any fluctuations and surges.

Chapter 1: System Wiring
ZP3-ECU Extinguishing Control Unit Installation and Commissioning Manual 3
Figure 1: ZP3-ECU Extinguishing Control Unit Main Board
24 VDC Power
See Figure 2. The external 24 VDC power connections are provided on the main
board.
ZP Loop Wiring
ZP loop connections are provided on the main board as shown in Figure 2, and
terminals are provided for the respective loop screens. Screens must be properly
connected at the fire panel.
Figure 2: ZP Wiring Connections

Chapter 1: System Wiring
4 ZP3-ECU Extinguishing Control Unit Installation and Commissioning Manual
Earth Connection
The Extinguishing Control Unit must be connected to a secure earth. Good wiring
practice should be followed and the earth connection should be kept as short as
possible. Earth is provided on pins 25 and 26, which makes connection to the
chassis.
Figure 3: Mounting Diagram
Mounting Instructions
The Extinguishing Control Unit main board is supplied with two screws and two
spring washers for mounting into the Extinguishing Control Unit box. The earth
lug from the wiring loom must be earthed as shown in Figure 3 to ensure the
effectiveness of the surge suppression board.
See Figure 3. Mount the Extinguishing Control Unit Main Board as follows:
1. Align the main board chassis mounting slots with the lower studs of the
Extinguishing Unit box.
2. Insert the main board into the Extinguishing Unit box so that the main board
chassis rests on the studs.
3. Insert the mounting screws, spring washers and the free earth lug of the
wiring loom, and tighten screws.
Note: Do not disassemble the circuit boards from the chassis.
Guidelines to Programming the ECU
All new protected areas MUST be wired using two ZP Loops. This is to ensure
the highest level of security available against accidental discharge of
extinguishant.

Chapter 1: System Wiring
ZP3-ECU Extinguishing Control Unit Installation and Commissioning Manual 5
The two addresses assigned to the Extinguishing Control Unit MUST be at least
TWENTY apart i.e. if ECU Loop A uses address A005 then ECU Loop B can only
utilise addresses from B025 onwards. Note that any two ZP loops of the fire
panel may be used for connecting the ECU. Any addresses may be assigned to
the devices within the protected area.
The devices in a protected area must be equally divided into two-coincidence
areas/patterns, namely CA1 and CA2.
A coincidence area may consist of a single detector or many detectors,
dependent on the size of the protected area.
Diagrams 1 to 4 shown in Figure 4 represent a plan view of protected areas with
the dotted lines encompassing detectors. The dotted lines form the two required
coincidence areas/patterns CA1 and CA2, which zig-zag across the protected
area, overlapping in certain places. It can be seen therefore that due to the
coincidence pattern a fire in any part of the protected area will be as close as
possible to both coincidence areas.
The ECU has two addresses each of which is associated to its own coincidence
area/pattern. There must be a fire condition in both coincidence areas to initialise
an extinguishant drop.
If you want to program a system on a Zone basis then the coincidence coverage
patterns will inherently become fire zones i.e. CA1 becomes fire Zone 1 and CA2
becomes fire Zone 2.
If you want to program a system on a device basis then each detector in CA1 will
be associated to the first ECU address and each detector in CA2 will be
associated with the second ECU address.
The basic programming principle is that from coincidence area 1 a fire alarm will
be mapped to the first ECU address and a fire alarm from coincidence area 2 will
be mapped to the second ECU address resulting in an extinguishing drop. The
devices MUST be programmed on a SKNS (single knock non-silencing) basis for
correct operation.
Programming examples are provided on the following pages.

Chapter 1: System Wiring
6 ZP3-ECU Extinguishing Control Unit Installation and Commissioning Manual
Figure 4: Examples of Cross-pattern Detection Areas
Programming on a ZONE Basis
The Extinguishing Control Unit shown in diagram 5 of Figure 4 is configured for
its first address to be 1005 and its second address to be 2025.
Diagram 1:
• Zone 1 consists of detector 1001 (coincidence area one)
• Zone 2 consists of detector 2001 (coincidence area two)
Diagram 3:
• Zone 1 consists of detectors 1001, 1002 & 1003 (coincidence area one)
• Zone 2 consists of detectors 2001, 2002 & 2003 (coincidence area two)

Chapter 1: System Wiring
ZP3-ECU Extinguishing Control Unit Installation and Commissioning Manual 7
Both areas are programmed identically.
Input Output Mode
Zone 1 1005 (ECU FIRST ADDRESS) SKNS (Single knock non silencing)
Zone 2 2025 (ECU SECOND ADDRESS) SKNS (Single knock non silencing)
Programming on a DEVICE Basis
The Extinguishing Control Unit shown in diagram 5 of Figure 4, is configured for
its first address to be 1005 and its second address to be 2025.
Diagram 1:
• Coincidence area one consists of device 1001
• Coincidence area two consists of device 2001
Diagram 3:
• Coincidence area one consists of devices 1001, 1002 & 1003
• Coincidence area two consists of devices 2001, 2002 & 2003
Both areas are programmed in a similar manner:
Diagram 1
Input Output Mode
1001 1005 (ECU FIRST ADDRESS) SKNS (Single knock non silencing)
2001 2025 (ECU SECOND ADDRESS) SKNS (Single knock non silencing)
Diagram 3
Input Output Mode
1001 1005 (ECU FIRST ADDRESS) SKNS (Single knock non silencing)
1002 1005 (ECU FIRST ADDRESS) SKNS (Single knock non silencing)
1003 1005 (ECU FIRST ADDRESS) SKNS (Single knock non silencing)
2001 2025 (ECU SECOND ADDRESS) SKNS (Single knock non silencing)
2002 2025 (ECU SECOND ADDRESS) SKNS (Single knock non silencing)
2003 2025 (ECU SECOND ADDRESS) SKNS (Single knock non silencing)
The same format and rules apply for any protected area.
Additional Installation Information
Optional Door Monitor Board
Some Extinguishing Control systems are fitted with optional door lock monitor
boards to report the locked/unlocked status of the doors to the protected area.
This board is piggy-backed on top of the main board using the supplied
hardware.

Chapter 1: System Wiring
8 ZP3-ECU Extinguishing Control Unit Installation and Commissioning Manual
Planner and Maestro Graphics Software
When configuring Planner panel programming package, or Maestro graphics
package, for use with an Extinguishing Control Unit, the LOOP A address is
denoted by "ECU" and the LOOP B address is denoted by "LRY".
In the Maestro Graphics package, the LOOP A address reports the ECU status,
and therefore it is not necessary to allow for an icon for the "LRY" LOOP B
address.
Operation
There is a cosmetic software "bug" in the fire alarm panel. If the loop B address
of the ECU is activated before the Loop A address, the fire panel reports
"TRIGGR". The ECU is only "triggered" when both the loop A and loop B
addresses are activated by fire conditions. If the Loop A address is activated first
then the "bug" is not apparent. This "bug" in no way affects the correct operation
of the ECU.
Connection to the ZP3-ECU Extinguishing Control Unit
Terminal functions are described in the ZP3-ECM Extinguishing Control Main
Board installation sheet, document number 501-0803ZE-1-01 included in
Appendix A of this manual. The connection wiring is shown in Figure 5.

Chapter 1: System Wiring
ZP3-ECU Extinguishing Control Unit Installation and Commissioning Manual 9
Figure 5: Wiring Connection - Extinguishing Control Unit ZP3-ECU
Connection of the ZP3-ECU to Extinguishing Status
Units ZP3-ECUS
The terminal functions are described in the ZP3-ESM Extinguishing Status Main
Board installation sheet, document number 501-0805ZE-1-01, which is included
in Appendix A of this manual. The connection wiring to the Extinguishing
Status/Repeater Units is shown in Figure 6.

Chapter 1: System Wiring
10 ZP3-ECU Extinguishing Control Unit Installation and Commissioning Manual
Figure 6: Connection Wiring to Extinguishing Status/Repeater Units

ZP3-ECU Extinguishing Control Unit Installation and Commissioning Manual 11
Chapter 2
Physical Installation
Summary
This chapter gives installation information.
Content
Extinguishing Control Unit 12
Installation Procedure 12
Extinguishing Control Door Monitor Board (Optional) 13

Chapter 2: Physical Installation
12 ZP3-ECU Extinguishing Control Unit Installation and Commissioning Manual
Extinguishing Control Unit
We recommend that the Extinguishing Control Unit is located outside the
protected area in close proximity to the exit and to the extinguishant cylinders. If
this is not possible, then the above warning regarding impedance of the actuator
line must be taken into account. The control devices in the protective area, such
as sounders, are connected directly to the Extinguishing Control Unit.
WARNING: The wiring connection to the extinguishant cylinder actuator is a low
impedance circuit, which can draw up to 1 a during ACTUation. Make sure that
wiring to the actuator is of sufficient capacity to avoid wiring resistance voltage
loss.
The Extinguishing Control Unit is designed to be either surface mounted or
recessed semi-flush into a wall as shown in Figure 7.
Figure 7: Mounting Arrangements
Note: The Extinguishing Status Units and Extinguishing Repeater Units are
mounted the same way.
Installation Procedure
Install the Extinguishing Control Unit as follows:
1. Unlock and open the front panel with the key provided.
2. Disconnect the front panel by unplugging the ribbon cable connector on the
main PCB.
