1 Product Introduction
CMP-200 series automatic barrier gate is a new barrier gate product combined with
the practical application of automatic barrier gate products in the industry. Its
appearance and structure design follows the needs of the market and industry, and
the traffic light indication has the humanized experience. As an economical
automatic barrier gate product, users can match the telescopic straight boom
according to the actual needs to meet different application scenarios.
2 Appearance and Dimensions

2
3 Parameters
Power adaptability
Input voltage AC 220V/110V±20%, 50/60Hz
Rated power
100W
Max power
120W
Remote control
distance
Open field≤30m
Remote control
frequency
433MHZ, Learning code
Chassis material
Cold gadolinium steel plate
Boom material
Aluminum
Working
temperature
-25℃~+75℃

3
Working humidity
<90%RH (no condensation)
Protection grade
IP54
Shell size (W*D*H)
1010*350*280 (mm)
Package size
(W*D*H)
1100*375*430 (mm)
Chassis net weight
45KG
Chassis gross
weight
47KG
Boom type
Telescopic straight boom, boom length≤4.5m, red and
white color, the rise/fall speed is 3s
Telescopic straight boom, boom length: 4.5m~6m, red and
white color, the rise/fall speed is 6s
4 Functions
1. The opening and closing angle is 90°±2°.
2. Up, down and stop interfaces with standard switch input.
3. Anti-smash function: with loop detector, infrared detector and pressure wave
functions, prevent car smashing.
4. Controller timeout protection: when the boom operation is abnormal and

4
exceeds the rise and fall time, the boom will stop operation automatically.
5. The barrier gate can be controlled by wireless remote control and wired
control button to meet the needs of different field applications.
6. It supports traffic lights with AC voltage, and DC voltage of 5V or 12V.
5 Movement Transmission Structure

5
6 Control Board Wiring Installation
1. Remove the wiring cover of the barrier gate main controller. As shown below:
2. The installation size of the control board in the barrier gate chassis is as follows
(unit: mm).
Take up

6
3. Refer to the wiring diagram of the barrier gate controller and connect the lines
one by one firmly. (Note: Power must be disconnected before installation or
maintenance.)
4. After checking and confirming reliable wiring, install the wiring cover back.
5. Install the desktop remote control. Place the desktop remote control on the
desk in the guard room or attach it to the wall and plug in power.
6. The wiring diagram of the controller is as follows:

7

8
7 Commisioning Instructions
1. Check all the connections and make sure the connections are correct before
connecting the power.
2. Press the“Up”button of the desktop remote control or “ ”on the remote
control handle, the boom will rises and stops automatically after the rising limit.
If the running direction is opposite, adjust the rise and fall wiring of the motor.
3. Press the "Down" button of the desktop remote control or " " on the remote
control handle, the boom will falls and stops automatically after the falling limit.
In the process of falling, press the "Up" button of the desktop remote control or
“”on the remote control handle to rise the boom.
4. In the process of rising and falling, press the "Stop" button of the desktop
remote control or “ ”on the remote control handle to suspend the operation
of the boom. Warning: To avoid accidents, no one is allowed to stand
under the boom during debugging.
5. In the process of boom falling, short connect the infrared detector and public
interface, the falling boom is transferred to rising immediately, which will stop
automatically after the rising limit.
6. In the process of boom falling, short connect the loop detector and public
interface, the falling boom is transferred to rising immediately, which will fall
automatically after the rising limit and stop automatically after the falling limit.

9
In the process of boom rising, short connect the loop detector and public
interface, the boom will fall automatically after the rising limit and stop
automatically after the falling limit. In other states (except the falling limit), short
connect the loop detector and public interface, the boom will automatically fall
to the limit.
7. Barrier gate Hall limit switch adjustment:
8. Left and right movement interchange method:

10
9. Barrier gate spring and boom length type matching:
8 Instructions
1. Up button
In the stop state, press the "Up" button of the desktop remote control or " " on the
remote control handle to rise the boom. In the process of boom falling, press the
"Up" button of the desktop remote control or " " on the remote control handle to
immediately rise the boom.
2. Down button
In the stop state, press the "Down" button of the desktop remote control or " " on
the remote control handle, and the boom will fall. In the process of boom rising,
pressing the "Down" button of the desktop remote control or " " on the remote
control handle is invalid.
3. Stop button
In the operation state of boom rising and falling, press the "Stop" button of the

11
desktop remote control or " " on the remote control handle to stop the boom.
4. Study/delete remote control code
Study code: In the stop state, press the“Study”button on the main controller until
the REMOTE indicator is on then release it, press any button on the remote control,
the REMOTE indicator is off, and the code studying is completed.
Delete code: In the stop state, press the“Study”button on the main controller until
the REMOTE indicator is on, continue to press and hold the“Study”button until the
REMOTE indicator is off, and the code deletion is completed. (Note: All codes are
deleted.)
9 Troubleshooting
No.
Troubles
Fault cause
Solution
1
The POWER indicator is not on,
the button is not responding.
1. The power supply is
not connected.
2. The fuse blew.
1. Connect the
power.
2. Replace the
fuse.
2
The POWER indicator is on, no
response by remote control.
1. Remote control
code is wrong.
2. Poor receiving
module.
1. Recode.
2. Replace
receiving module.
3. Change other

12
3. Same frequency
interference exists.
frequency.
3
The POWER indicator is on,
boom UP and DOWN indicator
is normal, the motor is not
running.
1. The motor wire is
open or connected
incorrectly.
2. Motor is stuck.
1. Connect the
motor wire.
2. Manual release
motor.
4
Unable to rise or fall boom to
limit.
1. The limit line is
misconnected.
2. Limit switch broken.
1. Reconnect the
rising and falling
limit line.
2. Replace limit
switch.
5
Remote control handle is not
responding.
1. The battery of the
handle is low.
2. Handle broken.
1. Replace battery.
2. Replace the
handle.
