ZKTeco CMP-200 Series User manual

Product Name and Model Number User Manual
Page | 1 Copyright©2020 ZKTECO CO., LTD. All rights reserved.
Thank you for choosing our product. Please read the instructions carefully
before operation. Follow these instructions to ensure that the product is
functioning properly. The images shown in this manual are for illustrative
purposes only.
For further details, please visit our Company’s website
www.zkteco.com.
User Manual
CMP-200
Date: June 2020
Doc Version: 1.1
English

CMP-200 User Manual
Page | 1 Copyright©2020 ZKTECO CO., LTD. All rights reserved.
Copyright © 2020 ZKTECO CO., LTD. All rights reserved.
Without the prior written consent of ZKTECO CO., LTD, no portion of this
manual can be copied or forwarded in any way or form. All parts of this manual
belong to ZKTeco and its subsidiaries (hereinafter the "Company" or "ZKTeco").
Trademark
is a registered trademark of ZKTECO CO., LTD. Other trademarks
involved in this manual are owned by their respective owners.
Disclaimer
This manual contains information on the operation and maintenance of the
ZKTeco product. The copyright in all the documents, drawings, etc. in relation
to the ZKTeco supplied product vests in and is the property of ZKTeco. The
contents hereof should not be used or shared by the receiver with any third
party without express written permission of ZKTeco.
The contents of this manual must be read as a whole before starting the
operation and maintenance of the supplied product. If any of the content(s) of
the manual seems unclear or incomplete, please contact ZKTeco before
starting the operation and maintenance of the said product.

CMP-200 User Manual
Page | 2 Copyright©2020 ZKTECO CO., LTD. All rights reserved.
It is an essential pre-requisite for the satisfactory operation and maintenance
that the operating and maintenance personnel are fully familiar with the
design and that the said personnel have received thorough training in
operating and maintaining the machine/unit/product. It is further essential for
the safe operation of the machine/unit/product that personnel have read,
understood and followed the safety instructions contained in the manual.
In case of any conflict between terms and conditions of this manual and the
contract specifications, drawings, instruction sheets or any other contract-
related documents, the contract conditions/documents shall prevail. The
contract specific conditions/documents shall apply in priority.
ZKTeco offers no warranty, guarantee or representation regarding the
completeness of any information contained in this manual or any of the
amendments made thereto. ZKTeco does not extend the warranty of any kind,
including, without limitation, any warranty of design, merchantability or
fitness for a particular purpose.
ZKTeco does not assume responsibility for any errors or omissions in the
information or documents which are referenced by or linked to this manual.
The entire risk as to the results and performance obtained from using the
information is assumed by the user.

CMP-200 User Manual
Page | 3 Copyright©2020 ZKTECO CO., LTD. All rights reserved.
ZKTeco in no event shall be liable to the user or any third party for any
incidental, consequential, indirect, special, or exemplary damages, including,
without limitation, loss of business, loss of profits, business interruption, loss
of business information or any pecuniary loss, arising out of, in connection
with, or relating to the use of the information contained in or referenced by
this manual, even if ZKTeco has been advised of the possibility of such
damages.
This manual and the information contained therein may include technical,
other inaccuracies or typographical errors. ZKTeco periodically changes the
information herein which will be incorporated into new
additions/amendments to the manual. ZKTeco reserves the right to add,
delete, amend or modify the information contained in the manual from time
to time in the form of circulars, letters, notes, etc. for better operation and
safety of the machine/unit/product. The said additions or amendments are
meant for improvement /better operations of the machine/unit/product and
such amendments shall not give any right to claim any compensation or
damages under any circumstances.
ZKTeco shall in no way be responsible (i) in case the machine/unit/product
malfunctions due to any non-compliance of the instructions contained in this
manual (ii) in case of operation of the machine/unit/product beyond the rate
limits (iii) in case of operation of the machine and product in conditions
different from the prescribed conditions of the manual.

CMP-200 User Manual
Page | 4 Copyright©2020 ZKTECO CO., LTD. All rights reserved.
The product will be updated from time to time without prior notice. The latest
operation procedures and relevant documents are available on
http://www.zkteco.com
If there is any issue related to the product, please contact us.
ZKTeco Headquarters
Address ZKTeco Industrial Park, No. 26, 188 Industrial Road,
Tangxia Town, Dongguan, China.
Phone +86 769 - 82109991
Fax +86 755 - 89602394
For business related queries, please write to us at: [e-mail].
To know more about our global branches, visit www.zkteco.com.
About the Company
ZKTeco is one of the world’s largest manufacturer of RFID and Biometric
(Fingerprint, Facial, Finger-vein) readers. Product offerings include Access
Control readers and panels, Near & Far-range Facial Recognition Cameras,
Elevator/floor access controllers, Turnstiles, License Plate Recognition (LPR)
gate controllers and Consumer products including battery-operated
fingerprint and face-reader Door Locks. Our security solutions are multi-
lingual and localized in over 18 different languages. At the ZKTeco state-of-
the-art 700,000 square foot ISO9001-certified manufacturing facility, we
control manufacturing, product design, component assembly, and
logistics/shipping, all under one roof.

CMP-200 User Manual
Page | 5 Copyright©2020 ZKTECO CO., LTD. All rights reserved.
The founders of ZKTeco have been determined for independent research and
development of biometric verification procedures and the productization of
biometric verification SDK, which was initially widely applied in PC security
and identity authentication fields. With the continuous enhancement of the
development and plenty of market applications, the team has gradually
constructed an identity authentication ecosystem and smart security
ecosystem, which are based on biometric verification techniques. With years
of experience in the industrialization of biometric verifications, ZKTeco was
officially established in 2007 and now has been one of the globally leading
enterprises in the biometric verification industry owning various patents and
being selected as the National High-tech Enterprise for 6 consecutive years. Its
products are protected by intellectual property rights.
About the Manual
This manual introduces the operations of CMP-200 product.
All figures displayed are for illustration purposes only. Figures in this manual
may not be exactly consistent with the actual products.

CMP-200 User Manual
Page | 6 Copyright©2020 ZKTECO CO., LTD. All rights reserved.
Document Conventions
Conventions used in this manual are listed below:
GUI Conventions
For Software
Convention Description
Bold font Used to identify software interface names e.g. OK, Confirm, Cancel
> Multi-level menus are separated bythese brackets. For example, File >
Create > Folder.
For Device
Convention Description
< > Button or key names for devices. For example, press <OK>
[ ] Window names, menu items, data table, and field names are inside
square brackets. For example, pop up the [New User] window
/ Multi-level menus are separated by forwarding slashes. For example,
[File/Create/Folder].
Symbols
Convention Description
This implies about the notice or pays attention to, in the manual.
The general information which helps in performing the operations
faster.
The information which is significant.
Care taken to avoid danger or mistakes.
The statement or event that warns of something or that serves as a
cautionary example.

CMP-200 User Manual
Page | 7 Copyright©2020 ZKTECO CO., LTD. All rights reserved.
Table of Contents
1PRODUCT INTRODUCTION...................................................................8
2WHAT IS IN THE BOX .............................................................................8
APPEARANCE AND DIMENSIONS...........................................................................................9
3PRODUCT INSTALLATION...................................................................10
INSTALLATION PRECAUTIONS ............................................................................................. 10
CABLE EMBEDDING............................................................................................................. 10
BOOM INSTALLATION .......................................................................................................... 11
4TECHNICAL PARAMETERS..................................................................12
5FUNCTIONS .........................................................................................13
6MOVEMENT TRANSMISSION STRUCTURE.........................................14
7CONTROL BOARD WIRING INSTALLATION ........................................15
8COMMISSIONING INSTRUCTIONS......................................................19
9TROUBLESHOOTING...........................................................................22

CMP-200 User Manual
Page | 8 Copyright©2020 ZKTECO CO., LTD. All rights reserved.
1Product Introduction
The Automatic Barrier Gate CMP-200 series is a modern barrier gate
technology combined with the practical implementation of automated barrier
gate products in the industry. This product’s appearance and structure design
are adapted to the market, and the industry requirements and the traffic light
indication has the humanized experience. As an economical automatic barrier
gate device, the user can adjust the telescopic straight boom according to the
actual requirement to meet various application scenarios.
2What is in the box
The box comes with;
•The barrier gate*1
•The boom*1
•The remote control*2
•The barrier fixed screw*4
•The boom fixed plate*1
•The boom fixed screw*2
•The key*2
•The user manual*1

CMP-200 User Manual
Page | 9 Copyright©2020 ZKTECO CO., LTD. All rights reserved.
Appearance and Dimensions
Left and Right Cabinet View
L: The cabinet on the left R: The cabinet on the right

CMP-200 User Manual
Page | 10 Copyright©2020 ZKTECO CO., LTD. All rights reserved.
3Product Installation
Installation Precautions
•Install the parking barrier on level ground. If the ground is not firm and
steady, then a cement base is required before installation.
•The boom can be cut, but cannot be increased. Cut the boom to the
required length, and then set the spring to balance and achieve the new
height. Two plastic nuts that lie in the bottom of the spring is designed
for adjusting the new balance.
•Do not change the wire connection inside when the power is on.
•The GND should be connected to the cabinet for secure protection.
Cable Embedding
•Prepare φ25 protective sleeve and cable in advance.
•Route the cables to be connected through the protective sleeves.
•Use a tool to open the cable board in the ground.
Control
room
Screw pad
Ground
Cabinet
Expansion bolt
4-M12
Ground
Base concrete
A standard power wire RVV3*1.0
Signal line RVV4*0.5
The power wire is wrapped
and protected using the
wire sleeve when laid out
under the ground (the
strong current should be
separated from the weak
current)

CMP-200 User Manual
Page | 11 Copyright©2020 ZKTECO CO., LTD. All rights reserved.
Boom Installation
Boom Installation Procedure
•Pull the barrier arm out from the main boom, and then fasten it with 2
screws as shown in Figure 1.
Figure 1 Connect the main boom with vice together by 2 screws
•Install the boom to the chassis (the frame), as shown in Figure 2.
Figure 2 Installing the Boom to the Chassis

CMP-200 User Manual
Page | 12 Copyright©2020 ZKTECO CO., LTD. All rights reserved.
4Technical Parameters
Power adaptability Input voltage AC 220V/110V±20%, 50/60Hz
Rated power 100W
Max power 120W
Remote control
distance Open field≤30m
Remote control
frequency 430MHZ, Learning code
Chassis material Cold gadolinium steel plate
Boom material Aluminum
Working
temperature -25℃~+75℃
Working humidity <90%RH (no condensation)
Protection grade IP54
Shell size (W*D*H) 1010*350*280 (mm)
Package size
(W*D*H) 1100*375*430 (mm)
Chassis net weight 45KG
Chassis gross
weight 47KG
Boom type
(The mainboard is
the same)
Telescopic straight boom, boom length≤4.5m, red
and white color, the rise/fall speed is 3s
Telescopic straight boom,
boom length: 4.5m~6m,
red and white color, the rise/fall speed is 6s

CMP-200 User Manual
Page | 13 Copyright©2020 ZKTECO CO., LTD. All rights reserved.
5Functions
•The opening and closing angles are 90°±2°.
•Up, Down and Stop operations interfaced with standard switch input.
•Anti-smash function: Supports loop detector, infrared detector, and
radar functions.
•Controller timeout protection: When the boom operation is abnormal
and exceeds the rise and fall time, the boom will stop the operation
automatically.
•The barrier gate can be controlled by wireless remote control and wired
control buttons to meet the needs of different field applications.
•It supports traffic lights with AC voltage and DC voltage of 5V or 12V.
•Mainboard built-in fuse, secure from overvoltage.
•Supports the connection of LPR, UHF reader controller, and other devices
to recognize and control the automatic door opening.

CMP-200 User Manual
Page | 14 Copyright©2020 ZKTECO CO., LTD. All rights reserved.
6Movement Transmission Structure

CMP-200 User Manual
Page | 15 Copyright©2020 ZKTECO CO., LTD. All rights reserved.
7Control Board Wiring Installation
•Remove the wiring cover of the barrier gate main controller.
•Refer to the wiring diagram of the barrier gate controller and connect the
lines one by one firmly. (Note: Power must be disconnected before
installation or maintenance.)
•After checking and confirming reliable wiring, install the wiring cover
back.
•Install the Desktop Remote Control: Place the Desktop Remote Control on
the table in the guard room or attach it to the wall and plug-in the power.
The wiring diagram of the controller is as follows:

CMP-200 User Manual
Page | 16 Copyright©2020 ZKTECO CO., LTD. All rights reserved.

CMP-200 User Manual
Page | 17 Copyright©2020 ZKTECO CO., LTD. All rights reserved.
•Connect to the LPR camera:
•Connection with the UHF controller.
Note: The Reader1 and 2 of the inbio260 controller are corresponding to
LOCK1, Reader3, and 4 are corresponding to LOCK2.

CMP-200 User Manual
Page | 18 Copyright©2020 ZKTECO CO., LTD. All rights reserved.
•Connection with the loop detector.
•Connection with the infrared detector

CMP-200 User Manual
Page | 19 Copyright©2020 ZKTECO CO., LTD. All rights reserved.
8Commissioning Instructions
1. Check all the connections and make sure the connections are correct
before connecting the power.
2. Please use the remote control or press the switch button on the
mainboard to test whether the machine is running normally.
3. Warning: Be sure to install the corresponding length of the boom before
the power-on test. To avoid accidents, no one is allowed to stand under
the boom during testing.
4. In the process of boom falling, short connect the infrared detector and
public interface, so that the falling boom will start rising immediately, and
will stop automatically after the rising limit. This is mimic the effect of
infrared detectors.
5. In the process of boom falling, short connect the loop detector and public
interface, the falling boom is transferred to rising immediately, which will
fall automatically after the rising limit and stop automatically after the
falling limit. In the process of boom rising, short connect the loop
detector and public interface, the boom will fall automatically after the
rising limit and stop automatically after the falling limit. In the open state,
short connect the loop detector and public interface; the boom will
automatically fall to the limit and stop. This imitates the effect of the loop
detector.
