ZOJE ZJ20U Series User manual

QD629 Control panel manual

Safety instructions
1. Users should read the instruction manual completely and carefully before installation or
operation.
2. The product must be installed and pre-operated by well-trained personnel.
3. All instructions marked must be followed or followed, otherwise Injuries may occur.
4. To ensure perfect performance and safety, please do not use an extension cable with
multiple sockets for connection to power supply.
5. When connecting power cords to power sources, ensure that the supply voltage is less
than 250 VAC and matches the rated voltage indicated on the motor nameplate.
※Attention: If the control box has 220V AC system, do not connect
The control box is connected to a 380V AC outlet. Otherwise, an error will occur and the
motor will not run. If this happens, immediately turn off the power and check the supply
voltage.
6. Do not work in direct sunlight, outdoors or indoor temperatures above 45°C or below 5°C.
7. Avoid working near the heater when equipment or humidity is below 30% or above 95%.
8. Do not work in places with heavy dust, corrosive substances or volatile gases.
9. Avoid exposing the power cord to heavy objects, excessive force, or excessive bending.
10. The power cord ground wire must be connected to the manufacturing facility ground
using appropriately sized wires and terminals. This connection must be securely fastened.
11. All moving parts must be protected from the intended parts.
12. After turning on the machine for the first time, turn on the sewing machine at low speed
and check the correct direction of rotation.
13. Turn off the power before the following operation:
a) Connect or disconnect any connectors on the control unit or motor.
b) Filling needle.
c) Raising the machine head.
d) Repair or make any mechanical adjustments.
d) Machine downtime.
14.Repairs and maintenance work must only be carried out by suitably trained electronics
technicians.
15. All repair parts must be provided or approved by the manufacturer.
16. Do not use any object or force to hit or ram the product.

1.ButtonDisplaysandoperatinginstructions
1.1 KeyDescription
Functionkey
enterparameter
area
Undernormalmode,pressthe[P]keytoentertheuserparametermode
Pressandholdthe[P]keytobootintoparametermodeTechnician
Enterand
determine\save
button
Enterparametervalues such items and theircontents change after
adjustment,needtopressthe[S]keytosavetheconfirmation.Note:The
parametersaresaveddirectlybythe[S]key.
1.Choosetheregionparameteritemsincrementingkey
2.Parametersettingvalueincrementingkey
3.Selecttheshortcutneedleposition
1.Choosetheregionparameteritemsofdiminishingkey
2.Isdecrementedkeyparametersettings
3.Slowplayseamselectionshortcuts
2 UserParameter&TechnicianParameter
Parameter ParameterFunction Range Default Description
Inthenormalscreen,press[P]
P01 MaximumSewingSpeed
（r/S）100-3700 3700 Maximumspeedofmachinesewing
P02 SpeedCurveAdjustment（%）1-100 80 TheLagerthevalue,thefastertoincrease
speed
P03 NeedleUP/DOWN UP/DN DN UP:NeedleStopsatUpPosition
DN:NeedleStopsatDownPosition
P07 SoftStartSpeed（r/S）200-1500 400 SoftStartSpeedAdjustment
P08 StitchNumbersforSoftStart 0-99 2SoftStartStitchesSetting(oneunit=half
stitch)
P14 SoftStart ON/OFF ON ON:Slowstartfeatureisturnedon. OFF:
Slowstartfunctionoff.
P15 Makeuppinmode 0-3 00:Semi-pin；1:apin2：Continuousfilling
halfneedle3：Continuousinjection
P24 Footpedalreversevoltage 30-500 120
P30 Thickmaterialangle 0-100 0
P42 InformationDisplay N01-N07
NO1 Electricallycontrolledversionserial
numbers
NO2 Selectedneedlecassetteversion
NO3 Speed
NO4 PedalsAD,
NO5 Positioningangle(0--359),
NO6 Underthepositioningangle
UP / Needle
positinon
DOWN /
Soft start

ParameterFunction
Range
Description
NO7 BusvoltageAD
P43
SettingDirectionofMotor
Rotation
CCW/CW
CCW
CW：Clockwise
CCW：CounterClockwise
Pressandholdthe[P]keytoboot
P44
Brakeforce
1-50
16
Effortstostopthemachinewhenselecting
P48
Low(Positioning)Speed
（r/S）
100-500
210
SettingPositioningSpeed
P56
NeedlesGoesUp
AutomaticallyasPower
turnedon
0-2
1
0:alwaysnottofindaposition
1：:alwayslookingforpositioning
2：Ifthemotorispositionedontheno
longerfind location (only with magnet
motor)
P58
UpPositionAdjustment
0-1439
40
UpPositionAdjustment
Theneedlewilladvancestopwhenthe
valuedecreased.
Theneedlewilldelaystopwhenthevalue
increased.
P59
DownPositionAdjustment
0-1439
720
DownPositionAdjustment
Theneedlewilladvancestopwhenthe
valuedecreased.
Theneedlewilldelaystopwhenthevalue
increased.
P60
TestingSpeed（r/S）
100-3700
2000
Settingtestingspeed.
P61
TestingA
ON/OFF
OFF
OptionofTestingA,aftersettingpress
【060.TV】tosetthespeedkeeprunning.
P62
TestingB
ON/OFF
OFF
OptionofTestingB,aftersettingpress
【060.TV】tosetthespeedexecutethe
cycleofStart–Sewing–Stop-Trimming
P63
TestingC
ON/OFF
OFF
OptionofTestingC,aftersettingpress
【060.TV】tosetthespeedexecutethe
cycleofStart–Sewing–Stopwithout
positioningfunction
P64
RunningTimeofTestingB
andC
1-250
20
SettingrunningtimeoftestingBandC
P65
StopTimeofTestingBandC
1-250
20
SettingstoptimeoftestingBandC
P66
MachineProtectionSwitch
Testing
0-2
1
0：Disable，1：Testingzerosignal，2：
Testingpositivesignal
P67
TrimmingProtectionSwitch
Testing
ON/OFF
OFF
OFF：Disable ON：Enable
Pressandholdthe[P],[S]keywhiletheboot
P70
ThefactoryTypeSelection
27
P72
The needle position
correction
0-1439
0
Hand rotation manualto theappropriate
position,pressSkeytosave
Parameter Default

ParameterFunction Range Description
P73 Underneedleposition
correction 0-1439 0 Hand rotation manualto theappropriate
position,pressSkeytosave
P84 Thickstartangle 0-330 9
P85 Thethickendangle 0-330 57
P92 Encoderstartangle 160 Viewmanual1.5chapter
3 ErrorCodeList
ErrorCode Problem Strategies
E01
1)PowerON,themainvoltagedetectionistoo
high
2)Whenthesupplyvoltageistoohigh
Turnoffthesystem powersupply,anddetect
whetherthesupplyvoltageiscorrect. (Or
exceedtheratedvoltagespecifiedinuse.)
Ifcorrect,pleasereplacethecontrolboxand
informthefactory
E02
1)PowerON,themainvoltagedetectionistoo
high
2)Whenthesupplyvoltageistoohigh
Turnoffthesystem powersupply,anddetect
whetherthesupplyvoltageiscorrect. (Or
exceedtheratedvoltagespecifiedinuse.)
Ifcorrect,pleasereplacethecontrolboxand
informthefactory
E03 Operation panel and CPU transmission
communicationexception
Turn off the system power,check the
operationpanelinterfaceisloose
If contact is good,please change the
operationpanel.
Ifitis notoperated,the controlbox is
damaged,pleasechange
E05 Controlofthecontactofthedevice
Offthe system powersupply,check and
controltheconnectorislooseorfalloff,Will
resumenormalaftertherestartsystem
Ifyou stillcan notworknormally,please
replacethespeedcontrollerandnotifythe
manufacturer.
E07
a)Motorplugwiringcontactisnottransferred
b) Lockheadormotorbeltforeignbodyinthe
carddie
c) Themachineistoothick,themotortorqueis
notenough.
d) Moduledrivenoutputexception
Rotatingheadmotorhandwheelobservation
isstuckIfstuck,thefirstruleoutmechanical
failure
Such asrotation normalCheckthemotor
encoderconnectorandmotorpowercable
jointsareloose
Ifthereisaloosepleaserevise
Such as good contactCheck the supply
voltageofthepowersupplyvoltageistoo
highortoohighIfyouhavetoadjustAs
normal,pleasereplacethecontrolboxand
notifythemanufacturer.
Parameter Default

E9
E11Synchronizersignalerror.
Poweroffsystem Checkthemotorencoder
interfaceislooseoroffWillresumenormal
aftertherestartsystem
Ifyoustillcannotworknormally,please
informthefactoryandreplacethemotor.
E14 Encodersignalexception
Turnoffthesystem poweCheckthemotor
encoderinterfaceislooseoroffWillresume
normalaftertherestartsystemIfyoustillcan
notworknormally,pleasereplacethemotor
andnotifythemanufacturer.
E15 Powermoduleisnotnormalovercurrent
protection
Turnoffthesystempower,andthenrestartIf
youstillcannotworknormally,pleaseinform
thefactoryandreplacethemotor.
E17 Headprotectionswitchisnotinthecorrect
position
Turnoffthesystempower,checkthenoseis
opened,theheadswitchisdamaged.
E20 Motorstartingfailure Afterdrivingthemotordoesnotrotate,donot
lookfortheencoderreferencepoint
4.PortOutlineDiagram
