Zoom H2next User manual

Quick Guide
You must read the Usage and
Safety Precautions before use.
© 2020 ZOOM CORPORATION
Copying or reprinting this manual in part or in whole without permission is prohibited.
Product names, registered trademarks and company names in this document are the property of
their respective companies.
All trademarks and registered trademarks in this document are for identification purposes only and
are not intended to infringe on the copyrights of their respective owners.
You might need this manual in the future. Always keep it in a place where you can access it easily.
The contents of this manual and the specifications of the product could be changed without notice.
The Operation Manual can be downloaded from the ZOOM website (www.zoom.
jp/docs/h2n).
This page has files in PDF and ePub formats.
The PDF file format is suitable for printing on paper and reading on a computer.
The ePub format can be read with electronic document readers and is designed
for reading on smartphones and tablets.

Part names
02
Part names
MS stereo mic
XY stereo mic
Speaker
Recording
indicator
Record button
Volume control
USB port
Headphones
/LINE OUT jack
LINE IN jack for
mic/line input
(can provide
plug-in power)
Remote control
jack (Remote
control sold
separately)
Left side Front

Part names
03
H2n Handy Recorder
Part names
Bottom
MENU button
MIC GAIN dial
Adjusts mic
input gain
Power
/HOLD switch
Strap attachment
(Use to prevent dropping)
PLAY control
Press to play/pause
(in menu, set item)
Shift up/down to search
forward/backward
(in menu, select item)
Battery
compartment
cover
Recording mode
selection dial
XY mic indicator Lights when
the XY mic (front) is ON.
Flashes when the input signal is
distorting.
MS mic indicator Lights
when the
MS mic (rear) is ON.
Flashes when the input
signal is distorting.
SD card slot cover
Tripod mounting socket
Right side To p

Preparation Powering the recorder
04
NOTE
· Use alkaline or nickel-metal hydride batteries.
· If the “Low battery!” warning appears, turn the power OFF
soon and put in new batteries.
· Use MENU > SYSTEM > BATTERY TYPE to set the type of
battery so that the amount of remaining battery charge can
be shown accurately.
Preparation
Powering the recorder
1. Turn the power OFF, and then remove the battery cover.
1. Connect the cable to the USB port.
3. Close the cover.
2. Insert batteries.
2. Plug the adapter into a power outlet.
Using batteries
Using an AC adapter (sold separately)
Press here
and slide down

Preparation Installing an SD card
05
H2n Handy Recorder
Installing an SD card
1. After turning the power OFF, open the SD card slot cover.
2. Insert the card into the slot.
To remove a card, push it further into
the slot and then pull it out.
HINT
Built-in memory
· The built-in memory only keeps the most recent recording.
· The recording format is fixed at 96kbps MP3.
· It cannot be used to record in 4ch surround or MS-RAW modes.
· Recording time is limited to 1 minute.
· Recordings saved to the built-in memory cannot be copied to an SD card or a computer.
NOTE
· Be sure to insert the SD card correctly, using the cut-off corner illustration next to the
slot as a guide.
· The built-in memory will be used if no SD card is in the recorder.
· Before using SD cards that have just been purchased or that have been formatted on a
computer, they must be formatted by the . To format an SD card, use MENU >
SD CARD > FORMAT.

Preparation Turning the power ON and OFF
06
HINT
Slide toward HOLD to disable the keys and prevent
misoperation during recording.
Turning the power ON and OFF
1. Slide down.
Turning the power ON
NOTE
· If “No SD card!” appears, confirm that an SD card is
correctly inserted into the recorder.
· If “Card Protected” appears, SD card write
protection is ON. Turn write protection OFF by
sliding the “Lock” switch on the card.
· If “Invalid card” appears, the card format is
incorrect. Use a different card or format the card.
1. Slide down and hold it until “Goodbye
see you!” appears on the screen.
Turning the power OFF

Preparation Setting the date and time
07
H2n Handy Recorder
Setting the date and time
1. Press .
2.
Use to select SYSTEM, and then press .
3. Use to select DATE/TIME, and then
press .
5. Use to select OK, and then press .
The date and time is added to recording files automatically, so set it correctly
whenever the batteries are replaced.
4. Adjust the settings.
Use to move the cursor
Press to select the item
Use to change the value
Press to confirm the setting

Preparation Display
08
Display
Home (recording) screen
Recording modeRecording mode
(File name shown during recording)
Recording time
LINE IN jack in
use indicator
Recording format
(WAV example)
(MP3 example)
Recording level
(Appearance in 4ch surround mode)
MS mic recording level
XY mic recording level
LO CUT
indicator
COMP/LIMITER
indicator
AUTO GAIN/AUTO REC indicator
(When AUTO REC enabled)
Remaining
battery level
indicator
Full
Empty
Clipping
indicator
Side level adjustment
(When set to MS-RAW)
Remaining recordable time
(When using built-in memory)
Playback time
Playing
(Playback paused)
Playback level
(Appearance in 4ch surround mode)
Playback speed Key control Side mic level
Mixer
(when in 4ch surround mode)
AB repeat
File name

Preparation Display
09
H2n Handy Recorder
Display
Playback screen
Recording modeRecording mode
(File name shown during recording)
Recording time
LINE IN jack in
use indicator
Recording format
(WAV example)
(MP3 example)
Recording level
(Appearance in 4ch surround mode)
MS mic recording level
XY mic recording level
LO CUT
indicator
COMP/LIMITER
indicator
AUTO GAIN/AUTO REC indicator
(When AUTO REC enabled)
Remaining
battery level
indicator
Full
Empty
Clipping
indicator
Side level adjustment
(When set to MS-RAW)
Remaining recordable time
(When using built-in memory)
Playback time
Playing
(Playback paused)
Playback level
(Appearance in 4ch surround mode)
Playback speed Key control Side mic level
Mixer
(when in 4ch surround mode)
AB repeat
File name

Recording Recording mode overview
10
The has four recording modes that can be selected according to your
purposes.
Mid-side (MS) stereo mode
This mode uses a mid mic to capture the sound
directly ahead and a bidirectional side mic to
capture sound from left and right.
The recording level of the side mic (S level) can
be adjusted, allowing the stereo width to be
changed. If you record with the S level set to
MS-RAW, you can also adjust the S level after
recording.
MS mics can capture a rich stereo image, so it is ideal for recording sounds in
wide and open conditions, including orchestras, live concerts and soundscapes.
XY stereo mode
This mode records in stereo with mics at 90º angles.
This allows a natural, deep and accurate sound image
to be captured, making it optimal for recording
sources nearby, including solo performances,
chamber music, interviews, live rehearsals and field
recordings.
Recording mode overview
Recording
L R
Side
(Adjustable)
Display
(front) side
Mid
Display
(front) side
LR
90°

Recording Recording mode overview
11
H2n Handy Recorder
Recording mode overview
2ch and 4ch surround modes
Sound can be captured in all directions using
both MS and XY mics.
You can select 2ch, which mixes the signals
from the MS and XY mics, or 4ch, which
records the signals from the MS and XY mics
separately.
With 4ch surround, you can adjust the balance
between the MS and XY signals after recording.
The S level can be adjusted for both 2ch and
4ch recordings.
These modes are suitable for recording live
rehearsals, studio sessions, business meetings and soundscapes, for example.
L
LR
R
Mid
Side
(adjustable)
90°
Display
(front) side

Recording Selecting the recording mode
12
Selecting the recording mode
1. Turn so that the triangle points to the desired mode.
2. Make settings for the recording mode.
Adjusting the S level (MS stereo, 2ch/4ch surround modes)
You can adjust the stereo width (S level) before recording.
1. Use to adjust the stereo width.
NOTE
· The 4ch surround mode can only be used
when an SD card is in the unit.
· In 4ch surround mode, only WAV formats
(44.1/48kHz, 16/24bit) can be used.
· In 4ch surround mode, two stereo files are
created (MS mic recording and XY mic
recording).
NOTE
Set to OFF or between –24 and +6 dB.
Wide NarrowThe graphic changes along with the value

Recording Selecting where recordings are saved
13
H2n Handy Recorder
Selecting the recording mode
2. Use to select FOLDER, and then
press .
3. Use to select the folder where you want
to save files, and then press .
NOTE
Select from among 10 folders. There are separate sets of folders for stereo and 4ch recordings.
Selecting where recordings are saved
1. Press .
Using MS-RAW mode (MS stereo mode/WAV format only)
If you want to adjust the stereo width after recording, record using MS-RAW
mode.
1. Hold down until RAW appears.

Recording Setting the recording format
14
Setting the recording format
1. Press .
You can set the recording format according to your sound quality and file size
needs.
2. Use to select REC, and then press .
3. Use to select REC FORMAT, and then
press .
4. Use to select the recording format, and
then press .
NOTE
· Use WAV formats for higher audio quality.
· Use MP3 formats, which are compressed and have much smaller file sizes, to
save space on the SD card. Beware, however, that MP3 compression reduces
audio quality.

Recording Setting the recording format
15
H2n Handy Recorder
WAV96kHz/24bit
WAV96kHz/16bit
WAV48kHz/24bit
WAV44.1kHz/24bit
WAV48kHz/16bit
WAV44.1kHz/16bit
MP3 320kbps
MP3 256kbps
MP3 224kbps
MP3 192kbps
MP3 160kbps
MP3 128kbps
MP3 112kbps
MP3 96kbps
MP3 80kbps
MP3 64kbps
MP3 56kbps
MP3 48kbps
Only these formats
can be selected
when using 4ch
recording mode
Sound quality
High
File size
Large
SmallLow
Setting the recording format

Recording Recording manually
16
1. Turn to adjust the input level.
1
3
2, 4
HINT
· Adjust the MIC GAIN so that the peak level stays around -12 dB.
· If an input signal is too strong, the MS/XY indicator on the top will flash
immediately.
2. Press to start recording.
3. Press to add a mark.
4. Press to stop recording.
NOTE
· One file can have a maximum of 99 marks.
· During recording, if the size of the file exceeds 2 GB, recording will continue in
a new file that will be created automatically.
Recording manually

Playback Playing back recordings
17
H2n Handy Recorder
Playing back recordings
HINT
The longer you hold the PLAY control the faster it will
search in that direction.
2. Press and hold to return to the home
screen.
1. Press .
Use to jump between marks and files
Hold to search forward or backward
Press to pause and restart playback
Use to adjust the volume
1
1
2
Playback
You can play files in the current folder. Change the folder to play files in a
different folder.

Specifications
18
Specifications
Recording media 16MB–2GB SD cards, 4GB–32GB SDHC cards
(Cards that can be used with this recorder are to be verified individually)
Built-in memory Can be used to record up to 1 minute in 96 kbps MP3 format (recording to this memory
overwrites any previous recording in it)
Recording Mic arrangements MS stereo with adjustable side mic level
90º XY stereo
Modes MS, XY, MS+XY (stereo) and MS+XY (4ch)
Microphones Types Directional (XY, MS mid mics)
Bidirectional (MS side mic)
Maximum sound
pressure input
120 dB spl (directional)
122 dB spl (bidirectional)
File formats Stereo
Uncompressed PCM 44.1/48/96kHz, 16/24bit WAV (BWF)
Compressed MP3
(recording)
44.1kHz, 48/56/64/80/96/112/128/160/192/224/256/320kbps
(Not compatible with MS-RAW recording)
Compressed MP3
(playback)
44.1/48kHz, 32/40/48/56/64/80/96/112/128/160/192/224/256/
320kbps
4ch
Uncompressed PCM 44.1/48kHz, 16/24bit WAV (BWF)
Two stereo files for each recording
Digital processing A/D conversion 24-bit 128× oversampling
D/A conversion 24-bit 128× oversampling
Signal processing 32-bit
Recording time 2GB card example 3:08:00 (44.1kHz/16bit WAV)
34:43:00 (128kbps MP3)
Features LO CUT 80Hz high-pass filter
COMP/LIMITER 3 types of compressors and 3 types of limiters
AUTO GAIN Automatic input gain adjustment
PRE REC 2 seconds of pre-recording
AUTO REC Automatic recording start/stop, continuous standby
TUNER Chromatic, guitar, bass and alternate (A/E/G/D/DADGAD) tunings
with automatic string detection
METRONOME 40–250 BPM range, five tones, pre-count
SPEED Playback speed adjustable between 50–150%

Specifications
19
H2n Handy Recorder
Specifications
Features KEY CONTROL Playback pitch adjustable ±6 semitones (cannot be used with
96kHz files)
AB REPEAT Repeats playback between selected points in a file
FILE DIVIDE Divides a file into two
FILE NORMALIZE Maximizes file volume (cannot be used with MP3s)
FILE MP3 ENCODE WAV files can be converted to MP3 formats at fixed bit rates
MARK Up to 99 marks can be added as desired when recording WAV
files
SURROUND MIXER Mix balance can be adjusted when playing back 4ch surround
recordings
Display Graphic LCD (128×64 pixels) with backlight
Input gain 0 to +39 dB
Input jack Line/mic stereo mini jack can supply plug-in power
2 kΩ impedance at input levels of 0 to –39 dBm
Output jack Line/headphone stereo mini jack
Rated output level: −10 dBm (output impedance 10 kΩ or more)
Headphones: 20 mW + 20 mW (into 32 Ω load)
Built-in speaker 400mW, 8Ω, mono
USB Mini-B type
Card reader operation
USB 2.0 High Speed
Audio interface operation
USB 1.0 Full Speed
Supports 44.1/48kHz sampling rates and 16-bit rate
Note: Use a USB cable that supports data transfer.
Bus power operation supported
Power AD-17 USB to AC adapter (DC 5V 1A), operates using two AA batteries
Continuous operation of 20 or more hours when recording 44.1kHz/16-bit WAV files using
alkaline batteries
Physical features Tripod mounting socket, strap attachment
Dimensions (mm): 67.6 (W) × 113.85 (H) × 42.7 (D)
Weight: 130 g (without batteries)
* Recording concerts and public performances, for example, without permission from rights holders is prohibited by law.
* Product specifications and appearance might be changed for the purpose of improvement without warning.
* 0 dBm = 0.775 Vrms

Z2I-4054-01
ZOOM CORPORATION
4-4-3 Kanda-surugadai, Chiyoda-ku, Tokyo 101-0062 Japan
www.zoom.co.jp
