Zte Blade A51 User manual

1
ZTE Blade A51
Quick Start Guide
2
LEGAL INFORMATION
Copyright © 2021 ZTE CORPORATION.
All rights reserved.
No part of this publication may be quoted, reproduced,
translated or used in any form or by any means,
electronic or mechanical, including photocopying and
microfilm, without the prior written permission of ZTE
Corporation.
Notice
ZTE Corporation reserves the right to make
modifications on print errors or update specifications in
this guide without prior notice.
We offer self-service for our smart terminal device users.
Please visit the ZTE official website
(atwww.ztedevices.com) for more information on
self-service and supported product models. Information
on the website takes precedence.
Visit https://www.ztedevices.com to download the user
manual. Just click Support from the home page and then
select the location, product type, and name to search for
related support information.
Disclaimer
ZTE Corporation expressly disclaims any liability for
faults and damages caused by unauthorized
modifications of the software.
Images and screenshots used in this guide may differ
from the actual product. Content in this guide may differ
from the actual product or software.
Trademarks
ZTE and the ZTE logos are trademarks of ZTE
Corporation.
Android™ is a trademark of Google LLC.
The Bluetooth® word mark and logos are
registeredtrademarks owned by the Bluetooth SIG, Inc.
and any use of such marks by ZTE Corporation is under
license.
microSDXC Logo is a trademark of SD-3C, LLC.
3
Other trademarks and trade names are those of their
respective owners.
Version No.: R1.0
Edition Time :February 26, 2021
4
Getting to Know Your Phone
Front camera
Touch screen
Earpiece
Proximity &
light sensor
Volume key
Power key
Headset jack
Dual-lens
camera
Speake
r
Indicator light
nano-SIM/
microSDXC
card tray
Flash Fingerprint
sensor
Charging/USB
Type-C jack

5
Setting Up Your Phone
The nano-SIM card(s) can be installed or removed while
the phone is turned on.
WARNING!
To avoid damage to the phone, do not use any other kind
of SIM cards, or any non-standard nano-SIM card cut
from a SIM card.You can get a standard nano-SIM card
from your service provider.
1. Insert the tip of the tray eject tool into the hole on
the card tray.
CAUTION:
Never replace the included tray eject tool with sharp
objects. Ensure that the tray eject tool is perpendicular to
the hole. Otherwise, the phone may be damaged.
6
2. Pull out the card tray. You can place a nano-SIM card
on the right card slot, and place a nano-SIM card or a
microSDXC card(optional) on the left card slot, as
shown. Carefully slide the tray back into place.
NOTE:
If two nano-SIM cards are installed, both cards can
connect to the 4G, 3G, or 2G network, and either card can
be used for mobile data.
Charging the Phone
Your phone’s battery should have enough power for the
phone to turn on, find a signal, and make a few calls.You
should fully charge the battery as soon as possible.
WARNING!
Use only ZTE-approved chargers and USB Type-C cables.
The use of unapproved accessories could damage your
phone or cause the battery to explode.
WARNING!
Do not remove the back cover. The battery is not
removable. Removal may cause fire or explosion.
1. Connect the adapter to the charging jack.
7
2. Connect the charger to a standard AC power outlet.
3. Disconnect the charger when the battery is fully
charged.
NOTE:
If the battery is extremely low, you may be unable to
power on the phone even when it is being charged. In this
case, try again after charging the phone for at least 20
minutes. Contact the customer service if you still cannot
power on the phone after prolonged charging.
Powering On/Off Your Phone
Make sure the battery is charged before powering on.
• Press and hold the Power key to turn on your phone.
• To power off, press and hold the Power key to open
the options menu, and touch >.
NOTE:
If the screen freezes or takes too long to respond, try
8
pressing and holding the Power keyfor over10seconds to
restart the phone.
Waking Up Your Phone
Your phone automatically goes into sleep mode when it
is not in use for some time. The display is turned off to
save power and the keys are locked to prevent accidental
operations.
You can wake up your phone by turning on the display
and unlocking the keys.
1. Press the Power keyto turn the screen on.
2. Swipe up on the screen.
NOTE:
If you have set a fingerprint, an unlock pattern, a PIN or a
password for your phone, you’ll need to use your
fingerprint, draw the pattern, or enter the PIN/password
to unlock your screen.

9
Product Safety Information
Don’t make or receive phone calls while
driving. Never text while driving.
Keep your phone at least 15 mm away from
your body while making calls.
Small parts may cause choking.
Your phone can produce a loud sound.
To prevent possible hearing damage, do not
listen at high volume levels for long periods.
Exercise caution when holding your phone
near
y
our ear while the louds
p
eaker is in use.
Avoid contact with anything magnetic.
Keep away from pacemakers and other
electronic medical devices.
Turn off when asked to in hospitals and
medical facilities.
Turn off when told to on aircraft and at
airports.
Turn off when near explosive materials or
liquids.
Don’t use at gas stations.
Your phone may produce a bright or flashing
light.
Don’t dispose of your phone in fire.
Avoid extreme temperatures.
10
Avoid contact with liquids. Keep your phone
dry.
Do not attempt to disassemble your phone.
Only use approved accessories.
For pluggable equipment, the socket-outlet
shall be installed near the equipment and
shall be easily accessible.
Don’t rely on your phone as a primary device
for emergency communications.
Specific Absorption Rate (EU SAR)
Your mobile device is a radio transmitter and receiver. It
is designed not to exceed the limits for exposure to radio
waves recommended by international guidelines. These
guidelines were developed by the independent scientific
organization ICNIRP and include safety margins designed
to assure the protection of all persons, regardless of age
and health.
The guidelines use a unit of measurement known as
Specific Absorption Rate, or SAR. The SAR limit for
mobile devices is 2 W/kg and the highest SAR value for
this device when tested at the head was 0.339 W/kg*, and
when tested at the body was 1.614W/kg* with 5 mm
distance. As mobile devices offer a range of functions,
they can be used in other positions, such as on the body
as described in the user manual**.
As SAR is measured utilizing the device’s highest
transmitting power, the actual SAR of this device while
operating is typically below that indicated above.This is
due to automatic changes to the power level of the
device to ensure it only uses the minimum power
required to communicate with the network.
11
* The tests are carried out in accordance with EN 50360,
EN 50566, EN50663, EN 62209-1 and EN 62209-2.
** Please see body worn operation in the user manual.
Specification
EUT
testedradios
application
GSM900/1800
WCDMA Band 1,8
FDD LTE Band 1,3,7,8,20
802.11b/g/n
BluetoothV5.0+EDR/LE
GPS
WCDMA Version Rel.9
LTE Version Rel.12
Maximum RF
output power
GSM900: 32.73dBm
GSM1800: 29.36dBm
WCDMA Band 1: 24.4dBm
WCDMA Band 8: 23.9dBm
FDD LTE Band 1: 24.3dBm
FDD LTE Band 3: 24.3dBm
FDD LTE Band 7: 23.9dBm
FDD LTE Band 8: 24.6dBm
FDD LTE Band 20: 24.7dBm
802.11b/g/n: 16.94dBm
Bluetooth EDR: 6.05dBm
Bluetooth LE: 8.68 dBm
GPS(RX Only)
CE Caution
Battery Caution
• There is a risk of explosion if battery is replaced by
an incorrect type.
• Dispose of used batteries according to the
instructions.
• Do not dispose of a battery into fire or a hot oven, or
mechanically crush or cut a battery.Doing so can
result in an explosion.
12
• Leaving a battery in an extremely high temperature
surrounding environment can result in an explosion
or the leakage of flammable liquid or gas.
• A battery subjected to extremely low air pressure
may result in an explosion or the leakage of
flammable liquid or gas.
USB Port
This product shall only be connected to a USB interface
of version USB2.0.
Proper Use
As described in this guide, your device can be used only in
right location. If possible, please do not touch the
antenna area on your device.
Do not expose your device to extreme temperatures
lower than -10 °C and higher than + 45°C.

Disposal of Y
o
1
2
3
For this product
’
directive, pleas
e
13
o
ur Old Appliance
1
. When this crossed-o
u
symbol is attache
d
means the produ
c
the European Dir
e
2
. All electrical and ele
c
should be dispose
from the municip
a
via designated col
appointed by the
g
the local authoriti
e
3
. The correct disposal
appliance will hel
p
potential negativ
e
for the environm
e
health.
’
s recycling informati
o
e
send an e-mail to we
e
u
t wheeled bin
d
to a product, it
c
t is covered by
e
ctive 2012/19/EU.
c
tronic products
d of separately
a
l waste stream
lection facilities
g
overnment or
e
s.
of your old
p
prevent
e
consequences
e
nt and human
o
n based on WEEE
e
[email protected].cn
14
EU DECLARATION OF CONFORMITY
Hereby, ZTE Corporation declares that the radio
equipment type ZTE Blade A51 is in compliance with
Directive 2014/53/EU.
The full text of the EU declaration of conformity is
available at the following Internet address:
https://certification.ztedevices.com
ErP Conformity
The external power supply of this product conforms to
the Energy-related Product Directive (ErP) 2009/125/EC
of the European Parliament and the Council.
The detailed ErP information is available on ZTE website
https://certification.ztedevices.com.
RF Exposure Information (FCC SAR)
This phone is designed and manufactured not to exceed
the emission limits for exposure to radio frequency (RF)
energy set by the Federal Communications Commission
of the United States.
During SAR testing, this device was set to transmit at its
highest certified power level in all tested frequency bands,
and placed in positions that simulate RF exposure in
usage against the head with no separation, and near the
body with the separation of 15 mm. Although the SAR is
15
determined at the highest certified power level, the
actual SAR level of the device while operating can be well
below the maximum value.This is because the phone is
designed to operate at multiple power levels so as to use
only the power required to reach the network. In general,
the closer you are to a wireless base station antenna, the
lower the power output.
The exposure standard for wireless devices employing a
unit of measurement is known as the Specific Absorption
Rate, or SAR.The SAR limit set by the FCC is 1.6 W/kg.
This device is complied with SAR for general
population/uncontrolled exposure limits in ANSI/IEEE
C95.1-1992 and had been tested in accordance with the
measurement methods and procedures specified in
IEEE1528.
The FCC has granted an Equipment Authorization for this
model phone with all reported SAR levels evaluated as in
compliance with the FCC RF exposure guidelines. SAR
information on this model phone is on file with the FCC
and can be found under the Display Grant section of
www.fcc.gov/oet/ea/fccid after searching on FCC ID:
SRQ-ZTEA51V. The FCC ID also can be found on the
device when you open Settings >About phone > FCC ID.
For this device, the highest reported SAR value for usage
against the head is 0.651 W/kg, and for usage near the
body is 0.823 W/kg.
While there may be differences between the SAR levels
of various phones and at various positions, they all meet
the government requirements.
SAR compliance for body-worn operation is based on a
16
separation distance of 15 mm between the unit and the
human body. Carry this device at least 15 mm away from
your body to ensure RF exposure level compliant or lower
to the reported level. To support body-worn operation,
choose the belt clips or holsters, which do not contain
metallic components, to maintain a separation of 15 mm
between this device and your body.
RF exposure compliance with any body-worn accessory,
which contains metal, was not tested and certified, and
using such body-worn accessory should be avoided.
FCC Regulations
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2)
this device must accept any interference received,
including interference that may cause undesired
operation.
CAUTION:
Changes or modifications not expressly approved by the
manufacturer could void the user’s authority to operate
the equipment.
Co-location of this product with other transmitters that
operate simultaneously are required to be evaluated
using the FCC multi-transmitter procedures.
NOTE:
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to

17
part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause
harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV
technician for help.
