Zte CDMA 2000 1X User manual

ZTE-C X769
CDMA 2000 1X Digital Mobile Phone
User Manual
The manual is applicable for X769mobile phone.

Copyright ©2010 by ZTE Corporation
All rights reserved.
No part of this publication may be excerpted, reproduced, translated or
utilized in any form or by any means, electronic or mechanical, including
photocopying and microfilm, without the prior written permission of ZTE
Corporation.
ZTE Corporation reserves the rightto make modifications on print errors or
update specifications in this manual without prior notice.
Version 1.0 in Mar. 2010

Contents
Before Use...................................................................................................................1
Safety Instructions ...................................................................................................1
Precautions for using the mobile phone..........................................................2
Precautions for using the battery.....................................................................5
Precautions for using the charger ...................................................................7
Parts Definition ........................................................................................................9
Insert and Remove Memory Card .........................................................................12
Battery....................................................................................................................13
Install the battery ...........................................................................................13
Remove the battery .......................................................................................13
Charge the battery.........................................................................................14
Power On/Off.........................................................................................................15
Enter 3D Interface.....................................................................................................16
Communication ........................................................................................................18
Dial.........................................................................................................................18

Make a call.....................................................................................................18
Answer calls...................................................................................................19
Call Options...................................................................................................19
Messages ..............................................................................................................20
Send New......................................................................................................20
My Movilnet space.........................................................................................21
View Message ...............................................................................................21
Settings..........................................................................................................21
Memory Info...................................................................................................23
Voice Mail ......................................................................................................23
Contacts.................................................................................................................24
All List ............................................................................................................24
Find................................................................................................................24
Add Entry.......................................................................................................24
Groups...........................................................................................................25
Speed Dials....................................................................................................25
Memory Status...............................................................................................26
Call History ............................................................................................................26

Application................................................................................................................27
Settings..................................................................................................................27
Display...........................................................................................................27
Call.................................................................................................................27
Security..........................................................................................................30
Extras.............................................................................................................31
Pen Calibration ..............................................................................................32
Profiles...................................................................................................................33
Organizer...............................................................................................................33
Games ...........................................................................................................33
Alarm..............................................................................................................33
Scheduler.......................................................................................................34
Stopwatch ......................................................................................................34
Calculator.......................................................................................................34
Unit Conversion .............................................................................................35
World Time.....................................................................................................35
Neo Aplic................................................................................................................35
Entertainment ...........................................................................................................36

Media Player..........................................................................................................36
Multimedia .............................................................................................................37
Camera..........................................................................................................37
Camera Recorder..........................................................................................37
Radio..............................................................................................................38
Record ...........................................................................................................38
My Doc...................................................................................................................38
Neo Nave...............................................................................................................39
Dial-up Internet Access ...........................................................................................40
Input Methods...........................................................................................................41
Handwriting Input...................................................................................................41
Virtual Keypad Input ..............................................................................................42
Appendix ...................................................................................................................44
Clearance and Maintenance .................................................................................44
Failure Analysis......................................................................................................46
Health and Safety Information...............................................................................47
FCC Regulations ...................................................................................................50

Declaration of RoHS Compliance..........................................................................51

錯誤! 使用 [常用] 索引標籤將 标题 1 套用到您想要在此處顯示的文字。
1
Before Use
Thank you for choosing ZTE-C X769 digital mobile phone. (Shortly referred
to as “Mobile Phone”)
To guarantee your mobile phone is always in its best condition, please read
this manual carefully and keep it for future reference.
The pictures in this user manual are only used to demonstrate the mobile
phone‟s functions, so they may be different from what you see on your
mobile phone.
Safety Instructions
If your mobile phone is lost or stolen, notify your service provider
immediately to prevent others from abusing it. To protect your mobile
phone against abuse, take the following precautions:
Set a phone lock code and modify it from time to time.
Keep your mobile phone with you at all times.

錯誤! 使用 [常用] 索引標籤將 标题 1 套用到您想要在此處顯示的文字。
2
Precautions for using the mobile phone
Road Safety
Pay attention to road safety and follow all local relevant laws and
regulations while driving.
Interference
Do not use your mobile phone near sensitive electronic equipment.
Radio wave interference may cause electronic equipment to
malfunction. Pay special attention when you use your mobile phone
near audio-phones, pacemakers and/or other medical electronic
equipment, fire detectors, automatic-doors and/or other
automatic-control equipment. For details on the influence caused by
your mobile phone on pacemakers or other medical electronic
equipment, please consult the manufacturer or your local distributor.
Do not use your mobile phone near TV sets, radios or office automated
equipment to avoid interference.

錯誤! 使用 [常用] 索引標籤將 标题 1 套用到您想要在此處顯示的文字。
3
On an Aeroplane
Turn off your mobile phone on anaeroplane when use is forbidden. The
mobile phone may affect the normal operation of electronic devices,
therefore please follow the relevant regulations when using your mobile
phone on an aeroplane.
In Hospital
Turn off your mobile phone in hospital where it‟s forbidden to use it. The
mobile phone may affect the normal operation of medical apparatus,
therefore please follow the relevant regulations when using your mobile
phone in hospital.
At the Petrol Station
Do not use your mobile phone in petrol station. Turn off your mobile
phone near fuels or chemicals.

錯誤! 使用 [常用] 索引標籤將 标题 1 套用到您想要在此處顯示的文字。
4
Waterproof
Keep your mobile phone away from water. This may cause overheating,
electrical leakage or failure if water or any other kind of liquid enters
your mobile phone.
Disassemble
Do not disassemble or reassemble your mobile phone as this may
cause damage, electrical leakage or circuit failure.
Antenna
Do not use your mobile phone if your antenna is damaged as this may
cause bodily harm.
Away from Children
Keep your mobile phone from children. Do not allow children to use the
mobile phone as a toy as this may be harmful to their health.

錯誤! 使用 [常用] 索引標籤將 标题 1 套用到您想要在此處顯示的文字。
5
Original Accessories
Use the original accessories or those authenticated by the
manufacturer. Using non-original accessories may affect the mobile
phone‟s performance, violate the warranty provisions or relevant
national regulations on mobile phones, or even cause bodily harm.
Areas where industrial explosives are used
Please strictly adhere to relevant laws and regulations to turn off your
mobile phone in or near areas where explosive materials are used.
Emergency Calls
Make sure your mobile phone is turned on and in the service area. Input
the national emergency number and press the Send key to dial. Let
others know where you are and do not hang up help has reached you.
The working temperature is 0~40℃,so don‟t operate it outside the range.
Operation under too high or too low temperature might cause problems.

錯誤! 使用 [常用] 索引標籤將 标题 1 套用到您想要在此處顯示的文字。
6
Precautions for using the battery
Put the battery in a cool and ventilated place where there is no direct
sunshine.
The battery life is usually limited, and it becomes shorter and shorter
after the battery is charged over and over again. If the charging fails
several times, this indicates that the battery is worn out and the
replacement is advised.
Dispose the worn-out batteries in designated places according to
specified regulations rather than throw them into residential garbage.
Do not throw the worn-out batteries into fire because this might cause
fire or explosion.
Do not press with great force when installing the battery because this
may result in leakage, overheating, explosion or fire.
Do not disassemble or reassemble the battery because this may result
in leakage, overheating, explosion or fire.
If the battery becomes hot, changes in color or gets deformed during the
course of use, charging or storage, please immediately stop using and
replace it.

錯誤! 使用 [常用] 索引標籤將 标题 1 套用到您想要在此處顯示的文字。
7
Keep the battery away from dampness to prevent overheating,
smoldering or erosion.
Do not leave the battery in direct sunshine, around a car or
high-temperature place because this might result in leakage or overheating.
This might affect the battery‟s performance and shorten its life.
Do not keep charging the battery continuously over 24 hours.
Note:
If the battery is damaged, please avoid contacting the materials in it. If
your skin has contacted those materials, flush your skin with lots of
water and seek for help from doctors if necessary.
Precautions for using the charger
Use the power voltage between 110VAC and 220VAC. Using the
voltage beyond the range may cause leakage, fire or damage to the
phone and charger.
Do not short-circuit the charger because this might cause electric shock,
smoldering or damage.

錯誤! 使用 [常用] 索引標籤將 标题 1 套用到您想要在此處顯示的文字。
8
Do not charge the battery in direct sunshine, near dampness, dust,
vibration, TV set, or radio (may affect the image, sound), etc.
Do not use the charger if the power cable is damaged because this
might cause fire or electric shock.
Do not place water containers near the charger to avoid water splashing.
If water or any other kind of liquid splashes on the charger, immediately
remove the charger from the power socket to avoid overheating, fire,
electric shock or failure.
Do not disassemble or reassemble the charger because this might
cause body injury, electric shock, fire or damage.
Do not touch any charger, power cable or power socket with wet hands
to avoid electric shock.
Do not place heavy objects onto power cables or refit power cable
because this might cause electric shock or fire.
Remove power plug from the socket before cleaning and maintenance.
Hold the charger rather than pull the power cable while removing the
plug from the socket because this might cause damage, electric shock
or fire.

錯誤! 使用 [常用] 索引標籤將 标题 1 套用到您想要在此處顯示的文字。
9
Parts Definition
Receiver
End/Power key
Left/right soft key
Send key
Navigation keys and OK key
Execute the operations at the
left-down/right down corner of
the screen.
Dial a number or receive
incoming calls; in idle mode,
press the key to view recent calls.
In idle mode:
Up key: Shortcut key
Down key: Messages
Left key: Brew
Right key: movilnet
OK key: Main menu
IPress and hold Down key to
quickly activate or deactivate
“Silent”mode.
Display

錯誤! 使用 [常用] 索引標籤將 标题 1 套用到您想要在此處顯示的文字。
10
Note:
In this user manual, “press”means pressing the key and then
releasing; “hold”means pressing and holding the key for about 2
seconds or more; “click”means clicking the corresponding icon on
the screen with touch-pen.
Side keys
Adjust the volume
Speaker
Camera

錯誤! 使用 [常用] 索引標籤將 标题 1 套用到您想要在此處顯示的文字。
11
Descriptions of icons on the status bar
Icons
Descriptions
Icons
Descriptions
Signal strength
Battery capacity
indication
Unread message
Vibrate
Ring and vibrate
Alarm ON
Messages full
New voice message
Mute
In roaming
Insert the headset
1X Internet access
Keypad locked
Calling or in a call
Memory card inserted
Conversation
encrypted

錯誤! 使用 [常用] 索引標籤將 标题 1 套用到您想要在此處顯示的文字。
12
Insert and Remove Memory Card
1. Turn off your mobile phone, remove the battery and disconnect the
external power.
2. Open the clasp in the direction of arrow as shown.
3. Insert the memory card into the slot.
4. Close the clasp.
5. Secure the clasp in the direction of arrow as shown.
Followthe converse steps to remove the card. Turn off your mobile phone
before taking out the memory card.
