Zte Charm Ring R1 User manual

Telecom R1 Mobile Phone
User Manual
Copyright © 2011. All rights reserved.
No part of this publication may be excerpted, reproduced, translated or utilized in any
form or by any means, electronic or mechanical, including photocopying and
microfilm, without the prior written permission of ZTE Corporation.
The manual is published by ZTE Corporation. We reserve the right to make
modifications on print errors or update specifications without prior notice.
Version 1.0 October 2011

Warnings and Safety Notices
Please read all the safety notices before using this device.
Do not use the phone near fuel or chemicals or in any prescribed area such as
service stations and refineries.
Do not transport or store flammable gas, liquid or explosives in the same
compartment of your vehicle as your mobile phone and accessories.
Limitation of Liability
ZTE shall not be liable for any loss of profits or indirect, special, incidental or
consequential damages resulting from or arising out of or in connection with using
this product, whether or not ZTE had been advised, knew or should have known the
possibility of such damages. The user should refer to the enclosed warranty card for
full warranty and service information.
Declaration of Conformity - SAR (Specific Absorption Rate)
We declare that the product(s) detailed in this manual, and in combination with
our accessories, conform with the essential requirements of The Radio
Communications Standard (Electro-magnetic Radiation Human Exposure)
2003 and the Australian Communications and Media Authority Section 376 of
the Telecommunications Act 1997. The highest SAR value recorded is 0. 539
W/Kg at GSM 900 MHz.

N14945 / Z1196. Contents
RF Safety Information..........................................................................................5
Handset Overview................................................................................................6
Information Bar Icons..........................................................................................8
Menu Quick Reference Guide.............................................................................9
1Getting Started ...........................................................................12
1.1 Insert the (U)SIM Card..............................................................12
1.2 Insert the battery.......................................................................14
1.3 Switch the phone On or Off ......................................................15
1.4 Charge your phone...................................................................15
1.5 Tips to maximise battery life .....................................................16
1.6 How do I set the time and date?...............................................17
1.7 How to make a voice call..........................................................17
1.8 How to answer an incoming call...............................................18
1.9 How to navigate the Menu........................................................18
1.10 How to change your Ringtone ..................................................19
1.11 How to configure Shortcuts.......................................................19
1.12 How to send a Text Message (SMS) ........................................20
1.13 Call Features Summary............................................................20
2Contacts......................................................................................24

3Messages and Emails................................................................28
3.1 How to send a Text Message (SMS)........................................28
3.2 How to view a received Text Message (SMS)..........................29
3.3 How to use Predictive Text.......................................................29
3.4 How to add words to the built in Dictionary (My Words)..........31
3.5 Special Characters and SMS Message Length .......................31
3.6 How to send a Multimedia Message (MMS) ............................32
3.7 How to receive a Multimedia Message (MMS) ........................33
3.8 WAP Push Messages...............................................................33
3.9 How to send an Email...............................................................34
3.10 How to retrieve an Email ..........................................................35
3.11 How to set up automatic Email Retrieval .................................36
3.12 What are User Folders? ...........................................................36
3.13 How to create a new Mailbox...................................................37
4Handset Features & Applications .............................................38
5Installing the Join Me Computer suite......................................45
6Troubleshooting, Technical and Warranty Information ...........46
6.1 Troubleshooting and FAQ’s......................................................46
6.2 Error Messages ........................................................................51
6.3 Technical Parameters...............................................................52
6.4 Support Information..................................................................53

6.5 Warranty Information ................................................................53
RF Safety Information
The handset has an internal antenna located at the top of the phone. For
optimum performance with minimum power consumption do not cover the
antenna area with your hand. Hold the handset between thumb and finger in
the middle of the device. Covering the antenna affects call quality, may cause
the handset to operate at higher power level than needed, and may shorten
talk and idle times.
Radio Frequency Energy
The handset is a low-power radio transmitter and receiver. When switched on it
intermittently transmits radio frequency (RF) energy (radio waves). The
transmit power level is optimized for best performance and automatically
reduces when there is good quality reception. Maximum power is only used at
the edge of network coverage so under most circumstances the power output
is very low. Under poor network conditions the phone transmits at a higher
power, may get hot and have a significantly shorter battery life.

Handset Overview
Left & Right Soft Keys
Performs the function
shown on the display
Power / End Key
Hold down to power
On or Off.
Press to End a call.
Display
C Key
Step back in menus.
Clear text.
Earpiece
*Key
Lock / Unlock the keypad.
Access text symbols.
Insert a Pause or Wait
command.
# Key
Switch to Meeting
Mode
Change text modes
Camera key
Speaker key

Handset Overview
Side View Home Screen
Call Key
Call a number, answer a
call, show Call History
Left soft
key
for
Contacts
Volume Up & Down
Power, USB and
Headset port
OK key for
Main Menu
Right soft key
for TWorld
Signal bars
Battery
level

Information Bar Icons
3G Signal Strength
Battery Level Indicator
GSM Signal Strength
Alarm is set
New SMS Message
Missed Call
Message Memory is Full
Missed Video Call
New MMS Message
Bluetooth ON
CTM
Silent Mode
New E-mail
Vibrate mode enabled
Headset and Vibrate Mode
Call Forward is Active
New Wap Push Message
Data channel available (GPRS)
Headset Mode
Data channel active (PDP)

GPS
Roaming
Menu Quick Reference Guide

Menu Quick Reference Guide Continued…
